Summary of Contents for Dometic TURBO DX AC
- Page 1 ENGLISH Dometic turbo Direct expansion air conDitioninG sYstems installation manual Dometic Environmental Corporation Rev. 5-30-07 L-2484...
-
Page 3: Table Of Contents
Dometic turbo Dx ac installation manual contents introduction installation Safety Considerations (Dangers, Warnings & Cautions) Prior To Installation Installation Overview Blower Rotation Placement of A/C Unit Mounting Brackets Condensate Drain Grills and Transition Boxes Ducting Seawater System Electrical Connections, Grounding and Bonding... -
Page 4: Introduction
4414 , or email sales@DometicEnviro.com. Please see the separate control operation manuals for installation of digital or mechanical controls. Turbo a/c units are covered under the existing Dometic Environmental Corpora- tion (Dometic) warranty policy contained in the corresponding control manual. -
Page 5: Safety Considerations (Dangers, Warnings & Cautions)
Dometic turbo a/c systems Very important safety considerations: Never install your air conditioner in the bilge or engine room areas. Ensure that the selected location is sealed from direct access to bilge and/or engine room vapors. Do not terminate condensate drain line within three feet of any outlet... - Page 6 Dometic turbo a/c systems FIGURE 1. Installation overview enGlisH...
-
Page 7: Mounting Brackets
Dometic turbo a/c systems 4. Route condensate drain hose to a sealed conden- sate or shower sump pump (see note below). 5. Drain hose must be routed downward to allow water to flow via gravity downhill. Very important! Do not terminate condensate drain line within 3' (.91M) of any outlet of engine or... - Page 8 Dometic turbo a/c systems FIGURE 3. Placement relating to Airflow enGlisH...
- Page 9 Dometic turbo a/c systems FIGURE 4. Mounting brackets and condensate drain enGlisH...
-
Page 10: Seawater System
Dometic turbo a/c systems as straight, smooth and taut as possible minimizing all ducting should: the number of 90° bends (two 90° bends can reduce airflow by 25%). The table in Figure 5 shows minimum • Be appropriately sized for each application. - Page 11 Dometic turbo a/c systems FIGURE 6. Proper ducting connections from any foreign matter. Failure to install a seawater however the discharge must always be above the strainer will void the pump and unit warranty. inlet. Pump head should be rotated toward the direc- tion of water flow.
- Page 12 Dometic turbo a/c systems The following is a summary of the seawater system 5/8" (15.9mm) reinforced marine grade hose. Connect installation: the discharge from the condenser coil to the over- board discharge thru-hull fitting with 5/8" (15.9mm) 1. Install the seawater scoop thru-hull inlet as close to reinforced marine grade hose.
- Page 13 Dometic turbo a/c systems FIGURE 7. Seawater system enGlisH...
-
Page 14: Electrical Connections, Grounding And Bonding
Dometic turbo a/c systems electrical connections, Grounding and 2. Connections between the vessel’s AC system grounding conductor (green wire) and the vessel’s DC bonding (Direct Current) negative or bonding system should All a/c units have a terminal strip mounted inside the be made as part of the vessel’s wiring, per ABYC... -
Page 15: Installation Checklist And Final Inspection
Grills and Ducting call Dometic with the unit part number, serial number, and wiring diagram number, all of which are located • Supply air grill mounted as high as possible on the unit data plate. - Page 16 Dometic environmental corporation 2000 N. ANDREWS AVE. EXT. I POMPANO BEACH, FL 33069 USA I 954-973-2477 I FAX 954 979 4414 P.O. BOX 15299 I RICHMOND, VA 23227 USA I 804-746-1313 I FAX 804-746-7248 www.DometicEnviro.com I sales@DometicEnviro.com uniteD states & canaDa serVice onlY...
