Follett Horizon Elite HCD1410RBT Manual

Features
Horizon Elite
1010 series - up to 978 lb (444 kg) in 24 hours
1410 series - up to 1372 lb (623 kg) in 24 hours
- automatically transport ice through a tube with RIDE
technology from up to 75' (22.9 m) away
- chewable, compressed nugget ice is preferred over cubes¹
- ice dispenses reliably from ice and beverage dispensers
- available with approximately 1.00" (2.54 cm) long
standard Chewblet ice or optional 3/8" (0.95 cm) long
Micro Chewblet ice
™
- quiet production without noisy harvest cycles
Revolutionary, scale inhibiting design
- produces ice that has 15% the TDS of the incoming water
for optimum dispensing and long life in drinks
- quarantines and regularly expels scale producing
dissolved solids to dramatically reduce scale buildup
- increases time between descaling and reduces or
eliminates the need for expensive scale treatment
- saves 35% water compared to comparable cubers
- three phase HCF1010 models ENERGY STAR
Durable, attractive ice machine
- regular bearing inspection or replacement is not required
- upgraded, easy-to-read LED operating status and
diagnostic display
Designed with sanitation in mind
- Agion® silver-based antimicrobial product protection of
key ice and water contact components²
- floatless, sealed design inhibits formation of biofilms
- semi-automatic cleaning and sanitizing system
Warranty
- 3 years parts and labor, 5 years compressor parts ³
Certifications
Independent third party studies. Contact Follett for details.
1
Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.
2
³ Refer to price list for additional warranty information.
remote 1010, 1410 series Chewblet
Short form specification:
Ice machine to be a Follett
______________ [Insert size/series, condenser type and installation/mount-
ing, from model number guide] capable of producing compressed nugget
ice using an efficient, sanitary horizontal evaporator/auger system and
delivering ice by a flexible wire reinforced transport tube to
ice storage bin,
drop-in dispenser or
evaporator with utility docking station, front-mounted unit status display,
evaporator water inlet at harvest end with automatic flush while producing
®
ice, and semi-automatic cleaning and sanitizing system, plus all the features
listed below and mounting/performance-enhancing accessories checked.
Model configurations
For use with ¹
ice storage bin
Follett Vision
undercounter
ice and beverage
dispenser
Cornelius PR150
certified
®
undercounter ice
and beverage
dispenser
countertop ice
and beverage
dispenser
(by others)
drop-in
dispenser
(by others)
Ice Manager
diverter
valve system
Ordered separately
1
Not compatible with Micro Chewblet ice
2
Requires top kit (see page 5 for part number)
3
4 For three phase remote condensing unit, replace third character (D) with F
e.g. HCF1010RBT
For Micro Chewblet ice, replace second character (C) with an M
5
e.g. HMD1010RBT
801 Church Lane | Easton, PA 18040, USA
1.800.523.9361 | 1.610.252.7301 | follettice.com
Horizon Elite
Horizon Elite ice machine model
®
ice and water dispenser,
Ice Manager
™
Install/mount Condenser V/Hz/Ph
with
top mount
without
with
RIDE
without
™
with
RIDE
without
with
RIDE
without
2
with
top mount
3
without
with
RIDE
without
with
RIDE
without
with
RIDE
without
ice machine
®
ice and beverage dispenser,
diverter valve system, slide-out
Item number Item number
5
1010 series 1410 series
115/60/1 HCD1010RBT HCD1410RBT
4
115/60/1 HCD1010NBT HCD1410NBT
115/60/1 HCD1010RBS HCD1410RBS
4
115/60/1 HCD1010NBS HCD1410NBS
115/60/1 4 HCD1010RVS HCD1410RVS
115/60/1 HCD1010NVS HCD1410NVS
115/60/1 HCD1010RPS HCD1410RPS
4
115/60/1 HCD1010NPS HCD1410NPS
115/60/1 HCD1010RHT HCD1410RHT
4
115/60/1 HCD1010NHT HCD1410NHT
115/60/1 4 HCD1010RHS HCD1410RHS
115/60/1 HCD1010NHS HCD1410NHS
115/60/1 HCD1010RJS HCD1410RJS
4
115/60/1 HCD1010NJS HCD1410NJS
115/60/1 HCD1010RMS HCD1410RMS
4
115/60/1 HCD1010NMS HCD1410NMS
™
5
