PRIUS PRIME_OM_OM47D13U_(U)

Search by illustration

Make sure to read through them

Plug-in hybrid system features, charging method,

etc.

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for

driving

Usage of the interior features, etc.

Caring for your vehicle and maintenance

procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners, and seat

belt, SRS airbag and headlight aim instructions for

Canadian owners

Search by symptom

Search alphabetically

Table of Contents

Summary of Contents for Toyota PRIUS PRIME 2019

Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Plug-in hybrid Plug-in hybrid system features, charging method, system etc. Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component...
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 2-2. Charging Reading this manual ....14 Charging equipment ..108 How to search......15 Charging cable ....113 Pictorial index ......16 Smart lid & connector locking system....119 For safety and security Power sources that can be used.........
Page 3 Operation of each Driving component 4-1. Key information 5-1. Before driving Keys ........270 Driving the vehicle ..... 314 Cargo and luggage .... 326 4-2. Opening, closing and locking the doors Vehicle load limits....329 Side doors ......275 Trailer towing ..... 330 Back door ......
Page 4 TABLE OF CONTENTS 5-5. Using the driving support Interior features systems Toyota Safety Sense P ..369 PCS (Pre-Collision 6-1. Using the air conditioning System)......377 system and defogger LDA (Lane Departure Automatic air conditioning Alert with steering system (vehicles with control) ......
Page 5 6-4. Using the other interior Maintenance and care features Other interior features ..539 • Sun visors ..... 539 7-1. Maintenance and care • Vanity mirrors....539 Cleaning and protecting • Power outlets ....540 the vehicle exterior ..562 •...
Page 6 TABLE OF CONTENTS When trouble arises Vehicle specifications 8-1. Essential information 9-1. Specifications Emergency flashers ..650 Maintenance data (fuel, oil level, etc.) ..716 If your vehicle has to be stopped in an Fuel information....725 emergency ...... 651 Tire information....
Page 7 Index What to do if... (Troubleshooting) ....768 Alphabetical index...... 772 For information regarding the equipment listed below, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. • Navigation system • Hands-free system • Audio system (for cellular phone) • Rear view monitor system PRIUS PRIME_OM_OM47D13U_(U)
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 Usage of data collected through Safety Connect (U.S.mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 PRIUS PRIME_OM_OM47D13U_(U)
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 772 Searching installation ■ position • Pictorial index....P. 16 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 768 Searching by title ■ • Table of contents .....P. 2 PRIUS PRIME_OM_OM47D13U_(U)
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 275 Locking/unlocking .
Page 17 Pictorial index Fuel filler door ........P. 364 Refueling method.
Page 18 Pictorial index ■ Instrument panel IOPPH012 Power switch ........P. 332 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 213 Display ......... . . P. 213 Energy monitor .
Page 20 Pictorial index ■ Switches Instrument cluster light control switch ....P. 190 S-APGS (Simple Advanced Parking Guidance System) switch ......... P. 454 VSC OFF switch .
Page 21 Pictorial index TRIP switch........P. 206 Audio remote control switches Meter control switches .
Page 22 Pictorial index ■ Interior IOPPH014 SRS airbags ........P. 36 Floor mats .
Page 23 Pictorial index Inside rear view mirror ......P. 304 Sun visors ........P. 539 Vanity mirrors.
Page 24 Pictorial index PRIUS PRIME_OM_OM47D13U_(U)
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......36 Front passenger occupant classification system ..50 Exhaust gas precautions..56 1-2. Child safety Riding with children..... 57 Child restraint systems..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 32 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 33 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 34 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 35 1-1. For safe use NOTICE ■ When using a seat belt extender When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself. PRIUS PRIME_OM_OM47D13U_(U)
Page 36: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. IO11PH018 PRIUS PRIME_OM_OM47D13U_(U)
Page 37 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS knee airbag Can help provide driver protection SRS seat cushion airbag Can help restrain the front passenger ◆...
Page 38 1-1. For safe use SRS airbag system components IO11PH019 Front impact sensors Front passenger’s seat belt buckle switch SRS warning light and “AIR BAG ON” and “AIR BAG OFF” Curtain shield airbags indicator lights Side impact sensors (rear) Front passenger airbag Driver’s seat belt...
Page 39 1-1. For safe use WARNING ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 42 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 43 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 44 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 45 1-1. For safe use ■ SRS airbag deployment conditions (SRS side and curtain shield airbags) ● The SRS side and curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 3300 lb.
Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 47 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 48 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 49 1-1. For safe use ● The surface of the seats with the SRS side airbag is scratched, cracked, or oth- erwise damaged. ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the SRS curtain shield air- bags inside is scratched, cracked, or otherwise damaged.
Page 50: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag and seat cushion airbag in the front passenger side. U.S.A.
Page 51 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Activated Devices...
Page 52 1-1. For safe use Child restraint system with infant ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Devices Seat cushion airbag in the front passenger Deactivated side Unoccupied...
Page 53 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ warning light SRS warning light Seat belt reminder light Front passenger airbag Deactivated Devices Seat cushion airbag in the front passenger Deactivated side : The system judges a person of adult size as an adult.
Page 54 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 55 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 56: Exhaust Gas Precautions
The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 57: Child Safety
1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats to avoid acci- dental contact with the shift lever, wiper switch etc.
Page 58: Child Restraint Systems
1-2. Child safety Child restraint systems Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual. ● Use a child restraint system when riding with a small child that cannot properly use a seat belt.
Page 59 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 60: Child Restraint System
1-2. Child safety Child restraint system Types of child restraint system installation methods ■ Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt P. 64 attachment IO12PH012 Child...
Page 61: When Using A Child Restraint System
1-2. Child safety When using a child restraint system When installing a child restraint system to a front passenger ■ seat For the safety of a child, install a child restraint system to a rear seat. When installing child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Page 62 1-2. Child safety WARNING ■ When using a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 63 1-2. Child safety WARNING ■ When using a child restraint system ● Use child restraint system suitable to the age and size of the child and install it to the rear seat. ● If the driver’s seat interferes with the child restraint system and prevents it from being attached correctly, attach the child restraint system to the right-hand...
Page 64: Fixed With A Seat Belt
1-2. Child safety Child restraint system fixed with a seat belt A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. ◆ Installing child restraint system using a seat belt (child restraint lock function belt) Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Page 65 1-2. Child safety While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there IO12PH020 is no slack in the belt, pull the belt to check that it cannot be extended.
Page 66 1-2. Child safety Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. IO12PH023 Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 67 1-2. Child safety Booster seat ■ If installing the child restraint system to the front passenger seat is unavoidable, refer to P. 61 for front passenger seat adjustment. High back type: If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint.
Page 68 1-2. Child safety ◆ Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. When releasing the buckle, the child restraint system spring up due to the rebound of the seat cushion.
Page 69 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious inju- ries that could result in death.
Page 70: Fixed With A Child Restraint Latch Anchor
1-2. Child safety Child restraint system fixed with a child restraint LATCH anchor Child restraint LATCH anchors ■ LATCH anchors are provided for each rear seat. (Buttons dis- playing the location of the anchors are attached to the seats.) IO12PH030 Installation with LATCH system ■...
Page 71 1-2. Child safety With flexible lower attachments  Latch the hooks of the lower straps onto LATCH anchors. For owners in Canada: symbol child restraint system indicates the presence of a lower connec- tor system. Canada only IO12PH032 With rigid lower attachments ...
Page 72 1-2. Child safety If the child restraint has a top tether strap, follow the child restraint manufacturer’s operation manual regarding the installa- tion, using the top tether strap to latch onto the top tether strap anchor. (P. 73) After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
Page 73: Using An Anchor Bracket (For Top Tether Strap)
1-2. Child safety Using an anchor bracket (for top tether strap) Anchor brackets (for top tether strap) ■ Anchor brackets are provided for each rear seat. Use anchor brackets when fix- ing the top tether strap. IO12PH034 Fixing the top tether strap to the anchor bracket ■...
Page 74 1-2. Child safety If the head restraint does not interfere with child restraint system installation, install the head restraint. IO12PH036 ■ Laws and regulations pertaining to anchors The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used.
Page 75: Emergency Assistance
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada.
Page 76 A variety of subscription terms is available for purchase. Contact your Toyota dealer, call the following appropriate Safety Connect response center or push the “SOS” button in your vehicle for further subscription details.
Page 77 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models (in the contiguous United States only). Contact with the Safety Connect response center is dependent upon the telematics device being in operative...
Page 78 Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Emergency Assistance Button (“SOS”) ■...
Page 79 For a description of the Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 80 Free/Open Source Software Information This product contains Free/Open Source Software (FOSS). The license information and/or the source code of such FOSS can be found at the following URL. https://www.denso.com/global/en/opensource/dcm/toyota/ ■ Certification for the Safety Connect FCC ID: JOYJ79 IC: 574B-J79...
Page 81: Theft Deterrent System
1-4. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 82 1-4. Theft deterrent system ■ Certification for the immobilizer system For vehicles sold in the U.S.A. and Hawaii  For vehicles sold in Canada  NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 83: Plug-In Hybrid System
Plug-in hybrid system 2-1. Plug-in hybrid system Plug-in hybrid system features ......84 Plug-in hybrid system precautions ....... 96 Plug-in hybrid vehicle driving tips....... 103 EV driving range ....106 2-2. Charging Charging equipment..108 Charging cable....113 Smart lid & connector locking system ....
Page 84: Plug-In Hybrid System Plug-In Hybrid System
2-1. Plug-in hybrid system Plug-in hybrid system features The plug-in hybrid system is a system excellent in both econom- ical efficiency of electric vehicles and practicality of hybrid vehi- cles. ● EV driving can be performed using electricity charged from an external power source.
Page 85 2-1. Plug-in hybrid system Plug-in hybrid system operation mode The plug-in hybrid system operates in the following modes. The multi-information display can be used to check which mode the plug-in hybrid system is currently being driven in. (P. 213) EV mode When a sufficient amount of electricity is remaining after charging , EV driving is performed using electricity stored in the...
Page 86 2-1. Plug-in hybrid system EV auto mode (P. 88) When a sufficient amount of electricity for EV driving is remaining in the hybrid battery (traction battery) after charging , the operation mode can be switched to EV auto mode. Switching to EV auto mode make powerful driving possible by using both the gasoline engine and electric motor in a driving condition that requires large driving force, such as when passing a vehicle on a highway or driving on a steep slope.
Page 87 2-1. Plug-in hybrid system Hybrid battery (traction battery) charge mode (P. 89) Electricity generated in the gasoline engine can be charged in the hybrid battery (traction battery) by switching to the hybrid battery (traction battery) charge mode when electricity needed for EV driv- ing is not remaining.
Page 88 2-1. Plug-in hybrid system Plug-in hybrid system operation mode selection switches The plug-in hybrid system operation modes can be switched using the switches. If there is not enough charge remaining in the hybrid battery (traction bat- tery) to allow EV driving, EV/EV auto mode will not be selectable. The hybrid battery (traction battery) charge mode cannot be selected if the hybrid battery (traction battery) is almost completely charged.
Page 89 2-1. Plug-in hybrid system Switching to the hybrid battery (traction battery) charge mode ■ Press and hold the switch. Take your hand off the switch once the hybrid battery charge mode indicator starts to blink. The hybrid battery charge mode indicator illuminates when the switch to hybrid battery (traction battery) charge mode is com-...
Page 90 2-1. Plug-in hybrid system Control when driving in each mode When in EV/EV auto mode ■ In EV/EV auto mode, EV driving (driving using only the electric motor) is possible. However, depending on the situation, EV driv- ing may be canceled and both gasoline engine and electric motor are used (P.
Page 91 2-1. Plug-in hybrid system When braking (regenerative braking) ■ The electric motor (traction motor) charges the hybrid battery (trac- tion battery). The EV driving range can be extended by actively using this regen- erative braking to store electricity in the hybrid battery (traction bat- tery).
Page 92 2-1. Plug-in hybrid system ■ Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ● The accelerator pedal is released while driving with the shift position in D or ●...
Page 93 2-1. Plug-in hybrid system ■ Gasoline engine operation in EV/EV auto mode Even if there is a sufficient amount of electricity remaining in the hybrid bat- tery (traction battery) and EV driving range (P. 207, 223, 230, 247) is being displayed on the multi-information display etc., EV driving (driving using only the electric motor) may be canceled and both gasoline engine and electric motor are used depending on the situation (EV driving will be returned to...
Page 94 2-1. Plug-in hybrid system ■ If the vehicle is not used for a long time ● The 12-volt battery may discharge. In this event, charge the 12-volt battery. (P. 593) In order to prevent the hybrid battery (traction battery) from becoming extremely low in charge, charge the hybrid battery (traction battery) from external power source or start the hybrid system at least once every 2 or 3 months, and turn the power switch off after the gasoline engine has...
Page 95 2-1. Plug-in hybrid system ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. WARNING ■ When using the hybrid battery (traction battery) charge mode Observe the following precautions when using the hybrid battery (traction battery) charge mode while parking.
Page 96: Plug-In Hybrid System Precautions
2-1. Plug-in hybrid system Plug-in hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 600V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.
Page 97 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 98 If a warning light comes on, a warning message is displayed or the 12- volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 99 2-1. Plug-in hybrid system WARNING ■ High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 100 2-1. Plug-in hybrid system WARNING ■ Road accident cautions Observe the following precautions to reduce the risk of death or serious injury: ● Pull your vehicle off the road, apply the parking brake, shift the shift posi- tion to P, and turn the hybrid system off. ●...
Page 101 Never resell, hand over or modify the hybrid battery. To prevent accidents, hybrid batteries that have been removed from a disposed vehicle are col- lected through Toyota dealer. Do not dispose of the battery yourself. Unless the battery is properly collected, the following may occur, resulting in death or serious injury: •...
Page 102 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer. ● A filter is installed to the air intake vent. When the filter remains noticeably dirty even after cleaning the air intake vent, filter cleaning or replacement is recommended.
Page 103: Plug-In Hybrid Vehicle Driving Tips
2-1. Plug-in hybrid system Plug-in hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using EV mode and HV mode effectively Primarily using EV mode when driving in cities and using HV mode when driving on highways (or freeways) can help conserve fuel and electricity.
Page 104 2-1. Plug-in hybrid system ◆ Accelerator pedal/brake pedal operation ● Drive your vehicle smoothly. Avoid abrupt acceleration and deceleration. Gradual acceleration and deceleration will make more effective use of the electric motor (traction motor) without having to use gasoline engine power. ●...
Page 105 2-1. Plug-in hybrid system ◆ Air conditioning ● Turn the “A/C” switch ( • ) off when it is not needed. Doing so can help reduce excessive electricity and fuel consumption. In summer: When the ambient temperature is high, use the recir- culated air mode.
Page 106: Ev Driving Range
2-1. Plug-in hybrid system EV driving range The EV driving range displayed on the multi-information display etc. shows the reference distance that EV driving (driving using only the electric motor) is possible, and the actual distance that can be driven may differ from that displayed. Even if the EV driving range is displayed, EV driving may be can- celed and both gasoline engine and electric motor are used depend- ing on the situation.
Page 107 2-1. Plug-in hybrid system Tips for extending the EV driving range The distance that can be driven in EV mode varies significantly depending on how the vehicle is driven, road conditions, the weather, the outside temperature, usage conditions of electrical components and the number of occupants.
Page 108: 2-2. Charging
2-2. Charging Charging equipment This vehicle features equipment for connecting to an external power source. Charging equipment and names Charging inlet Hybrid battery (traction bat- tery) status indicator Charging inlet light (P. 110) Charging port lid Charging cable (P. 113) (P.
Page 109 2-2. Charging Opening and closing the charging port lid Opening the charging port lid ■ Vehicles without smart lid & connector locking system: Press the rear edge of the charging port lid (the position shown in the illustration). Push and take your hand away to slightly open the charging port lid.
Page 110 2-2. Charging Closing the charging port lid ■ Close the charging port lid and press the rear edge of the charging port lid (the position shown in the illustration). Vehicles with smart lid & con- nector locking system: • When the doors are locked with the smart key system, wireless remote control or door lock switch, the charging...
Page 111 2-2. Charging Except during charging ■ The hybrid battery (traction battery) status indicators illuminate while the charging port lid is open and any of the followings are per- formed. 2, 3 ● When an electronic key is carried near the effective range (P.
Page 112 2-2. Charging Charging indicator The illumination/flashing pattern changes to inform the user of the charging status in the following ways. Illumination/flashing Vehicle condition pattern • Charging is in progress • Charging is possible Illuminated • “Traction Battery Heater” (P. 132) is operating •...
Page 113: Charging Cable
2-2. Charging Charging cable The function, correct operating, etc. of the charging cable are written. The names of each part of the charging cable Charging connector Power indicator (P. 115) Latch release button Charging indicator (P. 115) Plug Error warning indicator (P.
Page 114 2-2. Charging Safety functions The CCID (Charging Circuit Interrupting Device) has the following safety features. Electrical leakage detection function ■ If an electrical leakage is detected during charging, the power source will be automatically interrupted, thus preventing fires or electrical shocks caused by electrical leakage. If the power source is interrupted, the error warning indicator flashes.
Page 115 2-2. Charging CCID (Charging Circuit Interrupting Device) indicator Indicator operation ■ 3 indicators are used to indicate the following conditions. Power indicator Illuminates when electricity is flowing to the CCID (Charging Circuit Interrupting Device). Charging indicator Illuminates when charging is in progress.
Page 116 Charging illuminated celed, or there is a malfunction system error illuminated in the charging cable.  Consult your Toyota dealer Illuminated Flashes Plug There is a malfunction in the temperature plug temperature detection...
Page 117 Do not fold the charging connector or plug or insert foreign objects into them. ● Do not put the charging connector and plug into water. If they are dropped into water, contact your Toyota dealer. ● Do not bring the charging cable to a high-temperature item such as a heat- ing device.
Page 118 The plug is not dirtied by dust etc. Remove the plug from the outlet before inspecting it. If any abnormalities are found in the charging cable as a result of the inspection, immediately stop use and consult your Toyota dealer. ■ Maintaining the charging cable When the charging cable is dirty, first remove the dirt with a hard, wringed cloth, and then wipe the cable with a dry cloth.
Page 119: Smart Lid & Connector Locking System
2-2. Charging Smart lid & connector locking system  When carrying the electronic key on your person, for example in your pocket, only the charging port lid can be unlocked, and the charging connector can be locked or unlocked with the doors of the vehicle locked.
Page 120 2-2. Charging Using the smart lid system Unlocking the charging port lid ■ Pressing the rear edge of the charging port lid (the position shown in the illustration) carry- ing the electronic key on your person, for example in your pocket, can unlock the charging port lid.
Page 121 2-2. Charging Locking the doors using the smart key system or wireless remote control. (P. 275, 276) The charging port lid will be locked. If the charging port lid is closed with the doors locked, the charging port lid locks. ■...
Page 122 Press the center of the rear edge of the charging port lid to open it. (P. 109) This unlocking method is a temporary correction procedure for emergency use only. If the problem persists, have the vehicle inspected by your Toyota dealer immediately. PRIUS PRIME_OM_OM47D13U_(U)
Page 123 2-2. Charging Using the charging connector locking system Locking and unlocking the charging connector ■ Carry the electronic key on your person, for example in your pocket. Insert the charging connector into the charging inlet. (P. 144) Press the charging connector lock switch.
Page 124 2-2. Charging Changing the charging connector lock settings ■ The method for locking and unlocking the charging connector can be changed as follows in the “Vehicle Settings” settings on the multi-information display. Refer to P. 239 for details on how to change the settings. Setting Operation description The charging connector is locked and unlocked by...
Page 125 2-2. Charging ■ Charging connector locking system ● If the charging connector lock switch is operated repeatedly, the charging connector locking system may not work to protect the system. In this case, wait for a while before operating the switch again. ●...
Page 126 2-2. Charging ■ If the charging cable cannot be unlocked using the normal procedure If the charging connector cannot be unlocked by pressing the charging con- nector lock switch even after carrying an electronic key or unlocking the doors, the charging connector can be unlocked by operating the emergency release lever.
Page 127 Reinstall the cover to the its original position. This method is a temporary correction procedure for emergency use only. If the problem persists, have the vehicle inspected by your Toyota dealer imme- diately. Do not operate the emergency release lever when the charging connector can be unlocked in the normal procedure.
Page 128: Power Sources That Can Be Used
2-2. Charging Power sources that can be used An external power source that fulfills the following criteria is necessary for charging this vehicle. Confirm this before charging. WARNING ■ Warnings for electrical faults Make sure to observe the precautions in this Owner’s Manual when charging the vehicle.
Page 129 2-2. Charging ■ The charging environment For safe charging, the following charging equipment and settings are recom- mended. ● Weatherproof outlet When charging outdoors, connect the plug to a weatherproof outlet, and ensure that the plug remains waterproof while the plug is connected. ●...
Page 130 2-2. Charging WARNING ■ Power sources precautions Observe the following precautions. If you do not follow them, fire, electrical shock or damage may occur, possi- bly resulting in death or serious injury. ● Connect to an AC 120 V outlet (NEMA 5-15R) with a Ground-Fault Circuit- Interrupter (GFCI) and supplied by a circuit breaker per your local code.
Page 131: Charging Methods
2-2. Charging Charging methods The following methods can be used to charge the hybrid battery (traction battery). ◆ Charging from an external power source (P. 143) This is a charging method used when charging from an AC outlet (120 V) with the charging cable equipped to the vehicle or charging at a public charging station.
Page 132 2-2. Charging ■ Charging time may increase In the following situations, charging time may become longer than normal: ● In very hot or very cold temperatures. ● The vehicle is consuming a lot of electricity, for example, when the head light switch is on etc.
Page 133 2-2. Charging Hybrid battery (traction battery) warming control (Alaska and ■ Canada only) This control operates after the charging cable remains connected to the vehicle for 3 days and “Traction Battery Heater” automatically stops. It automatically insulates the hybrid battery (traction battery) in extremely low temperatures.
Page 134 2-2. Charging ■ “Traction Battery Heater” ● “Traction Battery Heater” may operate when charging is not being per- formed. ● When “Traction Battery Heater” is operating, the charging indicator illumi- nates. ● When “Traction Battery Heater” is operating during charging, the charging time may be longer than normal.
Page 135 2-2. Charging ■ “Traction Battery Cooler” ● When the hybrid battery (traction battery) is above a certain temperature and the power switch is turned off, a check screen is displayed on the multi- information display that indicates whether “Traction Battery Cooler” is imple- mented.
Page 136: Charging Tips
2-2. Charging Charging tips This section explains methods for using the charging function for this vehicle and checking information related to charging. Systematically charging To enable the use of EV mode, we recommend systematically charging the vehicle. Before leaving home In order to use EV mode, charge the hybrid battery (traction battery) at home before leaving.
Page 137 After applying to Entune, it is possible to use the smartphone application to search the nearby charging stations. For details about Entune, refer to http://www.toyota.com/entune/. Checking information related to charging Information related to charging can be displayed and checked on the vehicle’s multi-information display or 11.6-inch display (if equipped).
Page 138: Things To Know Before Charging
2-2. Charging Things to know before charging Make sure to read the following precautions before connecting the charging cable to the vehicle and charging the hybrid battery (traction battery). Charging precautions This vehicle has been designed to allow charging from an external power source using a charging cable for exclusive use with standard household AC outlets.
Page 139 2-2. Charging Confirm the following before charging Before charging, always check the following items. ● The parking brake is applied. (P. 345) ● The headlights are switched off or set to AUTO, and lights such as the emergency flashers and interior lights etc. are switched off. If these light switches are turned ON, then these features will consume electricity, and charging time will increase.
Page 140 When none of the above situations apply and there is a drastic drop in the remaining charge of the hybrid battery (traction battery) after charging com- pletes, have the vehicle inspected by your Toyota dealer. : When this occurs, even if the remaining charge display of the hybrid battery (traction battery) shows that it is fully charged, the remaining charge rapidly decreases faster than normal.
Page 141 2-2. Charging WARNING ■ Caution when charging People with implantable cardiac pacemakers or cardiac resynchronization therapy-pacemakers should not carry out the charging procedure. Ask someone else to do it. ● Do not approach the charging equipment and charging cable while charging.
Page 142 Do not allow water or foreign matter to enter the air intake vents ● Do not spill large amounts of water near the air intake vents If water is spilled, have the vehicle inspected by your Toyota dealer and do not charge the hybrid battery (traction battery) before the inspection. PRIUS PRIME_OM_OM47D13U_(U)
Page 143: How To Charge
2-2. Charging How to charge This section explains the procedure for charging the hybrid bat- tery (traction battery) with the equipped charging cable. When using a charging station, make sure to check the opera- tion instructions on the charging station. When the charge schedule is registered, make sure “Charge Now”...
Page 144 2-2. Charging Remove the charging inlet cap and secure it as shown in the illustration. Remove the protective cap of the charging connector and secure it to the cable. Insert the charging connector into the charging inlet. Align the guide position on the bot- tom of the charging connector, and push charging...
Page 145 2-2. Charging Confirm that the charging indi- cator is illuminated. Charging will not start if the charging indicator does not illumi- nate when the charging connector is inserted. (P. 178) If the charging indicator is flashing, the charge schedule is registered. (P.
Page 146 2-2. Charging ■ During charging ● The surface of the CCID (Charging Circuit Interrupting Device) may become hot, but this does not indicate a malfunction. ● Depending on radio wave conditions, interference may be heard on the radio. ● The current charging condition and the estimated time until charging will complete can be checked on the multi-information display or 11.6-inch dis- play (if equipped).
Page 147 2-2. Charging After charging Vehicles with smart lid & con- nector locking system: When the charging connector is locked, carry an electronic key and press the charging connec- tor lock switch. charging connector unlocked by the smart lid & con- nector locking system.
Page 148 2-2. Charging Remove the plug from the out- let when the charging equip- ment will not be used for a prolonged period of time. Hold the body of the plug when removing. Make sure to put the cable away immediately after disconnecting. (P.
Page 149 2-2. Charging ■ When removing the charging connector Press the latch release button, check that the lever raises up, and then pull the charging connector towards you. Vehicles with smart lid & connector lock- ing system: If the lever does not raise up even after the latch release button is pressed, charging...
Page 150 2-2. Charging WARNING ■ When charging Observe the following precautions. Failure to do so may cause an unexpected accident, resulting in death or serious injury. ● Connect to a power source suitable for charging. (P. 128) ● Check that the charging inlet, charging cable, plug and outlet are free of foreign matter.
Page 151 Toyota dealer. Continuing to charge the vehicle in that condition may lead to unforeseen accidents or serious injury.
Page 152 2-2. Charging NOTICE ■ When use the charging cable and related parts To prevent damage to the charging cable and related parts, observe the fol- lowing precautions. ● When interrupting or canceling charging, remove the charging connector before removing the plug. ●...
Page 153 2-2. Charging NOTICE ■ Using private power generator Do not use private power generators as a power source for charging. Doing so may make charging unstable, the voltage may be insufficient, and the error warning indicator on the CCID (Charging Circuit Interrupting Device) of the charging cable may flash.
Page 154: Using The Charging Timer Function
2-2. Charging Using the charging timer function Charging can be carried out at the desired time by registering the charge schedule. Also, it is possible to set the timer to one’s preferences, such as having charging complete by a certain departure time or be carried out at the same time on certain days.
Page 155 2-2. Charging Turning “Charge Now” on and off ■ If even one charge schedule is registered, charging does not start until the set time, even if the charging cable is connected to the vehicle. To start charging immediately without changing the charge schedule setting, turn “Charge Now”...
Page 156 (traction battery) when departing may be decreased. ■ Smartphone-linked operation (vehicles with 11.6-inch display) After applying to Entune, it is possible to use the smartphone application to change charging timer settings. For details about Entune, refer to http://www.toyota.com/entune/. PRIUS PRIME_OM_OM47D13U_(U)
Page 157 2-2. Charging ■ When timer settings are ignored When the following operations are performed while the charging timer is on standby, timer charging is temporarily canceled and charging is started imme- diately. ● When the Remote Air Conditioning System (P. 518) is operated ●...
Page 158 2-2. Charging Setting operations on multi-information display When operating timer settings, use the charging timer switch and meter control switches. Charging timer switch Meter control switches (P. 189) Multi-information display Registering the charge schedule ■ Press the charging timer switch. The “Charge Schedule”...
Page 159 2-2. Charging Press of the meter control switches to select the charging mode/ time settings row, and then press The charging mode/time set- tings screen will display. The clock display (12-hour dis- play/24-hour display) changes according to the clock settings. (P.
Page 160 2-2. Charging Press of the meter control switches to select the desired day to acti- vate for the repeated setting, and then press Each time is pressed, the repeated setting switches between on and off. When set to on, the selected day is highlighted and the charging timer is repeated on that day.
Page 161 2-2. Charging Changing the registered charge schedules ■ The registered charge schedules can be turned on, off, deleted or modified. Press the charging timer switch. The “Charge Schedule” screen will display on the multi-information dis- play. Press of the meter control switches to select “Scheduled Events”, and then press The “Scheduled Events”...
Page 162 2-2. Charging ● “ON/OFF” Each time of the meter control switch is pressed, the selected charge schedule switches between “On” and “Off”. When set to “Off”, a charging schedule is ignored and charging accord- ing to the timer is not carried out. When is pressed, setting is complete.
Page 163 2-2. Charging Setting “Charge Now” to “On” ■ The “Charge Now” setting can be changed by performing one of the two following procedures. Operation on “Charge Schedule” screen  Press the charging timer switch. The “Charge Schedule” screen will display on the multi-information dis- play.
Page 164 2-2. Charging Changing “Next Charging Event” ■ : When “Charge Now” is set to “On” etc., it is not possible to change the reg- istered “Next Charging Event”. Press the charging timer switch. The “Charge Schedule” screen will display on the multi-information dis- play.
Page 165 2-2. Charging After setting operations are complete, press A confirmation screen of chang- ing “Next Charging Event” will display. Press of the meter control switches to select “Yes”, and then press to save the timer settings. Press to return to the previous screen. When canceling the “Next Charging Event”, select “No”...
Page 166 2-2. Charging ■ To return to original setting after changing “Next Charging Event” set- ting Turning the setting of “Charge Now” on and then off can return the setting of “Next Charging Event” to its original setting. ■ When “Next Charging Event” is changed while charging ●...
Page 167 2-2. Charging Setting operations on the 11.6-inch display (if equipped) Setting operations related to the charging timer are performed on the “Charge Schedule” screen. For details on how to operate the 11.6-inch display, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Displaying the “Charge Schedule”...
Page 168 2-2. Charging How to read the “Charge Schedule” screen ■ Charge schedules (calendar display) Displays the week-long registered charge schedule in a list using icons. “Add” button Press to add a new item to the charge schedule. (P. 169) Charge schedules (list display) A list of items on the registered charge schedule is displayed.
Page 169 2-2. Charging “ON”/“OFF” button The charge schedule switches between “ON” and “OFF” each time this button is pressed. (P. 171) Scroll bar When the number of registered charge schedules exceeds 3, the dis- played contents can be changed by operating the button. Main content displayed on the calendar: Display Content...
Page 170 2-2. Charging Select the charging mode. Press “Start” or “Departure” to turn the button (charging mode) on and highlight the button. Operate the time setting wheel to set the start (or departure) time. When the charging mode is “Start”, set the charging start time (start time).
Page 171 2-2. Charging Switching charge schedules between “ON” and “OFF” ■ Display the “Charge Schedule” screen. (P. 167) From the items in the list displayed on the bottom of the screen, press “ON” or “OFF” in the row of the charge schedule you wish to change.
Page 172 2-2. Charging ● Changing registered items: Change the desired settings as described in step to step the “Registering the charge schedule” procedure. (P. 169) When a setting is changed, its icon on the calendar also changes. ● Deleting registered items: Press “Delete”.
Page 173 2-2. Charging Operation on ending screen  Turn the power switch off. The ending screen is displayed on the 11.6-inch display. While the ending screen is displayed, press “Charge Now”. Each time the button is pressed, “Charge Now” switches between on and off and the indicator on the button turns on and off.
Page 174 2-2. Charging Changing “Next Charging Event” ■ : When “Charge Now” is turned on etc., the registered “Next Charging Event” cannot be changed. Display the “Charge Schedule” screen. (P. 167) “Next Charging Event” is displayed on the “Charge Schedule” screen with an orange icon.
Page 175 2-2. Charging ■ Setting the charge schedule The charge schedule cannot be set while driving. ■ When charging timer setting operations are canceled When the vehicle is in the following conditions, charging timer setting opera- tions are canceled. ● The power switch is turned off before the settings are confirmed ●...
Page 176 2-2. Charging ■ When the power switch is turned off next charge schedule (“Next Charging Event”) can be checked on the ending screen that is displayed when the power switch is turned off. : The ending screen may not be dis- played during charging.
Page 177: When Normal Charging Cannot Be Carried Out
If charging is possible, the first outlet may have a malfunction. Contact the building or facility manager, or an electrician. Short circuit between CCID Immediately stop charging and con- (Charging Circuit Interrupting tact your Toyota dealer. Device) and plug PRIUS PRIME_OM_OM47D13U_(U)
Page 178 Immediately stop charging and contact your Toyota dealer. When the hybrid battery (traction Hybrid battery (traction battery) is battery) is fully charged, charging is already fully charged not performed.
Page 179 2-2. Charging Likely cause Correction procedure  Charging indicator flashes and charging cannot be carried out. When you wish to charge according When charging indicator flashes to the timer, wait until the set time. Charge schedule is registered To immediately start charging, set “Charge Now”...
Page 180 2-2. Charging Likely cause Correction procedure  Charging starts immediately, even though charge schedule is registered When charging according to the “Charge Now” is set to “On” timer, set “Charge Now” to “Off”. (P. 163, 172) Check that charge schedule is not Charge schedule is set to “Off”...
Page 181 Charging cable was connected after Connect the charging cable before set time the time set in “Start”. : In order to use the smartphone application, it is necessary to apply to Entune. For details about Entune, refer to http://www.toyota.com/entune/. PRIUS PRIME_OM_OM47D13U_(U)
Page 182 2-2. Charging When charging-related message is displayed When the hybrid system is started after charging, a message is dis- played in the multi-information dis- play. When this occurs, follow instructions displayed screen. Likely cause Correction procedure  If “Charging Stopped Connect Plug to Charge” is shown Charging connector is removed while charging After the hybrid battery (traction bat-...
Page 183 If charging cannot be carried out, even though the proper procedures were followed, have the vehicle inspected by your Toyota dealer. When the latch release button is Latch release button of charging pressed while charging, charging...
Page 184 Check if it is possible to charge with Charging equipment is not compati- the charging cable equipped to the ble with vehicle vehicle. If charging cannot be carried out, even when using genuine Charging equipment has stopped charging cable, consult your Toyota charging dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 185 Toyota dealer.  If “Charging Stopped High Energy Use See Owner’s Manual” is shown Check the following items, and then carry out charging again. • If the headlights and audio are turned on, turn them off.
Page 186 2-2. Charging Likely cause Correction procedure  If “The Traction Battery became low temperature System put priority on charging to preserve battery condition” is shown (Alaska and Canada only) When the hybrid battery (traction battery) warning control operates, The Hybrid battery (traction battery) the timer charge schedule is not warming control was operated used and charging is performed...
Page 187 Instrument cluster Instrument cluster Combination meter.... 188 Warning lights and indicators ......196 Main display ...... 204 Multi-information display......213 Head-up display ....246 Energy monitor/ consumption screen/ detail screen (vehicles with 7-inch display) ..254 Energy monitor/ consumption screen/ detail screen (vehicles with 11.6-inch display) ..
Page 188: Combination Meter
3. Instrument cluster Combination meter The large meter uses 2 liquid crystal displays to display informa- tion such as the vehicle condition, driving status, electricity con- sumption and fuel consumption. Combination meter layout The units used on the display may differ depending on the target region. Main display (P.
Page 189 3. Instrument cluster Operations related to the combination meter The meter control switches equipped on the steering wheel can be used to switch the screen display and change settings related to func- tions displayed on the screen. Each time button pressed, the mileage display switches among odometer, trip meters, etc., and the fuel con-...
Page 190 3. Instrument cluster Instrument cluster light control When the switches are pressed, the instrument cluster light changes as follows. The instrument cluster brightness levels that can be selected differ depending on whether the tail lights are on and surrounding brightness lev- els.
Page 191 3. Instrument cluster Information automatically displayed Some information will be displayed automatically according to power switch operation, vehicle condition, etc. When starting the hybrid system ■ When the hybrid system starts, an opening animation is dis- played on the main display. After the animation ends, the screens switch to the normal screen.
Page 192 3. Instrument cluster When stopping the hybrid system ■ ● When the hybrid system is stopped, the “Ending” screen is dis- played on the multi-information display (for approximately 30 seconds While the “Ending” screen is displayed, the following information can be displayed by pressing of the meter control switches.
Page 193 3. Instrument cluster Clock adjustment To adjust the time, perform operations on the screen (P. 239) of the multi-information display. Adjusting the time ■ Press of the meter control switches on the screen and select Press to display the cursor. Press of the meter control switches to...
Page 194 3. Instrument cluster ■ The meters and display illuminate when The power switch is in ON mode. ■ Adjusting the instrument cluster brightness (P. 190) ● The brightness levels that can be selected differ depending on whether the tail lights are on and surrounding brightness levels, as shown in the table below.
Page 195 3. Instrument cluster ■ When the menu screen on the navigation system is operated (vehicles with 11.6-inch display) A pop-up display of the menu screen icon is displayed on the multi-information dis- play. : The pop-up display on the navigation system can be turned off in the “Meter Customize”...
Page 196: Warning Lights And Indicators
3. Instrument cluster Warning lights and indicators The warning lights and indicators inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration dis- plays all indicators and warning lights illuminated. PRIUS PRIME_OM_OM47D13U_(U)
Page 197 3. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in any of the vehicle’s systems. Warning lights Pages Brake system warning light (U.S.A.) P. 660 Brake system warning light (Canada) P. 660 (Red) Brake system warning light P.
Page 198 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes or illuminates to indicate a malfunction.
Page 199 3. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Indicators Pages Turn signal indicator P. 344 Headlight indicator (U.S.A.) P. 346 Tail light indicator (Canada) P. 348 Parking brake indicator (U.S.A.) P.
Page 200 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 201 3. Instrument cluster Indicators and symbols displayed on the display Main display and multi-information display ■ Indicators Pages EV drive mode indicator P. 88 EV auto mode indicator P. 88 Hybrid battery charge mode indicator P. 89 “ECO MODE” indicator P.
Page 202 3. Instrument cluster Multi-information display (symbol display ■ Symbol display Pages Smart key system P. 332 Brake Override System/Drive-Start Control/ P. 664 Intelligent Clearance Sonar (if equipped) P. 395 LDA (Lane Departure Alert with steering con- trol) system P. 395 Low engine oil pressure warning P.
Page 203 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 204: Main Display
3. Instrument cluster Main display The main display shows basic information, such as the vehicle speed and remaining fuel amount. Also, the displayed informa- tion can be switched according to user preference. Display contents Simple screen Split screen : Refer to P. 208 for details on how to change the screen display. The units used on the display may differ depending on the target region.
Page 205 3. Instrument cluster Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Outside temperature Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C). The temperature display flashes for approximately 10 seconds when the outside temperature drops to approximately 37F (3C) or less, and then stops flashing.
Page 206 3. Instrument cluster Switching the mileage display and average fuel consumption display Each time is pressed, the mileage display and fuel consumption display change in the following order from 1 to 7. Mileage display Average fuel consumption dis- play After 1 to 7 are displayed, the dis- plays return to 1.
Page 207 3. Instrument cluster Mileage display Average fuel consumption display Average fuel consumption since ODO (Odometer) last reset Total mileage Average fuel consumption since last reset TRIP A average fuel consumption TRIP A (Trip meter A) Average fuel consumption since Mileage since last reset TRIP A was reset TRIP B average fuel consumption TRIP B (Trip meter B)
Page 208 3. Instrument cluster Switching the display mode Simple screen or split screen can be selected for the main display. When split screen is selected, a variety of information can be displayed on a sub-screen in addition to the contents of the simple screen. Setting procedure ■...
Page 209 3. Instrument cluster Switching contents displayed on the sub-screen ■ Press of the meter control switches and select the sub-screen. When the sub-screen is selected, is displayed on the sub- screen. Press of the meter control switches to select the dis- play item.
Page 210 3. Instrument cluster Display contents Detail Hybrid System Indicator A convenient Hybrid System Indicator is displayed. Refer to P. 218 for details on how to read the Hybrid System Indicator. Current electricity consumption When in EV/EV auto mode, the current electricity consumption during driving is displayed.
Page 211 • When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) ● When “-” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Electricity consumption When the unit is set to “MPH”:...
Page 212 3. Instrument cluster ■ Switching the driving mode (P. 415) When the driving mode is switched, the driving mode indicator changes and an animation is displayed on the multi-infor- mation display. Also, the background color of the main display, energy monitor (P. 216) and Hybrid System Indicator...
Page 213: Multi-Information Display
3. Instrument cluster Multi-information display A variety of information related to the vehicle can be displayed, including the operation status of each system and data related to Eco driving, and the settings of each system can be changed according to user preference. Display contents Information related to each icon on the upper portion of the multi-...
Page 214 3. Instrument cluster Menu icons Contents Pages Drive information The energy monitor that shows the operation status of the hybrid system, or other informa- P. 215 tion such as electricity consumption and fuel consumption are displayed. Navigation system-linked display The information related to the navigation sys- P.
Page 215 3. Instrument cluster Basic Operations Press of the meter control switches and select the icon of the desired item. The selected icon is highlighted and the display switches to the information screen. When split screen display is selected for the main display, the sub-screen of the main display can also be selected.
Page 216 3. Instrument cluster ◆ Energy monitor The energy monitor can be used to check the vehicle drive status, hybrid system operation status and energy regeneration status. While charging from the external power source, the flow of electrical energy while charging is displayed. When energy is flowing, an arrow appears and a bright point of light moves to show the direction of the flow of energy.
Page 217 3. Instrument cluster While charging ■ Hybrid battery (traction bat- tery) Charging connector (Display example) When the hybrid battery (traction battery) is being charged, a bright point of light moves from ■ When the charging connector is locked (vehicles with smart lid & con- nector locking system) (P.
Page 218 3. Instrument cluster ◆ Hybrid System Indicator The display changes according to accelerator pedal operation and displays the current driving status and energy regeneration status. The display contents of the Hybrid System Indicator are different in EV mode and HV mode. The Hybrid System Indicator can be displayed on the sub-screen of the main display (P.
Page 219 3. Instrument cluster 1, 2 EV indicator The EV indicator comes on when the vehicle is driven using only the electric motor (traction motor) or the gasoline engine is stopped. Hybrid battery (traction battery) status P. 224 Eco score P. 222 EV driving range P.
Page 220 3. Instrument cluster In HV mode  Multi-information Sub-screen Head-up display display (if equipped) Charge area Shows that energy is being recovered via the regenerative charging. Eco area Shows that the vehicle is being driven in an Eco-friendly manner.  Changed within the “ECO Accelerator Guidance”...
Page 221 3. Instrument cluster ● By keeping the indicator within Eco area, more Eco-friendly driv- ing can be achieved. ● Charge area indicates regeneration status. Regenerated energy will be used to charge the hybrid battery (traction battery). : Not displayed on the sub-screen or head-up display. : Not displayed on the sub-screen.
Page 222 3. Instrument cluster Eco score ■ The driving status for the following 3 situations are evaluated in 5 levels: Smooth start-off acceleration (“Eco-Start”), driving without sudden acceleration (“Eco-Cruise”) and smooth stopping (“Eco- Stop”). Each time the vehicle is stopped, a score result is displayed out of a perfect score of 100 points.
Page 223 3. Instrument cluster Information display of EV driving ■ One of the following 2 information in the items of “HV System Indi- cator” in “Meter Customize” settings can be selected to display in the left upper corner of the Hybrid System Indicator. (P. 241) “EV Energy”...
Page 224 3. Instrument cluster ■ When operation of each function stops ● The Hybrid System Indicator stops operating in the following situations. • The “READY” indicator is not illuminated. • The shift position is not D or B. ● The Eco score and “ECO Accelerator Guidance” stop operating in the fol- lowing situations.
Page 225 3. Instrument cluster ■ Remaining charge amount warning of hybrid battery (traction battery) ● The buzzer sounds intermittently when the hybrid battery (traction battery) remains without charging while the shift position is in N, or the remaining charge amount drops below a certain level. If the remaining charge amount drops further, the buzzer sounds continu- ously.
Page 226 3. Instrument cluster ◆ “Fuel Consumption Record” When the unit is set to “MPH”  The transitions of the average fuel consumption after the hybrid system starts can be checked in units of 1 mile (1.6 km) or 5 miles (8 km) of driving.
Page 227 3. Instrument cluster Types of “Fuel Consumption Record” ■ When the unit is set to “MPH”  Tab display Recorded contents Recorded range Average electricity con- The last 15 miles (24.1 km) “ 1 miles” sumption of every 1 mile driven (1.6 km) driven Average...
Page 228 3. Instrument cluster Switching the electricity and fuel consumption history screen ■ While the “Fuel Consumption Record” screen is displayed, press The tab display is selected and it is possible to switch the contents of the display. Press of the meter control switches to switch the con- tents of the display.
Page 229 3. Instrument cluster ◆ “Drive Monitor” Displays information such as the driving time and average vehicle speed, which are linked with the current mileage display. (P. 206) Current contents of the dis- play Displayed information shows which driving record the cur- rently displayed contents are based on.
Page 230 3. Instrument cluster ◆ “Drive Monitor 2” The following information of EV driving is displayed. Total average electricity con- sumption Indicates the total average electricity consumption since last reset until it is reset again. EV driving range (without using the air conditioning system) Indicates the estimated distance that can be driven using the cur- rent remaining hybrid battery (traction battery).
Page 231 3. Instrument cluster ◆ “Eco-Diary” The history of the average electricity consumption, air conditioning system load ratio (“A/C Load Ratio”) , distance traveled and aver- age fuel consumption can be displayed in a table according to day (“Daily”) or month (“Monthly”) units. : It indicates the percentage of the electricity consumed from the hybrid battery (traction battery) that is consumed by the air conditioning sys- tem.
Page 232 3. Instrument cluster Checking history ■ When each screen is selected, past records from the following ranges can be displayed by pressing of the meter con- trol switches. Displayed screen Displayed information Stored information Up to 32 reports “Daily” (8 screens) 4 reports Up to 24 reports “Monthly”...
Page 233 3. Instrument cluster Navigation system-linked display Displays a compass linked with the navigation system. Also, when the navigation system is perform- ing intersection guidance during destination guidance, the inter- section guidance is also displayed on the multi-information display. The illustration is only an example and may differ from the actual screen.
Page 234 3. Instrument cluster Air conditioning system settings screen The condition of the air conditioning system settings can be checked on the screen and the air conditioning system settings can be changed using the meter control switches. On the air conditioning settings screen, press of the meter con- trol switches to switch the contents of the display.
Page 235 3. Instrument cluster Item Settings Eco score P. 236 (A/C score) Temperature Changes according to operation of the meter control setting switches Outside air and recirculated air (Outside air mode) (Recirculated air mode) modes Fan speed 1 to 7 “CLIMATE “NORMAL”...
Page 236 3. Instrument cluster Eco score (A/C score) ■ The current air conditioning system usage status is evaluated in 5 levels to determine whether it is Eco-friendly. The evaluation changes according to the air conditioning system usage status. When the power switch is turned off, the current total driving score and advice related to using the air conditioning...
Page 237 3. Instrument cluster ■ Eco score (A/C score) ● The setting status of the following air conditioning system functions are reflected in the score. • Temperature setting • Fan speed setting • Outside air and recirculated air modes • “A/C” button •...
Page 238 3. Instrument cluster Driving assist system information The operation status of driving support system such as the LDA (Lane Departure Alert with steer- ing control) and dynamic radar cruise control with full-speed range and warning information are displayed. For details regarding the driving support functions, refer to the page for the corresponding function.
Page 239 3. Instrument cluster Settings display The operation contents of the driving support systems and settings related to the combination meter display can be changed. Driving support systems such as the PCS (Pre-Collision System) and Blind Spot Monitor (if equipped) is turned on and off by simply pressing Make sure not to cancel the systems accidentally.
Page 240 3. Instrument cluster Settings table ■ Item Settings Setting result “On” Turns the LDA system steering control function on and off. (P. 398) “Off” “High” Switches the LDA system lane deviation sensitivity. (P. 398) “Standard” “On” Turns the PCS (Pre-Collision System) on and off.
Page 241 3. Instrument cluster Item Settings Setting result Height Changes the display position and bright- ness of the head-up display. (P. 249) Brightness “km/h” Switches the speed unit used by the screen display. “MPH” “Meter Customize” settings: P. 241 “Vehicle Settings” settings: P. 739 : If equipped “Meter Customize”...
Page 242 3. Instrument cluster Item Settings Setting result “On” “Navigation” “Off” “On” “Instrument Panel Light” “Off” “On” “Climate Settings” “Off” “Cruise “On” Control Operation Turns the pop-up display of the “Off” “Pop-up Display Display” selected item on the multi- On/Off” information display on and off. “On”...
Page 243 3. Instrument cluster Item Settings Setting result “Yes” “Eco-Diary Deletes data of “Eco-Diary (Daily)” (Daily)”. (P. 231) “No” “History Reset” “Yes” “Eco-Diary Deletes data of “Eco-Diary (Monthly)” (Monthly)”. (P. 231) “No” “Electricity Deletes the data of the total “Yes” Consumption average electricity consump- “No”...
Page 244 3. Instrument cluster ■ Setting items ● “Meter Customize” and “Vehicle Settings” setting items are not selectable during driving and cannot be operated. Also, the settings screen is temporarily canceled in the following situations. • A warning message is displayed. •...
Page 245 3. Instrument cluster WARNING ■ Cautions while setting up the display As the hybrid system needs to be operating during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 246: Head-Up Display
3. Instrument cluster Head-up display  The head-up display can display the current vehicle speed and Hybrid System Indicator in front of the driver. Also, it can display various types of information to assist the driver. Operation switches and display contents The units used on the display may differ depending on the target region.
Page 247 3. Instrument cluster Meter control switches These switches are used when adjusting the display position and bright- ness of the head-up display. (P. 249) “HUD” (Head-up display) switch P. 248 ( Vehicle speed display Cruise control display P. 399 ( Hybrid System Indicator (P.
Page 248 3. Instrument cluster “HUD” (Head-up display) switch The “HUD” switch can be used to turn the head-up display on and off, or switch the display contents. When the head-up display is off ■ Pressing the “HUD” switch turns the head-up display on and starts the display.
Page 249 3. Instrument cluster Display position and brightness adjustment In order to improve the visibility of the head-up display, the display position and brightness can be adjusted. Displaying the adjustment screen on the multi-information display. When the head-up display is on: Select on the screen of the multi-information dis-...
Page 250 3. Instrument cluster Insert display Insert displays of the driving support systems ■ Insert displays are linked with the operation of the following sys- tems and used to show some of the information shown on the multi- information display on the head-up display. System Displayed information PCS (Pre-Collision System) (P.
Page 251 3. Instrument cluster Route guidance display When the navigation system route guidance is set, convenient route guidance is displayed. When approaching an intersec- tion, the shape of the intersection and the remaining distance to the intersection are displayed. Once the vehicle is within a fixed distance from the intersection, an 2, 3 arrow animation...
Page 252 3. Instrument cluster ■ Enabling/disabling of the head-up display When the head-up display is turned off with the “HUD” switch, it is not dis- played until the “HUD” switch is used to turn the head-up display on again. (Operation of the head-up display is not linked with the power switch.) ■...
Page 253 3. Instrument cluster WARNING ■ Before using the head-up display ● Check that the position and brightness of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
Page 254: Energy Monitor/Consumption Screen/Detail Screen (Vehicles With 7-Inch Display)
3. Instrument cluster Energy monitor/consumption screen/detail screen (vehicles with 7-inch display) You can view the status of your vehicle on the multi-information display and the audio system screen : For navigation system ◆ Multi-information display P. 213 ◆ Audio system screen Display the energy monitor, trip information or past record ■...
Page 255 3. Instrument cluster How to read the energy monitor Function summary ■ The energy monitor can be used to check the vehicle drive status, hybrid system operation status and energy regeneration status. Flow of energy and display details ■ When energy is flowing, an arrow appears and a bright point of light moves to show the direction of the flow of energy.
Page 256 3. Instrument cluster Audio system screen When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow These images are examples only, and may vary slightly from actual conditions. PRIUS PRIME_OM_OM47D13U_(U)
Page 257 3. Instrument cluster Display of the remaining hybrid battery (traction battery) The current remaining charge in the hybrid battery (traction battery) is displayed on the energy monitor screen. The system automatically switches to the HV mode when the neces- sary amount of battery charge for EV driving in EV mode is insuffi- cient.
Page 258 3. Instrument cluster Fuel consumption Trip information ■ If the “Trip Information” screen does not appear, select “Trip Infor- mation”. Reset the trip information data Previous fuel consumption per minute Current fuel consumption Regenerated energy in the past 15 minutes symbol indicates 30 Wh.
Page 259 3. Instrument cluster Past record ■ If the “Past Record” screen does not appear, select “Past Record”. Reset the past record data Best recorded fuel consump- tion Average fuel consumption (if equipped) Previous fuel consumption record Current fuel consumption Update the past record data “Energy Monitor”...
Page 260: Energy Monitor/Consumption Screen/Detail Screen (Vehicles With 11.6-Inch Display)
3. Instrument cluster Energy monitor/consumption screen/detail screen (vehicles with 11.6-inch display) You can view the status of your vehicle on the multi-information display and the audio system screen : For navigation system ◆ Multi-information display P. 213 ◆ Audio system screen Display the energy monitor, trip information or past record ■...
Page 261 3. Instrument cluster Display the detail screen ■ Display “Energy Monitor” screen. Select on the upper right screen. How to read the energy monitor Function summary ■ The energy monitor can be used to check the vehicle drive status, hybrid system operation status and energy regeneration status. The flow of electric energy during charging is displayed when charging from an external power source.
Page 262 3. Instrument cluster When the vehicle is powered by When the vehicle is powered by the both the gasoline engine and the electric motor (traction motor) electric motor (traction motor) When the vehicle is powered by the When there is no energy flow gasoline engine PRIUS PRIME_OM_OM47D13U_(U)
Page 263 3. Instrument cluster When the vehicle is charging the hybrid battery (traction battery) When the vehicle is charging the hybrid battery (traction battery) from Air Conditioning System use external power source : When the air conditioning compressor is not operating, an arrow does not appear and the bright point of light are not displayed.
Page 264 3. Instrument cluster Fuel consumption Trip information ■ If the “Trip Information” screen does not appear, select “Trip Infor- mation”. Previous fuel consumption per minute Current fuel consumption Reset the trip information data Regenerated energy in the past 15 minutes symbol indicates 30 Up to 5 symbols are shown.
Page 265 3. Instrument cluster Past record ■ Best recorded fuel consump- tion Average fuel consumption Current fuel consumption Previous fuel consumption record Reset the past record data Update the past record data “Trip Information” screen appears The image is an example only, and may vary slightly from actual conditions.
Page 266 3. Instrument cluster How to see the detail screen Displays information about each selected item. When you select the “”, and close the screen. Select “Battery” ■ ● Display of battery charging state Displayed when charging from an external power supply. Display of charge status The remaining time until the charging completed...
Page 267 3. Instrument cluster Select “Engine” ■ Display of the engine status. Select “Climate” ■ Display the power consump- tion of the air conditioner ■ Resetting the data ● Selecting “Clear” on the “Trip Information” screen will reset the trip informa- tion data.
Page 268 3. Instrument cluster PRIUS PRIME_OM_OM47D13U_(U)
Page 269: Operation Of Each Component
Operation of each component 4-1. Key information Keys ........270 4-2. Opening, closing and locking the doors Side doors......275 Back door......281 Smart key system ..... 286 4-3. Adjusting the seats Front seats ......295 Rear seats......297 Head restraints....299 4-4.
Page 270: Keys
Locks all the doors (P. 276) Unlocks all the doors (P. 276) Opens the side windows (P. 276) Operates Remote Air Condi- tioning System (P. 518) Sounds the alarm (P. 271) : This setting must be customized at your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 271 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using another mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 272 You can replace the battery by yourself (P. 633). However, as there is a danger that the electronic key may be damaged, it is recommended that replacement is carried out by your Toyota dealer. ● To avoid serious deterioration, do not leave the electronic key within 3 ft.
Page 273 If this message is displayed but you have not had a new electronic key regis- tered, ask your Toyota dealer to check if an unknown electronic key (other than those in your possession) has been registered.
Page 274 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. PRIUS PRIME_OM_OM47D13U_(U)
Page 275: Side Doors
4-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control or door lock switches. Unlocking and locking the doors from the outside ◆ Smart key system Carry the electronic key to enable this function.
Page 276 3 seconds unlocks the other doors. Press and hold to open the side windows. : This setting must be customized at your Toyota dealer. ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 277 4-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 278 4-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 279 4-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the power switch off. When the indicator on the key surface is turned off, push and hold , “A/C”...
Page 280 4-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehicle, resulting in death or serious injury. ●...
Page 281: Back Door
4-2. Opening, closing and locking the doors Back door The back door can be unlocked/locked and opened/closed by the following procedures. ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
Page 282 4-2. Opening, closing and locking the doors When closing the back door Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it. Be careful not to pull the back door sideways when closing the back door with the handle.
Page 283 4-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 284 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. PRIUS PRIME_OM_OM47D13U_(U)
Page 285 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 286: Smart Key System
4-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Unlocks and locks the doors (P. 275) ●...
Page 287 4-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of driver’s door handle, front passenger’s door handle back door opener switch .
Page 288 When “Smart Key System malfunction See owner’s manual” is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time.
Page 289 4-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system, wireless remote control and immobilizer system use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating prop- erly.
Page 290 4-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 291 4-2. Opening, closing and locking the doors ■ When the vehicle is not driven for extended periods ● To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. (P. 739) ■...
Page 292 4-2. Opening, closing and locking the doors ■ Certification for the smart key system For vehicles sold in the U.S.A. and Hawaii  PRIUS PRIME_OM_OM47D13U_(U)
Page 293 4-2. Opening, closing and locking the doors For vehicles sold in Canada  PRIUS PRIME_OM_OM47D13U_(U)
Page 294 (P. 286) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 295: Adjusting The Seats
4-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) Power seat (if equipped for driver’s side)  Seat position adjustment switch Seat cushion (front) angle adjustment switch...
Page 296 4-3. Adjusting the seats ■ When adjusting the seat Take care when adjusting the seat so that the head restraint does not touch the ceiling. WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat.
Page 297: Rear Seats
4-3. Adjusting the seats Rear seats The seatbacks can be folded down. Before folding down the seatbacks Park the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P. 339) Adjust the position of the front seat and the angle of the seatback. P.
Page 298 4-3. Adjusting the seats WARNING ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, apply the parking brake firmly and shift the shift position to P.
Page 299: Head Restraints
4-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats To fold Pull the head restraint up while pressing the lock release button.
Page 300 4-3. Adjusting the seats ■ Removing the head restraints Front seats  Pull the head restraint up while pressing the lock release button. Lock release button Rear seats  Pull the seatback lock release lever and fold down the seatback until it reaches the position where the head restraints can be removed.
Page 301 4-3. Adjusting the seats Rear seats  Pull the seatback lock release lever and fold down the seatback until it reaches the position where the head restraints can be installed. Align the head restraint with the installa- tion holes and push it down to the low- est lock position.
Page 302: Steering Wheel
4-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. IO44PH004 Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 303 4-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 304: Inside Rear View Mirror
4-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 305 4-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 306: Outside Rear View Mirrors
4-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, operate the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 307 4-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The power switch is in ACCESSORY or ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defog- gers.
Page 308: 4-5. Opening And Closing The Windows
4-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the side windows as follows: Closing One-touch closing Opening One-touch opening : To stop the side window partway, operate the switch in the opposite direction.
Page 309 The power windows can be opened and closed using the mechanical key. (P. 697) ● The power windows can be opened using the wireless remote control. (P. 276) : These settings must be customized at your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 310 4-5. Opening and closing the windows ■ When the 12-volt battery is disconnected The window lock switch is disabled. If necessary, press the window lock switch after reconnecting the 12-volt battery. ■ Power window open reminder function The buzzer sounds and a message is shown on the multi-information display in the instrument cluster when the power switch is turned off and the driver’s door is opened with the power windows open.
Page 311 4-5. Opening and closing the windows WARNING ■ Jam protection function ● Never use any part of your body to intentionally activate the jam protection function. ● The jam protection function may not work if something gets jammed just before the side window is fully closed. Be careful not to get any part of your body jammed in the side window.
Page 312 4-5. Opening and closing the windows PRIUS PRIME_OM_OM47D13U_(U)
Page 313: Driving
Driving 5-1. Before driving 5-5. Using the driving support systems Driving the vehicle..... 314 Toyota Safety Sense P ..369 Cargo and luggage ... 326 PCS (Pre-Collision Vehicle load limits ..... 329 System)......377 Trailer towing..... 330 LDA (Lane Departure Dinghy towing ....
Page 314: Driving The Vehicle
5-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Before starting the hybrid system Check that the charging cable is disconnected. (P. 139) Starting the hybrid system P. 332 Driving With the brake pedal depressed, shift the shift position to D. (P.
Page 315 5-1. Before driving Parking the vehicle Stop the vehicle completely. Set the parking brake. (P. 345) Shift the shift position to P. (P. 339) Check that the shift position indicator shows P. Press the power switch to stop the hybrid system. Slowly release the brake pedal.
Page 316 5-1. Before driving ■ “ECO Accelerator Guidance” (P. 221) It is easier to drive in an Eco-friendly manner by driving while referring to the “ECO Accelerator Guidance” display. Also, by using the “ECO Accelerator Guidance”, it is easier to increase the Eco score evaluation. ●...
Page 317 5-1. Before driving ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 200 miles (300 km): Avoid sudden stops. ● For the first 600 miles (1000 km): •...
Page 318 5-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 319 5-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Use engine braking (shift position B instead of shift position D) to maintain a safe speed when driving down a steep hill. Using the brakes continuously may cause the brakes to overheat and lose effectiveness.
Page 320 5-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When shifting the shift position ● Do not let the vehicle roll backward while a forward driving position is selected, or roll forward while the shift position is in R. Doing so may result in an accident or damage to the vehicle.
Page 321 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 322 5-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 323 5-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating.
Page 324 5-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the hybrid system output. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 325 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 326: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 329) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. PRIUS PRIME_OM_OM47D13U_(U)
Page 327 5-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 716) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 328 5-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: Receptacles containing gasoline ● ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 329: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 330: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 331: Dinghy Towing
5-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. IO51PH003 NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. PRIUS PRIME_OM_OM47D13U_(U)
Page 332: 5-2. Driving Procedures
5-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the charging cable is disconnected. (P. 139) Check that the parking brake is set.
Page 333 5-2. Driving procedures Stopping the hybrid system Stop the vehicle completely. Set the parking brake. (P. 345) Shift the shift position to P. (P. 339) Check that the shift position indica- tor shows P. (P. 338) Press the power switch. The hybrid system will stop.
Page 334 5-2. Driving procedures Changing power switch modes Modes can be changed by pressing the power switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 335 SORY mode. In this case, ACCESSORY mode may be turned off by applying the parking brake and pressing the power switch again. If there is a malfunc- tion in the system, have the vehicle inspected by your Toyota dealer immedi- ately.
Page 336 5-2. Driving procedures ■ Meter display When the power switch is turned off, each display will turn off as follows. ● The shift position indicator will turn off after approximately 2 seconds. ● The multi-information display, clock, etc. will turn off after approximately 30 seconds.
Page 337 ■ When starting the hybrid system If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 338: Hybrid Transmission
5-2. Driving procedures Hybrid transmission Shifting the shift lever Shift lever Operate the shift lever gently and ensure correct shifting operation. Release the shift lever after each shifting operation to allow it to return to position. When shifting to the D or R, move the shift lever along the shift gate.
Page 339 5-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the hybrid system Reversing Neutral (Condition in which the power is not transmitted) Normal driving Applying engine braking or strong braking when the accelerator pedal has been released on steep down- ward slopes etc.
Page 340 5-2. Driving procedures ■ For the shift positions ● When the power switch is off, the shift position cannot be changed. ● When the power switch is in ON mode (the hybrid system is not operating), the shift position can only be changed to N. The shift position will be changed to N even if the shift lever is shifted to D or R and held in that posi- tion.
Page 341 5-2. Driving procedures ■ Reverse warning buzzer When shifting into R, a buzzer will sound to inform the driver that the shift position is in R. ■ Restraining sudden start (Drive-Start Control) P. 316 ■ Automatic P position selection function ●...
Page 342 Shift lever and P position switch ● Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 343 If any of the following situations occurs, shift control system malfunctions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● When the warning message indicating the shift control system appears on the multi-information display.
Page 344: Turn Signal Lever
5-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 345: Parking Brake
5-2. Driving procedures Parking brake Operating instructions To set the parking brake, fully depress the parking brake pedal with your left foot while depress- ing the brake pedal with your right (U.S.A.) foot. (Depressing pedal again releases the parking brake.) (Canada) ■...
Page 346: Headlight Switch
5-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: U.S.A. (type A)  daytime running lights turn on. (P. 349) The side marker, park- ing, tail, license plate, instrument panel lights, daytime...
Page 347 5-3. Operating the lights and wipers U.S.A. (type B)  headlights, side marker, parking, LED (if equipped) accent (if equipped), daytime running lights (P. 349) and so on turn on and off automat- ically (when the power switch is in ON mode). The side marker, park- ing, LED accent (if equipped), tail, license...
Page 348 5-3. Operating the lights and wipers Canada  headlights, side marker, parking, LED accent equipped), daytime running lights (P. 349) and so on turn on and off automat- ically (when the power switch is in ON mode). The side marker, park- ing, accent equipped), tail, license...
Page 349 5-3. Operating the lights and wipers ■ Daytime running light system ● The daytime running lights illuminate using the same lights as the head- lights, and illuminate dimmer than the headlights. ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically when all of the following conditions are met.
Page 350 5-3. Operating the lights and wipers ■ Automatic light off system ● When the headlights come on: The headlights and tail lights turn off 30 sec- onds after a door is opened and closed if the power switch is turned to ACCESSORY mode or turned off.
Page 351: Automatic High Beam
5-3. Operating the lights and wipers Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 352 5-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 353 5-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 21 mph (34 km/h). •...
Page 354 5-3. Operating the lights and wipers ● In the situations shown below, the system may not be able to accurately detect surrounding brightness levels. This may cause the low beams to remain on or the high beams to cause problems for pedestrians, vehicles ahead or other parties.
Page 355 5-3. Operating the lights and wipers ■ Temporarily lowering sensor sensitivity The sensitivity of the sensor can be temporarily lowered. Turn the power switch off while the following conditions are met. • The headlight switch is in • The headlight switch lever is in high beam position. •...
Page 356: Fog Light Switch
5-3. Operating the lights and wipers Fog light switch  The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operating instructions Type A  Turns the fog lights off Turns the fog lights on ...
Page 357 5-3. Operating the lights and wipers Type B  Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam. NOTICE ■ To prevent 12-volt battery discharge Do not leave the lights on longer than necessary when the hybrid system is off.
Page 358: Windshield Wipers And Washer
5-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows. Intermittent windshield wipers with interval adjuster (if ■ equipped) Type A  Intermittent operation Low speed operation High speed operation Temporary operation Type B...
Page 359 5-3. Operating the lights and wipers Wiper intervals can be adjusted when intermittent operation is selected. Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wipers will automatically operate a couple of times after the washer squirts.
Page 360 5-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped) ■ Type A  Rain-sensing opera- tion Low speed operation High speed operation Temporary operation Type B  Rain-sensing operation Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain.
Page 361 5-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wipers will automatically operate a couple of times after the washer squirts.
Page 362 5-3. Operating the lights and wipers ■ The windshield wipers and washer can be operated when The power switch is in ON mode. ■ Dripping prevention wiper sweep (vehicles with rain-sensing windshield wipers) After washing and wiping operation several times, the wipers operate one more time after a short delay to prevent dripping.
Page 363 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent 12-volt battery discharge Do not leave the wipers on longer than necessary when the hybrid system is off.
Page 364: Cap
5-4. Refueling Opening the fuel tank cap The fuel tank of your vehicle has a special structure, which requires a reduction in fuel tank pressure before refueling. After the opener switch has been pressed, it will take several seconds until the vehicle is ready for refueling. Before refueling the vehicle ●...
Page 365 5-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 366: Refueling
5-4. Refueling NOTICE ■ Refueling ● Finish refueling within 30 minutes. If more than 30 minutes passes, the internal valve closes. In this condition, fuel may overflow during the refuel- ing process. Press the fuel filler door opener switch again. ●...
Page 367 5-4. Refueling ■ When the fuel filler door cannot be opened by pressing the inside switch Open the back door and remove the cover underneath the luggage compart- ment light. Pull the lever backward and check that the fuel lid opens. Using the lever to open the fuel filler door may not allow for an adequate reduction in fuel tank pressure before refueling.
Page 368 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 369: Using The Driving Support Systems
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 370 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 371 5-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor PRIUS PRIME_OM_OM47D13U_(U)
Page 372 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 373 • To replace the wiper insert: P. 630 • If the wiper blades need to be replaced, contact your Toyota dealer. ● Do not attach window tinting to the windshield.
Page 374 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 375 5-5. Using the driving support systems ■ Certification For vehicles sold in the U.S.A. and Hawaii  PRIUS PRIME_OM_OM47D13U_(U)
Page 376 5-5. Using the driving support systems For vehicles sold in Canada  PRIUS PRIME_OM_OM47D13U_(U)
Page 377: Pcs (Pre-Collision System)
5-5. Using the driving support systems PCS (Pre-Collision System) The pre-collision system uses a radar sensor and camera sen- sor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal col- lision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 378 5-5. Using the driving support systems ◆ Pre-collision brake assist When the system determines that the possibility of a frontal colli- sion is high, the system applies greater braking force in relation to how strongly the brake pedal is depressed. ◆...
Page 379 5-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 380 5-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 381 5-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on the screen (P. 239) of the multi-information display. The system is automatically enabled each time the power switch is turned to ON mode.
Page 382 5-5. Using the driving support systems ■ Operational conditions The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high. Each function is operational at the following speeds: ●...
Page 383 5-5. Using the driving support systems ■ Pedestrian detection function The pre-collision system detects pedestri- ans based on the size, profile, and motion of a detected object. However, a pedes- trian may not be detected depending on the surrounding brightness motion, posture, angle...
Page 384 5-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adja- cent lane may change, such as on a winding road • When rapidly closing on a vehicle ahead • If the front of the vehicle is raised or lowered, such as when the road sur- face is uneven or undulating •...
Page 385 5-5. Using the driving support systems • When passing under an object (bill- board, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
Page 386 5-5. Using the driving support systems • If a vehicle ahead is carrying a load which protrudes past its rear bumper • If a vehicle ahead has extremely high ground clearance • If a vehicle ahead is irregularly shaped, such as a tractor or side car •...
Page 387 5-5. Using the driving support systems • If the front of the vehicle is raised or lowered • If the wheels are misaligned • If a wiper blade is blocking the camera sensor • The vehicle is wobbling. • The vehicle is being driven at extremely high speeds. •...
Page 388 If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 389: Lda (Lane Departure Alert With Steering Control)
5-5. Using the driving support systems LDA (Lane Departure Alert with steering control) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane and provides assistance by operating the steering wheel to keep the vehicle in its lane.
Page 390 5-5. Using the driving support systems ◆ Steering control function When the system determines that the vehicle might depart from its lane, the system pro- vides assistance as necessary by operating the steering wheel in small amounts for a short period of time to keep the vehi- cle in its lane.
Page 391 5-5. Using the driving support systems WARNING ■ Before using LDA system Do not rely solely upon the LDA system. The LDA system does not auto- matically drive the vehicle or reduce the amount of attention that must be paid to the area in front of the vehicle. The driver must always assume full responsibility for driving safely by paying careful attention to the surround- ing conditions and operating the steering wheel to correct the path of the vehicle.
Page 392 Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. Turning LDA system on Press the LDA switch to turn the LDA system on.
Page 393 5-5. Using the driving support systems Indications on combination meter LDA indicator Illuminates when the LDA sys- tem is on. Steering control indicator and operation display of steering wheel operation support When that steering wheel assistance of the steering con- trol function is operating, the indicator illuminates and the operation display on the multi-...
Page 394 5-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 395 5-5. Using the driving support systems ■ Temporary cancelation of functions When the operation conditions are no longer met, a function may be tempo- rarily canceled. However, when the operation conditions are met again, oper- ation of the function is automatically restored. (P. 394) ■...
Page 396 5-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 397 The system may not be operating “Lane Departure Alert properly. Malfunction  Have the vehicle inspected at your Visit Your Dealer” Toyota dealer. Dirt, rain, condensation, ice, snow, etc. are present on the windshield in “Forward Camera front of the camera sensor. System ...
Page 398 5-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert function Adjust alert sensitivity Steering control function Turn steering wheel assistance on and off Turn function on and off Vehicle sway warning function Adjust alert sensitivity For how to change settings, refer to P.
Page 399: Dynamic Radar Cruise Control With Full-Speed Range
5-5. Using the driving support systems Dynamic radar cruise controlwith full-speed range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 400 5-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control with full-speed range ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 401 5-5. Using the driving support systems WARNING ■ Cautions regarding the driving assist systems Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. ●...
Page 402 5-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control with full-speed range Do not use dynamic radar cruise control with full-speed range in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 403 5-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 328 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 404 5-5. Using the driving support systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance switch.
Page 405 5-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 406 5-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed (Except when the vehicle has been stopped by system control in vehi- cle-to-vehicle distance control...
Page 407 5-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 408 5-5. Using the driving support systems Resuming follow-up cruising when the vehicle has been stopped by system control (vehicle-to-vehicle distance control mode) After the vehicle ahead of you starts off, push the lever up. Your vehicle will also resume fol- low-up cruising if the accelerator pedal is depressed after the vehi- cle ahead of you starts off.
Page 409 5-5. Using the driving support systems Approach warning (vehicle-to-vehicle distance control mode) When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the display will flash and the buzzer will sound to alert the driver.
Page 410 5-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 411 • The vehicle has been stopped for about 3 minutes. In this situation, the shift position may automatically switch to P. (P. 341) If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 412 ● Pre-collision braking is activated. If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 413 5-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 414 5-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 415: Driving Mode Select Switch
5-5. Using the driving support systems Driving mode select switch In response to driving conditions, one of 3 driving modes can be selected. Driving modes Repeatedly press the switch until the system changes to the intended driving mode. Each time the switch is pressed, the driving mode changes in the following “ECO MODE”...
Page 416 5-5. Using the driving support systems Normal mode Suitable for normal driving. When normal mode is selected, the “ECO MODE” and “PWR MODE” indicators turn off. Power mode Suitable for when crisp handling and enhanced accelerator response are desired, such as when driving on mountainous roads. When power mode is selected, the “PWR MODE”...
Page 417: (Blind Spot Monitor)
5-5. Using the driving support systems BSM (Blind Spot Monitor)  Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 418 5-5. Using the driving support systems The Blind Spot Monitor on/off screen and indicator The Blind Spot Monitor function and Rear Cross Traffic Alert function can be switched on and off using the multi-information display. (P. 239) When switched on, the BSM indicator illuminates on the meter and the buzzer sounds.
Page 419 When “Blind Spot Monitor System Malfunction Visit Your Dealer” is shown on the multi-information display There may be a sensor malfunction or misaligned. Have the vehicle inspected by your Toyota dealer. ■ Certification for the Blind Spot Monitor For vehicles sold in U.S.A.
Page 420 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. PRIUS PRIME_OM_OM47D13U_(U)
Page 421: The Blind Spot Monitor Function
5-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicle’s existence via the outside rear view mirror indicator.
Page 422 5-5. Using the driving support systems WARNING ■ Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. The Blind Spot Monitor function is a supplementary function which alerts the driver that a vehicle is present in the blind spot.
Page 423 5-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing situations: • When the sensor is misaligned due to a strong impact to the sensor or its surrounding area •...
Page 424: The Rear Cross Traffic Alert Function
5-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 425 5-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. IO55PH088 To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away.
Page 426 5-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects: ● Vehicles approaching from directly behind ●...
Page 427 5-5. Using the driving support systems • When backing up on a slope with a sharp change in grade • When backing out of a shallow angle parking spot • Immediately after the Blind Spot Monitor main switch is turned on •...
Page 428 5-5. Using the driving support systems ● Instances of the Rear Cross Traffic Alert function unnecessarily detecting a vehicle and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
Page 429: Intuitive Parking Assist
5-5. Using the driving support systems Intuitive parking assist  The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the displays and a buzzer. Always check the surrounding area when using this system.
Page 430 5-5. Using the driving support systems Display When the sensors detect an obstacle, the following displays inform the driver of the position and distance to the obstacle. Multi-information display ■ Front center sensor opera- tion Front corner sensor opera- tion Front side sensor operation Rear side sensor operation Rear corner sensor operation...
Page 431 5-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Front corner, front Rear corner, rear Display center and front side center and rear side sensors sensors 3.3 ft.
Page 432 5-5. Using the driving support systems Buzzer When an obstacle is detected, the buzzer sounds. ● As the obstacle is approached, the buzzer sounds more rapidly. When the obstacle is extremely close, the buzzer switches from sounding intermittently (short beeps) to continuously (a long beep). •...
Page 433 5-5. Using the driving support systems Detection range of the sensors Approximately 3.3 ft. (100 cm) Approximately 4.9 ft. (150 cm) Approximately 2.0 ft. (60 cm) Approximately 3.3 ft. (100 cm) • The detection range is shown in the illustration to the right. How- ever, the sensor will not detect the obstacle if it is too close.
Page 434 5-5. Using the driving support systems ■ Sensor detection information ● The sensor’s detection areas are limited to the areas around the vehicle’s bumper. ● Depending on the shape of the obstacle and other factors, the detection dis- tance may shorten, or detection may be impossible. ●...
Page 435 If “Parking Assist Malfunction” is displayed on the multi-information dis- play Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Toyota dealer. ■ Certification (Canada only) This ISM device complies with Canadian ICES-001.
Page 436 If obstacles draw too close to the sensor. ● The bumper or sensor receives a strong impact. ● A non-genuine Toyota suspension (lowered suspension etc.) is installed. ● There is another vehicle equipped with parking assist sensors in the vicin- ity.
Page 437 5-5. Using the driving support systems WARNING ■ Side sensors In the following situations, the intuitive parking assist may not operate nor- mally and may result in an unexpected accident. Drive carefully. ● Obstacles may not be detected in the side areas until the vehicle is driven for a short time and a scan of the side areas is completed.
Page 438 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● Intuitive parking assist operation display flashes, and a beep sounds when no obstacles are detected.
Page 439: Intelligent Clearance Sonar
5-5. Using the driving support systems Intelligent Clearance Sonar  When a collision may occur with an obstacle while parking or traveling at low speeds, when the vehicle suddenly moves for- ward due to mistaken accelerator pedal operation, or when the vehicle moves due to the wrong shift position being selected, the sensors detect obstacles to the front or rear in the traveling direction of the vehicle, and the system operates to lessen...
Page 440 5-5. Using the driving support systems ◆ The vehicle moves due to the wrong shift position being selected Types of sensors Front corner sensors Front center sensors Rear corner sensors Rear center sensors Changing settings of the Intelligent Clearance Sonar The Intelligent Clearance Sonar can be enabled/disabled on the screen (P.
Page 441 5-5. Using the driving support systems Operation When the Intelligent Clearance Sonar function detects an obstacle with a probability of collision, hybrid system output is restricted to restrain an increase in vehicle speed. (Hybrid system output restric- tion control: A) Furthermore, when the accelerator pedal continues to be depressed, the brakes are applied to reduce the vehicle speed.
Page 442 5-5. Using the driving support systems Accelerator pedal Control starts Brake pedal Collision is possible Hybrid system output Collision is likely Braking force PRIUS PRIME_OM_OM47D13U_(U)
Page 443 5-5. Using the driving support systems Operation conditions Operation starting conditions ■ When the ICS OFF indicator is not illuminated or flashing (P. 448, 662) and all of the following conditions are met, the system operates. Hybrid system output restriction control ...
Page 444 5-5. Using the driving support systems Display and buzzer for hybrid system output restriction control and brake control When the hybrid system output restriction control or brake control operates, the buzzer sounds and a message is displayed on the multi- information display to alert the driver.
Page 445 5-5. Using the driving support systems ■ Sensor detection range The detection range of the Intelligent Clearance Sonar function differs from the detection range of the intuitive parking assist (P. 433). Therefore, even if the intuitive parking assist detects an obstacle and pro- vides a warning, the Intelligent Clearance Sonar may not start operating.
Page 446 5-5. Using the driving support systems ■ Situations when the system may operate even though there is no possi- bility of a collision In the following situations, the system may operate even though there is no possibility of a collision. ●...
Page 447 5-5. Using the driving support systems ● Changes in the vehicle • The vehicle is tilted a large amount • The height of the vehicle has drastically changed due to the carried load (the nose tilts up or down) • The direction of the sensor has deviated due to a collision or other impact ■...
Page 448 If this message is shown even after removing dirt from the sensor, or shown when the sensor was not dirty to begin with, have the vehicle inspected at your Toyota dealer. ● System initialization may not have been performed after removal and instal- lation of the 12-volt battery.
Page 449 5-5. Using the driving support systems WARNING ■ For safe use Do not rely solely upon the system. Relying solely upon the system may lead to an unexpected accident. ● Driving safely is the sole responsibility of the driver. Pay careful attention to the surrounding conditions in order to ensure safe driving.
Page 450 If the area around a sensor is subjected to an impact, equipment may not operate properly due to a sensor malfunction. Have the vehicle inspected at your Toyota dealer. ● When using a high-pressure washer to wash the vehicle, do not spray water directly on the sensors.
Page 451: S-Apgs (Simple Advanced Parking Guidance System)
5-5. Using the driving support systems S-APGS (Simple Advanced Parking Guidance System)  Simple Advanced Parking Guidance System Function summary ■ The Simple Advanced Parking Guidance System automatically operates the steering wheel to provide support when backing into an area near a target parking spot, and when departing from a par- allel parking spot.
Page 452 5-5. Using the driving support systems Chart of Simple Advanced Parking Guidance System assist modes and functions Type of Assist mode Function summary See page parking Guidance is provided to detect intended parking spot and reach a position to begin back- Parallel parking Parallel park-...
Page 453 5-5. Using the driving support systems ■ Intelligent Clearance Sonar function while the Simple Advanced Parking Guidance System is operating While the Simple Advanced Parking Guidance System is operating, if the sys- tem detects an obstacle that could result in a collision, hybrid system output restriction control and brake control of the Intelligent Clearance Sonar func- tion are operated, regardless of whether the Intelligent Clearance Sonar func- tion is on or off.
Page 454 5-5. Using the driving support systems Switching assist mode Switching using the S-APGS switch ■ Press the switch This allows you to switch func- tions and cancel or restart assist modes. IO55PH104 While the power switch is on, the vehicle speed is approximately 19 mph (30 km/h) or less, each time the S-APGS switch is pressed the function switches as follows.
Page 455 5-5. Using the driving support systems Guidance screen The guidance screen is displayed on the multi-information display. Assistance level indicator Displays a gauge indicating the level until the vehicle’s stopping position/the position at which assist control ends. Stop display When illuminated, depress the brake pedal and stop the vehicle at once.
Page 456 5-5. Using the driving support systems Canceling or stopping assist mode Assist mode will be canceled or stopped in the following cases. Assist control is canceled when ■ ● The system temperature preservation function operates ● There is a system malfunction ●...
Page 457 5-5. Using the driving support systems How to parallel park (parallel parking assist mode) Function summary ■ If a parking space can be detected, you will be guided forward until you reach the assist control starting position, and then the parallel parking assist mode can be used.
Page 458 5-5. Using the driving support systems Parking ■ Stop so that the center of the target parking spot appears nearly perpendicular to vehicle. Then press the S-APGS switch 1 time and check that the display on the multi-information display switches to “Parallel Parking”. ●...
Page 459 5-5. Using the driving support systems Travel straight ahead paral- lel with the road (or curb), maintain approximately 3.3 ft. (1 m) from any parked vehicles. ● Proceed slowly. ● The system will begin searching for a parking 3.3 ft. space.
Page 460 5-5. Using the driving support systems When a beep sounds once and the stop display (P. 455) is shown on the display, stop the vehicle. When the shift position is changed to R, a high-pitched beep is emitted and assist control will start. ●...
Page 461 5-5. Using the driving support systems When a beep sounds once and the stop display (P. 455) is shown on the display, stop the vehicle. Change the shift position to D. Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around the vehicle and slowly proceed forward while adjusting your speed by depressing...
Page 462 5-5. Using the driving support systems When the vehicle is almost entirely within the target parking spot, a high-pitched beep is emitted and the stop display is shown on the display, stop the vehicle. This completes the parallel parking assist mode. ●...
Page 463 5-5. Using the driving support systems NOTICE ● If the road surface has any dips or inclines, the target parking spot cannot be correctly set. Therefore, the vehicle may be parked at an angle or may deviate from the parking spot. In these cases, do not use the parallel park- ing assist mode.
Page 464 5-5. Using the driving support systems How to depart from a parallel parking position (exit parallel park- ing assist mode) Function summary ■ When departing from a parallel parking position, select the direction you would like to depart in, and steering wheel operation assist con- trol will be provided to guide the vehicle to a position from which you can take off.
Page 465 5-5. Using the driving support systems Using the exit parallel parking assist mode to depart ■ With the shift position in P, press the S-APGS switch and check that the display on the multi-information display switches to “Exit Parallel Parking”. Operate the turn signal lever (P.
Page 466 5-5. Using the driving support systems When a beep sounds once and the stop display (P. 455) is shown on the display, stop the vehicle. Change the shift position to D. Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around the vehicle and slowly proceed forward while adjusting your speed by depressing...
Page 467 5-5. Using the driving support systems When a beep sounds once and the stop display (P. 455) is shown on the display, stop the vehicle. Change the shift position to R. Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle and slowly back up while adjusting your speed by depressing the...
Page 468 5-5. Using the driving support systems Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around the vehicle and slowly proceed forward while adjusting your speed by depressing the brake pedal.
Page 469 5-5. Using the driving support systems How to park next to other vehicles (back-in parking assist mode) Function summary ■ Stop so that the center of the target parking spot appears nearly perpendicular to the vehicle. If the space is detectable, the forward guidance function can be used.
Page 470 5-5. Using the driving support systems Parking ■ Stop so that the center of the target parking spot appears nearly perpendicular to vehi- cle. Then press the S-APGS switch 2 times and check that the display on the multi-infor- mation display switches to “Back-in Parking”.
Page 471 5-5. Using the driving support systems Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around vehicle slowly proceed forward while adjusting your speed...
Page 472 5-5. Using the driving support systems Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle, confirm that there are no obstacles in the parking space, and slowly back up while adjusting your speed by depressing the brake pedal.
Page 473 5-5. Using the driving support systems Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle slowly back up while adjusting your speed by depressing the brake pedal.
Page 474 5-5. Using the driving support systems ● Depending on the condition of the park- ing space, if there is not enough space in front of the vehicle required to perform the parking operation, the target parking spot may not be reachable. Intended parking spot Wall ■...
Page 475 The system may be malfunctioning.  Turn the power switch off and then start the hybrid system. Have the vehicle inspected by your Toyota dealer if the message is displayed again. There may be a system failure. Power steering equipment is temporarily overheat- ing.
Page 476 5-5. Using the driving support systems Message Situation/Handling method The vehicle is moved and assist control is started while the steering wheel is held.  Stop the vehicle and follow the guidance pro- vided by the system to start assist control. The S-APGS switch is operated when there is not enough space to the front and rear of the vehicle when departing from a parallel parking spot.
Page 477 5-5. Using the driving support systems Message Situation/Handling method The S-APGS switch is operated in an area where there are obstacles to the front, and the vehicle can- not move forward to the starting point for backing  Assist control cannot be used, as there are obstacles in front of the vehicle.
Page 478 5-5. Using the driving support systems Message Situation/Handling method The maximum number of movements for multi-turn maneuvering is reached during assist control, or the target parking spot cannot be reached due to the control being used on a road with steep grade. ...
Page 479 5-5. Using the driving support systems Message Situation/Handling method The vehicle moved  Press S-APGS too close to an obsta- switch after changing cle in front of the the shift position to R to vehicle. restart assist control. The vehicle moved ...
Page 480 5-5. Using the driving support systems Precautions during use Sensors ■ Detect the vehicle to help determine the parking spot. Front side sensors Rear side sensors ● The sensor detection range when using back-in parking assist mode Intended parking spot ●...
Page 481 5-5. Using the driving support systems ● When there is a parked vehicle behind the target parking spot, it may not be detected due to the distance. Also, depending on the shape of the vehicle and other conditions, the detectable range may shorten or detection may not be possible.
Page 482 5-5. Using the driving support systems WARNING ● Do not rely solely upon the Simple Advanced Parking Guidance System. As with unequipped vehicles, move forward and back up carefully while directly confirming the safety of your surroundings and the area to the rear of the vehicle.
Page 483 • Using tire chains ● Do not use tire other than that provided by the manufacturer. The system may not operate properly. When replacing tires, contact your Toyota dealer. ● The system may not be able position the vehicle in the set location in the following situations.
Page 484 If the vehicle bumper strikes something, equipment may not operate properly due to a sensor malfunction. Have the vehicle inspected at your Toyota dealer. ● In the following situations, the sensors may not operate normally and may lead to an accident.
Page 485: Driving Assist Systems
5-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 486 5-5. Using the driving support systems ◆ Hill-start assist control Helps to reduce the backward movement of the vehicle when start- ing on an uphill ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel.
Page 487 When the message is displayed on the multi-information display show- ing that TRAC has been disabled even if has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC, TRAC and hill-start assist control systems ●...
Page 488 5-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid system off.
Page 489 5-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick road. ■...
Page 490 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 491: Driving Tips
5-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 492 5-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and shift the shift position to P and block the wheel under the vehicle without setting the parking brake.
Page 493 5-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 494 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 495: Interior Features
Interior features 6-1. Using the air conditioning 6-2. Using the interior lights system and defogger Interior lights list ....524 Automatic air conditioning • Front interior light..525 system (vehicles with • Front personal lights ..525 7-inch display)....496 •...
Page 496: 7-Inch Display)
6-1. Using the air conditioning system and defogger Automatic air conditioning system (vehi- cles with 7-inch display) Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Adjusting the temperature setting ■ Move the temperature setting knob upwards to increase the temperature and downwards to decreases the temperature.
Page 497 6-1. Using the air conditioning system and defogger Change the airflow mode ■ Move the airflow change knob upwards downwards change the airflow mode. outlets used switched each time the knob is operated. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Airflow change...
Page 498 6-1. Using the air conditioning system and defogger Manual S-FLOW mode  When is pressed, S-FLOW mode will be manually enabled/disabled. (P. 503) indicator will illuminate when S-FLOW mode is enabled. When the power switch is turned to ON mode, the system is oper- ated in automatic S-FLOW mode.
Page 499 6-1. Using the air conditioning system and defogger Using automatic mode Press Adjust the temperature setting. (P. 496) To stop the operation, press Automatic mode indicator ■ If the fan speed setting or air flow modes are operated, the indicator goes off. However, automatic mode for functions other than that operated is maintained.
Page 500 6-1. Using the air conditioning system and defogger Defogging the windshield ■ Defoggers are used to defog the windshield and front side win- dows. Press to outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 501 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume change according selected airflow mode. Adjusting the air flow direction ■ Direct air flow to the left or right, up or down.
Page 502 6-1. Using the air conditioning system and defogger ■ Heating ● In HV mode, the gasoline engine may operate in order to extract heat from the engine coolant via the heater. ● In EV mode, heating is done by a heat pump system. •...
Page 503 6-1. Using the air conditioning system and defogger ■ Setting confirmation screen When changing the settings of the air conditioning system, the setting confirma- tion screen is shown as a pop-up on the multi-information display. Press of the meter control switches to go back to the previous screen.
Page 504 6-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode ● When driving on dusty roads such as tunnels or in heavy traffic, set to the recirculated air mode. This is effective in preventing outside air from entering the vehicle interior. During cooling operation, setting the recircu- lated air mode will also cool the vehicle interior effectively.
Page 505 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ● To let the fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 506 6-1. Using the air conditioning system and defogger NOTICE ■ Humidity sensor In order to detect fog on the windshield, a sensor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 503) Follow these points to avoid damaging the sensor: ●...
Page 507: Automatic Air Conditioning System (Vehicles With 11.6-Inch Display)
6-1. Using the air conditioning system and defogger Automatic air conditioning system (vehi- cles with 11.6-inch display) Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioner information area The following informations are displayed on the navigation system screen.
Page 508 6-1. Using the air conditioning system and defogger Air conditioning control screen conditioning control screen can be displayed by touch- ing the air conditioner information area on the navigation system screen. Air conditioning controls Adjusting the temperature setting ■ Press “” on to increase the temperature and “”...
Page 509 6-1. Using the air conditioning system and defogger S-FLOW mode ■ In S-FLOW mode, priority for the airflow is given to the front seats, reducing the airflow and air conditioning effect on the rear seats. When a passenger is not detected in the front passenger seat, depending on the set temperature and ambient temperature, prior- ity for the airflow will be given to the driver’s seat only.
Page 510 6-1. Using the air conditioning system and defogger Automatic mode indicator ■ If the fan speed setting or air flow modes are operated, the indicator goes off. However, automatic mode for func- tions other than that operated is maintained. Other functions Switching between outside air and recirculated air modes ■...
Page 511 6-1. Using the air conditioning system and defogger Defogging the rear window and outside rear view mirrors ■ Defoggers are used to defog the rear window and to remove rain- drops, dew and frost from the outside rear view mirrors. Press Defoggers switch between on and off each time is pressed.
Page 512 6-1. Using the air conditioning system and defogger Adjusting the air flow direction ■ Direct air flow to the left or right, up or down. Opening and closing the air outlets ■ Left side outlet/right side outlet Center outlets  ...
Page 513 6-1. Using the air conditioning system and defogger ■ Heating ● In HV mode, the gasoline engine may operate in order to extract heat from the engine coolant via the heater. ● In EV mode, heating is done by a heat pump system. •...
Page 514 6-1. Using the air conditioning system and defogger ■ Setting confirmation screen When changing the settings of the air conditioning system, the setting confirma- tion screen is shown as a pop-up on the multi-information display. Press of the meter control switches to go back to the previous screen.
Page 515 6-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode ● When driving on dusty roads such as tunnels or in heavy traffic, set to the recirculated air mode. This is effective in preventing out- side air from entering the vehicle interior. During cooling operation, setting the recirculated air mode will also cool the vehicle interior effectively.
Page 516 6-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 517 6-1. Using the air conditioning system and defogger NOTICE ■ Humidity sensor In order to detect fog on the windshield, a sensor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 514) Follow these points to avoid damaging the sensor: ●...
Page 518: Remote Air Conditioning System
6-1. Using the air conditioning system and defogger Remote Air Conditioning System The Remote Air Conditioning System uses electrical energy stored in the hybrid battery (traction battery) and allows the air conditioning to be operated by remote control. If the Remote Air Conditioning System is used while the charging cable is connected to the vehicle, the reduction of charge in the hybrid battery (traction battery) will be suppressed to allow you to use elec- tricity from an external power source.
Page 519 6-1. Using the air conditioning system and defogger ■ Operating conditions The system will only operate if all of the following conditions are met: ● The shift position is in P. ● The power switch is off. ● All doors are closed. ●...
Page 520 (Customizable features: P. 739) ■ Smartphone-linked operation (vehicles with 11.6-inch display) After applying to Entune, it is possible to use the smartphone application to operate the Remote Air Conditioning System. For details about Entune, refer to http://www.toyota.com/entune/. PRIUS PRIME_OM_OM47D13U_(U)
Page 521 6-1. Using the air conditioning system and defogger WARNING ■ Precautions for the Remote Air Conditioning System ● Do not use the system if people are in the vehicle. Even when the system is in use, the internal temperature may still reach a high or low level due to features such as the automatic shut-off.
Page 522: Heated Steering Wheel/ Seat Heaters
6-1. Using the air conditioning system and defogger Heated steering wheel  /seat heaters Heated steering wheel and seat heaters heat the side grips of the steering wheel and front seats, respectively. WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the steering wheel and seats when the heater is on: •...
Page 523 6-1. Using the air conditioning system and defogger Heated steering wheel (if equipped) Turns the heated steering wheel on/off The indicator in the instrument cluster comes on when the heated steering wheel is operating. ● The heated steering wheel can be used when the power switch is in ON mode.
Page 524: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Rear interior light (P. 526) Front personal/interior lights (P. 525) Shift lever lighting Footwell lights (if equipped) Front door courtesy lights PRIUS PRIME_OM_OM47D13U_(U)
Page 525: Front Interior Light
6-2. Using the interior lights Front interior light Turns the lights off Turns the door position on Turns the lights on Front personal lights Turns the lights on/off PRIUS PRIME_OM_OM47D13U_(U)
Page 526: Rear Interior Light
6-2. Using the interior lights Rear interior light Turns the switch to the door position (door linked) Operation is linked with the front interior light main switch. When the switch is off, the light does not illu- minate. Turns the light on ●...
Page 527: Using The Storage Features
6-3. Using the storage features List of storage features Auxiliary boxes (P. 531) Cup holders (P. 529) Glove box (P. 528) Console box (P. 528) Bottle holders/door pockets (P. 530) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 528: Glove Box
6-3. Using the storage features Glove box Pull up the lever. The glove box light turns on when the tail lights are on. Console box Press the knob and open the lid. The tray slides forward/backward and can be removed. PRIUS PRIME_OM_OM47D13U_(U)
Page 529: Cup Holders
6-3. Using the storage features Cup holders Front Rear   Front cup holders: When placing a mug, push the partition down. When placing cans, bottles, etc., push the partition once more to return it to its origi- nal position. WARNING Do not place anything other than cups or beverage cans in the cup holders.
Page 530: Bottle Holders/Door Pockets
6-3. Using the storage features Bottle holders/door pockets Front doors Rear doors   IO63PH022 ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. NOTICE Put the cap on before stowing a bottle. Do not place open bottles or glass and paper cups containing liquid in the bottle holders.
Page 531: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A Type B (if equipped)   Press in the lid. Vehicles with the wireless char- ger: P. 541 The overhead console is useful for temporarily storing small items. Type C  Lift the lid while pulling up the knob.
Page 532: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Auxiliary boxes Center Right side   Pull the strap upwards to lift up Pull the strap upwards to lift up the deck board. the deck board. The luggage cover, charging cable, tool bag, etc.
Page 533 6-3. Using the storage features NOTICE To prevent damage to the deck board, do not apply too much load on the deck board. Grocery bag hooks When using the hooks, press the bottom side to lift it up. There also is a hook on the other side.
Page 534 6-3. Using the storage features Luggage cover Type A  ■ Installing the luggage cover Remove the luggage cover from the bag. Slowly unfold the luggage cover. Attach the hook to the hook brackets. Black cap Gray cap Stowing the luggage cover ■...
Page 535 6-3. Using the storage features Bend one side of the cover towards you. Twist the other side in the opposite direction, as shown in the illustration. Make a small circle, then fold it inward. Make sure the three circles are side by side. PRIUS PRIME_OM_OM47D13U_(U)
Page 536 6-3. Using the storage features Put it in the bag. Type B  Installing the luggage cover ■ Install one side of the luggage cover to the holder. While push- ing that side in, install the other side to the opposite holder. ■...
Page 537 6-3. Using the storage features Removing the luggage cover ■ Push one end of the luggage cover inward and remove it from the holder. Stowing the luggage cover ■ Remove the deck boards. Store cover in the center aux- iliary box. Return the deck boards to its original position and close it.
Page 538 6-3. Using the storage features WARNING ● Do not place anything on the luggage cover. In the event of sudden brak- ing or turning, the item may go flying and strike an occupant. This could lead to an unexpected accident, resulting in death or serious injury. ●...
Page 539: Other Interior Features
6-4. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors Slide the cover to open.
Page 540: Power Outlets
6-4. Using the other interior features Power outlets Please use as a power supply for electronic goods that use less than 12 V DC/10 A (power consumption of 120 W). Front Rear   Open the lid. Open the lid. ■...
Page 541: Wireless Charger
6-4. Using the other interior features Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smart phones and mobile batteries, etc., on the charge area.
Page 542 6-4. Using the other interior features Using the wireless charger ■ Press power supply switch of the wireless char- ger. Switches on and off with each press of the power supply switch. When turned on, the operation indicator light (green) comes on. Even with the hybrid system off, the on/off state of the power supply switch is memorized.
Page 543 Handle the error based on the following table. Operation indicator Suspected causes Handling method light Flashing repeatedly Vehicle to charger com- Contact your Toyota once every second munication failure. dealer. (Orange) Remove foreign A foreign substance is substance...
Page 544 6-4. Using the other interior features ■ The wireless charger can be operated when The power switch is in ACCESSORY or ON mode. ■ Usable portable devices Qi standard wireless charge standard can be used on compatible devices. However, not all Qi standard devices and compatibility are guaranteed. Starting with mobile phones and smart phones, it is aimed for low power elec- trically supplied portable devices of no more than 5W.
Page 545 6-4. Using the other interior features ■ Certification for the wireless charger PRIUS PRIME_OM_OM47D13U_(U)
Page 546 6-4. Using the other interior features PRIUS PRIME_OM_OM47D13U_(U)
Page 547 6-4. Using the other interior features PRIUS PRIME_OM_OM47D13U_(U)
Page 548 6-4. Using the other interior features PRIUS PRIME_OM_OM47D13U_(U)
Page 549 6-4. Using the other interior features PRIUS PRIME_OM_OM47D13U_(U)
Page 550 6-4. Using the other interior features WARNING ■ Caution while driving When charging a portable device, for safety reasons, the driver should not operate the main part of the portable device while driving. ■ Caution regarding interference with electronic devices People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the...
Page 551 When other wireless keys (that emit radio waves) are being used nearby In addition, excluding the above-mentioned, when the charger does not per- form normally or the operation display lamp is flashing continuously, it is considered that the wireless charger is malfunctioning. Contact your Toyota dealer. ■...
Page 552: Coat Hooks
6-4. Using the other interior features Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 553: Garage Door Opener
6-4. Using the other interior features Garage door opener  The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 554 6-4. Using the other interior features ® Programming the HomeLink ■ Steps through must be performed within 60 seconds, other- wise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 555 6-4. Using the other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● Indicator light illuminates: Programming of a fixed code device has completed. The garage door or other device should oper- ®...
Page 556 6-4. Using the other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor operates when the ®...
Page 557 6-4. Using the other interior features ® Reprogramming a single HomeLink button ■ When the following procedure is performed, buttons which already have devices registered to them can be overwritten: ® With one hand, press and hold the desired HomeLink button.
Page 558 6-4. Using the other interior features ® Erasing the entire HomeLink memory (all three codes) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit orange to rapidly flashing green. If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 559 For vehicles sold in Canada  ■ When support is necessary Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. WARNING ■ When programming a garage door or other remote control device The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm.
Page 560 6-4. Using the other interior features PRIUS PRIME_OM_OM47D13U_(U)
Page 561: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior..562 Cleaning and protecting the vehicle interior... 567 7-2. Maintenance Maintenance requirements ....573 General maintenance..576 Emission inspection and maintenance (I/M) programs......579 7-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 562: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 563 7-1. Maintenance and care ■ Note for a smart key system If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In that case, follow the fol- lowing correction procedures to wash the vehicle: ●...
Page 564 ■ Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 565 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 566 7-1. Maintenance and care NOTICE ■ When using a high pressure car wash ● When washing the vehicle, do not let water of the high pressure washer hit directly or the vicinity of the camera. Due to the shock from the high pres- sure water, it is possible the device may not operate as normal.
Page 567: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 568 7-1. Maintenance and care Cleaning the air intake vents and filters Clean the air intake vents and fil- ters by the following procedures to prevent dust from accumulating in them, or to prevent them from clogging. The filters are attached to the back side of the air intake vent grilles.
Page 569 7-1. Maintenance and care Remove the filter. Remove dust using a vac- uum cleaner etc. to clean the filter. Also, remove dust on the grille as well as on the filter using a vacuum cleaner. Reinstall the filter to the origi- nal position.
Page 570 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 571 7-1. Maintenance and care WARNING ■ Water in the vehicle ● Do not splash or spill liquid in the vehicle, such as on the floor, in the hybrid battery (traction battery) air intake vent, and in the luggage com- partment. Doing so may cause the hybrid battery (traction battery), electrical compo- nents, etc.
Page 572 ● Carefully handle the removed filters not to damage. If the filter is damaged, have it replaced with a new filter by your Toyota dealer. ● Make sure to reinstall the filters and vents to its original positions after cleaning.
Page 573: Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 574 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 575 7-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the 12-volt battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 576: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 577 7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Hybrid transmission • When parked on a slope and the shift position “Park” mechanism is in P, is the vehicle securely stopped? •...
Page 578 7-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 579: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 580: Do-It-Yourself Maintenance Do-It-Yourself Service
• Rag or paper towel (P. 596) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology Engine/power For the U.S.A.:...
Page 581 7-3. Do-it-yourself maintenance Items Parts and tools Tire inflation • Tire pressure gauge pressure • Compressed air source (P. 609) • Water or washer fluid containing antifreeze (for win- Washer fluid ter use) (P. 598) • Funnel (used only for adding water or washer fluid) WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized.
Page 582 7-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. PRIUS PRIME_OM_OM47D13U_(U)
Page 583: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 584 7-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 585: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 586: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Washer fluid tank (P. 598) (P. 590) 12-volt battery (P. 593) Fuse boxes (P. 636) Power control unit coolant Engine oil level dipstick reservoir (P. 590) (P. 587) Radiator (P. 592) Engine oil filler cap (P. 588) Condenser (P.
Page 587 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 588 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 589 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 590 7-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the hybrid system is cold. Engine coolant reservoir ■ Reservoir cap “FULL” line “LOW” line If the level is on or below the “LOW”...
Page 591 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine/power control unit coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 592 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 593 7-3. Do-it-yourself maintenance 12-volt battery Check the 12-volt battery as follows: 12-volt battery exterior ■ Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals ■ When opening the cover of the positive (+) battery terminal While pushing the portion shown in the illustration from both sides, lift the end of the cover up.
Page 594 12-volt battery. Take extra care when con- necting the 12-volt battery if the power switch mode prior to discharge is unknown. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. WARNING ■ Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive.
Page 595 7-3. Do-it-yourself maintenance WARNING ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 596 7-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Slide and lift up the rubber strip to partly remove it as shown. Disconnect the claws and remove the service cover.
Page 597 7-3. Do-it-yourself maintenance Remove the reservoir cap. Add brake fluid slowly while checking the fluid level. Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel ■...
Page 598 7-3. Do-it-yourself maintenance Washer fluid Open the lid. Check the washer fluid level on the level gauge. “NORMAL” “LOW” If the washer fluid level is at “LOW”, add washer fluid. PRIUS PRIME_OM_OM47D13U_(U)
Page 599 7-3. Do-it-yourself maintenance WARNING ■ When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 600: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. Do not fail to initialize the tire pressure warning system after tire rotation.
Page 601 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 602) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■...
Page 602 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 603 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 604 7-3. Do-it-yourself maintenance ■ Tire types Summer tires ● Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 605 In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • When a replacement tire is used, the system may not operate cor- rectly due to the structure of the replacement tire.
Page 606 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the initialization of the system, the tire pressure warning light does not flash 3 times and the setting message does not appear on the multi-information display.
Page 607 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 608 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 609: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 723) PRIUS PRIME_OM_OM47D13U_(U)
Page 610 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 611 7-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 612: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 613 7-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 614 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 615: Replacing The Tire
7-3. Do-it-yourself maintenance Replacing the tire When raising your vehicle with a jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Before jacking up the vehicle ● Stop the vehicle in a safe place on a hard, flat surface. ●...
Page 616 7-3. Do-it-yourself maintenance Location of the jack and tools Jack Jack handle Tool bag Wheel nut wrench Towing eyelet PRIUS PRIME_OM_OM47D13U_(U)
Page 617 7-3. Do-it-yourself maintenance WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Only use the tire jack that comes with this vehicle for replacing a tire. Do not use it on other vehicles, and do not use other tire jacks for replacing tires on this vehicle.
Page 618 7-3. Do-it-yourself maintenance Taking out the tools Open the back door. (P. 281) Lift the deck under box cover up and take out the tool bag. Open the tool bag and then take out the jack handle and wheel nut wrench.
Page 619 7-3. Do-it-yourself maintenance Taking out the jack Pull the cover to disconnect the tabs, and remove the cover. Turn the portion to loosen the jack, and slowly take out the jack. Be careful when handling the jack, as it may become hot depending on conditions.
Page 620 7-3. Do-it-yourself maintenance Replacing a tire Chock the tires. Tire position Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 621 7-3. Do-it-yourself maintenance Turn the tire jack portion hand until the center of the recessed portion of the jack is in contact with the center of the jack point. Jack point Assemble the jack handle and the wheel nut wrench as shown in the illustration.
Page 622 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 623 7-3. Do-it-yourself maintenance Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 624 7-3. Do-it-yourself maintenance Reinstall the wheel ornament. Align the cutout of the wheel ornament with the valve stem as shown. Stow the tire jack and all tools. ■ Jack point The mark indicating the jack point is stamped on the underside of the vehi- cle.
Page 625 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. PRIUS PRIME_OM_OM47D13U_(U)
Page 626: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Replacing the air conditioning filter Turn the power switch off. Confirm that the charging connector is not connected. Also, do not use the Remote Air Conditioning System during the procedure.
Page 627 7-3. Do-it-yourself maintenance With the glove box fully open, slightly lift up the glove box and pull toward the seat to detach the bottom of the glove box. Do not use excessive force if the glove box does not detach when lightly pulled.
Page 628 7-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...
Page 629 7-3. Do-it-yourself maintenance NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system. ■ When removing the glove box Always follow the specified procedure to remove the glove box (P. 626). If the glove box is removed without following the specified procedure, the hinge of the glove box may become damaged.
Page 630: Wiper Rubber Replacement
7-3. Do-it-yourself maintenance Wiper rubber replacement When replacing the wiper rubber, perform the following proce- dure. Windshield wiper blade removal and installation While securely supporting the wiper blade connection hand, press the lock knob to release the lock, and then pull out the wiper blade.
Page 631 7-3. Do-it-yourself maintenance Wiper rubber replacement Pull the wiper rubber until it pro- trudes from the slit on the back of the wiper blade. Pull out the end of the wiper rubber from the slit, and then pull out the rest of the wiper rubber.
Page 632 Wiper blade and wiper rubber handling Improper handling may result in damage to the wiper blades or wiper rubber. If you have any concerns about replacing the wiper blades or wiper rubber yourself, contact your Toyota dealer. ■ Wiper blade cap The cap cannot be removed, as it is integrated with the front wiper blade.
Page 633: Electronic Key Battery
7-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery Release the lock and take out the mechanical key. Remove the cover.
Page 634 When installing, reverse the steps listed. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 635 7-3. Do-it-yourself maintenance WARNING ■ Removed battery and other parts These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury. NOTICE ■...
Page 636: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Confirm that the charging connector is not connected. Also, do not use the Remote Air Conditioning System during the procedure.
Page 637 7-3. Do-it-yourself maintenance Remove the fuse. Only type A fuse can be removed using the pullout tool. Check if the fuse is blown. Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing.
Page 638 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 641) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 639: Headlight Aim
7-3. Do-it-yourself maintenance Headlight aim Vertical movement adjusting bolts Adjustment bolt A Adjustment bolt B Before checking the headlight aim Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed. Park the vehicle on level ground. Sit in the driver’s seat.
Page 640 Turn bolt B the same number of turns and in the same direction as step If the headlight cannot be adjusted using this procedure, take the vehi- cle to your Toyota dealer to adjust the headlight aim. PRIUS PRIME_OM_OM47D13U_(U)
Page 641: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 724) Bulb locations...
Page 642 7-3. Do-it-yourself maintenance Replacing light bulbs Back-up lights ■ Remove the 2 clips that secure the lower portion of the cover at the back of the rear tire. Pull out the center portion of the clip to unlock using a flat- head screwdriver, and then pull it to remove.
Page 643 7-3. Do-it-yourself maintenance Remove the cover end and pull the cover toward the front of the vehicle to make a gap between the cover and rear bumper. Remove the clip inside of the cover, and remove the cover. Pull out the center portion of the clip to unlock using a flat- head screwdriver, and then pull it to remove.
Page 644 7-3. Do-it-yourself maintenance Install a new light bulb then install the bulb base to the light unit by inserting it and turning the bulb base clock- wise. Reinstall the cover to the its original position, and attach the clip inside of the cover. Attach the clip on the cover, then press the center portion of the clip to lock.
Page 645 7-3. Do-it-yourself maintenance Reinsert the 3 clips to the upper portion of the cover. Turn the clip clockwise to lock. Attach the clip on the cover, and then press the center portion of the clip to lock. Attach the clip on the cover, and then press the center portion of the clip to lock.
Page 646 ■ LED lights The lights other than the back-up lights each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the lens does not indicate a malfunction.
Page 647 7-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 648 7-3. Do-it-yourself maintenance PRIUS PRIME_OM_OM47D13U_(U)
Page 649: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ..650 If your vehicle has to be stopped in an emergency ...... 651 If the vehicle is trapped in rising water....652 8-2. Steps to take in an emergency If your vehicle needs to be towed ......
Page 650: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 651: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 652: If The Vehicle Is Trapped In Rising Water
: Contact your Toyota dealer or aftermarket accessory manufacturer for fur- ther information about an emergency hammer. ■...
Page 653: Steps To Take In An Emergency
In the following situations, it is not possible to be towed by another vehicle using cables or chains, as the front wheels may be locked due to the parking lock. Contact your Toyota dealer or commercial towing service. ● There is a malfunction in the shift control system. (P. 335, 676) ●...
Page 654 8-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels.
Page 655 8-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. Front If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 656 Shift the shift position to N and release the parking brake. : If the shift position cannot be changed or the current shift position can not be confirmed, contact your Toyota dealer or commercial towing ser- vice before towing. PRIUS PRIME_OM_OM47D13U_(U)
Page 657 8-2. Steps to take in an emergency ■ While towing If the hybrid system is off, the power assist for the brakes and steering will not function, making steering and braking more difficult. ■ Wheel nut wrench Wheel nut wrench is installed in luggage compartment. (P. 616) ■...
Page 658 8-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 659: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 660: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or (U.S.A.) • The brake system is malfunctioning  Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- (Canada) cle may be dangerous. Brake system warning light (yellow indicator) Indicates a malfunction in: •...
Page 661 Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; or • The seat belt pretensioner system  Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: •...
Page 662  Immediately stop the vehicle in a safe place. (P. 707) • When the light comes on without flashing: Indicates a malfunction in the exhaust heat recirculator system  Have the vehicle inspected by your Toyota dealer immediately. ICS OFF indicator Indicates a malfunction in the Intelligent Clearance Sonar function ...
Page 663 Toyota dealer. When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system (P. 667)  Have the system checked by your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 664  Release the accelerator pedal and depress the brake pedal. Indicates a malfunction in the Brake Override System (with warning buzzer)  Have the vehicle inspected by your Toyota dealer immediately. Drive-Start Control Indicates that the shift position was changed and Drive-...
Page 665 8-2. Steps to take in an emergency : Brake system warning buzzer: When there is a possible problem that could affect braking performance, the warning light will come on and a warning buzzer will sound. : Low engine oil pressure warning buzzer: A buzzer also sounds continuously for approximately 30 seconds at maxi- mum in addition to the low engine oil pressure warning light when the “READY”...
Page 666 The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. ■ When the tire pressure warning light comes on Inspect the appearance of the tire to check that the tire is not punctured.
Page 667 1 minute If the tire pressure warning light frequently comes on after blinking for 1 minute when the power switch is turned to ON mode, have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 668 8-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 669 8-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly. PRIUS PRIME_OM_OM47D13U_(U)
Page 670: If A Warning Message Is Displayed
If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer. : The master warning light may not come on or flash when a warning mes- sage is displayed.
Page 671 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 672 The Open door warning light comes on. (P. 662) ■ If “Visit Your Dealer” is shown The system or part shown on the multi-information display is malfunctioning. Have the vehicle inspected by your Toyota dealer. ■ If a message about an operation is shown ●...
Page 673 ● If “Engine Oil Pressure Low” is shown, this may be a malfunction. Immedi- ately stop the vehicle in a safe place and contact your Toyota dealer. ● If the following messages are shown, there may be a malfunction. Immedi- ately have the vehicle inspected by your Toyota dealer.
Page 674 P. 568. ● When the air intake vents or filters are not dirty and the warning message is shown, have the vehicle inspected at your Toyota dealer. ■ If “Traction Battery Needs to be Protected Refrain From the Use of Position”...
Page 675 8-2. Steps to take in an emergency ■ If “Shift to Before Exiting Vehicle” is shown Message is displayed when the driver’s door is opened without turning the power switch to off with the shift position in any position other than P. Shift the shift position to P.
Page 676 8-2. Steps to take in an emergency ■ If “Cruise Control not Available” is shown The dynamic radar cruise control with full-speed range system cannot be used temporarily. Use the system when it becomes available again. ■ If “Maintenance Required Soon” is displayed (U.S.A. only) Indicates that all maintenance according to the driven distance on the mainte- nance schedule should be performed soon.
Page 677 Have the vehicle inspected by your Toyota dealer immediately. ● Continuing to drive the vehicle without having the hybrid battery (traction battery) inspected will cause the hybrid system not to start. ● If the hybrid system does not start, contact your Toyota dealer immedi- ately. PRIUS PRIME_OM_OM47D13U_(U)
Page 678: If You Have A Flat Tire
After temporar- ily repairing the tire with the kit, have the tire repaired or replaced by your Toyota dealer. WARNING ■...
Page 679 A flat tire that cannot be repaired with the emergency tire puncture repair kit In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact your Toyota dealer. ● When the tire is damaged due to driving without sufficient air pressure ●...
Page 680 8-2. Steps to take in an emergency Location of the emergency tire puncture repair kit Emergency tire puncture repair kit PRIUS PRIME_OM_OM47D13U_(U)
Page 681 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Hose Power plug Air release cap Air pressure gauge Sticker Compressor switch PRIUS PRIME_OM_OM47D13U_(U)
Page 682 8-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Pull the strap up and remove the cover. Take out the emergency tire puncture repair kit. ■ When installing the cover Insert the claw in to the hole, and return the cover.
Page 683 8-2. Steps to take in an emergency Emergency repair method Take out the repair kit from the plastic bag. Remove the valve cap from the valve of the punctured tire. Extend the hose. Remove the air release cap from the hose. Attach the sticker enclosed with the bottle on the specified loca- tions.
Page 684 8-2. Steps to take in an emergency Lift the rubber stopper on the compressor. Remove the power plug from the compressor. Connect the power plug to the power outlet socket. (P. 540) Front Rear   PRIUS PRIME_OM_OM47D13U_(U)
Page 685 8-2. Steps to take in an emergency Connect the bottle to the com- pressor. As shown in the illustration, insert the bottle securely into the com- pressor until the upper side of the mark on the bottle is aligned with the upper end of the notch.
Page 686 25 minutes, the tire is too damaged to be repaired. Turn the compressor switch off and contact your Toyota dealer. • If the tire inflation pressure exceeds the specified air pressure, let out some air to adjust the tire inflation pressure. (P. 689, 723)
Page 687 8-2. Steps to take in an emergency With the compressor switch off, disconnect the hose from the valve on the tire and then pull out the power plug from the power outlet socket. Some sealant may leak when the hose is removed. Install the valve cap onto the valve of the emergency repaired tire.
Page 688 Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 50 mph (80 km/h) to the nearest Toyota dealer that is less than 62 miles (100 km) away for tire repair or replacement. When having the tire repaired or replaced, make sure to tell the Toyota dealer that the sealant is injected.
Page 689 8-2. Steps to take in an emergency ■ If the tire is inflated to more than the specified air pressure Disconnect the hose from the valve. Install the air release cap to the end of the hose and push the protrusion on the air release cap into the tire valve to let some air out.
Page 690 The sealant has a limited life span. The expiry date is marked on the bottle. The sealant should be replaced before the expiry date. Contact your Toyota dealer for replacement. ● The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire.
Page 691 8-2. Steps to take in an emergency WARNING ■ Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 692 8-2. Steps to take in an emergency WARNING ■ When fixing the flat tire ● Stop your vehicle in a safe and flat area. ● Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
Page 693 8-2. Steps to take in an emergency WARNING ■ Driving to spread the liquid sealant evenly Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury.
Page 694 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 695: If The Hybrid System Will Not Start
8-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 696 ● The 12-volt battery may be discharged. (P. 701) ● One or both of the 12-volt battery terminals may be disconnected. (P. 593) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 697: If The Electronic Key Does Not Operate Properly
Turning the key rearward unlocks the driver’s door. Turning the key once again within 3 seconds unlocks the other doors. Opens the windows (turn and hold) : This setting must be customized at your Toyota dealer. (P. 739) PRIUS PRIME_OM_OM47D13U_(U)
Page 698 8-2. Steps to take in an emergency Starting the hybrid system Depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. When electronic detected, a buzzer sounds and the power switch will turn to ON mode.
Page 699 8-2. Steps to take in an emergency Locking and unlocking the charging port lid Locking the charging port lid ■ Close the charging port lid. (P. 110) Lock the doors using the mechanical key. (P. 697) The charging port lid can be locked if the step is performed in reverse.
Page 700 8-2. Steps to take in an emergency ■ Stopping the hybrid system Set the parking brake, shift the shift position to P and press the power switch as you normally do when stopping the hybrid system. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 701: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 702 Make sure the “READY” indicator comes on. If the indicator light does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected.
Page 703 ■ When the 12-volt battery is removed or discharged ● Information stored in the ECU is cleared. When the 12-volt battery is depleted, have the vehicle inspected at your Toyota dealer. ● Some systems may require initialization. (P. 750) ■...
Page 704 • If the 20 hour rate capacity is low, even if the time period where the vehi- cle is not used is a short time, the 12-volt battery may discharge and the hybrid system may not be able to start. ● For details, consult your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 705 8-2. Steps to take in an emergency WARNING ■ When removing the 12-volt battery terminals Always remove the negative (-) terminal first. If the positive (+) terminal con- tacts any metal in the surrounding area when the positive (+) terminal is removed, a spark may occur, leading to a fire in addition to electrical shocks and death or serious injury.
Page 706 8-2. Steps to take in an emergency NOTICE ■ When handling jumper cables When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fans, etc. PRIUS PRIME_OM_OM47D13U_(U)
Page 707: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. PRIUS PRIME_OM_OM47D13U_(U)
Page 708 : Vehicles with 7-inch display : Vehicles with 11.6-inch display If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 709 “LOW” line Add coolant if necessary. Water can be used in an emer- gency if coolant is unavailable. If water was added in an emer- gency, have the vehicle inspected at your Toyota dealer as soon as possible. PRIUS PRIME_OM_OM47D13U_(U)
Page 710 Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: The hybrid system temperature has dropped and the vehicle may be driven normally. However, if the message appears again frequently, contact your Toyota dealer. WARNING ■...
Page 711 8-2. Steps to take in an emergency NOTICE ■ When adding engine/power control unit coolant Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool coolant to a hot hybrid system too quickly can cause damage to the hybrid system.
Page 712: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 713 8-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 714 8-2. Steps to take in an emergency PRIUS PRIME_OM_OM47D13U_(U)
Page 715: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.) ..716 Fuel information ....725 Tire information ....728 9-2. Customization Customizable features ..739 9-3. Initialization Items to initialize ....750 PRIUS PRIME_OM_OM47D13U_(U)
Page 716: Specifications Maintenance Data
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 182.9 in. (4645 mm) Overall width 69.3 in. (1760 mm) Overall height 57.9 in. (1470 mm) Wheelbase 106.3 in. (2700 mm) Front 60.2 in. (1530 mm) Tread Rear 60.6 in.
Page 717 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 718 9-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 1.8 L 4-cylinder (2ZR-FXE) Type 4-cylinder in line, 4-cycle, gasoline Bore and stroke 3.17  3.48 in. (80.5  88.3 mm) Displacement 109.7 cu.in.
Page 719 9-1. Specifications Electric motor (generation motor/traction motor) Generation/traction motor  Type Permanent magnet synchronous motor Maximum output 22.5 kW Maximum torque 29.5 ft•lbf (40 N•m, 4.1 kgf•m) Traction motor  Type Permanent magnet synchronous motor Maximum output 53 kW Maximum torque 120.2 ft•lbf (163 N•m, 16.6 kgf•m) Hybrid battery (traction battery) Type...
Page 720 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 721 Do not use plain water alone. : The coolant capacity is a reference quantity. If replacement is necessary, contact your Toyota dealer. Ignition system (spark plug) Make DENSO FC16HR-CY9 0.035 in. (0.9 mm) NOTICE ■...
Page 722 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. PRIUS PRIME_OM_OM47D13U_(U)
Page 723 9-1. Specifications Brakes Pedal clearance 4.53 in. (115 mm) Min. Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm) Brake pad wear limit 0.04 in. (1.0 mm) Parking brake pedal travel 8 —11 clicks Fluid type FMVSS No. 116 DOT 3 or SAE J1703 : Minimum pedal clearance when depressed with a force of 67.4 lbf (300 N, 30.6 kgf) while the hybrid system is operating.
Page 724 9-1. Specifications Light bulbs Light bulbs Bulb No. Type Exterior Back-up lights Vanity lights  Front interior/personal lights  Interior Rear interior light  Door courtesy lights  Luggage compartment light  A: Wedge base bulbs (clear) B: Double end bulbs PRIUS PRIME_OM_OM47D13U_(U)
Page 725: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 726 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 727 9-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 728: Tire Information
9-1. Specifications Tire information Typical tire symbols Tire size (P. 729) DOT and Tire Identification Number (TIN) (P. 729) Location of treadwear indicators (P. 600) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 729 9-1. Specifications Typical DOT and Tire Identification Number (TIN) Type A Type B   DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer’s code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 730 9-1. Specifications Tire dimensions ■ Section width Tire height Wheel diameter Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer PRIUS PRIME_OM_OM47D13U_(U)
Page 731 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 732 9-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 733 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation parked for three hours or more, or has not pressure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum inflation...
Page 734 9-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty 12-volt battery, and special trim A metal support for a tire or a tire and tube...
Page 735 9-1. Specifications Tire related term Meaning A breakdown of the bond between compo- Bead separation nents in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass...
Page 736 9-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall (b) The outward facing sidewall of an asym- metrical tire that has a particular side that...
Page 737 9-1. Specifications Tire related term Meaning A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that Radial ply tire extend to the beads are laid at substantially 90...
Page 738 9-1. Specifications Tire related term Meaning Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing...
Page 739: Customization
Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the parking brake set and the shift position in P.
Page 740 9-2. Customization Changing using the navigation system ■ Vehicles with 7-inch display  Press the “APPS” button on the navigation system. Select “Setup”. Select “Vehicle” on the “Setup” screen and select “Vehicle cus- tomization”. Various settings can be changed. Refer to the list of settings that can be changed for details.
Page 741 Customizable features Settings that can be changed using the multi-information display Settings that can be changed using the navigation system Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, – = Not available ■...
Page 742 9-2. Customization HUD (Head-up display) (P. 246) ■ Default Customized Function setting setting Route guidance – – : If equipped Door lock (P. 275, 697) ■ Default Customized Function setting setting Speed linked – Shift position Automatic door locking linked –...
Page 743 9-2. Customization Smart key system (P. 286) ■ Default Customized Function setting setting Smart door unlocking Driver’s door All the doors – Smart key system – – Time elapsed before unlock- ing all the door when gripping 2 seconds 1.5 seconds –...
Page 744 9-2. Customization Power windows (P. 308) ■ Default Customized Function setting setting Mechanical key linked opera- – – tion (open) Mechanical key linked opera- – – tion (close) Wireless remote control linked – – operation (open only) Mechanical key, wireless remote control linked opera- –...
Page 745 9-2. Customization Automatic light control system (P. 346) ■ Default Customized Function setting setting Time elapsed before 30 seconds 60 seconds headlights turn off 90 seconds Light sensor sensitivity Level 0 Level -2 to 2 O Daytime running lights : If equipped : This function cannot be customized for vehicles sold in Canada.
Page 746 9-2. Customization S-APGS (Simple Advanced Parking Guidance System) ■ (P. 451) Default Customized Function setting setting Near Obstacle detection range Standard Slightly far – – Narrow Back-in parking space Standard Slightly wide – – Wide Narrow Parallel parking space Standard Slightly wide –...
Page 747 9-2. Customization Remote Air Conditioning System (P. 518) ■ Default Customized Function setting setting Press once Press twice Operation using the “A/C” but- Press and Press and ton on the wireless remote hold for 0.8 – – hold for 2.4 control seconds seconds...
Page 748 9-2. Customization Seat belt reminder (P. 665) ■ Default Customized Function setting setting Vehicle speed linked seat belt – – reminder buzzer ■ Vehicle customization ● When the Speed linked door locking function and the Shift position linked door locking function are both on, the door lock operates as follows. •...
Page 749 9-2. Customization Charge settings ■ Charge schedule Setting the charging timer: P. 158 Changing the upper limit of the charging cur- Charge current rent:P. 129 Charging connector lock Changing the charging connector lock settings: (if equipped) P. 124 Setting “Traction Battery Heater” on/off: Traction battery heater P.
Page 750: 9-3. Initialization
9-3. Initialization Items to initialize The following items must be initialized for normal system opera- tion after such cases as the 12-volt battery being reconnected, or maintenance being performed on the vehicle. Item When to initialize Reference Power window • When functioning abnormally P.
Page 751: For Owners
For owners Reporting safety defects for U.S. owners......752 Seat belt instructions for Canadian owners (in French) ....... 753 SRS airbag instructions for Canadian owners (in French) ....... 755 Headlight aim instructions for Canadian owners (in French) ....... 764 PRIUS PRIME_OM_OM47D13U_(U)
Page 752: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 753: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 754 Entretien et nettoyage Ceintures de sécurité ■ Avec un chiffon ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent pas d’usure excessive, d’effilo- chage ou de coupures. AVERTISSEMENT ■...
Page 755: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian own- ers (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. IO11PH018 PRIUS PRIME_OM_OM47D13U_(U)
Page 756 ◆ Coussins gonflables SRS avant Coussin gonflable SRS du conducteur/coussin gonflable SRS du passager avant Peuvent aider à protéger la tête et la poitrine du conducteur et du passager avant contre les impacts avec des composants inté- rieurs Coussin gonflable SRS de protection des genoux Peut aider à...
Page 757 Composants du système de coussins gonflables SRS IO11PH019 Capteurs d’impact avant Contacteur de boucle de cein- ture de sécurité du passager Lampe témoin SRS, et voyants avant “AIR BAG ON” et “AIR BAG OFF” Coussins gonflables en rideau Coussin gonflable du passager Capteurs d’impact latéral...
Page 758 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la conception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 759 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS Observez les précautions suivantes en ce qui concerne les coussins gon- flables SRS. Les négliger pourrait occasionner des blessures graves, voire mortelles. ● Le conducteur et tous les passagers du véhicule doivent porter leur cein- ture de sécurité...
Page 760 Un bébé ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Toyota recommande vivement de placer et d’attacher correcte- ment tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 761 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas sur la planche de bord. ● Ne laissez pas un enfant se tenir face au coussin gonflable SRS du passager avant ni s’asseoir sur les genoux d’un passager avant.
Page 762 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne fixez et n’appuyez rien sur des zones telles que la planche de bord, le tampon de volant ou encore la partie inférieure du tableau de bord. Ces objets peuvent se transformer en projectiles lorsque les coussins gon- flables SRS du conducteur, du passa- ger avant et de protection des genoux...
Page 763 SRS Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica- tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion- ner des blessures graves, voire mortelles.
Page 764: Headlight Aim Instructions For Canadian Owners (In French)
Headlight aim instructions for Canadian own- ers (in French) The following is a French explanation of headlight aim instruc- tions from the headlight aim section in this manual. Boulons de réglage vertical Boulon de réglage A Boulon de réglage B Avant de vérifier la portée des phares Assurez-vous que le réservoir de carburant du véhicule est plein et que la partie de carrosserie située autour des phares n’est pas...
Page 765 Tournez le boulon B du même nombre de tours et dans le même sens qu’à l’étape Si vous n’arrivez pas à régler vos phares en suivant cette procé- dure, apportez le véhicule chez votre concessionnaire Toyota afin qu’il règle la portée des phares. PRIUS PRIME_OM_OM47D13U_(U)
Page 766 PRIUS PRIME_OM_OM47D13U_(U)
Page 767 Index What to do if... (Troubleshooting) ....768 Alphabetical index ..... 772 For information regarding the equipment listed below, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. • Navigation system • Audio system • Hands-free system (for cellular phone) • Rear view monitor system PRIUS PRIME_OM_OM47D13U_(U)
Page 768 Toyota dealer. (P. 271) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 274) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (P. 633) ●...
Page 769 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (P. 332) ● Is the shift position in P? (P. 339) ●...
Page 770 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and all the passengers wearing the seat belts? (P. 665) ● The parking brake indicator is on Is the parking brake released? (P. 345) Depending on the situation, other types of warning buzzer may also sound.
Page 771 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and repair the flat tire temporarily with the emergency tire puncture repair kit. (P. 678) The vehicle becomes stuck ●...
Page 772 Alphabetical index Alphabetical index Airbags ........36 Airbag operating conditions ..44 A/C ........496, 507 Airbag precautions for Air conditioning eco your child......40 mode ......499, 510 Airbag warning light ....661 Air conditioning filter ..... 626 Correct driving posture ... 28 Automatic air Curtain shield airbag conditioning system..
Page 773 Alphabetical index Approach warning ....409 Battery (traction battery) ..96 Assist grips ......552 Air intake vent......97 Audio input Charging ....... 108 Audio system Location ........96 Automatic air Specification ......719 conditioning system ..496, 507 Status indicator..... 110 Air conditioning eco Blind Spot Monitor (BSM)..
Page 774 Alphabetical index Cargo capacity......329 Child restraint system....58 Catch protection function..309 Fixed with a LATCH CD player system........70 Chains........492 Fixed with a seat belt....64 Charging........108 Front passenger occupant Charging cable...... 113 classification system .... 50 Charging equipment .....
Page 775 Alphabetical index Clock......... 188 Dimension ........ 716 Adjustment......193 Dinghy towing......331 Coat hooks ....... 552 Display Combination meter....188 BSM (Blind Spot Monitor) ..417 Clock adjustment ....193 Drive information ....215 Main display......204 Dynamic radar cruise control Multi-information display ..
Page 776 Alphabetical index Drive information..... 215 Electronic key ......270 Drive-Start Control ....316 Battery-saving function ..288 Driver’s seat belt reminder If the electronic key does light......... 662 not operate properly ... 697 Driving ........314 Replacing the battery.... 633 Break-in tips......
Page 777 Alphabetical index Emergency tire puncture Engine switch ......332 repair kit ......... 678 Auto power off function..334 Energy monitor ..216, 255, 261 Changing the power Engine switch modes ..... 334 Accessory mode ....334 If your vehicle has to be Compartment ......
Page 778 Alphabetical index Front seats ....... 295 Adjustment......295 Hands-free system Cleaning........ 567 (for cellular phone) Correct driving posture ... 28 Head restraints ......299 Head restraints ..... 299 Head-up display....... 246 Seat heaters ......522 Headlights ........ 346 Front side marker lights..346 Automatic High Beam Light switch ......
Page 779 Alphabetical index Hybrid battery (traction battery)...... 96 I/M test ........579 Air intake vent ......97 Identification ......717 Charging ....... 108 Engine ........718 Location ........96 Vehicle........717 Specification ......719 Ignition switch Status indicator ..... 110 (power switch)....... 332 Hybrid battery (traction battery) Auto power off function..
Page 780 Alphabetical index Jack........... 616 Language (multi-information Positioning a floor jack..585 display) ........241 Vehicle-equipped jack... 616 LATCH system......60 Jack handle ......616 LDA (Lane Departure Alert Jam protection function..309 with steering control) ... 389 Lever Auxiliary catch lever....583 Hood lock release lever ..
Page 781 Alphabetical index Energy monitor ..... 216 Intelligent Clearance Main display ......204 Sonar........444 Maintenance Intuitive parking assist ..430 Do-it-yourself maintenance... 580 Language......241 General maintenance ... 576 LDA (Lane Departure Alert Maintenance data ....716 with steering control) ..393 Maintenance requirements ...
Page 782 Alphabetical index Power control unit coolant ..590 Capacity........ 721 P position switch ..... 339 Checking....... 590 Panic mode ......271 Preparing and checking Parking assist sensors before winter ...... 491 Intelligent Clearance Radiator ........ 592 Sonar........439 Power outlets......540 Intuitive parking assist ..
Page 783 Alphabetical index Radar cruise control S-APGS (Simple Advanced (dynamic radar cruise Parking Guidance control with full-speed System) ........451 range) ........399 S-FLOW mode....497, 509 Radiator ........592 Safety Connect ......75 Radio Seat belts ........30 Rear passengers’ seat belt Adjusting the seat belt ....
Page 784 Alphabetical index Sensor Smart key system....286 Automatic headlight Antenna location....286 system ........ 349 Entry functions...... 275 Automatic High Beam Starting the hybrid system ..332 system ........ 351 Smart lid & connector BSM (Blind Spot Monitor) ..420 locking system ......
Page 785 Alphabetical index Fog light switch ..... 356 Fuel filler door opener Tail lights........346 switch ......... 366 Light switch......346 Garage door opener Replacing light bulbs .... 646 switches......553 Talk switch Heated steering wheel Telephone switch switch ......... 523 Theft deterrent system “HUD”...
Page 786 Emergency towing ....653 Vehicle proximity Towing eyelet......656 notification system ....91 Trailer towing ......330 Vehicle Stability Control Toyota Safety Sense P .... 369 (VSC) ........485 TRAC (Traction Control) ..485 Voice command system Function ........ 485 VSC (Vehicle Stability VSC OFF switch ....
Page 787 Alphabetical index Warning lights......197 Warning messages....670 ABS........661 Warning reflector storage Brake Override System..664 space........533 Brake system ......660 Washer ........358 Charging system....660 Checking....... 598 Drive-Start Control ....664 Preparing and checking Driver’s seat belt reminder..662 before winter ......
Page 788 Alphabetical index Wireless remote control key .......... 270 Battery-Saving Function ..288 Locking/Unlocking....270 Panic mode......271 Remote Air Conditioning System ....... 518 Replacing the battery.... 633 WMA disc PRIUS PRIME_OM_OM47D13U_(U)
Page 789 Alphabetical index : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. PRIUS PRIME_OM_OM47D13U_(U)
Page 790 Alphabetical index PRIUS PRIME_OM_OM47D13U_(U)
Page 791 Alphabetical index PRIUS PRIME_OM_OM47D13U_(U)
Page 792 With filter 4.4 qt. (4.2 L, 3.7 Imp.qt.) (Drain and refill — Without filter 4.1 qt. (3.9 L, 3.4 Imp.qt.) reference) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC GF-5 multigrade engine oil P. 720 PRIUS PRIME_OM_OM47D13U_(U)

Toyota PRIUS PRIME 2019 Manual

Quick Links

Related Manuals for Toyota PRIUS PRIME 2019

Summary of Contents for Toyota PRIUS PRIME 2019
