Page 1 SECTION – FEATURES ON NEW TOYOTA VEHICLE Overview of instruments and controls Instrument panel overview ........
Page 2 Instrument panel overview 1. Side vent ......2. Side defroster outlet 3. Instrument cluster ....4.
Page 3 1. Headlight and turn signal switches ......2. Wiper and washer switches ..3.
Page 4 17. Climate remote control switches ......18. Instrument panel light control dial ......19.
Page 5 Instrument cluster and multi−information display overview 1. Service reminder indicators and indicator lights ..125, 133 2. Speedometer 3. Fuel gauge ..... . 4.
Page 6 Indicator symbols on the instrument cluster and multi−information display Anti−lock brake system warning light Brake system warning lights (U.S.A.) SRS warning light (Canada) Engine oil replacement reminder light Driver’s seat belt reminder light (for vehicles sold in the U.S.A.) Front passenger’s seat belt reminder light Vehicle stability control system warning light Tire pressure warning light Low fuel level indicator light...
Page 7 Tail light indicator light Hybrid battery warning light Electric power steering system warning light Driving ready light Automatic head light leveling system Automatic air conditioner indicator light warning light Hybrid system warning light Recirculate mode indicator light Cruise control indicator light Windshield air flow indicator light Rear window and outside rear view mirror Shift position indicator light...
Page 8 : For details, see “Service reminder indi- cators and warning buzzers— —Instru- ment cluster” on page 125. : For details, see “Service reminder indi- cators and warning buzzers— —Multi− information display” on page 133. : If this light flashes, see “Cruise con- trol”...
Page 9: Table Of Contents
SECTION – FEATURES ON NEW TOYOTA VEHICLE Toyota hybrid system Toyota hybrid system ........
Page 10: Toyota Hybrid System Operating Condition
Toyota hybrid system Toyota hybrid system operating condition Toyota hybrid system combines a gaso- Basic operations are described below. Be- line engine and electric motor power to sides, Toyota hybrid system performs vari- improve the fuel economy and minimize ous controls depending on the operating the emissions as well as to provide condition: The “Energy Monitor”...
Page 11 12p060b 12p061b 12p062b Gasoline power Electric and gasoline Storing electric power in use power in use During normal driving, the vehicle runs When driving at full throttle, additional When decreasing speed or applying the mainly on gasoline power. However, the electric power is applied from the hybrid brakes, the turning force of the wheels electric motor, using electric power gener-...
Page 12: Starting Your Vehicle
Starting your vehicle Your vehicle is equipped with push but- ton start system. The hybrid system will start automatically by pressing the “POWER” switch briefly with the brake pedal depressed. With smart function 1. Carry the key with you. 2. Press the “POWER” switch briefly with the brake pedal depressed.
Page 13: For Efficient Use Of Your Vehicle
For efficient use of your vehicle Drive your vehicle with a smooth accel- When parking, be sure to put the hy- INFORMATION eration and deceleration. brid transaxle in “P”. While driving, use the hybrid transaxle in “D”. While driving, energy recovered The gasoline engine starts and stops through the regenerative brake as the...
Page 14: Precautions For Use
(about 200 V) and to other compo- As unwanted noise may occur in the nents that are all high voltage. High volt- reception of mobile radios, contact age cables your Toyota dealer for installation or CAUTION removal. Inverter unit Air conditioning Electric motor...
Page 15 How- start even with a jump−start to the 12 volt ever, during high speed driving you battery, contact your Toyota dealer. may feel that deceleration by engine braking is less than that of ordinary vehicle.
Page 16 When multi−information display shows this message, the master warn- ing light comes on in the instru- ment cluster. Read the message and follow the instruction. 12P009d 12p065a When you leave your vehicle, or stop or park for a while, put the hybrid transaxle in “P”.
Page 17 To prevent this, never touch As sealed Nickel−Metal hydride batteries the high voltage parts (hybrid bat- If your vehicle needs to be towed, are used, be sure to consult your Toyota tery assembly, etc.) cables do it with the front wheels or all dealer when disposing of your vehicle.
Page 19 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys ............Hybrid vehicle immobilizer system .
Page 20: Keys
Your Toyota dealer will need ence of radio waves. Radio waves lock knob in the arrow direction and take...
Page 21: Hybrid Vehicle Immobilizer System
Toyota dealer using the key phone. cally checked to determine whether it number. corresponds to the registered ID code We recommend writing down the key num- for the vehicle.
Page 22 Carrying a smart key and pressing the “POWER” switch automatically cancels the system, which enables the hybrid system to start. The indicator light will go off. For your Toyota dealer to make you a new key with built−in transponder chip, 21p007b 21p006a your dealer will need your key number and master key.
Page 23 The FCC ID: MOZRI−24KTY indicator light will go off. MADE IN JAPAN For your Toyota dealer to make you a This device complies with Part 15 of the new key with built−in transponder chip, 21p007b FCC Rules.
Page 24: Smart Entry And Start System
Smart entry and start system For vehicles sold in Canada By carrying a smart key, you can lock and unlock the doors and start the hy- brid system. This device complies with RSS−210 of industry Canada. Operation is subject to For locking the doors, see “Locking the the following two conditions: doors with smart function”...
Page 25 INFORMATION If you do not drive your vehicle, CAUTION store the smart key, keeping it at Be sure to take the smart key with least 5 m (16 ft.) away from the ve- People with implanted pacemakers you. hicle. or cardiac defibrillators should keep In the following cases, the smart away from the smart entry and start function or wireless remote control...
Page 26 ANTENNA LOCATIONS 1. Antennas inside cabin 2. Antennas outside cabin 21p157 ALARMS AND WARNING LIGHT Your vehicle is equipped with alarms inside and outside, as well as warning light in the instrument cluster, that re- mind you if there is a problem involv- ing the smart entry and start system.
Page 27 (a) The hybrid system was not turned (b) The smart key was brought outside (d) The smart key was brought outside off and the transaxle was in a posi- the vehicle with the transaxle in a the vehicle. tion other than “P”. position other than “P”.
Page 28: Glove Box
(f) The smart key was brought outside (g) Preventing from being (i) Outside of effective range the vehicle. locked inside the vehicle When the “POWER” switch is pressed, it When a door other than the driver’s door When you close the door with the hybrid is determined that the smart key is not in is opened or closed with the hybrid sys- system off but with the smart key left in...
Page 29 Warning and its meaning Inside warning alarm Outside warning alarm Warning light Causes One beep The driver’s door was opened when the hybrid system was in “ACC” — — (sounds continuously) or “IG−ON” and when the transaxle was in a position other than “P”. The driver brought out the smart key from the vehicle with the hybrid One beep One beep...
Page 30 LOCKING THE DOORS WITH SMART INFORMATION FUNCTION The smart entry and start system will The rear doors are not equipped lock the doors without being inserted with smart function. into the door keyhole. When locking the doors, be sure to 21p128 When you exit the vehicle carrying the push the lock button on the outside...
Page 31 When you push and hold down the back INFORMATION door opener switch, carrying the smart key, the ID code is checked in the same The rear doors are not equipped way as in the front door case. And all the with smart function.
Page 32 CHANGING THE DOORS TO BE UN- When you take hold of the handle If another person who is not carry- LOCKED or push the back door opener to ing a smart key takes hold of an Each time you push the lock button unlock the door(s), be sure to con- outside door handle or push the together with the panic button on the...
Page 33 BATTERY POWER SAVING To reactivate the smart function, perform INFORMATION any of the following: When doors are locked, the smart entry z When changing the mode, be sure and start system transmits electromagnetic (a) Press the lock button on the outside to push both lock and panic but- waves to the outside of the vehicle at front door handle or back door while...
Page 34 If you do not intend to drive your vehicle INFORMATION for a long time, push the cancel switch to deactivate the smart function. To maintain communication with the vehicle, smart keys use built−in bat- INFORMATION tery power. The battery service life is about 1 to 3 years on average.
Page 35: Wireless Remote Control
Wireless remote control— For vehicles sold in U.S.A. CAUTION FCC ID: MOZB31EG Changes modifications MADE IN JAPAN pressly approved by the party respon- sible for compliance could void the FCC ID: MOZB31UG 21p147 user’s authority to operate the equip- MADE IN JAPAN ment.
Page 36 “—Replacing bat- age to the key. tery” on page 38. Do not leave the key in places where If you lose your key, contact your Toyota the temperature becomes high such as dealer as soon as possible to avoid the 21p013f on the dashboard.
Page 37 For To lock: Push the lock switch. All the side details, contact your Toyota dealer. doors and back door are locked simulta- neously. At this time, the turn signal lights When the unlock switch is pressed the will flash once.
Page 38: Replacing Battery
CAUTION Toyota dealer. sible for compliance could void the For vehicles sold in U.S.A. user’s authority to operate the equip- Special care should be taken that ment. small children do not swallow the re- FCC ID: MOZB21TG moved battery or components.
Page 39 (+) side O−ring when installing. 5. Replace the mechanical key and cover with slide the lock knob. After replacing the battery, check that the key operates properly. If the key still does not operate properly, contact your Toyota dealer.
Page 40: Side Doors
Side doors 21p008a 21p009a 21p010a Driver’s side LOCKING AND UNLOCKING THE DRIV- LOCKING AND UNLOCKING WITH IN- ER’S DOOR WITH MECHANICAL KEY SIDE LOCK KNOB Insert the mechanical key into the key- Move the lock knob. hole and turn it. To lock: Push the knob forward.
Page 41 LOCKING AND UNLOCKING WITH CAUTION POWER DOOR LOCK SWITCH Push the switch. Before driving, be sure that the doors To lock: Push the switch down on the closed locked, especially front side. when small children are in the ve- 21p012b To unlock: Push the switch down on the hicle.
Page 42: Back Door
If the back door system does not operate down on it. After closing the back door, properly after the above procedure, there try pulling it up to make sure it is secure- may be a problem in the system. Contact ly closed. your Toyota dealer.
Page 43: Power Windows
The power windows work when the “IG− open or close. To stop the window part- checked by your Toyota dealer. ON” mode is enabled. way, lightly move the switch in the oppo- Key off operation: If both front doors are site direction and then release it.
Page 44 CAUTION To avoid death or serious injury, you Window lock must do the following. switch Before you close the power win- 21p021b dows, always make sure there is nobody around the power windows. must also make sure heads, hands and other parts of the bodies of all occupants are kept completely inside...
Page 45: Hood
Hood Never leave anyone (particularly a small child) alone in your vehicle, es- pecially with the key still inserted or with the hybrid system other than 21p026c “OFF”. Otherwise, he/she could use 21p027d the power window switches and get trapped in a window. Unattended per- son (particularly a small child) can be involved in a serious accident.
Page 46: Theft Deterrent System
If necessary, press down gently on the and other exterior lights. front edge to lock it. This function can be deactivated or acti- vated. For details, contact your Toyota CAUTION dealer. After inserting the support rod into the slot, make sure the rod supports the hood securely from falling down on to your head or body.
Page 47 The indicator light will come on when all If any of the doors are unlocked without doors hood closed the mechanical key, wireless remote con- locked. trol transmitter or smart function and the key is not in the key slot, all the doors The system will automatically be set after will be automatically locked again.
Page 48: Fuel Tank Cap
12 volt battery ter- minal is disconnected and then recon- nected. When testing the hood, release the lock with the hood lock release lever and raise the hood. If the system does not work properly, have it checked by your Toyota dealer.
Page 49 If the cap is not tightened securely, the malfunction indicator lamp comes Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible.
Page 50 CAUTION Make sure the cap is installed se- curely to prevent fuel spillage in the event of an accident. Use only a genuine Toyota fuel tank cap for replacement. It is designed to regulate fuel tank pressure. NOTICE To prevent damage to the cap, apply force only in the turning direction to the cap.
Page 51 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Occupant restraint systems Seats ............Front seats .
Page 52: Seats
Front seats— Seats —Front seat precautions While the vehicle is being driven, all ve- Driver seat Slightly recline the back of hicle occupants should have the seatback seat. Although vehicle designs vary, upright, sit well back in the seat and prop- CAUTION many drivers can achieve the 250 erly wear the seat belts provided.
Page 53 —Seat adjustment precautions Front passenger seat Front seats (with SRS side airbags) CAUTION CAUTION CAUTION Do not adjust the seat while the vehicle is moving as the seat may The SRS side airbags are installed in The SRS front passenger airbag also unexpectedly move and cause the the driver and front passenger seats.
Page 54 —Adjusting front seats 1. SEAT POSITION ADJUSTING LEVER While adjusting the seat, do not put Hold the center of the lever and pull it your hands under the seat or near up. Then slide the seat to the desired the moving parts. Otherwise, your position with slight body pressure and hands or fingers may be caught release the lever.
Page 55 —Flattening seatbacks CAUTION Do not allow passengers to ride on the flattened seat while driving; use the seat in the normal position. 22p226a 22p227a After putting back the seat, pushing the seat and seatback for- ward and rearward to make sure it is secured in place.
Page 56: Fold−Down Rear Seat
Fold−down rear seat CAUTION When only rear left seat is folded down, rear seat alone can be used. Never sit on the center seat because 22p203 the rear center seat belt cannot be fastened correctly when the rear left seat is folded down. Lower the head restraints to the lowest BEFORE RETURNING REAR SEAT position.
Page 57: Head Restraints
Head restraints For your safety and comfort, adjust the CAUTION head restraint before driving, To raise: Pull it up. When returning the seatback to the To lower: Push it down while pressing the upright position, observe the follow- lock release button. ing precautions in order to prevent 22p002b Rear center head restraint—When an oc-...
Page 58: Armrest
Seat belts— Armrest —Seat belt precautions Toyota strongly urges that the driver and Do not allow any children to stand up or passengers in the vehicle be properly re- kneel on either rear or front seats. An strained at all times with the seat belts unrestrained child could suffer serious in- provided.
Page 59 —Fastening front and rear seat belts CAUTION Be careful not to damage the belt webbing or hardware. Take care that Persons should ride in their seats they do not get caught or pinched properly wearing their seat belts in the seat or doors. whenever vehicle moving.
Page 60 If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed, because it cannot protect an adult occupant or your child from death or serious...
Page 61 CAUTION Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be 22p005b 22p004a kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in a colli- sion.
Page 62: Seat Belt Extender
“AIRBAG OFF” indicator light is Please contact your local Toyota dealer so 22p205a illuminated, disconnect the extender that the dealer can order the proper re- tongue from the seat belt buckle, quired length for the extender. Bring the...
Page 63 When releasing the seat belt, press on normally, immediately contact your the buckle release button on the extender, Toyota dealer. Do not use the seat not on the seat belt. This helps prevent until the seat belt is fixed, because...
Page 64: Srs Warning
—Seat belt pretensioners The front passenger’s seat belt pretension- er will not activate if no passenger is detected in the front passenger seat by the front passenger occupant classification system. However, the front passenger’s 22p009b seat belt pretensioner may activate if lug- 22p237 gage is put on the seat, or the seat belt is buckled up regardless of the presence...
Page 65 “AIRBAG ON” result in death or serious injury. Con- fenders, front end structure or con- indicator light, “AIRBAG OFF” indicator sult your Toyota dealer about any re- sole light, front passenger’s seat belt buckle pair and modification.
Page 66: Srs Airbags
The seat belt pretensioner assembly or In the following cases, contact your Toyota The SRS (Supplemental Restraint Sys- surrounding area has been damaged. dealer as soon as possible:...
Page 67 The driver and front passenger can child restraint system. Toyota The SRS front passenger airbag will not be killed or seriously injured by the strongly recommends that all in- activate if there is no passenger sitting in inflating airbags if they do not wear fants and children be placed in the the front passenger seat.
Page 68 The SRS front airbags are designed to deploy in severe (usually frontal) colli- sions where the magnitude and duration of the forward deceleration of the ve- hicle exceeds the designed threshold Hitting a curb, edge Falling into or jump- level. Collision from of pavement or 22p015c...
Page 69 8. Driver’s seat position sensor The airbag sensor assembly consists of a safing sensor and airbag sensor. 9. Airbag sensor assembly The front airbag sensors constantly moni- 10. Airbag module for driver tor the forward deceleration of the vehicle. (airbag and inflator) If an impact results in a forward decelera- 22p238 tion beyond the designed threshold level,...
Page 70 These Toyota strongly recommends that: er wears the seat belt even if not are usually in the nature of minor burns wearing it.
Page 71 22p020a 22p236 22p022c Do not sit on the edge of the seat Toyota strongly recommends that Do not put anything or any part of or lean against the dashboard when all infants and children be placed in your body on or in front of the...
Page 72 Do not perform any of the following or open any components, such as changes without consulting your the steering wheel pad, steering Toyota dealer. Such changes can in- wheel, column cover, dashboard terfere with proper operation of the 22p010a near...
Page 73 The SRS warning light and “AIRBAG OFF” indicator light will come on if there is a malfunction in the front passenger occu- pant classification system. In the following cases, contact your Toyota dealer as soon as possible: The SRS front airbags have been in- flated.
Page 74 —SRS side airbags and curtain shield airbags In response to a severe side impact, the CAUTION SRS side airbags and curtain shield air- bags work with the seat belts to help The SRS side airbag and curtain reduce injury by inflating. The SRS side shield airbag system is designed airbags help reduce injuries mainly to the 22p024c...
Page 75 Toyota shown in the illustration. strongly recommends that all in- The SRS side airbags and curtain shield fants and children be placed in the airbags are designed to inflate when the rear seats of the vehicle and prop- passenger compartment area suffers a se- erly restrained.
Page 76 8. Passenger’s seat belt buckle switch The SRS side airbag and curtain shield airbag system is controlled by the airbag 9. Airbag sensor assembly sensor assembly. The airbag sensor as- sembly consists of a safing sensor and airbag sensor. In a severe side impact, the side and 22p239 curtain shield airbag sensor and/or the curtain shield airbag sensor trigger(s) the...
Page 77 Deployment of the airbags happen in a fraction of a second, so the airbags must inflate with considerable force. While the system is designed to reduce serious inju- ries, it may also cause minor burns or abrasions and swelling. 22p028d 22p207a Front seats as well as parts of the front and rear pillars, and roof side rail may be...
Page 78 Do not allow anyone to kneel on the passenger seat, facing the pas- senger’s side door, since the side airbag and curtain shield airbag could inflate with considerable 22p210 22p029d speed and force. Otherwise, he/she may be killed or seriously injured. Special care should be taken espe- cially when you have a small child in the vehicle.
Page 79 Failure to follow these instructions can result in death or serious injury. Do not use seat accessories which Consult your Toyota dealer about any cover the parts where the side air- repair and modification. bags inflate. Such accessories may...
Page 80 Contact your z Repairs made on or near the con- are operating properly. Toyota dealer as soon as possible. sole or front seat The light does not come on when the “IG−ON” mode is enabled or remains on for more than 6 seconds.
Page 81 —Front passenger occupant classification system In the following cases, contact your Toyota Your vehicle is equipped with a front dealer as soon as possible: passenger occupant classification sys- tem. This system detects the conditions Any of the SRS side airbags and cur- 1.
Page 82 A rear passenger lifts the front passen- The “AIRBAG ON” and “AIRBAG OFF” ger seat cushion with their legs. indicator lights will be illuminated ini- tially when the “IG−ON” mode is en- Objects are placed under the front pas- abled. After about 4 seconds, they will senger seat.
Page 83 22p240a The SRS warning light and “AIRBAG OFF” indicator light will come on if there is a malfunction in the front pas- senger occupant classification system.
Page 84 Condition and operation in the front passenger occupant classification system Indicator/ warning light Devices Condition detected by Curtain shield “AIRBAG ON” Front Side airbag on Front the front passenger Front airbag in the and “AIRBAG SRS warning passenger’s the front passenger’s occupant classification front...
Page 85 CAUTION Do not recline the front passenger Wear the seat belt properly. seat seatback so that it interferes Make sure the front passenger’s To avoid potential death or serious with a rear seat as it may cause the seat belt tab has not been left in- injury when the front passenger occu- “AIRBAG OFF”...
Page 86: Child Restraint
Child restraint— —Child restraint precautions Toyota strongly urges the use of ap- When it is unavoidable to install the Toyota strongly urges use of propriate child restraint systems for forward−facing child restraint sys- proper child restraint system which children. tem on the front passenger seat, conforms to the size of the child, The laws of all 50 states in the U.S.A.
Page 87 —Child restraint system A child restraint system for a small A forward−facing child restraint sys- Do not use the seat belt extender child or baby must itself be properly should allowed when installing child restraint restrained on the seat with the lap por- installed on front passenger system on the front or rear passen-...
Page 88 —Types of child restraint system Child restraint systems are classified into the following 3 types depending on the child’s age and size. (A) Infant seat (B) Convertible seat (C) Booster seat 22p031c 22p033c Install the child restraint system following the instructions provided by its manufac- turer.
Page 89 —Installation with 3−point type seat belt 22p018c 22p034c 22p045e (A) INFANT SEAT INSTALLATION CAUTION Do not install a child restraint sys- An infant seat must be used in rear− tem on the rear seat if it interferes facing position only. Never install a rear−facing child re- with the lock mechanism of the straint system on the front passen-...
Page 90 1. Run the lap and shoulder belt through 2. Fully extend the shoulder belt to put it Contact your Toyota dealer immedi- or around the infant seat following the in the lock mode. When the belt is ately.
Page 91 22p040c 22p041c 22p039c 3. While pressing the infant seat firmly 4. To remove the infant seat, press the CAUTION against the seat cushion and seatback, buckle release button and allow the let the shoulder belt retract as far as belt to retract completely. The belt will Push and pull the child restraint sys- it will go to hold the infant seat secure- move freely again and be ready to...
Page 92 Install the child restraint system on the CAUTION front passenger seat only when it is un- avoidable. Your vehicle is equipped with a Push and pull the child restraint sys- front passenger occupant classification tem in different directions to be sure system.
Page 93 “AIRBAG OFF” the child restraint system and contact your senger airbag and side airbag on indicator light is illuminated. In the Toyota dealer. front passenger seat could event of an accident, the impact of...
Page 94 On vehicles with side airbags and curtain shield airbags, do not allow the child to lean his/her head or any part of his/her body against the 22p044b door or the area of the seat, front 22p036f or rear pillar or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint...
Page 95 1. Run the lap and shoulder belt through 2. Fully extend the shoulder belt to put it Contact your Toyota dealer immedi- or around the convertible seat following in the lock mode. When the belt is ately.
Page 96 22p048c 22p049c 22p050b 3. While pressing convertible seat 4. To remove the convertible seat, press CAUTION firmly against the seat cushion and the buckle release button and allow the seatback, let the shoulder belt retract belt to retract completely. The belt will Push and pull the child restraint sys- as far as it will go to hold the convert- move freely again and be ready to...
Page 97 On vehicles with side airbags and curtain shield airbags, do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front 22p051c 22p052a or rear pillar or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint...
Page 98 Always make sure the shoulder belt child from death or serious injury. is positioned across the center of Contact your Toyota dealer immedi- child’s shoulder. The belt should be ately. Do not install the child re- 22p053c kept away from child’s neck, but...
Page 99 —Using a top strap Anchor brackets 22p055c 22p056e 22p050b Symbol 2. To remove the booster seat, press the Follow the procedure below for a child Use the anchor brackets on the back of buckle release button and allow the restraint system that requires the use the rear seatback to attach the top strap.
Page 100 22p063b 22p215 22p064e TO USE THE ANCHOR BRACKET: 2. Open the cover of the anchor brack- 3. Fix the child restraint system with the seat belt. 1. Remove luggage cover (See “Luggage cover” on page 316.) and Latch hook onto the anchor raise the head restraint to the upper- bracket and tighten the top strap.
Page 101 —Installation with child restraint lower anchorages CAUTION Make sure the top strap is securely latched, and check that the child re- straint system is secure by pushing 22p076f and pulling it in different directions. Follow all the installation instructions provided by its manufacturer. 22p077h The lower anchorages for the child re- straint...
Page 102 CHILD RESTRAINT SYSTEM INSTALLA- For installation details, refer to the instruc- TION tion manual equipped with each product. 1. Widen the gap between the seat CAUTION cushion and seatback slightly and confirm the position of the lower an- When using the lower anchorages chorages below the symbol in the for the child restraint system, be seatback.
Page 103 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Steering wheel and Mirrors Tilt steering wheel ......... . Outside rear view mirrors .
Page 104: Tilt Steering Wheel
Tilt steering wheel Outside rear view mirrors— CAUTION Do not adjust the steering wheel while the vehicle is moving. Doing so may cause the driver to mishan- 22p058f 22p059a dle the vehicle and an accident may occur resulting in death or serious injuries.
Page 105 —Power rear view mirror control NOTICE CAUTION If ice should jam the mirror, do not Do not adjust the mirror while the operate the control or scrape the mir- vehicle is moving. Doing so may ror face. Use a spray de−icer to free cause the driver to mishandle the the mirror.
Page 106: Anti−Glare Inside Rear View Mirror
Anti−glare inside rear view mirror —Folding rear view mirrors CAUTION Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the ve- 22p066a 22p061a hicle and an accident may occur re- sulting in death or serious injuries. The rear view mirrors can be folded Adjust the mirror so that you can just backward for parking in compact areas.
Page 107: Auto Anti−Glare Inside Rear View Mirror
Auto anti−glare inside rear view mirror In automatic function mode, if the mirror detects light from the headlights of the vehicle behind you, the mirror surface darkens slightly to reduce the reflected light. To turn off the automatic function, push 22p235 22p214a the “...
Page 108: Vanity Mirrors
Vanity mirrors 22p098b 22p223 To use the vanity mirror, swing down To turn on the vanity light, slide the the sun visor and slide the cover. switch. The vanity light switch has the following positions: “ON”—Turns the light on when you swing down the sun visor.
Page 109 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlights and turn signals ........Emergency flashers .
Page 110: Headlights And Turn Signals
Headlights and turn signals (with automatic light control system) When the headlight switch is turned to the first or second clickstop, the brightness of the instrument cluster will be reduced slightly unless the instrument panel light control dial is turned fully on. 23p137a 23p124_1 NOTICE...
Page 111 Daytime running light system The headlights turn on at reduced intensi- ty when the parking brake is released with the hybrid system started, even with the light switch in the “OFF” position. To turn on the other exterior lights and 23p109b 23p110b instrument panel lights, twist the knob to...
Page 112 Headlights and turn signals (without automatic light control system) If the turn signal indicator lights (green Automatic light cut off system lights) on the instrument panel flash faster The lights automatically turn off when the than normal, a front or rear turn signal driver’s door is opened with the hybrid bulb is burned out.
Page 113 If the turn signal indicator lights (green lights) on the instrument panel flash faster than normal, a front or rear turn signal bulb is burned out. See “Replacing light bulbs—” on page 422. 23p003d 23p004d High−Low beams—For high beams, turn TURN SIGNALS the headlights on and push the lever away To signal a turn, push the headlight/...
Page 114: Emergency Flashers
Emergency flashers Instrument panel light control NOTICE To prevent the battery from being dis- charged, do not leave the lights on longer than necessary when the hy- brid system is not running. 23p005a 23p138 To turn on the emergency flashers, To adjust the brightness of the instru- push the switch.
Page 115: Front Fog Lights
Front fog lights Interior lights (on some models) To turn on the interior light, slide the switch. The interior light switch has the following positions: “ON”—Keeps the light on all the time. 23p111 23p126 “OFF”—Turns the light off. “DOOR”—Turns the light on when any door is opened.
Page 116: Personal Lights
Personal lights Luggage compartment light Key slot lights 23P012c 23p107 23p125 To turn on the personal light, push the To turn on the luggage compartment For easy access to the key slot, the key switch. To turn it off, push the switch light, push the switch upwards.
Page 117: Windshield Wipers And Washer
Windshield wipers and Rear window wiper and washer washer Twist the interval adjuster upward to increase the wiping time interval be- tween sweeps, and downward to de- crease it. The wiper lever must be in the “INT” posi- 23p008f tion. 23p123a To squirt washer fluid, pull the lever toward you and release it.
Page 118: Rear Window And Outside Rear View Mirror Defoggers
Rear window and outside rear view mirror defoggers For instructions on adding washer fluid, To defog or defrost the rear window, see “Adding washer fluid” on page 422. push the “CLIMATE” button to display air conditioner screen and touch the NOTICE switch.
Page 119 CAUTION Since the mirror surface can get hot, do not touch them when the switch is on. Make sure you turn the defogger off when the window is clear. Leaving the defogger on for a long time could cause the 12 volt battery to discharge.
Page 121 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators Fuel gauge ..........Odometer and two trip meters .
Page 122: Fuel Gauge
24p002b page 320.) If the fuel gauge display flashes, there may be a problem in the system. In this case, contact your Toyota dealer as soon Blin as possible. The gauge indicates the approximate If the fuel level approaches “E” or the low...
Page 123: Odometer And Two Trip Meters
Odometer and two trip meters At the first blinking of the light, the master warning light in the instrument cluster comes on and the message appears on the multi−information display to remind the driver to fill fuel. On inclines or curves, due to the move- 25p127a 24p004e ment of fuel in the tank, the low fuel level...
Page 124: Km/H Or Mph Button
Km/h or MPH button 3. Trip meter reset button—Resets the two trip meters to zero, and also change the meter display. To change the meter display, quickly push and release the button. The meter 24p115 display changes in the order from the odometer to trip meter A to trip meter B, then back to the odometer each time you push.
Page 125: Service Reminder Indicators And Warning Buzzers
Do this. If parking brake is off, stop immediately and contact Toyota dealer. (red indicator and buzzer) Take vehicle to Toyota dealer. If red brake system warning light is also on, stop imme- diately and contact Toyota dealer. (yellow indicator) Fasten driver’s seat belt.
Page 126 Close all doors. Fill up tank. Replace engine oil Take vehicle to Toyota dealer. If red brake system warning light is also on, stop imme- diately and contact Toyota dealer. Adjust tire inflation pressure. If light remains on, contact Toyota dealer.
Page 127 If any of the following conditions oc- The yellow warning light comes on curs, immediately stop your vehicle at while driving. a safe place and contact your Toyota YELLOW WARNING LIGHT dealer. When the regenerative brake system The red warning light does not turn is fails...
Page 128 Any of the following conditions may oc- You may hear a sound in the engine (c) Front Passenger’s Seat Belt cur, but do not indicate the malfunc- compartment when the driver’s door is Reminder Light and Buzzer tion: opened or the brake pedal is de- This light acts as a reminder to have the...
Page 129 Contact your teries will not be charged if the transaxle several trips, contact your Toyota deal- Toyota dealer as soon as possible so is in Neutral N.” appears on the multi−in- er as soon as possible.
Page 130 Contact your Toyota dealer if the fill fuel during braking. belt buckle switch, front passenger occu- gauge blinks. pant classification system, “AIRBAG ON”...
Page 131 “IG−ON” 2. Press the “POWER” switch twice to In the following cases, contact your Toyota mode. If you continue driving without en- select the “IG−ON” mode while holding dealer: gine oil replacement, and if the driving down the trip meter reset button.
Page 132 When ready to be initialized, the light blinks three times. When the system malfunctions... If the system malfunctions, the light blinks. Although it is no problem to continue driving, have your vehicle checked by your Toyota dealer as soon as pos- sible.
Page 133 It is normal if they go out after a while. If any service reminder indicator or warn- ing buzzer does not function as described above, have it checked by your Toyota Type 2 dealer as soon as possible.
Page 134 If the indicator comes on... Do this. Stop immediately and contact Toyota dealer. Stop and check. Stop and check. Take vehicle to Toyota dealer. Take vehicle to Toyota dealer immediately. Take vehicle to Toyota dealer. Take vehicle to Toyota dealer.
Page 135 NOTICE off the road to a safe place and stop the the vehicle and check your hybrid system. engine immediately. Call a Toyota dealer For detailed instructions, see “If your ve- When the charging system warning or qualified repair shop for assistance.
Page 136 If this light comes on, take your ve- light goes off. Even if the hybrid system warning light hicle to the Toyota dealer as soon as comes on, you can temporarily increase b. The hybrid battery is discharged. possible. In this case, you may feel...
Page 137 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS “POWER” switch, Transmission and Parking brake Push button start system ........Hybrid transaxle .
Page 138 Push button start system— —Key slot CAUTION Do not put your finger into the key slot. Your finger might be injured. 25p118 21p006a NOTICE Observe the following instructions, or the key mechanism might be damaged and will not work properly. z The key should be operated with a clean hand and fingers.
Page 139 Observe the following instructions or slot. the push button start system may not Should you find anything unusual, work properly. contact your Toyota dealer as soon as 25p113 z The switch should be operated with possible. a clean finger. Do not use an oily or dirty finger.
Page 140 —Selecting the push button start system mode (with smart function—on some models) 1) “ACC” (Green indicator is turned on) 3) “OFF” (Indicator is turned off) Accessories such as the radio operate. The hybrid system is off. Pressing the “POWER” switch briefly with- You may hear a motor sound in the en- out depressing the brake pedal in the gine compartment for a few seconds after...
Page 141 For starting tips, see “How to start the NOTICE hybrid system—” on page 350. z The hybrid system cannot If in an emergency, you must turn the started when the shift position is in hybrid system off while the vehicle is “N”.
Page 142 —Selecting the push button start system mode (without smart function) In the “ACC” mode, pressing the “POW- INFORMATION ER” switch briefly while depressing the brake pedal will start the hybrid system. You can insert a genuine key while in If you leave your vehicle in the “ACC” the “IG−ON”...
Page 143 For starting tips, see “How to start the NOTICE hybrid system—” on page 350. z The hybrid system cannot If, in an emergency, you must turn the started when the shift position is in hybrid system off while the vehicle is “N”.
Page 144 Hybrid transaxle Your hybrid transaxle has an electronic shift lever system to minimize incorrect operation. This means you can only shift to other position from “P” when the brake “P” position switch pedal is depressed. With the following improper shifting, the rejection function operates and a beep sounds so the hybrid transaxle cannot be shifted.
Page 145 Do not hang anything on the lever. pedal, shift the shift lever to “D”. Should you find anything unusual, CAUTION contact your Toyota dealer as soon as possible. (a) Shift lever Never put your foot on the accelera- The shift position is displayed on the in- tor pedal while shifting.
Page 146: Parking Brake Pedal
If the driver’s door is opened when the CAUTION transaxle is in “N”, “D” or “B”, beep sounds and a warning message appears Be careful when downshifting on a on the multi−information display to warn slippery surface. Abrupt shifting you to shift the transaxle to “P”. could cause the vehicle to skid or 25p004c If you push the “P”...
Page 147 In these cases, stop your vehicle in a control the speed using only the brake safe and level place, apply the parking pedal operation without depressing the ac- brake securely and contact your Toyota celerator pedal. dealer immediately. Regenerative brake...
Page 148 The slip indicator light blinks in the follow- may not function correctly. When ing conditions also. replacing the tires or wheels, con- tact your Toyota dealer. (See The vehicle tires are racing. Utmost “Checking and replacing tires” on care is required when driving.
Page 149 The slip indicator light comes on when the In the following cases, contact your Toyota “IG−ON” mode is enabled and will go off dealer: after the “READY” light comes on. If the The warning light does not come on indicator light does not come on when the after the “IG−ON”...
Page 150 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota deal-...
Page 151 Avoid abrupt maneuvering and bra- CAUTION As an added safety feature, your ve- king. If the vehicle tires deteriorate, hicle has been equipped with a tire you could lose control of the steer- Each tire, including the spare (if pro- pressure monitoring system (TPMS–...
Page 152 When the tires must be repaired or replaced, have them repaired or re- If a radio set at similar frequencies is placed by the nearest Toyota dealer in use in the vehicle. or an authorized tire dealer. The If a window tint that affects the radio tire pressure warning valves and wave signals is installed.
Page 153 Pushing the tire pressure warning reset switch should not turn off the tire pressure For vehicles sold in U.S.A. warning light. NOTICE: This equipment has been tested and This device complies with Part 15 of the found to comply with the limits for a FCC Rules.
Page 154 ID code of tire pres- pressly approved by the party respon- sure warning valve and transmitter. Have sible for compliance could void the the ID code registered by your Toyota user’s authority to operate the equip- dealer. ment.
Page 155 If initialization not performed. cannot be performed, have the system checked at your Toyota dealer. If you push the tire pressure reset switch accidentally and initialization is performed, adjust the tire inflation pressure to the specified level and initialize the system again.
Page 156 Parking brake Cruise control When parking, firmly apply the parking The cruise control allows you to cruise brake to avoid inadvertent creeping. the vehicle at a desired speed over 40 km/h (25 mph) even with your foot off To set: Fully depress the parking brake the accelerator pedal.
Page 157 Toyota deal- completely off. If the speed is not satisfactory, tap the er at the earliest opportunity.
Page 158 “– SET” direc- The indicator light does not come on. tion. The indicator light flashes again. The indicator light goes out after it comes on. If this is the case, contact your Toyota dealer and have your vehicle inspected.
Page 159 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Multi−information display Reference ..........Before using the multi−information display .
Page 160: Reference
Reference "Type 1 1. Multi−information display* (See page 163 for details.) 2. “DISPLAY” button display adjustment screen shown. (See page 238 for details.) 3. “INFO” button The information menu screen is shown. (See page 166 for details.) 4. “CLIMATE” button The air conditioning operation screen is 27p163b shown.
Page 161 "Type 2 1. Multi−information display* (See page 163 for details.) 2. “DISPLAY” button display adjustment screen shown. (See page 238 for details.) 3. “INFO” button The information menu screen is shown. (See page 166 for details.) 4. “CLIMATE” button The air conditioning operation screen is 27p162b shown.
Page 162 "Type 3 1. Multi−information display* (See page 163 for details.) 2. “DISPLAY” button display adjustment screen shown. (See page 238 for details.) 3. “INFO” button The information menu screen is shown. (See page 166 for details.) 4. “CLIMATE” button The air conditioning operation screen is shown.
Page 163: Before Using The Multi−Information Display
Before using the multi−information display Switch operation When the “ACC” mode is enabled, the This system operates mainly initial screen appears and the system be- switches on the screen. To protect the gins operating. screen, lightly touch switches screen with your finger. When you touch After a few seconds, the previous mode a switch on the screen or on the bezel, display will appear.
Page 164: Functions
Functions 26p148 26p027c 27p142a Type 1* Type 3 2. Adjustment The contrast and brightness on the screen 1. Trip information, Telephone, Lan- are adjusted. For details, see page 238. guage and Screen setting For details, see page 166. *: For other functions (Maintenance, Cal- ender and Beep setting), see the sepa- 27p149 rate “Navigation System Owner’s Manu-...
Page 165 27p150 26p203a 24p117 3. Air conditioner 4. Audio 5. Warning display Climate setting operations are available. The radio and compact disc operations The warning symbol for the faulty system For details, see page 288. are available. For details, see page 242. appears.
Page 166: Information
Information Type 1 Type 2 and Type 26p009b 27p148 26p027c Type 1 Type 3 Push the “INFO” button to display the “Information Menu” screen. Trip information: The energy monitor and fuel consumption screen are selected. Telephone: Telephone screen is shown. (See “Hands−free system”...
Page 167 —Trip information Energy monitor screen Touch the “Energy” switch. Vehicle driving condition, hybrid system operating condi- tion and energy recovery condition are shown. 27p151b 27p152b 1. Indicates the flow of energy by orange and yellow arrows. While the energy is recovered, arrows change...
Page 168 —Language Fuel consumption screen Touch the “Consumption” switch. Average fuel consumption, momentary fuel con- sumption recovered energy shown. 26P180 27p154 1. Indicates the past momentary fuel con- sumption every 5 minutes. 2. Indicates the energy recovered for 5 minutes with symbols. One symbol re- fers to 50 Wh or the energy by which a 50 W bulb illuminates for an hour.
Page 169: Screen Setting
—Screen setting You can select the language shown on SWITCH COLOR the screen. Touch your desired switch Select the desired switch color and on the screen. touch “OK”. DELETE PERSONAL DATA The following personal data can be de- 27p145 leted or returned to their default set- tings: Phone book data Dialed numbers and received calls...
Page 170 27p145 27p342 27p343 1. Touch “Delete personal data”. 2. Touch “Delete”. 3. Touch “Yes”. The “Delete personal data” screen ap- The “Confirmation for deleting all personal pears. data” screen appears.
Page 171: Hands−Free System
Hands−free system— BACKGROUND COLOR Hands−free system allows you to make or receive a call without taking your Select the desired background color hands off the steering wheel by con- and touch “OK”. necting your cellular phone. This system supports Bluetoothr. Bluetoothr is a wireless data system by 26p030c which you can call without your cellular...
Page 172 INFORMATION In the following conditions, the sys- tem may not function. The cellular phone is turned off. 27p333 27p334 The current position is outside the communication area. The cellular phone is not connected. The cellular phone has a low bat- tery.
Page 173 The other party’s voice outputs from the 2. Indicates amount battery driver’s speaker. When the received calls charge left. or received voice outputs, the audio from the audio system will be muted. Empty Full INFORMATION It is not displayed while the Bluetoothr is 27p180 connecting or the phone book data is be- Talk alternately with the other party...
Page 174 An antenna for the Bluetoothr connec- When you release your vehicle: INFORMATION tion is built in the display. The indica- A lot of personal data is registered tion of the Bluetoothr connection may This system supports the following when you use the hands−free system. turn yellow and the system may not When you release your vehicle, initial- service.
Page 175 — Entering a Bluetoothr phone To use the hands−free system, you CAUTION: Radio Frequency Radiation need to enter your phone into the sys- FCC ID: BABBT003A Exposure tem. Once you have registered it, you IC ID: 2024B−BT003A MADE IN JAPAN This equipment complies with FCC can make a hands−free call.
Page 176 27p181 27p182 27p183 2. Touch the “Telephone” switch to dis- 3. Touch the “Settings” switch to dis- 4. Touch “Bluetooth*” switch to play “Telephone” screen. play “Settings” screen. display “Bluetooth* Settings” screen. You can also push the button of the *: Bluetooth is a registered trademark of steering wheel to display this screen when Bluetooth SIG.
Page 177 27p184 27p185 27p186 5. Touch the “Register” switch to con- 6. When this screen is displayed, input 7. When the connection is completed, nect your cellular phone to the sys- the Passkey displayed on the screen this screen is displayed. tem.
Page 178 27p187 27p188 27p189 When this screen is displayed, follow the Connecting a Bluetoothr phone When the “ACC” or “IG−ON” mode is guidance on the screen to try again. enabled, the selected Bluetoothr phone (a) automatically will be automatically connected and the When you register your phone, auto connection result is displayed.
Page 179 Reconnecting the Bluetoothr phone If the Bluetoothr phone is disconnected with poor reception from Bluetoothr network when the “ACC” or “IG−ON” mode is enabled, the system automatically reconnects the Bluetoothr 27p190 27p191 phone. In this case, the connection result is not displayed. If the Bluetoothr is disconnected on pur- pose such as you turned your cellular phone off, this does not happen.
Page 180 —Calling on the Bluetoothr phone After you enter the Bluetoothr phone, Each time you touch “A”, an inputted you can call by using hands−free sys- digit is deleted. tem. You can call using the 7 methods When you touch “ ”, the number you described below.
Page 181 27p193 27p194 27p195 (b) By phone book 2. Select the desired number from the Touch “ ” or push the button of the list. You can call by phone book data which steering wheel. is transferred from your cellular phone. The system has one phone book.
Page 182 27p196 27p197 27p198 (c) By dialed numbers When you call by phone book, the Touch “ ” or push the button of the name (if registered) is displayed. You can call by dialed number. steering wheel. system memorizes up to 5 dialed num- When you call the same number con- tinuously, only the newest number is bers.
Page 183 27p196 27p199 27p200 (d) By received calls 2. Touch the “Incoming Calls” switch to When a telephone number registered in display “Incoming Calls” screen. the phone book is received, the name You can call by received calls. When and the number are displayed. a call is received, the system memo- rizes up to 5 numbers.
Page 184 27p198 27p201 27p202 (e) By speed dial 2. Touch the desired number to call. Touch “ ” or push the button of the You can change the page by touch- You can call by registered telephone steering wheel. ing “Speed Dial 2” or “Speed Dial number which you selected from a...
Page 185 You: Push the talk switch. System: “After the beep, please say the name.” You: “Charlize.” System: “Charlize chosen, when ready, 27p203 27p194 please briefly push talk switch or push the off−hook switch to dial.” You: Push the talk switch. System: “After the beep, please...
Page 186 Cancelling the voice recognition The voice recognition will be cancelled when you do the following. Keep on pushing the talk switch. Push the button of the steering 27p204 27p205 wheel. Touch the “Cancel” switch. (Except for recognizing the command) Say “Cancel”. “Next”...
Page 187 You: Push the talk switch. System: “After the beep, please say the number.” You: “812387” System: “When ready, please briefly 27p206 27p207 push the talk switch or push the off−hook switch to dial.” You: Push the talk switch. System: “After the beep, please continue to add numbers or say “Dial”.”...
Page 188 —Receiving on the —Talking on the Bluetoothr Bluetoothr phone phone To adjust the volume of received call: Touch “–” or “+” or use the volume switch of the steering wheel. On the international phone call, the other party’s name may not be displayed cor- rectly depending on the cellular phone 27p208 27p209...
Page 189 To input a Key: Touch the “0−9” switch. To transfer the call Touch the “Transfer Call” switch. You cannot change from hands−free call 27p206 27p210 to cellular phone call while you are driv- ing. When you change from cellular phone call to hands−free call, the hands−free screen will be displayed and you can operate it on the screen.
Page 190 You can do this operation when you want to operate an answering machine or use a telephone service in bank for example. You can register the phone number and the code number in the phone book. 27p211 27p212 Sending a tone by the speed tone 2.
Page 191 —Changing the settings of the Bluetoothr phone 27p311 27p214 27p215 Touch the “Settings” switch to display You can change the settings of the (a) Registering the speed dial “Settings” screen. phone. You can register the desired telephone number from phone book, dialed num- bers and received calls.
Page 192 27p216 27p217 27p218 2. Touch “Register” switch 3. Select the data you want to register. 4. Touch the desired telephone number. “Speed Dial”.
Page 193 27p219 27p220 27p221 5. Touch the switch you want to regis- 6. If you select a switch you registered Deleting the speed dial individually ter in. before, this screen is displayed. You can delete “01” − “17” of the The latest dialed number is registered in Touch the “Yes”...
Page 194 27p222 27p223 27p224 2. Touch the switch you want to delete. 3. Touch the “Yes” switch. Deleting all of the speed dial 1. Touch the “Delete All” switch of “Speed Dial”.
Page 195 27p225 27p226 27p227 2. Touch the “Yes” switch. (b) Registering the speed tone 2. Use the software keyboard to input the name. You can register the desired tone num- ber. Up to 6 speed tone numbers can be registered. 1. Touch “Register”...
Page 196 27p228 27p229 27p230 3. Input the number and touch “OK”. 4. Touch the desired switch you want 5. If you select a switch you registered to register in. before, this screen is displayed. Touch the “Yes” switch if you want to overwrite it.
Page 197 27p231 27p232 27p233 Editing the speed tone. 2. Touch the switch you want to edit. 3. Use the software keyboard to input the name. You can edit the speed tone. 1. Touch the “Edit” switch of “Speed Tone”.
Page 198 27p234 27p235 27p232 4. Input the number and touch “OK”. Deleting the speed tone individually. 2. Touch the switch you want to delete. You can delete “1” to “6” of the speed tone. If you delete them all at once, all of 6 numbers are deleted.
Page 199 27p236 27p237 27p238 3. Touch the “Yes” switch. Deleting all the speed tone 2. Touch the “Yes” switch. 1. Touch the “Delete All” switch of “Speed Tone”.
Page 200 Automatic volume settings for high speed You can set the volume one step up when the vehicle speed is over 80 km/h (50 mph). (When it is under 70 km/h (44 mph), previous volume is back.) 27p239 27p240 Each time you touch the “Adaptive Volume Control”...
Page 201 27p241 27p242 27p243 Initializing the settings Touch the “Yes” switch. (d) Setting the screen You can initialize the settings. 1. Touch the “Screen” switch to display the “Screen Settings” screen. Touch the “Default” switch.
Page 202 27p244 27p245 27p246 2. Do detailed settings Receiving Call Display Auto answer screen and touch “OK”. You can select the method of the re- When a call is received, the display ceiving call display. automatically changes to the talking screen and you can start to talk on the Touch the “Full”...
Page 203: Power" Switch
27p189 27p247 27p248 The Bluetoothr connection status at Touch the “ON” or “OFF” switch of Initializing the settings startup Show Bluetoothr connection status at You can initialize the settings. startup. When you turn the “POWER” switch to Touch the “Default” switch. “ACC”...
Page 204 27p249 27p250 27p251 Touch the “Yes” switch. (e) Setting the phone book You can do the detailed settings of phone book. You can register phone numbers in the phone book. Touch the “Phone Book” to display the “Phone Book Management” screen.
Page 205 27p252 27p253 27p254 Transferring a telephone number 2. Select the group you want to trans- 3. Touch the “Overwrite” or “Add To” fer the data to. switch. You can transfer the telephone numbers in your Bluetoothr phone to the sys- tem.
Page 206 27p255 27p256 27p257 4. Transfer the phone book data to the 5. When this screen is displayed, the When this screen is displayed, try the system using the Bluetoothr phone. transfer is completed. transfer operation again. This screen appears while transferring. To cancel it, touch the “Cancel”...
Page 207 27p258 27p259 27p260 Registering the phone book data 2. Touch the desired switch to edit the 3. When you complete the edit, touch phone book. the “OK” switch. You can register the phone book data. 1. Touch the “Register” switch.
Page 208 27p261 27p262 27p263 Editing the name 2. Use the software keyboard to input Editing the phone number the name. When you do not input the name, the You can register a phone number in number is displayed. “TEL1” and “TEL 2” separately. Up to 2 numbers a person can be registered.
Page 209 27p264 27p265 27p266 2. Input the number and touch ”OK”. 3. Select the desired icon. Selecting the group You can set a group for a contact (for example: “Family”, “Friends”, “Of- fice”...). It will then be easier for you to find this contact when needed, by using the group display.
Page 210 27p267 27p268 27p269 2. Select the desired group. Setting the voice recognition 2. Select the phone number and touch the “REC” switch to record a voice You can set the voice recognition. Up tag. to 20 numbers can be registered for the voice recognition.
Page 211 27p270 27p271 27p272 3. Touch the “PLAY” switch to play the Adding data to the phone book 2. Select the data you want to add log voice tag. data to. You can add data to the phone book. If you want to delete it, touch the “Delete” 1.
Page 212 27p273 27p274 27p272 3. Confirm added data Editing the data 2. Select the data you want to edit. screen and touch “OK”. You can edit the registered data. 1. Touch the “Edit” switch.
Page 213 27p275 27p276 27p277 3. Touch the desired switch. When you also touch the “Edit” switch Deleting the data on this screen, you can edit it. When you edit the data, touch “OK”. You can delete the data. When you release your vehicle, delete all your data on the system.
Page 214 27p272 27p278 27p193 2. Touch the desired switch. 3. Touch the “Yes” switch. You can also delete it in the following way. 1. Touch the “Phone Book” switch.
Page 215 27p194 27p279 27p280 2. Select the desired data. 3. Touch the “Delete” switch. 4. Touch the “Yes” switch.
Page 216 27p281 27p282 27p283 Deleting all the phone data 2. Select the deleting method. 4. Select the desired group. 1. Touch the “Delete All” switch of Group Data ..deleting all the phone “Phone book”. data in group All Contact Data deleting all the phone...
Page 217 27p284 27p193 27p285 5. Touch the “Yes” switch. You can also delete it in the following 2. Touch the “Delete All” switch. way. 1. Touch the “Phone Book” switch.
Page 218 27p286 27p287 27p288 3. Touch the “Yes” switch. Registering a group name 2. Select the group you want to regis- ter. register groups. “No Group”, “Group 01” − “Group 19” are registered by default. You can change “Group 01” − “Group 19” into desired names.
Page 219 27p289 27p290 27p291 3. When you complete all the edit, Selecting a group icon 2. Select the desired icon. touch the “OK” switch. 1. Touch the “Icon” switch.
Page 220 27p292 27p293 27p294 Editing a group name 2. Use the software keyboard to input Deleting a group name the name. 1. Touch the “Name” switch. You can delete the group names indi- vidually or all at once. If you delete a group name, that group will return to default setting.
Page 221 27p288 27p295 27p296 2. Select the group you want to delete 3. Touch the “Yes” switch. Deleting all the group names the name of. 1. Touch the “Delete All” switch of “Group Name”.
Page 222 27p297 27p298 27p299 2. Touch the “Yes” switch. Deleting the log data 2. Touch the “Yes” switch. You can delete the log data individually or all at once. When you release your vehicle, delete all the data on the system. individually 1.
Page 223 (f) Setting the security When you set the security, you can pre- vent people from using some functions of the hands−free system. It is useful when you leave your vehicle with the hotel or you do not want others to see 27p300 27p301 the data you registered.
Page 224 27p302 27p303 27p304 Changing the security code 2. Touch the “Change” switch. 3. Input the security code. The security code is 4 digits and the Choose a new code that is hard for other default is “0000”. people to know. 1.
Page 225 Phone Book Lock When you set the phone book lock, you have following functions locked. Display of the phone book screen and 27p305 27p306 transferring, registering, editing, delet- ing the phone book data. Display of speed dial screen, register- ing, deleting the speed dial and speed dialing.
Page 226 27p307 27p308 27p309 2. Input the security code and touch Initializing the security code 2. Input the security code and touch “OK”. “OK”. You can initialize the settings. 1. Touch the “Default” switch.
Page 227 — Setting a Bluetoothr phone 27p310 27p311 27p312 3. Touch the “Yes” switch. (a) Selecting a Bluetoothr phone 2. Touch the “Select Telephone” switch to display “Select Telephone” screen. In case you register more than one You can select the Bluetoothr phone Bluetoothr phone, you need to choose from a maximum of 6 numbers.
Page 228 27p313 27p314 27p315 Although register 3. Touch the “OK” switch. When the result message is displayed, Bluetoothr phones in the system, only one you can use the Bluetoothr phone. Bluetoothr phone can function at a time.
Page 229 (b) Displaying Bluetoothr information You can see or set the information of the Bluetoothr phone on the system. Device Name name Bluetoothr phone which 27p316 27p317 displayed screen. You can change it into a desired name. Bluetoothr Device Address ....the address peculiar to the system.
Page 230 27p318 27p319 27p318 2. Touch the “Change” switch. 3. When complete setting, (c) Changing a Device Name touch “ ”. You can change a device name. If you change a device name, the name regis- tered in your cellular phone is not changed.
Page 231 (d) Changing the Bluetoothr settings You can change the display and settings of Bluetoothr information on the system. information displays following items. 27p320 27p321 Device Name name Bluetoothr network. You can change it. Passkey ..the password when you register your...
Page 232 27p322 27p323 27p324 2. Touch “Change” “Device 3. Use the software keyboard to input 4. Input a Passkey with 4 − 8 digits. Name” or “Passkey”. the device name. When you touch “A”, the inputted digit is You can input up to 20 characters. deleted.
Page 233 27p325 27p326 27p327 5. When complete setting, (e) Initializing the Bluetoothr settings. 2. Touch the “Yes” switch. touch “ ”. You can initialize the settings. 1. Touch the “Default” switch.
Page 234 27p328 27p329 27p330 (f) Deleting a Bluetoothr phone 2. Select the telephone you want to de- 3. Touch the “Yes” switch. lete and touch “OK”. 1. Touch “Delete” switch “Bluetooth* Telephone”. *: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
Page 235 27p331 27p332 27p319 When you delete the telephone while (g) Displaying the information of the 2. When you complete confirming it, another Bluetoothr phone is connected, Bluetoothr phone you delete touch “ ”. this message is displayed. You can display the information of the Touch the “Yes”...
Page 236 —Speech command system If the hands−free system does not re- spond or the confirmation screen does not disappear, push speech command switch and try again. If no command is given, a beep sounds and the indicator disappears 6 seconds 27p335 27p203 later.
Page 237 —Help screen This system has a function which dis- plays the voice recognition help screen. You can see the command list and op- erating guide on it. 27p334 27p361 Microphone (a) Command List 1. Touch the “Command List” tab on It is unnecessary to speak directly into the upper side of the screen.
Page 238: Adjustment
Adjustment Type 1 Type 2 and Type 27p362 26p024a 27p142a Type 1 and Type 2 (b) Operating Guide Push the “DISPLAY” button to display the “Display” screen. 1. Touch the “Operating Guide” tab on the upper side of the screen. 2.
Page 239 Contrast and brightness adjustment Depending on the position of the head- light switch, the screen changes to the CONTRAST “+”: day mode or night mode. Strengthens the contrast of the screen. To display the screen in the day mode CONTRAST “–”: even with the headlight switch on, touch Weakens the contrast of the screen.
Page 240: Outside Temperature Display
Outside temperature display The outside temperature is shown rang- ing from −30_C (−22_F) up to 50_C (122_F) at the upper right of the energy consumption or energy monitor screen or the upper left/right of the air condi- tioner screen. 27p155b Separate to the above screen, when the outside temperature...
Page 241 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Audio system Reference ..........Using your audio system .
Page 242: Reference
Reference "Type 1 1. Multi−information display screen With (See page 248 for details.) Navigation 2. Ejecting a compact disc System (See page 266 for details.) 3. Compact disc slot (See page 266 for details.) 4. Frequency tuning and file search (See page 253 and 274 for details.) 5.
Page 243 10. Adjusting the volume (See page 247 for details.) 11. Compact disc load button (See page 266 for details.) 12. Audio operation screen display button (See page 248 for details.)
Page 244 "Type 2 1. Multi−information display screen (See page 248 for details.) 2. Ejecting a compact disc (See page 266 for details.) 3. Compact disc slot (See page 266 for details.) 4. Frequency tuning and file search (See page 253 and 274 for details.) 5.
Page 245 "Type 3 1. Multi−information display screen (See page 248 for details.) 2. Ejecting a compact disc (See page 271 for details.) 3. Compact disc slot (See page 271 for details.) 4. Frequency tuning (See page 253 for details.) 5. Scan tuning (See page 255 for details.) 6.
Page 246: Using Your Audio System
Using your audio system— —Some basics This section describes some of the basic TURNING THE SYSTEM ON AND OFF features Toyota audio system. Push “PWR” button to turn the audio sys- Some information may not pertain to your tem on and off. The system turns on in system.
Page 247 VOLUME CONTROL To adjust the volume, push and turn the “VOL”. Type 1 and Type 2 Type 1 Type 3 Type 2...
Page 248 26p260 26p136a Type 3 Radio (Type 1) Radio (Type 3) Push “AM”, “AM·SAT”, “FM”, “DISC” or “DISC·AUX” button to turn on that mode. The selected mode turns on directly. Push these buttons if you want to switch from one mode to another. If the disc is not set, the compact disc player does not turn on.
Page 249 26p205c 26p138a 26p206b Compact disc (Type 1) Compact disc (Type 3) TONE AND BALANCE Touching the “SOUND” switch on the The switches for radio and compact screen displays the sound adjustment disc player operation are displayed on screen. the liquid crystal display. Touch them lightly and directly on the screen.
Page 250 How good an audio program sounds to you is largely determined by the mix of the treble, mid−range, and bass levels. In fact, different kinds of music and vocal programs usually sound better with differ- ent mixes of treble, mid−range and bass. 26p261 A good balance of the left and right stereo channels and of the front and rear sound...
Page 251: Clock
AUTOMATIC SOUND LEVELIZER (ASL) YOUR RADIO ANTENNA YOUR COMPACT DISC PLAYER (Type 1 and Type 2 only) To remove an antenna on the roof, care- When you insert a disc, gently push it in When the audio sound becomes difficult to fully turn it counterclockwise.
Page 252: Radio Operation
Radio operation (a) Listening to the radio Push these buttons to choose either an AM or FM station. “AM”, “FM1” or “FM2” appears on the dis- play. If your vehicle is equipped with satellite radio broadcast system, when you push “AM·SAT”...
Page 253 Push and turn this knob to step up the station band or to step down. Your radio automatically changes to stereo reception when a stereo broadcast is re- ceived. “ST” appears on the display. If the signal becomes weak, the radio reduces 26P197 26p260 the amount of channel separation to pre-...
Page 254 (c) Selecting a station Tune in the desired station using one of the following methods. Preset tuning: Touch the switch (1−6) for the station you want. The switch (1−6) is 26p141a 26p262 highlighted in green and station frequency appears on the display. Manual tuning: Turn the “TUNE·FILE”...
Page 255 Preset scan tuning: Push the “SCAN” button or touch the “SCAN” switch (AM mode only) and hold it until you hear a beep. “P. SCAN” appears on the display. The radio will tune in the next preset sta- tion up or down the band, stay there for 26p126 26p263 a few seconds, and then move to the next...
Page 256 (d) RDS (Radio Data System) (1) Program type Each time you touch the “TYPE A” or “TYPE "” switch, program type changes as in the following: 26p142a 26p264 ROCK EASY LIS (Easy listening) CLS JAZZ (Classical music and Jazz) R&B (Rhythm and Blues) INFORM (Information) RELIGION Type 3...
Page 257 26p257 26p265 26p258 Type 3 Type 1 Type 3 When you touch the “TYPE A” or “TYPE "”, “TYPE SEEK” switch appears. Touch the switch and the system starts to seek the station in the relevant program type. Type 2...
Page 258 (2) Traffic program: A station that regularly broadcasts traf- fic information is automatically located. When touch “TRAF” switch, “TRAF SEEK” appears on the display and 26p266 26p259 the radio will start seeking any traffic pro- gram station. If any traffic program station is not found, “NOTHING”...
Page 259 (3) Radio text If the system receives a radio text from RDS station, “MSG” appears on the dis- play. Touch the “MSG” switch, and a text message is displayed on the screen. 26p267 26p145b Type 1 Type 3 In case a text message is not accepted in a screen, you can touch the “MSG”...
Page 260: Radio Operation (Xmr Satellite Radio Broadcast)
To listen to a satellite radio broadcast in Customers should have their radio ID your vehicle, an additional genuine Toyota ready; the radio ID can be found by se- satellite receiver and antenna must be lecting the “channel 000” on the radio.
Page 261 (e) Selecting a channel Tune in the desired channel using one of the following methods. Preset tuning: Touch the switch (1−6) for the channel you want. The switch (1−6) is 26P197 26p213b highlighted in green. Manual tuning within the channel cate- gory: Turn the “TUNE·FILE”...
Page 262 To scan the preset channels: Push the “SCAN” button and hold it until you hear a beep. “P.SCAN” appears on the display. The radio will find the next preset chan- nel, stay there for a few seconds, and then move to the next preset channel. To select a channel, push the “SCAN”...
Page 263 26p216c (g) Displaying the title and name When you touch the “TEXT” switch, the song/program title and the artist name/fea- ture are displayed. Up to 32 alphanumeric characters can be displayed. (Some information will not be fully displayed.)
Page 264 The XMr antenna is not connected. Check whether the XMr antenna cable is attached securely. ANTENNA A short−circuit occurs in the antenna or the surrounding antenna cable. See a Toyota certified dealer. You have not subscribed to the XMr satellite radio. The radio is being updated with the latest encryption code.
Page 265 NOTICE If this equipment does cause harmful This XMr tuner supports “Audio Ser- interference to radio or television re- vices” (Music and Talk) of only XMr This equipment has been tested and ception, which can be determined by satellite radio and “Text Information”, found to comply with the limits for a turning the equipment off and on, the linked to the respective “Audio Ser-...
Page 266: Compact Disc Player Operation (Type 1 And Type 2)
Compact disc player operation (Type 1 and Type 2) (a) Inserting or ejecting compact disc Setting all the discs: NOTICE Type 1: 1. Push the “LOAD” button until you Do not insert one disc stacked on top hear a beep. Setting a single compact disc: of another one or feed them in con- The amber indicators at both ends of the...
Page 267 26p129c 26p205c Ejecting a single alone: The numbers of the trays where the com- (b) Playing a compact disc pact disc is not set are dimmed. 1. Touch the switch (1−6) to highlight Type 1: the disc number you want to eject. Type 2: Push the “DISC·AUX”...
Page 268 The player will skip any empty disc trays. When the AUX adapter is in use, each time you push the “DISC·AUX” button, the audio switches the compact disc mode and AUX mode alternately. For details about AUX adapter, see page 278. 26p205c Type 2: Push the “DISC·AUX”...
Page 269 (e) Fast Forward/Reverse Push the “SEEK·TRACK” button and hold it to fast forward/reverse the disc. When you release the switch, the player will resume playing. 26p234b 26p235b When fast forwarding, if you reach the end of the final track, the player will go back to the start track and continue op- eration.
Page 270 After all the discs are scanned in one pass, normal play resumes. 26p218c 26p236b (j) Searching for a desired track (l) Displaying the track list Touch the “SCAN” switch briefly, the play- Touch the “TRACK LIST” switch. er will play the next track for 10 seconds, The track list screen will be displayed.
Page 271: Compact Disc Player Operation (Type 3)
“CD” appears on the display. If the malfunction is not rectified, take your vehicle to your Toyota dealer. The discs set in the player are played continuously. The track number and the time from the beginning of the program...
Page 272 (c) Selecting a desired track (d) Searching for a desired track (e) Other compact disc player functions “SEEK·TRACK” button: Use for direct Touch the “SCAN” switch. “RPT” switch: Use it for automatic repeat access to a desired track. of the track you are currently listening to. “SCAN”...
Page 273: Mp3/Wma Player Operation
The inside of the player unit may be cancel it, touch the “TITLE OFF” switch. too hot due to the very high ambient temperature. Eject the disc and allow the player to cool down. If the malfunction is not rectified, take your vehicle to your Toyota dealer.
Page 274 “TUNE·FILE” knob: Turn the knob clockwise to search up the files. Turn the knob counterclockwise to search down the files. 26p239b 26p240a (d) Selecting a desired folder (e) Selecting a desired file “FOLDER” switch: “TRACK” button: Touch either side of the “FOLDER” switch. Push the “SEEK·TRACK”...
Page 275 26p241b 26p242b (f) Fast forward/reverse (g) Repeating the same file (i) Listening to the files in the folder you are listening to, in random or- Push the “SEEK·TRACK” button and hold Touch the “RPT” switch briefly. When the it to fast forward/reverse the disc. When file is finished, the player will automatical- you release the switch, the player will ly go back to the beginning of the file and...
Page 276 26p243b 26p244b 26p245b (k) Searching for a desired file (m) Displaying the folder list (n) Displaying the file list Touch the “SCAN” switch briefly, and the Touch the “FOLDER LIST” switch. Touch the “FILE” switch. player will play the next file for 10 se- The folder list screen will be displayed.
Page 277: Audio Remote Controls
Push “+” to increase the If the malfunction is not rectified, take volume and “–” to decrease the volume. your vehicle to your Toyota dealer. The volume continues to increase or de- crease while the switch is being pressed.
Page 278: Aux Adapter
AUX adapter (Type 1 and Type 2 only) (a) When the radio mode is selected (b) When the “CD” mode is selected “ ” or “ ” switch: Push this switch for “ ” or “ ” switch: Use this switch to seek tuning or to select a station.
Page 279: Audio System Operating Hints
Audio system operating hints If you install an audio system other than Here are some common reception prob- NOTICE a genuine audio system, you will not be lems that probably do not indicate a prob- able to use the AUX adapter. lem with your radio: To ensure correct audio system op- erations:...
Page 280 Bumpy roads or other vibrations may make your compact disc player skip. Fading—AM broadcasts are reflected by the upper atmosphere—especially at night. If moisture gets into your compact disc These reflected signals can interfere with player, you may not hear any sound those received directly from the radio sta- even though your compact disc player tion, causing the radio station to sound...
Page 281 NOTICE z Do not use special shaped, trans- parent/translucent, low quality or la- beled discs such as those shown in the illustrations. The use of such discs may damage the player or changer, or it may be impossible to eject the disc. z This system is not designed for use of Dual Disc.
Page 282 MP3 WMA FILES MP3 (MPEG Audio Layer 3) and WMA (Windows Media Audio) are audio com- pression standards. The MP3/WMA player can play MP3 and WMA files on CD−ROM, CD−R and CD−RW discs. The unit can play disc recordings com- patible with ISO 9660 level 1 and level 2 and with the Romeo and Joliet file Correct...
Page 283 WMA files can contain a WMA tag that The MP3/WMA player does not play is used in the same way as an ID3 back MP3/WMA files from discs record- tag. WMA tags carry information such er using packet write data transfer 001.mp3 as track title, artist name.
Page 284 CD−R and CD−RW discs Recordings on CD−R/CD−RW cannot ISO 9660 format— be played using the DDCD (Double CD−R/CD−RW discs that have not been This is the international standard for the Density CD) system. subject to the “finalizing process” (a formatting of CD−ROM folders and files. proc ess that allows discs to be played TERMS For the ISO 9660 format, there are two...
Page 285 WMA— WMA (Windows Media Audio) is an audio compression format developed by Micro- soft. It compresses files into a size small- er than that of MP3 files. The decoding formats for WMA files are Ver. 7, 8, and...
Page 287 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Controls ........... Climate remote control .
Page 288: Controls
Controls "Type 1 1. Passenger compartment temperature display 2. Outside temperature display 3. Temperature control switches 4. Air flow control switches 5. Fan speed control switches 6. Automatic control switch 7. Air intake control switch 8. Rear window and outside rear view mirror defogger switch (See page 118 27p165a for details.)
Page 289 "Type 2 1. Passenger compartment temperature display 2. Outside temperature display 3. Temperature control switches 4. Air flow control switches 5. Fan speed control switches 6. Automatic control switch 7. Air intake control switch 8. Rear window and outside rear view mirror defogger switch (See page 118 27p164a for details.)
Page 290 "Type 3 1. Outside temperature display 2. Passenger compartment temperature display 3. Air flow control switches 4. Fan speed control switches 5. Temperature control switches 6. “OFF” switch 7. Automatic control switch 8. Rear window and outside rear view mirror defogger switch (See page 118 27p337 for details.) 9.
Page 291 The automatic air conditioning automat- ically maintains the set temperature. This air conditioning features automatic fan speed and air flow control which auto- matically selects the most suitable fan speed and air flow to control the tempera- ture. The hybrid system must be in the “IG−ON”...
Page 292 (a) Climate control SETTING OPERATION—automatic con- When one of the manual control buttons trol is depressed while operating in automatic mode, the mode relevant to the depressed 1. Touch the “AUTO” switch. button is set. Other conditions continue to The indicator located in the instrument be adjusted automatically.
Page 293 2. Use the “TEMP” switch to set the SETTING OPERATION—manual control desired temperature. When manual control The temperature of air delivered to the switches is touched while operating in passenger compartment will be controlled automatic mode, the mode relevant to automatically according to the setting.
Page 294 If manual air flow selection is desired— The outlets from which air is delivered If quick heating or cooling is desired— can be selected manually by touching the switch. The function of each mode is as follows: 1. Panel—Air flows mainly from instrument panel vents.
Page 295 Touch the “TEMP” switches and hold ei- If manual fan speed control is desired— 1. Fan speed at low ther one until the maximum figure or mini- 2. Fan speed at high mum figure appears. The fan speed can be set to your desired speed by touching the appropriate air flow control switch.
Page 296 If manual switching of air intake is de- The air intake control switch is used to 2−way air intake control sired— switch the air intake between the OUT- To improve fuel economy, OUTSIDE AIR SIDE AIR mode and RECIRCULATED AIR mode control changes when the air in- mode.
Page 297 (b) Windshield defogging and defrosting If manual on−off of the air conditioning To remove interior fog on the wind- is desired— shield— Touch the “A/C” switch to turn the air Touch the windshield air flow switch. conditioning on and touch it again to turn To remove frost or exterior fog on the the air conditioning off.
Page 298 OUTSIDE AIR and the fan speed se- To cool off your Toyota after it has lector to any setting except “OFF”. been parked in the hot sun, drive with If following another vehicle on a dusty the windows open for a few minutes.
Page 299: Climate Remote Control
Climate remote control Instrument panel vents (steering switches) “ ” switch: Use this switch to turn on or off the rear window and outside rear view mirror defoggers. (For details, see page 118.) 27p006a CAUTION 27p104 Operate the switches with due care while you are driving to avoid acci- dents.
Page 300: Air Conditioning Filter
—Checking and replacing the Air conditioning filter— air conditioning filter The air conditioning filter may clog af- ter long use. The filter may need to be replaced if the air flow of the air condi- tioning and heater experiences extreme reductions in operating efficiency, or if the windows begin to fog up easily.
Page 301 82p007a 82p107 82p008c 1. Open the glove box, and slide off 2. Push in each side of the glove box 3. Pull the filter case toward you to the damper as shown. to disconnect the claws. take it out.
Page 302 5. Install the filter and filter case in the reverse order of removal. When setting the filter to the filter case, ensure that the flat side of the filter is down and the ribbed side is up. 82p009b Position the filter case so that the “yUP” mark is pointing up and install it in the vehicle.
Page 303 SECTION – OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Clock ............Rear view monitor system .
Page 304: Clock
Rear view monitor system Clock The rear view monitor system assists CAUTION the driver by displaying an image of the view behind the vehicle while back- Never depend on rear view ing up. The image is displayed in re- monitor system entirely when back- verse on the screen.
Page 305 When replacing the tires, please consult If the back of the vehicle is hit, the your Toyota dealer. If you replace the position and mounting angle of the tires, the area displayed on the screen camera may change. Be sure to may change.
Page 306 AREA DISPLAYED ON SCREEN When water droplets are adhering to the camera, or when humidity is high Image is displayed approximately level (for example, when it rains) on screen. When foreign matter (for example, The area detected by the camera is snow or mud) adheres to the camera limited.
Page 307: Power Outlets
Power outlets The power outlets are designed for power supply for car accessories. The hybrid system must be in “ACC” or “IG−ON” for the power outlets to be used. NOTICE 28p010a z To prevent the fuse from being blown, do not use the electricity over the total vehicle capacity of 12V/120W.
Page 308: Rear Console Box
Glove boxes Rear console box To open the glove boxes, push each button. The inside of the upper glove box is sepa- rated by the partition. When storing a lon- ger object, remove the partition. 28p002a With the instrument panel lights on, the lower glove box light will come on when the lower glove box is open.
Page 309: Garage Door Opener
Garage door opener (a) Programing the HomeLink When the programming the HomeLink Indicator light first time, erase HomeLink The HomeLink in your vehicle has 3 memory once before following the steps buttons and you can store one program below to program the HomeLink .
Page 310 28p130a 28p131 28p132 25 to 75 mm HomeLink (1 to 3 in.) Hand−held garage transmitter 2. Place your hand−held garage transmit- 3. Simultaneously press hold 5. Test the operation of the HomeLink ter 25 to 75 mm (1 to 3 in.) away from hand−held garage transmitter...
Page 311 1. Decide which of the 3 HomeLink but- security systems, home door locks or ing mounted garage door opener motor. tons you want to program. lighting, contact your authorized Toyota The exact location and color of the dealer for assistance. 2. Place your hand−held...
Page 312 Using a garage For additional programming assistance door opener without these features with your HomeLink Universal increases risk of serious injury or Transceiver call the: death. Toyota Customer Experience Center at 1−800−331−4331 (U.S.A.) Toyota Canada Customer Interaction Centre at 1−888−869−6828 (Canada)
Page 313: Auxiliary Boxes
Auxiliary boxes To use the box, open the lid as shown in the following illustrations. CAUTION 28p003a To reduce the chance of injury in 28p117 case of an accident or a sudden stop, always keep the auxiliary box closed while driving. Auxiliary box on the ceiling—...
Page 314: Cup Holders
Cup holders Bottle holders The cup holder is designed for holding cups or drink−cans securely. To use the cup holder, open the lid. 28p005b CAUTION 28p109 Do not place anything else other than cups or drink−cans on the cup holder, such items thrown about in the compartment...
Page 315: Tie−Down Hooks
Tie−down hooks Luggage storage box NOTICE Do not put a cup or open bottle in the bottle holder because the con- tents may spill when the door opens or closes. 22p120 28p112a To secure your luggage, use the tie− 1. To open the luggage storage box, turn down hooks as shown above.
Page 316: Luggage Cover
Luggage cover 28p113a 28p114 28p115 2. Hold the lid open by inserting the sup- To use the luggage cover, pull it out of To remove the luggage cover, lift it up. port rod into the slot. the retractor and hook it on the an- chors.
Page 317: Floor Mat
Floor mat 28p007b 28p116a 28p125 You can stow the luggage cover in the To replace the luggage cover, adjust the Use a floor mat of the correct size. luggage storage luggage cover so that “TOP” is facing upwards. If the vehicle carpet and floor mat have compartment as shown in the illustration.
Page 318 28p008b CAUTION Make sure the floor mat is properly placed on the vehicle carpet. If the floor mat slips and interferes with the movement of the pedals during driv- ing, it may cause an accident.
Page 319 INFORMATION BEFORE DRIVING YOUR TOYOTA Information before driving your Toyota Break−in period ..........
Page 320: Break−In Period
To help prevent gas station mixups, your to the future economy and long life of If your engine knocks... Toyota has a smaller fuel tank opening. your vehicle: The special nozzle on pumps with un- If you detect heavy knocking even when Avoid full−throttle...
Page 321 Toyota, be sure that it has an octane try changing gasoline brands. If this does The WWFC consists of four categories rating no lower than 87.
Page 322: Fuel Pump Shut−Off System
Fuel pump shut−off system FUEL TANK CAPACITY The fuel pump shut−off system stops sup- If you plan to drive your Toyota in plying fuel to the engine to minimize the another country... 45 L (11.9 gal., 9.9 lmp.gal.) risk of fuel leakage when the engine stalls...
Page 323: Three−Way Catalytic Converters
Do not drive, idle or park your ve- as possible. Remember, your Toyota hicle over anything that might burn dealer knows your vehicle and its easily such as grass, leaves, paper three−way catalytic converter sys-...
Page 324: Engine Exhaust Cautions
The exhaust gases cannot your Toyota dealer. Continued in- chamber. This oil as well as some part escape, making this a particularly halation of exhaust fumes can lead of the oil film left on the cylinder wall dangerous situation.
Page 325 Oil consumption: Max. 1.0 L per 1000 is essential that the oil level be checked km (1.1 qt./600 miles, 0.9 Imp.qt./600 regularly. Toyota recommends that the oil miles) level be checked every time you refuel When judging the amount of oil con- the vehicle.
Page 326: Coolant Heat Storage System
Coolant flow control The coolant in this tank is hot even valve if the engine and radiator are cold. replacement coolant, 30p103 contact your Toyota dealer. touch bolts pieces) painted in yellow. In case the bolts are loosened, Electric water pump...
Page 327: Brake System
If the brake system have passed. warning light comes on, immediately stop your vehicle and contact your Toyota deal- The brake pedal stroke may be short when you press the “POWER” switch with the brake pedal depressed.
Page 328 ANTI−LOCK BRAKE SYSTEM Depressing the brake pedal on slippery CAUTION road surfaces such as on a manhole cov- The anti−lock brake system is designed er, a steel plate at a construction site, to automatically help prevent lock−up of Do not pump the brake pedal if the joints in a bridge, etc.
Page 329 CAUTION Anti−lock brake system is not de- signed to shorten the stopping dis- overestimate anti−lock tance: Always drive at a moderate brake system: Although the anti−lock speed and maintain a safe distance brake system assists in providing ve- from the vehicle in front of you. 30p002b hicle control, it is still important to Compared with vehicles without an...
Page 330 Contact your vehicle decelerates to a speed below tion: Toyota dealer as soon as possible to approximately 5 km/h (3 mph). The light may stay on for about 60 service the vehicle. For an explanation of this system’s warn- seconds after the “IG−ON”...
Page 331: Electric Power Steering System
This checked and replaced by your Toyota is power steering motor noise, and is not NOTICE dealer as soon as possible. Expensive ro- a malfunction. tor damage can result if the pads are not If you repeat the operation which will replaced when necessary.
Page 332: Your Toyota's Identification
This number is on the left top of the axle case as shown. instrument panel, and can be seen through the windshield from outside. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle.
Page 333: Theft Prevention Labels
Suspension and chassis Theft prevention labels Your new vehicle carries theft preven- CAUTION tion labels which are approximately 47 mm (1.85 in.) by 12 mm (0.47 in.). Do not modify the suspension/chassis The purpose of these labels is to reduce with lift kits, spacers, springs, etc.
Page 334: Tire Information
Tire information— —Tire symbols (Standard tire) This illustration indicates typical tire symbols. 1. Tire size—For details, see “Tire size” on page 338. 2. DOT Tire Identification Number (TIN)—For details, see “DOT and Tire Identification Num- ber (TIN)” on page 337. 3.
Page 335 6. Radial tires or bias−ply tires—A radial tire has “RADIAL” on the sidewall. The tire not marked with “RADIAL” is a bias−ply tire. 7. “TUBELESS” or “TUBE TYPE” —A tubeless tire does not have a tube inside the tire and air is direct- ly filled in the tire.
Page 336 —Tire symbols (Compact spare tire) This illustration indicates typical tire symbols. 1. “TEMPORARY USE ONLY”—A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded into its sidewall. This tire is designed for temporary emergency use only. For details, see “Compact spare tire”...
Page 337 —DOT and Tire Identification Number (TIN) 6. Maximum cold tire inflation The “DOT” symbol certifies that the pressure—This means the pres- tire conforms to applicable Federal sure to which a tire may be in- Motor Vehicle Safety Standards. flated. For recommended cold tire inflation pressure, see “Tires”...
Page 338 —Tire size —Name of each section of tire 30p227a 21A007a 21A006a This illustration indicates typical tire 1. Section width 1. Bead size. 2. Tire height 2. Sidewall 1. Tire (P=Passenger car, 3. Wheel diameter 3. Shoulder T=Temporary use) 4. Tread 2.
Page 339 150 would wear conditions on specified government purchasers of Toyota vehicles with in- one and a half (1−1/2) times as well test surfaces of asphalt and concrete. formation on uniform tire quality grad-...
Page 340 Temperature A, B, C—The tempera- ture grades are A (the highest), B, and C, representing the tire’s resis- tance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 341 —Glossary of tire terminology Tire related term Meaning tire inflation pressure when the vehicle has been parked for at least 3 hours or more, or it has not been driven more than 1.5 km or 1 mile under that Cold tire inflation pressure condition the maximum cold inflation pressure to which a tire may be inflated and it is Maximum inflation pressure...
Page 342 Tire related term Meaning the combined weight of those installed regular production options weighing over 2.3 kg (5 lb.) in excess of those standard items which they replace, not pre- Production options weight viously considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim Vehicle capacity weight the rated cargo and luggage load plus 68 kg (150 lb.) times the vehicle’s desig-...
Page 343 Tire related term Meaning the load on an individual tire that is determined by distributing to each axle Vehicle normal load on the tire its share of the curb weight, accessory weight, and normal occupant weight (distributed in accordance with Table 1 that follows) and dividing by two Weather side the surface area of the rim not covered by the inflated tire Table 1–...
Page 344: Vehicle Load Limits
Be sure all items are se- Towing capacity described on the tire and loading in- cured in place. Toyota does not recommend towing formation label. For location of the tire D Be careful to keep the vehicle bal- a trailer with your vehicle. Your ve- and loading information label, see anced.
Page 345 —Capacity and distribution Cargo capacity depends on the to- NOTICE D Never allow anyone to ride in tal weight of the occupants. the luggage compartment. It is Do not load the vehicle beyond the (Cargo capacity) = (Total load capac- not designed for passengers.
Page 346 (4) The resulting figure equals the Toyota does not recommend towing available amount of cargo and lug- a trailer with your vehicle. Your ve- gage load capacity. For example, hicle is not designed for trailer towing. if the “XXX” amount equals 1400 lbs.
Page 347: Types Of Tires
Types of tires 199 kg – 176 kg = 23 kg. Determine what kind of tires your CAUTION (444 lb. – 388 lb. = 56 lb.) vehicle is originally equipped with. As shown in the above example, if the 1. All season tires Even if the total load of occu- number of occupants increases, the All season tires are designed to pro-...
Page 348 2. Summer tires CAUTION Summer tires are high−speed capabil- ity tires best suited to highway driving D Do not mix summer and all sea- under dry conditions. son tires on your vehicle as Since summer tires do not have the this can cause dangerous han- same traction performance as snow dling characteristics, resulting...
Page 349 SECTION STARTING AND DRIVING Starting and driving Before starting the hybrid system ......How to start the hybrid system .
Page 350: Before Starting The Hybrid System
How to start the hybrid (b) Turning on the hybrid system— (a) Before starting system (Using the smart Before starting the hybrid the hybrid system system function—on some models) 1. Check the area around the vehicle be- 1. Apply the parking brake firmly. fore entering it.
Page 351 If the “READY” the “READY” light. If this happens, contact light does not come on, contact your Toyota dealer. your Toyota dealer. Before starting the hybrid system, be sure CAUTION z When you start the hybrid system to follow the instructions in “(a) Before...
Page 352: Tips For Driving In Various Conditions
To dry them, drive vehicle cautiously while lightly pressing the brake pedal with the park- ing brake applied. If they still do not work safely, pull to the side of the road and call a Toyota dealer for assistance.
Page 353: Driving In The Rain
Driving in the rain Driving on a slippery road surface CAUTION Do not drive in excess of the speed Drive carefully when it is raining, because limit. Even if the legal speed limit visibility will be reduced, the windows may Before driving off, make sure the permits it, do not drive over 140 become fogged−up, and the road will be...
Page 354: Winter Driving Tips
CAUTION protection for engine coolant. Do not drive on a road that has flooded after heavy rain etc. Doing so may cause Only use “Toyota Super Long Life Coolant” Sudden braking, acceleration and serious damage to the vehicle. similar high quality ethylene glycol steering when driving on a slippery based non−silicate, non−amine, non−nitrite,...
Page 355: Dinghy Towing
Section 8−3 tells you how to visually inspect the 12 volt battery. Your Do not use your parking brake when Toyota dealer will be pleased to check the there is a possibility it could freeze. level of charge. When...
Page 356: Trailer Towing
Stop−and−go driving sion. carrier for a wheelchair, scooter, bi- wastes power. cycle, etc. Your Toyota is not designed Keep your vehicle tuned−up and in Avoid unnecessary stopping for trailer towing or for the use of tow top shape. A dirty air cleaner, improp- braking.
Page 357 CAUTION Never turn off the hybrid system to coast down hills. Your power steering and brake booster will not function without the hybrid system running. Also, the emission control system op- erates properly only when the hybrid system is running.
Page 359: In Case Of An Emergency
SECTION IN CASE OF AN EMERGENCY In case of an emergency If your vehicle will not start ........If your hybrid system stalls while driving .
Page 360 Have the key checked at your electrical burns, or damaged electronic Toyota dealer. If none of your keys work, components, these instructions must be there may be a malfunction in the hybrid followed precisely.
Page 361 If the on yourself or in your eyes, remove “READY” light does not come on, any contaminated clothing and flush contact your Toyota dealer. the affected area with water imme- diately. Then get immediate medical attention. If possible, continue to...
Page 362 7. If the engine in the vehicle with the booster battery is not running, start it Exclusive jump starting Exclusive jump and let it run for a few minutes. During terminal cover starting terminal jump starting, run the engine at about 2000 rpm with the accelerator pedal lightly depressed.
Page 363 “READY” light is on. If the hybrid bat- Jumper tery warning light comes on in the mul- cable ti−information display, the hybrid battery is also discharged. Contact your Toyota 50p080a dealer. 50p045c 11. Carefully disconnect the cables in the exact reverse order: the negative cable and then the positive cable.
Page 364 4. If the coolant is leaking, stop the hy- system. Wait until the steam subsides steering will not work so steering and brid system immediately. Call a Toyota before opening the hood. If there is no braking will be much harder than usu- dealer for assistance.
Page 365 You should have it checked as bility of death or serious injury: a highway. Park on a level spot soon as possible at your Toyota dealer. with firm ground. D Follow jacking instructions. 2. Stop the hybrid system and turn D Do not put any part of your on your emergency flashers.
Page 366 NOTICE D Make sure to set the jack prop- erly in the jack point. Raising Do not continue driving with a de- the vehicle with jack improper- flated tire. Driving even a short dis- ly positioned will damage the tance can damage a tire and wheel vehicle or may allow the ve- beyond repair.
Page 367 The compact spare tire can be used NOTICE CAUTION many times, if necessary. It has tread life of up to 4800 km (3000 miles) de- Your ground clearance reduced D The compact spare tire was de- pending on road conditions and your when compact spare...
Page 368 —Required tools and spare tire 50p010e 50p008c 50p009a 1. Get the required tools and spare To remove the jack, unlock the tight- To remove the spare tire: tire. ening strap. 1. Remove the luggage storage box. 1 Wheel nut wrench To store the jack, make sure it is se- 2.
Page 369 —Blocking the wheel —Loosening wheel nuts When installing the jack box, align the arrows on the jack box with the ones on the body. 50p011b 50p051b 2. Block the wheel diagonally op- 3. Loosen all the wheel nuts. posite the flat tire to keep the Always loosen the wheel nuts before vehicle from rolling when it is raising the vehicle.
Page 370 —Positioning the jack —Raising your vehicle CAUTION Never use oil or grease on the bolts or nuts. The nuts may loos- en and the wheels may fall off, 50p014e 50p015c which could cause a serious ac- cident. 4. Position the jack at the jack 5.
Page 371 —Changing wheels CAUTION Never get under the vehicle when the vehicle is supported by the jack alone. 50p052 50p017c 6. Remove the wheel nuts and Before putting on wheels, remove any change tires. corrosion on the mounting surfaces with a wire brush or such. Installation Lift the flat tire straight off and put it of wheels without good metal−to−met- aside.
Page 372 —Reinstalling wheel nuts —Lowering your vehicle CAUTION Never use oil or grease on the bolts or nuts. Doing so may lead to overtightening the nuts and 50p018c 50p019c damaging the bolts. The nuts may loosen and the wheels may fall off, which could cause a seri- ous accident.
Page 373 —Stowing flat tire 9. Restow all the tools and jack se- CAUTION curely. Then secure the flat tire in the luggage compartment D When lowering the vehicle, with the tire tie−down belts and make sure all portions of your tie−down hooks as follows body and all other persons 50p087 around will not be injured as...
Page 374 50p088 50p089 50p090 2. Put the flat tire on the center of 3. Pass the belts through the center 4. Attach the other ends of the belts the luggage storage box lid with hole of the wheel as shown above. to the rear tie−down hooks.
Page 375 D When carrying the flat tire, se- slowly to the nearest Toyota dealer cure it using a tire tie−down and fill to the correct pressure. belts. Otherwise, the flat tire...
Page 376 If towing is necessary, we recommend TOWING PRECAUTIONS: (a) Towing with wheel lift type truck— you to have it done by your Toyota Use a safety chain system for all towing, —From front dealer or a commercial tow truck ser- and abide by the state/provincial and local vice.
Page 377 Towing in this manner may be done only (c) Towing with sling type truck If towing is necessary, we recommend on hard−surfaced roads for a short dis- you to have it done by your Toyota tance speeds. Also, NOTICE...
Page 378 —Installing towing eyelet Before towing, release the parking brake CAUTION and put the hybrid transaxle in “N”. The hybrid system must be in the “IG−ON” Use extreme caution when towing ve- mode. hicles. Avoid sudden starts or erratic In the following cases, as the front wheels driving maneuvers which would place might be locked by means of the parking excessive stress on the emergency...
Page 379 Toyota dealer if you can give them the key number and master key. Even if you lose only one key, contact your Toyota dealer to make a new key. If 50p047a you lose all your master keys, you cannot 50p048a make new keys;...
Page 380 Be sure to have the back door opener To open the back door from inside, per- checked/repaired by your Toyota dealer. form the following procedure. 1. Open the luggage storage box (See “Luggage storage box” on page 315.)
Page 381 APPEARANCE CARE Corrosion prevention and appearance care Protecting your Toyota from corrosion ......Washing and waxing your Toyota .
Page 382 Now, it is up to be dry. wet the mud and debris without remov- you. Proper care of your Toyota can help ing. The lower edge of doors, rocker High ambient temperatures can cause ensure long−term corrosion prevention.
Page 383 Washing and waxing your Toyota Check the interior of your vehicle. Wa- Your Toyota is a hybrid vehicle. Pay When driving in a coastal area ter and dirt can accumulate under the particular attention when washing your When driving on a road sprinkled with floor mats and could cause corrosion.
Page 384 Do not instructions. Use a soft cotton mitt and rub or press hard—you might scratch Waxing your Toyota keep it wet by dipping it frequently into the paint. Polishing and waxing is recommended the wash water.
Page 385 Cleaning the interior 3. Wax the vehicle again when water First vacuum over the upholstery to re- CAUTION does not bead but remains on the sur- move loose dirt. Then, using a sponge or face in large patches. soft cloth, apply the soap solution to the Do not wash the vehicle floor with vinyl.
Page 386 Do not apply water—the best results are Windows NOTICE obtained by keeping the carpet as dry as The windows may be cleaned with any possible. Read the shampoo instructions z Do not use organic substances (sol- household window cleaner. and follow them closely. vents, kerosene, alcohol, gasoline, NOTICE etc.) or alkaline or acidic solutions.
Page 387 If you have any questions about the leather these could cleaning of your Toyota, your local cause discoloring. Toyota dealer will be pleased to answer them. z Use of a nylon brush or synthetic fiber cloth, etc. may scratch the fine grained surface of the leather.
Page 389 Customer Experience Center 1-800-331-4331 POWERED 2007 Pocket Reference Guide MN 00452-PRG07-PRI Printed in USA 07/06...
Page 390 Remove the luggage storage box. Your dealership and the entire staff of Toyota Loosen the bolt and remove it. Motor Sales, U.S.A., Inc. wish you many years Remove the jack box.
Page 391 Jump starting Rear air vent Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Warning System reset Programmable by customer. For dealer-programmable features, please visit your Toyota dealer. HomeLink ® is a registered trademark of Johnson Controls, Inc.
Page 392: Key Slot
BASIC HYBRID VEHICLE OPERATION Hybrid Synergy Drive System Key fob The Hybrid Synergy Drive System utilizes a computer Master key controlled gasoline engine and electric motor to provide the most efficient combination of power for the vehicle. To conserve energy, when the brakes are applied, braking force generates electricity which is then sent to the traction battery.
Page 393 BASIC HYBRID VEHICLE OPERATION Keyless entry Smart Key (if equipped) Locking operation Push Unlocking operation By carrying a Smart Key, the vehicle can be locked, unlocked and the Hybrid System engaged without handling the key. Locking operation Push ONCE: Driver door Rear hatch Front door TWICE: All doors...
Page 394 BASIC HYBRID VEHICLE OPERATION Unlocking operation Turning the Hybrid System ON Rear hatch Front door Start function NOTE: After unlocking, if a door is not opened within 30 seconds, all doors will relock for safety. Refer to your Owner’s Manual and the following section of this guide for Smart Key unlocking programmable options.
Page 395 BASIC HYBRID VEHICLE OPERATION Parking & turning OFF the Hybrid System Shifting Park button Shift position Shift lever Park button Reverse (Buzzer sounds) Neutral When the vehicle is at a complete stop, keep brake pedal depressed and push Park button Drive above the shift lever.
Page 396 OVERVIEW Instrument panel Without navigation system With navigation system 1, 2 Headlight, turn signal and front fog light controls Audio system Wiper and washer controls 12V DC Power outlet “POWER” Park button Clock Electronic shift lever “AUDIO” switch (Multi-information display control) Ignition key (key fob) slot “CLIMATE”...
Page 397 OVERVIEW Electric power steering system Instrument cluster warning Smart Key system warning Turn signal indicator Headlight high beam indicator Headlight indicator Service indicators and reminder Speedometer Tail light indicator Fuel gauge Odometer and two trip meters Slip indicator Automatic headlight leveling system warning Indicator symbols Cruise control indicator Brake system warning...
Page 398 OVERVIEW Fuel tank door opener and cap Hood release Driver seat Pull Pull up Turn Store Pull up latch and raise hood NOTE: Tighten until one click is heard. If the cap is Engine maintenance not tightened enough, Check Engine “ ”...
Page 399 * can be programmed to operate Right turn garage doors, estate gates, security lighting, etc. Lane change Refer to the Owner’s Manual for more details. For programming assistance, contact the Toyota Customer Experience Center at 1-800-331-4331, or Lane change visit http://www.homelink.com Left turn ®...
Page 400 FEATURES/OPERATIONS Seat adjustments-Front Tilt steering wheel Angle Lock release lever Hold wheel, push lever down, set angle and return lever. Note: Do not attempt to adjust while the vehicle Position Seatback angle is in motion. Seats-Head restraints Windows Rear Front Driver side Down Window lock...
Page 401: Switches
FEATURES/OPERATIONS Air Conditioning/Heating Steering wheel switches Type 1 functions Auto A/C ON/OFF Temperature selector Air intake selector Windshield vent Rear window and outside rear view mirror Type 2 functions defogger Cruise control Turning system ON/OFF System ON/OFF With navigation system Setting a speed Resume /Increase speed...
Page 402 FEATURES/OPERATIONS Audio operation screen Audio Audio Type 1 functions operation screen Audio Push RADIO To preset a station Tune in the desired station and touch a station selector icon (1-6) until you hear a beep. Push to turn Eject CD To scan for stations Push “SCAN.”...
Page 403 FEATURES/OPERATIONS AUX audio jack (if equipped) Cup and bottle holders Cup holder-Front Cup holder-Rear Center console Bottle holder Front door Refer to the Owner’s Manual for more details. Clock Power outlets H-Hour set Instrument panel (12V) Center console box (12V) M-Minute set Luggage storage box Unlock...
Page 404: Emergency Features
SAFETY AND EMERGENCY FEATURES Door locks Emergency flashers Lock Unlock Push Doors-Child safety locks Rear air vent Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Note: The air vent on the right side of the rear Seat belts seatback is designed to assist in cooling the Hybrid vehicle battery.
Page 405 SAFETY AND EMERGENCY FEATURES Jump starting Jump start terminal Exclusive jump starting terminal cover The jump start terminal is in the fuse box. To access the terminal, open the fuse block cover and the jump start terminal cover. Connecting jumper cables Recommended connecting point Connect positive (red) jumper cable to the jump...
Page 406 SECTION VEHICLE MAINTENANCE AND CARE Vehicle maintenance and care Maintenance requirements ........General maintenance .
Page 407 See “Owner’s War- form them are presented in Section 8. or if you prefer, your Toyota dealer will be ranty Information Booklet” or “Owner’s pleased to do them at a nominal cost.
Page 408 Information Booklet” or “Owner’s Manual should investigate the cause or take your mation. Supplement” for the details. vehicle to your Toyota dealer or a quali- Radiator, condenser and hoses fied service shop immediately. It is recom- Check that the front of the radiator and...
Page 409 INSIDE THE VEHICLE Seat belts OUTSIDE THE VEHICLE Check that the seat belt system such as Items listed below should be checked Items listed below should be performed buckles, retractors and anchors operate regularly, e.g. while performing periodic from time to time, unless otherwise properly and smoothly.
Page 410 Be on the alert for changes in perfor- If you notice any of these clues, take your mance, sounds, and visual tip−offs that vehicle to your Toyota dealer as soon as Check the tires carefully for cuts, indicate service is needed. Some impor- possible.
Page 411 Toyota dealer comes on. In this case, your vehicle may to prepare the vehicle for re−testing. not pass the I/M test and need to be repaired.
Page 412 SECTION – DO−IT−YOURSELF MAINTENANCE Introduction Engine compartment overview ....... Fuse locations .
Page 413: Engine Compartment Overview
Engine compartment overview 1. Windshield washer fluid tank 2. Brake fluid reservoir 3. Engine oil filler cap 4. Engine coolant reservoir 5. Inverter coolant reservoir 6. Fuse block 7. Radiator and condenser 8. Engine oil level dipstick 9. 12 volt battery (in luggage compartment) 81p001g...
Page 414: Fuse Locations
Fuse locations 81p006c 81p003b 81p002c 81p005b...
Page 415: Do−It−Yourself Service Precautions
Read separate compartment—the engine, radiator, just the body jack supporting it. Al- Toyota Warranty statement for details and ways use automotive jack stands or exhaust manifold and spark plug suggestions. boots, etc.—will be hot. So be care- other solid supports.
Page 416 Call your dealer z Add only “Toyota Super Long Life water to prevent it damage to parts for information concerning recycling Coolant” or similar high quality eth- or paint.
Page 417: Positioning The Jack
Positioning the jack When jacking up your vehicle with the Do not raise the vehicle with some- jack, position jack correctly as one in the vehicle. shown in the illustrations. When raising the vehicle, do not CAUTION place any objects on top of or un- derneath the jack.
Page 418: Parts And Tools
CHECKING BRAKE FLUID Tools: need to perform do−it−yourself mainte- Parts (if level is low): Funnel nance. Remember all Toyota parts are de- SAE J1703 or FMVSS No.116 DOT 3 REPLACING LIGHT BULBS signed in metric sizes, so your tools must brake fluid be metric.
Page 420 SECTION – DO−IT−YOURSELF MAINTENANCE Engine and Chassis Checking the engine oil level ....... . . Checking the coolant level .
Page 421: Checking The Engine Oil Level
Checking the engine oil level 3. Reinsert the dipstick—push it in as far If the oil level is below or only slightly as it will go, or the reading will not be above the low level, add engine oil of Low level Full level correct.
Page 422 If SAE 5W−30 oil is not available, SAE NOTICE 10W−30 oil may be used. However, it “Toyota Genuine Motor Oil” is used in should be replaced with SAE 5W−30 at z Be careful not to spill engine oil on your Toyota vehicle. Use Toyota approved the next oil change.
Page 423: Checking The Coolant Level
Mark is added to some oil con- Toyota engines. tainers to help you select the oil you Please contact your Toyota dealer for fur- should use. ther details about “Toyota Genuine Motor Oil”.
Page 424 If you can find no leak, have your Toyota Canada—“Toyota Super Long Life CAUTION dealer test the cap pressure and check Coolant” is a mixture of 55% coolant and for leaks in the cooling system. 45% deionized water. This coolant pro- The coolant heat storage tank reaches vides protection down to about −42_C...
Page 425: Checking The Radiator And Condenser
Checking brake fluid If either of the above parts is extremely dirty or you are not sure of their condi- tion, take your vehicle to a Toyota dealer. CAUTION 82p002b To prevent burning yourself, be care- ful not to touch the radiator or con- denser when the engine is hot.
Page 426: Checking Tire Inflation Pressure
Toyota dealer as soon as possible. Do at the proper level. not drive if the red brake system warn- The recommended cold tire inflation ing light is on. Call a Toyota dealer for pressures, tire sizes and the com- assistance. bined weight of occupants and cargo...
Page 427 In case of applying too much air, press the center of the valve If a tire frequently needs refilling, have it checked by your Toyota deal- and release the air to adjust.
Page 428: Checking And Replacing Tires
Checking and replacing tires CAUTION High tire pressure (overinfla- Tread wear indicator tion)— Keep your tires properly inflated. D Poor handling Otherwise, the following condi- D Excessive wear tions may occur and cause an ac- D Uneven wear cident resulting in death or seri- ous injuries.
Page 429 The tires on your Toyota have built−in If air loss occurs while driving, do not REPLACING YOUR TIRES tread wear indicators to help you continue driving. Driving even a short When replacing a tire, use a tire of know when the tires need replace-...
Page 430: Rotating Tires
D Do not use tires other than the To equalize tire wear and help ex- manufacturer’s recommended tend tire life, Toyota recommends size, as this may cause danger- that you rotate your tires accord- ous handling characteristics ing to the maintenance schedule.
Page 431: Installing Snow Tires And Chains
Installing snow tires and chains When rotating tires, check for uneven WHEN SNOW TIRES SNOW TIRE INSTALLATION CHAINS wear and damage. Abnormal wear is Snow tires should be installed on all usually caused by incorrect tire infla- Snow tires or chains are recommended wheels.
Page 432: Replacing Wheels
Correct replacement wheels are available fully follow the instructions of the chain avoid losing control of the vehicle. at your Toyota dealer. manufacturer. Otherwise an accident may occur. A wheel of a different size or type may If wheel covers are used, they will be...
Page 433: Aluminum Wheel Precautions
When balancing your wheels, use only Toyota balance weights or equivalent and a plastic or rubber hammer. As with any wheel, periodically check your aluminum wheels for damage. If damaged, replace immediately.
Page 434 SECTION – DO−IT−YOURSELF MAINTENANCE Electrical components Checking 12 volt battery condition ......12 volt battery recharging precautions .
Page 435: Checking 12 Volt Battery Condition
Checking 12 volt battery condition— —Checking 12 volt battery —Precautions exterior CAUTION EMERGENCY MEASURES If electrolyte gets in your eyes, 12 VOLT BATTERY PRECAUTIONS flush your eyes with clean water and get immediate medical atten- When the 12 volt battery must be re- placed, use the Prius designated bat- tion.
Page 436 After you reconnect the 12 volt battery, Hold−down clamp Ground cable NOTICE shift the shift lever to “N” and confirm the shift position is “N” when the “IG−ON” z Be sure the hybrid system and all mode is enabled. accessories are off before perform- ing maintenance.
Page 437: Volt Battery Recharging Precautions
12 volt battery recharging Checking and replacing fuses precautions During recharging, the battery is pro- NOTICE ducing hydrogen gas. Type A Never recharge the battery with the Therefore, before recharging: hybrid system on. Also, be sure all 1. If recharging with the battery installed accessories are turned off.
Page 438 The location of the pull−out there is a problem with the electrical sys- tool is shown in the illustration. tem. Have your Toyota dealer correct it as soon as possible. If you are not sure whether the fuse has...
Page 439: Adding Washer Fluid
LEDs burn out, take your vehicle to or death by electric shock. and most auto parts stores. Follow the your Toyota dealer to have the light re- manufacturer’s directions for how much to placed. Do not attempt to take apart or re- mix with water.
Page 440 Front turn signal — pooled inside light, contact your lights Toyota dealer. Rear turn signal lights — Tail lights — Stop lights — High mounted stop- — light Back−up lights...
Page 441 —Headlights 83p030a 83p031 83p010a Removing clip 1. Open the hood. Remove the clips 2. RIGHT−HAND HEADLIGHT ONLY: Re- and take out the cover. move the clip and take out the air cleaner inlet. Remove and install the clips as shown in the following illustrations.
Page 442 83p011 83p013a 83p014a Removing clip 3. Unplug the connector. Turn the bulb 4. Release the bulb retaining spring cover counter−clockwise and remove and remove the bulb along with the socket. Install a new bulb into the socket and return the bulb retaining If the connector is tight, wiggle it.
Page 443 —Front fog lights —Parking lights If either the left or right front fog lights burns out, contact your Toyota dealer. NOTICE Do not try to replace the front fog 83p015b 83p016a light bulbs by yourself. You may dam- age the vehicle.
Page 444 —Rear turn signal, tail and —Front turn signal lights back−up lights 83p018a 83p023a 83p025c a: Rear turn signal light b: Back−up light c: Tail light 83p019b 83p024b...
Page 445 —License plate lights 83p026b 83p028b Remove the cover. 83p027a...
Page 446 SECTION SPECIFICATIONS Specifications Dimensions and weight ........Electric motor .
Page 447: Dimensions And Weight
Dimensions and weight Engine Electric motor Overall length mm (in.) 4445 (175.0) Type: Permanent magnet synchronous Model: 1.5 L 4−cylinder (1NZ−FXE) motor (water cooling) Overall width mm (in.) 1725 (67.9) Type: 4−cylinder in line, 4 cycle, gasoline Maximum output:/rpm: Overall height mm (in.) 1490 (58.7)*...
Page 448: Fuel
Fuel Hybrid battery Service specifications Fuel type: Type: Nickel−Metal hydride battery ENGINE Unleaded gasoline, Octane Rating 87 Voltage: 7.2 V Valve clearance (engine cold), mm (in.): (Research Octane Number 91) or Intake 0.17 − 0.23 (0.007 − 0.009) Capacity: 6.5 Ah (3HR) higher Exhaust 0.27 −...
Page 449 Without filter 3.4 (3.6, 3.0) converter 2.7 (2.9, 2.4) “Toyota Genuine Motor Oil” is used in your Coolant type: Toyota vehicle. Use Toyota approved “Toyota “Toyota Super Long Life Coolant” is Genuine Motor Oil” or equivalent to satisfy the...
Page 450 L (qt., Imp.qt.): SAE J1703 or FMVSS No. 116 DOT 3 3.6 (3.8, 3.2) STEERING Fluid type: Wheel free play: “Toyota Genuine ATF WS” or Less than 30 mm (1.2 in.) equivalent Please contact your Toyota dealer for further details.
Page 451: Tires
Tires Tire size and inflation pressure: Standard Cold tire inflation pressure kPa (kgf/cm or bar, psi) Tire size Wheel size Front Rear P185/65R15 86S 6 JJ 240 (2.4, 35) 230 (2.3, 33) P195/55R16 86V 6 JJ Spare Cold tire inflation pressure Tire size Wheel size kPa (kgf/cm...
Page 452: Fuses
Fuses 90p007b 90p005b 90p008b Instrument panel Engine compartment Luggage compartment 1. PWR 30 A: Power windows 8. GAUGE 10 A: Gauge and meter, back− 15. TAIL 10 A: Tail lights, license plates up lights, emergency flasher, power light, parking lights 2.
Page 453 22. IGN 7.5 A: Hybrid system, hybrid ve- 35. ABS−1 25 A: Anti−lock brake system hicle immobilizer system, SRS airbags 36. ETCS 10 A: Electronic throttle control 23. SPARE 30 A: Spare system 24. SPARE 15 A: Spare 37. BATT FAN 10 A: Battery cooling fan 25.
Page 454 SECTION REPORTING SAFETY DEFECTS FOR U.S. OWNERS Reporting safety defects for U.S. owners Reporting safety defects for U.S. owners ..... .
Page 455 However, NHTSA cannot become involved in individual prob- lems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc.
Page 456 U −7 Quick index D If a service reminder indicator or warning buzzer comes on . . . D If your vehicle will not start ........D If your vehicle overheats .
Page 457: Important Information About This Manual
Important information about this manual Safety and vehicle damage Safety symbol NOTICE warnings This is a warning against anything which may cause damage to the Throughout this manual, you will see safe- vehicle equipment ty and vehicle damage warnings. You warning is ignored.
Page 458 Important information about your Toyota...
Page 459 Toyota encourages you and your None of these systems, either in- family to take the time to read dividually or together, can ensure Section 2−2 of this Owner’s Manu-...
Page 461: Event Data Recorder
D Engine speed Toyota recommends you to read D Whether the brake pedal was the provisions in Section 2−2 care- applied or not fully and refer to them as needed...
Page 463 There are a variety of driving situ- lice or other authorities ations which include activating the VSC under which the VSC EDR D Used as a defence for Toyota in a law suit will record certain information. The VSC EDR may record some or all...
Page 464 New vehicle warranty Your responsibility for Important health and maintenance safety Your new vehicle is covered by the following Toyota limited war- information about your It is the owner’s responsibility to ranties: make sure the specified mainte- Toyota D New vehicle warranty nance performed.
Page 465 CAUTION WARNING: Engine exhaust, some of its constitu- ents, and a wide variety of automobile compo- nents contain or emit chemicals known to the State of California to cause cancer and birth de- fects and other reproductive harm. In addition, oils, fuels and fluids contained in vehicles as well as waste produced by component wear contain or emit chemicals known to the State of California...
Page 467 Toyota vehicles are currently avail- able in the market. You should Installation of a mobile know that Toyota does not warrant these products and is not respon- two−way radio system sible for their performance, repair,...
Page 468 For details, see “Keys” on of by the qualified service shop or Manual. For details about tire page 20 and “Smart entry and by your Toyota dealer before you inflation pressure and load lim- start system” on page 24. dispose of your vehicle.
Page 469 CAUTION When your vehicle or bat- tery needs to be disposed of, be sure to consult your Toyota dealer. Hybrid bat- teries must be collected through Toyota dealers. If your vehicle is disposed without dismantling, someone could receive an electric shock by touching the high voltage parts of the hybrid battery.
Page 470 Hybrid battery Perchlorate Material The hybrid battery has a limited service life. Call your Toyota deal- Special handling may apply, er for information about recycling www.dtsc.ca.gov/hazardou- or disposal of hybrid battery and swaste/perchlorate. your vehicle. Your vehicle has components that contain perchlorate.
Page 471 CAUTION...
Page 472 Toyota dealer. If a vehicle fire occurs, extin- guish it using a fire extin- guisher for the exclusive use on electric fires. Or, use a...
Page 473 If your vehicle needs to be towed, do it with the front wheels raised. For details on towing, see “If your vehicle needs to be towed” on page 376.
Page 474 CAUTION High Voltage Your vehicle is equipped with cables connected parts of the vehicle subject to high volt- age (about 500 V at maximum). There are some other parts that reach high temperatures while you drive. Never touch battery cables (wrapped in orange−col- ored harnesses) or their con- nectors since they are under...

Toyota 2007 Prius Owner's Manual

Table of Contents

1 2 Section -

2 1 Section -

2 2 Section -

2 3 Section -

2 4 Section -

2 5 Section -

2 7 Section -

2 8 Section -

2 9 Section -

2 10 Section -

3 Section

4 Section

8 1 Section -

8 2 Section -

Quick Links

Chapters

Related Manuals for Toyota 2007 Prius

Summary of Contents for Toyota 2007 Prius

Table of Contents
