Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Instrument cluster Reading this manual ....14 How to search......15 Pictorial index ......16 Instrument cluster Combination meter ....98 For safety and security Warning lights and indicators ......107 Main display....... 115 1-1.
Page 3 278 Inside rear view mirror..210 4-5. Using the driving support systems Outside rear view mirrors......212 Toyota Safety Sense P..283 3-5. Opening and closing the PCS (Pre-Collision windows and moon roof System) ......291 Power windows ....214...
Page 4 TABLE OF CONTENTS 5-5. Playing an audio CD and Audio system MP3/WMA/AAC discs CD player operation ..454 5-6. Using an external device 5-1. Basic Operations iPod player operation ..460 Audio system types ..434 USB memory device Audio system ....435 player operation ....
Page 5 ® 5-9. Bluetooth phone Interior features ® Using a Bluetooth Phone ......484 Making a call..... 487 6-1. Using the air conditioning Receiving a call ....490 system and defogger Speaking on the phone..491 Automatic air conditioning ® system (vehicles without Bluetooth phone 11.6-inch display) ....
Page 6 TABLE OF CONTENTS 6-4. Using the other interior 7-3. Do-it-yourself features maintenance Other interior features ..563 Do-it-yourself service • Sun visors ..... 563 precautions...... 602 • Vanity mirrors....563 Hood ........605 • Power outlets ....564 Positioning a floor jack..607 •...
Page 7 8-2. Steps to take in an Vehicle specifications emergency If your vehicle needs to be towed ......674 9-1. Specifications If you think something is Maintenance data wrong ......681 (fuel, oil level, etc.) ..754 If a warning light turns on Fuel information....
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 10 Usage of data collected through Toyota Enform (U.S.mainland only) If your Toyota has Toyota Enform and if you have subscribed to those ser- vices, please refer to the Toyota Enform Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13 PRIUS_OM_OM47C35U_(U)
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 812 Searching installation ■ position • Pictorial index....P. 16 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 808 Searching by title ■ • Table of contents .....P. 2 PRIUS_OM_OM47C35U_(U)
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior The shape of the headlights may differ depending on the grade, etc. (P. 658) Side doors ........P. 181 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ....... . . P. 270 Precautions against winter season ..... P. 427 Precautions against car wash (vehicles with rain-sensing windshield wipers) .
Page 18 Pictorial index ■ Instrument panel Power switch ........P. 241 Starting the hybrid system/changing the modes .
Page 19 Pictorial index Multi-information display ......P. 122 Display ......... . . P. 122 Energy monitor .
Page 20 Pictorial index ■ Switches Instrument cluster light control switch ....P. 100 S-APGS (Simple Advanced Parking Guidance System) switch ......... P. 376 VSC OFF switch .
Page 21 Pictorial index TRIP switch........P. 117 Audio remote control switches .
Page 22 Pictorial index ■ Interior SRS airbags ........P. 36 Floor mats .
Page 23 Pictorial index Inside rear view mirror ......P. 210 Sun visors ........P. 563 Vanity mirrors.
Page 24 Pictorial index PRIUS_OM_OM47C35U_(U)
Page 25: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 26 For safe driving ....28 Seat belts ......30 SRS airbags......36 Front passenger occupant classification system ..50 Exhaust gas precautions..55 1-2. Child safety Riding with children..... 56 Child restraint systems..
Page 26: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 28: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 29 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ●...
Page 30: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 31 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 32 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 33 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 34 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 35 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 36: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. PRIUS_OM_OM47C35U_(U)
Page 37 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS knee airbag Can help provide driver protection SRS seat cushion airbag Can help restrain the front passenger ◆...
Page 38 1-1. For safe use SRS airbag system components Front impact sensors Front passenger’s seat belt buckle switch SRS warning light and “AIR BAG ON” and “AIR BAG OFF” Curtain shield airbags indicator lights Side impact sensors (rear) Front passenger airbag Driver’s seat belt...
Page 39 1-1. For safe use WARNING ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 42 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 43 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 44 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 45 1-1. For safe use ■ SRS airbag deployment conditions (SRS side and curtain shield airbags) ● The SRS side and curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 3300 lb.
Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 47 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 48 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 49 1-1. For safe use ● The surface of the seats with the SRS side airbag is scratched, cracked, or oth- erwise damaged. ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the SRS curtain shield air- bags inside is scratched, cracked, or otherwise damaged.
Page 50: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag and seat cushion airbag in the front passenger side. U.S.A.
Page 51 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Activated Devices...
Page 52 1-1. For safe use Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ warning light SRS warning light Seat belt reminder light Front passenger airbag Deactivated Devices Seat cushion airbag in the front passenger Deactivated side There is a malfunction in the system...
Page 53 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 54 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 55: Exhaust Gas Precautions
The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 56: 1-2. Child Safety
1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats to avoid acci- dental contact with the shift lever, wiper switch etc.
Page 57: Child Restraint Systems
1-2. Child safety Child restraint systems Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual. ● Use a child restraint system when riding with a small child that cannot properly use a seat belt.
Page 58 1-2. Child safety Points to remember The laws of all 50 states of the U.S.A. as well as Canada now require the use of child restraint systems. ● Prioritize and observe the warnings, as well as the laws and regula- tions for child restraint systems.
Page 59 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 60 1-2. Child safety Child restraint system Types of child restraint system installation methods ■ Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt P. 64 attachment Child restraint...
Page 61 1-2. Child safety When using a child restraint system When installing a child restraint system to a front passenger ■ seat For the safety of a child, install a child restraint system to a rear seat. When installing child restraint system to the front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Page 62 1-2. Child safety WARNING ■ When using a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 63 1-2. Child safety WARNING ■ When using a child restraint system ● Use a child restraint system suitable to the age and size of the child and install it to the rear seat. ● If the driver’s seat interferes with the child restraint system and prevents it from being attached correctly, attach the child restraint system to the right-hand...
Page 64 1-2. Child safety Child restraint system fixed with a seat belt A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. ◆ Installing child restraint system using a seat belt (child restraint lock function belt) Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Page 65 1-2. Child safety While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 66 1-2. Child safety Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 67 1-2. Child safety Booster seat ■ If installing the child restraint system to the front passenger seat is unavoidable, refer to P. 61 for front passenger seat adjustment. High back type: If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint.
Page 68 1-2. Child safety ◆ Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. When releasing the buckle, the child restraint system spring up due to the rebound of the seat cushion.
Page 69 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious inju- ries that could result in death.
Page 70 1-2. Child safety Child restraint system fixed with a child restraint LATCH anchor Child restraint LATCH anchors ■ LATCH anchors are provided for the rear outboard seats. (Buttons displaying the location of the anchors are attached to the seats.) When installing in the rear outboard seats ■...
Page 71 1-2. Child safety With flexible lower attachments  Latch the hooks of the lower straps onto LATCH anchors. For owners in Canada: symbol child restraint system indicates the presence of a lower connec- tor system. Canada only With rigid lower attachments ...
Page 72 1-2. Child safety If the child restraint has a top tether strap, follow the child restraint manufacturer’s operation manual regarding the installa- tion, using the top tether strap to latch onto the top tether strap anchor. (P. 73) After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
Page 73 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● When using the LATCH anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system.
Page 74 1-2. Child safety Fixing the top tether strap to the anchor bracket ■ Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. Rear outboard seats  Remove the head restraint. (P. 206) Latch the hook onto the Top tether strap anchor bracket and tighten...
Page 75 1-2. Child safety Rear center seat  Adjust the head restraint to the upmost position. If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove head restraint. (P. 206) Latch the hook onto the Top tether strap anchor bracket and tighten the top tether strap.
Page 76 1-2. Child safety ■ Laws and regulations pertaining to anchors The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to SAE J1819. WARNING ■...
Page 77: Emergency Assistance
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada.
Page 78 A variety of subscription terms are available for purchase. Contact your Toyota dealer, call the following appropriate Safety Connect response center or push the “SOS” button in your vehicle for further subscription details.
Page 79 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models (in the contiguous United States only). Contact with the Safety Connect response center is dependent upon the telematics device being in operative...
Page 80 Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Emergency Assistance Button (“SOS”) ■...
Page 81 For a description of the Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Toyota.com in the United States, Toyotapr.com in Puerto Rico and Toyota.ca in Canada. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 82 1-3. Emergency assistance ■ Certification for the Safety Connect PRIUS_OM_OM47C35U_(U)
Page 83: Hybrid System
1-4. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving condi- tions, improving fuel efficiency and reducing exhaust emis- sions.
Page 84 1-4. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 85 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to start the hybrid system, contact your Toyota dealer. ■ Charging the 12-volt battery P.
Page 86 ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS_OM_OM47C35U_(U)
Page 87: Hybrid System Precautions
1-4. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high volt- age system (about 600 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 88 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 89 If a warning light comes on, a warning message is displayed, or the 12-volt battery is disconnected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 90 1-4. Hybrid system WARNING ■ High voltage precautions This vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
Page 91 1-4. Hybrid system WARNING ■ Road accident cautions Observe the following precautions to reduce the risk of death or serious injury: ● Pull your vehicle off the road, apply the parking brake, shift the shift posi- tion to P, and turn the hybrid system off. ●...
Page 92 Toyota dealer or a qualified service shop. If the hybrid battery is not dis- posed of properly, it may cause electric shock that can result in death or serious injury.
Page 93 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer. ● There is a filter installed to the air intake vent. When the filter remains noticeably dirty even after cleaning the air intake vent, filter cleaning or replacement is recommended.
Page 94: 1-5. Theft Deterrent System
1-5. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 95 1-5. Theft deterrent system ■ Certification for the immobilizer system For vehicles sold in the U.S.A., Hawaii, American Samoa, Guam, Saipan  and Puerto Rico For vehicles sold in Canada  NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 96 1-5. Theft deterrent system PRIUS_OM_OM47C35U_(U)
Page 97 Instrument cluster Instrument cluster Combination meter....98 Warning lights and indicators ......107 Main display ...... 115 Multi-information display......122 Head-up display ....155 Energy monitor/ consumption screen (vehicles without 11.6-inch display).... 162 Energy monitor/ consumption screen (vehicles with 11.6-inch display).... 169 PRIUS_OM_OM47C35U_(U)
Page 98: Combination Meter
2. Instrument cluster Combination meter The large meter uses 2 liquid crystal displays to display informa- tion such as the vehicle condition, driving status and fuel con- sumption. Combination meter layout The units used on the display may differ depending on the target region. Main display (P.
Page 99 2. Instrument cluster Operations related to the combination meter The meter control switches equipped on the steering wheel can be used to switch the screen display and change settings related to func- tions displayed on the screen. Each time button pressed, the mileage display switches among odometer, trip meters, etc., and the fuel con-...
Page 100 2. Instrument cluster Instrument cluster light control When the switches are pressed, the instrument cluster light changes as follows. The instrument cluster brightness levels that can be selected differ depending on whether the tail lights are on and surrounding brightness lev- els.
Page 101 2. Instrument cluster Information automatically displayed Some information will be displayed automatically according to power switch operation, vehicle condition, etc. When starting the hybrid system ■ When the hybrid system starts, an opening animation is dis- played on the 2 displays. After the animation ends, the screens switch to the normal screen.
Page 102 2. Instrument cluster When there is information to be notified about the vehicle ■ When a shift position is mistakenly selected or a problem occurs in a vehicle system, a warning message (or image) is displayed on the multi-information display. When a warning message is displayed, follow the instructions displayed on the display.
Page 103 2. Instrument cluster Clock adjustment To adjust the time, perform operations on the screen (P. 149) of the multi-information display. Adjusting the time ■ Press of the meter control switches on the steering wheel and select Press of the meter control switches and select Press to display the cursor.
Page 104 2. Instrument cluster Resetting the minutes display ■ Press of the meter control switches on the steering wheel and select Press of the meter control switches and select Press The minutes display switches to “00”. : e.g. 1:00 to 1:29  1:00 1:30 to 1:59 ...
Page 105 2. Instrument cluster ■ When disconnecting and reconnecting 12-volt battery terminals The settings of the clock will be reset. ■ Calendar settings If calendar recording is interrupted due to replacement of the 12-volt battery or 12- volt battery discharge, etc., when the power switch is turned to ON mode after maintenance, the calendar settings check screen is automatically displayed on the...
Page 106 2. Instrument cluster WARNING ■ To prevent an accident Do not place anything or attach a sticker in front of the instrument cluster. The item may obscure or obstruct the display, or could reflect off the display, possibly causing an accident. ■...
Page 107: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration dis- plays all indicators and warning lights illuminated. PRIUS_OM_OM47C35U_(U)
Page 108 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in any of the vehicle’s systems. Warning lights Pages Brake system warning light (U.S.A.) P. 682 Brake system warning light (Canada) P. 682 (Red) Brake system warning light P.
Page 109 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes or illuminates to indicate a malfunction.
Page 110 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Indicators Pages Turn signal indicator P. 256 Headlight indicator (U.S.A.) P. 258 Tail light indicator (Canada) P. 260 Parking brake indicator (U.S.A.) P.
Page 111 2. Instrument cluster Indicators Pages Dynamic radar cruise control indicator (if P. 314 equipped) P. 314, Cruise control “SET” indicator P. 260, AFS OFF indicator (if equipped) 1, 3 PCS warning light (if equipped) P. 295 LDA indicator (if equipped) P.
Page 112 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 113 2. Instrument cluster Indicators and symbols displayed on the display Main display and multi-information display ■ Indicators Pages EV drive mode indicator P. 247 “ECO MODE” indicator P. 335 “PWR MODE” indicator P. 335 EV Indicator P. 128 : The displayed indicator changes according to the current driving mode. Multi-information display (symbol display ■...
Page 114 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 115: Main Display
2. Instrument cluster Main display The main display shows basic information, such as the vehicle speed and remaining fuel amount. Also, the displayed informa- tion can be switched according to user preference. Display contents Simple screen Split screen : Refer to P. 119 for details on how to change the screen display. The units used on the display may differ depending on the target region.
Page 116 2. Instrument cluster Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Outside temperature Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C). The temperature display flashes for approximately 10 seconds when the outside temperature drops to approximately 37F (3C) or less, and then stops flashing.
Page 117 2. Instrument cluster Switching the mileage display and average fuel consumption display Each time is pressed, the mileage display and fuel consumption display change in the following order from 1 to 6. Mileage display Average fuel consumption dis- play After 1 to 6 are displayed, the dis- plays return to 1.
Page 118 2. Instrument cluster Mileage display Average fuel consumption display Average fuel consumption since ODO (Odometer) last reset Total mileage Average fuel consumption since last reset TRIP A average fuel consumption TRIP A (Trip meter A) Average fuel consumption since Mileage since last reset TRIP A was reset TRIP B average fuel consumption TRIP B (Trip meter B)
Page 119 2. Instrument cluster Switching the display mode Simple screen or split screen can be selected for the main display. When split screen is selected, a variety of information can be displayed on a sub-screen in addition to the contents of the simple screen. Setting procedure ■...
Page 120 2. Instrument cluster Switching contents displayed on the sub-screen ■ Press of the meter control switches and select the sub-screen. When the sub-screen is selected, is displayed on the sub- screen. Press of the meter control switches to select the dis- play item.
Page 121 • When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) ● When “-” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Distance to empty ●...
Page 122: Multi-Information Display
2. Instrument cluster Multi-information display A variety of information related to the vehicle can be displayed, including the operation status of each system and data related to Eco driving, and the settings of each system can be changed according to user preference. Display contents Information related to each icon on the upper portion of the multi-...
Page 123 2. Instrument cluster Menu icons Contents Pages Drive information The energy monitor that shows the operation P. 124 status of the hybrid system, or other informa- tion such as fuel consumption is displayed. Clock setting display P. 142 The clock settings can be changed. Navigation system-linked display The information related to the navigation sys- P.
Page 124 2. Instrument cluster Basic Operations Press of the meter control switches and select the icon of the desired item. The selected icon is highlighted and the display switches to the information screen. When split screen display is selected for the main display, the sub-screen of the main display can also be selected.
Page 125 2. Instrument cluster ◆ Energy monitor The energy monitor can be used to check the vehicle drive status, hybrid system operation status and energy regeneration status. When energy is flowing, an arrow appears and a bright point of light moves to show the direction of the flow of energy. When energy is not flowing, the bright point of light are not displayed.
Page 126 2. Instrument cluster ■ Hybrid battery (traction battery) status ● The display changes in 8 levels according to the remaining charge amount of the hybrid battery (traction battery). High ● The hybrid battery (traction battery) status is also displayed on the following screen, but the contents of the display are the same.
Page 127 2. Instrument cluster ◆ Hybrid System Indicator The display changes according to accelerator pedal operation and displays the current driving status and energy regeneration status. The Hybrid System Indicator can be displayed on the sub-screen of the main display (P. 120) and the head-up display (if equipped) (P.
Page 128 2. Instrument cluster 2, 3 EV indicator The EV indicator comes on when the vehicle is driven using only the electric motor (traction motor) or the gasoline engine is stopped. Hybrid battery (traction battery) status P. 126 Eco score P. 129 ●...
Page 129 2. Instrument cluster Eco score ■ The driving status for the following 3 situations are evaluated in 5 levels: Smooth start-off acceleration (“Eco-Start”), driving without sudden acceleration (“Eco-Cruise”) and smooth stopping (“Eco- Stop”). Each time the vehicle is stopped, a score result is displayed out of a perfect score of 100 points.
Page 130 2. Instrument cluster ■ When operation of each function stops ● The Hybrid System Indicator stops operating in the following situations. • The “READY” indicator is not illuminated. • The shift position is not D or B. ● The Eco score and “ECO Accelerator Guidance” stop operating in the fol- lowing situations.
Page 131 2. Instrument cluster ◆ “Fuel Consumption Record” The transitions of the average fuel consumption after the hybrid system starts can be checked in such a unit as every 5 minutes or every 1 mile (1.6 km) or 1 km (0.6 mile) of driving.
Page 132 2. Instrument cluster Types of “Fuel Consumption Record” ■ When the unit is set to “MPH”  Tab display Recorded contents Recorded range Average fuel consumption “5 min” The past 30 minutes of every 5 minutes Average fuel consumption The last 15 miles (24.1 km) “1 miles”...
Page 133 2. Instrument cluster When the unit is set to “km/h”  Tab display Recorded contents Recorded range Average fuel consumption “5 min” The past 30 minutes of every 5 minutes Average fuel consumption The last 15 km (9.3 miles) “1 km” of every 1 km (0.6 mile) driven driven...
Page 134 2. Instrument cluster Switching the fuel consumption history screen ■ While the “Fuel Consumption Record” screen is displayed, press The tab display is selected and it is possible to switch the contents of the display. Press of the meter control switches to switch the con- tents of the display.
Page 135 2. Instrument cluster ◆ “Drive Monitor” Displays information such as the driving time and average vehicle speed, which are linked with the current mileage display. (P. 117) Current contents of the dis- play Displayed information shows which driving record the cur- rently displayed contents are based on.
Page 136 2. Instrument cluster ◆ “Eco Savings” “Gasoline Price” and “COMP. Consumption” information is regis- tered in the “Meter Customize” settings (P. 151), making it possi- ble to display 2 types of information related to gasoline fuel consumption. “SAVINGS”  If information about the vehicle used to compare fuel consumption (“COMP.
Page 137 2. Instrument cluster How to read the display ■ “SAVINGS” display “FUEL COST” display Trip meter distance traveled Estimate of fuel consumption saved for displayed distance trav- eled Estimate of fuel expenses necessary to drive currently displayed distance Estimate of fuel expenses to drive currently displayed distance (your vehicle) Estimate of fuel expenses to drive currently displayed distance (comparison vehicle)
Page 138 2. Instrument cluster Checking monthly record ■ The display can be switched to “TRIP” or “Monthly” by pressing with the tab display selected, and then pressing of the meter control switches. Using the “Monthly” display, the monthly records for “SAVINGS” and “FUEL COST”...
Page 139 2. Instrument cluster ◆ “Eco-Diary” The distance traveled and average fuel consumption history can be displayed in a table according to day (“Daily”) or month (“Monthly”) units. How to read the display ■ “Daily” display “Monthly” display Record of the day/month Date/month of stored information Total distance traveled for the day/month Average fuel consumption of the day/month...
Page 140 2. Instrument cluster Checking history ■ When each screen is selected, past records from the following ranges can be displayed by pressing of the meter con- trol switches. Displayed screen Displayed information Stored information Up to 32 reports “Daily” (8 screens) 4 reports Up to 24 reports “Monthly”...
Page 141 2. Instrument cluster ◆ AWD display (for AWD vehicles only) Displays the drive status of each wheel in 6 steps from 0 to 5. Front-left wheel drive status Front-right wheel drive status Rear-left wheel drive status Rear-right wheel drive status How to read the drive status display: Drive status Not being driven...
Page 142 2. Instrument cluster Clock setting display clock settings changed. Item Setting result Adjusts the clock. (P. 103) Sets the minutes to “00”. (P. 104) PRIUS_OM_OM47C35U_(U)
Page 143 2. Instrument cluster Navigation system-linked display (if equipped) Displays a compass linked with the navigation system. Also, when the navigation system is perform- ing intersection guidance during destination guidance, the inter- section guidance is also displayed on the multi-information display. The illustration is only an example and may differ from the actual screen.
Page 144 2. Instrument cluster Air conditioning system settings screen The condition of the air conditioning system settings can be checked on the screen and the air conditioning system settings can be changed using the meter control switches. On the air conditioning settings screen, press of the meter con- trol switches to switch the contents of the display.
Page 145 2. Instrument cluster Item Settings Eco score P. 146 (A/C score) Temperature Changes according to operation of the meter control setting switches Outside air and recirculated air (Outside air mode) (Recirculated air mode) modes Fan speed 1 to 7 “CLIMATE “NORMAL”...
Page 146 2. Instrument cluster Eco score (A/C score) ■ The current air conditioning system usage status is evaluated in 5 levels to determine whether it is Eco-friendly. The evaluation changes according to the air conditioning system usage status. When the power switch is turned off, the current total driving score and advice related to using the air conditioning...
Page 147 2. Instrument cluster ■ Operating switches of the air conditioning system operation panel ● When conditioning system switches are operated to change the air conditioning settings while a screen other than the air conditioning system settings screen is displayed on the multi- information display, a pop-up display for the air conditioning settings contents is displayed.
Page 148 2. Instrument cluster Driving assist system information The operation status of driving support system such as the LDA (Lane Departure Alert with steer- ing control) (if equipped) and dynamic radar cruise control with full-speed range (if equipped) and warning information dis- played.
Page 149 2. Instrument cluster Settings display The operation contents of the driving support systems and settings related to the combination meter display can be changed. Driving support systems such as the PCS (Pre-Collision System) (if equipped) and Blind Spot Monitor (if equipped) is turned on and off by sim- ply pressing .
Page 150 2. Instrument cluster Settings table ■ Item Settings Setting result “On” Turns the LDA system steering control function on and off. (P. 313) “Off” “High” Switches the LDA system lane deviation sensitivity. (P. 313) “Standard” “On” Turns the PCS (Pre-Collision System) on and off.
Page 151 2. Instrument cluster “Meter Customize” settings ( ■ Item Settings Setting result “Simple” “Simple/Split Switches the display mode of Screen” the main display. (P. 119) “Split” “Yes” “Screen Turns the multi-information dis- OFF” play off. “No” “On” “ECO Acceler- Turns the “ECO Accelerator ator Guidance”...
Page 152 2. Instrument cluster Item Settings Setting result “English” (English) Switches the language dis- “Language” “Français” (French) played on the screen. “Español” (Spanish) Month/Day/Year Changes the date used to “Calendar” record fuel consumption data. Day/Month/Year “Gasoline Price” “Eco Savings” Registers data used to calcu- (P.
Page 153 2. Instrument cluster ■ Setting items ● “Meter Customize” and “Vehicle Settings” setting items are not selectable during driving and cannot be operated. Also, the settings screen is temporarily canceled in the following situations. • A warning message is displayed. •...
Page 154 2. Instrument cluster WARNING ■ Cautions while setting up the display As the hybrid system needs to be operating during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 155: Head-Up Display
2. Instrument cluster  Head-up display The head-up display can display the current vehicle speed and Hybrid System Indicator in front of the driver. Also, it can display various types of information to assist the driver. Operation switches and display contents The units used on the display may differ depending on the target region.
Page 156 2. Instrument cluster Insert display P. 158 ( This display inserts information from each driving support system accord- ing to driving conditions. Route guidance display (vehicles with navigation system) (P. 159) This display is automatically shown when the navigation system is per- forming route guidance.
Page 157 2. Instrument cluster Display position and brightness adjustment In order to improve the visibility of the head-up display, the display position and brightness can be adjusted. Displaying the adjustment screen on the multi-information display. When the head-up display is on: Select on the screen of the multi-information dis-...
Page 158 2. Instrument cluster Insert display Insert displays of the driving support systems ■ Insert displays are linked with the operation of the following sys- tems and used to show some of the information shown on the multi- information display on the head-up display. System Displayed information PCS (Pre-Collision System)
Page 159 2. Instrument cluster Route guidance display (vehicles with navigation system) When the navigation system route guidance is set, convenient route guidance is displayed. When approaching an intersec- tion, the shape of the intersection and the remaining distance to the intersection are displayed.
Page 160 2. Instrument cluster ■ Enabling/disabling of the head-up display When the head-up display is turned off with the “HUD” switch, it is not dis- played until the “HUD” switch is used to turn the head-up display on again. (Operation of the head-up display is not linked with the power switch.) ■...
Page 161 2. Instrument cluster WARNING ■ Before using the head-up display ● Check that the position and brightness of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
Page 162: Energy Monitor/Consumption Screen (Vehicles Without 11.6-Inch Display)
2. Instrument cluster Energy monitor/consumption screen (vehicles without 11.6-inch display) You can view the status of your vehicle on the multi-information display and the audio system screen : For navigation system or multimedia system ◆ Multi-information display P. 122 ◆ Audio system screen Display the energy monitor, trip information or past record screen.
Page 163 2. Instrument cluster Energy monitor If the “Trip Information” or “Past Record” screen is displayed, select “Energy”. 2WD models  Audio system screen When the vehicle is powered by electric motor (traction motor) When the vehicle is powered by both the gasoline engine and electric motor (traction...
Page 164 2. Instrument cluster Audio system screen When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions.
Page 165 2. Instrument cluster AWD models  Audio system screen When the vehicle is powered by electric motor (traction motor) When the vehicle is powered by both the gasoline engine and electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS_OM_OM47C35U_(U)
Page 166 2. Instrument cluster Audio system screen When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions.
Page 167 2. Instrument cluster Fuel consumption Trip information ■ If the “Trip Information” screen does not appear, select “Trip Infor- mation”. Reset the trip information data Previous fuel consumption per minute Current fuel consumption Regenerated energy in the past 15 minutes symbol indicates 30 Wh.
Page 168 2. Instrument cluster Past record ■ If the “Past Record” screen does not appear, select “Past Record”. Reset the past record data Best recorded fuel consump- tion Average fuel consumption (if equipped) Previous fuel consumption record Current fuel consumption Update the past record data “Energy Monitor”...
Page 169: Energy Monitor/Consumption Screen (Vehicles With 11.6-Inch Display)
2. Instrument cluster Energy monitor/consumption screen (vehicles with 11.6-inch display) You can view the status of your vehicle on the multi-information display and the audio system screen : For navigation system ◆ Multi-information display P. 122 ◆ Audio system screen Display the energy monitor, trip information or past record ■...
Page 170 2. Instrument cluster Display the power consumption of the air conditioner ■ Display “Energy Monitor” screen. Select on the upper right screen. When you select the “”, and close the screen. How to read the energy monitor Function summary ■ The energy monitor can be used to check the vehicle drive status, hybrid system operation status and energy regeneration status.
Page 171 2. Instrument cluster When the vehicle is powered by When the vehicle is powered by the both the gasoline engine and the electric motor (traction motor) electric motor (traction motor) When the vehicle is powered by the When there is no energy flow gasoline engine PRIUS_OM_OM47C35U_(U)
Page 172 2. Instrument cluster When the vehicle is charging the hybrid battery (traction battery) Hybrid battery (traction battery) sta- Air Conditioning System use Full : When the air conditioning compressor is not operating, an arrow does not appear and the bright point of light are not displayed. PRIUS_OM_OM47C35U_(U)
Page 173 2. Instrument cluster Fuel consumption Trip information ■ If the “Trip Information” screen does not appear, select “Trip Infor- mation”. Previous fuel consumption per minute Current fuel consumption Reset the trip information data Regenerated energy in the past 15 minutes symbol indicates 30 Up to 5 symbols are shown.
Page 174 2. Instrument cluster Past record ■ Best recorded fuel consump- tion Average fuel consumption Current fuel consumption Previous fuel consumption record Reset the past record data Update the past record data “Trip Information” screen appears The image is an example only, and may vary slightly from actual conditions.
Page 175: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........176 3-2. Opening, closing and locking the doors Side doors......181 Back door......187 Smart key system ..... 192 3-3. Adjusting the seats Front seats ......200 Rear seats......202 Head restraints....205 3-4.
Page 176: 3-1. Key Information
Wireless remote control Locks all the doors (P. 182) Unlocks all the doors (P. 182) Opens the side windows and moon roof (if equipped) (P. 182) Sounds the alarm (P. 177) : This setting must be customized at your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 177 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using another mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 178 You can replace the battery by yourself (P. 650). However, as there is a danger that the electronic key may be damaged, it is recommended that replacement is carried out by your Toyota dealer. ● To avoid serious deterioration, do not leave the electronic key within 3 ft.
Page 179 If this message is displayed but you have not had a new electronic key regis- tered, ask your Toyota dealer to check if an unknown electronic key (other than those in your possession) has been registered.
Page 180 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. PRIUS_OM_OM47C35U_(U)
Page 181: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control or door lock switches. Unlocking and locking the doors from the outside ◆ Smart key system Carry the electronic key to enable this function.
Page 182 Press and hold to open the side windows and moon roof (if equipped). : This setting must be customized at your Toyota dealer. ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 183 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 184 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 185 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the power switch off. When the indicator on the key surface is turned off, push and hold for approximately 5 seconds while pushing the button on the key.
Page 186 3-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant could be thrown out of the vehicle, resulting in death or serious injury. ●...
Page 187: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be unlocked/locked and opened/closed by the following procedures. ◆ Smart key system (if equipped) Carry the electronic key to enable this function. Locks all the doors Check that the door is securely locked.
Page 188 3-2. Opening, closing and locking the doors When closing the back door Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it. Be careful not to pull the back door sideways when closing the back door with the handle.
Page 189 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving ● Make sure that the back door is fully closed. If the back door is not fully closed, it may open unexpectedly while driving and hit near-by objects or luggage in the luggage compartment may be thrown out, causing an acci- dent.
Page 190 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. PRIUS_OM_OM47C35U_(U)
Page 191 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 192: Smart Key System
3-2. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ● Unlocks and locks the doors (P. 181) ●...
Page 193 When “Smart Key System malfunction See owner’s manual” is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time.
Page 194 3-2. Opening, closing and locking the doors ■ Electronic Key Battery-Saving Function When battery-saving mode is set, battery depletion is minimized by stopping the electronic key from receiving radio waves. Press twice while pressing and holding . Confirm that the electronic key indicator flashes 4 times.
Page 195 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 196 3-2. Opening, closing and locking the doors ● The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc. Clean the lock sensor and attempt to operate it again. ● A sudden approach to the effective range or door handle may prevent the doors from being unlocked.
Page 197 3-2. Opening, closing and locking the doors ■ Certification for the smart key system For vehicles sold in the U.S.A., Hawaii, American Samoa, Guam, Saipan  and Puerto Rico PRIUS_OM_OM47C35U_(U)
Page 198 3-2. Opening, closing and locking the doors For vehicles sold in Canada  PRIUS_OM_OM47C35U_(U)
Page 199 (P. 192) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 200: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) Power seat (if equipped for driver’s side)  Seat position adjustment switch Seat cushion (front) angle adjustment switch...
Page 201 3-3. Adjusting the seats ■ When adjusting the seat Take care when adjusting the seat so that the head restraint does not touch the ceiling. WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat.
Page 202: Rear Seats
3-3. Adjusting the seats Rear seats The seatbacks can be folded down. Before folding down the seatbacks Park the vehicle in a safe place. Apply the parking brake firmly (P. 257) and shift the shift position to P. (P. 251) Adjust the position of the front seat and the angle of the seatback.
Page 203 3-3. Adjusting the seats Folding down the seatbacks Pull the seatback lock release lever and fold the seatback down. Returning the rear seatbacks To avoid trapping the seat belt between the seat and the inside of the vehicle, pass the seat belt inside the seat belt guide and then return the seatback securely to the locked position.
Page 204 3-3. Adjusting the seats WARNING ■ After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the seatback is securely locked in position by lightly pushing it back and forth.
Page 205: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats Rear outboard seats ■...
Page 206 3-3. Adjusting the seats ■ Removing the head restraints Front and rear center seats  Pull the head restraint up while pressing the lock release button. Lock release button Rear outboard seats  Pull the seatback lock release lever and fold down the seatback until it reaches the position where the head restraints can be removed.
Page 207 3-3. Adjusting the seats Rear outboard seats  Pull the seatback lock release lever and fold down the seatback until it reaches the position where the head restraints can be installed. Align the head restraint with the installa- tion holes and push it down to the low- est lock position.
Page 208: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 209 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 210: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 211 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror  Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 212: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, operate the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 213 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The power switch is in ACCESSORY or ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defog- gers.
Page 214: Power Windows
3-5. Opening and closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the side windows as follows: Closing One-touch closing Opening One-touch opening : To stop the side window partway, operate the switch in the opposite direction.
Page 215 1 second or more. If you release the switch while the side window is moving, start again from the beginning. If the side window reverses and cannot be fully closed or opened, have the vehicle inspected by your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 216 ● The power windows can be opened using the wireless remote control. (P. 182) : These settings must be customized at your Toyota dealer. ■ When the 12-volt battery is disconnected The window lock switch is disabled. If necessary, press the window lock switch after reconnecting the 12-volt battery.
Page 217 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 218 3-5. Opening and closing the windows and moon roof WARNING ■ Jam protection function ● Never use any part of your body to intentionally activate the jam protection function. ● The jam protection function may not work if something gets jammed just before the side window is fully closed.
Page 219: Moon Roof
3-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 220 ● The moon roof can be opened and closed using the mechanical key. (P. 737) ● The moon roof can be opened using the wireless remote control. (P. 182) : These settings must be customized at your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 221 : If the switch is released at the incorrect time, the procedure will have to be performed again from the beginning. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Moon roof open reminder function The buzzer sounds and a message is shown on the multi-information display in the instrument cluster when the power switch is turned off and the driver’s...
Page 222 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof ● Do not allow any passengers to put their hands or head outside the vehicle while it is moving.
Page 223: Driving
Driving 4-1. Before driving 4-5. Using the driving support systems Driving the vehicle..... 224 Toyota Safety Sense P ..283 Cargo and luggage ... 235 PCS (Pre-Collision Vehicle load limits ..... 238 System)......291 Trailer towing..... 239 LDA (Lane Departure Dinghy towing ....
Page 224: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 241 Driving With the brake pedal depressed, shift the shift position to D. (P. 250) Check that the shift position indicator shows D. Release the parking brake.
Page 225 4-1. Before driving Starting off on a steep uphill Firmly set the parking brake with the brake pedal depressed, and then shift the shift position to D. Release the brake pedal and gently depress the accelerator pedal. Release the parking brake. ■...
Page 226 : Depending on the situation, the shift position may not be changed. ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●...
Page 227 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. ■...
Page 228 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Use engine braking (shift position B instead of shift position D) to maintain a safe speed when driving down a steep hill. Using the brakes continuously may cause the brakes to overheat and lose effectiveness.
Page 229 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When shifting the shift position ● Do not let the vehicle roll backward while a forward driving position is selected, or roll forward while the shift position is in R. Doing so may result in an accident or damage to the vehicle.
Page 230 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 231 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 232 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating.
Page 233 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the hybrid system output. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 234 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 235: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (P. 238) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. PRIUS_OM_OM47C35U_(U)
Page 236 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 754) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 237 4-1. Before driving WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment: Receptacles containing gasoline ● ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 238: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 239: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 240: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. ■...
Page 241: Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Firmly depress the brake pedal. and a message will be dis- played on the multi-information dis- play.
Page 242 4-2. Driving procedures Stopping the hybrid system Stop the vehicle completely. Set the parking brake. (P. 257) Shift the shift position to P. (P. 251) Check that the shift position indica- tor shows P. (P. 250) Press the power switch. The hybrid system will stop.
Page 243 4-2. Driving procedures Changing power switch modes Modes can be changed by pressing the power switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 244 ■ If the “READY” indicator does not come on In the event that the “READY” indicator does not come on even after perform- ing the proper procedures for starting the vehicle, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning P.
Page 245 4-2. Driving procedures ■ Meter display When the power switch is turned off, each display will turn off as follows. ● The shift position indicator will turn off after approximately 2 seconds. ● The multi-information display, clock, etc. will turn off after approximately 30 seconds.
Page 246 ■ When starting the hybrid system If the hybrid system becomes difficult to start, have your vehicle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the power switch If the power switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 247: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid bat- tery (traction battery), and only the electric motor (traction motor) is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
Page 248 4-2. Driving procedures ■ Switching to EV drive mode when the gasoline engine is cold If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically after a short period of time in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 249 4-2. Driving procedures WARNING ■ Caution while driving When driving in EV drive mode, pay special attention to the area around the vehicle. Because there is no engine noise, pedestrians, people riding bicy- cles or other people and vehicles in the area may not be aware of the vehi- cle starting off or approaching them, so take extra care while driving.
Page 250: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever Shift lever Operate the shift lever gently and ensure correct shifting operation. Release the shift lever after each shifting operation to allow it to return to position. When shifting to the D or R, move the shift lever along the shift gate.
Page 251 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the hybrid system Reversing Neutral (Condition in which the power is not transmitted) Normal driving Applying engine braking or strong braking when the accelerator pedal has been released on steep down- ward slopes etc.
Page 252 4-2. Driving procedures ■ For the shift positions ● When the power switch is off, the shift position cannot be changed. ● When the power switch is in ON mode (the hybrid system is not operating), the shift position can only be changed to N. The shift position will be changed to N even if the shift lever is shifted to D or R and held in that posi- tion.
Page 253 4-2. Driving procedures ■ Restraining sudden start (Drive-Start Control) P. 226 ■ Automatic P position selection function ● If the power switch is on and the shift position is not already P, completely stopping the vehicle and pressing the power switch causes the shift position to automatically switch to P and the power switch to turn off ●...
Page 254 Shift lever and P position switch ● Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 255 If any of the following situations occurs, shift control system malfunctions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● When the warning message indicating the shift control system appears on the multi-information display.
Page 256: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 257: Parking Brake
4-2. Driving procedures Parking brake Operating instructions To set the parking brake, fully depress the parking brake pedal with your left foot while depress- ing the brake pedal with your right (U.S.A.) foot. (Depressing pedal again releases the parking brake.) (Canada) ■...
Page 258: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: U.S.A. (type A)  daytime running lights turn on. (P. 261) The side marker, park- ing, tail, license plate, instrument panel lights, daytime...
Page 259 4-3. Operating the lights and wipers U.S.A. (type B)  headlights, side marker, parking lights, (if equipped) LED accent lights (if equipped), daytime run- ning lights (P. 261) and so on turn on and off automatically (when the power switch is in ON mode).
Page 260 4-3. Operating the lights and wipers Canada  headlights, side marker, parking lights, LED accent lights (if equipped), daytime run- ning lights (P. 261) and so on turn on and off automatically (when the power switch is in ON mode). The side marker, park- ing, accent...
Page 261 4-3. Operating the lights and wipers ■ Daytime running light system ● The daytime running lights illuminate using the same lights as the head- lights, and illuminate dimmer than the headlights. ● To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically when all of the following conditions are met.
Page 262 The system may be malfunctioning. Have the vehicle inspected by your Toy- ota dealer. ■ If the AFS OFF indicator flashes (vehicles with AFS) It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization Settings (e.g. light sensor sensitivity) can be changed.
Page 263: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 264 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 265 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 21 mph (34 km/h). •...
Page 266 4-3. Operating the lights and wipers ● In the situations shown below, the system may not be able to accurately detect surrounding brightness levels. This may cause the low beams to remain on or the high beams to cause problems for pedestrians, vehicles ahead or other parties.
Page 267 4-3. Operating the lights and wipers ■ Temporarily lowering sensor sensitivity The sensitivity of the sensor can be temporarily lowered. Turn the power switch off while the following conditions are met. • The headlight switch is in • The headlight switch lever is in high beam position. •...
Page 268: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights offer improved visibility in difficult driving condi- tions, such as in rain and fog. Operating instructions Type A  Turns the fog lights off Turns the fog lights on ...
Page 269 4-3. Operating the lights and wipers Type B  Turns the fog lights off Turns the fog lights on ■ Fog lights can be used when The headlights are on in low beam. NOTICE ■ To prevent 12-volt battery discharge Do not leave the lights on longer than necessary when the hybrid system is off.
Page 270: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows. Intermittent windshield wipers with interval adjuster (if ■ equipped) Type A  Intermittent operation Low speed operation High speed operation Temporary operation Type B...
Page 271 4-3. Operating the lights and wipers Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wipers will automatically operate a couple of times after the washer squirts. PRIUS_OM_OM47C35U_(U)
Page 272 4-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped) ■ Type A  Rain-sensing opera- tion Low speed operation High speed operation Temporary operation Type B  Rain-sensing operation Low speed operation High speed operation Temporary operation When is selected, the wipers will operate automatically when the sensor detects falling rain.
Page 273 4-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wipers will automatically operate a couple of times after the washer squirts. PRIUS_OM_OM47C35U_(U)
Page 274 4-3. Operating the lights and wipers ■ The windshield wipers and washer can be operated when The power switch is in ON mode. ■ Dripping prevention wiper sweep (vehicles with rain-sensing windshield wipers) After washing and wiping operation several times, the wipers operate one more time after a short delay to prevent dripping.
Page 275 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent 12-volt battery discharge Do not leave the wipers on longer than necessary when the hybrid system is off.
Page 276: Rear Window Wiper And Washer
4-3. Operating the lights and wipers  Rear window wiper and washer Operating the wiper lever Operating the switch operates the rear wiper as follows: Type A  Intermittent operation Normal operation Type B  Intermittent operation Normal operation Washer/wiper dual operation Pushing the lever operates the...
Page 277 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent 12-volt battery discharge Do not leave the wiper on longer than necessary when the hybrid system is off.
Page 278: 4-4. Refueling
4-4. Refueling Opening the fuel tank cap The fuel tank of your vehicle has a special structure, which requires a reduction in fuel tank pressure before refueling. After the opener switch has been pressed, it will take several seconds until the vehicle is ready for refueling. Before refueling the vehicle ●...
Page 279 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 280 4-4. Refueling NOTICE ■ Refueling ● Finish refueling within 30 minutes. If more than 30 minutes passes, the internal valve closes. In this condition, fuel may overflow during the refuel- ing process. Press the fuel filler door opener switch again. ●...
Page 281 4-4. Refueling ■ When the fuel filler door cannot be opened by pressing the inside switch Open the back door and remove the cover underneath the luggage compart- ment light. Pull the lever backward and check that the fuel lid opens. Using the lever to open the fuel filler door may not allow for an adequate reduction in fuel tank pressure before refueling.
Page 282 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 283: Using The Driving Support Systems
■ Toyota Safety Sense P The Toyota Safety Sense P is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 284 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 285 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor PRIUS_OM_OM47C35U_(U)
Page 286 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. ● Do not disassemble the radar sensor.
Page 287 • To replace the wiper insert: P. 646 • If the wiper blades need to be replaced, contact your Toyota dealer. ● Do not attach window tinting to the windshield.
Page 288 ● Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. ● If a surfboard or other long object is to be mounted on the roof, make sure that it will not obstruct the camera sensor.
Page 289 4-5. Using the driving support systems ■ Certification PRIUS_OM_OM47C35U_(U)
Page 290 4-5. Using the driving support systems PRIUS_OM_OM47C35U_(U)
Page 291: Pcs (Pre-Collision System)
4-5. Using the driving support systems  PCS (Pre-Collision System) The pre-collision system uses a radar sensor and camera sen- sor to detect vehicles and pedestrians in front of your vehicle. When the system determines that the possibility of a frontal col- lision with a vehicle or pedestrian is high, a warning operates to urge the driver to take evasive action and the potential brake pressure is increased to help the driver avoid the collision.
Page 292 4-5. Using the driving support systems ◆ Pre-collision brake assist When the system determines that the possibility of a frontal colli- sion is high, the system applies greater braking force in relation to how strongly the brake pedal is depressed. ◆...
Page 293 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 294 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: ● When the vehicle is being towed ●...
Page 295 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on the screen (P. 149) of the multi-information display. The system is automatically enabled each time the power switch is turned to ON mode.
Page 296 4-5. Using the driving support systems ■ Operational conditions The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high. Each function is operational at the following speeds: ●...
Page 297 4-5. Using the driving support systems ■ Conditions under which the system may operate even if there is no pos- sibility of a collision ● In some situations such as the following, the system may determine that there is a possibility of a frontal collision and operate. •...
Page 298 4-5. Using the driving support systems • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge • When there is a metal object (manhole cover, steel plate, etc.), steps, or a protrusion on the road surface or roadside •...
Page 299 4-5. Using the driving support systems • When driving near a TV tower, broadcasting station, electric power plant, or other location where strong radio waves or electrical noise may be present ■ Situations in which the system may not operate properly ●...
Page 300 4-5. Using the driving support systems • When driving in inclement weather such as heavy rain, fog, snow or a sandstorm • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead • When driving through steam or smoke •...
Page 301 4-5. Using the driving support systems ● Some pedestrians such as the following may not be detected by the radar sensor and camera sensor, preventing the system from operating properly: • Pedestrians shorter than approximately 3.2 ft. (1 m) or taller than approx- imately 6.5 ft.
Page 302 If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●...
Page 303: Lda (Lane Departure Alert With Steering Control)
4-5. Using the driving support systems LDA (Lane Departure Alert with steering  control) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane and provides assistance by operating the steering wheel to keep the vehicle in its lane.
Page 304 4-5. Using the driving support systems Functions included in LDA system ◆ Lane departure alert function When the system determines that the vehicle might depart from its lane, a warning is dis- played on the multi-information display and the warning buzzer sounds to alert the driver.
Page 305 4-5. Using the driving support systems ◆ Vehicle sway warning function When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 306 4-5. Using the driving support systems WARNING ■ Before using LDA system Do not rely solely upon the LDA system. The LDA system does not auto- matically drive the vehicle or reduce the amount of attention that must be paid to the area in front of the vehicle. The driver must always assume full responsibility for driving safely by paying careful attention to the surround- ing conditions and operating the steering wheel to correct the path of the vehicle.
Page 307 Do not install or place anything on the hood or grille. Also, do not install a grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. Turning LDA system on Press the LDA switch to turn the LDA system on.
Page 308 4-5. Using the driving support systems Indications on combination meter LDA indicator Illuminates when the LDA system is on. Steering control indicator and operation display of steering wheel operation support When that steering wheel assis- tance of the steering control func- tion is operating, the indicator illuminates and the operation dis- play on the multi-information dis-...
Page 309 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 310 4-5. Using the driving support systems ■ Temporary cancellation of functions When the operation conditions are no longer met, a function may be tempo- rarily canceled. However, when the operation conditions are met again, oper- ation of the function is automatically restored. (P. 309) ■...
Page 311 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. ● There are shadows on the road that run parallel with, or cover, the white (yellow) lines.
Page 312 “Lane Departure Alert properly. Malfunction  Have the vehicle inspected at your Visit Your Dealer” Toyota dealer. Dirt, rain, condensation, ice, snow, etc., are present on the windshield in “Front Camera front of the camera sensor.  Turn the LDA system off, remove Unavailable See Owner’s Manual”...
Page 313 4-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert function Adjust alert sensitivity Steering control function Turn steering wheel assistance on and off Turn function on and off Vehicle sway warning function Adjust alert sensitivity For how to change settings, refer to P.
Page 314: Dynamic Radar Cruise Control With Full-Speed Range
4-5. Using the driving support systems Dynamic radar cruise controlwith full-speed  range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 315 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control with full-speed range ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 316 4-5. Using the driving support systems WARNING ■ Cautions regarding the driving assist systems Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. ●...
Page 317 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control with full-speed range Do not use dynamic radar cruise control with full-speed range in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 318 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 328 ft. (100 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 319 4-5. Using the driving support systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance switch.
Page 320 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 321 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed (Except when the vehicle has been stopped by system control in vehi- cle-to-vehicle distance control...
Page 322 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 323 4-5. Using the driving support systems Resuming follow-up cruising when the vehicle has been stopped by system control (vehicle-to-vehicle distance control mode) After the vehicle ahead of you starts off, push the lever up. Your vehicle will also resume fol- low-up cruising if the accelerator pedal is depressed after the vehi- cle ahead of you starts off.
Page 324 4-5. Using the driving support systems Approach warning (vehicle-to-vehicle distance control mode) When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the display will flash and the buzzer will sound to alert the driver.
Page 325 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 326 • The vehicle has been stopped for about 3 minutes. In this situation, the shift position may automatically switch to P. (P. 253) If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 327 ● Parking Support Brake function is operated. (if equipped) If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 328 4-5. Using the driving support systems ● Vehicles with small rear ends (trailers with no load on board, etc.) ● Motorcycles traveling in the same lane ● When water or snow thrown up by the surrounding vehicles hinders the detecting of the sensor ●...
Page 329 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 330: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Use the cruise control on freeways and highways. Indicators Cruise control switch Set speed ...
Page 331 4-5. Using the driving support systems Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed (above approximately 25 mph [40 km/h]) and push the lever down to set the speed.
Page 332 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 333 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 334 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 335: Driving Mode Select Switch
4-5. Using the driving support systems Driving mode select switch In response to driving conditions, one of 3 drive modes can be selected. Driving modes Repeatedly press the switch until the system changes to the intended drive mode. Each time the switch is pressed, the drive mode changes in the following order “ECO MODE”...
Page 336 4-5. Using the driving support systems Normal mode Suitable for normal driving. When normal mode is selected, the “ECO MODE” and “PWR MODE” indicators turn off. Power mode Suitable for when crisp handling and enhanced accelerator response are desired, such as when driving on mountainous roads. “PWR MODE”...
Page 337: (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 338 4-5. Using the driving support systems The Blind Spot Monitor on/off screen and indicator The Blind Spot Monitor function and Rear Cross Traffic Alert function can be switched on and off using the multi-information display. (P. 149) When switched on, the BSM indicator illuminates on the meter and the buzzer sounds.
Page 339 When “Blind Spot Monitor System Malfunction Visit Your Dealer” is shown on the multi-information display There may be a sensor malfunction or misaligned. Have the vehicle inspected by your Toyota dealer. ■ Certification for the Blind Spot Monitor For vehicles sold in U.S.A.
Page 340 Do not attach accessories or stickers to the sensor or surrounding area on the bumper. ● Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. PRIUS_OM_OM47C35U_(U)
Page 341: The Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicle’s existence via the outside rear view mirror indicator.
Page 342 4-5. Using the driving support systems WARNING ■ Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. The Blind Spot Monitor function is a supplementary function which alerts the driver that a vehicle is present in the blind spot.
Page 343 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing situations: • When the sensor is misaligned due to a strong impact to the sensor or its surrounding area •...
Page 344: The Rear Cross Traffic Alert Function
4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 345 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 346 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects: ● Vehicles approaching from directly behind ●...
Page 347 4-5. Using the driving support systems • When backing up on a slope with a sharp change in grade • When backing out of a shallow angle parking spot • Immediately after the Blind Spot Monitor main switch is turned on •...
Page 348 4-5. Using the driving support systems ● Instances of the Rear Cross Traffic Alert function unnecessarily detecting a vehicle and/or object may increase in the following situations: • When a vehicle passes by the side of your vehicle • When the parking space faces a street and vehicles are being driven on the street •...
Page 349: Intuitive Parking Assist
4-5. Using the driving support systems  Intuitive parking assist The distance from your vehicle to nearby obstacles when paral- lel parking or maneuvering into a garage is measured by the sensors and communicated via the displays and a buzzer. Always check the surrounding area when using this system.
Page 350 4-5. Using the driving support systems Display When the sensors detect an obstacle, the following displays inform the driver of the position and distance to the obstacle. Multi-information display ■ Front center sensor opera- tion Front corner sensor opera- tion Front side sensor operation Rear side sensor operation Rear corner sensor operation...
Page 351 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Front corner, Rear corner, Display front center and rear center and front side sensors rear side sensors 3.3 ft.
Page 352 4-5. Using the driving support systems Buzzer When an obstacle is detected, the buzzer sounds. ● As the obstacle is approached, the buzzer sounds more rapidly. When the obstacle is extremely close, the buzzer switches from sounding intermittently (short beeps) to continuously (a long beep). •...
Page 353 4-5. Using the driving support systems Detection range of the sensors Approximately 3.3 ft. (100 cm) Approximately 4.9 ft. (150 cm) Approximately 2.0 ft. (60 cm) Approximately 3.3 ft. (100 cm) • The detection range is shown in the illustration to the right. How- ever, the sensor will not detect the obstacle if it is too close.
Page 354 4-5. Using the driving support systems ■ Operation conditions The power switch is turned on. ● Front corner sensors: • Shift position is not in P • Vehicle speed is approximately 6 mph (10 km/h) or less ● Front side sensors/rear side sensors: •...
Page 355 If “Parking Assist Malfunction” is displayed on the multi-information dis- play Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Toyota dealer. ■ Certification (Canada only) This ISM device complies with Canadian ICES-001.
Page 356 4-5. Using the driving support systems WARNING ■ When using intuitive parking assist Observe the following precautions to avoid an unexpected accident. ● Do not exceed the speed limit of 6 mph (10 km/h). ● The sensors’ detection areas and reaction times are limited. When moving forward or reversing, check the areas surrounding the vehicle (especially the sides of the vehicle) for safety, and drive slowly, using the brake to control the vehicle’s speed.
Page 357 If obstacles draw too close to the sensor. ● The bumper or sensor receives a strong impact. ● A non-genuine Toyota suspension (lowered suspension etc.) is installed. ● There is another vehicle equipped with parking assist sensors in the vicin- ity.
Page 358 4-5. Using the driving support systems WARNING ■ Side sensors In the following situations, the clearance sonar may not operate normally and may result in an unexpected accident. Drive carefully. ● Obstacles may not be detected in the side areas until the vehicle is driven for a short time and a scan of the side areas is completed.
Page 359 When using intuitive parking assist In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. ● Intuitive parking assist operation display flashes, and a beep sounds when no obstacles are detected.
Page 360: Parking Support Brake Function
4-5. Using the driving support systems  Parking Support Brake function When a collision may occur with an obstacle while parking or traveling at low speeds, when the vehicle suddenly moves for- ward due to mistaken accelerator pedal operation, or when the vehicle moves due to the wrong shift position being selected, the sensors detect obstacles to the front or rear in the traveling direction of the vehicle, and the system operates to lessen...
Page 361 4-5. Using the driving support systems ◆ The vehicle moves due to the wrong shift position being selected PRIUS_OM_OM47C35U_(U)
Page 362 4-5. Using the driving support systems Types of sensors Front corner sensors Front center sensors Rear corner sensors Rear center sensors Changing settings of the Parking Support Brake function The Parking Support Brake function can be enabled/disabled on the screen (P. 149) of the multi-information display. When the Parking Support Brake function is off, the PKSB OFF indi- cator illuminates.
Page 363 4-5. Using the driving support systems Operation When the Parking Support Brake function detects an obstacle with a probability of collision, hybrid system output is restricted to restrain an increase in vehicle speed. (Hybrid system output restriction control: A) Furthermore, when the accelerator pedal continues to be depressed, the brakes are applied to reduce the vehicle speed.
Page 364 4-5. Using the driving support systems Accelerator pedal Control starts Brake pedal Collision is possible Hybrid system output Collision is likely Braking force PRIUS_OM_OM47C35U_(U)
Page 365 4-5. Using the driving support systems Operation conditions Operation starting conditions ■ When the PKSB OFF indicator is not illuminated or flashing (P. 370, 693) and all of the following conditions are met, the system operates. Hybrid system output restriction control ...
Page 366 4-5. Using the driving support systems Display and buzzer for hybrid system output restriction control and brake control When the hybrid system output restriction control or brake control operates, the buzzer sounds and a message is displayed on the multi- information display to alert the driver.
Page 367 4-5. Using the driving support systems ■ Sensor detection range The detection range of the Parking Support Brake function differs from the detection range of the intuitive parking assist. (P. 353) Therefore, even if the intuitive parking assist detects an obstacle and pro- vides a warning, the Parking Support Brake function may not start operating.
Page 368 4-5. Using the driving support systems ■ Situations when the system may operate even though there is no possi- bility of a collision In the following situations, the system may operate even though there is no possibility of a collision. ●...
Page 369 4-5. Using the driving support systems ● Changes in the vehicle • The vehicle is tilted a large amount • The height of the vehicle has drastically changed due to the carried load (the nose tilts up or down) • The direction of the sensor has deviated due to a collision or other impact ■...
Page 370 If this message is shown even after removing dirt from the sensor, or shown when the sensor was not dirty to begin with, have the vehicle inspected at your Toyota dealer. ● System initialization may not have been performed after removal and instal- lation of the 12-volt battery.
Page 371 4-5. Using the driving support systems WARNING ■ For safe use Do not rely solely upon the system. Relying solely upon the system may lead to an unexpected accident. ● Driving safely is the sole responsibility of the driver. Pay careful attention to the surrounding conditions in order to ensure safe driving.
Page 372 If the area around a sensor is subjected to an impact, equipment may not operate properly due to a sensor malfunction. Have the vehicle inspected at your Toyota dealer. ● When using a high-pressure washer to wash the vehicle, do not spray water directly on the sensors.
Page 373: S-Apgs (Simple Advanced Parking Guidance System)
4-5. Using the driving support systems S-APGS (Simple Advanced Parking Guidance  System) Simple Advanced Parking Guidance System Function summary ■ The Simple Advanced Parking Guidance System automatically operates the steering wheel to provide support when backing into an area near a target parking spot, and when departing from a par- allel parking spot.
Page 374 4-5. Using the driving support systems Chart of Simple Advanced Parking Guidance System assist modes and functions Type of Assist mode Function summary See page parking Guidance is provided to detect intended parking spot and reach a position to begin back- Parallel parking Parallel park- ing up from.
Page 375 4-5. Using the driving support systems ■ Parking Support Brake function while the Simple Advanced Parking Guidance System is operating While the Simple Advanced Parking Guidance System is operating, if the sys- tem detects an obstacle that could result in a collision, hybrid system output restriction control and brake control of the Parking Support Brake function are operated, regardless of whether the Parking Support Brake function is on or off.
Page 376 4-5. Using the driving support systems Switching assist mode Switching using the S-APGS switch ■ Press the switch This allows you to switch func- tions and cancel or restart assist modes. While the power switch is on, the vehicle speed is approximately 19 mph (30 km/h) or less, each time the S-APGS switch is pressed the function switches as follows.
Page 377 4-5. Using the driving support systems Guidance screen The guidance screen is displayed on the multi-information display. Assistance level indicator Displays a gauge indicating the level until the vehicle’s stopping position/the position at which assist control ends. Stop display When illuminated, depress the brake pedal and stop the vehicle at once.
Page 378 4-5. Using the driving support systems Canceling or stopping assist mode Assist mode will be canceled or stopped in the following cases. Assist control is canceled when ■ ● The system temperature preservation function operates ● There is a system malfunction ●...
Page 379 4-5. Using the driving support systems How to parallel park (parallel parking assist mode) Function summary ■ If a parking space can be detected, you will be guided forward until you reach the assist control starting position, and then the parallel parking assist mode can be used.
Page 380 4-5. Using the driving support systems Parking ■ Stop so that the center of the target parking spot appears nearly perpendicular to vehicle. Then press the S-APGS switch 1 time and check that the display on the multi-information display switches to “Parallel Parking”. ●...
Page 381 4-5. Using the driving support systems Travel straight ahead paral- lel with the road (or curb), maintain approximately 3.3 ft. (1 m) from any parked vehicles. ● Proceed slowly. ● The system will begin searching for a parking 3.3 ft. space.
Page 382 4-5. Using the driving support systems When a beep sounds once and the stop display (P. 377) is shown on the display, stop the vehicle. When the shift position is changed to R, a high-pitched beep is emitted and assist control will start. ●...
Page 383 4-5. Using the driving support systems When a beep sounds once and the stop display (P. 377) is shown on the display, stop the vehicle. Change the shift position to D. Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around the vehicle and slowly proceed forward while adjusting your speed by depressing...
Page 384 4-5. Using the driving support systems When the vehicle is almost entirely within the target parking spot, a high-pitched beep is emitted and the stop display is shown on the display, stop the vehicle. This completes the parallel parking assist mode. ●...
Page 385 4-5. Using the driving support systems NOTICE ● If the road surface has any dips or inclines, the target parking spot cannot be correctly set. Therefore, the vehicle may be parked at an angle or may deviate from the parking spot. In these cases, do not use the parallel park- ing assist mode.
Page 386 4-5. Using the driving support systems How to depart from a parallel parking position (exit parallel park- ing assist mode) Function summary ■ When departing from a parallel parking position, select the direction you would like to depart in, and steering wheel operation assist con- trol will be provided to guide the vehicle to a position from which you can take off.
Page 387 4-5. Using the driving support systems Using the exit parallel parking assist mode to depart ■ With the shift position in P, press the S-APGS switch and check that the display on the multi-information display switches to “Exit Parallel Parking”. Operate the turn signal lever (P.
Page 388 4-5. Using the driving support systems When a beep sounds once and the stop display (P. 377) is shown on the display, stop the vehicle. Change the shift position to D. Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around the vehicle and slowly proceed forward while adjusting your speed by depressing...
Page 389 4-5. Using the driving support systems Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle and slowly back up while adjusting your speed by depressing the brake pedal.
Page 390 4-5. Using the driving support systems When the vehicle has nearly reached the take-off point, a high-pitched beep is emitted and assist control finishes. From there, grasp the steer- ing wheel and proceed for- ward. ■ Exit parallel parking assist mode ●...
Page 391 4-5. Using the driving support systems How to park next to other vehicles (back-in parking assist mode) Function summary ■ Stop so that the center of the target parking spot appears nearly perpendicular to the vehicle. If the space is detectable, the forward guidance function can be used.
Page 392 4-5. Using the driving support systems Parking ■ Stop so that the center of the target parking spot appears nearly perpendicular to vehi- cle. Then press the S-APGS switch 2 times and check that the display on the multi-infor- mation display switches to “Back-in Parking”.
Page 393 4-5. Using the driving support systems Assume an ordinary driving posture, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the front and around vehicle slowly proceed forward while adjusting your speed...
Page 394 4-5. Using the driving support systems Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle, confirm that there are no obstacles in the parking space, and slowly back up while adjusting your speed by depressing the brake pedal.
Page 395 4-5. Using the driving support systems Assume an ordinary posture for backing up, rest your hands lightly on the steering wheel without applying any force, directly confirm the safety of the area to the rear and around the vehicle slowly back up while adjusting your speed by depressing the brake pedal.
Page 396 4-5. Using the driving support systems ● Depending on the condition of the park- ing space, if there is not enough space in front of the vehicle required to perform the parking operation, the target parking spot may not be reachable. Intended parking spot Wall ■...
Page 397 The system may be malfunctioning.  Turn the power switch off and then start the hybrid system. Have the vehicle inspected by your Toyota dealer if the message is displayed again. There may be a system failure. Power steering equipment is temporarily overheat- ing.
Page 398 4-5. Using the driving support systems Message Situation/Handling method The vehicle is moved and assist control is started while the steering wheel is held.  Stop the vehicle and follow the guidance pro- vided by the system to start assist control. The S-APGS switch is operated when there is not enough space to the front and rear of the vehicle when departing from a parallel parking spot.
Page 399 4-5. Using the driving support systems Message Situation/Handling method The S-APGS switch is operated in an area where there are obstacles to the front, and the vehicle can- not move forward to the starting point for backing  Assist control cannot be used, as there are obstacles in front of the vehicle.
Page 400 4-5. Using the driving support systems Message Situation/Handling method The maximum number of movements for multi-turn maneuvering is reached during assist control, or the target parking spot cannot be reached due to the control being used on a road with steep grade. ...
Page 401 4-5. Using the driving support systems Message Situation/Handling method  Press The vehicle moved S-APGS too close to an obsta- switch after changing cle in front of the the shift position to R to vehicle. restart assist control.  Press The vehicle moved S-APGS too close to an obsta-...
Page 402 4-5. Using the driving support systems Precautions during use Sensors ■ Detect the vehicle to help determine the parking spot. Front side sensors Rear side sensors ● The sensor detection range when using back-in parking assist mode Intended parking spot ●...
Page 403 4-5. Using the driving support systems ● When there is a parked vehicle behind the target parking spot, it may not be detected due to the distance. Also, depending on the shape of the vehicle and other conditions, the detectable range may shorten or detection may not be possible.
Page 404 4-5. Using the driving support systems WARNING ● Do not rely solely upon the Simple Advanced Parking Guidance System. As with unequipped vehicles, move forward and back up carefully while directly confirming the safety of your surroundings and the area to the rear of the vehicle.
Page 405 • Using tire chains or compact spare tire (if equipped) ● Do not use tire other than that provided by the manufacturer. The system may not operate properly. When replacing tires, contact your Toyota dealer. ● The system may not be able position the vehicle in the set location in the following situations.
Page 406 If the vehicle bumper strikes something, equipment may not operate properly due to a sensor malfunction. Have the vehicle inspected at your Toyota dealer. ● In the following situations, the sensors may not operate normally and may lead to an accident.
Page 407: Rear View Monitor System
4-5. Using the driving support systems Rear view monitor system The rear view monitor system assists the driver by displaying an image of the view behind the vehicle with fixed guide lines on the screen while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 408 4-5. Using the driving support systems Using the rear view monitor system Screen description ■ The rear view monitor system screen will be displayed if the shift lever is shifted to R while the power switch is in ON mode. Vehicle width extension guide line Displays a guide path when the vehicle is being backed straight up.
Page 409 4-5. Using the driving support systems Rear view monitor system precautions Area displayed on screen ■ The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image adjustment proce- dure for the rear view monitor system screen is the same as the procedure for adjusting the...
Page 410 4-5. Using the driving support systems Rear view monitor system camera ■ The camera for the rear view monitor system is located as shown in the illustration. ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 411 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 412 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixed guide lines on the screen and the actual dis- A margin of error...
Page 413 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 414 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 415 4-5. Using the driving support systems WARNING ■ When using the rear view monitor system The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to visually check all around the vehicle both directly and using the mirrors before proceeding.
Page 416 Doing so may result in the camera malfunc- tioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. PRIUS_OM_OM47C35U_(U)
Page 417: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 418 4-5. Using the driving support systems ◆ Hill-start assist control Helps to reduce the backward movement of the vehicle when start- ing on an uphill ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆...
Page 419 TRAC has been disabled even if has not been pressed TRAC is temporary deactivated. If the information continues to show, contact your Toyota dealer. ■ Operating conditions of hill-start assist control When the following four conditions are met, the hill-start assist control will operate: ●...
Page 420 4-5. Using the driving support systems ■ Automatic system cancelation of hill-start assist control The hill-start assist control will turn off in any of the following situations: ● Shift the shift position to P or N ● The accelerator pedal is depressed ●...
Page 421 4-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid system off.
Page 422 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 423 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 424: 4-6. Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the fol- lowing points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 425: Driving Tips
4-6. Driving tips ◆ When braking Make sure to operate the brakes gently and in a timely manner. A greater amount of electrical energy can be regenerated when slow- ing down. ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy.
Page 426 4-6. Driving tips ◆ Checking tire inflation pressure Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel economy. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel economy. Use tires that are appro- priate for the season.
Page 427: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 428 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and shift the shift position to P and block the wheel under the vehicle without setting the parking brake.
Page 429 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 430 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 431 4-6. Driving tips PRIUS_OM_OM47C35U_(U)
Page 432: Audio System
Audio system 5-1. Basic Operations Audio system types ..434 Audio system ....435 Using the steering wheel audio switches....438 AUX Port/USB Port ..439 Basic audio operations ..440 5-2. Setup Setup menu ...... 442 General settings ....443 Audio settings ....
Page 433 Audio system ® 5-5. Playing an audio CD and 5-9. Bluetooth phone MP3/WMA/AAC discs ® Using a Bluetooth CD player operation..454 Phone ......484 Making a call ....487 5-6. Using an external device Receiving a call ....490 iPod player operation..
Page 434: 5-1. Basic Operations
5-1. Basic Operations Audio system types Entune Audio  P. 435 Entune Premium Audio with Navigation  Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 435: Audio System
5-1. Basic Operations  Audio system Operations such as listening to audio, using the hands-free phone, confirming vehicle information and changing audio sys- tem settings are started by using the following buttons. Audio system operation buttons “AUDIO” button Display the “Select Audio Source” screen or audio top screen. (P.
Page 436 5-1. Basic Operations Operating the touch screen By touching the screen with your finger, you can control the audio sys- tem, etc. Touch ■ Quickly touch and release once. ● Changing and selecting various settings Drag ■ Touch the screen with your finger, and move the screen to the desired position.
Page 437 5-1. Basic Operations ■ When using the touch screen ● If the screen is cold, the display may be dark, or the system may seem to be operating slightly slower than normal. ● The screen may seem dark and hard to see when viewed through sun- glasses.
Page 438: Using The Steering Wheel Audio Switches
5-1. Basic Operations Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 439: Aux Port/Usb Port
5-1. Basic Operations AUX Port/USB Port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Select “iPod”, “USB” or “AUX” on the audio source selection screen and the device can be operated via audio system. Connecting the AUX port/USB port iPod ■...
Page 440: Basic Audio Operations
5-1. Basic Operations Basic audio operations Basic audio operations and functions common to each mode are explained in this section. Operating the audio system Press this button to eject a disc. Insert a disc into the disc slot. Press to mute/unmute or pause/resume the current operation. Press the “”...
Page 441 5-1. Basic Operations Random playback Select to change on/off. Repeat play Select to change on/off. ■ Certification For vehicles sold in the U.S.A., Hawaii, Guam, Saipan, Puerto Rico and  United States Virgin Islands CAUTION: THIS PRODUCT IS A CLASS  LASER PRODUCT. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIA- TION EXPOSURE.
Page 442: 5-2. Setup
5-2. Setup Setup menu You can adjust the audio system to your desired settings. Display “Setup” screen Press the “SETUP” button to display the “Setup” screen. Select to adjust the settings for operation sounds, screen ani- mation, etc. (P. 443) Select to set the voice settings.
Page 443: General Settings
The animation effect for the screen can be set to on/off. Select to delete personal data. (P. 444) Select to update program versions. For details, contact your Toyota dealer. Select to display the software information. Notices related to third party software used in this product are enlisted. (This includes instructions for obtaining such software, where applicable.)
Page 444 5-2. Setup Delete personal data Select “Delete Personal Data” on the “General Settings” screen. Select “Delete”. Check carefully beforehand, as data cannot be retrieved once deleted. A confirmation screen will be displayed. Select “Yes”. The following personal data will be deleted or changed to its default settings.
Page 445: Audio Settings
5-2. Setup Audio settings Settings are available for adjusting the radio operation, cover art, etc. Screen for audio settings Press the “SETUP” button. Select “Audio” on the “Setup” screen. Number of Radio Presets Select the number of radio preset stations. Display Cover Art on/off.
Page 446: Display Settings
5-2. Setup Display settings Settings are available for adjusting the contrast and brightness of the screen. Screen for display settings Press the “SETUP” button. Select “Display” on the “Setup” screen. Adjust screen contrast/bright- ness. Adjust screen contrast/bright- ness of the rear view monitor camera.
Page 447: Voice Settings
5-2. Setup Voice settings This screen is used for guidance for voice command systems setting. Adjust the voice guidance vol- ume setting. voice recognition prompts “High”, “Low” or “Off”. Set the train voice recognition. The user will be asked to say 10 sample phrases.
Page 448: Selecting The Audio Source
5-3. Using the Multimedia system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button to display the audio source selection screen. If the audio source selection screen is not displayed, press the “AUDIO” button again.
Page 449: List Screen Operation
5-3. Using the Multimedia system List screen operation When a list screen is displayed, use the appropriate buttons to scroll through the list. How to scroll : Select to scroll to the next or previous page. : If appears to the right of titles, the complete titles are too long for the display.
Page 450 5-3. Using the Multimedia system Selecting, fast-forwarding and reversing tracks/files/songs Selecting a track/file/song ■ Press the “” or “” button on “SEEK•TRACK” or turn the “TUNE•SCROLL” knob to select the desired track/file/song number. To fast-forward or reverse, press and hold the “” or “” button on “SEEK•TRACK”.
Page 451: Optimal Use Of The Audio System
5-3. Using the Multimedia system Optimal use of the audio system On the “Sound Settings” screen, sound quality (Treble/Mid/ Bass), volume balance can be adjusted. How to adjust the sound settings and sound quality Select “-” or “+” to adjust 1 2 3 the treble, mid or bass to a level between -5 and 5.
Page 452: 5-4. Using The Radio
5-4. Using the radio Radio operation Select “AM” or “FM” on the audio source selection screen to begin listening to the radio. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source. Audio source selection screen appears Preset stations...
Page 453 5-4. Using the radio Setting station presets Search for desired stations by turning the “TUNE•SCROLL” knob or pressing the “” or “” button on “SEEK•TRACK”. Select “(add new)”. To change the preset station to a different one, select and hold the preset station.
Page 454: Cd Player Operation
5-5. Playing an audio CD and MP3/WMA/AAC discs CD player operation Insert disc or select “CD” on the audio source selection screen with a disc inserted to begin listening to a CD. Audio control screen Pressing the “AUDIO” button displays the audio control screen from any screens of the selected source.
Page 455 ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or •...
Page 456 5-5. Playing an audio CD and MP3/WMA/AAC discs ■ MP3, WMA and AAC files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
Page 457 5-5. Playing an audio CD and MP3/WMA/AAC discs ● AAC file compatibility • Compatible standards MPEG4/AAC-LC • Compatible sampling frequencies 11.025/12/16/22.05/24/32/44.1/48 (kHz) • Compatible bit rates 16-320 (kbps) Compatible channel modes: 1ch and 2ch ● Compatible media Media that can be used for MP3, WMA and AAC playback are CD-Rs and CD-RWs.
Page 458 5-5. Playing an audio CD and MP3/WMA/AAC discs ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 459 5-5. Playing an audio CD and MP3/WMA/AAC discs NOTICE ■ Discs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 460: 5-6. Using An External Device
5-6. Using an external device iPod player operation Connecting an iPod enables you to enjoy music from the vehicle speakers. Select “iPod” on the audio source selection screen. When the iPod connected to the system includes iPod video, the system can only output the sound by selecting the browse screen.
Page 461 5-6. Using an external device Selecting a play mode Select “Browse” on the screen. Select the desired play mode. Then select a song to begin using the selected play mode. Shuffle play Select to change on/off. Repeat play Select to change on/off. PRIUS_OM_OM47C35U_(U)
Page 462 5-6. Using an external device ■ About iPod ● Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer to meet Apple performance standards.
Page 463 Owner’s Manual. ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please consult your Owner’s...
Page 464 5-6. Using an external device ■ Compatible models ● Made for • iPhone 5 • iPhone 4s • iPhone 4 • iPhone 3GS • iPhone 3G • iPod touch (5th generation) • iPod touch (4th generation) • iPod touch (3rd generation) •...
Page 465: Usb Memory Device Player Operation
5-6. Using an external device USB memory device player operation Connecting a USB memory device enables you to enjoy music from the vehicle speakers. Touch “USB” on the audio source selection screen. Connecting a USB memory device P. 439 Audio control screen Pressing the “AUDIO”...
Page 466 Error messages for USB memory If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures “Connection error. Please...
Page 467 5-6. Using an external device ● MP3, WMA and AAC files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 468 5-6. Using an external device ● ID3, WMA and AAC tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 469 5-6. Using an external device NOTICE ■ To prevent damage to the USB memory device or its terminals ● Do not leave the USB memory device in the vehicle. The temperature inside the vehicle may become high. ● Do not push down on or apply unnecessary pressure to the USB memory device while it is connected.
Page 470: Using The Aux
5-6. Using an external device Using the AUX To use the AUX port, connect a portable player, press the “AUDIO” button, then select “AUX” to display the audio control screen. Connecting a portable audio player P. 439 ■ Operating portable audio players connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
Page 471: Connecting Bluetooth
® 5-7. Connecting Bluetooth Preparations to use wireless communication ® The following can be performed using Bluetooth wireless com- munication: A portable audio player can be operated and listened to via ■ audio system Hands-free phone calls can be made via a cellular phone ■...
Page 472 ® 5-7. Connecting Bluetooth Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio sys- tem (P. 474, 475, 476) ® 2. Connect the Bluetooth device to be used (P. 478) To be used for audio To be used for hands-free phone ®...
Page 473 ® 5-7. Connecting Bluetooth Registering and connecting from the “Bluetooth Setup” screen To display the screen shown below, press the “SETUP” button and select “Bluetooth ” on the “Setup” screen. Select to connect the device to be used with audio system. (P.
Page 474: Registering A Bluetooth ® Audio Player For The First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth audio player for the first time ® To use the Bluetooth Audio, it is necessary to register an audio player with the system. Once the player has been registered, it is possible to use the ®...
Page 475: Registering A Bluetooth ® Phone For The First Time
® 5-7. Connecting Bluetooth ® Registering a Bluetooth phone for the first time To use the hands-free system, it is necessary to register a ® Bluetooth phone with the system. Once the phone has been registered, it is possible to use the hands-free system.
Page 476: Registering A Bluetooth ® Device
® 5-7. Connecting Bluetooth ® Registering a Bluetooth device ® Bluetooth compatible phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Display the “Bluetooth Setup”...
Page 477 ® 5-7. Connecting Bluetooth Check that this screen is dis- played when registration is complete. Select “OK” when connection status changes from “Connecting...” to “Connected”. If an error message is displayed, follow the guidance on the screen to try again. Registration can be performed from screens other than the “Bluetooth Setup”...
Page 478: Connecting A Bluetooth ® Device
® 5-7. Connecting Bluetooth ® Connecting a Bluetooth device ® Up to 5 Bluetooth devices (Phones [HFP] and audio players [AVP]) can be registered. ® If more than 1 Bluetooth device has been registered, select which device to connect to. Press the “SETUP”...
Page 479 ® 5-7. Connecting Bluetooth Manual connection When auto connection has failed or “Bluetooth Power” is turned off, ® you must connect the Bluetooth device manually. : Bluetooth is a registered trademark of Bluetooth SIG, Inc. ® Follow the steps in “Connecting a Bluetooth device”...
Page 480: Displaying A Bluetooth ® Device Details
® 5-7. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Display the “Bluetooth Setup” screen. (P. 473) : Bluetooth is a registered trademark of Bluetooth SIG, Inc. Select the device.
Page 481: Detailed Bluetooth ® Settings
® 5-7. Connecting Bluetooth ® Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Display the “Bluetooth Setup” screen. (P. 473) Select “System Settings”. The following screen is displayed: ®...
Page 482: Bluetooth Audio
® 5-8. Bluetooth Audio ® Listening to Bluetooth Audio ® The Bluetooth audio system enables the user to enjoy music played on a portable player from the vehicle speakers via wire- less communication. ® When a Bluetooth device cannot be connected, check the connec- tion status on the “Bluetooth Audio”...
Page 483 ® 5-8. Bluetooth Audio ® Playing Bluetooth audio Select to Play/Pause. For details on “Bluetooth Audio” screen operation methods, refer to Basic Audio Operations. (P. 440) For details on how to select a track or album, refer to selecting, fast- forwarding and reversing tracks/files/songs.
Page 484: Bluetooth Phone
® 5-9. Bluetooth phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 485 ® 5-9. Bluetooth phone Telephone switch ■ P. 498 Microphone ■ The vehicle’s built in microphone is used when talking on the phone. The person you are speaking to can be heard from the front speak- ers. ® To use the hands-free system, you must register your Bluetooth phone in the system.
Page 486 ® 5-9. Bluetooth phone Status display You can check indicators such as signal strength and battery charge on the phone screen. Connection status Signal strength “Rm” is displayed when receiving in a roaming area. While roaming, display “Rm” top-left on the icon. Battery charge Indicators Conditions...
Page 487: Making A Call
® 5-9. Bluetooth phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the following procedure: Dialing Display the phone screen. (P. 484) Select the “Dial Pad” tab and enter a phone number. To delete the input phone number, select For the first digit, you can enter “+”...
Page 488 ® 5-9. Bluetooth phone ® For PBAP compatible Bluetooth phones ■ When “Automatic Transfer” is set to off  Select the desired item. Select to transfer new con- tacts from a cellular phone, select “Always” and then enable “Automatic Trans- fer”.
Page 489 ® 5-9. Bluetooth phone Calling using favorites list You can make a call using numbers registered in the contact. Display the phone screen. (P. 484) Select “Favorites” tab. Select the desired number to make a call. Dialing from call history You can make a call using the call history, which has the 3 functions below.
Page 490: Receiving A Call
® 5-9. Bluetooth phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone Press the switch on the steering wheel or select To refuse a call Press the switch on the steering wheel or select To adjust the incoming call volume Turn the “PWR•VOL”...
Page 491: Speaking On The Phone
® 5-9. Bluetooth phone Speaking on the phone The following screen is displayed when speaking on the phone. To adjust the call volume Select “-” or “+”. You can also adjust the volume using the steering switches or the volume knob. To prevent the other party from hearing your voice Select “Mute”.
Page 492 ® 5-9. Bluetooth phone ■ Release Tones ● A continuous tone signal is a character string that consists of numbers and the characters p or w. (e.g.056133w0123p#1) ● When the “p” pause tone is used, the tone data up until the next pause tone will be automatically sent after 2 seconds have elapsed.
Page 493 ® 5-9. Bluetooth phone To transfer a call Select “Handset Mode” to on from a hands-free call to a cellular phone call. Select “Handset Mode” to off from a cellular phone call to a hands-free call. Transmit volume setting Select “Transmit Volume”. Select the desired level for the transmit volume.
Page 494: Bluetooth ® Phone Message Function
® 5-9. Bluetooth phone ® Bluetooth phone message function Received messages can be forwarded from the connected ® Bluetooth phone, enabling checking and replying using the audio system. ® Depending on the type of Bluetooth phone connected, received messages may not be transferred to the message inbox. If the phone does not support the message function, this func- tion cannot be used.
Page 495 ® 5-9. Bluetooth phone ■ Receiving a message ● Depending on the cellular phone used for receiving messages, or its regis- tration status with the audio system, some information may not be dis- played. ● The pop up screen is separately available for incoming e-mail and SMS/ MMS messages under the following conditions: E-mail: •...
Page 496 ® 5-9. Bluetooth phone Checking the messages Display the message inbox screen. (P. 494) Select the desired message from the list. Check that the message is displayed. E-mails: Select “Mark Unread” or “Mark Read” to mark mail unread or read on the message inbox screen.
Page 497 ® 5-9. Bluetooth phone Replying to a message Display the message inbox screen. (P. 494) Select the desired message from the list. Select “Quick Message”. Select the desired message. Select “Send”. If an error message is displayed, follow the guidance on the screen to try again.
Page 498: Using The Steering Wheel Switches
® 5-9. Bluetooth phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches Volume switch • Increase/Decrease the vol- • Press and hold: Continuously increase/ decrease the volume...
Page 499: Bluetooth ® Phone Settings
® 5-9. Bluetooth phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Phone/Message Settings” screen To display the screen shown below, press the “SETUP” button, and select “Phone” on the “Setup” screen. Set the phone connection (P.
Page 500: Contact/Call History Settings
® 5-9. Bluetooth phone Contact/Call History Settings ® The contact can be transferred from a Bluetooth phone to the system. The contact also can be added, edited and deleted. The call history can be deleted and contact and favorites can be changed.
Page 501 ® 5-9. Bluetooth phone Update contacts from phone Operation methods differ between PBAP compatible and PBAP ® incompatible but OPP compatible Bluetooth phones. If your cellular phone is neither PBAP nor OPP compatible, the con- tacts cannot be transferred. ® For PBAP Compatible Bluetooth Phones ■...
Page 502 ® 5-9. Bluetooth phone Updating the contacts in a different way (From the “Call ■ History” screen) ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 500) Display the phone screen. (P. 484) Select the “Call History”...
Page 503 ® 5-9. Bluetooth phone Editing the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 500) Select “Edit Contacts”. Select the desired contact. Select corresponding to the desired name or number. For editing the name ...
Page 504 ® 5-9. Bluetooth phone Deleting the contact data ® For PBAP compatible Bluetooth phones, this function is available when “Automatic Transfer” is set to off. (P. 500) Select “Delete Contacts”. Select the desired contact and select “Delete”. Select “Yes” when the confirmation screen appears. Deleting the contact in a different way (From the “Contact ■...
Page 505 ® 5-9. Bluetooth phone When 15 contacts have already been registered to the favorites  list When 15 contacts have already been registered to the favorites list, a registered contact needs to be replaced. Select “Yes” when the confirmation screen appears to replace a contact.
Page 506 ® 5-9. Bluetooth phone Deleting the contacts in the favorites list ■ Select “Remove Favorite”. Select the desired contacts and select “Remove”. Select “Yes” when the confirmation screen appears. Check that a confirmation screen is displayed when the opera- tion is complete. Deleting contacts in the favorites list in a different way (from the ...
Page 507 ® 5-9. Bluetooth phone Message Settings Display the “Phone/Message Settings” screen. (P. 499) Select “Messaging Settings”. Select the desired item to be set. automatic message transfer on/off. automatic message readout on/off. Set the SMS/MMS notifica- tion popup on/off. Set the e-mail notification popup on/off.
Page 508 ® 5-9. Bluetooth phone Displaying the “Messaging Settings” screen in a different way ■ Display the phone screen. (P. 484) Select Select “Settings”. Select “Messaging Settings”. Phone Display Settings Display the “Phone/Message Settings” screen. (P. 499) Select “Phone Display Settings”. Select the desired item to be set.
Page 509: What To Do If
 For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ The Bluetooth version of the connected cellular phone may be older than the specified version.
Page 510 ® 5-9. Bluetooth phone When registering/connecting a cellular phone  A cellular phone cannot be registered. An incorrect passcode was entered on the cellular phone.  Enter the correct passcode on the cellular phone. The registration operation has not been completed on the cellular phone side.
Page 511  For a list of specific devices which operation has been confirmed on this system, check with your Toyota dealer or the following web- site: http://www.toyota.com/entune/ Automatic phonebook transfer function on this system is set to off.
Page 512 ® 5-9. Bluetooth phone In other situations  ® The Bluetooth connection status is displayed at the top of the screen each time the power switch is turned to the ACCESSORY or ON mode. Connection confirmation display on this system is set to on. ...
Page 513: Bluetooth
® 5-10. Bluetooth ® Bluetooth ® ■ When using the Bluetooth audio system ● In the following conditions, the system may not function. • If the portable audio player is turned off • If the portable audio player is not connected •...
Page 514 ® 5-10. Bluetooth ® ■ Bluetooth antenna The antenna is built into the display. ® If the Bluetooth device is behind the seat or in the glove box or console box, or is touching or covered by metal objects, the connection status may deterio- rate.
Page 515 ® 5-10. Bluetooth ■ Compatible models ® The Bluetooth audio system supports portable audio players with the follow- ing specifications. ® ● Bluetooth specifications: Ver. 2.0, or higher (Recommended: Ver. 3.0+EDR or higher) ● Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
Page 516 ® 5-10. Bluetooth ® ■ Certifications for the Bluetooth For vehicles sold in the U.S.A., Hawaii, Guam, Saipan, Puerto Rico and  United States Virgin Islands PRIUS_OM_OM47C35U_(U)
Page 517 ® 5-10. Bluetooth For vehicles sold in Canada  PRIUS_OM_OM47C35U_(U)
Page 518 ® 5-10. Bluetooth ■ Reconnecting the portable audio player If the portable audio player is disconnected due to poor reception, the system automatically reconnects the portable audio player. If you have switched off the portable audio player yourself, follow the instruc- tions below to reconnect: ●...
Page 519: Using The Voice Command System Voice Command System
5-11. Using the voice command system Voice command system The voice command system enables the hands-free system to be operated using voice commands. Using the voice command system Press the talk switch. To cancel the voice command sys- tem, press and hold the talk switch. Select to train voice recogni- tion.
Page 520 5-11. Using the voice command system ■ Microphone P. 485 ■ When using the microphone ● It is unnecessary to speak directly into the microphone when giving a com- mand. ● When “Voice Prompt Interrupt” set to on, it is not necessary to wait for the confirmation beep before speaking a command.
Page 521 5-11. Using the voice command system Casual speech recognization Due to natural language speech recognition technology, this system enables recognition of a command when spoken naturally. However, the system cannot recognize every variation of each command. In some situations, it is possible to omit the command for the proce- dure and directly state the desired operation.
Page 522 5-11. Using the voice command system Command list Some recognizable voice commands and their actions are shown below as examples. Basic  Command Action Prompts voice guidance to offer examples of com- “Help” mands or operation methods “Go Back” Returns to the previous screen Phone ...
Page 523 5-11. Using the voice command system Mobile Assistant ® The Mobile Assistant feature will activate Apple’s Siri Eyes Free mode via the steering wheel switches. To operate the Mobile Assis- tant, a compatible cellular phone must be registered and connected to ®...
Page 524 5-11. Using the voice command system ■ Notes about Mobile Assistant ● The available features and functions may vary based on the iOS version installed on the connected device. ® ● Some Siri features are limited in Eyes Free mode. If you attempt to use an ®...
Page 525: Using The Storage Features
Interior features 6-1. Using the air conditioning 6-2. Using the interior lights system and defogger Interior lights list ....548 Automatic air conditioning • Front interior light..549 system (vehicles without • Front personal lights ..549 11.6-inch display).... 526 •...
Page 526: System (Vehicles Without 11.6-Inch Display)
6-1. Using the air conditioning system and defogger Automatic air conditioning system (vehicles without 11.6-inch display) Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Adjusting the temperature setting ■ Move the temperature setting knob upwards to increase the temperature and downwards to decrease the temperature.
Page 527 6-1. Using the air conditioning system and defogger Change the airflow mode ■ Move the airflow change knob upwards downwards change the airflow mode. outlets used switched each time the knob is operated. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Airflow change...
Page 528 6-1. Using the air conditioning system and defogger S-FLOW mode ■ In S-FLOW mode, priority for the airflow is given to the front seats, reducing the airflow and air conditioning effect on the rear seats. When a passenger is not detected in the front passenger seat, depending on the set temperature and ambient temperature, prior- ity for the airflow will be given to the driver’s seat only.
Page 529 6-1. Using the air conditioning system and defogger Using automatic mode Press Adjust the temperature setting. Press The cooling and dehumidification function switches between on and off each time is pressed. To stop the operation, press ■ Automatic mode indicator If the fan speed setting or air flow modes are operated, the auto- matic mode indicator goes off.
Page 530 6-1. Using the air conditioning system and defogger Defogging the windshield ■ Defoggers are used to defog the windshield and front side win- dows. Press to outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 531 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected airflow mode. Adjusting the air flow direction ■ Direct air flow to the left or right, up or down Opening and closing the air outlets ■...
Page 532 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 533 6-1. Using the air conditioning system and defogger ■ Windshield fog detection function When automatic mode is set, the humidity sensor (P. 535) detects fog on the windshield and controls the air conditioning system to prevent fog. ■ Outside/recirculated air mode ●...
Page 534 6-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 535 6-1. Using the air conditioning system and defogger NOTICE ■ Humidity sensor (if equipped) In order to detect fog on the windshield, a sensor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 533) Follow these points to avoid damaging the sensor: ●...
Page 536: Automatic Air Conditioning System (Vehicles With 11.6-Inch Display)
6-1. Using the air conditioning system and defogger Automatic air conditioning system (vehicles with 11.6-inch display) Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioner information area The following informations are displayed on the navigation system screen.
Page 537 6-1. Using the air conditioning system and defogger Air conditioning control screen conditioning control screen can be displayed by touch- ing the air conditioner information area on the navigation system screen. Air conditioning controls Adjusting the temperature setting ■ Press “” on to increase the temperature and “”...
Page 538 6-1. Using the air conditioning system and defogger S-FLOW mode ■ In S-FLOW mode, priority for the airflow is given to the front seats, reducing the airflow and air conditioning effect on the rear seats. When a passenger is not detected in the front passenger seat, depending on the set temperature and ambient temperature, prior- ity for the airflow will be given to the driver’s seat only.
Page 539 6-1. Using the air conditioning system and defogger Using automatic mode Select on the air conditioning control screen. Adjust the temperature setting. (P. 537) To stop the operation, select Automatic mode indicator ■ If the fan speed setting or air flow modes are operated, the indicator goes off.
Page 540 6-1. Using the air conditioning system and defogger Defogging the windshield ■ Defoggers are used to defog the windshield and front side win- dows. Press to outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 541 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume change according selected airflow mode. Adjusting the position of the air outlets ■ Direct air flow to the left or right, up or down.
Page 542 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 543 6-1. Using the air conditioning system and defogger ■ Windshield fog detection function When automatic mode is set, the humidity sensor (P. 545) detects fog on the windshield and controls the air conditioning system to prevent fog. ■ Outside/recirculated air mode ●...
Page 544 6-1. Using the air conditioning system and defogger ■ Customization Settings (e.g. A/C auto switching operation) can be changed. (Customizable features: P. 780) WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 545 6-1. Using the air conditioning system and defogger NOTICE ■ Humidity sensor In order to detect fog on the windshield, a sensor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 543) Follow these points to avoid damaging the sensor: ●...
Page 546: Heated Steering Wheel/ Seat Heaters
6-1. Using the air conditioning system and defogger   Heated steering wheel /seat heaters ● Heated steering wheel Warm up the grip of the steering wheel ● Seat heaters (front seats) Warm up the seat upholstery WARNING ● Care should be taken to prevent injury if anyone in the following categories comes in contact with the steering wheel and seats when the heater is on: •...
Page 547 6-1. Using the air conditioning system and defogger Heated steering wheel (if equipped) Turns the heated steering wheel on/off The indicator in the instrument cluster comes on when the heated steering wheel is operating. ● The heated steering wheel can be used when the power switch is in ON mode.
Page 548: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Front personal/interior lights (P. 549) Shift lever lighting Rear interior light (P. 550) Front door courtesy lights Footwell lights (if equipped) PRIUS_OM_OM47C35U_(U)
Page 549: Front Interior Light
6-2. Using the interior lights Front interior light Vehicles without moon roof Vehicles with moon roof   Turns the lights off Turns the door position on/off Turns the door position on Turns the lights on/off Turns the lights on Front personal lights Vehicles without moon roof Vehicles with moon roof...
Page 550: Rear Interior Light
6-2. Using the interior lights Rear interior light Turns the switch to the door position (door linked) Operation is linked with the front interior light main switch. When the switch is off, the light does not illu- minate. Turns the light on ●...
Page 551: List Of Storage Features
6-3. Using the storage features List of storage features Bottle holders/door pockets Auxiliary boxes (P. 555) (P. 553) Seat back pockets (P. 556) Cup holders (P. 553) Console box (P. 552) Glove box (P. 552) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: •...
Page 552: Glove Box
6-3. Using the storage features Glove box Pull up the lever. The glove box light turns on when the tail lights are on. Console box Lift the lid. The tray slides forward/backward and can be removed. PRIUS_OM_OM47C35U_(U)
Page 553: Cup Holders/Bottle Holders/Door Pockets
6-3. Using the storage features Cup holders/bottle holders/door pockets Front cup holders ■ Rear cup holders ■ Pull down the armrest. Bottle holders/door pockets ■ Front doors Rear doors   PRIUS_OM_OM47C35U_(U)
Page 554 6-3. Using the storage features ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. WARNING Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 555: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes Type A (if equipped)  Press in the lid. The overhead console is useful for temporarily storing small items. Type B  Vehicles with the wireless char- ger: P. 567 Type C (if equipped) ...
Page 556: Seat Back Pockets
6-3. Using the storage features Seat back pockets (if equipped) Owner’s manual etc. can be stored in the left-side seatback pocket with the fastener. PRIUS_OM_OM47C35U_(U)
Page 557: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Deck Board Pull the lever upwards. Secure it with the grocery bag hooks. WARNING ● If the deck board is opened, close it before driving. In the event of sudden braking, an accident may occur due to an occupant being struck by the deck board or the items stored in the auxiliary box.
Page 558 6-3. Using the storage features Cargo hooks Vehicles with emergency tire puncture repair kit  Raise the hook to use. The cargo hooks are provided for securing loose items. Vehicles with spare tire  Open the deck board, then raise the hook to use. Return the deck board to its original position and close it.
Page 559 6-3. Using the storage features WARNING To avoid injury, always return the cargo hooks to their stowed positions when not in use. Grocery bag hooks When using the hooks, press the bottom side to lift it up. There also is a hook on the other side.
Page 560 6-3. Using the storage features Warning reflector storage space The warning reflector can be stowed on the center auxiliary box. (The warning reflector itself is not included as an original equipment) Vehicles with emergency tire Vehicles with emergency tire  ...
Page 561 6-3. Using the storage features Luggage cover (if equipped) Installing the luggage cover ■ Install one side of the luggage cover to the holder. While push- ing that side in, install the other side to the opposite holder. Using the luggage cover ■...
Page 562 6-3. Using the storage features Stowing the luggage cover (except vehicles with full-size spare ■ tire) Open the deck board and secure it with the grocery bag hooks. Store cover in the deck under box. Close the deck board. WARNING ●...
Page 563: Other Interior Features
6-4. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 564: Power Outlets
6-4. Using the other interior features Power outlets Please use as a power supply for electronic goods that use less than 12 V DC/10 A (power consumption of 120 W). Open the cover. ■ The power outlet can be used when The power switch is in ACCESSORY or ON mode.
Page 565: Usb Charging Ports
6-4. Using the other interior features USB charging ports The USB charging ports are used to supply 2.1 A of electricity at 5 V to external devices. The USB charging ports are for charging only. They are not designed for data transfer or other purposes. Depending on the external device, it may not charge properly.
Page 566 6-4. Using the other interior features ■ The USB charging ports can be used when The power switch is in ACCESSORY or ON mode. ■ Situations in which the USB charging ports may not operate correctly ● If a device which consumes more than 2.1 A at 5 V is connected ●...
Page 567: Wireless Charger
6-4. Using the other interior features Wireless charger (if equipped) A portable device can be charged by just placing Qi standard wireless charge compatible portable devices according to the Wireless Power Consortium, such as smart phones and mobile batteries, etc., on the charge area.
Page 568 6-4. Using the other interior features Using the wireless charger ■ Press power supply switch of the wireless char- ger. Switches on and off with each press of the power supply switch. When turned on, the operation indicator light (green) comes on. Even with the hybrid system off, the on/off state of the power supply switch is memorized.
Page 569 Handle the error based on the following table. Operation indicator Suspected causes Handling method light Flashing repeatedly Vehicle to charger com- Contact your Toyota once every second munication failure. dealer. (Orange) Remove foreign A foreign substance is substance...
Page 570 6-4. Using the other interior features ■ The wireless charger can be operated when The power switch is in ACCESSORY or ON mode. ■ Usable portable devices Qi standard wireless charge standard can be used on compatible devices. However, not all Qi standard devices and compatibility are guaranteed. Starting with mobile phones and smart phones, it is aimed for low power elec- trically supplied portable devices of no more than 5W.
Page 571 6-4. Using the other interior features ■ Certification for the wireless charger PRIUS_OM_OM47C35U_(U)
Page 572 6-4. Using the other interior features PRIUS_OM_OM47C35U_(U)
Page 573 6-4. Using the other interior features PRIUS_OM_OM47C35U_(U)
Page 574 6-4. Using the other interior features WARNING ■ Caution while driving When charging a portable device, for safety reasons, the driver should not operate the main part of the portable device while driving. ■ Caution regarding interference with electronic devices People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the...
Page 575 When other wireless keys (that emit radio waves) are being used nearby In addition, excluding the above-mentioned, when the charger does not per- form normally or the operation display lamp is flashing continuously, it is considered that the wireless charger is malfunctioning. Contact your Toyota dealer. ■...
Page 576: Armrest
6-4. Using the other interior features Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest, do not place too much strain on the arm- rest. Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook.
Page 577: Assist Grips
6-4. Using the other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 578: Garage Door Opener
6-4. Using the other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 579 6-4. Using the other interior features ® Programming the HomeLink ■ Steps through must be performed within 60 seconds, other- wise the indicator light will stop flashing and programming will not be able to be completed. ® Press and release the HomeLink button you want to program ®...
Page 580 6-4. Using the other interior features ® Test the HomeLink operation by pressing the newly pro- grammed button and observing the indicator light: ● Indicator light illuminates: Programming of a fixed code device has completed. The garage door or other device should oper- ®...
Page 581 6-4. Using the other interior features Press and hold the desired ® HomeLink button (inside the vehicle) for 2 seconds and release Repeat this sequence (press/hold/ release) up to 3 times to complete programming. If the garage door opener motor operates when the ®...
Page 582 6-4. Using the other interior features ® Reprogramming a single HomeLink button ■ When the following procedure is performed, buttons which already have devices registered to them can be overwritten: ® With one hand, press and hold the desired HomeLink button.
Page 583 6-4. Using the other interior features ® Erasing the entire HomeLink memory (all three codes) Press and hold the 2 outside but- tons for 10 seconds until the ® HomeLink indicator light changes from continuously lit orange to rapidly flashing green. If you sell your vehicle, be sure to erase the programs stored in the ®...
Page 584 For vehicles sold in Canada  ■ When support is necessary Visit on the web at www.homelink.com/toyota or call 1-800-355-3515. WARNING ■ When programming a garage door or other remote control device The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm.
Page 585: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior..586 Cleaning and protecting the vehicle interior... 592 7-2. Maintenance Maintenance requirements ....595 General maintenance..598 Emission inspection and maintenance (I/M) programs......601 7-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 586: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 587 7-1. Maintenance and care ■ Note for a smart key system If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In that case, follow the fol- lowing correction procedures to wash the vehicle: ●...
Page 588 ■ Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 589 7-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 590 Failure to observe these precautions may result in damage to the decorative resin parts or wheels. • Do not remove the decorative resin parts When decorative resin parts removal is necessary, contact your Toyota dealer. • Do not hold the tire by the decora- tive resin parts to lift up or carry the tire.
Page 591 7-1. Maintenance and care NOTICE ■ When using a high pressure car wash ● When washing the vehicle, do not let water of the high pressure washer hit directly or the vicinity of the camera. Due to the shock from the high pres- sure water, it is possible the device may not operate as normal.
Page 592: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 593 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 594 Water may also cause the body to rust. ■ When cleaning the inside of the windshield (vehicles with Toyota Safety Sense P) Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
Page 595: Maintenance
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 596 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 597 7-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the 12-volt battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm.
Page 598: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 599 7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Hybrid transmission • When parked on a slope and the shift position “Park” mechanism is in P, is the vehicle securely stopped? •...
Page 600 7-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock system work prop- Engine hood erly? • There should not be any signs of fluid leakage Fluid leaks after the vehicle has been parked. •...
Page 601: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 602: Do-It-Yourself Service
(P. 618) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology Engine/power For the U.S.A.:...
Page 603 7-3. Do-it-yourself maintenance Items Parts and tools Tire inflation • Tire pressure gauge pressure • Compressed air source (P. 632) • Water or washer fluid containing antifreeze (for win- Washer fluid ter use) (P. 620) • Funnel (used only for adding water or washer fluid) WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized.
Page 604 7-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. PRIUS_OM_OM47C35U_(U)
Page 605: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull the auxiliary catch lever to the left and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 606 7-3. Do-it-yourself maintenance WARNING ■ When closing the hood When closing the hood, take extra care to prevent your fingers etc. from being caught. ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury.
Page 607: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 608: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir 12-volt battery (P. 614) (P. 612) Power control unit coolant Fuse boxes (P. 653) reservoir (P. 612) Engine oil level dipstick Radiator (P. 614) (P. 609) Condenser (P. 614) Engine oil filler cap (P. 610) Electric cooling fans Brake fluid reservoir Washer fluid tank (P.
Page 609 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 610 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 611 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 612 7-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the hybrid system is cold. Engine coolant reservoir ■ Reservoir cap “FULL” line “LOW” line If the level is on or below the “LOW”...
Page 613 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine/power control unit coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 614 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 615 ● Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 616 7-3. Do-it-yourself maintenance WARNING ■ Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: ●...
Page 617 7-3. Do-it-yourself maintenance WARNING ■ When disconnecting the 12-volt battery Do not disconnect the negative (-) terminal on the body side. The discon- nected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or serious injury. NOTICE ■...
Page 618 7-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Slide and lift up the rubber strip to partly remove it as shown. Disconnect the claws and remove the service cover.
Page 619 7-3. Do-it-yourself maintenance Remove the reservoir cap. Add brake fluid slowly while checking the fluid level. Make sure to check the fluid type and prepare the necessary item. SAE J1703 or FMVSS No.116 DOT 3 or SAE J1704 Fluid type or FMVSS No.116 DOT 4 brake fluid Items Clean funnel...
Page 620 7-3. Do-it-yourself maintenance Washer fluid Open the lid. Vehicles with the level gauge: Check the washer fluid level on the level gauge. “NORMAL” “LOW” If the washer fluid level is at “LOW”, add washer fluid. PRIUS_OM_OM47C35U_(U)
Page 621 7-3. Do-it-yourself maintenance ■ Using the gauge (if equipped) The washer fluid level can be checked by observing the position of the level on the liquid-covered holes in the gauge. If the level falls below the second hole from the bottom (the “LOW” position), refill Current the washer fluid.
Page 622: Tires
7-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 623 Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the same interval as tire inspection. Do not fail to initialize the tire pressure warning system after tire rota- tion.
Page 624 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 625) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized when the ■...
Page 625 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 626 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 627 7-3. Do-it-yourself maintenance ■ Tire types Summer tires ● Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 628 In the following cases, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • When a replacement tire is used, the system may not operate cor- rectly due to the structure of the replacement tire.
Page 629 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the initialization of the system, the tire pressure warning light does not flash 3 times and the setting message does not appear on the multi-information display.
Page 630 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 631 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 632: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 762) PRIUS_OM_OM47C35U_(U)
Page 633 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 634 7-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 635: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 636 7-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 637 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 638: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Replacing the air conditioning filter Turn the power switch off. Open the glove box and slide off the damper. Push in each side of the glove box to disconnect the claws, and then slowly and fully open the glove box while supporting...
Page 639 7-3. Do-it-yourself maintenance Remove the filter cover. Unlock the filter cover. Move the filter cover in the direction of the arrow, and then pull it out of the claws. Remove the filter case. Remove the air conditioning fil- ter from the filter case and replace it with a new one.
Page 640 7-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...
Page 641: Cleaning The Hybrid Battery (Traction Battery) Air Intake Vent And Filter
7-3. Do-it-yourself maintenance Cleaning the hybrid battery (traction bat- tery) air intake vent and filter To prevent the fuel economy from being affected, visually inspect the hybrid battery (traction battery) air intake vent peri- odically for dust and clogs. If it is dusty or clogged or if “Mainte- nance required for Traction battery cooling parts See owner’s manual”...
Page 642 7-3. Do-it-yourself maintenance Remove the air intake vent cover. Pull the cover as shown in the illustration to disengage the 5 claws, starting from the claw in the upper right cor- ner. Pull the cover toward the front of the vehicle to remove Remove the air intake vent fil- ter.
Page 643 7-3. Do-it-yourself maintenance Reinstall the filter to the cover. Engage the filter to the 2 claws as shown in the illus- tration. Engage the 1 claw to install the filter. Make sure that the filter is not crooked or deformed when install- ing it.
Page 644 It may take approximately 20 minutes after the hybrid system is started until the warning message disappears. If the warning message does not disap- pear, have the vehicle inspected by your Toyota dealer. WARNING ■...
Page 645 ● Carefully handle the removed filter so that it will not be damaged. If the fil- ter is damaged, have it replaced with a new filter by your Toyota dealer. ● Make sure to reinstall the filter and cover to their original positions after cleaning.
Page 646: Wiper Insert Replacement
7-3. Do-it-yourself maintenance Wiper insert replacement When replacing the wiper insert, perform the following proce- dure to operate each wiper. Windshield wipers Windshield wiper blade removal and installation ■ While securely supporting the wiper blade connection by hand, press the lock knob to release the lock, and then pull out the wiper blade.
Page 647 7-3. Do-it-yourself maintenance Pull out the end of the wiper insert from the slit, and then pull out the rest of the wiper insert. When installing a new wiper insert, perform the procedure in reverse. After installation, check that the end of the wiper insert is installed all the way to the end of the cap.
Page 648 7-3. Do-it-yourself maintenance Pull the wiper insert out past the stopper on the wiper blade, and then continue to pull until it is completely removed. Lightly grasp between the claws of the wiper blade to allow the wiper insert to lift up, making it easier to remove.
Page 649 Wiper blade and wiper insert handling Improper handling may result in damage to the wiper blades or wiper insert. If you have any concerns about replacing the wiper blades or wiper insert your- self, contact your Toyota dealer. ■ Front wiper blade cap The cap cannot be removed, as it is integrated with the front wiper blade.
Page 650: Electronic Key Battery
7-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery Release the lock and take out the mechanical key. Remove the cover.
Page 651 When installing, reverse the steps listed. ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
Page 652 7-3. Do-it-yourself maintenance WARNING ■ Removed battery and other parts These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury. NOTICE ■...
Page 653: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the power switch off. Open the fuse box cover. Engine compartment type A fuse box ...
Page 654 7-3. Do-it-yourself maintenance Remove the fuse. Only type A fuse can be removed using the pullout tool. Check if the fuse is blown. Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing.
Page 655 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 658) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 656: Headlight Aim
7-3. Do-it-yourself maintenance Headlight aim Vertical movement adjusting bolts Adjustment bolt A Adjustment bolt B Before checking the headlight aim Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed. Park the vehicle on level ground. Sit in the driver’s seat.
Page 657 Turn bolt B the same number of turns and in the same direction as step If the headlight cannot be adjusted using this procedure, take the vehi- cle to your Toyota dealer to adjust the headlight aim. PRIUS_OM_OM47C35U_(U)
Page 658: Light Bulbs
As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 764)
Page 659 7-3. Do-it-yourself maintenance Bulb locations Front ■ 1, 2 Parking light (bulb type) Front side marker light : If equipped : The location of the parking lights may differ depending on the grade, etc. Rear ■ Back-up light Rear side marker light Rear turn signal light PRIUS_OM_OM47C35U_(U)
Page 660 7-3. Do-it-yourself maintenance Replacing light bulbs Parking lights (bulb type) (if equipped) ■ Remove the clips and the engine compartment cover. There are two types of clips used, which vary depending on the vehicle. Type A Type B Turn the bulb base counter- clockwise.
Page 661 7-3. Do-it-yourself maintenance Front side marker lights ■ For the right side only: Remove the clip and slide the washer tank inlet pipe to the right. To prevent damage to the cover, protect the tip of the screwdriver with a rag. Turn the bulb base counter- clockwise.
Page 662 7-3. Do-it-yourself maintenance Rear turn signal lights, back-up lights and rear side maker ■ lights Open the back door. Insert a screwdriver into the cover on the side of the light and detach the claws indicated by the dotted lines near the exterior of the vehicle.
Page 663 7-3. Do-it-yourself maintenance Turn the bulb base counterclockwise. Back-up light Rear turn signal light   Rear side maker light  PRIUS_OM_OM47C35U_(U)
Page 664 7-3. Do-it-yourself maintenance Remove the light bulb. Back-up light Rear turn signal light   Rear side maker light  PRIUS_OM_OM47C35U_(U)
Page 665 7-3. Do-it-yourself maintenance Install a new light bulb then install the bulb base to the light unit by inserting it and turning the bulb base clockwise. Back-up light Rear turn signal light   Rear side maker light  PRIUS_OM_OM47C35U_(U)
Page 666 7-3. Do-it-yourself maintenance Align the grooves on the light unit with the claws, and insert the light unit straight so that the 2 pins on the light unit fit into the holes. Confirm that the light unit is completely secured. Install the 2 screws.
Page 667 ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water have built up on the inside of the lens.
Page 668 7-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
Page 669: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ..670 If your vehicle has to be stopped in an emergency ...... 671 If the vehicle is trapped in rising water ..... 672 8-2. Steps to take in an emergency If your vehicle needs to be towed ......
Page 670: 8-1. Essential Information
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 671: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 672: If The Vehicle Is Trapped In Rising Water
: Contact your Toyota dealer or aftermarket accessory manufacturer for fur- ther information about an emergency hammer. : Vehicles with laminated glass ■...
Page 673 8-1. Essential information ■ How to distinguish laminated glass When looking from the cross-sectional view point, laminated glass is two sheets of glass pasted together. Laminated glass Tempered glass PRIUS_OM_OM47C35U_(U)
Page 674: 8-2. Steps To Take In An Emergency
In the following situations, it is not possible to be towed by another vehicle using cables or chains, as the front wheels may be locked due to the parking lock. Contact your Toyota dealer or commercial towing service. ● There is a malfunction in the shift control system. (P. 244, 699) ●...
Page 675 8-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front (2WD models) From the front (AWD models)  ...
Page 676 8-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. Front If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 677 Shift the shift position to N and release the parking brake. : If the shift position cannot be changed or the current shift position can not be confirmed, contact your Toyota dealer or commercial tow- ing service before towing. PRIUS_OM_OM47C35U_(U)
Page 678 8-2. Steps to take in an emergency ■ While towing If the hybrid system is off, the power assist for the brakes and steering will not function, making steering and braking more difficult. ■ Wheel nut wrench Wheel nut wrench is installed in luggage compartment. (P. 703, 722) ■...
Page 679 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle 2WD models  Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 680 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ While towing ● When towing using cables or chains, avoid sudden starts, etc. which place excessive stress on the towing eyelets, cables or chains. The towing eye- lets, cables or chains may become damaged, broken debris may hit peo- ple, and cause serious damage.
Page 681: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 682: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or (U.S.A.) • The brake system is malfunctioning  Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- (Canada) cle may be dangerous. Brake system warning light (yellow indicator) Indicates a malfunction in: •...
Page 683 Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; or • The seat belt pretensioner system  Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: •...
Page 684  Immediately stop the vehicle in a safe place. (P. 746) • When the light comes on without flashing: Indicates a malfunction in the exhaust heat recirculator system  Have the vehicle inspected by your Toyota dealer immediately. PKSB OFF indicator Indicates a malfunction in the Parking Support Brake func- tion ...
Page 685 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system (P. 689)  Have the system checked by your Toyota dealer. “AFS OFF” indicator Indicates a malfunction in the adaptive front-lighting sys-  Have the vehicle inspected by your Toyota dealer...
Page 686  Release the accelerator pedal and depress the brake pedal. Indicates a malfunction in the Brake Override System (with warning buzzer)  Have the vehicle inspected by your Toyota dealer immediately. Drive-Start Control Indicates that the shift position was changed and Drive-...
Page 687 8-2. Steps to take in an emergency : Brake system warning buzzer: When there is a possible problem that could affect braking performance, the warning light will come on and a warning buzzer will sound. : Low engine oil pressure warning buzzer: A buzzer also sounds continuously for approximately 30 seconds at maxi- mum in addition to the low engine oil pressure warning light when the “READY”...
Page 688 If it is, tighten it securely. The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. PRIUS_OM_OM47C35U_(U)
Page 689 1 minute If the tire pressure warning light frequently comes on after blinking for 1 minute when the power switch is turned to ON mode, have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 690 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. ●...
Page 691 8-2. Steps to take in an emergency WARNING ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 692 8-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly Do not install tires with different specifications or makers, as the tire pressure warning system may not operate properly. PRIUS_OM_OM47C35U_(U)
Page 693: If A Warning Message Is Displayed
If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer. : The master warning light may not come on or flash when a warning mes- sage is displayed.
Page 694 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 695 The Open door warning light comes on. (P. 684) ■ If “Visit Your Dealer” is shown The system or part shown on the multi-information display is malfunctioning. Have the vehicle inspected by your Toyota dealer. ■ If a message about an operation is shown ●...
Page 696 ● If “Engine Oil Pressure Low” is shown, this may be a malfunction. Immedi- ately stop the vehicle in a safe place and contact your Toyota dealer. ● If the following messages are shown, there may be a malfunction. Immedi- ately have the vehicle inspected by your Toyota dealer.
Page 697 ■ If “Shift System Malfunction See Owner’s Manual” is shown Indicates a malfunction in the shift control system. Immediately have the sys- tem inspected by your Toyota dealer. The system may not operate properly. ■ If “Low 12-Volt Battery Apply Parking Brake Securely While Parking See Owner’s Manual”...
Page 698 8-2. Steps to take in an emergency ■ If “Shift to Before Exiting Vehicle” is shown Message is displayed when the driver’s door is opened without turning the power switch to off with the shift position in any position other than P. Shift the shift position to P.
Page 699 8-2. Steps to take in an emergency ■ If “Maintenance Required Soon” is displayed (U.S.A. only) Indicates that all maintenance according to the driven distance on the mainte- nance schedule should be performed soon. Comes on approximately 4500 miles (7200 km) after the message has been reset.
Page 700 Have the vehicle inspected by your Toyota dealer immediately. ● Continuing to drive the vehicle without having the hybrid battery (traction battery) inspected will cause the hybrid system not to start. ● If the hybrid system does not start, contact your Toyota dealer immedi- ately. PRIUS_OM_OM47C35U_(U)
Page 701: If You Have A Flat Tire (Vehicles Without Spare Tire)
After temporar- ily repairing the tire with the kit, have the tire repaired or replaced by your Toyota dealer. WARNING ■...
Page 702 A flat tire that cannot be repaired with the emergency tire puncture repair kit In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact your Toyota dealer. ● When the tire is damaged due to driving without sufficient air pressure ●...
Page 703 8-2. Steps to take in an emergency Location of the emergency tire puncture repair kit and tools 2WD models  Jack handle Emergency tire puncture repair kit Jack (Use of the jack: P. 707) Towing eyelet Wheel nut wrench PRIUS_OM_OM47C35U_(U)
Page 704 8-2. Steps to take in an emergency AWD models  Towing eyelet Emergency tire puncture repair kit Jack handle Jack Wheel nut wrench (Use of the jack: P. 707) PRIUS_OM_OM47C35U_(U)
Page 705 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Hose Power plug Air release cap Air pressure gauge Sticker Compressor switch PRIUS_OM_OM47C35U_(U)
Page 706 8-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Pull up the handle to open the deck board. Secure the deck board using the grocery bag hooks. (P. 559) Take out the emergency tire puncture repair kit. 2WD models: If the luggage cover (if equipped) is stowed, turn over the tonneau cover to take out the emergency tire puncture repair kit.
Page 707 8-2. Steps to take in an emergency ■ Taking out the jack Unhook the tightening strap and take out the jack. 2WD models AWD models ■ Storing the jack Place the jack in the same direction as the mark next to the storage space.
Page 708 8-2. Steps to take in an emergency Emergency repair method Take out the repair kit from the plastic bag. Remove the valve cap from the valve of the punctured tire. Extend the hose. Remove the air release cap from the hose. Attach the sticker enclosed with the bottle on the specified loca- tions.
Page 709 8-2. Steps to take in an emergency Make sure that the compressor switch is off. Lift the rubber stopper on the compressor. Remove the power plug from the compressor. PRIUS_OM_OM47C35U_(U)
Page 710 8-2. Steps to take in an emergency Connect the power plug to the power outlet socket. (P. 564) Connect the bottle to the com- pressor. As shown in the illustration, insert the bottle securely into the com- pressor until the upper side of the mark on the bottle is aligned with the upper end of the notch.
Page 711 8-2. Steps to take in an emergency Check the specified tire inflation pressure. Tire inflation pressure is specified on the label on the driver’s side pillar as shown. (P. 762) Start the hybrid system. (P. 241) To inject the sealant and inflate the tire, turn the compressor switch on.
Page 712 25 minutes, the tire is too damaged to be repaired. Turn the compressor switch off and contact your Toyota dealer. • If the tire inflation pressure exceeds the specified air pressure, let out some air to adjust the tire inflation pressure. (P. 715, 762)
Page 713 19 psi (130 kPa, 1.3 kgf/cm bar): The puncture cannot be repaired. Contact your Toyota dealer. If the tire inflation pressure is 19 psi (130 kPa, 1.3 kgf/cm or bar) or higher, but less than the specified air pres- sure: Proceed to step If the tire inflation pressure is the specified air pressure (P.
Page 714 Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 50 mph (80 km/h) to the nearest Toyota dealer that is less than 62 miles (100 km) away for tire repair or replacement. When having the tire repaired or replaced, make sure to tell the Toyota dealer that the sealant is injected.
Page 715 8-2. Steps to take in an emergency ■ If the tire is inflated to more than the specified air pressure Disconnect the hose from the valve. Install the air release cap to the end of the hose and push the protrusion on the air release cap into the tire valve to let some air out.
Page 716 The sealant has a limited life span. The expiry date is marked on the bottle. The sealant should be replaced before the expiry date. Contact your Toyota dealer for replacement. ● The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire.
Page 717 8-2. Steps to take in an emergency WARNING ■ Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 718 8-2. Steps to take in an emergency WARNING ■ When fixing the flat tire ● Stop your vehicle in a safe and flat area. ● Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
Page 719 8-2. Steps to take in an emergency WARNING ■ Driving to spread the liquid sealant evenly Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury.
Page 720 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 721: If You Have A Flat Tire (Vehicles With Spare Tire)
8-2. Steps to take in an emergency If you have a flat tire (vehicles with spare tire) Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 622 WARNING ■...
Page 722 8-2. Steps to take in an emergency Location of the spare tire, jack and tools Vehicles with compact spare tire  Wheel nut wrench Jack Jack handle Spare tire Towing eyelet PRIUS_OM_OM47C35U_(U)
Page 723 8-2. Steps to take in an emergency Vehicles with full-size spare tire  Jack handle Towing eyelet Wheel nut wrench Jack Spare tire PRIUS_OM_OM47C35U_(U)
Page 724 8-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Only use the tire jack that comes with this vehicle for replacing a flat tire.
Page 725 8-2. Steps to take in an emergency Taking out the jack Pull up the handle to open the deck board. Secure the deck board using the grocery bag hooks. (P. 559) Unhook the tightening strap and take out the jack. PRIUS_OM_OM47C35U_(U)
Page 726 8-2. Steps to take in an emergency Taking out the spare tire Open and secure the deck board. (P. 725) Remove the tray. Vehicles with compact spare tire: If the luggage cover is stowed (P. 562) , remove both the tray and luggage cover. Vehicles with compact spare Vehicles with full-size spare ...
Page 727 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 728 8-2. Steps to take in an emergency Turn the tire jack portion hand until the center of the recessed portion of the jack is in contact with the center of the jack point. Jack point Assemble the jack handle and the wheel nut wrench as shown in the illustration.
Page 729 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 730 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 731 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) For vehicles with the wheel ornament: When reinstalling an original wheel or installing a full- size spare tire, reinstall the wheel ornament.
Page 732 8-2. Steps to take in an emergency ■ The compact spare tire (if equipped) ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 733 8-2. Steps to take in an emergency WARNING ■ When using the compact spare tire (if equipped) ● Remember that the spare tire provided is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle. Do not use more than one compact spare tire simultaneously.
Page 734 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
Page 735: If The Hybrid System Will Not Start
8-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate procedure: The hybrid system will not start even though the correct starting procedure is being followed.
Page 736 ● The 12-volt battery may be discharged. (P. 740) ● One or both of the 12-volt battery terminals may be disconnected. (P. 614) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 737: If The Electronic Key Does Not Operate Properly
(turn and hold) Turning the key rearward unlocks the driver’s door. Turning the key once again within 3 seconds unlocks the other doors. : If equipped : This setting must be customized at your Toyota dealer. (P. 780) PRIUS_OM_OM47C35U_(U)
Page 738 8-2. Steps to take in an emergency Starting the hybrid system Depress the brake pedal. Touch the Toyota emblem side of the electronic key to the power switch. When electronic detected, a buzzer sounds and the power switch will turn to ON mode.
Page 739 8-2. Steps to take in an emergency ■ Stopping the hybrid system Set the parking brake, shift the shift position to P and press the power switch as you normally do when stopping the hybrid system. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 740: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid sys- tem if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 741 Maintain the engine speed of the second vehicle and start the hybrid system of your vehicle by turning the power switch to ON mode. Make sure the “READY” indicator comes on. If the indicator light does not come on, contact your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 742 ■ When the 12-volt battery is removed or discharged ● Information stored in the ECU is cleared. When the 12-volt battery is depleted, have the vehicle inspected at your Toyota dealer. ● Some systems may require initialization. (P. 790) ■...
Page 743 • If the 20 hour rate capacity is low, even if the time period where the vehi- cle is not used is a short time, the 12-volt battery may discharge and the hybrid system may not be able to start. ● For details, consult your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 744 8-2. Steps to take in an emergency WARNING ■ When removing the 12-volt battery terminals Always remove the negative (-) terminal first. If the positive (+) terminal con- tacts any metal in the surrounding area when the positive (+) terminal is removed, a spark may occur, leading to a fire in addition to electrical shocks and death or serious injury.
Page 745 8-2. Steps to take in an emergency NOTICE ■ When handling jumper cables When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fans, etc. PRIUS_OM_OM47C35U_(U)
Page 746: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the hybrid system has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Toyota dealer. PRIUS_OM_OM47C35U_(U)
Page 747 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the hybrid system immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 748 “FULL” line “LOW” line Add coolant if necessary. Water can be used in an emer- gency if coolant is unavailable. If water was added in an emer- gency, have the vehicle inspected at your Toyota dealer as soon as possible. PRIUS_OM_OM47C35U_(U)
Page 749 Stop the hybrid system and contact your Toyota dealer. If the message is not displayed: The hybrid system temperature has dropped and the vehicle may be driven normally. However, if the message appears again frequently, contact your Toyota dealer. WARNING ■...
Page 750 8-2. Steps to take in an emergency NOTICE ■ When adding engine/power control unit coolant Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool coolant to a hot hybrid system too quickly can cause damage to the hybrid system.
Page 751: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 752 8-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 753: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.) ..754 Fuel information ....765 Tire information ....768 9-2. Customization Customizable features ..780 9-3. Initialization Items to initialize ....790 PRIUS_OM_OM47C35U_(U)
Page 754: 9-1. Specifications
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 180.1 in. (4575 mm) Overall width 69.3 in. (1760 mm) Without raised 57.9 in. (1470 mm) vehicle height models Overall height With raised vehi- 58.7 in. (1490 mm) cle height AWD models 58.1 in.
Page 755: Specifications
The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 756 9-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 1.8 L 4-cylinder (2ZR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.17  3.48 in. (80.5  88.3 mm) Bore and stroke Displacement 109.7 cu.in.
Page 757 9-1. Specifications Fuel 2WD models AWD models Fuel type Unleaded gasoline only Octane Rating 87 (Research Octane Number 91) or higher Fuel tank capacity 11.4 gal. 10.6 gal. (Reference) (43 L, 9.5 Imp.gal.) (40 L, 8.8 Imp.gal.) Electric motor (traction motor) Front Rear (AWD models) Permanent magnet...
Page 758 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: API SN/RC multigrade engine oil...
Page 759 9-1. Specifications How to read oil container label: API registered marks is added to some oil containers to help you select the oil you should use. PRIUS_OM_OM47C35U_(U)
Page 760 Do not use plain water alone. : The coolant capacity is a reference quantity. If replacement is necessary, contact your Toyota dealer. Ignition system (spark plug) Make DENSO FC16HR-CY9 0.035 in. (0.9 mm) NOTICE ■...
Page 761 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may damage the transmission of your vehicle. Rear differential (rear electric motor) (AWD models) Fluid capacity 1.3 qt. (1.2 L, 1.1 Imp.qt.)
Page 762 9-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Vehicles without spare tire ■ 15-inch tires (except ZVW51L-AHXBBA model  Tire size 195/65R15 91S Front 36 psi (250 kPa, 2.5 kgf/cm or bar) Tire inflation pressure (Recommended cold Rear 35 psi (240 kPa, 2.4 kgf/cm...
Page 763 9-1. Specifications Vehicles with spare tire ■ 15-inch tires (Type A)  195/65R15 91S, Tire size T125/70D17 98M (spare) Front 36 psi (250 kPa, 2.5 kgf/cm or bar) Tire inflation pressure (Recommended cold Rear 35 psi (240 kPa, 2.4 kgf/cm or bar) tire inflation pressure) Spare...
Page 764 9-1. Specifications Light bulbs Light bulbs Bulb No. Type Parking lights (bulb type) Front side maker lights Exterior Rear turn signal lights WY21W Back-up lights W16W Rear side maker lights  Vanity lights  Front interior/personal lights  Interior Rear interior light ...
Page 765: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 766 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 767 9-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
Page 768: Tire Information
9-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire  PRIUS_OM_OM47C35U_(U)
Page 769 9-1. Specifications Tire size (P. 770) DOT and Tire Identification Number (TIN) (P. 770) Location of treadwear indicators (P. 622) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Summer tires or all season tires (P.
Page 770 9-1. Specifications Typical DOT and Tire Identification Number (TIN) Type A Type B   DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identification mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year Manufacturer’s code : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 771 9-1. Specifications Tire dimensions ■ Section width Tire height Wheel diameter Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer PRIUS_OM_OM47C35U_(U)
Page 772 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 773 9-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 774 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation parked for three hours or more, or has not pressure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum inflation...
Page 775 9-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty 12-volt battery, and special trim A metal support for a tire or a tire and tube...
Page 776 9-1. Specifications Tire related term Meaning A breakdown of the bond between compo- Bead separation nents in the bead A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass...
Page 777 9-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall (b) The outward facing sidewall of an asym- metrical tire that has a particular side that...
Page 778 9-1. Specifications Tire related term Meaning A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that Radial ply tire extend to the beads are laid at substantially 90...
Page 779 9-1. Specifications Tire related term Meaning Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing...
Page 780: Customization Customizable Features
Entune Audio or Entune Premium Audio with Navigation, or at your Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the parking brake set and the shift position in P.
Page 781 9-2. Customization Changing using the Entune Audio (if equipped) ■ Press the “SETUP” button on the Entune Audio. Select “Vehicle” on the “Setup” screen and select “Vehicle Cus- tomization”. Various settings can be changed. Refer to the list of settings that can be changed for details.
Page 782 Settings that can be changed using the multi-information display Settings that can be changed using the Entune Audio or Entune Premium Audio with Navigation Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, – = Not available Hybrid system (P. 83) ■...
Page 783 9-2. Customization HUD (Head-up display) (P. 155) ■ Default Customized Function setting setting Route guidance – – : If equipped Door lock (P. 181, 737) ■ Default Customized Function setting setting Speed linked – Shift position Automatic door locking linked –...
Page 784 9-2. Customization Smart key system (P. 192) ■ Default Customized Function setting setting Smart key system – Smart door unlocking Driver’s door All the doors – Time elapsed before unlock- ing all the door when gripping 2 seconds 1.5 seconds –...
Page 785 9-2. Customization Power windows and moon roof (P. 214, 219) ■ Default Customized Function setting setting Mechanical key linked opera- – – tion (open) Mechanical key linked opera- – – tion (close) Wireless remote control linked – – operation (open only) Wireless remote control linked –...
Page 786 9-2. Customization Automatic light control system (P. 258) ■ Default Customized Function setting setting Time elapsed before 30 seconds 60 seconds – headlights turn off 90 seconds Light sensor sensitivity Level 0 Level -2 to 2 – Daytime running lights –...
Page 787 9-2. Customization S-APGS (Simple Advanced Parking Guidance System) ■ (P. 373) Default Customized Function setting setting Near Obstacle detection range Standard Slightly far – – Narrow Back-in parking space Standard Slightly wide – – Wide Narrow Parallel parking space Standard Slightly wide –...
Page 788 9-2. Customization Illumination (P. 548) ■ Default Customized Function setting setting Time elapsed before the inte- 15 seconds 7.5 seconds – rior lights turn off 30 seconds Operation after the power – – switch is turned off Operation when the doors are –...
Page 789 9-2. Customization ■ Vehicle customization ● When the Speed linked door locking function and the Shift position linked door locking function are both on, the door lock operates as follows. • When shifting the shift position to any position other than P, all the doors will be locked.
Page 790: 9-3. Initialization
9-3. Initialization Items to initialize The following items must be initialized for normal system opera- tion after such cases as the 12-volt battery being reconnected, or maintenance being performed on the vehicle. Item When to initialize Reference Power window When functioning abnormally P.
Page 791: For Owners
For owners Reporting safety defects for U.S. owners......792 Seat belt instructions for Canadian owners (in French) ....... 793 SRS airbag instructions for Canadian owners (in French) ....... 795 Headlight aim instructions for Canadian owners (in French) ....... 804 PRIUS_OM_OM47C35U_(U)
Page 792: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 793: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 794 Entretien et nettoyage Ceintures de sécurité ■ Avec un chiffon ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles ne présentent pas d’usure excessive, d’effilo- chage ou de coupures. AVERTISSEMENT ■...
Page 795: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian own- ers (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. PRIUS_OM_OM47C35U_(U)
Page 796 ◆ Coussins gonflables SRS avant Coussin gonflable SRS du conducteur/coussin gonflable SRS du passager avant Peuvent aider à protéger la tête et la poitrine du conducteur et du passager avant contre les impacts avec des composants inté- rieurs Coussin gonflable SRS de protection des genoux Peut aider à...
Page 797 Composants du système de coussins gonflables SRS Capteurs d’impact avant Contacteur de boucle de cein- ture de sécurité du passager Lampe témoin SRS, et voyants avant “AIR BAG ON” et “AIR BAG OFF” Coussins gonflables en rideau Coussin gonflable du passager Capteurs d’impact latéral...
Page 798 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la conception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 799 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS Observez les précautions suivantes en ce qui concerne les coussins gon- flables SRS. Les négliger pourrait occasionner des blessures graves, voire mortelles. ● Le conducteur et tous les passagers du véhicule doivent porter leur cein- ture de sécurité...
Page 800 Un bébé ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Toyota recommande vivement de placer et d’attacher correcte- ment tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 801 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas sur la planche de bord. ● Ne laissez pas un enfant se tenir face au coussin gonflable SRS du passager avant ni s’asseoir sur les genoux d’un passager avant.
Page 802 AVERTISSEMENT ■ Précautions relatives aux coussins gonflables SRS ● Ne fixez et n’appuyez rien sur des zones telles que la planche de bord, le tampon de volant ou encore la partie inférieure du tableau de bord. Ces objets peuvent se transformer en projectiles lorsque les coussins gon- flables SRS du conducteur, du passa- ger avant et de protection des genoux...
Page 803 SRS Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifica- tions suivantes sans d’abord consulter votre concessionnaire Toyota. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occasion- ner des blessures graves, voire mortelles.
Page 804: Headlight Aim Instructions For Canadian Owners (In French)
Headlight aim instructions for Canadian own- ers (in French) The following is a French explanation of headlight aim instruc- tions from the headlight aim section in this manual. Boulons de réglage vertical Boulon de réglage A Boulon de réglage B Avant de vérifier la portée des phares Assurez-vous que le réservoir de carburant du véhicule est plein et que la partie de carrosserie située autour des phares n’est pas...
Page 805 Tournez le boulon B du même nombre de tours et dans le même sens qu’à l’étape Si vous n’arrivez pas à régler vos phares en suivant cette procé- dure, apportez le véhicule chez votre concessionnaire Toyota afin qu’il règle la portée des phares. PRIUS_OM_OM47C35U_(U)
Page 806 PRIUS_OM_OM47C35U_(U)
Page 807: Index
Index What to do if... (Troubleshooting) ....808 Alphabetical index ..... 812 For vehicles with Entune Premium Audio with Navigation, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Hands-free system (for cellular phone) •...
Page 808 Toyota dealer. (P. 177) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 180) The doors cannot be locked or unlocked ● Is the electronic key battery weak or depleted? (P. 650) ●...
Page 809 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start ● Did you press the power switch while firmly depressing the brake pedal? (P. 241) ● Is the shift position in P? (P. 251) ●...
Page 810 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 687) ● The parking brake indicator is on Is the parking brake released? (P. 257) Depending on the situation, other types of warning buzzer may also sound.
Page 811 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Vehicles without spare tire Stop the vehicle in a safe place and repair the flat tire temporarily with the emergency tire puncture repair kit. (P. 701) ●...
Page 812: Alphabetical Index
Alphabetical index Alphabetical index Airbags ........36 Airbag operating conditions ..44 A/C ........526, 536 Airbag precautions for your Air conditioning filter ..... 638 child........39 Automatic air Airbag warning light ....683 conditioning system..526, 536 Correct driving posture ... 28 CLIMATE CONTROL....
Page 813 Alphabetical index Anti-lock brake system Automatic door locking (ABS) ........417 and unlocking systems ..184 Function ........ 417 Automatic High Beam ..... 263 Warning light......683 Automatic light control Approach warning ....324 system........261 Armrest........576 AUX port........439 Assist grips ......
Page 814 Alphabetical index ® Bluetooth audio ..... 482 Catch protection function..215 ® Bluetooth phone....484 CD player........454 Deleting the call history..504 Chains ........428 Making a call......487 Child restraint system....57 Managing the contacts..500 Fixed with a LATCH Message function....
Page 815 Alphabetical index Cleaning Aluminum wheels....587 Daytime running light Camera sensor ..... 287 system........261 Exterior ......... 586 Deck board....... 557 Hybrid battery (traction Defogger battery) air intake vent..641 Outside rear view Interior........592 mirrors ......530, 540 Radar sensor ......286 Rear window....
Page 816 Alphabetical index Doors Electric Power Steering Automatic door locking (EPS) ........418 and unlocking system..184 Function........ 418 Back door......187 Warning light......683 Door glasses......214 Electronic key ......176 Door lock....... 181 Battery-saving function ..194 Open door warning buzzer ... 684 If the electronic key does Open door warning light..
Page 817 Alphabetical index Engine........756 EPS (Electronic Power Accessory mode ....243 Steering) ........ 418 Compartment ......608 Function........ 418 Engine switch......241 Warning light......683 Exhaust gas precautions ..55 EV indicator ......127 Hood ........605 EV drive mode ......247 How to start the hybrid Event data recorder (EDR)..
Page 818 Alphabetical index Front turn signal lights High coolant temperature Replacing light bulbs..... 667 warning light......684 Turn signal lever ....256 High mounted stoplight Fuel Replacing......667 Capacity........ 757 High-voltage components ..87 Fuel gauge......116 Hill-start assist control ... 418 Information......
Page 819 Alphabetical index I/M test ........601 Jack Identification Positioning a floor jack..607 Engine........756 Vehicle-equipped Vehicle ........755 jack......703, 722 Ignition switch Jack handle...... 703, 722 (Power switch)....... 241 Jam protection function Auto power off function ..243 Moon roof ......
Page 820 Alphabetical index Language (multi-information Main display......115 display)........151 Maintenance LATCH system ......60 Do-it-yourself maintenance... 602 LDA (Lane Departure Alert General maintenance ... 598 with steering control).... 303 Maintenance data ....754 Lever Maintenance Auxiliary catch lever....605 requirements ...... 595 Hood lock release lever ..
Page 821 Alphabetical index Multi-information display..122 Outside temperature Air conditioning system display........116 settings screen ....144 Overhead console ....555 Audio system-linked Overheating ......746 display ........ 143 BSM (Blind Spot Monitor) ..337 Display contents ....122 P position switch..... 251 Drive information....
Page 822 Alphabetical index Power outlets ......564 Rear seat ........202 Power steering (Electric Rear side marker lights Power Steering system) ..418 Light switch......258 Warning light......683 Replacing light bulbs .... 662 Power switch......241 Wattage ........ 764 Auto power off function ..243 Rear turn signal lights Changing the power Replacing light bulbs ....
Page 823 Alphabetical index Seats......... 200, 202 Adjustment......200 S-APGS (Simple Advanced Adjustment precautions ..201 Parking Guidance Child seats/child restraint System) ........373 system installation....60 Safety Connect ......77 Cleaning ....... 592 Seat back pockets ....556 Front seats......200 Seat belts........
Page 824 Alphabetical index Side mirrors ......212 Stuck Adjustment......212 If the vehicle becomes BSM (Blind Spot Monitor) ..337 stuck........751 Folding ........212 Sun visors ........ 563 Heaters ......530, 540 Sunshade Side windows......214 Moon roof ......220 Water-repellent coating..
Page 825 Alphabetical index Power door lock switches ..183 Tire inflation pressure..... 632 Power switch......241 Maintenance data ....762 Power window switch.... 214 Warning light......685 Rear window wiper and Tire pressure warning washer switch..... 276 system........624 Rear window and outside Function........
Page 826 Emergency towing ....674 Vehicle data recordings.... 10 Towing eyelet......677 Vehicle identification Trailer towing ......239 number........755 Toyota Safety Sense P .... 283 Vehicle proximity notification Traction battery (hybrid system........84 battery) ........87 Vehicle Stability Control Traction control (TRAC)..417 (VSC) ........
Page 827 Alphabetical index Warning lights......107 Warning messages....693 ABS........683 Warning reflector..... 560 Brake Override System..686 Washer Brake system ......682 Checking....... 620 Charging system....682 Preparing and checking Drive-Start Control ....686 before winter ...... 427 Driver’s seat belt reminder Switch ......
Page 828 4.4 qt. Engine oil capacity (4.2 L, 3.7 Imp.qt.) (Drain and refill — reference) Without filter 4.1 qt. (3.9 L, 3.4 Imp.qt.) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: API SN/RC multigrade engine oil P. 758 PRIUS_OM_OM47C35U_(U)

This manual is also suitable for:

Prius c 2019

Toyota Prius 2019 Manual

Quick Links

Troubleshooting

Related Manuals for Toyota Prius 2019

Summary of Contents for Toyota Prius 2019
