Rangemaster Infusion 100 Induction User's Manual & Installation Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER GUIDE &
INSTALLATION INSTRUCTIONS
Infusion 100 Induction
U110729 - 03

Advertisement

Table of Contents
loading

Related Manuals for Rangemaster Infusion 100 Induction

Summary of Contents for Rangemaster Infusion 100 Induction

  • Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS Infusion 100 Induction U110729 - 03...
  • Page 2 Terms & Conditions 1. This is my Rangemaster is open to residents of UK mainland only, aged 18 years & over. 2. All entries should be submitted to the advertised e-mail address, or Rangemaster UK Facebook, Instagram or Twitter page using the advertised hashtag &...

  • Page 3: Table Of Contents

    Contents Before you start... Cooking tips Personal safety Cooking Table Electrical connection safety Cleaning your cooker Peculiar smells Ventilation Troubleshooting Maintenance Induction care Installation Oven care Dear Installer Oven Shelves (dependant on model) Safety Requirements and Regulations Hob care Provision of Ventilation Cooker care Location of Cooker Cooling fan...

  • Page 4: Before You Start

    Before you start... CAUTION: Your cooker should give you many years of A long term cooking process • trouble-free cooking if installed and operated has to be supervised from time to time. correctly. It is important that you read this A short term cooking process has to be section before you start.
  • Page 5 WARNING: THE APPLIANCE MUST BE Fig. 1.1 EARTHED. Note: The cooker must be connected to the correct electrical supply as stated on the voltage label on the cooker, through a suitable cooker control unit incorporating a double- 10 mm² max pole switch, having a contact separation of at least 3 mm in all poles.

  • Page 6: Peculiar Smells

    The appliance must be installed in Maintenance • accordance with the regulations in force Only a qualified service engineer • and only in a well ventilated space. should service the appliance and only approved spare parts should be used. It Failure to install the appliance correctly •...

  • Page 7: Induction Care

    • performance, we recommend the use of possible. Frost on frozen foods or moisture AGA Rangemaster Induction cookware. on fresh foods can cause hot fat to bubble If you decide to purchase an alternative up and over the sides of the pan. Carefully...
  • Page 8 change in temperature. Fig. 1.3 Only certain types of stainless steel, • enamelled steel or cast iron cookware with enamelled bases are suitable for induction hob cooking. Take care NOT to scratch the surface when • placing cookware on the glass panel. Fig.

  • Page 9: Oven Care

    DO NOT place anything between the • Fig. 1.8 base of the pan and the hob surface (e.g. asbestos mats, aluminium foil, wok stand). Take care NOT to place metallic objects • ArtNo.324-0001 Steam burst such as knives, forks, spoons and lids on the hob surface since they can get hot.

  • Page 10: Oven Shelves (Dependant On Model)

    Accidental damage may cause the door Hob care • glass panel to fracture. NEVER allow anyone to climb or stand on • the hob. Keep oven vent ducts unobstructed. • DO NOT use the hob surface as a cutting DO NOT use harsh abrasive cleaners or •...

  • Page 11: Cooling Fan

    DO NOT put the griddle plate in a Cooling fan • dishwasher. This appliance may have a cooling fan. When the grill or oven is in operation the fan will run NEVER use caustic or abrasive cleaners as • to cool the fascia and control knobs. these will damage the surface.

  • Page 12: Cooker Overview

    Cooker Overview Fig. 2.1 The 100 induction cooker (Fig. 2.1) has the following Fig. 2.2 features: 5 induction cooking zones A control panel A separate glide-out grill A programmable fan oven Tall fan oven The Hob Use only pans that are suitable for induction hobs. We recommend stainless steel, enamelled steel pans or cast iron pans with enamelled bases.
  • Page 13 Make sure that the base of the pan is clean and dry to prevent Fig. 2.3 any residue burning onto the hob panel. This also helps prevent scratches and deposits. Always use pans that are the same size as (or slightly larger than) the areas marked on the hob.
  • Page 14 Residual Heat Indicator, H Automatic heat-up time at Power Level 100% (min:sec) After use, a cooking zone will remain hot for a while as heat 0:48 dissipates. When a cooking zone is switched off the residual heat indicator symbol [H ], will appear in the display. This 2:24 shows that the cooking zone temperature is above 60 °C and 3:50...
  • Page 15 Low Temperature Setting, L1/L2 Maximum Operating Time Power Level This function should only be used when cooking from cold. 2 hours L1 and L2 Each cooking area is equipped with 2 low temperature 6 hours settings: 6 hours 5 hours •...

  • Page 16: The Glide-Out Grill

    Overheat Function Fig. 2.9 This function identifies when the temperature of the pan rises rapidly and works to maintain a safe level of pan temperature. It should not interfere with normal cooking. Cookware with bases that become distorted (Fig. 2.2) when heated may interfere with the operation of the Overheat Function.

  • Page 17: The Ovens

    The Ovens Fig. 2.12 The clock must be set to the time of day before the ovens will work. See the following section on ‘The Clock’ for instructions on setting the time of day. References to ‘left-hand’ and ‘right-hand’ ovens apply as Fan oven viewed from the front of the appliance.

  • Page 18: Accessories

    Accessories Fig. 2.17 Shelf guard Oven Shelves – Left-hand (Main) Oven The oven shelves (Fig. 2.17) are retained when pulled forward but can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by Front the shelf stop bumps in the oven sides (Fig.

  • Page 19: Button Clock

    3 Button clock Using the clock Fig. 3.1 You can use the clock to turn the programmable oven on and off. The clock must be set to the time of day before the oven will work. NOTE: When using the timer functions, first set the clock as ArtNo.306-0001 - 3-button clock required before setting the oven temperature.
  • Page 20 When the ‘stop time’ is reached an alarm will sound and Fig. 3.7 the oven will stop working. The word ‘AUTO’ will flash on the display (Fig. 3.6). Press any button to stop the alarm and return to manual cooking. If the alarm is not stopped, it will stop ArtNo.306-0001 - 3-button clock automatically after 7 minutes.

  • Page 21: Cooking Tips

    Cooking tips Using Your Induction Cooker General oven tips If you have not used an induction cooker before please be The wire shelves should always be pushed firmly to the back aware of the following: of the oven. • Make sure that the pans you have or buy are suitable Baking trays with food cooking on them should be placed for use on the induction hob.

  • Page 22: Cooking Table

    Cooking Table The oven control settings and cooking times given in the table below are intended to be used as a Top (T) guide only. Individual tastes may require the temperature to be altered to provide a preferred result. ArtNo.050-0007 Centre (C) Oven shelf positions Food is cooked at lower temperature in a fan oven than in a conventional oven.

  • Page 23: Cleaning Your Cooker

    Cleaning your cooker Isolate the electricity supply before carrying out any Fig. 6.1 major cleaning. Then allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. DO NOT mix different cleaning products –...
  • Page 24 Grills Fig. 6.2 ArtNo.331-0003 Grill frame out, no pan The grill pan and trivet should be washed in hot soapy water. After grilling meats or any foods that soil, leave to soak for a few minutes immediately after use. Stubborn particles may be removed from the trivet using a nylon brush.
  • Page 25 Glass fronted door panels Fig. 6.5 The oven door front panels can be taken off so that the glass panels can be cleaned. Move the cooker forward to gain access to the sides (see the ‘Moving the Cooker’ section under ‘Installation’).
  • Page 26 Cleaning table Cleaners listed (Table 6.1) are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish...

  • Page 27: Troubleshooting

    Troubleshooting DocNo.050-0001 - Troubleshooting - Induction GENERIC Interference with and repairs to the hob MUST NOT The cooling fan be carried out by unqualified persons. Do not try The induction hob incorporates a cooling fan. This cooling to repair the hob as this may result in injury and fan is active when either the grill or the oven(s) are on.
  • Page 28 The oven light is not working Fig. 7.1 The bulb has probably blown. You can buy a replacement bulb (which is not covered under the guarantee) from most electrical stores. Ask for a 40 W – 230 V halogen lamp (G9) (Fig. 7.1). Before removing the existing bulb, turn off the power supply and make sure that the oven is cool.

  • Page 29: Installation

    INSTALLATION Check the appliance is electrically safe when you have finished. Installation Dear Installer You will need the following equipment to complete the cooker installation satisfactorily: Before you start your installation, please complete the details • Multimeter (for electrical checks). below, so that, if your customer has a problem relating to your installation, they will be able to contact you easily.

  • Page 30: Positioning The Cooker

    INSTALLATION Check the appliance is electrically safe when you have finished. Positioning the Cooker Fig. 8.1 Fig. 8.1 and Fig. 8.2 show the minimum recommended distance from the cooker to nearby surfaces. 75 mm min 650 mm min 75 mm min The cooker should not be placed on a base.

  • Page 31: Lowering The Two Rear Rollers

    INSTALLATION Check the appliance is electrically safe when you have finished. Lowering the Two Rear Rollers Fig. 8.5 To adjust the height of the rear of the cooker, first fit a 13 mm spanner or socket wrench onto the hexagonal adjusting nut (Fig.

  • Page 32: Electrical Connection

    INSTALLATION Check the appliance is electrically safe when you have finished. Electrical Connection Current Operated Earth Leakage Breakers The combined use of your induction cooker and other The cooker must be installed by a qualified electrician, in domestic appliances may cause nuisance tripping, so we accordance with the relevant national and local regulations.

  • Page 33: Final Fitting

    INSTALLATION Check the appliance is electrically safe when you have finished. Final Fitting Fig. 8.13 Fitting the 2-piece Plinth ArtNo.350-0010 - Fitting the plinth 1 (Kitchener) Fit the inner plinth to the bottom front of the cooker using the 4 or 5 screws provided (Fig. 8.13). Fit the outer plinth (2 screws, 1 each end) to the inner plinth.

  • Page 34: Circuit Diagrams

    Circuit Diagrams Earth On Terminal Block N(6) On Terminal Block N(4) INDUCTION UNIT DISPLAY L(2) L(3) w/br w/br INTERFACE On Terminal Block BOARD w/br w/br w/br Code Colour Code Description w/br White or brown Left-hand front element Left-hand back element Right-hand back element Right-hand front element Centre element...
  • Page 35 Oven P095199 P095199 P095199 The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Colour Grill energy regulator Cooling fan Blue Grill front switch Oven light switch Brown Grill elements Oven light...

  • Page 36: 10. Technical Data

    DATA BADGE LOCATION: Cooker back, serial number repeater badge below the oven door opening. COUNTRY OF DESTINATION: GB, IE. Connection Electric 230 / 400 V ~ 50 Hz 3N Dimensions Model Infusion 100 Induction Total height Min 905 mm Max 930 mm Total width 994 mm Total depth:...
  • Page 37 Hotplate Efficiency Data Brand Rangemaster Model Identification Infusion Size Type Induction Type of Hob Induction Number of electric zones Zone 1 - Ø cm 18.5 Heating Technology Energy Consumption (ECElectric cooking) - Wh/kg Zone 2 - Ø cm 15.5 Heating Technology Energy Consumption (ECElectric cooking) - Wh/kg Zone 3 - Ø...
  • Page 38 Oven Data Brand Rangemaster Model identification Infusion Mass Type of oven Electric Number of cavities Left-hand Efficiency Fuel type Electric Cavity type Fanned Power - conventional Power - forced air convection Volume Litres Energy consumption (electricity) - conventional kWh / cycle...
  • Page 39 • Has not been repaired by persons or organisations other than those authorised to act on behalf of AGA Rangemaster. Date of Purchase Exceptions: • Items not included under the free 1 year guarantee Installer’s Name &...
  • Page 40 Registered Office: c/o Aga Rangemaster, Meadow Lane, Long Eaton, Nottingham, NG10 2GD Rangemaster continuously seeks improvements in specification, design and production of products and thus, alterations take place periodically. Whilst every effort is made to produce up-to-date literature, this brochure should not be regarded as...
