Omron E5AK-T Instruction Manual

NOTICE
E5AK-T
9. If you remove the controller from its case, never
Digital Controller touch nor apply shock to the electronic parts
inside.
10. Do not cover the controller.
INSTRUCTION MANUAL
EN
11. Do not use the controller in the following places:
- Places subject to icing, condensation, dust or
Thank you for purchasing this
corrosive gas (especially sulfide gas or
OMRON product.
ammonia gas)
This manual primarily describes
- Places subject to vibration and large shocks
precautions required installing and
- Places subject to splashing liquid or oil
operating the digital controller. Before
atmosphere
operating the product, read this
- Places subject to intense temperature changes
manual thoroughly to acquire sufficient
- Places subject to heat radiation from a furnace.
knowledge of the product. Keep this
12. Be sure to wire properly with correct polarity of
manual for future reference.
terminals.
13. Avoid wiring near high voltage sources and power
OMRON Corporation
lines carrying large currents.
0691369-0B
12
To ensure safe and correct use of this M NAMES OF PARTS ON FRONT PANEL
product, also read the following
manuals:
• E5AK-T Digital Controller Program status
indicators
User's Manual
The above manuals can be obtained
from any OMRON sales office or Bar graph
PTN TIME
100
dealer.
Operation status
M UNPACKING indicators 0
%
OUT1 OUT2
SUB1 SUB2
Make sure that the package contains the
RUN
MANU RMT RST
following items. If all the items are not in HOLD RST
WAIT AT
the package or an item is damaged,
contact your dealer immediately.
RUN/RESET key
Display key
• E5AK-T -------------------------- 1
RUN/RST
• Mounting bracket ------------- 2
• Instruction Manual ------------ 1
PRECAUTIONS IN USING THE PRODUCT
M SETTING THE OUTPUT UNIT
When the product is used under the
circumstances or environment
below,ensure adherence to limitations
of the ratings and functions.Also,take
[OUT]
countermesures for safety precautions
E53-R
such as fail-safe installations.
E53-S
• Use under circumstances or OUT1
E53-Q
environment which are not described
E53-Q3
in the instruction manual. E53-Q4
OUT2
E53-C3
• Use for nuclear power control, railway,
E53-C3D
aircraft, vehcle, incinerator, medical
E53-V34
equipment,entertainment
E53-V35
equipment,safety device etc...
• Use for applications where death or
Bracket
serious property damage is possible
and extensive safety precautions are
required.
Press down on the hook on the top of the front panel
(part pointed with an arrow in the above drawing) and
PRECAUTIONS ON SAFETY
turn a screwdriver to loosen the screw on the lower
part of the front panel.
WARNING
M INSTALLATION
Incorrect handling may cause death or injury.
• Mounting Panels
Unit (mm)
WARNING
Do not touch the terminals while the power is ON.
This may cause an electric shock.
NOTICE
Items shown below are necessary for
safe usage.
120 min.
＋0.8
92
Please note them carefully.
0
1. Do not use the product in place
where explosive or flammable gases
may be present.
2. Never disassemble , repair or modify
the product.
3. Tighten the terminal screws properly.
4. Use the specified size solderless
terminals for wiring.
5. Use the product within the rated
Recommended panel thickness is 1 to 8 mm.
supply voltage.
6. Use the product within the rated load.
7. The life expectancy of the output
relay varies considerably according
North America
to its the output relay within its rated
OMRON ELECTRONICS LLC
load and electrical life expectancy, if
Phone:1-847-843-7900
the output relay is used beyond its
OMRON CANADA INC.
life expectancy, its contacts may
Phone: 1-416-286-6465
become fused or burned.
Phone : 1-514-636-6676
8. A switch or circuit breaker should be
(French Language)
provided close to this unit.
The switch or circuit breaker should
be within easy reach of the operator,
and must be marked as a
disconnecting means for this unit.
MAIN SPECIFICATIONS
- Supply voltage AC100-240V (-15% to +10%), 50/60 Hz,
16VA
and power AC24V (-15% to +10%), 50/60Hz, 12VA
consumption DC24V (-15% to +10%), 8W
- Input Thermocouple, platinum resistance
thermometer, current input, voltage input
- Control output According to output unit
- Auxiliary output 1a AC 250 V, 3A (resistive load)
- Control method ON/OFF or PID control
- Ambient temperature -10 to 55°C (For UL3121-1, IEC/EN61010-1,
Surrounding AirTemperature:50°C)
- Ambient humidity 35 to 85%
- Storage temperature -25 to 65°C
- Weight Approx. 450 g
- Enclosure ratings Front panel : NEMA4 for indoor use (IP66
equivalent)
- Setup environment Installation category II, Pollution degree 2.
(Conforming to IEC/EN61010-1, UL3121-1, CSA C22.2 No.1010.1)
- Altitude 2000m max.
- Recommended fuse T2A, AC250V, Time-lag, Low-breaking
capacity
• No.1 display: Displays process values or parameter symbol.
• No.2 display: Displays present set point, manipulated variable or
parameter settings.
• Pattern No.: Displays pattern No..
No.1 display
PV • Program status indicators: Indicate how the present-SP of the
8.8.8.8
operating step changes.
• Operation status indicators
Pattern No.
PTN SV
- OUT1: Lights when the "CONTROL OUTPUT 1" is ON.
7 8.8.8.8
- OUT2: Lights when the "CONTROL OUTPUT 2" is ON.
RMT HOLD MANU SUB1 SUB2
- SUB1: Lights when the "AUXILIARY OUTPUT 1" is ON.
OUT1 OUT2 RST AT WAIT No.2 display
- SUB2: Lights when the "AUXILIARY OUTPUT 2" is ON.
- MANU: Lights in the manual operation mode.
- RST: Lights when the control is in reset status.
A
M
- RMT: Lights during remote operation.
E5AK
- HOLD: Lights when the program is in hold status.
- WAIT: Lights when the program is in wait status.
- AT: Flashes during auto-tuning.
Down key Up key
• Bar graph: Displays pattern elapseing time %.
• RUN/RESET key: Switches between run and reset operation.
• Display key: Selects parameters.
• Down key: Each press returns the setting.
• Up key: Each press advances the setting.
M EXTERNAL DIMENSIONS (unit: mm)
96□
13.5
PV
8.8.8.8
PTN SV
7
PTN TIME 8.8.8.8
100
RMT HOLD MANU SUB1 SUB2
OUT1 OUT2 RST AT WAIT
0
%
RUN
RST
A
M
E5AK
Watertight packing
Setting is not required on the E5AK-TPRR □□ .
• Mounting the Controller
110 min.
＋0.8
92
0
(1) Attach the watertight packing from the terminal side and then insert
the controller to the panel.
(2) Fit the mounting bracket (supplied) into the grooves on the top and
bottom sides of the rear case.
(3) Alternately tighten the top and bottom screws on the mounting bracket
applying equal pressure a little at a time until the rachet rotates freely.
Europe
Asia / Pacific
OMRON EUROPE B.V. 欧姆龍（中国）有限公司 (中国)
(EUROPEAN H.Q.)
Phone: (8610)8391-3005
Phone: 31-23-56-81-300 歐姆龍亞洲有限公司 (香港)
Fax : 31-23-56-81-388
Phone: 852-2375-3827
台灣歐姆龍股有限公司總公司(台灣)
Phone: 886-2-2715-3331
韓国OMRON株式会社(大韓民国)
Phone: 82-2-512-0871(Korean)
Phone: 82-2-549-2766
(English/Japanese)
M WIRING TERMINALS
Basic insulation is used between the outputs (Between relay output and analog output)
If reinforced insulation is required between the outputs, connect to a device that does
not have exposed chargeable parts and whose basic insulation is suitable for the
maximum voltage used in the outputs.
AC100-240V
50/60Hz
16VA
10
or SOURCE
9
AC/DC24V
＋
8
50/60Hz
OUT1
12VA, 8W
7
−
＋
6
OUT2
5
−
4
SUB1
3
2
SUB2
1
M CABLE CONNECTIONS
• RS-232C interface: E5AK-TM01M
Host computer
RS-232C：25P
No.
1 FG
2 SD
3 RD
4 RS
5 CS
6 DR
100
20 ER
7 SG
• RS-422 interface: E5AK-TM02M
Host computer
RS-422
Shielded cable
RDA
RDB
SDA
SDB
SG
FG
• Up to 32 controllers including a host computer can be connected .
• The total cable length should not exceed 500 meters. Use shielded twisted pair leads (AWG28 min.) for the cables.
• Attach terminators to the controllers at both ends of a series of controllers connected in an open configuration. For example, in the configuration on the left, connect terminators to the
host computer and the unit No.30, and do not connect terminators to connector Nos. 0 to 29.
M ERROR DISPLAY
Input error
Memory error
A/D converter error
OMRON ASIA-PACIFIC PTE LTD.
(Singapore)
Phone: 65-6835-3011
OMRON ELECTRONICS PTY.LTD.
Calibration data error
(AUSTRALIA)
Phone: 02-9878-6377
Display range
over
● OPTION1
EV1 20
EV2 19
30 20 COM 18
31 32
OPTION2
29 19 OPTION1 Event input１／２
18
28
E5AK-T□B□
O
27 17
W
26 16 CT
● OPTION2
C
OPTION3
25 15
＋
14
24
13
23 V 4-20mA
RSP
＋
− −
22 12
−
4-20mA
33
21 11
mA Transfer output
＋
−
TC Pt E5AK-T□F□
＋
• Do not wire the terminals which are not used.
E5AK-T
• Only one controller can be connected to the host computer.
• The cable length should not exceed 15 meters.
RS-232C • Use shielded twisted pair leads (AWG28 min.) for the cables.
No.
20 SD
19 RD
18 SG
Shielded
cable
• RS-485 interface:E5AK-TM03M
Host computer
E5AK-T（No.0） E5AK-T（No.30）
RS-485
RS-422 RS-422
No. No.
Terminator ×２ −
（240Ω 1/2W）
32 SDA 32 SDA
＋
31 SDB 31 SDB
19 RDA 19 RDA
FG
20 RDB 20 RDB
18 SG 18 SG
Check the input wiring (incorrect,
Input is in error. disconnected, or short-circuited),
input type .
Internal memory is in error. Repair.
Internal circuits are in error. Repair.
The calibration data is in error. This
message is displayed for two seconds Repair.
when the power is turned ON.
This is not an error. This is displayed
when the display range is exceeded.
32
SDA
A
SDB 31 32
＋
B
SD 20 RDA 19 31
＋ A
RD 19 RDB 20 19
− B
SG 18 18 20
SG
RS-485
RS-232C RS-422
E5AK-T□01□ E5AK-T□02□ E5AK-T□03□
● OPTION3
＋
＋
30
EV3 26
L ＋
EV4 25
29
−
− COM 24
Event input３／４
E5AK-T□B□
A＜B："1" Mark
Shielded cable
A＞B："0" Space
Terminator（120Ω 1/2W）
E5AK-T（No.0） E5AK-T（No.30）
RS-485
RS-485
No. No.
32 A 32 A
31 B 31 B
19 A 19 A
20 B 20 B
M Others
• Only the E53-R output unit can be used for
E5AK-TPRR □□ controllers.
• No user serviceable parts.
However, Output unit can be replaced.
Return to OMRON for all repairs.
