 Thank you for choosing Air Conditioners, please read this owner's manual carefully before
operation and retain it for future reference.If you have lost the Owner's Manual, please
contact the local agent or visit www.gree.com or sent email to global@gree.com.cn or
electronic version.
 GREE reserves the right to interpret this manual which will be subject to any change due to
product improvement without further notice.
 GREE Electric Appliances, Inc. of Zhuhai reserves the final right to interpret this manual.
Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
Multi Variable Air Conditioners
Wall Mounted Type Indoor Unit
Owner's Manual
Air Conditioners
GMV-N28G/A3A-K
GMV-N36G/A3A-K
GMV-N56G/A3A-K
GMV-N63G/A3A-K
GMV-N28G/A2A-K
GMV-N36G/A2A-K
GMV-N56G/A2A-K
GMV-N63G/A2A-K
GMV-N28G/A4A-K
GMV-N36G/A4A-K
GMV-N56G/A4A-K
GMV-N63G/A4A-K
GMV-N28G/A8A-K
GMV-N36G/A8A-K
GMV-N56G/A8A-K
GMV-N63G/A8A-K
GMV-N28G/C9A-K
GMV-N36G/C9A-K
GMV-N56G/C9A-K
GMV-N63G/C9A-K
GMV-N28G/E3A-K
GMV-N36G/E3A-K
GMV-N56G/E3A-K
GMV-N63G/E3A-K
GMV-N28G/A3A-D
GMV-N36G/A3A-D
GMV-N56G/A3A-D
GMV-N63G/A3A-D
GMV-N28G/A2A-D
GMV-N36G/A2A-D
GMV-N56G/A2A-D
GMV-N63G/A2A-D
GMV-N28G/A4A-D
GMV-N36G/A4A-D
GMV-N56G/A4A-D
GMV-N63G/A4A-D
GMV-N28G/A8A-D
GMV-N36G/A8A-D
GMV-N56G/A8A-D
GMV-N63G/A8A-D
GMV-N28G/C9A-D
GMV-N36G/C9A-D
GMV-N56G/C9A-D
GMV-N63G/C9A-D
GMV-N28G/E3A-D
GMV-N36G/E3A-D
GMV-N56G/E3A-D
GMV-N63G/E3A-D
GMV-N45G/A3A-K
GMV-N71G/A3A-K
GMV-N45G/A2A-K
GMV-N71G/A2A-K
GMV-N45G/A4A-K
GMV-N71G/A4A-K
GMV-N45G/A8A-K
GMV-N71G/A8A-K
GMV-N45G/C9A-K
GMV-N71G/C9A-K
GMV-N45G/E3A-K
GMV-N71G/E3A-K
GMV-N45G/A3A-D
GMV-N71G/A3A-D
GMV-N45G/A2A-D
GMV-N71G/A2A-D
GMV-N45G/A4A-D
GMV-N71G/A4A-D
GMV-N45G/A8A-D
GMV-N71G/A8A-D
GMV-N45G/C9A-D
GMV-N71G/C9A-D
GMV-N45G/E3A-D
GMV-N71G/E3A-D

Advertisement

Table of Contents
loading

Related Manuals for Gree GMV-N22G/A3A-K

Summary of Contents for Gree GMV-N22G/A3A-K

  • Page 1  GREE Electric Appliances, Inc. of Zhuhai reserves the final right to interpret this manual. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 2 They can take this product for environmental safe recycling. R410A(R32/125:50/50):2087.5 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 3: Table Of Contents

    10.1 Adjusting air direction up and down ................ 16 10.2 Adjusting air direction left and right ................. 16 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 4: Safety Precautions

    Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 5 Gree Electric Appliances, Inc. of Zhuhai. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 6: Product Introduction

    (5) There is no obstacle at inlet or outlet. Please ensure good air circulation. (6) Keep the unit away from heating source, inflammable gas or smoke. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 7: Schematic Diagram Of Installation Spaces

    (outdoor unit). 3.3.1 Select communication line for indoor unit and wired controller Fig 3.3.1 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 8: Wiring Requirements

    GMV-N45G/A3A-K, GMV-N45G/A2A-K GMV-N45G/A4A-K, GMV-N45G/A8A-K 220-240V ~ 50Hz GMV-N45G/C9A-K, GMV-N45G/E3A-K GMV-N50G/A3A-K, GMV-N50G/A2A-K GMV-N50G/A4A-K, GMV-N50G/A8A-K 220-240V ~ 50Hz GMV-N50G/C9A-K, GMV-N50G/E3A-K Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 9 ⑤Install cut-off device near the unit. The minimum distance between each stage of cut-off device should be 3mm(The same for both indoor unit and outdoor unit). Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 10: Installation Instructions

    GMV-N56G/A3A-D, GMV-N63G/A3A-D, GMV-N71G/A3A-D GMV-N56G/A2A-D, GMV-N63G/A2A-D, GMV-N71G/A2A-D GMV-N56G/A4A-D, GMV-N63G/A4A-D, GMV-N71G/A4A-D GMV-N56G/A8A-D, GMV-N63G/A8A-D, GMV-N71G/A8A-D GMV-N56G/C9A-D, GMV-N63G/C9A-D, GMV-N71G/C9A-D GMV-N56G/E3A-D, GMV-N63G/E3A-D, GMV-N71G/E3A-D Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 11: The Installation Of The Rear Panel

    After finishing setting, “UC” is displayed on receiver light board for 5 seconds and “MASTER” icon is displayed on wired controller. 4.3.2 Setting by wired controller Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 12: Installation Of The Drainage Pipe

    ② If the tightening torque for the flare nut is too great, leakage would happen. 5 Wiring Work Warning! Before obtaining access to terminals, all supply circuits must be disconnected. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 13: Connect Cables And Terminals Of Wiring Board

    All indoor units must be unified of power supply so that they can be powered ON/OFF at the Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 14: Connection Of Communication Line Of Idu And Odu

    (2) Lead the communication line of wired controller across the rubber ring. (3) Connect the communication wire to terminal H1 and H2 of indoor 4-bit wiring board. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 15: Illuminate For Connection Of Wired Controller And Indoor Units Network

    (4) Guarantee that the installation height of the indoor unit should be 2.5m above the floor. Fig 5.6 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 16: The Best Usage Method

    (Only soft dry cloth and wet cloth moistened with neutral detergent could be used to clean the surface panel of the air conditioner.) 7.1 Cleaning panel Note： Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 17: Cleaning The Air Filters

    (1) Check if there is blockage in the inlet or outlet vent of the air conditioner. (2) Check if the earth wire is earthed reliably. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 18: Check After The Usage Season

    This is the sound of the running refrigerant was running Mist came from the air outlet vent when Indoor air is cooled rapidly cooling Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 19: Service Center

    3 different outlet directions to make the indoor temperature more even. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 20 ● GREE Electric Appliances, Inc. de Zhuhai se reserva el derecho final de interpretación de este manual. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 21 Éstos se encargarán de reciclar su producto de modo seguro para el medio ambiente. R410A(R32/125:50/50):2087.5 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 22 10.1 Ajuste de la dirección del aire hacia arriba y hacia abajo ........16 10.2 Ajuste de la dirección del aire hacia la izquierda y derecha ........16 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 23 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 24 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 25: Descripción De La Unidad Y Sus Principales Componentes

    Elemento Temperatura DB °C Temperatura WB °C Temperatura DB °C Temperatura WB °C Refrigeración asignada Calefacción asignada Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 26: El Mejor Método De Uso

    4.1 Limpieza del panel Nota: Desmóntelo antes de limpiarlo. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 27: Limpieza De Los Filtros De Aire

    (1) Compruebe si la entrada o salida del acondicionador está atascada. (2) Compruebe si el cable de puesta a tierra está conectado a tierra de modo fiable. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 28: Comprobaciones Posteriores A La Temporada De Uso

    Es el sonido emitido por la expansión del panel y otras partes debido al después de él cambio de temperatura. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 29: Centro De Servicio Técnico

    3 direcciones de salida diferentes, con lo cual se conseguirá una temperatura interior más uniforme. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 30 ● GREE Electric Appliances, Inc. of Zhuhai se réserve le droit d'interpréter ce manuel. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 31 Ce dernier peut récupérer le produit en vue d'un recyclage respectueux de l'environnement. R410A(R32/125:50/50):2087.5 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 32 10.1 Réglage de la direction de l’air vers le haut et le bas ........... 16 10.2 Réglage de la direction de l’air vers la gauche et la droite ........16 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 33: Précautions De Sécurité

    électriques ou les incendies, etc. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 34 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 35: Présentation Du Produit

    (5) Aucun obstacle ne gêne l’entrée ou la sortie. Veuillez garantir la bonne circulation d'air. (6) Tenir l’unité éloignée des sources de chaleur, de gaz inflammable ou fumée. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 36: Exigences De La Ligne De Communication

    Unité intérieure 2 Unité intérieure 1 Unité intérieure 3 Unité intérieure n Commande Commande sous-maîtresse maîtresse Fig 3.3.1 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 37: Exigences De Câblage

    GMV-N45G/A3A-K, GMV-N45G/A2A-K GMV-N45G/A4A-K, GMV-N45G/A8A-K 220-240V ~ 50Hz GMV-N45G/C9A-K, GMV-N45G/E3A-K GMV-N50G/A3A-K, GMV-N50G/A2A-K GMV-N50G/A4A-K, GMV-N50G/A8A-K 220-240V ~ 50Hz GMV-N50G/C9A-K, GMV-N50G/E3A-K Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
  • Page 38 étage de coupure de l’appareil doit être de 3 mm (la même pour les unités intérieure et extérieure). Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 39: Pose De L'unité Intérieure

    GMV-N56G/A3A-D, GMV-N63G/A3A-D, GMV-N71G/A3A-D GMV-N56G/A2A-D, GMV-N63G/A2A-D, GMV-N71G/A2A-D GMV-N56G/A4A-D, GMV-N63G/A4A-D, GMV-N71G/A4A-D GMV-N56G/A8A-D, GMV-N63G/A8A-D, GMV-N71G/A8A-D GMV-N56G/C9A-D, GMV-N63G/C9A-D, GMV-N71G/C9A-D GMV-N56G/E3A-D, GMV-N63G/E3A-D, GMV-N71G/E3A-D Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 40: Pose Du Panneau Arrière

    Une fois le réglage terminé, « UC » s’affiche sur le panneau lumineux de réception pendant 5 secondes et l’icône « MASTER » apparaît sur la télécommande. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 41: Préparation De L'ouverture De Tuyauterie

    Si le couple de serrage de l’écrou d'évasement est trop élevé, des fuites se produiront. 5 Travaux de câblage électrique Avertissement ! Avant d'accéder aux bornes, déconnecter tous les circuits d'alimentation. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 42: Connexion Des Câbles Et Des Bornes De La Carte De Câblage

    Toutes les unités intérieures doivent être raccordées à l’alimentation afin de pouvoir être mise sous tension/arrêtées au même moment. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 43: Connexion De La Ligne De Communication De L'ui Et L'ue

    (3) Connecter le câble de communication aux bornes H1 et H2 de la carte de câblage 4 bit intérieure. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 44: Pose De L'unité Intérieure

    Matériel inférieur 2 Câble de commande Câble de raccordement Matériel inférieur 1 Tuyau d'évacuation de l'alimentation Fig 5.6 Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 45: Bonne Méthode D'utilisation

    7.1 Nettoyage du panneau Remarque : Retirer le panneau avant le nettoyage. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 46: Nettoyage Des Filtres À Air

    (1) Vérifier si l'entrée et la sortie d'air du climatiseur sont obstruées. (2) Vérifier si le fil de terre a été raccordé correctement. Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 47: Vérification Après L'utilisation Saisonnière

    De la buée sort de l'orifice de sortie L'air intérieur est refroidi rapidement. d'air en mode climatisation Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.

  • Page 48: Centre D'entretien

    Copyright 2018. This translation is property of GREE PRODUCTS SL. All rights reserved. Total or partial reproduction without its express authorization is prohibited.
