Page 1: Table Of Contents
TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior fea- Air conditioning and audio systems, as well as other in- tures terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 2 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 378)
Page 3 1-1. Key information NOTICE To prevent key damage Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 4 1 -2 . Ope ning, c losing a nd loc k ing t he doors Wire le ss re m ot e c ont rol (if e quippe d) The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle.
Page 5 When the wireless key battery is depleted If window tint with a metallic content or metallic objects are attached to the rear window Customization that can be configured at Toyota dealer Settings (e.g. operation signal) can be changed. (Customizable features →P. 420)
Page 6 1-2. Opening, closing and locking the doors Certification for wireless remote control For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 7 1 -2 . Ope ning, c losing a nd loc k ing t he doors Doors The vehicle can be locked and unlocked using the wireless remote control, key or door lock switch. Wireless remote control (if equipped) →P. 26 Locks the door Unlocks the door Vehicles with power door lock...
Page 8 1-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the locks are set. These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 9 1-2. Opening, closing and locking the doors Setting and canceling the functions To switch between set and canceled, follow the procedure below: Close all the doors and switch the engine switch to the “ON” STEP position. (Perform step 2 within 10 seconds.) Shift the shift lever to P or N, and STEP press and hold the driver's door...
Page 10 The doors cannot be locked when The key is in the engine switch and either of the front door is open. Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customiz- able features →P.
Page 11 1 -2 . Ope ning, c losing a nd loc k ing t he doors Ba ck door The back door can be locked and unlocked using the wireless remote control or key. Wireless remote control (if equipped) →P. 26 Locks the back door Unlocks the back door Opens the back door...
Page 12 1-2. Opening, closing and locking the doors CAUTION Caution while driving Keep the back door closed. This not only keeps personal belongings from being thrown out, but also pre- vents exhaust gases from entering the vehicle. NOTICE To prevent damage to the back door components Do not apply any force, paint or let any other foreign matter on the damper.
Page 13 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) Front se at s Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Folding down the front passenger's seat (vehicles with seatback table) Move the seat rearward.
Page 14 1-3. Adjustable components (seats, mirrors, steering wheel) Lower the head restraint and fix STEP the seatback at the most upright lock position. Pull up either seatback lock STEP release knob beside the seat- back and fold the seatback down. Active head restraints (vehicles with side airbags and curtain shield airbags) When a front seatback receives strong impact,...
Page 15 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment Be careful that the seat does not hit passengers or luggage. Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of...
Page 16 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) Re a r se at s The seatbacks of the rear seats can be folded down. Stow the rear outside seat belt STEP buckles and move the rear...
Page 17 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. Make sure that the seatback is securely locked in position by lightly rocking it back and forth.
Page 18 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) H e a d re st ra int s Vertical adjustment Push and hold the lock release button when lowering the head Lock restraint.
Page 19 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) Se at be lt s Make sure that all occupants are wearing their seat belts before driv- ing the vehicle.
Page 20 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal...
Page 21 Replacing the belt after the pretensioner has been activated The seat belts cannot be used after a pretensioner has been activated. After an accident, have the pretensioners inspected by your Toyota dealer. Make sure the pretensioners are replaced if they have been activated.
Page 22 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
Page 23 Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 24 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) St e e ring w he e l The steering wheel can be adjusted to a comfortable position. Hold steering STEP...
Page 25 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) Ant i-gla re inside re a r vie w m irror Glare from the headlights of vehicles behind can be reduced by using the following functions.
Page 26 1-3. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
Page 27 1 -3 . Adjust a ble c om pone nt s (se a t s, m irrors, st e e ring w he e l) Out side re a r vie w m irrors Mirror angle can be adjusted using the switch. Select a mirror to adjust.
Page 28 1-3. Adjustable components (seats, mirrors, steering wheel) Mirror angle can be adjusted when The engine switch is in the “ACC” or “ON” position. When the mirrors are fogged up (vehicles with outside rear view mirror defoggers) Turn on the mirror defoggers to defog the mirrors. (→P. 168) CAUTION When driving the vehicle Observe the following precautions while driving.
Page 29 1 -4 . Ope ning a nd c losing t he w indow s Pow e r w indow s (if e quippe d) The power windows can be opened and closed using the following switches. Closing Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win-...
Page 30 1-4. Opening and closing the windows CAUTION Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 31 1 -4 . Ope ning a nd c losing t he w indow s M oon roof (if e quippe d) Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing Open* The moon roof stops slightly before the fully opened posi- tion.
Page 32 1-4. Opening and closing the windows The moon roof can be operated when The engine switch is in the “ON” position. Operating the moon roof after turning the engine OFF The moon roof can be operated for approximately 45 seconds after the engine switch is turned to the “ACC”...
Page 33 1-4. Opening and closing the windows CAUTION Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving. Do not sit on top of the moon roof.
Page 34 1 -5 . Re fue ling Ope ning t he fue l t a nk c a p Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the engine switch OFF and ensure that all the doors and windows are closed.
Page 35 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. Fuel type Unleaded gasoline (87 Octane rating [Research Octane Number 91] or higher) Fuel tank capacity 13.2 gal.
Page 36 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 37 1-5. Refueling NOTICE Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface.
Page 38 1 -6 . T he ft de t e rre nt syst e m Engine im m obilize r syst e m The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer.
Page 39 1-6. Theft deterrent system CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTICE To prevent damage to the key Do not modify, remove or disable the engine immobilizer system. If any unauthorized changes or modifications are made, the proper operation of the system cannot be guaranteed.
Page 40 1 -6 . T he ft de t e rre nt syst e m T he ft preve nt ion la be ls (for U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles.
Page 41 1 -7 . Sa fe t y inform a t ion Corre c t driving post ure Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 35) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily...
Page 42 1-7. Safety information CAUTION While driving Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 43 1 -7 . Sa fe t y inform a t ion SRS a irba gs The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
Page 44 1-7. Safety information Airbag system components Front airbag sensors SRS warning light Front passenger occupant Front passenger’s seat belt classification system (ECU buckle switch and sensors) Airbag sensor assembly Side and curtain shield air- Curtain shield airbag sen- bag sensors (if equipped) sors (if equipped) Front passenger airbag Driver airbag...
Page 45 1-7. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 46 1-7. Safety information SRS warning light This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensors (if equipped), curtain shield airbag sensors (if equipped), driver's seat position sensor, driver's seat belt buckle switch, front passenger occupant classification system, “AIR BAG ON”...
Page 47 1-7. Safety information Side airbags and curtain shield airbags (if equipped) The SRS side airbags and curtain shield airbags are designed to inflate when the passenger compartment is subjected to a severe impact from the side. Depending on the conditions and type of accident, there are times when the curtain shield airbags may deploy (inflate) in a front impact.
Page 48 1-7. Safety information Types of collisions that may not deploy the SRS side airbags and cur- tain shield airbags (if equipped) The SRS side airbags and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a col- lision to the side of the vehicle body other than the passenger compartment.
Page 49 1-7. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
Page 50 1-7. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
Page 51 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
Page 52 1-7. Safety information CAUTION SRS airbag precautions Do not allow a child to sit on the knees of a front passenger while the vehicle is moving. Do not drive the vehicle while the driver or passenger has items resting on their knees.
Page 53 1-7. Safety information CAUTION SRS airbag precautions Vehicles with side airbags and curtain shield airbags: Do not attach anything to areas such as the door, windshield glass, side door glass, front and rear pillars, roof side rail or assist grip. Curtain shield airbags: Do not hang coat hangers or other hard objects on the coat hooks.
Page 54 Vehicles with side and curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. Vehicles without side and curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad are damaged or cracked, have them replaced by your Toyota dealer.
Page 55 1 -7 . Sa fe t y inform a t ion Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 56 1-7. Safety information Conditions and operation of the front passenger occupant classification system Adult “AIR BAG ON” and “AIR BAG OFF” indicator “AIR BAG lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seats (if equipped) Devices...
Page 57 1-7. Safety information Unoccupied “AIR BAG ON” and “AIR BAG OFF” indicator Not illuminated lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seats (if equipped) Devices Curtain shield airbag in the front Activated...
Page 58 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 82) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 59 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 60 1 -7 . Sa fe t y inform a t ion Child re st ra int syst e m s A child restraint system for a small child or baby must be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of U.S.A.
Page 61 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Infant seat Convertible seat Booster seat...
Page 62 In an accident, the child can be crushed against the windshield, or between you and the vehicle's interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 63 1-7. Safety information CAUTION Child restraint precautions Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 64 1 -7 . Sa fe t y inform a t ion I nst a lling child re st ra int s Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using a seat belt or a child restraint lower anchorage.
Page 65 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 66 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 67 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 68 1-7. Safety information Removing a child restraint installed with a seat belt Push the release button and fully retract the seat belt. Installation with child restraint lower anchorages Type A Widen the gap between STEP the seat cushion and seatback slightly. Latch the hooks of the STEP lower straps onto the...
Page 69 1-7. Safety information Type B Widen the gap between STEP the seat cushion and seatback slightly. Latch the buckles onto STEP the anchors. If the child restraint has a top strap, the top strap should be latched onto the anchors. For owners in Canada: A symbol on a child restraint sys- tem indicates the presence of a...
Page 70 1-7. Safety information Child restraint systems with a top strap Secure the child restraint using STEP the seat belt lower anchors, and remove the head restraint. Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top strap. Make sure the top strap is securely latched.
Page 71 1-7. Safety information CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 42) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 72 1-7. Safety information CAUTION When installing a child restraint system When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
Page 73 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 74 Seat belt instructions for Canadian ow ners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.
Page 75 Entretien et soin Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées. ATTENTION Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité...
Page 76: Before Driving
TABLE OF CONTENTS Index 1-7. Safety information ....63 Before driving Correct driving posture ..63 SRS airbags ......65 Front passenger occupant 1-1. Key information ....24 classification system... 77 Keys ........24 Child restraint systems ..82 Installing child restraints ..86 1-2.
Page 77: Interior Features
2-5. Driving information... 140 Hands-free phone system (for cellular phone) Cargo and luggage ..... 140 features ......200 Vehicle load limits ....143 Using the hands-free Winter driving tips ....144 phone system Trailer towing ...... 148 (for cellular phone) ... 203 Dinghy towing Making a phone call ...
Page 78: Maintenance And Care
TABLE OF CONTENTS Index Compass ......262 When trouble arises Maintenance and care 5-1. Essential information ..342 If your vehicle needs to 4-1. Maintenance and care..268 be towed ......342 If you think something Cleaning and protecting the is wrong ......
Page 79: Vehicle Specifications
Vehicle specifications 6-1. Specifications....390 Maintenance data (fuel, oil level, etc.).... 390 Fuel information ....405 Tire information ....408 6-2. Customization ....420 Customizable features ..420 6-3. Initialization ....... 422 Items to initialize ....422 For owners Reporting safety defects for U.S.
Page 80 Pic t oria l inde x Exterior Headlights (low beam) P. 125 ∗ Moon roof P. 53 Headlights (high beam) P. 126 Outside rear view Hood P. 283 mirrors P. 49 Front turn signal/parking and front side marker lights P. 117, 125 Windshield wipers P.
Page 81 Rear window defogger P. 168 ∗ Fuel filler door P. 56 Rear window wiper P. 131 Doors P. 29 Back door P. 33 License plate lights P. 125 Tires Rotation P. 303 Replacement P. 362 Stop/tail and rear side Inflation pressure P.
Page 82 Pic t oria l inde x Interior Seat belts P. 41 SRS driver airbag P. 65 Head restraints P. 40 Bottle holders P. 241 Power window SRS front passenger ∗ switches P. 51 airbag P. 65 Glove box Bottle holders P.
Page 83 Vehicles with moon roof Vanity mirrors P. 245 Sun visors P. 244 Auxiliary box P. 242 Moon roof switches P. 53 ∗ SRS curtain shield airbags P. 65 Interior lights P. 233 Personal/interior lights P. 234 Anti-glare inside rear view mirror P.
Page 84 Pic t oria l inde x Interior Vehicles without moon roof Vanity mirrors P. 245 Sun visors P. 244 Personal lights P. 235 ∗ SRS curtain shield airbags P. 65 Interior lights P. 233 Anti-glare inside rear view mirror P. 47...
Page 85 ∗ Door lock switch P. 29 Inside door lock button P. 29 ∗ Window lock switch P. 51 ∗ Power window switches P. 51 ∗ : If equipped...
Page 86 Pic t oria l inde x Interior ∗ Power outlet P. 249 Cup holders P. 239 ∗ Power outlet P. 249 Parking brake lever P. 118 ∗ Cigarette lighter P. 248 AUX adapter P. 196...
Page 87 Pic t oria l inde x Instrument panel Gauges and meters P. 119 Headlight switch P. 125 Turn signal lever P. 117 Emergency ∗ Fog light switch P. 128 flasher switch Security indicator Audio system P. 169 Outside rear view P.
Page 88 Pic t oria l inde x Instrument panel Air conditioning system P. 162 Rear window and outside rear view mirror defogger ∗ ∗ switch /rear window defogger switch P. 168...
Page 89 Engine (ignition) switch P. 106 ∗ Audio remote control Telephone switches ∗ switches * P. 197 P. 204 ∗ Cruise control switch P. 132 ∗ Talk switch P. 204 ∗ : If equipped : For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
Page 90 Pic t oria l inde x Instrument panel ∗ Power outlet main switch P. 249 Clock P. 246 Shift lock override ∗ Shift lever P. 110, 115 button P. 377...
Page 91 ∗ VSC/TRAC off switch P. 135 Auxiliary box P. 242 Hood lock release lever P. 283 ∗ : If equipped...
Page 92 Abbre via t ion list Abbreviat ion/Ac ronym list ABBREVIATIONS MEANING Air Conditioner Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Rating GVWR Gross Vehicle Weight Rating Emission inspection and maintenance Light Emitting Diode Methylcyclopentadienyl Manganese Tricarbonyl...
Page 93 Wha t t o do if... What t o do if... If you have a flat tire A tire punctures P. 362 P. 376 If the engine will not start The engine does not start P. 60 Engine immobilizer system P.
Page 94 What to do if... nWarning lights Brake system warning Active torque control 4WD sys- light tem warning light P. 353 Engine oil replacement reminder light P. 352 P. 355 Charging system warn- Tire pressure warning ing light light P. 353 P.
Page 95 GAS STAT I ON I N FORM AT I ON Auxiliary catch lever Fuel filler door P. 283 P. 56 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 283 P. 56 P. 400 Fuel tank capacity 13.2 gal.
Page 96 3 -1 . U sing t he a ir c ondit ioning syst e m a nd de fogge r Air c ondit ioning syst e m Heater Air outlet selection dial Temperature control dial Fan speed control dial Air intake mode switch Air conditioning system Air outlet selection dial Temperature control dial...
Page 97 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting (heater) Turn the temperature control dial clockwise to increase the temper- ature. Adjusting the temperature setting (air conditioning system) Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 98 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. : Some models Mainly air flows to the feet. : Some models Air flows to the feet and the windshield defogger operates. The air intake is automatically switched to outside air mode.
Page 99 3-1. Using the air conditioning system and defogger Air flows to the windshield and side windows. The air intake is automatically switched to outside air mode. It is not possible to return to recircu- lated air mode when the switch is Switching air intake modes Press The mode switches between outside air mode (indicator off) and recircu-...
Page 100 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Adjusting the position Direct air flow to the left or right, up or down. Opening and closing Open the vent. Close the vent.
Page 101: Air Conditioning System
3-1. Using the air conditioning system and defogger For quick cooling (vehicles with air conditioning system) Turn the temperature control dial to the “MAX A/C” position and select the recirculated air mode. For quick clearing of the windshield and side windows (vehicles with air conditioning system) Press to turn the air conditioning on.
Page 102: Rear Window And Outside Rear View Mirror Defoggers
3 -1 . U sing t he a ir c ondit ioning syst e m a nd de fogge r Rear w indow and outside rear view mirror defoggers Clear the rear window using the defogger. On/off Outside rear view mirror defogger (if equipped) Turning the rear window defogger on will turn the outside rear view mirror defoggers on.
Page 103: Using The Audio System
3 -2 . U sing t he a udio syst e m Audio syst e m t ype s With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system Type A: CD player with CD changer controller and AM/FM radio Type B: CD player with changer and AM/FM radio...
Page 104 3-2. Using the audio system Title Page Using the radio P. 172 Using the CD player P. 178 Playing MP3 and WMA discs P. 185 Optimal use of the audio system P. 193 Using the AUX adapter P. 196 Using the steering wheel audio switches P.
Page 105 3-2. Using the audio system NOTICE To prevent battery discharge Do not leave the audio system on longer than necessary with the engine off. To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.
Page 106 3 -2 . U sing t he a udio syst e m U sing t he ra dio Power Volume Adjusting frequency (AM, FM mode) or channel (SAT mode) Station selector Displaying radio Scanning for AM⋅SAT/FM text messages receivable stations mode buttons Changing the channel Seeking the frequency...
Page 107 3-2. Using the audio system Scanning all radio stations within range Press STEP All stations with reception will be played for 5 seconds each. When the desired station is reached, press once STEP again. ® Satellite Radio* (if equipped) ® Receiving XM Satellite Radio Press...
Page 108 The display changes as follows each time the button is pressed. l CH NAME l TITLE (SONG/PROGRAM TITLE) l NAME (ARTIST NAME/FEATURE) l CH NUMBER *: Except JBL brand audio system⎯ ® ® Use of XM Satellite Radio requires XM tuner and service. Contact your Toyota dealer.
Page 109 3-2. Using the audio system When the battery is disconnected Station presets are erased. Reception sensitivity Cargo loaded on the roof luggage carrier, especially metal objects, may ® adversely affect the reception of XM Satellite Radio. Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 110 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 111 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).
Page 112: Using The Cd Player
3 -2 . U sing t he a udio syst e m U sing t he CD pla ye r CD load Power Volume (type B only) Fast-forwarding a track CD eject Reversing a track Selecting a track Playback Searching Repeat play playback Displaying text...
Page 113 3-2. Using the audio system Loading multiple CDs (type B) Press and hold until you hear a beep. STEP Insert a CD when the indicator on the slot turns from amber to STEP green. The indicator on the slot turns to amber when the CD is inserted. Insert the next CD when the indicator on the slot turns from STEP amber to green again.
Page 114 3-2. Using the audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press (reverse) or (fast-for- ward). Scanning tracks Press STEP The first ten seconds of each track will be played. Press again when the desired track is reached. STEP Selecting a CD (type A with a CD changer and type B) To select a CD to play...
Page 115 3-2. Using the audio system Random playback Current CD Press (RAND). Tracks are played in a random order until is pressed once more. All CDs (type A with a CD changer and type B) Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in a random order until pressed once more.
Page 116 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. Discs that can be used Discs with the marks shown below can be used.
Page 117 3-2. Using the audio system NOTICE CDs that cannot be used Do not use the following types of CDs or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. Type A: CDs that have a diameter other than 4.7 in.
Page 118 3-2. Using the audio system NOTICE CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. Do not apply oil to the CD player. Store CDs away from direct sunlight.
Page 119: Playing Mp3 And Wma Discs
3 -2 . U sing t he a udio syst e m Pla ying M P3 a nd WM A disc s Power Volume Selecting a file CD load (type B only) CD eject Selecting a CD Fast-for- warding a Selecting file a file...
Page 120 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. Selecting the desired folder by cueing the first file of each folder Press and hold until you hear a beep.
Page 121 3-2. Using the audio system Repeat play To repeat a file Press (RPT). To repeat all of the files in a folder Press and hold (RPT) until you hear a beep. Random playback To play files from a particular folder in random order Press (RAND).
Page 122 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the Discs that can be used Discs with the marks shown below can be used.
Page 123 3-2. Using the audio system MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 124 3-2. Using the audio system Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 125 3-2. Using the audio system ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title and artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 126 3-2. Using the audio system NOTICE CDs that cannot be used (→P. 183) CD player precautions (→P. 184)
Page 127: Optimal Use Of The Audio System
3 -2 . U sing t he a udio syst e m Opt im a l use of t he a udio syst e m Displays the current mode Changes the following set- tings • Sound quality and volume balance (→P.
Page 128 3-2. Using the audio system Adjusting sound quality Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right Bass -5 to 5 Mid- *1,*2 -5 to 5 High range Treble -5 to 5 Front/rear Shifts to volume...
Page 129 3-2. Using the audio system JBL brand audio system When “ASL” is selected, turning to the right turns “ASL” on, and turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed. Trademark owned by SRS Labs, Inc.
Page 130: Using The Aux Adapter
3 -2 . U sing t he a udio syst e m U sing t he AU X a da pt e r This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device.
Page 131: Using The Steering Wheel Audio Switches
3 -2 . U sing t he a udio syst e m Using the steering w heel audio sw itches (if equipped) Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations Select tracks, files...
Page 132 ® ® Use of XM Satellite Radio requires XM tuner and service. Contact your Toyota dealer. Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Press and hold the switch to continue increasing or decreasing the vol- ume.
Page 133 3-2. Using the audio system Selecting a track/file Press to select the CD mode. STEP Press to select the desired track/file. STEP Selecting a folder (type A) Press to select the CD mode. STEP Press and hold until you hear a beep. STEP Selecting a disc (type A with a CD changer and type B) Press...
Page 134: Using The Hands-Free
3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) Hands-free phone system (for cellular phone) features (if equipped) ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
Page 135 3-3. Using the hands-free phone system (for cellular phone) Trademark owned by Bluetooth SIG. Inc. Certification for the hands-free phone system FCC ID: ACJ932C5ZZZ035 IC ID: 216J-C5ZZZ035 MADE IN JAPAN NOTE: This device complies with Part 15 of the FCC Rules and RSS-210 of industry Canada.
Page 136 3-3. Using the hands-free phone system (for cellular phone) FCC WARNING: Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 137 3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) Using the hands-free phone system (for cellular phone) (if equipped) Audio unit Displays such items as message, name, and phone number Lower-case characters...
Page 138 3-3. Using the hands-free phone system (for cellular phone) Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. Hands-free phone system on/starts a call (off-hook switch) Hands-free phone system off/ends a call/refuses a call (on-hook switch) Press: Voice command sys- tem on Press and hold: Voice com-...
Page 139 3-3. Using the hands-free phone system (for cellular phone) Microphone Vehicles with moon roof Vehicles without moon roof...
Page 140 3-3. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating Operation procedure when using a voice command Press the talk switch and say the command for a desired function.
Page 141 3-3. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 142 3-3. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in Callback the incoming call history memory Dialing a number stored in Redial the outgoing call history memory...
Page 143: Setup
3-3. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book Security Phonebook Unlocking the phone book Unlock Registering the cellular Pair Phone phone to be used Changing a registered name Change Name...
Page 144 3-3. Using the hands-free phone system (for cellular phone) Using a short cut key First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Phone book add Adding a new number entry Changing the name of a Phone book change phone number in the phone name...
Page 145 3-3. Using the hands-free phone system (for cellular phone) Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command For numbers, say a combination of single digits from zero to nine, # (pound), ∗...
Page 146 3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) M a k ing a phone c a ll Making a phone call l Dialing by inputting a number “Dial by number”...
Page 147 3-3. Using the hands-free phone system (for cellular phone) Dialing by inputting a name Press the talk switch and say “Dial by name”. STEP Select a registered name to be input by either of the following STEP methods: a. Press the talk switch and say a registered name. b.
Page 148 3-3. Using the hands-free phone system (for cellular phone) Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the oper- ation of the phone.
Page 149 3-3. Using the hands-free phone system (for cellular phone) The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” by using a voice command or Storing the number in the phone book: Select “Store” by using a voice command or Deleting: Select “Delete”...
Page 150 3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) Se t t ing a c e llula r phone Registering a cellular phone in the hands-free phone system allows the system to function.
Page 151 3-3. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used Select “Select Phone” by using a voice command or STEP Pattern A Select the cellular phone to be used by either of the following STEP methods, and select “Confirm”...
Page 152 3-3. Using the hands-free phone system (for cellular phone) Press the talk switch or select “Record Name” by using STEP and say a new name. Select “Confirm” by using a voice command or STEP Listing the registered cellular phones Selecting “List Phones” by using a voice command or causes the list of registered cellular phones to be read aloud.
Page 153 3-3. Using the hands-free phone system (for cellular phone) Deleting a cellular phone Select “Delete” by using a voice command or STEP Pattern A Select the cellular phone to be deleted by either of the follow- STEP ing methods and select “Confirm” by using a voice command a.
Page 154 3-3. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” by using a voice command or STEP Pattern A Press the talk switch, say a 4 to 8-digit number, and select STEP “Confirm” by using a voice command or Pattern B Select a 4 to 8-digit number by using STEP...
Page 155 3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) Se c urit y a nd syst e m se t up To enter the menu of each setting, follow the steps below: Security setting items and operation procedure l Setting or changing the PIN (Personal Identification Number) 1.
Page 156 3-3. Using the hands-free phone system (for cellular phone) Changing the PIN Select “Set PIN” by using a voice command or STEP Enter the registered PIN by using a voice command or STEP Enter a new PIN by using a voice command or STEP When using , input the code 1 digit at a time.
Page 157 3-3. Using the hands-free phone system (for cellular phone) Setting voice guidance volume Select “Guidance Vol” by using STEP Change the voice guidance volume. STEP To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization Select “Initialize” and then “Confirm” by using STEP Select “Confirm”...
Page 158: Using The Phone Book
3-3. Using the hands-free phone system (for cellular phone) Initialization The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code Once the initialization has been completed, the data cannot be restored to its original state.
Page 159 3 -3 . U sing t he ha nds-fre e phone syst e m (for c e llula r phone ) U sing t he phone book To enter the menu of each setting, follow the steps below: l Adding a new phone number 1.
Page 160 3-3. Using the hands-free phone system (for cellular phone) Adding procedure Select “Add Entry” by using a voice command or STEP Use one of the following methods to input a telephone num- STEP ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
Page 161 3-3. Using the hands-free phone system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
Page 162 3-3. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following STEP methods, and select “Confirm” by using a voice command or a. Press the talk switch and say the desired name. b.
Page 163 3-3. Using the hands-free phone system (for cellular phone) Select the desired preset button, and register the data into STEP speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” by using a voice command or b.
Page 164 3-3. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” by using a voice command or STEP Pattern A Select the data to be deleted by either of the following meth- STEP ods, and select “Confirm” by using a voice command or a.
Page 165 3-3. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will be available.
Page 166 3 -4 . U sing t he int e rior light s I nt e rior light s list Personal/interior lights or personal lights (→P. 234, 235) Interior lights (→P. 233)
Page 167: Using The Interior Lights
“DOOR” position, the lights will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed.
Page 168: Personal/Interior Lights
3-4. Using the interior lights Personal/interior lights Personal/interior lights (vehicles with moon roof) Interior lights “DOOR” position Personal lights On/off...
Page 169 3-4. Using the interior lights Personal lights Personal lights (vehicles without moon roof) On/off...
Page 170: Using The Storage Features
3 -5 . U sing t he st ora ge fe a t ure s List of st ora ge fe at ure s Auxiliary boxes Glove box Bottle holders Cup holders Console box...
Page 171 3-5. Using the storage features Glove box and console box Glove box Pull up the lever. CAUTION Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Console box Type A Lift the lid while pulling the lever.
Page 172 3-5. Using the storage features Console box Type B (upper) Lift the lid while pulling the lever. Type B (lower) Lift the lid and tray while pulling the lever. CAUTION Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 173 3-5. Using the storage features Cup holders Cup holders Front Rear Pull the lid to open. Using the cup holder (front) to store small items Remove the holders.
Page 174 3-5. Using the storage features Cup holders Adjusting the cup holder to the size of the cups or drink-cans Remove the holder and change the holder position. Small size Middle size Large size CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.
Page 175 3-5. Using the storage features Bottle holders Bottle holders Front Rear CAUTION Items unsuitable for the bottle holder Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 176 3-5. Using the storage features Bottle holders and auxiliary boxes NOTICE When a pet bottle is in the front bottle holder (vehicles with manual window) As there is a possibility of interfering with a manual window regulator handle, pre- vent the window from opening and clos- ing, do not place a pet bottle in the holder when turning the handle.
Page 177 3-5. Using the storage features Auxiliary boxes CAUTION Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. Items that should not be left in the overhead console Do not leave glasses or lighters in the console. If the interior of the vehicle becomes hot, lighters may explode and glasses may warp or become cracked.
Page 178: Other Interior Features
3 -6 . Ot he r int e rior fe a t ure s Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.
Page 179: Vanity Mirrors
3 -6 . Ot he r int e rior fe a t ure s Va nit y m irrors Slide the cover.
Page 180: Clock
3 -6 . Ot he r int e rior fe a t ure s Clock Adjusts the hour. Adjusts the minutes. Rounds nearest hour.* *: e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 The clock is displayed when The engine switch is in the “ACC”...
Page 181: Ashtrays
3 -6 . Ot he r int e rior fe a t ure s Asht ra ys (if e quippe d) An ashtray can be installed in a cup holder. CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of an accident or sudden braking. To prevent fire Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
Page 182: Cigarette Lighter
3 -6 . Ot he r int e rior fe a t ure s Ciga re t t e light e r (if e quippe d) Push cigarette lighter down. The cigarette lighter will pop up when it is ready for use. The cigarette lighter can be used when The engine switch is in the “ACC”...
Page 183: Power Outlet
3 -6 . Ot he r int e rior fe a t ure s Pow e r out le t (if e quippe d) The power outlet can be used for a following component. 12 V: Accessories that run on less than 10 A. 115 V: Accessories that uses less than 100 W.
Page 184 3-6. Other interior features NOTICE To avoid damaging the power outlet Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent the fuse from being blown 12 V Do not use an accessory that uses more than 12 V 10 A.
Page 185: Grocery Bag Hook
3 -6 . Ot he r int e rior fe a t ure s Groc e r y ba g hook This hook is designed to hang things like grocery bag. Cabin Press the hook. Luggage compartment...
Page 186 3-6. Other interior features NOTICE Grocery bag hook weight capacity Cabin Do not hang any object heavier than 44 lb. (20 kg) on the grocery bag hook. Luggage compartment Do not hang any object heavier than 7 lb. (3 kg) on the grocery bag hooks.
Page 187: Seatback Table
3 -6 . Ot he r int e rior fe a t ure s Se at ba ck t a ble (if e quippe d) Front passenger's seatback can be used as a temporary table only when the vehicle is stopped. Fold down the front passen- ger's seat to use the seatback table.
Page 188: Floor Mat
3 -6 . Ot he r int e rior fe a t ure s Floor m at Securely place a mat that matches the size of the space on the car- pet. Secure the driver's floor mat using the hooks provided. CAUTION When inserting the floor mat Observe the following precautions.
Page 189: Luggage Compartment Feature
3 -6 . Ot he r int e rior fe a t ure s Lugga ge c om pa r t m e nt fe at ure Cargo hooks Cargo hooks are provided for securing loose items. Tie-down belts To tighten To loosen To hook To unhook...
Page 190 3-6. Other interior features Auxiliary boxes Turn knobs “UNLOCK” position, remove the deck boards.
Page 191 3-6. Other interior features Grocery bag hooks (→P. 251) Tonneau cover (if equipped) Remove the deck board. STEP Take out the bag. STEP Remove the tonneau cover STEP from the bag.
Page 192 3-6. Other interior features Slowly unfold the tonneau STEP cover. Attach the hook to the hook STEP brackets. Raise the rear center head STEP restraint to attach the hook.
Page 193 3-6. Other interior features Folding the tonneau cover Hold the tonneau cover with both STEP hands. Point your thumbs in opposite directions. Bend one side of the cover STEP towards you. Twist the other side in the oppo- STEP site direction, as shown in the illustration.
Page 194 3-6. Other interior features Make a small circle, then fold it STEP inward. Make sure the three circles are STEP side by side. Put it in the bag. STEP...
Page 195 3-6. Other interior features CAUTION When unfolding the tonneau cover Be careful not to hit yourself when unfolding the tonneau cover. Caution while driving Keep the deck boards locked. Injuries may result in the event of an accident or sudden braking.
Page 196: Compass
3 -6 . Ot he r int e rior fe a t ure s Com pa ss (if e quippe d) The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation To turn the compass on or off, press and hold “AUTO”...
Page 197 3-6. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in the illustration, the compass will deviate.
Page 198 3-6. Other interior features Circling calibration Stop the vehicle in a place where it is safe to drive in a circle. STEP Press and hold “AUTO” for 9 STEP seconds. C appears on the compass dis- play. Drive the vehicle at 5 mph (8 STEP km/h) or less in a circle until a direction is displayed.
Page 199 3-6. Other interior features CAUTION While driving the vehicle Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.
Page 200 3-6. Other interior features...
Page 201: Maintenance And Care
4 -1 . M a int e na nc e a nd c a re Cle a ning a nd prot e c t ing t he ve hicle ex t e rior Perform the following to protect the vehicle and maintain it in prime condition.
Page 202 Do not use organic cleaners such as benzene or gasoline. If the windshield washer nozzle become blocked Contact your Toyota dealer. Do not try to clear it with a pin or other object. This may damage the nozzle. Cleaning the exterior lights Wash carefully.
Page 203 4 -1 . M a int e na nc e a nd c a re Cle a ning a nd prot e c t ing t he ve hicle int e rior The following procedures will help protect your vehicle's interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner.
Page 204 Wipe the window in strokes running parallel to the heater wires. Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. Shampooing the carpets There are several commercial foaming-type cleaners available.
Page 205 4-1. Maintenance and care NOTICE Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alka- line solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Preventing damage to leather surfaces Observe the following precautions to avoid damage to and deterioration of leather surfaces.
Page 206: Maintenance
It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 207 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 208 Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Check the connections. Battery (→P.
Page 209 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 210 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...
Page 211: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...
Page 212: Do-It-Yourself Maintenance
Brake fluid level (→P. 297) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 213 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 323) as original Radiator and condenser ⎯ (→P. 296) • Tire pressure gauge Tire inflation pressure (→P. 312) • Compressed air source • Water washer fluid containing Washer fluid (→P.
Page 214 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 215 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also, a backfire could cause a fire in the engine compart- ment.
Page 216: Hood
4 -3 . Do-it -yourse lf m a int e na nc e H ood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood.
Page 217 4-3. Do-it-yourself maintenance CAUTION Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. After installing the support rod into the slot Make sure the rod supports the hood securely from falling down on to your head or body.
Page 218: Positioning A Floor Jack
4 -3 . Do-it -yourse lf m a int e na nc e Posit ioning a floor ja ck When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine...
Page 219 4-3. Do-it-yourself maintenance Rear 2WD models without 18-inch tires 2WD models with 18-inch tires AWD models...
Page 220 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 221: Engine Compartment
4 -3 . Do-it -yourse lf m a int e na nc e Engine c om pa r t m e nt 1.8 L 4-cylinder (2ZR-FE) engine Engine oil filler cap Battery (→P. 298) (→P. 291) Radiator (→P. 296) Engine oil level dipstick Electric cooling fan (→P.
Page 222 4-3. Do-it-yourself maintenance 2.4 L 4-cylinder (2AZ-FE) engine Engine coolant reservoir Fuse box (→P. 323) (→P. 295) Battery (→P. 298) Engine oil filler cap Radiator (→P. 296) (→P. 291) Electric cooling fans Engine oil level dipstick Condenser (→P. 296) (→P. 290) Washer fluid tank (→P.
Page 223 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil Park the vehicle on level ground. After turning off the engine, STEP wait a few minutes for the oil to drain back into the bottom of the engine.
Page 224 4-3. Do-it-yourself maintenance 2.4 L 4-cylinder (2AZ-FE) engine Full Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 225 4-3. Do-it-yourself maintenance Install the filler cap, turning it clockwise. STEP The approximate quantity of oil needed to raise the level between low and full on the dipstick is indicated as follows: 1.8 L 4-cylinder (2ZR-FE) engine 1.6 qt. (1.5 L, 1.3 Imp. qt.) 2.4 L 4-cylinder (2AZ-FE) engine 1.1 qt.
Page 226 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 227 4-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage Check the oil level on a regular basis. When replacing the engine oil Be careful not to spill engine oil on the vehicle components. Avoid overfilling, as the engine could be damaged. Check the oil level on the dipstick every time you refill the vehicle.
Page 228 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
Page 229 Check the radiator and condenser and remove any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser, as they may be hot and may cause burns.
Page 230 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Make sure to check the fluid type and prepare the necessary items. Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Brake fluid can absorb moisture from the air...
Page 231 Ground cable Checking battery fluid Check the battery condition using the indicator color. Green: Good condition Dark: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Clear or light yellow: Not working properly. Have the battery checked your...
Page 232 4-3. Do-it-yourself maintenance Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
Page 233 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: Do not cause sparks by touching the battery terminals with tools.
Page 234 4-3. Do-it-yourself maintenance NOTICE When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid For vehicles sold in U.S.A. If the washer fluid level is at “LOW” add washer fluid. For vehicles sold in Canada If any washer does not work or the low windshield washer fluid warn- ing light comes on, the washer tank may be empty.
Page 235 4-3. Do-it-yourself maintenance NOTICE Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. Diluting washer fluid Dilute washer fluid with water as necessary. Refer to the freezing temperatures listed on the washer fluid tank.
Page 236: Tires
The tire pressure warning system (if equipped) Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 355) The compact spare tire is not equipped with the tire pressure warning valves and transmitters.
Page 237 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer . (→P. 306)
Page 238 4-3. Do-it-yourself maintenance How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the engine switch STEP OFF. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire infla- STEP tion pressure level.
Page 239 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 240 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- sure warning light does not flash 3 times.
Page 241 4-3. Do-it-yourself maintenance Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 242 4-3. Do-it-yourself maintenance Tire pressure warning system certification For vehicles sold in the U.S.A. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 243 Do not mix tires of different makes, models, tread patterns or tread- wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias-belted, or bias-ply tires. Do not mix summer, all season and winter tires.
Page 244 Repairing or replacing tires, wheels and tire pressure warning valves and transmitters When removing or fitting the wheels, tires or the tire pressure warning valves and transmitters, contact your Toyota dealer as the tire pressure warning valves and transmitters may be damaged if not handled cor- rectly.
Page 245: Tire Inflation Pressure
4 -3 . Do-it -yourse lf m a int e na nc e T ire inflat ion pre ssure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 400)
Page 246 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not at the recommended level STEP...
Page 247 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 248 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling Possibility of blowouts resulting from overheated tires Poor sealing of the tire bead Wheel deformation and/or tire separation A greater possibility of tire damage from road hazards...
Page 249: Wheels
Used wheels l Bent wheels that have been straightened Aluminum wheel precautions l Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 250 4-3. Do-it-yourself maintenance When replacing wheels The wheels of your Toyota, except for the compact spare tire, are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire pressure warning valves and transmitters must be installed.
Page 251: Air Conditioning Filter
4 -3 . Do-it -yourse lf m a int e na nc e Air c ondit ioning filt e r The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch OFF. STEP Open the glove box.
Page 252 4-3. Do-it-yourself maintenance Replacement method Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 253: Key Battery
4 -3 . Do-it -yourse lf m a int e na nc e Key battery (vehicles w ith w ireless remote control) Replace the battery with a new one if it is discharged. You will need the following items: l Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) l Lithium battery CR2025 Replacing the battery...
Page 254 The wireless remote control will not function properly. The operational range is reduced. Use CR2025 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 255 4-3. Do-it-yourself maintenance NOTICE For normal operation after replacing the battery Observe the following precautions to prevent accidents. Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other components inside the remote control. Do not bend either of the battery terminals.
Page 256: Checking And Replacing Fuses
4 -3 . Do-it -yourse lf m a int e na nc e Che ck ing a nd re pla c ing fuse s If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch OFF.
Page 257 4-3. Do-it-yourself maintenance Take out the pullout tool. STEP Only type A fuse can be removed using the pullout tool. For type A and B fuses: Remove the fuse. STEP Check if the fuse has blown. STEP Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 258 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer.
Page 259 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment Fuse Ampere Circuit CDS FAN 30 A Electric cooling fan(s) RDI FAN 40 A Electric cooling fan(s) Anti-lock brake system, vehicle sta- ABS NO. 3 30 A bility control system Anti-lock brake system, vehicle sta- ABS NO.
Page 260 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 60 A Electric power steering 50 A EFI MAIN, HORN, IG2 H-LP LH LO, H-LP RH LO, H-LP H-LP MAIN 50 A LH HI, H-LP RH HI EFI NO. 2 10 A Emission control system Multiport fuel injection system/ EFI NO.
Page 261 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Main body ECU, gauge and meters, daytime running light sys- ECU-B 10 A tem, air conditioning system, wire- less remote control RAD NO. 1 15 A Audio system DOME 10 A Interior lights, personal light, clock SPARE 10 A Spare fuse...
Page 262 4-3. Do-it-yourself maintenance Under the driver’s side instrument panel Fuse Ampere Circuit Parking lights, tail lights, license plate lights, multiport fuel injection TAIL 10 A system/sequential multiport fuel injection system, instrument cluster lights PANEL 7.5 A Switch illumination FR DOOR 20 A Power windows RL DOOR...
Page 263 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Air conditioning system, rear win- HTR-IG 10 A dow defogger WIPER 25 A Windshield wipers RR WIPER 15 A Rear window wiper WASHER 15 A Windshield washer Main body ECU, electric power steering, electric cooling fan(s), shift lock control system, anti-lock brake system, multiport fuel injec- ECU-IG NO.
Page 264 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.
Page 265: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 266 4-3. Do-it-yourself maintenance Rear bulb locations Rear turn signal lights Back-up lights Stop/tail and rear side marker lights License plate lights...
Page 267 4-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams Turn the bulb base counterclock- STEP wise. Unplug the bulb while depress- STEP ing the lock release. Headlight high beams Turn the bulb base counterclock- STEP wise.
Page 268 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. Front fog lights (if equipped) Remove the fender liner bolts STEP and clip. Partly remove the fender liner. STEP Turn the bulb base counterclock- STEP wise.
Page 269 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. Front turn signal/parking and front side marker lights Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 270 4-3. Do-it-yourself maintenance Stop/tail and rear side marker lights, rear turn signal lights and back-up lights Open the back door. STEP Left side Remove the cover. STEP Right side (type A) Remove the cover using the flat- STEP head screwdriver. To protect the cover, place a rag between the flathead screwdriver and the cover.
Page 271 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up light Stop/tail and rear side marker light Remove the light bulb. STEP Rear turn signal light Back-up light Stop/tail and rear side marker light...
Page 272 STEP wise. Remove the light bulb. STEP LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 273 4-3. Do-it-yourself maintenance Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Large drops of water are built up on the inside of the lens.
Page 274 6 -1 . Spe c ific a t ions M a int e na nc e dat a (fue l, oil leve l, e t c .) Dimensions and weights 171.9 in. (4365 mm) Overall length 173.0 in. (4395 mm) Overall width 69.5 in (1765 mm) 61.0 in (1550 mm)
Page 275 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 276 6-1. Specifications Engine number The engine number is stamped on the engine block as shown. 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine...
Page 277 6-1. Specifications Engine 1.8 L 4-cylinder (2ZR-FE) engine Model 2ZR-FE engine 4 cylinder in line, Type 4 cycle, gasoline 3.17 × 3.48 in. Bore and stroke (80.5 × 88.3 mm) Displacement 109.7 cu.in. (1798 cm Drive belt tension 143 ± 22 lb. Valve clearance (engine cold) Intake Automatic adjustment...
Page 278 6-1. Specifications 2.4 L 4-cylinder (2AZ-FE) engine Model 2AZ-FE engine 4 cylinder in line, Type 4 cycle, gasoline 3.48 × 3.78 in. Bore and stroke (88.5 × 96.0 mm) Displacement 144.1 cu.in. (2362 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 0.007 ⎯...
Page 279 4.1 qt. (3.9 L, 3.4 Imp.qt.) 2.4 L 4-cylinder (2AZ-FE) engine 3.8 qt. (3.6 L, 3.2 Imp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and vis- cosity shown below. Recommended oil viscosity...
Page 280 (Reference) 2.4 L 4-cylinder (2AZ-FE) engine 6.0 qt. (5.7 L, 5.0 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 281 Recommended gear oil SAE 75W viscosity Automatic transaxle 1.8 L 4-cylinder (2ZR-FE) engine Fluid capacity 2.6 qt. (2.5 L, 2.2 Imp.qt.) (drain and refill) 2.4 L 4-cylinder (2AZ-FE) engine 3.7 qt. (3.5 L, 3.1 Imp.qt.) Fluid type Toyota Genuine ATF WS...
Page 282 6-1. Specifications NOTICE Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Rear differential (AWD models) Oil capacity 0.5 qt.
Page 283 6-1. Specifications Brakes 1.8 L 4-cylinder (2ZR-FE) engine • With vehicle stability control: 3.4 in. (87 mm) • Without vehicle stability control: 3.2 in. (81 mm) Pedal clearance 2.4 L 4-cylinder (2AZ-FE) engine • AWD models: 3.4 in. (87 mm) •...
Page 284 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P205/55R16 89H, T135/70R16 100M Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm...
Page 285 6-1. Specifications Type C Tire size P205/55R16 89H, T135/70R17 102M 2WD models Front: 32 psi (220 kPa, 2.2 kgf/cm bar) Rear: 32 psi (220 kPa, 2.2 kgf/cm bar) Spare: 60 psi (420 kPa, 4.2 kgf/cm Tire inflation pressure bar) (Recommended cold tire AWD models inflation pressure) Front: 35 psi (240 kPa, 2.4 kgf/cm...
Page 286 6-1. Specifications Type E Tire size P215/45R17 87W, T135/80R16 101M Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) 17 ×...
Page 287 6-1. Specifications Type G Tire size P215/45R18 89W, T135/70R17 102M Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) 18 ×...
Page 288 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam 9006 High beam 9005 Front turn signal/park- ing and front side 3457NA 27/7 marker lights Front fog lights (if ⎯ Exterior equipped) ⎯ Rear turn signal lights Stop/tail and rear side 7443 21/5 marker lights...
Page 289: Specifications
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
Page 290 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
Page 291 6-1. Specifications NOTICE Notice on gasoline quality Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s catalytic converters causing the emission control system to malfunction. Do not use gasohol other than that stated here. Other gasohol may cause fuel system damage or vehicle performance problems.
Page 292: Tire Information
6 -1 . Spe c ific a t ions T ire infor m at ion Typical tire symbols Full-size tire Compact spare tire Tire size (→P. 411) DOT and Tire Identification Number (TIN) (→P. 410) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P.
Page 293 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL”...
Page 294 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal...
Page 295 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
Page 296 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 297 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100.
Page 298 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 299 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 300 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 301 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 302 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 303 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 304: Customization
Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toy- ota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 305 6-2. Customization Customized Item Function Default setting setting Driver's door unlocked in one All doors Unlocking using a key step, all doors unlocked in one unlocked in two step steps Opening driver's door Door lock unlocks all doors (vehicles with power Shifting gears to P door lock unlocks all doors.
Page 306: Initialization
6 -3 . I nit ia liza t ion I t e m s t o init ia lize The following items must be initialized for normal system operation in cases such as after maintenance is performed on the vehicle. Item When to initialize Reference...
Page 307 2 -1 . Driving proc e dure s Driving t he ve hicle The following procedures should be observed to ensure safe driv- ing. Starting the engine →P. 106 Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. STEP (→P.
Page 308 2-1. Driving procedures Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. STEP Set the parking brake. (→P. 118) STEP Shift the shift lever to P. (→P. 110) STEP When parking on a hill, if necessary, block the wheels. Turn the engine switch to the “LOCK”...
Page 309 Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended...
Page 310 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
Page 311 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. Do not under any circumstances shift the shift lever to P (vehicles with an automatic transmission) or R while the vehicle is moving.
Page 312 2-1. Driving procedures CAUTION Do not drive the vehicle off-road. This is not a AWD vehicle designed for real off-road driving. Proceed with all due caution if it becomes unavoidable to drive off-road. Do not drive across river crossings or through other bodies of water. This may cause electric/electronic components to short circuit, damage the engine or cause other serious damage to the vehicle.
Page 313 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in...
Page 314 2-1. Driving procedures CAUTION When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
Page 315 2-1. Driving procedures NOTICE When driving the vehicle Manual transmission Do not shift gears unless the clutch pedal is fully depressed. After shifting, do not release the clutch abruptly. Doing so may damage the clutch, tran- saxle and gears. Do not rest your foot on the clutch pedal while driving. Doing so may cause clutch trouble.
Page 316 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage can result if the pads are not replaced when needed.
Page 317 2 -1 . Driving proc e dure s Engine (ignit ion) sw it ch Starting the engine Automatic transmission Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
Page 318 2-1. Driving procedures Changing engine switch position “LOCK” The steering wheel is locked and the key can be removed. “ACC” Some electrical components such as the audio system can be used. “ON” All electrical components can be used. “START” For starting the engine.
Page 319 2-1. Driving procedures Turning the engine switch from “ACC” to “LOCK” Shift the shift lever to P (auto- STEP matic transmission) or N (man- ual transmission). (→P. 110, 115) Push in the key and turn to the STEP “LOCK” position. Steering lock release When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 320 2-1. Driving procedures NOTICE To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for long periods if the engine is not running. When starting the engine 2.4 L 4-cylinder (2AZ-FE) engine ⎯ Do not crank for more than 30 sec- onds at a time.
Page 321 2 -1 . Driving proc e dure s Aut om at ic t ra nsm ission (if e quippe d) Select a shift position appropriate for the driving conditions. Shifting the shift lever Standard type Multi-mode type While the engine switch is in the “ON” position, depress the brake pedal and move the shift lever.
Page 322 2-1. Driving procedures Shift position uses Function Shift position Standard type Multi-mode type Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving (→P. 112) Position for engine braking Position for more powerful engine braking Position for maximum engine braking : To improve fuel consumption and reduce noises, set the shift lever in the D position for normal driving.
Page 323 2-1. Driving procedures Changing shift ranges in S mode (multi-mode type) Shift the shift lever to the S position and operate the shift lever. Upshifting Downshifting The initial shift range in S mode is automatically set to 4 or 5.
Page 324 2-1. Driving procedures Shift ranges and their functions Shift range Function A gear between 1 and 5 is automatically selected according to vehicle speed and driving conditions. A gear between 1 and 4 is automatically selected according to vehicle speed and driving conditions. A gear between 1 and 3 is automatically selected according to vehicle speed and driving conditions.
Page 325 If the “S” indicator does not come on even after shifting the shift lever to S (multi-mode type) This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in D.)
Page 326 2 -1 . Driving proc e dure s M a nua l t ra nsm ission (if e quippe d) Shifting the shift lever Fully depress the clutch pedal before operating shift lever, and then release the clutch pedal slowly.
Page 327 2-1. Driving procedures Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. 2.4 L 4-cylinder (2AZ-FE) engine (without double wishbone rear suspen- sion) mph (km/h) Shift position Maximum speed 31 (50) 53 (86) 82 (132) 112 (181)
Page 328 2 -1 . Driving proc e dure s Tur n signa l leve r Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 329 2 -1 . Driving proc e dure s Pa rk ing bra ke Sets the parking brake Fully set the parking brake U.S.A. Canada while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while press- ing the button.
Page 330 2 -2 . I nst rum e nt c lust e r Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the “ON” position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed.
Page 331 2-2. Instrument cluster Engine coolant temperature gauge Displays the engine coolant temperature. Automatic transmission shift position indicator lights (if equipped) →P. 110 Odometer and trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset.
Page 332 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter When the headlight switch is turned on, the brightness will be reduced slightly unless the control button is turned fully clockwise. NOTICE To prevent damage to the engine and its components Do not let the indicator needle of the tachometer enter the red zone, which...
Page 333 2 -2 . I nst rum e nt c lust e r I ndic at ors a nd w a r ning light s The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems.
Page 334 2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (→P. 117) (→P. 125) (U.S.A.) Headlight high beam Tail light indicator indicator (→P. 126) (→P. 125) (Canada) Slip indicator Front fog light indicator (→P.
Page 335 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 336 2 -3 . Ope ra t ing t he light s a nd w ipe rs H e a dlight sw it ch The headlights can be operated manually. side marker, parking, tail, license plate and instrument U.S.A. Canada panel lights turn on. The headlights and all lights listed above turn on.
Page 337 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 338 2-3. Operating the lights and wipers Light reminder buzzer A buzzer sounds when the engine switch is turned OFF and the driver's door is opened with the key removed from the engine switch while the lights are turned on. NOTICE To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not run- ning.
Page 339 2 -3 . Ope ra t ing t he light s a nd w ipe rs Fog light sw it ch (if e quippe d) The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam.
Page 340 2 -3 . Ope ra t ing t he light s a nd w ipe rs Windshie ld w ipe rs a nd w a she r Wiper can be operated manually. Intermittent windshield wiper operation Low speed windshield wiper operation High speed...
Page 341 2-3. Operating the lights and wipers The windshield wipers and washers can be operated when The engine switch is in the “ON” position. Intermittent windshield wiper interval mode (if equipped) Wiper intervals can be adjusted for intermittent operation. Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency...
Page 342 2 -3 . Ope ra t ing t he light s a nd w ipe rs Re a r w indow w ipe r a nd w a she r (if e quippe d) Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion...
Page 343 2 -4 . U sing ot he r driving syst e m s Cruise c ont rol (if e quippe d) Use cruise control to maintain a set speed without using the acceler- ator. Setting the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control.
Page 344 2-4. Using other driving systems Canceling and resuming regular acceleration Cancel Pull the lever towards you to cancel cruise control. The speed setting is also can- celed when the brakes are applied or the clutch pedal (manual transmission) depressed. Resume To resume cruise control and return to the set speed, push the lever up.
Page 345 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION To avoid operating the cruise control by mistake Keep the “ON-OFF”...
Page 346 2 -4 . U sing ot he r driving syst e m s Driving a ssist syst e m s To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle.
Page 347 2-4. Using other driving systems When VSC and TRAC are operating If the vehicle is in danger of slip- ping or the front wheels (2WD), or 4 wheels (AWD) spin, the indi- cator flashes to indicate that VSC/TRAC have been engaged. A buzzer (intermittent) sounds to indicate that VSC is operating.
Page 348 • The brake pedal may pulsate slightly after ABS is activated. • The brake pedal may move down slightly after ABS is activated. If the “VSC OFF” indicator light flashes There is a malfunction in the TRAC and VSC systems. Contact your Toyota dealer and have your Toyota inspected.
Page 349 2-4. Using other driving systems EPS operation sound When the steering wheel operates, a motor sound (whirring sound) may be heard. This does not indicate a malfunction. Reduced effectiveness of EPS The effectiveness of EPS is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time.
Page 350 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 351 2 -5 . Driving inform a t ion Ca rgo a nd lugga ge Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. l Be careful to keep the vehicle level.
Page 352 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 148) Example on your vehicle Cargo capacity Total load capacity...
Page 353 2-5. Driving information CAUTION Storage precautions To prevent cargo and luggage from sliding forward during braking, do not stack anything in the luggage compartment. Keep cargo and lug- gage low, as close to the floor as possible. Never allow anyone to ride in the luggage compartment. It is not designed for passengers.
Page 354 2 -5 . Driving inform a t ion Ve hicle loa d lim it s Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. Total load capacity: 850 lb. (385 kg) Total load capacity means the combined weight of occupants, cargo and luggage.
Page 355 2 -5 . Driving inform a t ion Wint e r driving t ips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 356 2-5. Driving information When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission), 1 or R (manual transmission) without setting the park- ing brake.
Page 357 2-5. Driving information Snow chain installation (vehicles with 16-inch and 17-inch tires) Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. Install tire chains on the front tires only. Do not install tire chains on rear tires.
Page 358 2-5. Driving information NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 359 For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Weight limits Confirm that the total trailer weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits.
Page 360 Total trailer weight Tongue load Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer.
Page 361 Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
Page 362 When towing a trailer If the gross trailer weight exceeds 1500 lb. (680 kg), trailer brakes are required. Toyota recommends trailers with brakes that conform to all appli- cable federal and state/provincial regulations. Never tap into your vehicle's hydraulic system, as this will lower the vehi- cle's braking effectiveness.
Page 363 NOTICE When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 364 2-5. Driving information l Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to right.
Page 365 2-5. Driving information l In order to maintain efficient engine braking and electrical charging performance, do not use overdrive (automatic transmission) or the 5th gear (manual transmission). l Due to the added load of the trailer, your vehicle's engine may overheat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade.
Page 366 2-5. Driving information CAUTION To avoid an accident Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.
Page 367 2 -5 . Driving inform a t ion Dinghy t ow ing (a ut om at ic t ra nsm ission) Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
Page 368 2 -5 . Driving inform a t ion Dinghy t ow ing (m a nua l t ra nsm ission) Your vehicle can be dinghy towed in a forward direction (with 4 wheels on the ground) behind a motor home. Towing your vehicle with 4 wheels on the ground To prevent damage to your vehicle, perform the following procedures before towing.
Page 369 2-5. Driving information NOTICE Dinghy towing direction Do not tow the vehicle backwards. Doing so may cause serious damage. To prevent the steering from locking Ensure the engine switch is in the “ACC” position.
Page 370 2-5. Driving information...
Page 371 I f your ve hicle ne e ds t o be t ow e d If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck.
Page 372 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
Page 373 5-1. Essential information Emergency towing procedure STEP Release the parking brake. STEP Shift the shift lever to N. STEP Turn the engine switch to the “ACC” (engine off) or “ON” (engine running) position. CAUTION Caution while towing Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains.
Page 374 5-1. Essential information Towing with a sling-type truck NOTICE To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel-lift type truck from the front 2WD models Release the parking brake.
Page 375 5-1. Essential information AWD models Use a towing dolly under the rear wheels. NOTICE To prevent damaging the vehicle When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 376 5-1. Essential information NOTICE To prevent causing serious damage to the transmission (vehicles with an automatic transmission) Never tow this vehicle from the rear with the front wheels on the ground. To prevent damaging the vehicle (vehicles with a manual transmission) Do not tow the vehicle when the engine switch is in the “LOCK”...
Page 377 5 -1 . Esse nt ia l inform a t ion I f you t hink som e t hing is w rong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 378 5 -1 . Esse nt ia l inform a t ion Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine.
Page 379 5 -1 . Esse nt ia l inform a t ion Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 380 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained...
Page 381 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* •...
Page 382 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 383 If it is, tighten it securely. The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible.
Page 384 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light Check that all doors are Indicates that a door is not closed.
Page 385 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. *: Driver's and front passenger’s seat belt warning buzzers: The driver’s and front passenger’s seat belts warning buzzers sound to alert the driver and front passenger that his or her seat belt is not fastened.
Page 386 5-2. Steps to take in an emergency Front passenger detection sensor and passenger seat belt reminder If luggage is placed on the front passenger seat, the front passenger detection sensor may cause the warning light to flash, even if a passen- ger is not sitting in the seat.
Page 387 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 388 Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 420) However, Toyota recommends that the seat belt reminder buzzer be operational to alert the driver and front passen- ger that the seat belts are not fastened.
Page 389 5-2. Steps to take in an emergency CAUTION Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 390 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 391 5 -2 . St e ps t o t a k e in a n e m e rge nc y I f you have a flat t ire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface.
Page 392 5-2. Steps to take in an emergency Taking out the jack Turn the knobs to the “UNLOCK” STEP position and remove the deck board. Remove the hook. STEP...
Page 393 5-2. Steps to take in an emergency Taking out the spare tire Turn the knobs to the “UNLOCK” STEP position and remove the deck boards. Loosen the center fastener that STEP secures the spare tire.
Page 394 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
Page 395 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel.
Page 396 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 397 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 398 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft• lbf (103 N• m, 10.5 kgf• m) Stow the flat tire, tire jack and all tools. STEP Stowing the flat tire Vehicles with aluminum wheel:...
Page 399 5-2. Steps to take in an emergency Put the flat tire on the deck STEP boards with the outer side of the wheel facing up. Hook the belt clips closest to the buckles onto the front cargo hooks. Pass the belts through the center STEP hole of the wheel.
Page 400 5-2. Steps to take in an emergency Pull the ends of the belts to STEP secure the tire. The compact spare tire The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily only in an emergency. Make sure to check the tire pressure of the compact spare tire.
Page 401 5-2. Steps to take in an emergency CAUTION Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 402 5-2. Steps to take in an emergency CAUTION Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury: Never use oil or grease on the wheel bolts or wheel nuts. The oil or grease can cause the wheel nuts to loosen, causing a seri- ous accident.
Page 403 5-2. Steps to take in an emergency CAUTION When the spare tire is attached The vehicle speed may not be correctly detected, and the following sys- tems may not operate correctly: ABS & Brake assist VSC (if equipped) TRAC (if equipped) Navigation system (if equipped) Also, not only can the following system not be utilized fully, it may actu- ally negatively effect the drive-train components:...
Page 404 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ters Do not use liquid sealants on flat tires.
Page 405 One of the following may be the cause of the problem. l One or both of the battery terminals may be disconnected. l The battery may be discharged. (→P. 379) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 406 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 407 5 -2 . St e ps t o t a k e in a n e m e rge nc y I f you lose your ke ys New genuine keys can be made by your Toyota dealer. Bring a mas- ter key and the key number stamped on the key number plate.
Page 408 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. 1.8 L 4-cylinder (2ZR-FE) engine Remove the engine cover.
Page 409 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible.
Page 410 5-2. Steps to take in an emergency 2.4 L 4-cylinder (2AZ-FE) engine STEP Connecting the jumper cables If required, remove all vent plugs from the booster battery. Lay a cloth over the open vents on the booster battery. (This helps reduce the explosion hazard, personal injuries and burns.) Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle...
Page 411 STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. Avoiding a discharged battery Turn off the headlights and the audio system while the engine is turned off.
Page 412 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 413 5-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle Do not pull- or push-start the vehicle, because the catalytic converter may overheat and become a fire hazard. When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fans or any of the belts when connecting or disconnecting them.
Page 414 Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP STEP...
Page 415 (→ unavailable. P. 396 Have the vehicle checked at the nearest Toyota dealer as soon as possible. Overheating If you observe the following, your vehicle may be overheating. The engine coolant temperature gauge enters the red zone or a loss of power is experienced.
Page 416 5-2. Steps to take in an emergency NOTICE When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.
Page 417 5 -2 . St e ps t o t a k e in a n e m e rge nc y I f t he ve hicle be c om e s st uck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow.

Toyota Matrix 2009 Owner's Manual

Table of Contents

Interior Features

Quick Links

TABLE OF CONTENTS

Chapters

Related Manuals for Toyota Matrix 2009

Summary of Contents for Toyota Matrix 2009

Table of Contents
