- Page 1 Configuration Guide Air Handling Unit Controller US5182 2800 Laura Lane • Middleton, WI 53562 | 800.288.9383 | www.tcsbasys.com 202305...
-
Page 2: Table Of Contents
Introduction ............................3 Getting Started ............................3 US5182-to-Laptop Connection ............................ 3 Using Insight ............................4 Network Setup ................................4 Programming the US5182 .............................. 5 Systems and Setpoints ..............................6 Analog Inputs ..................................7 Digital Inputs ..................................8 Digital Outputs ................................. 8 Analog Outputs ................................9 Additional Functions (1 of 2) ............................ -
Page 3: Introduction
While this configuration process can be accomplished several different ways, the preferred method is to connect a laptop computer directly to the US5182 via a USB cable, and use TCS Insight software to program the unit. This manual will guide you through each step you must take when using this method. -
Page 4: Using Insight
• Identify the COM port you will be using to communicate with the US5182 • Assign a unique device address to the US5182 (if more than one controller is connected to your system) • Populate the I/O tabs under the Programming menu... -
Page 5: Programming The Us5182
When using a USB-C cable for communicating with the US5182, the address will always be zero. Programming the US5182 STEP 1 Click on the US5182 device icon to bring up the device tabs in the main window (this can take several seconds). STEP 2 Click on the Programming tab in the main window. -
Page 6: Systems And Setpoints
Click on the desired section to activate the relevant settings and program the fields. NOTE: Discharge Zone Control should be enabled only if the US5182 is being used as a master controller for a Ubiquity subsystem with a QD2040 or QD3041 building controller. STEP 2... -
Page 7: Analog Inputs
Configuration Analog Inputs Under the Analog Inputs tab, you can enable or monitor settings for the following: • Space Temperature • Return Air • Discharge Air • Discharge Hot • Outdoor Air • Mixed Air The folowing configurable values are available: •... -
Page 8: Digital Inputs
Configuration Digital Inputs Under the Digital Inputs tab, you can enable or monitor settings for the following: • DI 1 – 6 • DI Setpoint Setback • Fan Proving STEP 1 Click on the desired field to program the relevant settings. -
Page 9: Analog Outputs
Configuration Analog Outputs Under the Analog Outputs tab, you can enable or monitor settings for the following: • AO1 – 6 • Modulating Heat/Cool Control • Heat Error PID • Cool Error PID • Discharge Reset • Discharge Tempering • Outdoor Air Damper Control •... -
Page 10: Additional Functions (2 Of 2)
Exit the Insight software by either closing the window or by clicking on the Exit command under the File tab. STEP 2 Disconnect the laptop computer from the US5182. 2800 Laura Lane • Middleton, WI 53562 | 800.288.9383 | www.tcsbasys.com...
