INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
If the information in these instructions are
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
LOG SET MODELS
LS(3236,42)FF-1
For Use With
DVCP(32,36,42)-3 Fireplaces
NOTICE: Ceramic fiber logs may differ in
appearance from those shown in this manual.
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
GAS-FIRED
WARNING
Page 1

Advertisement

loading

Summary of Contents for Empire Comfort Systems WHITE MOUNTAIN HEARTH DVCP32-3

  • Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL LOG SET MODELS INSTALLER: GAS-FIRED LS(3236,42)FF-1 Leave this manual with the appliance. CONSUMER: For Use With DVCP(32,36,42)-3 Fireplaces Retain this manual for future reference. WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2 LS(3236) LOG SET IDENTIFICATION INDEX LETTER PART FRONT & DESCRIPTION NUMBER VIEW VIEW Rear 37698 Left 37699 Front Right 37700 Front Rear 37701 Crossover Right 37702 Crossover Left 37703 Small Page 2 37708-1-0617...
  • Page 3 LS(42) LOG SET IDENTIFICATION INDEX LETTER PART FRONT & DESCRIPTION NUMBER VIEW VIEW Rear 37541 Left 37542 Front Right 37545 Front Rear 37546 Crossover Right 37559 Crossover Left 37549 Small Left 37550 Crossover 37708-1-0617 Page 3...
  • Page 4 LOG INSTALLATION PREPARATION LOG PLACEMENT EMBER AND COAL PLACEMENT The positioning of logs is critical to safe and clean operation After placing logs into position, place dime-sized pieces of of this fireplace. Sooting and other problems may result if the glowing embers over the burner surface.
  • Page 5 LOG SET PLACEMENT - LS3236FF STEP 1. Push up pins 6, 7 and 8 as shown in Figure 2. Replace burner cover inside fireplace. Top View Front View 37708-1-0617 Page 5...
  • Page 6 LOG SET PLACEMENT - LS3236FF STEP 2. Place (Log Index Letter B) onto pins 1 and 2 on the burner. See image below. Top View Front View Page 6 37708-1-0617...
  • Page 7 LOG SET PLACEMENT - LS3236FF STEP 3. Place (Log Index Letter F) onto pins 6 and 8 on the burner. See image below. Top View Front View 37708-1-0617 Page 7...
  • Page 8 LOG SET PLACEMENT - LS3236FF STEP 4. Place (Log Index Letter C) onto pin 3 and pin on log B. See image below. Top View Front View Page 8 37708-1-0617...
  • Page 9 LOG SET PLACEMENT - LS3236FF STEP 5. Place (Log Index Letter D) onto pin on log C and to left side of pilot. See image below. Top View Front View 37708-1-0617 Page 9...
  • Page 10 LOG SET PLACEMENT - LS3236FF STEP 6. Place (Log Index Letter A) onto pins 4 and 5 on the log support bracket. See image below. Top View Front View Page 10 37708-1-0617...
  • Page 11 LOG SET PLACEMENT - LS3236FF STEP 7. Place (Log Index Letter E) onto pin 9 and the pin on log A. See image below. Top View Front View 37708-1-0617 Page 11...
  • Page 12 LOG SET PLACEMENT - LS3236FF STEP 8. This completes the placement of the logs. Place Glowing Embers in locations indicated in Figure 4 along the circular ports. Use dime-shaped size embers. Place ember sticks and coal in area shown in Figure 5. Replace glass door and barrier screen as indicated in fireplace manual.
  • Page 13 LOG SET PLACEMENT - LS42FF STEP 1. Push up pins 6, 7 and 8 as shown in Figure 3. Replace burner cover inside fireplace. Top View Front View 37708-1-0617 Page 13...
  • Page 14 LOG SET PLACEMENT - LS42FF STEP 2. Place (Log Index Letter B) onto pins 1 and 2 on the burner. See image below. Top View Front View Page 14 37708-1-0617...
  • Page 15 LOG SET PLACEMENT - LS42FF STEP 3. Place (Log Index Letter F) onto pin 6 on the burner. See image below. Top View Front View 37708-1-0617 Page 15...
  • Page 16 LOG SET PLACEMENT - LS42FF STEP 4. Place (Log Index Letter C) onto pin 3 and pin on log B. See image below. Top View Front View Page 16 37708-1-0617...
  • Page 17 LOG SET PLACEMENT - LS42FF STEP 5. Place (Log Index Letter D) onto pin on log C and to left side of pilot. See image below. Top View Front View 37708-1-0617 Page 17...
  • Page 18 LOG SET PLACEMENT - LS42FF STEP 6. Place (Log Index Letter G) onto pin 7 and on to the side of log D. See image below. Top View Front View Page 18 37708-1-0617...
  • Page 19 LOG SET PLACEMENT - LS42FF STEP 7. Place (Log Index Letter A) onto pins 4 and 5 on the log support bracket. See image below. Top View Front View 37708-1-0617 Page 19...
  • Page 20 LOG SET PLACEMENT - LS42FF STEP 8. Place (Log Index Letter E) onto pin 8 and the pin on log A. See image below. Top View Top View Front View Front View Page 20 37708-1-0617...
  • Page 21 LOG SET PLACEMENT - LS42FF STEP 9. This completes the placement of the logs. Place Glowing Embers in locations indicated in Figure 4 along the circular ports. Use dime-shaped size embers. Place ember sticks and coal in area shown in Figure 5. Replace glass door and barrier screen as indicated in fireplace manual.
  • Page 22: Appliance Service History

    APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 22 37708-1-0617...
  • Page 23: Master Parts Distributor List

    This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F.
  • Page 24 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 24 37708-1-0617...
