- Page 1 INDUSTRIAL SEWING MACHINE Attachment MODEL MP-G10-NC MP-G20-NC TECHNICAL MANUAL Needle Cooler A181E022P01...
-
Page 3: For Safe Use
FOR SAFE USE Before the installation, operation, and inspection for this product, read the “FOR SAFE USE” and the technical manuals carefully. Also read the other technical manuals, “Sewing Machine Head”, “Control Unit” and “Operation Panel” describing some instructions, which are not in this manual, and use the sewing machine properly. -
Page 4: Applicable Models
1. Features The Needle Cooler will cool the needle heated by friction with the sewing material. 2. Applicable models Name Applicable models MP-G10-NC PLK-G1010 MP-G20-NC PLK-G2010R 3. Specifications ： DC24V Control power supply ： 0.5 MPa（5 kgf /cm ）or more... - Page 5 4. Configuration The Fig. numbers in the drawing correspond to the part numbers given in the following explanations. When ordering service parts, please specify in the Parts No. (M********). 4.1 Needle cooler mechanism - 2 -...
- Page 6 4.1 Needle cooler mechanism (Parts list) 部品コード 数量 品 名 Description Parts No. Amt. Req. M91055089 ﾉｽﾞﾙ Nozzle MH10N0780 ﾎﾙﾀﾞ Holder M91073004 SW-PW ﾌﾟﾗﾏｲﾅﾍﾞﾈｼﾞ M4X16 Screw M4X16 MH10N0758 ﾌﾞﾗｹｯﾄ Bracket MH10N0352 ｷﾝｿﾞｸｶﾗｰ Metal collar M91560089 ﾌｨﾝｶﾞｰﾊﾞﾙﾌﾞ Finger valve M91058004 SW-PW ﾌﾟﾗﾏｲﾅﾍﾞﾈｼﾞ M4X6 Screw M4X6 M95008017 ｾﾌﾃｨｿｹｯﾄ...
- Page 7 4.2 Pneumatic pressure control unit MP-G10-NC MP-G20-NC 4.3 Accessories - 4 -...
- Page 8 4.2 Pneumatic pressure control unit (Parts list) 部品コード 数量 品 名 Description Parts No. Amt.Req. MH25A1601 ﾃﾞﾝｼﾞﾍﾞﾝﾄﾘﾂｹｲﾀ Valve mounting plate M91066004 SW-PW ﾌﾟﾗﾏｲﾅﾍﾞﾈｼﾞ M4X25 Screw M4X25 ME10X0599 ﾃﾞﾝｼﾞﾍﾞﾝｸﾐﾀﾃ Solenoid valve assy M90511050 ｻﾞｶﾞﾈ 5 Washer 5 M95003017 ｾﾌﾃｨｿｹｯﾄ M5X8 Safety socket bolt M5X8 MH10N0508 ｾﾂｿﾞｸﾃﾞﾝｾﾝｸﾐﾀﾃ...
-
Page 9: Assembly Procedures
5. Assembly procedures CAUTION ★ To work in the presence of residual pressure in the pneumatic circuit It is dangerous. Please work after you remove the residual pressure always. The method of removing the residual pressure, and pull up the handle of the pressure regulating filter regulator, can be done by turning counter-clockwise until the pressure gauge shows 0. - Page 10 5.3 Installing the pneumatic pressure control related parts and piping ( in the case of MP-G10-NC ) (1) Please fix with two wood screws provided the pneumatic pressure control unit of sewing machine table underside as shown in Figure 4.
- Page 11 5.5 How to setup and cable connection (1) Insert the connector of the solenoid valve assembly in to the general purpose output connector CON M (15P). (2) Press the on the standard screen to open the MENU mode. (3) Press the in the menu icon.
-
Page 12: Operation
6. Operation CAUTION Assembly of this device is completed, please check your work once again. Because there is a case to unexpected behavior, please away from the sewing machine when the power is turned on and the air pressure. (1) Pull up on the handle of the filter regulator, adjust to 0.4MPa(4kgf/cm ) air pressure by turning in a clockwise direction. - Page 13 MEMO...
