Ultra PLUS+ 750 Lo-Boy Sprayer
Model 231–574, Series A
REF
NO. PART NO.
DESCRIPTION
1
065–312
CONDUIT, electrical
specify length when ordering
8
110–963
SCREW, serrated flange, hex hd,
5/16–18 x 3/4"
9 100–069
BALL, steel, 1/4" dia.
10
110–996
NUT, heavy hex, 5/16–18 unc–2a
13
100–643
SCREW, socket head, 1/4–20 x 1"
14
101–242
RING, retaining
16
100–644
SCREW, socket head, 1/4–20 x 0.75" 2
19
104–811
HUBCAP
20
105–510
LOCKWASHER, spring, 1/4"
21
106–062
WHEEL, semi–pneumatic
22
186–126*
LABEL, warning
23
106–115
LOCKWASHER, spring, 3/8"
24
107–209
SCREW, filh, no. 8–32 x1"
25
107–210
CAPSCREW, sch, 3/8–16 x 1–1/2"
26
107–218
CAPSCREW, sch, 1/4–20 x 2.75"
27
100–020
WASHER
29
107–447
SEAL, conduit, see page 28
31
108–460
CONNECTOR, conduit, 45
33
105–521
PLUG, tubing
34 108–865
SCREW, pan head, no. 8 x 3/8"
35
109–032
SCREW, pnhd, 10–32 x 1/4"
36
188–161
HOSE, drain
37
103–117
RING, retaining
38
178–342
CLIP, small
39
109–046
ADAPTER, female, ORS 3/8–18 npt(f) 1
11/16–16 UN thread
40
162–453
NIPPLE, 1/4 npt(m) x 1/4 npsm
41
185–952*
LABEL, DANGER, English
42
176–817
SPRING, retaining
43
176–818
PIN, straight, hdls,
0.3125" dia x 1.023"
44
110–240
SPEED NUT
45
178–034*
TAG, WARNING
47
178–941
NUT, hex
49
179–899
COVER, housing
50
100–509
PLUG, pipe, 1/4–18 npt
51
179–961
GEAR REDUCER
53
183–770
STRAINER
56
290–028
LABEL, ID, motor cover, left
57
290–029
LABEL, ID, motor cover, right
58
290–027
LABEL, ID, front cover
59
238–343
SHIELD, motor
includes items 34, 41, 56, 57
62
178–566
SLEEVE
63
290–024
LABEL, ID, control, top
64
290–033
LABEL, ID, control, bottom
65
206–994
THROAT SEAL LIQUID, 8 OZ
66
214–570
FLUID FILTER
Includes 66a and 66b
see manual 307–273 for parts
Parts List – Sprayer
QTY
0.7 ft
11
2
8
2
2
2
6
2
1
4
4
4
2
4
2
1
2
10
4
1
2
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
REF
NO. PART NO.
DESCRIPTION
66a
100–040
.PLUG
66b
162–453
NIPPLE, 1/4 npt(m) x 1/4 npsm
67
220–369
DRIVE HOUSING
includes replaceable items 67a and 67b
67a
178–967
.WASHER, silver–colored
67b
107–089
.WASHER, bronze–colored
68
218–034
CONNECTING ROD
69
218–035
BEARING HOUSING
70
223–748
HOSE, grounded, nylon,1/4" ID
cpld 1/4 npsm (f), 29" (715 mm),
spring guards both ends
71
183–769
TUBE, suction
73
222–376**
MOTOR, ELECTRIC
includes replaceable items 73a to 73d
(which are shown on page 33
and one of item 9
73a
107–267
.TERMINAL, female; See page 33
73b
107–504
.TERMINAL, female; See page 33
73c
103–885
.TERMINAL, wire, female,
snap–on; See page 33
73d
185–951*
.LABEL, DANGER, English
74
237–677
VALVE, pressure drain
76
222–580
DISPLACEMENT PUMP
See page manual 307–806 for parts
77
183–288
HANDLE, cart
78
221–119
FRAME, sprayer
80
108–982
CONNECTOR, tube
83
185–384
BRACKET
84
185–407
SPACER
85
110–229
SWIVEL
86
188–150
HOSE, suction
88
103–927
CLAMP, hose
89
154–636
WASHER
90
103–473
TIE, wire
91
183–275
SPACER, wheel
92
189–943
LABEL, warning
94
110–220
UNION, adapter, swivel
100
238–361
HOSE, grounded, nylon, 1/4" ID,
cpld 1/4 npsm(f), 50 ft (15 m)
spring guards both ends
101
238–358
HOSE, grounded, nylon, 3/16" ID,
cpld 1/4 npsm(f), 3 ft (.9 m),
spring guards both ends
102
222–667
SPRAY GUN
see manual 307–614 for parts
103
237–859
GUARD, tip, RAC, Performance Series 1
104
221–621
TIP, spray, 621
*Extra Danger and W arning tags and labels available free.
**Motor Brush Repair Kit 220–853 is available.
Order separately.
QTY
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
2
2
2
1
1
1
2
