DEVIreg™ 233
• Do not expose the thermostat to moisture, water,
dust, and excessive heat.
2
Mounting Instructions
Please observe the following placement guidelines:
• Place the floor sensor in a conduit in an appropriate
place where it is not exposed to sunlight or draft
from door openings.
• Equally distant and >2cm from two heating cables.
• The conduit should be flush with the floor surface -
countersink the conduit if necessary.
• Route the conduit to the connection box.
• The bending radius of the conduit must be min
50mm.
Installation Guide
Place the thermostat at a suitable height
on the wall.
In wet rooms, place the thermostat according to local
regulation on IP classes. Do not install the thermostat
in small bathrooms with poor ventilation, nor close
to the toilet due to the risk of condensed water and
water splash.
Note: A floor sensor enables a more accurate
temperature control and is recommended in all floor
heating applications and mandatory under wooden
floors to reduce the risk of over-heating the floor.
5
