Page 1: Installation Instructions
Installation Instructions Doorphone Card Model KX-TD161 Please read this manual before installing the card. - Page 2 Thank you for purchasing the Panasonic Card. Doorphone Card Supports 4 doorphones and 4 door openers. The doorphone is an option (KX-T30865). Contents Location of the Card ..... 3 Installation for the Card .
- Page 3 Location of the Card The location of the optional card is shown below. Precaution: To protect the printed circuit boards (P- boards) from static electricity, do not touch parts on the P-boards in the main unit and on the optional cards. Front cover is open.
- Page 4 Doorphone Card Connector Front cover is open. KX-TD1232 DOORPHONE Doorphone Card...
- Page 5 Installation for the Card 1. Set the power switch on the main unit to the OFF position and disconnect the power cord from the AC outlet. Power Switch Disconnect from AC outlet Disconnect from AC outlet Power Switch...
- Page 6 Loosen the two screws on the right side of the main unit and open the front cover in the direction of arrow Note The two screws are attached to the front cover • with springs so that they will not be lost. 3.
- Page 7 Before installing the Doorphone Card to the main unit, install the Doorphone (KX-T30865). For details about the doorphone, refer to the Installation Manual. 1. Connect two 4-conductor modular connectors to the Doorphone Card Cabinet, and pass the cords through the grooves in the cabinet. 2.
- Page 8 3. Connect the cord to the Doorphone Card Connector. KX-TD1232 KX-TD816 To Terminal Box Installation...
- Page 9 Wiring of the Doorphone 1. Connect the Doorphone Card to the terminal box using two 4-conductor modular connectors. 2. Connect the wires of doorphone 1 to the red and green screws of the terminal box. 3. Connect the wires of doorphone 2 to the yellow and black screws of the terminal box.
- Page 10 KX-TD816 View of Doorphone Connector Jack Doorphone 4 Doorphone 3 Doorphone 2 Doorphone 1 4-conductor wiring is required. Doorphone 3 (KX-T30865) Yellow 4-conductor wiring is required. Doorphone 1 (KX-T30865) Yellow Terminal Box Doorphone 4 (KX-T30865) Black Green Terminal Box Doorphone 2 (KX-T30865) Black Green...
- Page 11 KX-TD1232 View of Doorphone Connector Jack Doorphone 4 Doorphone 3 Doorphone 2 Doorphone 1 Note • NB Colors shown on the above diagram indicate the internal cable connections of the Terminal Box. 4-conductor wiring is required. Doorphone 3 (KX-T30865) Yellow 4-conductor wiring is required.
- Page 12 Connecting Door Openers Loosen the screw to remove the cover. Loosen the screws on the terminal strip.
- Page 13 3. Insert the wires coming from the door openers into holes and tighten the screws. Pass all the wires through the Holder. Note • Set the door opener paired with the doorphone. • For wiring, UL 1015, AWG 22 twisted wire or the equivalent is recommended.
- Page 16 Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way, Secaucus, New Jersey 07094 www.panasonic.com Panasonic Sales Company (“PSC”), Division of Matsushita Electric of Puerto Rico, Inc. Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park, Carolina,...
