Table of Contents

IMPORTANT SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 1 - Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Step 2 - Installation of the Indoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Step 3 - Installation of the Outdoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Step 4 - Final Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operating Range
The following information lists the operating range specific to each model.
ASH124UCDDA
ASH3036UCDDA
ASH4248UCDDA
NOTES:
• To achieve optimal capacity and efficiency at 5°F (-15°C) and below it is recommended to operate indoor fan in Turbo
Mode.
• It is recommended to have a secondary heating source(s) available in case the temperature drops below the operating
range.
*Install Wind Baffle to expand cooling operating range to -4F - 115F
Record Keeping
Thank you for purchasing this GE Appliances product. This
installation manual will help you get the best performance from
your new heat pump.
For future reference, record the model and serial number located
on the label on the side of your air conditioner/heat pump, and the
date of purchase.
Staple your proof of purchase to this manual to aid in obtaining
warranty service if needed.
To register your new GEA Duct Free System go to
GEAppliances.com/ductless/registration-form and input the
model/serial number information on this page. To receive a 10-
year compressor and parts warranty, registration is required within
60 days of installation.
31-5000788 Rev. 0
Cooling*: 23°F -115°F
Heating: -15°F - 75°F
_____________________________________
Model number
_____________________________________
Serial number
_____________________________________
Date of purchase
3
