Warning: All work related to the installation of this product should be qualified service personnel or system installer.
Features
The Data Multiplex Board, WV-PB4164, is an optional board to be installed in the Digital Disk Recorder, WJ-RT416.
Installation of this board allows users to control 4 cameras through coaxial communication cables.
Precautions
Unplug the power cord from the WJ-RT416 before
installing the board.
This board is exclusively designed for the WJ-RT416
(sold separately).
Do not install this board in other devices or use this
board independently.
Keep unused board in an antistatic bag.
The board is shipped in an antistatic bag. Discharge
static electricity from your body by touching a metal
object such as a metal locker before opening the bag
to protect the board from static electricity.
Do not touch the parts (circuits) on the board.
The parts (circuits) on the board are vulnerable to static
electricity.
Do not touch the parts on the board directly to prevent
the board from damage caused by static electricity.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Data Multiplex Board
WV-PB4164
Model No.
Discharge static electricity before touching the
board.
Before touching the board, discharge static electricity
from your body by touching a metal object such as a
metal locker. When handling the board, hold only the
back end part (connector side) even after discharging
static electricity.
Fix the board with the screws firmly.
Make sure that the board is firmly fixed in Network Disk
Recorder by tightening the fixing screws.
If the board is not fixed firmly, it may damage both the
board and the Digital Disk Recorder.
Handle with care.
Do not strike or shake the board, as this may cause
damage.
Contact a dealer when having a problem.
Turn off the power of the Digital Disk Recorder immedi-
ately and unplug the power plug from the AC outlet,
and then contact qualified service personnel.
Instructions

Advertisement

Table of Contents
loading

Related Manuals for Panasonic WJ-RT416

Summary of Contents for Panasonic WJ-RT416

  • Page 1 Warning: All work related to the installation of this product should be qualified service personnel or system installer. Features The Data Multiplex Board, WV-PB4164, is an optional board to be installed in the Digital Disk Recorder, WJ-RT416. Installation of this board allows users to control 4 cameras through coaxial communication cables.

  • Page 2: Limitation Of Liability

    Limitation of Liability THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY PAR- TICULAR PURPOSE, OR NON-INFRINGEMENT OF THE THIRD PARTY’S RIGHT. THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR TYPOGRAPHICAL ERRORS.

  • Page 3: Installations

    Installations Remove the screws and slide the cover backward to detach the cover from the body. Remove the 4 screws securing the Data Multiplex Board. MPX board...
  • Page 4 Connect the blue connectors of 12-pin and 13-pin cables that are supplied to the corresponding blue connectors of the CODEC board below the Data Multiplex Board. Then, connect the blue connectors of 4-pin and 8-pin cables that are supplied to the corresponding blue connectors of the CPU board. Set all the switches (S1 - S4) on the main board of the recorder to "OFF".
  • Page 5 Connect the other side connectors of the cables that were connected in the step 3 to the corresponding connec- tors of the additional Data Multiplex Board. Slide the cover back to the original position and secure the cover with the screws. 12-pin connector 13-pin connector 8-pin connector...

  • Page 6: Specifications

    Setup • Check the menu of the WJ-RT416 to see whether the board has been successfully installed. • Refer to the operating instructions of the Digital Disk Recorder WJ-RT416 for further information. Specifications Operating Temperature: Dimensions: Weight: Weight and dimensions indicated are approximate.
