- Page 1 GS-5424PLC V2, GS-5216PLC & GS-5210PL Quick Installation Guide 11-2020 / v1.0...
-
Page 2: Table Of Contents
Contents I. Product Information ............1 I-1. Package Contents ............... 2 I-2. Hardware Overview ............2 I-3. LED Status ................4 II. Getting Started the Configuration Utility ....5... -
Page 3: Product Information
You can find all supporting documents from the link below or via QR Code: https://www.edimax.com/download (Once you’ve visited the Edimax official website, please enter the model #. into the search box to search for your product.) -
Page 4: I-1. Package Contents
Before start using this product, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s): Surveillance Quick Rack-Mount Power Console Model# Installation Web-Smart Cord Cable Guide Switch GS-5424PLC V2 GS-5216PLC GS-5210PL I-2. Hardware Overview GS-5424PLC V2:... - Page 5 GS-5216PLC: 9 10 GS-5210PL: 9 10 1 2 3 GS-5424PLC V2 GS-5216PLC GS-5210PL Reset Button Reset Button Reset Button LED (PoE/Alert, SYS LED (PoE/Alert, PWR) LED (PoE/Alert, SYS) PWR) LED PoE LED PoE LED Link/Act LED Link/Act LED Link/Act LED PoE...
-
Page 6: I-3. Led Status
I-3. LED Status Function Status Description On (Amber) Port is connected, Link at 10/100M On (Green) Port is connected, Link at 1000M Data Rate: Port is disconnected or link failure 10/100/1000M Flashing Sending or receiving data (Amber or Green) Feeding power to PoE devices PoE function is not active On (Green) Port is connected, Link at 1000M... -
Page 7: Getting Started The Configuration Utility
II. Getting Started the Configuration Utility This section describes how to navigate the web-based switch configuration utility. Be sure to disable any pop-up blocker. Launching the Configuration Utility: To open the web-based configuration utility: 1. Open a Web browser. 2. Enter the IP address of the device you are configuring in the address bar on the browser (factory default IP address is 192.168.2.1) and then press Enter. - Page 8 4. The first time that you log in with the default username and password, you are required to enter a New Password and Confirm Password 5. For more information about Web-based Configuration Utility, please download User Manual from EDIMAX Download Center: https://www.edimax.com/download NOTE: Your computer’s IP address must be in the same subnet as the switch.
- Page 9 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
- Page 10 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 11 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/30/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/30/EU.
- Page 12 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: 16-Port Gigabit PoE Switch, 2 RJ45/2 SFP combo ports Model No.: GS-5210PL...
- Page 13 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: 18-Port Gigabit PoE Switch, 2 RJ45/2 SFP combo ports Model No.: GS-5216PLC...
- Page 14 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: 28-Port Gigabit PoE Switch, 4 RJ45/4 SFP combo ports Model No.: GS-5424PLC V2...
