- Page 1 DVI E XTENSION YSTEM BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2007 Broadata Communications, Inc.
- Page 2 This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 3: Table Of Contents
4.0 MAINTENANCE AND TROUBLESHOOTING....9 4.1 MAINTENANCE ...............9 4.2 TROUBLESHOOTING ............9 5.0 SPECIFICATIONS ............11 6.0 SERVICE PROCEDURE ..........12 6.1 REPLACEMENT POLICY ..........12 6.2 RETURN AND REPAIR SERVICE ......... 12 7.0 LIMITED WARRANTY ............ 13 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
The 4800/4802 Series is a high performance, yet affordable, Fiber Optic DVI Extension System that is designed to carry one (1) DVI channel, over long distances through four (4) multimode fibers (for 4800 Series) or through two (2) multimode fibers (for 4802 Series). -
Page 5: Setup
+5V pin. The receiver (RX) module should be supplied by an AC/DC power adapter. In general, most notebook PCs require using an AC/DC power adaptor for the TX module. Broadata Technical Support, (800) 214-0222... -
Page 6: Installation
UXGA 60Hz. 3. Plug the transmitter module directly into the DVI receptacle of the PC and confirm if the blue LED is ON. Or, connect the 5V power adapter into the power jack of the transmitter. Broadata Technical Support, CustomerService@Broadatacom.com... - Page 7 Note: If you cannot see the initial screen of the OS system and have skipped Step 1 and Step 2, you have to follow Step 1 and Step 2 instructions. 9. See processing to adjust the system screen. Broadata Technical Support, (800) 214-0222...
-
Page 8: Maintenance And Troubleshooting
Reset the system by un-plugging and re-plugging the transmitter DVI port or receiver DVI port, or by un-plugging and re-plugging the power cord plugs of the transmitter and receiver modules. g. Re-boot up the system while connecting the optical DVI extension module. Broadata Technical Support, CustomerService@Broadatacom.com... - Page 9 Display Properties of Windows and click the Settings tab. b. Ensure that the resolution setting is less than WUXGA (1920 x 1200) at 60Hz refresh ratio. c. Reset the system. Disconnect and reconnect the optical DVI cables or 5V power adapters. Broadata Technical Support, (800) 214-0222...
-
Page 10: Specifications
0.59” x 1.54'' x 2.33” Standalone (4802 Series) 0.59” x 1.54” x 2.33” Card-cage plug-in card 5.24'' x 0.94'' x 11.6'' Power Level +5VDC @ 0.32A (4800 Series) +5VDC @ 0.6A (4802 Series) Operating Temperature 0 to +50 Humidity 0 to 95% RH, non-condensing... -
Page 11: Service Procedure
The BCI 4800/4802 System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 12: Limited Warranty
Fiber Optic DVI Extension System 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 13 BCI 4800/4802 User’s Manual Fiber Optic DVI Extension System Notes Broadata Technical Support, (800) 214-0222...
- Page 14 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-4800B...
