Broadata LBO-H/DP-EAD-T Manual

Link bridge fiber optic hdmi/displayport transmitter system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LBO-H/DP-EAD-T
L
B
F
O
TM
INK
RIDGE
IBER
PTIC
HDMI/D
P
ISPLAY
ORT
T
S
RANSMITTER
YSTEM
BCI reserves the right to make changes to the products described herein without prior
notice or consent. No liability is assumed as a result of their use or application. All
rights reserved.
©2015 Broadata Communications, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Broadata LBO-H/DP-EAD-T

Summary of Contents for Broadata LBO-H/DP-EAD-T

  • Page 1 HDMI/D ISPLAY RANSMITTER YSTEM BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2015 Broadata Communications, Inc.
  • Page 2 LBO-H/DP-EAD-T User Manual Link Bridge Fiber Optic HDMI/DisplayPort Transmitter SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS AS OUR PRODUCTS CONTAIN CLASS I LASER PRODUCTS WARNING This product is a CLASS I LASER PRODUCT only when the units are connected with a fiber optical cable.

  • Page 3: Table Of Contents

    5.0 MAINTENANCE AND TROUBLESHOOTING ....13 5.1 MAINTENANCE .............. 13 5.2 TROUBLESHOOTING ........... 13 6.0 SPECIFICATIONS ............15 7.0 SERVICE PROCEDURE ..........16 7.1 REPLACEMENT POLICY ..........16 7.2 RETURN AND REPAIR SERVICE ......... 16 8.0 LIMITED WARRANTY ............ 17 Broadata Technical Support, (800) 214-0222...

  • Page 4: Product Description

    60Hz) or 720p/1080i/1080p HDTV video resolution. DVI video is also available through a DVI-to-HDMI adapter cable. No user adjustment is required for the LBO-H/DP-EAD-T unit due to the use of advanced digital fiber optic transmission system technology with zero compression and zero bit reduction.
  • Page 5 PWR/ LINK D A TA HDMI IN SPDIF DISPLAY PORT AUDIO HDMI LB - H / D - EAD AUTO Figure 1-1 LBO-H/DP-EAD-T Front Panel REAR PANEL +12VDC 1.5AMP LINK Figure 1-2 LBO-H/DP-EAD-T Rear Panel Broadata Technical Support, (800) 214-0222...

  • Page 6: Setup

    (also known as the minimum bend radius). 2.2 Cabling and Connectors In order to setup the LBO-H/DP-EAD-T properly, make sure to observe the following instructions when installing the proper cables. The LBO-H/DP-EAD-T requires two parts to the cabling setup, the electrical and the optical.

  • Page 7: Display Video Interface

    The HDMI video connection is the HDMI plug connectors for the video input port. Use the following instructions to properly connect your video as illustrated in Figure 2-2. Connect the LBO-H/DP-EAD-T (Transmitter) unit’s to HDMI video input port to the user’s HDMI video source with the appropriate HDMI cables.

  • Page 8: Audio Interface

    To send audio signals, label and connect one stereo audio-jack cable to the “AUDIO” connector of the line level or digital audio source. On the LBO-H/DP-EAD-T unit, connect the other end of the cables to the front panel stereo jack connector labeled “AUDIO IN”...

  • Page 9: Optical Fiber Connection

    1. Ensure the power is off before proceeding with the fiber optic cable installation. 2. Prior to connecting the fiber optic cables, remove and save the dust caps from the optical port of the LBO-H/DP-EAD-T units. Clean the fiber optic connector and use a lint-free cloth dampened with alcohol to thoroughly wipe the side and end of the ferrule.

  • Page 10: Dc Power Connection

    Link Bridge Fiber Optic HDMI/DisplayPort Transmitter 3.0 DC Power Connection Congratulations! You are now ready to power up the LBO-H/DP-EAD-T and set up your network connection. In order to make sure that you have a proper installation, please observe the following: 1.

  • Page 11: Operation

    Fiber Optic HDMI/DisplayPort Transmitter 4.0 OPERATION After the installation procedure is completed, the units are ready for operation. To operate the LBO-H/DP-EAD-T unit, simply apply power as indicated in the previous sections. The following describes the LED activity. LED Indicator Description When power is connected, this LED turns RED.

  • Page 12: Maintenance And Troubleshooting

    However, observe the following light indicators to make sure that the unit is working properly: 5.2 Troubleshooting If the LBO-H/DP-EAD-T units do not operate properly after installation, check for: possible cable breaks, loose connections, and incorrect cable connections. If a problem exists on the fiber link, please check your fiber connectors for improperly cleaned fiber cables and connectors.
  • Page 13 Both ends of the link are connected to the corresponding equipment and to the same corresponding channel port. c. Cable connections at both the video/audio channels are securely fastened to each connector. Turn the power off, then back on to reset the link. Broadata Technical Support, (800) 214-0222...

  • Page 14: Specifications

    LBO-H/DP-EAD-T User Manual Link Bridge Fiber Optic HDMI/DisplayPort Transmitter 6.0 SPECIFICATIONS Video Resolution Up to 1080p@60Hz or 1920x1200@60Hz Connector HDMI Female Plug/DisplayPort Protocol DDC/EDID/HDCP Compatible Transmission Cable Type Multimode Number of Cables Connector Physical Dimension 8.36”(W) x 4.23”(D) x 1.12”(H) Power Level (max.)

  • Page 15: Service Procedure

    U.S. Please call Customer Service at 800-214-0222 for information. 7.2 Return/Repair Service The LBO-H/DP-EAD-T System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc.

  • Page 16: Limited Warranty

    Fiber Optic HDMI/DisplayPort Transmitter 8.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole...
  • Page 17 LBO-H/DP-EAD-T User Manual Link Bridge Fiber Optic HDMI/DisplayPort Transmitter Broadata Technical Support, (800) 214-0222...
  • Page 18 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBOH/DPEADT...
