Crestron TSW-550/750/1050-TTK
& TSW-550/750/1050-SMK
TableTop and Swivel Mount Kits
Installation Guide

Advertisement

Table of Contents
loading

Summary of Contents for Crestron TSW-550-TTK

  • Page 1 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK TableTop and Swivel Mount Kits Installation Guide...
  • Page 2 States and/or other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
  • Page 3: Table Of Contents

    Installation ......................... 10 Resources ..........................21 Further Inquiries ......................21 Future Updates ......................21 Return and Warranty Policies ....................22 Merchandise Returns / Repair Service ..............22 Crestron Limited Warranty ..................22 Installation Guide – DOC. 7411C Contents • i...
  • Page 5: Tabletop And Swivel Mount Kits: Tsw-550/750/1050-Ttk & Tsw-550/750/1050-Smk

    Kits TableTop and Swivel Mount Kits: TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Introduction The TSW-550-TTK, TSW-750-TTK and TSW-1050-TTK provide ® stylish and convenient tabletop enclosures for Crestron TSW-550, TSW-750 and TSW-1050 Touch Screens (respectively). The touch screen is angled when installed in the enclosure. The complete assembly may be placed on any flat, level surface.
  • Page 6: Specifications

    Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Specifications Specifications for the TSW-550/750/1050-TTK are listed in the following table. TSW-550/750/1050-TTK Specifications SPECIFICATION DETAILS Enclosure Plastic, black or white; 38º fixed angle device opening; freestanding or swivel mount installation* Dimensions TSW-550-TTK Height 3.11 in (79 mm);...
  • Page 7 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits TSW-550/750/1050-TTK Specifications (Continued) SPECIFICATION DETAILS Dimensions (Continued) TSW-750-TTK (with TSW-750 installed) Height 3.79 in (97 mm); 3.92 in (100 mm) with swivel mount Width 7.59 in (193 mm) Depth 4.43 in (113 mm) TSW-1050-TTK Height 4.01 in (102 mm);...
  • Page 8 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK TSW-550/750/1050-TTK Specifications (Continued) SPECIFICATION DETAILS Available Models (Continued) TSW-1050-TTK-B-S TableTop Kit for TSW-1050, Black Smooth TSW-1050-TTK-W-S TableTop Kit for TSW-1050, White Smooth Available Accessory TSW-550/750/1050-SMK Swivel Mount Kit for TSW-550-TTK, TSW-750-TTK & TSW-1050-TTK * TSW-550/750/1050-SMK Swivel Mount Kit sold separately.
  • Page 9: Physical Description

    Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits Physical Description TSW-550-TTK Overall Dimensions (Front View) 4.95 in (126 mm) 3.12 in (79 mm) 5.57 in (142 mm) TSW-550-TTK Overall Dimensions (Side View, Shown Without and With TSW-550 Installed) 3.64 in 3.11 in (92 mm) (79 mm) 3.72 in...
  • Page 10 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK TSW-750-TTK Overall Dimensions (Front View) 6.63 in (169 mm) 3.94 in (100 mm) 7.18 in (183 mm) TSW-750-TTK Overall Dimensions (Side View, Shown Without and With TSW-750 Installed) 3.79 in 3.25 in (97 mm) (83 mm) 4.15 in...
  • Page 11 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits TSW-1050-TTK Overall Dimensions (Front View) 6.95 in (176 mm) 4.95 in (126 mm) 7.91 in (201 mm) TSW-1050-TTK Overall Dimensions (Side View, Shown Without and With TSW-1050 Installed) 4.79 in 4.01 in (122 mm) (102 mm) 5.37 in...
  • Page 12: Setup

    Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Setup Supplied Hardware The hardware supplied with the TSW-550/750/1050-TTK is listed in the following table. Supplied Hardware for the TSW-550/750/1050-TTK DESCRIPTION PART NUMBER QUANTITY Plastic, Strain Relief, Black 2033955 Plastic, Strain Relief, Gray 2033954 Overlay, Template, Table...
  • Page 13 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits The hardware supplied with the TSW-550/750/1050-SMK is listed in the following table. Supplied Hardware for the TSW-550/750/1050-SMK DESCRIPTION PART NUMBER QUANTITY Assembly, Swivel Stop 4504353 Plate and Screw Metal Washer, Keyed, 4506321 Swivel Stop Cork/Rubber Washer,...
  • Page 14: Installation

    Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Installation To attach a TSW-550, TSW-750 or TSW-1050 touch screen to the TSW-550/750/1050-TTK and mount it using the optional swivel mount kit, refer to the following procedures. Preparing the TSW-550/750/1050-TTK The TSW-550/750/1050-TTK comes with parts for routing device cabling through either the back of the unit or through the bottom for a neat appearance.
  • Page 15 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits TSW-550/750/1050-TTK Showing Metal Bracket and Plastic Cover (TSW-750-TTK Shown) Metal Bracket Plastic Cover TSW-550/750/1050-TTK Bottom View Showing Location of Screws (TSW-750-TTK Shown) Remove These Screws to Release Metal Bracket 2. With the metal bracket removed, pull downward on the plastic cover to remove it from the TSW-550/750/1050-TTK.
  • Page 16 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Strain Relief on Inserted LAN Cable 4. Attach the strain relief to the TSW-550/750/1050-TTK by pushing it upward into the slot on the rear of the TSW-550/750/1050-TTK, as shown in the following illustrations. Strain Relief (Front and Side Views)
  • Page 17 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits 6. Connect the LAN cable to the TSW-550, TSW-750 or TSW-1050 and gently pull excess cable out through the rear of the TSW-550/750/1050-TTK to ensure the touch screen seats completely into the TSW-550/750/1050-TTK and that its magnets engage the metal bracket.
  • Page 18 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Attaching Swivel Mechanism Tube to TSW-550/750/1050-TTK (TSW-750-TTK Shown) TSW-750-TTK Swivel Mechanism Tube (4517227) Screws (3) #06-32 x 3/16" (2007202) Felt Washer (2024711) 2. Remove the paper liner from the felt washer (2024711) and attach the washer to the bottom of the swivel mechanism tube (4517227), as shown in the illustration above.
  • Page 19 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits position of the TSW-550/750/1050-TTK. Observe the dashed line indicating the front edge of the TSW-550/750/1050-TTK to ensure the device does not overhang the mounting surface. 5. Using the six mounting holes on the swivel stop plate (4504353) as a template, drill pilot holes 0.093”...
  • Page 20 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Swivel Mechanism Assembly Table Or Mounting Surface (Front Edge) Bottom Side of Table or Mounting Surface Swivel Mechanism Tube Mounting Hole (4517227) Mounting Holes (6) Slot In Tube In Swivel Stop Plate Swivel Stop Plate Screws (6) #08-8B x ½"...
  • Page 21 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits Customize Range Aside from the permanently installed limiting screw attached to the swivel stop plate, two additional #08-32 x 1/8” limiting screws (2017634) are included with the TSW-550/750/1050-SMK. These screws are provided to set a custom range for swivel movement. Refer to the following illustrations for their application.
  • Page 22 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Using the Security Option For secure applications, the touch screen can be “locked” to the TSW-550/750/1050-TTK using the two #04-20 x 5/8” screws (2007139) included with each unit. To use the security option, perform the following procedure: 1.
  • Page 23 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits NOTE: Before performing the following step, place tape on the back of the touch screen, as shown in the following illustration. The rear assembly must be held in place during the rest of this procedure.
  • Page 24 Kits Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Attach Metal Bracket to Rear Assembly of Touch Screen Use Included #04-20 x 5/8” Screws to Attach Metal Bracket 5. Remove the tape attached before performing step 3. 6. With the touch screen still face down on the clean, soft surface,...
  • Page 25: Resources

    Crestron Web site (www.crestron.com/offices) for assistance within a particular geographic region. To post a question about Crestron products, log onto the Online Help section of the Crestron Web site (www.crestron.com/onlinehelp). First- time users must establish a user account to fully benefit from all available features.
  • Page 26: Return And Warranty Policies

    (property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party.
  • Page 27 Crestron TSW-550/750/1050-TTK & TSW-550/750/1050-SMK Kits This page is intentionally left blank. Installation Guide – DOC. 7411C Kits: TSW-550/750/1050-TTK & TSW-550/750/1050-SMK • 23...
  • Page 28 Crestron Electronics, Inc. Installation Guide – DOC. 7411C 15 Volvo Drive Rockleigh, NJ 07647 (2034170) Tel: 888.CRESTRON 02.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
