  • Page 1 Crestron TSW-RMB Retrofit Mounting Brackets for TSW-750 & TSW-1050 Installation Guide...
  • Page 2 Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
  • Page 3: Table Of Contents

    Crestron TSW-RMB Retrofit Mounting Brackets for TSW-750 & TSW-1050 Contents Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB Introduction ..........................1 Physical Description ....................2 Setup ............................7 Supplied Hardware ...................... 7 Installation ........................8 Resources ..........................10 Further Inquiries ......................10 Future Updates ......................
  • Page 5: Retrofit Mounting Brackets For Tsw-750 & Tsw-1050: Tsw-Rmb

    A complete set of brackets is available to streamline the process without having to tear up or patch the wall surface. The TSW-RMB simply mounts over the existing back box, mounting kit, or cutout to accommodate the new touch screen.
  • Page 6: Physical Description

    (171 mm) 5.65 in (144 mm) 3.74 in (95 mm) 4.80 in 3.95 in (122 mm) (101 mm) CT/LC-1000, APAD Mounting Hole TPS-2000L Mounting Hole 2 • Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB Installation Guide – DOC. 7609A...
  • Page 7 TSW-750-RMB-2 Overall Dimensions (Top, Front and Side Views) 1.36 in (35 mm) 6.10 in (155 mm) 5.00 in (127 mm) 4.50 in 3.90 in (115 mm) (99 mm) Installation Guide – DOC. 7609A Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB • 3...
  • Page 8: Tsw-1050-Rmb

    (126 mm) (101 mm) (99 mm) CT/LC-1000, APAD Mounting Hole (Use 17517 Bracket) TPS-4L Mounting Hole (Use 170070 Bracket) TPS-2000L Mounting Hole (Use 17517 Bracket) 4 • Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB Installation Guide – DOC. 7609A...
  • Page 9: Tsw-1050-Rmb

    (166 mm) 4.50 in (115 mm) 5.80 in 5.10 in 4.60 in (148 mm) (130 mm) (117 mm) For 170071 Bracket Mount to Back Box Installation Guide – DOC. 7609A Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB • 5...
  • Page 10 TSW-1050-RMB-5 Overall Dimensions (Top, Front and Side Views) 1.35 in (35 mm) 9.05 in (230 mm) 7.37 in (188 mm) 6.28 in 5.59 in (160 mm) (142 mm) 6 • Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB Installation Guide – DOC. 7609A...
  • Page 11: Setup

    Crestron TSW-RMB Retrofit Mounting Brackets for TSW-750 & TSW-1050 Setup Supplied Hardware The hardware supplied with the TSW-RMB is listed in the following table. Supplied Hardware for the TSW-RMB DESCRIPTION PART NUMBER QUANTITY Mounting Bracket, LC/CT-1000 4001193 Mounting Bracket, TPS-4L...
  • Page 12: Installation

    The following illustration shows a TSW-750 touch screen installation using a TSW-750-RMB-1 with a BB-1000L back box but installation with a back box is similar for all TSW-RMB models. TSW-RMB Installation with Back Box 8 • Retrofit Mounting Brackets for TSW-750 & TSW-1050: TSW-RMB Installation Guide – DOC. 7609A...
  • Page 13 For applications where there is no existing back box, use the following installation procedure: Use the four included #04-40 x 3/4” screws (2029110) to loosely attach the TSW-RMB to the included mounting brackets. Install the screws only enough to engage the threads in the mounting brackets. Do not tighten them yet.
  • Page 14: Resources

    Crestron worldwide offices at www.crestron.com/offices. To post a question about Crestron products, log onto Crestron’s Online Help at www.crestron.com/onlinehelp. First-time users must establish a user account to fully benefit from all available features.
  • Page 15: Return And Warranty Policies

    (property or economic damages inclusive) arising from the sale or use of this equipment. Crestron is not liable for any claim made by a third party or made by the purchaser for a third party.
  • Page 16 Crestron Electronics, Inc. Installation Guide – DOC. 7609A (2038191) 15 Volvo Drive Rockleigh, NJ 07647 Tel: 888.CRESTRON 11.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
