REMOTE RAIN GAUGE
MODEL: RGR122
USER'S MANUAL
INTRODUCTION
Congratulations on your purchasing the RGR122 Remote Rain
Guage. The rain guage is equipped with the following functions:
- Daily and total rainfall display
- Nine-day rainfall history
- Rainfall alarm
- Indoor temperature display
- Maximum and minimum temperatures
- Real-time calendar clock
- Daily alarm
- 300-feet transmission range
The RGR122 operates at 433MHz. No wire installation is required.
MAIN FEATURES: MAIN UNIT
1
Advertisement
Table of Contents
Related Manuals for Oregon Scientific RGR122
Summary of Contents for Oregon Scientific RGR122
-
Page 1: Main Unit View
- Nine-day rainfall history - Rainfall alarm - Indoor temperature display - Maximum and minimum temperatures - Real-time calendar clock - Daily alarm - 300-feet transmission range The RGR122 operates at 433MHz. No wire installation is required. MAIN FEATURES: MAIN UNIT... -
Page 2: Rain Collector View
A. FOUR-LINE DISPLAY - For displaying the total rainfall, current rainfall or rainfall history, indoor temperature and calendar clock B. RAIN RESET / SINCE BUTTON - Displays the start day for total rainfall - Presses and hold to clear the total and current rainfall - Press and hold to reset the date stamp C. -
Page 3: Top View
TOP VIEW P. ANTENNA - Transmits radio signal to main unit Q. CROSS - Checks the leveling of the rain collector R. BATTERY COMPARTMENT - Accommodates two UM-3 or AA-sized batteries INSTALLATION 1. Position the main unit and rain collector within effective range (300 feet). -
Page 4: Total Rainfall
3. Remove the fiber tape from around the bucket assemblies. 4. Insert batteries into the main unit. MODE L NO. RG R12 2 RAIN C LOC K RESE T 5. Press the [RESET] button on the main unit to initiate operation. 6. -
Page 5: Disconnected Signals
The alarm will go off for one minute when the rainfall reaches the preset value and the rain alarm indicator will flash. A reminder beep will be emitted every minute. Once the rain alarm is on the indicator will not stop flashing unless [RAIN AL] switch is turned off or the rain alarm value is reset or normally pass to next day. -
Page 6: The Reset Button
THE RESET BUTTON This button is used only when the unit is operating in an unfavorable way. Use a blunt stylus to hold down the button. All settings will return to their default values. PRECAUTIONS This product is engineered to give you years of satisfactory service if you handle it carefully. -
Page 7: Note On Compliance
Power Main unit : 2 pcs UM-3 or “AA” 1.5V battery Remote sensing unit : 2 pcs UM-3 or “AA” 1.5V alkaline battery Weight Main unit : 6.10 ounces (173 gm) Remote sensing unit : 9.17 ounces (260 gm) Dimensions Main unit : 5.24 x 3.54 x 0.98 inches (133 x 90 x 25mm) -
Page 8: Customer Assistance
CUSTOMER ASSISTANCE Should you require assistance regarding this product and its operation, please contact our customer care department at 800-853-8883 or via email at helpme@oscientific.com. WARRANTY This product is warranted to be free of manufacturing defects for a period of 3 months from date of retail purchase. Defective product should be directed to the place of retail purchase for exchange. -
Page 9: Remote Rain Gauge
Company Name: Oregon Scientific, Inc. Address: 19861 SW 95th Place, Tualatin, Oregon 97062, USA Telephone Number: 1-800-853-8883 MODEL: RGR122 REMOTE RAIN GAUGE Instruction Manual **** Mode D'emploi **** Bedienungsanleitung **** Manuale di Istruzioni **** Instrucciones de Funcionamiento...
