INTRODUCTION
Congratulations on purchasing the BHR616 Wireless Rain Guage.
Enclosed with this package is one (1) main display unit and one
(1) remote rain collector.
The rain gauge is equipped with the following features and
functions:
- Daily and total rainfall display
- Nine-day rainfall recall history
- Easy wireless installation
FEATURES & KEY CONFIGURATION :
MAIN UNIT
A
B
C
D
E
WIRELESS RAIN GAUGE
MODEL: BHR616
USER'S MANUAL
G
F
1
A. Upper Window
- Displays the total rainfall, clock and date.
B.
RF Signal Indicator
- Indicates the signal-receiving status of the unit
C. Lower Window
- Displays the rainfall history
D. MODE/SET BUTTON
- Switches between the clock and calendar in normal mode
- Press and hold to enter the setting mode
E.
SINCE BUTTON
- Displays the start day for total rainfall
- Press and hold to clear the total and current rainfall and to
reset the start date
F.
HISTORY BUTTON
- Displays the rainfall history in normal mode
- Advances digits in setting mode.
G. SEARCH BUTTON
- Initiates a search for the rain gauge sensor
H. RESET BUTTON
- Returns all settings to their original default values
I.
[IN/MM] SWITCH
- Select rainfall measurement in inches or millimeters
I
H
Advertisement
Related Manuals for Oregon Scientific BHR616
Summary of Contents for Oregon Scientific BHR616
-
Page 1: Main Unit
INTRODUCTION Congratulations on purchasing the BHR616 Wireless Rain Guage. Enclosed with this package is one (1) main display unit and one (1) remote rain collector. The rain gauge is equipped with the following features and functions: - Daily and total rainfall display... - Page 2 RAIN COLLECTOR: FEATURES Antenna -Transmits signal to main unit Cross - To level the rain collector BATTERY INSTALLATION: MAIN UNIT The main unit uses 2 UM-3 or AA alkaline batteries. 1. Unscrew the battery door at the bottom of the unit. 2.
-
Page 3: Rainfall History
LOW BATTERY WARNING There are two low-battery indicators [ the rain collection unit is shown as " [ indicator for the main unit is shown as [ batteries immediately when the respective indicator lights up. Note : Every time the batteries in the main unit are changed, it is necessary to repeat installation steps 6 through 7 prior to use. -
Page 4: Specifications
Wall-mounting: Wall mount bracket Connector: Use wall-mount connector to align with other wall-mount bracket if necessary. Wall Mount Connector Wall Mount Bracket Un-install the brackets: MAINTENANCE When handled properly, this unit is engineered to give you years of satisfactory service. Here are a few product care instructions: 1. -
Page 5: Customer Assistance
Consult the dealer of an experienced radio/TV technician for help. Company Name: Oregon Scientific, Inc. Address:19861 SW 95th Place, Tualatain, Oregon 97062, USA Telephone Number:1-800-853-8883 Name and model number of the product: Wireless Rain Gauge...
