LT-20DA6SK
INTEGRATED DIGITAL WIDE LCD PANEL TV
Downloaded from:
https://www.usersmanualguide.com/
D
Digital
V
V
ideo
B
B
roadcasting
Trade Mark of the DVB Digital Video Broadcasting
Project (1991 to 1996) Number: 3795
ENGLISH
INSTRUCTIONS

Advertisement

Table of Contents
loading

Related Manuals for JVC InteriArt LT-20DA6SK

Summary of Contents for JVC InteriArt LT-20DA6SK

  • Page 1 ENGLISH LT-20DA6SK INTEGRATED DIGITAL WIDE LCD PANEL TV INSTRUCTIONS Digital ideo roadcasting Trade Mark of the DVB Digital Video Broadcasting Project (1991 to 1996) Number: 3795 Downloaded from: https://www.usersmanualguide.com/...

  • Page 2: Table Of Contents

    Contents For your safety ........2 Other Features ........33 Important Instruction ......4 PC Mode ..........35 Installation .......... 35 Where to install ........5 Main Menu in PC mode: ..... 35 Distance Recommendation ....5 PC Picture Position Menu: ....35 Important Information ......

  • Page 3: For Your Safety

    For your safety This equipment has been designed and manufactured to meet international safety stan- dards but, like any electrical equipment, care must be taken if you are to obtain the best re- sults and safety is to be assured. So, please read the points below for your own safety. They are of a general nature, intended to help you with all your electronic consumer products and some points may not apply to the goods you have just purchased.
  • Page 4 table-cloths, curtains etc. Overheating will cause damage and shorten the life of the equip- ment. DON’T allow electrical equipment to be exposed to dripping or splashing or objects filled with liquids, such as vases, to be placed on the equipment. DON’T place hot objects or naked flame sources, such as lighted candles or night-lights on, or close to the equipment.

  • Page 5: Important Instruction

    WARNING • Fingers may be trapped under the TV causing injuries. Hold the TV at the bottom in the middle, and do not allow it to tilt up or down. • The TV may fall causing injuries. Hold the bottom of the stand with your hand and tilt the TV up and down.

  • Page 6: Where To Install

    Where to install WARNING • When you install the TV on the wall, only use a JVC wall mounting unit which is designed for this TV. • Make sure the TV is installed on the wall by a skilled installer.

  • Page 7: Important Information

    Important Information Please take note EXCLUSION CLAUSE shall under no circumstances be liable for loss and/or damage to the product caused by: • fire; • earthquake; • accidental damage; • intentional misuse of the product; • use of the product in improper conditions; •...

  • Page 8: Control Panel Buttons

    Control Panel Buttons QPX@SÃG6HQ DIAS6S@9ÃS@8@DW@S TQ@6F@S TQ@6F@S UW6W UW6W H@IVÃÃPF H@IVÃÃPF ÃQSPBS6HÃ Ã Ã Ã ÃWPGVH@Ã TU6I97` With certain combinations of connectors and leads the back cover may not be easily fitted. If the cover is left off, this in no way infringes safety requirements.

  • Page 9: Using The Stand

    Using the stand This TV comes with a Table Top Stand already attached. This stand can be used to adjust the direction of the TV screen 10° backward and 5° forward. Tilt the TV up and down: While holding the bottom of the stand with one hand, use your other hand to hold the middle of the top of the TV and slowly tilt the TV up and down.

  • Page 10: Remote Control Buttons

    Remote Control Buttons / I = (Stand By) button TV / VCR / DVD Switch Number buttons AV button 9 & (EXT-1, EXT-2, EXT-2S, EXT-3, EXT-4, EXT-4S, PC, DIGITAL TV) Colour button MENU = Menu button = Cursor Up button OK button = Cursor Right button BACK = Back button...

  • Page 11: Features

    Features • It is a remote controlled Integrated Digital colour television and PC monitor. • 100 programmes from VHF, UHF bands or cable channels can be preset. • It can tune cable channels. • Controlling the TV is very easy by its menu driven system. •...

  • Page 12: Getting Started

    Getting Started Follow Step 1 to 7 to set up your TV: Step 1: Checking the accessories supplied • Remote control unit x 1 • AA/R6 battery x 2 • AC adapter x 1 • Power cord x 1 Step 2: Inserting batteries •...
  • Page 13 ph…qÆ‚pxr‡ ‡r…€vhy† • 100 mm mount based on VESA regulation is equipped. • The handle and the stand can be left by loosing the screws with a screwdriver when mount- ing the TV on a wall. • Spread a soft cloth on a flat table and then place the TV on the cloth with the screen facing downwards when you leave the handle and the stand.
  • Page 14 &RQQHFW D YLGHR GHYLFH $(5,$/ (;7 (;7 68Ãhqhƒ‡r… U‚Ã98ÃDI 9&5 IMPORTANT: • Only use the adaptor supplied with this TV. • The TV set is designed to operate on 24 V DC. For this, an adaptor is used which gives 24 V DC voltage.
  • Page 15 Step 6: Switching the TV ON/OFF QSÃGv†‡Ã@€ƒ‡’ÃT‡h…‡Ãhˆ‡‚€h‡vpÆrh…pu To switch the TV on Your TV will switch on by two steps: 1- Connect the power supply cord to the sys- tem. Then the TV switches itself to stand- The IDTV will automatically tune to the UHF by mode and the power lamp becomes transmission channels 21 to 68 looking for red located on the front of the TV.

  • Page 16: T-V Link

    • The VCR is T-V LINK compatible. To use T-V LINK functions • The VCR is connected to EXT-2. A “T-V LINK compatible VCR” means a JVC • The scart cable is fully wired. video cassette recorder with the T-V LINK logo, or with one of the following logos.

  • Page 17: Basic Operations

    Switching input mode When you press the following buttons / I, • Pressing TV/AV/OK button will change the , TV / DTV, ZOOM, , AV, MENU, input mode. SUBTITLE, GUIDE, , BACK, number buttons) during recording, a mes- Entering Main Menu sage appears asking if you want to stop •...

  • Page 18: Operating While Watching Idtv

    the IDTV automatically searches for any new Example: PR6 press 6, PR12 press 1 information which may be broadcast and will and 2. download this to your IDTV automatically. Press directly the programme number to This operation will normally take approxi- reselect single digit programmes.
  • Page 19 Choosing Channel 1. Press “ ” or “ ” buttons to choose the channel. 2. Press OK button. ELECTRONIC PROGRAMME GUIDE (EPG) The selected channel is displayed. Another way of selecting a channel is with Programme Reminders the electronic programme guide, or EPG. Like the Channel List, the EPG screen dis- You can easily set the reminder so that you plays a list of the stored channels along with...

  • Page 20: Digital Teletext

    DISPLAYING THE SUBTITLES • The aspect ratio when watching a channel with just digital teletext broadcasting is the With Digital terrestrial broadcasting (DVB-T), same as the aspect ratio of the picture some programmes are broadcast with sub- watched previously. titles. Subtitles can be displayed when watching these programmes.
  • Page 21 from the TV to the VCR to automatically start and end the recording. It is not necessary to set the timer on the VCR. 7+5(( • When your VCR is not T-V LINK compatible, you also need to set the VCR timer settings to match the TV timer settings.
  • Page 22 Mode: cording before you record the programme. There are some T-V LINK compatible re- Use the “ ” / “ ” buttons to choose the cording device that will not correctly receive timer mode (Once/Daily/Weekly), and then the Direct Rec command from the TV. press the OK button.

  • Page 23: Configuration

    Configuration 1. Press the “ ” / “ ” buttons and choose Subtitle. Set the basic setting when watching Digital 2. Press the “ ” / “ ” buttons and choose a terrestrial broadcasting (DVB-T). subtitle language that appears when the Choose configuration and press the OK but- SUBTITLE button is pressed.

  • Page 24: Edit Pr List

    1. Press the “ ” / “ ” buttons and choose Enter PIN code, and press the OK button. 2. Input the current PIN code. When you are making this setting for the first time, input 0000. When a PIN code has already been set, enter the correct PIN code.
  • Page 25 • Sometimes you may notice a drop in picture Editing a channel name quality while watching your programme in 1. Press the “ ” / “ ” buttons and choose the quarter-screen. This is not a fault. Edit Name on the bar at the bottom of the screen.

  • Page 26: Installation

    Setting the favourite channels If only channels that you often watch are set as favourite channels, you can choose from just those channels by pressing • After setting the favourite channels, check the “Favourite Mode” in “Configuration” (see page 22) is set to ON. 1.

  • Page 27: Common Interface

    When “OK” button is pressed, following warning screen is displayed in case of acci- message will appear on the right bottom dental operation. side of the screen: 6…rÃ’‚ˆÃ†ˆ…rÃ’‚ˆÃh‡Ã‡‚Ãqryr‡rÇurÃQSÃyv†‡Ã hqÃ…r†r‡ÃhyyÆr‡‡vt†4 QSÃGv†‡Ã@€ƒ‡’ ` r† I‚ Manual Search: Highlight the YES button with the “ ” or “ ” key and press OK to erase all the channels This is for searching for digital channels on and settings.

  • Page 28: Setting The Tv

    • To see the viewing contract information, Press “MENU” button again to remove menu. press MENU, Select DIGITAL and Press OK, Picture Menu then Select Common Interface and press Press “MENU” button, now you are in main • When no module is inserted, “No CI Mod- menu.
  • Page 29 Setting Sharpness Setting Colour Temp. • Using “ ” or “ ” button select Sharpness. • Using “ ” or “ ” button select Colour Temp. • Press “ ” button to increase sharpness level. • Press “ ” or “ ” button to select “Warm”, “Cool”...

  • Page 30: Sound Menu

    Reset Setting Balance Press BLUE button to reset the picture It allows adjusting the distribution between modes to factory default settings. the left and right speakers. • Using “ ” or “ ” button select Balance. To Store the Settings •...

  • Page 31: Feature Menu

    Selecting Sound Mode • Using “ ” or “ ” button select Child Lock. • Press “ ” / “ ” button to select Child Lock • Using “ ” or “ ” button select Sound On or Off . Mode.
  • Page 32 Selecting Fine Tuning You can use the Fine Tuning process for fine adjustment (after coarse adjustment), if you are not happy about the image on the screen. Use “ ” or “ ” button on Fine Tuning item, until getting the best image on the screen. Selecting Search To start the search process, press “...

  • Page 33: Program Menu

    • After stored, T-V LINK menu will appear. If you do not need to do T-V LINK, select Can- cel and press “ ” or “OK” button to exit the menu. If you do not have a T-V LINK compatible VCR, Program Menu select Cancel and press “...

  • Page 34: Source Menu

    automatically on your TV, according to the Other Features transmission of programme systems in TV Status your area. Programme Number, Programme Name (or EXT), (they are displayed on the upper left of the screen). The sound indicator is displayed with them too. They are displayed after programme change for 3 seconds.
  • Page 35 this volume is set to the preceding value, AUTO: and the second one is increasing or de- When a WSS (Wide Screen Signalling) sig- creasing the volume level. nal, which shows the aspect ratio of the pic- ture, is included in the broadcast signal or No-Signal Detection (TV mode) the signal from an external device, the TV If no valid signal detected, it takes 5 minutes...

  • Page 36: Pc Mode

    PC Mode Installation • Power off both Computer and the TV before The top and bottom of the picture are slightly making any connections. cut off. • Set your PC’s resolution correctly before connecting to the TV. See the table in page 14:9 ZOOM: 43 for supported modes.

  • Page 37: Pc Picture Menu

    Auto Position PC Picture Menu If you shift the picture horizontally or vertically In the Main menu, select “PC Picture” using to an unwanted position, use this item to put “ ” or “ ” button, then enter the PC Picture the picture into correct place automatically.

  • Page 38: Source Menu

    Contrast, Bright-1, Colour and Sharpness • When PIP is displayed on the screen, “ ” are described at Picture menu on page 27. button allows you to switch sound between PC and selected PIP source. Setting PIP Size No-Signal and Out Of Range •...

  • Page 39: To Select Index Page

    To select a page of Teletext • Pressing “ ” button again will conceal the revealed answers. • Press the appropriate digit buttons for the To Stop Automatic Page Change required Teletext page number. The selected page number is displayed at The teletext page you have selected may the top left corner of the screen.

  • Page 40: Peripheral Equipment Connections

    For Fastext and Toptext nect the decoder to the VCR. If not, the T-V LINK function may not work properly. And The subject-heading for the information may then set the Decoder (EXT-2) function for the have a particular colour. channel to ON to unscramble a scrambled •...
  • Page 41 supply you a corresponding decoder unit to Connect the decoder to the video allow the programmes to be unscrambled. recorder For further information ask your dealer. See Some video recorders have a special euro- also the booklet supplied with your decoder. connector for decoder.

  • Page 42: Peripheral Equipment Connections

    Peripheral Equipment Connections 9 '& < 3& ,1387 & (;7 &RPSRQHQW $XGLR ,Q 5 (;7 &RPSRQHQW $XGLR ,Q / (;7 $17(11$ 69LGHR ,Q 3& $8',2 ,1 9LGHR ,Q $XGLR 5 (;7 $XGLR / +($'3+21( $8',2 287 7(50,1$/ $XGLR 5 $XGLR / &$5' 6/27 6XEZRRIHU 2XW - 41 -...

  • Page 43: Antenna Connections

    Antenna Connections 2XWGRRU $QWHQQD &RQQHFWLRQV WCAÃh‡rh S‚ˆqÃ&$Âu€Ãp‚h‘vhyÃphiyr Srh…ÂsÃUW Ayh‡Ã"‚u€Ã‡vÃyrhqÃphiyr WCAVCAÃh‡rh Srh…ÂsÃUW S‚ˆqÃ&$‚u€Ãp‚h‘vhyÃphiyr Peripheral Equipment Connections HEADPHONE AUDIO 6V9DPÃÃDI WD9@PÃDI VIDEO $17 ,1 &$0&25'(5 FOR SATELLITE RECEIVER DECODER - 42 -...

  • Page 44: Pc Input Typical Display Modes

    PC Input Typical Display Modes The display has a maximum resolution of 1360x768, vertical sync. frequency range of 50-75 Hz and a horizontal sync. frequency range of 30-69 KHz. The following table is an illustration of some of the typical video display modes. 5HVROXWLRQ )UHTXHQF\ 0RGH...

  • Page 45: Tips

    PC Picture Tips If no PC picture appears, check that the D- Can not turn the TV on? SUB cable is connected properly. Check that your PC’s resolution set correctly. See Check that TV/VCR/DVD switch is set to TV pages 43 for supported modes. position.

  • Page 46: Specifications

    Specifications Model Item LT-20DA6SK Broadcasting Systems PAL BG, DK, I, L, Lp Channels and Digital : 474 MHz - 858 MHz Frequencies Analogue : 46.25 MHz - 862.25 MHz Cable TV (S1-S20/ S21-S41) Input Signal Video: Analog 0,7 Vp-p 75 ohm positive Sync: TTL Level positive or negative, Seperate sync.
  • Page 47 50076128 ©2005 Victor Company of Japan, Limited 0205MKH-VT-VT Downloaded from: https://www.usersmanualguide.com/...
