JVC LT-20DA6SK Service Manual

JVC LT-20DA6SK Service Manual

Wide lcd panel television
Hide thumbs Also See for LT-20DA6SK:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
SERVICE MANUAL
WIDE LCD PANEL TELEVISION
11
2005
YA354
1
2
4
5
8
7
0
i
AV
TV/DTV
MENU
OK
P
TOP MENU
ZOOM
PC
RM-C1896
TV
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
LT-20DA6SK
3
6
9
BACK

TABLE OF CONTENTS

COPYRIGHT © 2005 Victor Company of Japan, Limited
No.YA354
2005/11

Advertisement

Table of Contents
loading

Related Manuals for JVC LT-20DA6SK

Summary of Contents for JVC LT-20DA6SK

  • Page 1: Table Of Contents

    SERVICE MANUAL WIDE LCD PANEL TELEVISION YA354 2005 LT-20DA6SK TV/DTV MENU BACK TOP MENU ZOOM RM-C1896 TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION Items Contents Dimensions ( W × H × D ) 53.7cm × 41.1cm × 21.4cm [Included stand] 53.7cm × 37.7cm × 9.7cm [TV only] Mass 6.5kg [Included stand] 5.5kg [TV only] Power Input ADAPTOR AC100 ~ 240V 50Hz DC24V Power Consumption 80W (Standby: 3.0W) TV RF System...

  • Page 3: Precaution

    SECTION 1 PRECAUTION SAFETY PRECAUTIONS (1) The design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits.
  • Page 4 INSTALLATION 1.2.1 HEAT DISSIPATION 1.2.3 NOTES ON HANDLING If the heat dissipation vent behind this unit is blocked, cooling (1) WHEN TAKING UNIT OUT OF A PACKING CASE efficiency may deteriorate and temperature inside the unit will When taking the unit out of a packing case, do not grasp rise.
  • Page 5 HANDLING LCD PANEL 1.3.1 PRECAUTIONS FOR TRANSPORTATION 1.3.2 OPTICAL FILTER (ON THE FRONT OF THE LCD PANEL) When transporting the unit, pressure exerted on the internal LCD (1) Avoid placing the unit under direct sunlight over a panel due to improper handling (such as tossing and dropping) prolonged period of time.

  • Page 6: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS FEATURES T-V LINK OFF TIMER When you have a T-V LINK compatible VCR connected to the This function can set the TV to automatically turn off after a set EXT-2 Terminal on the TV,it is easier to set up the VCR and to time.
  • Page 7 TECHNICAL INFORMATION 2.3.1 LCD PANEL This unit uses the flat type panel LCD (Liquid Crystal Display) panel that occupies as little space as possible, instead of the conventional CRT (Cathode Ray Tube), as a display unit. Since the unit has the two polarizing filter that are at right angles to each other, the unit adopts "normally black" mode, where light does not pass through the polarizing filter and the screen is black when no voltage is applied to the liquid crystals.
  • Page 8 BASIC OPERATION OF SERVICE MODE 2.4.5 SERVICE MODE SETTING ITEMS 2.4.1 HOW TO ENTER THE SERVICE MODE Setting Setting items Contents (1) Press [INFORMATION] key and [MUTING] key on the menu remote control unit simultaneously to enter the SERVICE Adjust Group ---- MODE SCREEN.

  • Page 9: Disassembly

    SECTION 3 DISASSEMBLY DISASSEMBLY PROCEDURE NOTE: • Make sure that the power cord is disconnected from the outlet. • Pay special attention not to break or damage the parts. • When removing each board, remove the connectors as required. • Taking notes of the connecting points (connector numbers) makes service procedure manageable. •...
  • Page 10 HANDLE BACK COVER SIDE AV COVER CARD SLOT COVER BUTTON FUNCTION SIDE CONTROL PWB AV JACK PWB METAL HANG AV JACK BRACKET BACK DOOR MAIN PWB TERMINAL BOARD CABLE HOLDER LED PWB LCD PANEL UNIT HINGE COVER FOOT TOP COVER SPEAKER LED LENS SPEAKER...
  • Page 11 MEMORY IC REPLACEMENT • This model uses the memory IC. • This memory IC stores data for proper operation of the video and drive circuits. • When replacing, be sure to use an IC containing this (initial value) data. 3.2.1 SETTINGS OF FACTORY SHIPMENT 3.2.1.1 BUTTON OPERATION 3.2.1.2...
  • Page 12 REPLACEMENT OF CHIP COMPONENT 3.3.1 CAUTIONS (1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it. 3.3.2 SOLDERING IRON (1) Use a high insulation soldering iron with a thin pointed end of it.

  • Page 13: Adjustment

    SECTION 4 ADJUSTMENT This service manual does not describe ADJUSTMENT. SECTION 5 TROUBLESHOOTING This service manual does not describe TROUBLESHOOTING. (No.YA354)1-13...
  • Page 14 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan (No.YA354) Printed in Japan...
  • Page 15 SCHEMATIC DIAGRAMS WIDE LCD PANEL TELEVISION YA354 2005 LT-20DA6SK CD-ROM No.SML200511 TV/DTV MENU BACK TOP MENU ZOOM RM-C1896 No.YA354 COPYRIGHT © 2005 Victor Company of Japan, Limited 2005/11...
  • Page 16 LT-20DA6SK STANDARD CIRCUIT DIAGRAM NOTE ON USING CIRCUIT DIAGRAMS 1.SAFETY Type No indication : Ceramic capacitor The components identified by the symbol and shading are : Metalized mylar capacitor critical for safety. For continued safety replace safety ciritical : Polypropylene capacitor components only with manufactures recommended parts.
  • Page 17 MAIN PWB PATTERN ..........................2-33 SIDE CONTROL PWB PATTERN ......................2-37 LED PWB PATTERN ..........................2-37 AV JACK PWB PATTERN ........................2-37 USING P.W. BOARD P.W.B ASS’Y name LT-20DA6SK VE-20228287 MAIN P.W. BOARD VE-20224821 SIDE CONTROL P.W. BOARD VE-20220627 LED P.W. BOARD VE-20224823 AV JACK P.W.

  • Page 18: Block Diagram [Tv Parts]

    BLOCK DIAGRAM [TV PARTS] +12V CARD To STi5518 +12V PL301 Serial Interface RX,TX,IRQ IR_IN 3.3V CONTROLLER Power Supply 2.5V KEYPAD SDA5550M PL302 CARD 1.8V SDRAM MENU S+5V PROM S3.3V S2.5V SOURCE POWER S1.8V GENERATOR MC14 CVBS IF SCALER R(0-7) VIDEO BT656 B(0-7) DEINTERLACER...

  • Page 19: Block Diagram [Idtv Parts]

    BLOCK DIAGRAM [IDTV PARTS] DIGITAL DIGITAL FRONTEND TUNER ST0360 FC_DATA(0-7) FC_CLK FC_SYNC FC_VALID +12V EMI DRAM 3.3V FROM 2.5V POWER (0-14) 1.8V SUPPLY CPU_ DATA CARD S+5V (0-7) Serial Interface RX,TX,IRQ INTERFACE S3.3V CONTROLLER STV0700 CMD(0-7) TO SDA 5550 CONTROLLER &...

  • Page 20: Circuit Diagrams

    CIRCUIT DIAGRAMS MAIN PWB CIRCUIT DIAGRAM (1/12) MAIN PWB ASS'Y (1/12) VE-20228287 (No.YA354)2-7 2-8(No.YA354)
  • Page 21 MAIN PWB CIRCUIT DIAGRAM (2/12) MAIN PWB ASS'Y (2/12) VE-20228287 NOTE : Refer to the part list for the part number of IC300 and IC302. (No.YA354)2-9 2-10(No.YA354)
  • Page 22 MAIN PWB CIRCUIT DIAGRAM (3/12) MAIN PWB ASS'Y (3/12) VE-20228287 (No.YA354)2-11 2-12(No.YA354)
  • Page 23 MAIN PWB CIRCUIT DIAGRAM (4/12) MAIN PWB ASS'Y (4/12) VE-20228287 (No.YA354)2-13 2-14(No.YA354)
  • Page 24 MAIN PWB CIRCUIT DIAGRAM (5/12) MAIN PWB ASS'Y (5/12) VE-20228287 (No.YA354)2-15 2-16(No.YA354)
  • Page 25 MAIN PWB CIRCUIT DIAGRAM (6/12) MAIN PWB ASS'Y (6/12) VE-20228287 (No.YA354)2-17 2-18(No.YA354)
  • Page 26 MAIN PWB CIRCUIT DIAGRAM (7/12) MAIN PWB ASS'Y (7/12) VE-20228287 (No.YA354)2-19 2-20(No.YA354)
  • Page 27 MAIN PWB CIRCUIT DIAGRAM (8/12) MAIN PWB ASS'Y (8/12) VE-20228287 (No.YA354)2-21 2-22(No.YA354)
  • Page 28 MAIN PWB CIRCUIT DIAGRAM (9/12) MAIN PWB ASS'Y (9/12) VE-20228287 (No.YA354)2-23 2-24(No.YA354)
  • Page 29 MAIN PWB CIRCUIT DIAGRAM (10/12) MAIN PWB ASS'Y (10/12) VE-20228287 (No.YA354)2-25 2-26(No.YA354)
  • Page 30 MAIN PWB CIRCUIT DIAGRAM (11/12) MAIN PWB ASS'Y (11/12) VE-20228287 (No.YA354)2-27 2-28(No.YA354)
  • Page 31 MAIN PWB CIRCUIT DIAGRAM (12/12) MAIN PWB ASS'Y (12/12) VE-20228287 (No.YA354)2-29 2-30(No.YA354)

  • Page 32: Side Control Pwb Circuit Diagram

    AV JACK PWB CIRCUIT DIAGRAM SIDE CONTROL PWB CIRCUIT DIAGRAM SIDE CONTROL PWB ASS'Y VE-20224821 LED PWB CIRCUIT DIAGRAM AV JACK PWB ASS'Y LED PWB ASS'Y VE-20224823 VE-20220627 (No.YA354)2-31 2-32(No.YA354)

  • Page 33: Pattern Diagrams

    PATTERN DIAGRAMS MAIN PWB PATTERN [SOLDER SIDE] (No.YA354)2-33 2-34(No.YA354)
  • Page 34 MAIN PWB PATTERN [PARTS SIDE] (No.YA354)2-35 2-36(No.YA354)

  • Page 35: Side Control Pwb Pattern

    SIDE CONTROL PWB PATTERN LED PWB PATTERN AV JACK PWB PATTERN (No.YA354)2-37 2-38(No.YA354)
  • Page 36 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan (No.YA354) Printed in Japan...
  • Page 37 ENGLISH LT-20DA6SK INTEGRATED DIGITAL WIDE LCD PANEL TV INSTRUCTIONS Digital ideo roadcasting Trade Mark of the DVB Digital Video Broadcasting Project (1991 to 1996) Number: 3795...
  • Page 38 Contents...

  • Page 39: For Your Safety

    For your safety Some “DOs” and “DON’Ts” for you IF IN DOUBT PLEASE CONSULT A COMPETENT ELECTRICIAN. DON’T DON’T...
  • Page 40 DON’T DON’T DON’T DON’T DON’T DON’T DON’T ** Cold cathode fluoresant lamp in LCD PANEL contains a small amount of mercury, please follow local ordinates or regulations for disposal. Warning:...

  • Page 41: Important Instruction

    WARNING • Fingers may be trapped under the TV causing injuries. Hold the TV at the bottom in the middle, and do not allow it to tilt up or down. • The TV may fall causing injuries. Hold the bottom of the stand with your hand and tilt the TV up and down.
  • Page 42 Where to install Distance Recommendation...

  • Page 43: Important Information

    Important Information Please take note EXCLUSION CLAUSE WARNING! NEVER LEAVE A STATIONARY IMAGE ON THE Care and disposal SCREEN...

  • Page 44: Control Panel Buttons

    Control Panel Buttons QPX@SÃG6HQ DIAS6S@9ÃS@8@DW@S TQ@6F@S TQ@6F@S UW6W UW6W H@IVÃÃPF H@IVÃÃPF ÃQSPBS6HÃ Ã Ã Ã ÃWPGVH@Ã TU6I97`...
  • Page 45 Using the stand...

  • Page 46: Remote Control Buttons

    Remote Control Buttons 9 & 0(18 79'79 %$&. 68%7,7/( *8,'( UP QÃH@IV =220 3&...
  • Page 47 Features...

  • Page 48: Getting Started

    Getting Started Step 1: Checking the accessories supplied Step 2: Inserting batteries NOTE: Remove the batteries from remote control when it is not to be used for a long period.Otherwise it can be damaged due to any leakage of battery. Old batteries must be disposed in a designated area.
  • Page 49 ph…qÆ‚pxr‡ ‡r…€vhy† Step 4: Connecting an aerial VCR and mains &RQQHFW WKH DHULDO $(5,$/ 68à hq hƒ ‡r … ‡‚Ã98ÃDI...
  • Page 50 &RQQHFW D YLGHR GHYLFH $(5,$/ (;7 (;7 68Ãhqhƒ‡r… U‚Ã98ÃDI 9&5 Step 5: Using the cable holder...
  • Page 51 Step 6: Switching the TV ON/OFF QSÃGv†‡Ã@€ƒ‡’ÃT‡h…‡Ãhˆ‡‚€h‡vpÆrh…pu HINT: Depending on the reception conditions in your par- ticular area, you may find that the list of channels found includes one or more repeated names. This is because the receiver may detect and store some channels, including those it cannot receive clearly, from adjacent areas along- side the strong channels from a transmitter nearby.
  • Page 52 T-V LINK...

  • Page 53: Basic Operations

    Operation with Remote Control Basic Operations You can operate your TV using both the re- mote control and TV buttons. Operation with the buttons on the...

  • Page 54: Everyday Operation

    Hint: The channel list numbers are assigned by the broadcasters. Because not all channels are broadcast free-to-air and stored by the receiver, the channel list numbers do not run continuously. The fifteenth channel in the list, for example, may not be channel number 15 but channel number 17.
  • Page 55 Using the Electronic Programme Guide...

  • Page 56: Digital Teletext

    DTV Menus 6XEWLWOH 21 Hrˆ 6XEWLWOH 2)) ÃQvp‡ˆ…r ÃT‚ˆq Arh‡ˆ…r DIGITAL TELETEXT 9DBDU6G ÃT‚ˆ…pr Uv€r…† 8‚svtˆ…h‡v‚ @qv‡ÃQSÃGv†‡ D†‡hyyh‡v‚ 8‚€€‚ÃD‡r…shpr Timers (DTV Timer Recording)
  • Page 57 7+5(( 7+5(( 7+5((...
  • Page 58 When recording on a T-V LINK compatible VCR: When recording on a T-V LINK incompatible VCR: Cancelling the timer setting WARNING : Do not turn off the main power. The timer function will not work with the main power Reactivating the cancelled timer switched off.
  • Page 59 Configuration • When the BACK button is pressed, the previ- ous screen is returned to. When MENU but- ton is pressed, the menu disappears. • When the...
  • Page 60 6ˆ‡‚€ h‡vpÃ9 ‚ y‚ hq @hiyrq Trh…puÃs‚…ÃIr ÃWr…†v‚ Edit PR List...
  • Page 62 T‡h…‡Ãhˆ‡‚€h‡vpÆrh…pu4Ã8ˆ……r‡ÃQSÃyv†‡ vyyÃirÃ…rƒyhprq ` r† I‚ Installation 0(18 %$&. I‚Ã…‚t…h€€rÃs‚ˆq Qyrh†rÃpurpxÃh‡rhÆvthy...

  • Page 63: Common Interface

    6…rÃ’‚ˆÃ†ˆ…rÃ’‚ˆÃh‡Ã‡‚Ãqryr‡rÇurÃQSÃyv†‡Ã hqÃ…r†r‡ÃhyyÆr‡‡vt†4 QSÃGv†‡Ã@€ƒ‡’ ` r† I‚ QSÃGv†‡Ã@€ƒ‡’ÃT‡h…‡Ãhˆ‡‚€h‡vpÆrh…pu Common Interface Hint The bar graphs of signal quality and signal level give a good indication of whether any channels are likely to be found. If only the signal level graph shows a high value then it is likely that an analogue channel occu- pies that broadcast frequency.

  • Page 64: Picture Menu

    Picture Menu Setting The TV Menu System MAIN MENU Hrˆ ÃQvp‡ˆ…r ÃT‚ˆq Arh‡ˆ…r D†‡hyy ÃT‚ˆ…pr ÃÃÃà ÃÃC)Ãà Fu“ ÃÃÃÃÃW)ÃÃÃC“...
  • Page 65 Note 1: At low signal level, the changings on the Noise Reduction function are not effective when there is menu on the screen. If the menu is removed, the effect of this function is seen. At normal broadcasting, Noise Reduction changings are effective at once.
  • Page 66 Sound Menu...
  • Page 67 Feature Menu Install Menu...

  • Page 69: Program Menu

    Program Menu Caution: Using “Delete” or “Insert” function rewrite the current channel list in the Program menu. Therefore, the programme numbers of some of channels will change.

  • Page 70: Other Features

    Other Features TV Status Sound Indicator 0RQR 6WHUHR Source Menu 'XDO , 'XDO ,, Hyper Sound ÃÃÃÃÃÃÃÃÃT‚ˆ…prÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃ)ÃUW Ã9DBDU6G ÃUW @YU @YU! @YU!ÃT Mute Indicator @YU" @YU# @YU#ÃT...

  • Page 71: Volume Bar

    No-Signal Detection (TV mode) Volume Bar Note: You can only choose REGULAR and FULL in PC mode. EXT Modes Zoom Modes...

  • Page 72: Main Menu In Pc Mode

    PC Mode Installation $ÃQvÃHvvÃ9TˆiÃ8‚rp‡‚… Main Menu in PC mode: PC Picture Position Menu:...

  • Page 73: Pc Picture Menu

    PC Picture Menu Sound Menu PIP Picture QDQÃQvp‡ˆ…r 8‚‡…h†‡ Ã7…vtu‡Ãà Ã8‚y‚ˆ… Tuh…ƒr†† QDQÃTv“r QDQÃQ‚†v‡v‚ ÃÃÃÃÃÃÃÃ)ÃS@T@U...

  • Page 74: Analogue Teletext

    No-Signal and Out Of Range Detection (PC mode) Analogue Teletext Source Menu ÃÃÃÃÃÃÃÃÃT‚ˆ…prÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃÃ)ÃQ8 Ã9DBDU6G ÃUW @YU @YU! @YU!ÃT @YU" @YU# @YU#ÃT To operate Teletext Sound in PC mode UPQÃH@IV...
  • Page 75 To select a page of Teletext To Stop Automatic Page Change To Select a Subcode Page To Select Index Page Searching for a teletext page while watching TV To Select Double Height Text To exit Teletext Fastext and Toptext To Reveal “concealed” Information...
  • Page 76 RGB mode EXT-2 S Mode Via the RCA jacks Peripheral Equipment Connections Via the ANT (aerial) socket Via the Euroconnector T-V LINK compatible VCR Decoder...
  • Page 77 Connect the decoder to the video recorder Connecting Headphones TV and Video Recorder (VCR) Connecting the PC To connect to S-Video input NTSC Playback Camera and Camcorder...

  • Page 78: Peripheral Equipment Connections

    Peripheral Equipment Connections 9 '& < 3& ,1387 & (;7 &RPSRQHQW $XGLR ,Q 5 (;7 &RPSRQHQW $XGLR ,Q / (;7 $17(11$ 69LGHR ,Q 3& $8',2 ,1 9LGHR ,Q $XGLR 5 (;7 $XGLR / +($'3+21( $8',2 287 7(50,1$/ $XGLR 5 $XGLR / &$5' 6/27 6XEZRRIHU 2XW...

  • Page 79: Antenna Connections

    Antenna Connections 2XWGRRU $QWHQQD &RQQHFWLRQV WCAÃh‡rh S‚ˆqÃ&$Âu€Ãp‚h‘vhyÃphiyr Srh…ÂsÃUW Ayh‡Ã"‚u€Ã‡vÃyrhqÃphiyr WCAVCAÃh‡rh Srh…ÂsÃUW S‚ˆqÃ&$‚u€Ãp‚h‘vhyÃphiyr Peripheral Equipment Connections 6V9DPÃÃDI WD9@PÃDI $17 ,1 &$0&25'(5...

  • Page 80: Pc Input Typical Display Modes

    PC Input Typical Display Modes 5HVROXWLRQ )UHTXHQF\ 0RGH +RUL]RQWDO 9HUWLFDO +RU N+] 9HU +]                    ...
  • Page 81 PC Picture Tips Can not turn the TV on? Sound Can not turn the TV off? Care of the Screen Remote Control Colours of image on screen are abnormal No solution Bad picture (in digital mode) No Image on Display Screen...

  • Page 82: Specifications

    Specifications Model Item LT-20DA6SK Broadcasting Systems PAL BG, DK, I, L, Lp Channels and Digital : 474 MHz - 858 MHz Frequencies Analogue : 46.25 MHz - 862.25 MHz Cable TV (S1-S20/ S21-S41) Input Signal Video: Analog 0,7 Vp-p 75 ohm positive Sync: TTL Level positive or negative, Seperate sync.
  • Page 83 50076128 ©2005 Victor Company of Japan, Limited 0205MKH-VT-VT...

  • Page 84: Parts List

    PARTS LIST CAUTION The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the  safety. The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied. P.W.

  • Page 85: Exploded View Parts List

    LED P.W. BOARD ASS'Y (VE-20220627) ....................... 3-12 PACKING ................................... 3-13 PACKING PARTS LIST ............................. 3-13 USING P.W. BOARD & REMOTE CONTROL UNIT P.W.B ASS'Y No. P.W.B ASS'Y name LT-20DA6SK MAIN P.W.B VE-20228287 AV JACK P.W.B VE-20224823 SIDE CONTROL P.W.B VE-20224821 LED P.W.B...

  • Page 86: Exploded View -1

    EXPLODED VIEW -1 (No.YA354)3-3...

  • Page 87: Printed Wiring Board Parts List

    VE-30034805 Q902 VE-30001454 TRANSISTOR IC106 VE-30017956 Q903 VE-30001457 TRANSISTOR IC107 VE-30019372 Q904 VE-30007798 TRANSISTOR IC108 VE-30027533 Q905 VE-30007798 TRANSISTOR IC300 VE-LT-20DA6SK (SERVICE) Q1120 VE-30001457 TRANSISTOR IC301 VE-30013571 Q1121 VE-30001457 TRANSISTOR IC302 VE-20227534 (SERVICE) Q1206 VE-30012551 TRANSISTOR IC305 VE-30010689 DIODE Q1207...
  • Page 88 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C109 VE-30012582 CAPACITOR 10nF 50V K C318 VE-30012569 CAPACITOR 33pF 50V J C110 VE-30012582 CAPACITOR 10nF 50V K C319 VE-30000371 E CAPACITOR 22uF 50V M C111 VE-30012582 CAPACITOR...
  • Page 89 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C601 VE-30000074 CAPACITOR 100nF 63V J C775 VE-30000345 E CAPACITOR 10uF 50V M C602 VE-30000074 CAPACITOR 100nF 63V J C776 VE-30010555 CAPACITOR 1uF 16V K C603 VE-30000074 CAPACITOR...
  • Page 90 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C1103 VE-30000345 E CAPACITOR 10uF 50V M C1437 VE-30016654 CAPACITOR 100nF 16V K C1104 VE-30012582 CAPACITOR 10nF 50V K C1438 VE-30016654 CAPACITOR 100nF 16V K C1109 VE-30016654 CAPACITOR...
  • Page 91 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R137 VE-30012506 RESISTOR 1/16W 1.5K J R343 VE-30012668 RESISTOR 1/16W 220R J R138 VE-30012506 RESISTOR 1/16W 1.5K J R344 VE-30012657 RESISTOR 1/16W 1K J R139 VE-30012657 RESISTOR...
  • Page 92 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R517 VE-30012659 RESISTOR 1/16W 2.2K J R746 VE-30012674 RESISTOR 1/16W 27K J R518 VE-30012510 RESISTOR 1/16W 100R J R747 VE-30012641 RESISTOR 1/16W 10K J R522 VE-30012641 RESISTOR...
  • Page 93 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R1128 VE-30012712 RESISTOR 1/16W 8.2K J R1741 VE-30026054 RESISTOR ARRAY 1/32W 47R J R1134 VE-30014128 RESISTOR 1/16W 33R J R1742 VE-30026054 RESISTOR ARRAY 1/32W 47R J R1135 VE-30014128 RESISTOR...

  • Page 94: Av Jack Pwb P.w. Board Ass'y (Ve-20224823)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local 600R/100MHz L1822 VE-30016659 COIL L726 VE-30001971 FERRITE 200mA L1823 VE-30017542 FIXED COIL 10uH J 600R/100MHz L1824 VE-30017143 FIXED COIL 22uH J L729 VE-30001971 FERRITE 200mA L1825 VE-30018612...

  • Page 95: Side Control P.w. Boar Ass'y (Ve-20224821)

    Ref No. Part No. Part Name Description Local 600R/100MHz L104 VE-30020393 FERRITE 200mA 600R/100MHz L105 VE-30020393 FERRITE 200mA 600R/100MHz L106 VE-30020393 FERRITE 200mA 600R/100MHz L107 VE-30020393 FERRITE 200mA 600R/100MHz L108 VE-30020393 FERRITE 200mA 600R/100MHz L109 VE-30020393 FERRITE 200mA 600R/100MHz L110 VE-30020393 FERRITE 200mA...

  • Page 96: Packing

    PACKING PACKING PARTS LIST  Ref.No. Part No. Part Name Description Local VE-50076130 CARTON BOX VE-20217803 CUSHION ASSEMBLY VE-70000587 POLY BAG VE-30034033 REMOTE CONTROL UNIT RM-C1895  5 VE-50076128 INSTRUCTION BOOK (ENGLISH)  6 VE-30002375 POWER CORD  7 VE-30033122 ADAPTER DC24V ------------...
