Epson product. Epson is not responsible for any use of this information as applied to other products. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to...
Images are displayed at a native resolution of 800 × 600 pixels (PowerLite 62c) or 1024 × 768 pixels (PowerLite 82c). Epson 3LCD technology ensures accurate color and remarkable saturation, even in well-lit rooms.
To prevent unauthorized use of the projector, you can assign a password, create a user logo which is displayed at startup to identify the projector, and disable the projector’s buttons through the Operation Lock feature. For more information about security features, see page 65.
Epson support. If you still need help after checking this User’s Guide and the sources listed above, you can use the Epson PrivateLine Support service to get help fast. Call (800) 637-7661 and enter the PIN on your PrivateLine Support card.
In addition, Epson offers free Extra Care unlikely event of an equipment failure, you won’t have to wait for your unit to be repaired. Instead, Epson will ship you a replacement unit anywhere in the United States or Canada, usually via overnight delivery.
Save all packaging in case you need to ship the projector. Always use the original packaging (or equivalent) when you need to send the projector to another location. If you are moving the projector by hand, use the carrying case included with the projector.
To receive a component video signal from a VCR or other video device, you need a D-sub, 15-pin, VGA-to-component video cable, which is available from Epson. See page 13. Some older PowerBooks and Macintosh desktop models may need a Macintosh video adapter; see your computer dealer. Older iMac systems may need a special adapter to provide a VGA output port;...
Optional Accessories To enhance your use of the projector, Epson provides the following optional accessories: Product Replacement lamp Air filter set (includes 2 filters) ® Samsonite wheeled soft case for projector and laptop Samsonite soft shoulder case with laptop compartment...
Setting Up the Projector his chapter tells you how to set up the projector and connect it to a computer or video source. You can connect up to four devices simultaneously: four video sources, one computer and three video sources, or two computers and two video sources. You’ll find instructions for the following in this chapter: ■...
You can download the Projection Distance Calculator program from the Drivers and Downloads section of Epson’s web site: 29.5 to 35.4 feet http://support.epson.com Also keep these considerations in mind: ■ ■ ■...
Try to place the projector directly in front of the center of the screen, facing it toward the screen squarely. If the projector isn’t positioned this way, the image will be “keystone” shaped, instead of square or rectangular. If you place the projector below the level of the screen, you’ll have to tilt it up by extending the front adjustable foot, as described on page 38.
Connecting to a Computer You can connect the PowerLite projector to any computer that has a note standard VGA or BNC monitor port, including PC notebook and If you have an iBook with an laptop computers, Macintosh PowerBooks and iBooks, and hand-held RCA video-out port, follow devices.
Connecting with the VGA Cable Follow these instructions to connect to your computer with the VGA cable that came with your projector. Before you start, make sure your computer and the projector are turned off. 1. If you are connecting the projector to a desktop computer, disconnect the monitor cable from your computer.
If more than one device is connected to the projector, select the correct source after projection starts by pressing the button on the projector or the remote control. See page 34. Connecting with a VGA-5BNC Cable If your computer provides video output through BNC connectors, follow these instructions to connect the projector to your computer with an optional VGA-5BNC cable.
Connecting a USB Cable for Remote Mouse Control Using the remote control as a wireless mouse lets you click through slide show-style presentations, such as PowerPoint, from up to 20 feet away. This makes it easy to deliver your presentation, since you won’t need to stand near your computer.
Connecting an External Monitor If you want to see your presentation close-up as well as on the projection screen, you can connect an external monitor to the projector. This lets you view images on your computer monitor while note the projector is in standby mode (plugged in but not turned on) and Some LCD monitors may not be able to display the check your presentation or switch between picture sources even if...
Playing Sound Through the Projector Your computer probably has its own sound system; however, it may not be adequate for your presentation. If you need more volume, you can connect a commercially available computer audio cable to take advantage of the projector’s built-in amplifier and speaker. You can obtain a computer audio cable (3.5-mm stereo miniplug) from a computer or electronics dealer.
For composite video, use a commercially available RCA A/V cable. See page 25. For S-Video, use the S-Video cable supplied with your video device or order one from Epson. See page 26. For RGB video, use the VGA computer cable included with the projector. See page 27.
Connecting a Composite Video Source If you’re connecting a composite video device, use a commercially available RCA A/V cable. Before starting, make sure the projector and your DVD player or other video source are turned off. 1. Connect the yellow RCA plug on one end of the cable to the projector’s yellow jack.
You’ll need an S-Video cable, which is usually provided with your video source, or you can purchase one from Epson (part number ELPSV01). See page 13 for ordering information. Before starting, make sure the projector and your DVD player or other video source are turned off.
Connecting an RGB Video Source Follow these instructions to connect the projector to a video player or satellite receiver that has an RGB video output port using the VGA computer cable that came with the projector. Before starting, make sure the projector and your DVD player or other video source are turned off.
If your video source has component video connectors, you can use them to project a higher quality video image. You’ll need a component video cable, which can be purchased from Epson (part number ELPKC19). See page 13 for ordering information.
Playing Sound Through the Projector The projector has a built-in speaker with a maximum output of 5 W. You can play sound from your video equipment through the projector’s speaker if your video device has an audio output port. For RCA-Style Audio Output Ports Most video devices have an RCA-style audio output port.
Page 30
For Stereo Mini-Jack Audio Output Ports Some video devices, especially camcorders, may have a stereo mini-jack audio output port. In this case, use a commercially available stereo mini-jack audio cable to connect to the projector: 1. Connect one end of the audio cable to the note To play sound from a source, you must connect the audio...
Projecting nce you’ve set up the projector, you’re ready to turn it on, adjust the image, and give your presentation. Although you can operate the projector without it, the remote control lets you use additional features. See Chapter 3 for instructions on using the remote.
Turning On Your Equipment Make sure your projector and other equipment are set up and connected correctly, as described in Chapter 1. Then turn on your projector, as described below. If you turn on your connected computer or video equipment before starting the projector, the projector automatically detects and displays the image source.
Page 33
4. Turn on your computer or video source if you have not already. 5. Press the P button on top of the projector to turn it on. Power (You can also press the P Power Projector The projector beeps and the power light flashes green as the projector warms up.
Selecting the Image Source Selecting the image source lets you switch between images input from different pieces of equipment connected to the projector (such as a computer and DVD player). If you don’t see the image you want, note press one of the following buttons on the remote control: The name of the selected ■...
Page 35
Check the Signal menu to make sure the correct input source is ■ selected. See page 58. If you’re using a PC laptop: Hold down the key and press the function key that lets you ■ display on an external monitor. It may have an icon such as or it may be labelled CRT/LCD projector to sync up after pressing it.
Page 36
If you’re using a Macintosh laptop with OS X: You may need to set up your system to display on the projector screen as well as the LCD screen. Follow these steps: 1. From the Apple menu, select 2. Select If you’re using a Macintosh laptop with OS 9: You may need to set up your system to display on the projector screen as well as the LCD screen.
3. Drag one monitor icon on top of the other. If the option isn’t available, you may need to select one of Arrange the Simulscan resolution settings: 1. Click the icon, if necessary. Monitor Click here 2. Select a resolution, as shown. (Allow a few seconds Simulscan for the projector to sync up after making the selection.) Adjusting the Image...
Focusing and Zooming Your Image Rotate the focus ring to sharpen the image. Rotate the zoom ring to reduce or enlarge the image. You can also change the image size by moving the projector closer to or farther away from the screen. You can use the the remote control to zoom in on a portion of the image.
2. Once the image is positioned where you want, release the lever to lock the foot in position. 3. To fine-tune the height of the image, rotate the foot at the back of the projector. If the image is no longer rectangular after raising it, see the next section.
note You can also use the buttons on the projector to access the menu system: Menu button ESC button You can also make keystone adjustments using the projector’s Settings Enter button Arrow buttons menu. See page 61. Adjusting the Brightness The brightness of an image depends on the source you are projecting and the amount of light in the room.
Adjusting the Color Mode You may want to adjust the color mode to select a different setting that is appropriate for the image you’re projecting and the environment in which you’re projecting it. If you’re projecting computer or RGB video images, the default color mode is , which is appropriate for presentations in Presentation...
The projector beeps twice, the Power lamp is turned off, and the power light turns orange. With Epson’s exclusive Instant Off cool-down period, so you can pack up and go immediately after turning off the projector. button to...
Page 43
If you want to turn the projector on again, press the P button. 4. Press up on the blue foot release lever and lower the projector to retract the front adjustable foot, as shown. Foot 5. Replace the lens cap and unplug the power cord. 6.
Using the Remote Control he remote control lets you access your projector’s features from anywhere in the room—up to 20 feet away. For example, you can turn the projector on and off, freeze the presentation, zoom in on a portion of your image, and access the menu system.
Controlling the Picture and Sound You can use the remote control to select your source, temporarily turn off the picture and sound, freeze the action, or zoom in on the picture. Make sure you have set up your projector and connected any equipment as described in Chapter 1.
Turning Off the Picture and Sound Press the button on the remote control to turn off the A/V Mute image and sound and darken your screen. This is useful if you want to temporarily re-direct your audience’s attention without the distraction of a bright screen.
4. While the image is enlarged, you can: 5. When you’re done, press the note Changing the Image’s Aspect Ratio You must be projecting component, composite, or If you’re projecting a widescreen format image, you can use the S-Video images to change the Resize aspect ratio.
Using the Remote Control as a Wireless Mouse When you use the remote control as a wireless mouse, you can control your computer or click through slide show-style presentations (such as PowerPoint) from up to 20 feet away. This gives you more flexibility, since you don’t need to stand near your computer to change slides.
Replacing the Batteries The remote control uses two AAA alkaline batteries. Follow these note steps when you need to replace them: The remote control 1. Press in the tab to remove the battery cover. automatically shuts off when it detects a button being pressed more than 30 seconds.
Fine-tuning the Projector ou can use the button on the projector or remote control to Menu access on-screen menus to adjust the image, sound, and other features. This chapter covers the following information: ■ Using the menu system Adjusting image colors and clarity ■...
Using the Projector’s Menu System The six projector menus let you adjust and customize the projector features: ■ ■ ■ ■ ■ ■ Fine-tuning the Projector menu lets you modify the colors of the projected Image image and fine-tune brightness, contrast, and sharpness. menu lets you make adjustments to the input signal.
Changing Menu Settings Use the buttons on the remote control to access the menus and change settings. Follow these steps: 1. Press the button on the remote control or projector to Menu display the menu screen: Menus The six menus are listed on the left, and the options available for the highlighted menu are shown on the right.
Page 54
4. After highlighting the option you want to adjust, use the 5. Press the 6. Press the Fine-tuning the Projector pointer button on the remote control or left or right arrow buttons on the projector to change the setting. In some cases, you may have to press the button to see a sub-screen for Enter...
Adjusting Colors and Clarity The Image menu lets you make adjustments to the colors of the projected image and fine-tune brightness, contrast, and sharpness. The options available depend on which image source is selected: Computer (analog-RGB) and RGB video Component, composite, and S-video Follow these steps to adjust the appearance of your image: 1.
Page 56
3. Use the note You can also select High brightness mode in the Settings menu. See page 61. Fine-tuning the Projector pointer button (or the up and down arrow buttons) and press to select any of the following options: Enter ■...
Page 57
■ Sharpness Sharpens or softens the image. ■ Color Adjustment Adjusts the temperature and intensity of red, green, and blue. 4. When the image is set correctly, press are automatically saved. . Your settings Menu Fine-tuning the Projector...
Adjusting the Input Signal Although the projector normally detects and optimizes the input signal automatically, you can use the Signal menu to make manual adjustments. In addition to changing the position of the projected image, you can correct tracking and sync for computer images, or change the aspect ratio to widescreen format for video images.
Page 59
3. Press . Then use the Enter arrow buttons) and the Enter following options: ■ (computer images) Auto Setup Leave this setting to automatically optimize the computer image. Turn it off if you want to save adjustments you have made to the video settings. (computer images) ■...
4. When you’re finished adjusting the signal settings, press Customizing Projector Features The Settings menu lets you customize the way you use the projector, from adjusting lamp brightness and speaker volume to changing the shape of the mouse pointer. 1. Press the 2.
Page 61
3. Press . Then use the Enter arrow buttons) and the Enter ■ Keystone Adjusts a distorted image from a trapezoid shape to rectangular. ■ Auto Keystone Automatically adjusts a distorted image from a trapezoid shape to rectangular when the projector’s foot is extended or retracted.
Selecting Projector Setup Options Use the Extended menu to customize the way you set up the projector. You can configure the projector for rear and/or ceiling projection, change the language for the menus and messages, set the screen background color, capture and store a custom image or logo for the startup screen, and set up the projector for network use.
Page 63
EMP Link 21L software. This software can be downloaded from the Epson website at support.epson.com. (You must turn the projector off and then on again to use the new setting.) ■...
Viewing Lamp Usage and Other Information note You can make changes to Use the Info menu to view information about the display settings of many of the signal settings on your computer and the number of hours the lamp has been used. the Signal menu.
■ Source Displays the input source currently being projected. (computer, RGB video, and component video) ■ Input Signal Displays the input signal setting. (computer, RGB video, and component video) ■ Resolution Displays the input resolution. (composite and S-Video) ■ Video Signal Displays the video signal format.
30 times in a row, the projector is locked and you’ll need to note contact Epson to unlock it. See “Where To Get Help” on page 95. If you should happen to If someone else will be using the projector for awhile but you want to...
Page 67
3. Use the pointer button (or the down arrow button) and press to select Enter User’s Logo 4. When you see a message asking if you want to use the present image as a user’s logo, select displays over the image. 5.
Setting a Password 1. Press the note If a password has already been set, you see the Password Protect Release screen. See “Starting the Projector with a Password” on page 69. 2. Select 3. Select 4. Hold down the Hold down this button to activate the numeric keypad 5.
The countdown for the elapsed time begins as soon as you close the Password Protect menu. (You can check the elapsed time in this menu next to Time elapsed 4. To enable your screen logo, select . Select and press Enter When this feature is on the logo appears whenever the projector is turned on (if the...
When you see the Password Protect Release screen again, you can try to enter the correct password. If you have forgotten the password, contact Epson with the request code number that appears in the Password Protect Release screen for assistance. See “Where To Get Help” on page 95.
Restoring the Default Settings The Reset menu lets you return most projector menu settings to their default values. It also lets you reset the lamp hours to their initial default value; see page 79 for instructions on resetting the lamp timer. To reset most projector menu settings, select button to display the confirmation screen.
Maintaining and Transporting the Projector regular basis is keep the lens clean. Any dirt or smears on the lens may warning show up on your projected image. Before you clean any You also need to periodically clean the air filter and the air intake and part of the projector, turn it off and unplug exhaust vents.
Cleaning the Lens Clean the lens whenever you notice dirt or dust on the surface. ■ ■ caution Do not use glass cleaner to clean the lens. Cleaning the Projector Case Before you clean the case, first turn off the projector and unplug the power cord.
2. Turn the projector upside-down and clean the filter and air intake vent on the base of the projector. To clean the filter and air vent, Epson recommends using a small vacuum cleaner designed for computers and other office equipment. If you don’t have one, gently clean them using a very soft brush (such as an artist’s brush).
Page 76
3. If you need to replace the filter, slide it off, as shown. 4. Align the new filter carefully as you slide it into place. It should click into place. Maintaining and Transporting the Projector...
To maintain projector brightness and image quality, replace the lamp as soon as possible. Contact your dealer or call Epson at (800) 873-7766 in the United States for a replacement lamp. Request part number V13H010L34. In Canada, please call (800) 463-7766 to locate a dealer.
Page 78
5. Use the screwdriver to loosen the two screws holding the lamp in 6. Hold the lamp as shown and pull it straight out. note The lamp(s) in this product contain mercury. Please consult your state and local regulations regarding disposal or recycling.
9. Lower the lamp cover into place. (The opening should be almost covered, and the top of the cover should be flush with the top of the projector.) Then slide the cover closed and tighten the screw. 10. Reset the lamp timer as described in the next section. Resetting the Lamp Timer You must reset the lamp timer after replacing the lamp to clear the warning message.
The projector contains many glass and precision parts. If you need to Enter button transport it, please follow these packing guidelines to prevent damage to the projector: ■ note Epson shall not be liable for ■ any damages incurred during transportation. ■ Maintaining and Transporting the Projector...
Solving Problems his chapter helps you solve problems with your projector, and tells you how to contact technical support for problems you can’t solve yourself. This chapter explains the following: Using the projector’s on-screen help system ■ ■ What to do when the projector’s status lights flash ■...
Using On-Screen Help If the image doesn’t look right or your audio isn’t working, you can get help by pressing the control. The following choices are available: ■ ■ ■ Follow these steps to get help: 1. Press the Press to Use to select a problem or return to the...
4. Highlight a solution (if this choice is available). Then press the button to select the solution. Enter Press the button if you need to back up. If the solution is to adjust one of the settings, use the button on the remote control or the left and right arrow buttons on the projector to adjust it.
Page 84
See page 95. Flashing red There is a problem with the fan or a sensor. Turn the projector off and unplug it. Contact Epson for help. See page 95. The lamp is burned out, broken, or not installed correctly; or the lamp cover is open. Close the cover or replace or reseat the lamp, if necessary, as described on page 77.
Solving Problems with the Image or Sound No image appears on the screen. Check that the power light is green, not flashing, and the lens cap ■ is off. ■ The projector may be in standby or sleep mode. If the projector has not received any input signal for 30 minutes, it turns off the lamp to conserve the lamp life and save energy.
Page 86
Nothing appears on the external monitor. ■ ■ You see a blue screen with the message ■ ■ ■ ■ If you’re using a PC laptop: ■ Solving Problems Make sure the VGA computer cable is connected to your computer’s video port and the projector’s port.
Page 87
Depending on your computer’s video card, you might need to use ■ the Display utility in the Control Panel to make sure that both the LCD screen and external monitor port are enabled. See your computer’s documentation or online help for details. If you’re using a PowerBook or iBook with Macintosh OS X: 1.
Page 88
Only part of the computer image is displayed. ■ ■ ■ ■ ■ Solving Problems If you’re projecting from a computer or RGB video device, press button on the remote control. If this doesn’t work or if Auto you’re projecting from a component, composite, or S-Video device, you may need to adjust the menu.
Page 89
The image isn’t rectangular, but trapezoid-shaped. ■ Make sure the projector isn’t placed off to one side of the screen, at an angle, or the image won’t be rectangular. Place it directly in front of the center of the screen, facing the screen squarely. If you’ve tilted the projector upward, the image will be broader at ■...
Page 90
■ ■ ■ ■ ■ The image is blurry. ■ ■ ■ ■ ■ ■ Solving Problems The video signal may be split between the computer and the projector. If you notice a decline in the projected image quality when the image is displayed simultaneously on your laptop computer and the projector, turn off the laptop’s LCD display.
Page 91
You see vertical stripes or the image still looks blurry after trying the solutions in the previous section. If you’re projecting from a computer and displaying an image that ■ contains a lot of fine detail, you may notice one or more vertical stripes or bands, or some of the characters may look heavy or blurred.
Page 92
■ ■ There is no sound. ■ ■ ■ ■ ■ ■ Solving Problems projecting from a composite video or S-Video source, make sure the correct is selected on the Signal message. See Video Signal page 58 for details. Check your computer display settings to correct the color balance. If the image seems dark, the lamp may be nearing time for replacement.
You have forgotten the password. ■ Write down the request code that appears in the Password Protect Release screen and contact Epson. See “Where To Get Help” on page 95. If you turned on the password protect feature before setting the ■...
Page 94
You have lost the remote control. You need the remote control to access many projector features. If you have lost it, you can order another from Epson. See page 96 for details about ordering. You can’t control the mouse pointer with the remote control.
Telephone Support Services To use the Epson PrivateLine Support service, call (800) 637-7661 and enter the PIN on the Epson PrivateLine Support card included in your Start Here kit. This is the fastest way of speaking to a live representative, and it’s free. This service is available 6 Pacific Time, Monday through Friday, for the duration of your warranty period.
Page 96
To purchase online, visit the (562) 276-4394 (U.S.) or Epson Store at www.epsonstore.com (U.S. sales only). In Canada, (905) 709-3839 (for dealer please call (800) 463-7766 for dealer referral. referral in Canada).
Projection Lamp note Power consumption Lamp life results vary depending on environmental Lamp life conditions and usage. Turn the projector off when not in use. Continuous Remote Control 24-hour-a-day use may reduce the overall life of the Range product. Batteries (2) Mouse Compatibility Dimensions Height...
Environmental Temperature Operating: 41 to 95 °F (5 to 35 °C) Storage: 14 to 140 °F (–10 to 60 °C) Humidity Operating: 20 to 80% RH, non-condensing Storage: 10 to 90% RH, non-condensing Altitude Up to 4,921 feet (1,500 m) Up to 7,500 feet (2,286 m) with high altitude mode enabled Safety and Approvals...
Compatible Video Formats You can use any of the following video sources: VCR, DVD player, camcorder, digital camera, gaming console, or laser disc player. The projector supports composite video, S-Video, component video, and RGB video, and it automatically senses the video format (HDTV, SDTV, NTSC, PAL, or SECAM).
Although images are displayed at the projector’s native resolution of 1024 × 768 pixels (PowerLite 82c) or 800 × 600 pixels (PowerLite 62c), Epson’s patented SizeWise chip supports computer display formats ranging from VGA through UXGA. To project images output from a computer, the computer’s external monitor signal must be set at a refresh rate (vertical frequency) that’s...
Notices his chapter includes safety instructions and other important information about your Epson PowerLite projector. Important Safety Instructions Follow these safety instructions when setting up and using the projector: ■ Do not place the projector on an unstable cart, stand, or table.
Page 104
■ ■ ■ ■ ■ ■ ■ ■ ■ WARNING: The cords included with this product contain chemicals, including lead, known to the State of California to cause birth defects or other reproductive harm. Wash hands after handling. (provided in accordance with Proposition 65 in Cal.
Remote Control Information You can operate the projector by remote control via a line-of-sight infrared (IR) receiver at the front and rear of the projector. The projector may not respond to remote control commands under the following conditions: ■ There is an object between the remote control IR emitter and the IR receiver on the projector.
FCC Compliance Statement For United States Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
