Compaq Prosignia 170 Quickspecs

A A G
T L A N C E
Immediate out-of-box productivity
with pre-installed software like
Microsoft Office Small Business,
and access to convenient
Compaq Online Services
8-MB Video SDRAM
Weight starting at 5.3 lbs
1.1 inches thin
Integrated 56K V.90 Mini PCI
modem
Full-size keyboard
User removable hard drive
Dual battery support
MultiBay technology supports an
additional 6-cell Battery, Second
Hard Drive, 24X Max CD-ROM,
4X DVD-ROM drive, or LS-120
drive
AGP 2X Graphics
– 8-MB Video SDRAM
– 66-MHz graphics BUS
– Dual-view display support
– NTSC/PAL output
Magnesium LCD display
enclosure
Docking solutions
Compaq Services including a
three-year, Worldwide Limited
Warranty with a free one-year
second business day pick-up and
delivery service — Certain
restrictions and exclusions apply.
Consult the Compaq Customer
Support Center for details.
C
O N F I G U R A B L E
C
O M P O N E N T S
Choice of Intel Pentium III 500 or
450
Choice of 14.1 or 13.3 TFT
1024 x 768 display
Choice of 6, 12 or 18-GB
removable hard drives
Choice of 24X Max CD-ROM or
4X DVD-ROM
64 MB standard SDRAM
upgradable to 320 MB
Integrated Mini PCI V.90
data/14.4 Kb/s fax modem or
V.90 fax/modem Intel PRO+
Ethernet combination card)
Choice of Pointing Stick or Touch
Pad
Choice of Microsoft Office 2000
Small Business, Office 2000
Professional or Word 2000
Other components available
Q S
UICK PECS
Overview
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
1. 14.1-in or 13.1-in TFT 1024 x 768 display
. .
. .
2. Microphone
. .
. .
. .
3. Power Switch
. .
. .
4. Integrated RJ-11 Jack, 56K V.90 Mini PCI modem;
. .
. . Optional RJ-11 and RJ-45 Jack with Intel PRO+
. .
Mini PCI (not shown)
. .
. .
. . 5. MultiBay
. .
. .
6. PC Card Slots
. .
. .
7. Battery Power Light
. .
. .
8. AC Power Light
. .
. .
9. Microphone Jack
. .
. .
. .
10. Stereo Speaker/Headphone Jack
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
.
1 DA-10472-00A-004 — 04.12.2000
Compaq Prosignia
Notebook 170
Configure to Order
11. Primary Battery
12. Primary Hard Drive
13. Left/Right/Third Mouse Buttons
14. 3D Point Stick
15. Stereo Speakers
16. Cable Lock Connector
17. NTSC/PAL Connector
18. Lid Switch
19. Suspend Button
20. Status LED's
21. Display Latch
