Olympus IR-500 Quick Start Manual

— With Dock&Done-compatible printer —
C Dock&Done-compatible printer*
QUICK START GUIDE
Digital Camera
IR-500
Print directly by
*
Thank you for purchasing this OLYMPUS Digital Camera IR-500. Sold separately one-touch operation
This guide contains instructions for basic operations to use the digital camera
— With Dock&Done-compatible storage unit and printer —
immediately after purchase. For details on operations and settings, refer to
the supplied reference manual. For inquiries, contact the OLYMPUS service
center in the enclosed Authorized Distributors List.
Your new life of photography has begun.
What is QDock&Done?
Storing images and photo printing
Dock&Done is a total system that puts personal imaging into a single
can be done at one time
process. For example, by simply setting the digital camera on the cradle,
A Dock&Done-compatible Digital Camera (IR-500)
new pictures are stored, photo printing is done and the camera's batteries
are recharged.
By simply connecting to Dock&Done-compatible products through the
— With Dock&Done-compatible storage unit — cradle, storing images and photo printing can be done with ease.
A Digital camera
B Dock&Done-compatible storage unit
Connect the Dock&Done-compatible digital camera and store image
fi les in a simple step.
B Dock&Done-compatible C Dock&Done-compatible digital photo printer
storage unit*
By connecting to the Dock&Done-compatible storage unit with the
*
Sold separately Store images by one-touch operation Dock&Done cable, storing images and photo printing can be done with
ease.
Tip
Printed in Japan
1AG6P1P2324-- VM036402 Availability of these models may vary from country to country.
User registration
Preparation
To stay informed of important updates and news regarding your Olympus
product, be sure to register your purchase. You can register by one of the
Inserting the battery and card
following ways:
A Digital camera
a Open the battery/card cover.
• Register online
Install the OLYMPUS Master software from the supplied CD-ROM.
When starting OLYMPUS Master after installation, the registration screen
appears.
• Use the registration card
Fill out the supplied registration card, and return it by mail.
QDock&Done cable*
Unpacking the box contents
Grasp the cover on both sides and lift it up.
b Insert the battery and card as shown below.
Make sure your box contains everything listed below. If any item is missing
or damaged, contact the dealer where you purchased the camera. Inserting the battery
* Sold separately
Card Lithium ion battery
Digital camera
(xD- Picture Card) (LI-12B)
Battery lock lever
Press up the battery lock lever with
the corner of the battery.
AC adapter
*1
Cradle Power cord
(A511)
Notes
• Insert the card by pushing it straight in (not at an angle).
• Strap • Basic Manual
• If you insert the card with wrong orientation or at an angle, the contact area could be
• USB cable • Quick Start Guide (this guide)
damaged or you may not be able to remove the card.
• AV cable • Warranty card
• Do not apply excessive force to the battery/card cover as it may be damaged.
• CD-ROMs (OLYMPUS Master/ • Authorized Distributors List
Manual CD) • Registration card *2
*1
The shape of the plug differs from country to country.
*2
Not supplied in some areas.
c Close the battery/card cover.
OK
Note
Do not open the battery/card cover, disconnect the AC adapter, or remove the camera
OK OK
from the cradle while the camera is operating or communicating with a computer. Such
actions could destroy all the data on the card. Once destroyed, data cannot be restored.
Charging the battery
Charge the supplied battery before use.
Inserting the card
Tip
Make sure to turn off the camera by closing the multi-swing display or pressing the
power switch before charging. Charging cannot be performed when the camera's power
is on.
a Connect the AC adapter to the cradle.
OK OK
Cradle
Push the card in until it clicks.
A/V OUT
(MONO)
- + USB
DC IN 5V USB
To DC input terminal
To a wall outlet
AC adapter
(A511)
Power cord *
* The shape of the plug differs from country to country.
b Set the camera on the cradle.
Power on/off
The mark on the camera connector dial indicates the orientation of the
Opening the multi-swing display.
camera when the camera is set on the cradle. Select the mark by turning
the camera connector dial according to the desired camera orientation. The camera automatically turns
on when the display is opened.
Setting the camera with the Setting the camera with the
The camera turns off when the
multi-swing display opened multi-swing display closed
display is closed.
Camera Camera
connector dial connector dial
Power lamp
Pressing the power switch.
When the camera is off with the multi-swing display opened, press the
power switch to turn on the camera. The power lamp lights up.
Power lamp
To turn off the camera, press the power switch again.
c Charging begins.
Power switch
The power lamp slowly blinks during charging. The lamp goes off when
charging is complete.
Notes
OPEN
• The power lamp blinks rapidly if an error occurs during charging. If this happens,
remove the battery from the camera and insert it again, or disconnect the AC adapter
Tips
from the cradle and connect it again.
• If you hold the cradle upside down with the camera set, the camera may fall out of • If the camera is not operated for a certain period of time, the camera automatically
the cradle. enters the sleep mode (standby mode) to save battery power, and the power lamp
• Do not pick up by the camera only when it is set on the cradle. goes off. To cancel the sleep mode, press any button. You can select how long the
camera is on before it enters the sleep mode.
• When the camera has been turned on by opening the multi-swing display in the
shooting mode, if no operation is made in the fi rst 30 seconds, the camera may turn
off automatically.
Selecting the display language (W)
You can select the language in which the menus and error messages are
displayed on the monitor.
a Turn the mode dial to
Multi-swing
display q.
Mode dial
The setup menu appears.
QUICK
VIEW
abcd buttons
OK
OPEN
OPEN
9 button
b Press a/c to select "W."
ALL RESET OFF
ENGLISH
SCREEN OFF
3MIN
SLEEP
CUSTOM BUTTON
Power lamp
Lights up when the
QUICK
VIEW
camera is on. c Press d to enter the language settings.
OK ENGLISH
OPEN FRANCAIS
ESPAÑOL
PORTUGUES
CANCEL SELECT GO
Tips
• The available display languages differ depending on the region where the
camera is sold.
• The available display languages can be added by updating the fi rmware. For
details, refer to the Olympus website.
d Press a/c to select the desired language.
e Press 9.
The selected language is set and the screen returns to the setup menu.
