Chapter 1
Introduction
Section 1-1

Overview

1-1-1 Purpose of Chapter 1
This chapter describes important issues related to safely servicing the LOGIQ C Series. The service
provider must read and understand all the information presented in this manual before installing or
servicing a unit.
Table 1-1
Section
1-1
1-2
1-3
1-4
1-5
1-1-2

Purpose of Service Manual

This Service Manual provides installation and service information for the LOGIQ C Series and contains
the following chapters:
1.) - Introduction: Contains a content summary and warnings.
2.) - Site Preparations: Contains pre-installation requirements for the LOGIQ C Series.
3.) - System Setup: Contains installation procedures.
4.) - Functional Checks: Contains functional checks that are recommended as part of the installation,
or as required during servicing and periodic maintenance.
5.) - Components and Functions (Theory): Contains block diagrams and functional explanations of
the electronics.
6.) - Service Adjustments: Contains instructions on how to make available adjustments to the LOGIQ
C Series.
7.) - Diagnostics/Troubleshooting: Provides procedures for running diagnostic or related routines
for the LOGIQ C Series.
8.) - Replacement Procedures: Provides disassembly procedures and reassembly procedures for all
changeable Field Replaceable Units (FRU).
9.) - Renewal Parts: Contains a complete list of field replaceable parts for the LOGIQ C Series.
10.) - Care & Maintenance: Provides periodic maintenance procedures for the LOGIQ C Series.
