D 5273008-100, R
IRECTION
Section 3-6

System Configuration

3-6-1

System Specifications

3-6-1-1 Physical Dimensions
The physical dimensions of the LOGIQ C Series unit are summarized in
The Size of LOGIQ C Series.
Table 3-4
Height
1400
55.16
3-6-1-2 Weight
Table 3-5
Model
LOGIQ C Series
3-6-2

Electrical Specifications

Table 3-6
System
1
2
3 - 10
9
EVISION
Physical Dimensions of LOGIQ C Series
Width
500
19.70
Weight of LOGIQ C Series With Monitor and Without Other Peripherals
Weight [kg] Weight [lb]
Approximately 75 Approximately 165
Electrical Specifications for LOGIQ C Series
Voltage
110 -120 V AC
220- 240 V AC
Section 3-6 - System Configuration
LOGIQ C B
Depth Unit
700 mm
27.58 inches
Current Frequency
500VA 50/60Hz
500VA 50/60Hz
S S M
ASIC ERIES ERVICE ANUAL
Table 3-4 on page 3-10 .
