- Page 1 Wide Area Network Adapters IBM PCI WAN 2 Port S91 IBM PCI WAN MultiPort T1/E1 S94 IBM PCI WAN MultiPort T1/E1 P92 Installation Guide OPTIONS by IBM Part Number: 33L4649...
- Page 3 IBM intends to announce such IBM products, programming, or services in your country. Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing representative. © Copyright International Business Machines Corporation 1999.
-
Page 5: Table Of Contents
Table of Contents Overview .....................1 IBM PCI WAN 2 Port S91..............1 IBM PCI WAN MultiPort T1/E1 P92 .............1 IBM PCI WAN MultiPort T1/E1 S94 .............2 Hardware Installation ..................3 Software Installation..................3 PCI System Setup ..................3 Connection Status Indicators ...............4 IBM PCI WAN 2 Port S91..............4 IBM PCI WAN MultiPort T1/E1 S94 and IBM PCI WAN MultiPort T1/E1 P92 ............5... -
Page 7: Overview
V.36/RS-449, or X.21 interfaces) at speeds of up to 2 Mbps, and/or through an ISDN BRI port at speeds of up to 128 kbps (over the “D” channel or the “B” channels). Note The IBM PCI WAN 2 Port S91 also supports protocols such as SDLC, PPP, and Frame Relay. Hardware Features The IBM PCI WAN 2 Port S91 features a 25 MHz Motorola 68302 microprocessor with 1 MB of RAM and 1 MB of FLASH memory. -
Page 8: Ibm Pci Wan Multiport T1/E1 S94
Ease of Use The IBM PCI WAN MultiPort T1/E1 P92 is a Plug and Play adapter with automatic interface selection. In most cases, no hardware configuration is required after installing the IBM PCI WAN MultiPort T1/E1 P92 and connecting the appropriate cable. -
Page 9: Hardware Installation
Note Please refer to the user manual that came with your personal computer for detailed installation instructions. Use the following procedure to install your IBM WAN Adapters. Set the host computer system power switch to OFF and disconnect the power cord. -
Page 10: Connection Status Indicators
Connection Status Indicators IBM PCI WAN 2 Port S91 As shown in Figure 1 below, the IBM PCI WAN 2 Port S91 has three status lights (LEDs) on the end bracket. Two of these lights indicate the status of the ISDN connection, and the third identifies the card during configuration. -
Page 11: Ibm Pci Wan Multiport T1/E1 S94 And Ibm Pci Wan Multiport T1/E1 P92
IBM PCI WAN MultiPort T1/E1 S94 and IBM PCI WAN MultiPort T1/E1 P92 The green LED adjacent to each port on the IBM PCI WAN MultiPort T1/E1 S94 and the IBM PCI WAN LED 1 MultiPort T1/E1 P92 (see Figure 2 at right) provides a convenient indication of the status of the connection on that port. -
Page 12: Configuring The Ibm Wan Adapters
Configuring the IBM WAN Adapters Before you can use the IBM WAN Adapters, you must configure it to work with your communications software. LED 1 The documentation which came with this software contains complete instructions on how to configure the card. -
Page 13: Making An Isdn Connection
Making an ISDN Connection IBM PCI WAN 2 Port S91 only Locate the ISDN cable included with the IBM PCI WAN 2 Port S91. • In Europe, connect one end of the cable to the ISDN port, and connect the other end to the wall jack installed by your ISDN service provider. -
Page 14: Making A Vhsi Connection
Making a VHSI Connection An IBM WAN Adapter can connect as a DTE to devices such as Data Service Units (DSUs) which support one of the following interfaces: V.24, V.35, EIA- 530, V.36/RS-449, or X.21. The IBM WAN Adapter can be ordered with different interface cables as shown in the table below. -
Page 15: Vhsi Port Interface Specifications
VHSI Port Interface Specifications The standards compliant with each interface supported on the VHSI ports are listed in the table below. The rest of this section describes the allocation of pins used to implement the electrical and signalling requirements of each interface. A wiring diagram is also provided, to show the correspondence of the interface pinout to the VHSI port. -
Page 16: Vhsi Cable Construction Information
VHSI Cable Construction Information If you plan to construct your own VHSI cables, be sure to observe the guidelines given below. Wire Gauge, Grounding, and Pairing • Use 28 AWG 7-strand wire with 0.020–0.028" insulation. • The chassis must be grounded both by a drain wire and by the braid; both must be connected to the connector case and shell at each end of the cable. -
Page 17: The V.24 Interface
The V.24 Interface The pin-out assignments for the V.24 interface are shown in the following diagram. PG N D TCLK RCLK TEST SG N D DTECLK Figure 6: V.24 Interface The signal definitions and names are listed in Table 5 below. Pin # Signal Name... - Page 18 VHSI—V.24 Connections The wiring diagram below shows the connections required to construct a VHSI—V.24 cable. For the additional information required to construct your own cables, see “VHSI Cable Construction Information” on page 10. VHSI V.24 DRAIN WIRE BRAID Figure 7: VHSI—V.24 Connections VHSI Port Interface Specifications...
-
Page 19: The V.35 Interface
The V.35 Interface The pin-out assignments for the V.35 interface are shown in the following diagram. SGND P G N D C T S R T S D C D D T R TEST T X D+ R XD + TX D- R XD - CLK+... - Page 20 VHSI—V.35 Connections The wiring diagram below shows the connections required to construct a VHSI—V.35 cable. For the additional information required to construct your own cables, see “VHSI Cable Construction Information” on page 10. TWISTED PAIRS (MANDATORY) VHSI V.35 DRAIN WIRE BRAID Figure 9: VHSI—V.35 Connections VHSI Port Interface Specifications...
-
Page 21: The Eia-530 Interface
The EIA-530 Interface The pin-out assignments for the EIA-530 interface are shown in the following diagram. PG ND TXD- TXD+ TRXC+ RXD+ RXD- RTS+ RTXC+ CTS+ TEST DSR+ RTS- SG N D DTR+ DCD+ RTXC- DSR- DCD- DTR- CL K- C L K + TRXC- CTS-... - Page 22 VHSI—EIA-530 Connections The wiring diagram below shows the connections required to construct a VHSI—EIA-530 cable. For the additional information required to construct your own cables, see “VHSI Cable Construction Information” on page 10. TWISTED PAIRS (MANDATORY) VHSI EIA-530 DRAIN WIRE BRAID Figure 11: VHSI—EIA-530 Connections VHSI Port Interface Specifications...
-
Page 23: The V.36/Rs-449 Interface
The V.36/RS-449 Interface The pin-out assignments for the V.36/RS-449 interface are shown in the following diagram. PG N D TXD+ TXD- TRXC+ TRXC- RXD+ RXD- RTS+ RTS- RTXC+ RTXC- CTS+ CTS- TEST DSR- DSR+ DTR- DTR+ DCD- DCD+ C LK - C L K + G N D Figure 12: V.36/RS-449 Interface... - Page 24 VHSI—V.36/RS-449 Connections The wiring diagram below shows the connections required to construct a VHSI—V.36/RS-449 cable. For the additional information required to construct your own cables, see “VHSI Cable Construction Information” on page 10. TWISTED PAIRS (MANDATORY) VHSI V.36 / RS-449 DRAIN WIRE BRAID Figure 13: VHSI—V.36/RS-449 Connections...
-
Page 25: The X.21 Interface
The X.21 Interface The pin-out assignments for the X.21 interface PG N D T(B) T(A) are shown in the following diagram. C(B) C(A) R(B) R(A) I(B) I(A) The signal definitions and names are listed in S(B) S(A) B(B) B(A) Table 9 below. PG ND SGND Figure 14: X.21 Interface... -
Page 26: Back-To-Back Connections
Back-to-Back Connections The wiring diagram below shows the connections required to construct a back- to-back VHSI—VHSI cable. Back-to-back operations are conducted through the V.36 interface. For the additional information required to construct your own cables, see “VHSI Cable Construction Information” on page 10. TWISTED PAIRS (MANDATORY) VHSI... -
Page 27: Product Warranty
IBM, will provide warranty service under the type of service designated for the Machine and will manage and install engineering changes that apply to the Machine. For IBM or your reseller to provide warranty service for a feature, conversion, or upgrade, IBM or your reseller may require... - Page 28 IBM's or your reseller's service center, to restore a Machine to good working order. When a type of service involves the exchange of a Machine or part, the item IBM or your reseller replaces becomes its property and the replacement becomes yours.
- Page 29 IBM or your reseller of changes in a Machine's location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM's possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
-
Page 30: Limitation Of Liability
Circumstances may arise where, because of a default on IBM's part or other liability you are entitled to recover damages from IBM. In each such instance, regardless of the basis on which you are entitled to claim damages from IBM (including fundamental breach, negligence, misrepresentation, or other contract... -
Page 31: Telecommunication Notices
If you experience trouble with this product, contact your Authorized Reseller, or call IBM. In the United States, call IBM at 1-800-772-2227. In Canada, call IBM at 1-800-565-3344. You may be required to present proof of purchase. - Page 32 Canadian Department of Communications Certification Label NOTICE: The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction.
- Page 33 raccordement. L'abonné ne doit pas oublier qu'il est possible que la conformité aux conditions énoncées ci-dessus n'empêchent pas la dégradation du service dans certaines situations. Les réparations de matériel homologué doivent être effectuées par un centre d'entretien canadien autorisé désigné par le fournisseur. La compagnie de télécommunications peut demander à...
-
Page 34: Electronic Emission Notices
• Consult an IBM authorized dealer or service representative for help. Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from IBM authorized dealers. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. - Page 35 Directive 89/366/ECC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM can not accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-IBM option cards.
