Reference Manual for the Model FR114P, FR114W and FM114P Cable/DSL ProSafe Firewall
Click Apply to save your configuration.
8.
Note: If your ISP assigns a private WAN IP address (such as 192.168.x.x or 10.x.x.x),
the dynamic DNS service will not work because private addresses will not be routed on
the Internet.

LAN IP Setup

The LAN IP Setup menu allows configuration of LAN IP services such as DHCP and RIP. From
the Main Menu of the browser interface, under Advanced, click on LAN IP Setup to view the LAN
IP Setup menu, shown in
Figure 9-2. LAN IP Setup Menu

LAN TCP/IP Setup

The firewall is shipped preconfigured to use private IP addresses on the LAN side, and to act.as a
DHCP server. The firewall's default LAN IP configuration is:
Advanced Configuration
Figure 9-2
9-3
