安全提示
Installation & Maintenance Manual
The manual covers the following models
DB175A, DB215A, DB255A
DBice APP QR Code
Note：Subsequent updated versions of this manual will not be noticed, thank you.
File No：JT190100004
Concent
1. Features-------- ------- --------- -------- ----3
3. Critical Parameter-------------------------4
4. Unpacking-----------------------------------4
5. Installation Location ----------------------4
6. Leveling Adjustment -- --- ---- --- --- --- ---4
7. Wat er sup pl y/ P ur g e- - - - - - - - - - - - - - - - - - - - - 5
7 . 1 W a t e r / s u p p l y - - - - - - - - - - - - - - - - - - - - - - - 5
7 . 2 P u r g e - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
8 . P o w e r S u p p l y - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
9. Clean af t er I nst al lat ion - -- -- -- --- -- -- -- -5
10. Check after Installation ----------------5
1 1. O p er at i on - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6
11.1 Coustomer operation---------------6
11. 2 Ser vice - -- - -- -- -- - - - - -- -- -- - -- -- - -- - 9
11.3 Advanced Setup -----------------11
12. O per at ion inspect ion - - - -- - -- -- - -- - -- - 11
13. Regular cleaning-----------------------12
14. Condenser cleaning--------------------12
15. Cleaning & Sanitation--------------- --12
15.1 Cleaning process ---------------------13
15.2 Disinfection process ----------------13
15.3 Rinse process -------------------------13
15.4 Parts removal -----------------------------14
16.Out of use/Winterization-----------------15
17.Maintenance-------------------------------15
1 8 . D B i c e a p p - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 6
Version：A
1 / 16
Advertisement
Table of Contents
Related Manuals for Hoshizaki DB Series
Summary of Contents for Hoshizaki DB Series
-
Page 1: Table Of Contents
安全提示 Concent DB Series Ice Maker 1. Features-------- ------- --------- -------- ----3 2 . S i z e& Ap p ea r a nc e - - - - - - - - - - - - - - - - - - - - - 3 Installation &... - Page 2 安全提示 Safety TipsConcent When operates and maintains an ice maker ,be sure to pay attention to the safety tips in the manual. Ignoring these tips may result in personal injury and ice maker damage. In this manual, you will see the following forms of security tips： WARNING Potential personal injury.
-
Page 3: Db Series Ice Maker
安全提示 Features Appearance 1. Features DB series ice maker are with several patent control system, it could be simply operated, suitable for different water quality conditions; The key components are from international renowned brands, which ensures reliability in harsh environments;... -
Page 4: Critical Parameter
安全提示 Critical Parameter good condition, and the machine model is 3. Critical Parameter consistent with what you have purchased. Take out accessories and documents, check for its consistency with packing list. If there is any discrepancy or damage, please ... -
Page 5: Leveling Adjustment
安全提示 Water Supply 6. Leveling Adjustment The main gully drain capacity shall be enough for all drain water: Note The drain hose of the water-cool condenser Do not put hard object under legs for and the drain hose of ice bin should be placed separately leveling ice maker. -
Page 6: Clean After Installation
安全提示 Operation 9. Clean after Installation 11. Operation 11.1 Coustomer operation After the ice maker is installed, clean the shell, liner and ice scoop with a clean wet cloth or 11.1.1 Language option sponge; 10. Check after installation After the ice maker is installed, check against the ... - Page 7 安全提示 Operation minutes of increase or decrease in ice making time) 11.1.4 Energy saving setting： 11.1.4.1 Ice making mode ：It is applicable to winter or off-season, when less ice needed) press SETUP - > USER SETUP - >ICE MAKING MODE icon TIMER ON, XX h XX m later, the ice maker starts ...
- Page 8 安全提示 Operation 11.1.5 Clean Press CLEAN icon in main interface to start Press SETUP ->MACHINE INFO enter the clean process . interface. Press ESC icon in to stop clean process . RESTART option: Select: When power supply is restored ...
-
Page 9: Service
安全提示 Operation E1：Ice making time more than 40 minutes 11.1.9 Restore Factory Settings (Default mode, E2：Ice defrost time more than 4 minutes suitable for any condition) E3：Water Shortage Protect E4：Ice Making System Error E5：Ice defrost System Error E6：High Pressure Protect E7：High Temperature Protect E8：N/A E9：N/A... -
Page 10: Advanced Setup
安全提示 Operation 11.3.1 Freeze/harvest time set 11.2.3.Sensor Function Check Press SETUP -> SERVICE -> INPUT CHECK Longest Freeze: This parameter specifies the Harvest Probe and water level probe: maximum ice making time. When the ice making time is ... -
Page 11: Operation Inspection
安全提示 Operation Inspection 11.3.3 Equipment Information Input 12 Operation Inspection Notice The ice maker has been tested and inspected in factory before delivery. Generally, the new installed machine does not need any debugging. In This funciton is only for manufacturer. order to ensure the normal operation of the ice maker, the operation 11.3.4 Temperature Setup... -
Page 12: Regular Cleaning
安全提示 Regular Cleaning should be from top to bottom ( it will break 13 Regular Cleaning condenser fins act from one side to another) Use commercial coil (air conditioning) cleaner. Important Follow the instructions and precautions for coil cleaning agent when using. The damaged Condenser dirty will block air flow, cause fins should be straightened with a fin comb. -
Page 13: Cleaning Process
安全提示 Cleaning and Disinfection 15.1Cleaning process 15.2 Disinfection process Open door and check if any ice formed on Put 2 packets of disinfectant (KAY5, 28.4g/packet) evaporator. If ice formed on evaporator, please into 8 liter warm water (45 ~ 50°C). press button ”Manual ice collection”... -
Page 14: Parts Removal
安全提示 Cleaning and Disinfection Discard the first three plates of ice to ensure that the disinfectant is completely discharged from the system. Turn off the power and put the ice maker back in place to complete the cleaning and disinfection process。... -
Page 15: Out Of Use/Winterization
安全提示 Mantiance 16 Out of use / Winterization NOTICE Under the environment of less than 0 ° C, if water is left in the machine, it may cause serious damage to machine parts, and the fault caused by this reason is not covered by the warranty. - Page 16 安全提示 DBice APP Select your equipment SN 18. DBice APP download and instructions Click “Unbind equipment” APP size: 23MB Confirm then click “YES” or “NO” QR Code Operation manual for equipment Click “Manual” button. Equipment parameters (for service purpose) ...
