7E8 SATA Product Manual
Standard 5xxE model
ST8000NM000A
ST6000NM021A
ST4000NM002A
ST2000NM001A
Self-Encryption 5xxE models
ST8000NM004A
ST6000NM023A
ST4000NM010A
ST2000NM010A
SED (FIPS 140-2) 5xxE models
ST8000NM008A
ST6000NM025A
ST4000NM012A
* Default configuration is 512E for 512E / 4KN drives.
See
to Fast Format to 4KN in seconds
Section 2.2.1
100840703, Rev. B
Gen. 10 May 2019
Advertisement
Table of Contents
Related Manuals for Seagate EXOS Standard 5 E Series
Summary of Contents for Seagate EXOS Standard 5 E Series
- Page 1 7E8 SATA Product Manual Standard 5xxE model ST8000NM000A ST6000NM021A ST4000NM002A ST2000NM001A Self-Encryption 5xxE models ST8000NM004A ST6000NM023A ST4000NM010A ST2000NM010A SED (FIPS 140-2) 5xxE models ST8000NM008A ST6000NM025A ST4000NM012A * Default configuration is 512E for 512E / 4KN drives. to Fast Format to 4KN in seconds Section 2.2.1 100840703, Rev.
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 41 Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 6: Introduction
• Tarnish-resistant components to help protect drive from environmental elements, increasing field reliability. • Worldwide Name (WWN) capability uniquely identifies the drive. Seagate recommends validating the configuration with the selected HBA/ Note RAID controller manufacturer to ensure use of full capacity is supported. -
Page 7: Drive Specifications
Voltage tolerance (including noise) 12V ±10% Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections and 2.11) 2.6.1 Operating temperature Operating temperature 20°C (operating) Temperature gradient (°C per hour max) 30°C (nonoperating) Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 8: 2.2Formatted Capacity
ST6000NM021A, ST6000NM023A, ST6000NM025A 11,721,045,168 ST4000NM002A, ST4000NM010A, ST4000NM012A 7,814,037,168 ST2000NM001A, ST2000NM010A 3,907,029,168 * One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 9: Fast Format - Logical Sector Size Conversion
Se tor Co figuratio des riptors page for at log page 00h Offset Type Description 0...15 Bytes Sector Configuration descriptor 0 16...31 Bytes Sector Configuration descriptor 1 ..112...127 Bytes Sector Configuration descriptor 7 128...511 Bytes Reserved Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 10: Lba Mode
216 (226 MB/s max) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 23/30 Standby to Ready (sec) (typ/max) 23/30 Ready to spindle stop (sec) (max) Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 11: Power Specifications
0.562 0.561 9.54 Maximum DC 0.565 0.565 9.61 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 12 0.564 0.476 8.53 Maximum DC 0.564 0.476 8.53 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Exos 7E8 SATA Product Manual, Rev. B...
- Page 13 0.584 0.394 7.64 Maximum DC 0.59 0.394 7.68 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate Exos 7E8 SATA Product Manual, Rev. B...
- Page 14 0.577 0.296 6.44 Maximum DC 0.583 0.296 6.47 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 15: Typical Current Profiles
2.5.2 Typical current profiles Figure 1. 8TB Typical startup and operation current profile 2.5.3 Typical current profiles Figure 2. 6TB Typical startup and operation current profile Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 16: Typical Current Profiles
2.5.4 Typical current profiles Figure 3. 4TB Typical startup and operation current profile 2.5.5 Typical current profiles Figure 4. 2TB Typical startup and operation current profile Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 17: Conducted Noise
• EPC Feature enabled flag is set if at least one Idle power condition timer is enabled Power Condition Log reports the following for each power condition • Nominal recovery time from the power condition to active Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 18 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 19: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. 2.6.2 Humidity The values below assume that no condensation on the drive occurs. -
Page 20: Shock And Vibration
Linear Random Non-Operating Vibration The drive will not incur physical damage or have non-recoverable errors after being subjected to the power spectral density noise specified below. Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 21: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 22: Reliability
Storage Workgroup Security Subsystem Class: Enterprise_A” specification with additional vendor-unique features as noted in this product manual. 2.12.2 Regulatory Models The following regulatory model number represent all features and configurations within the series: Regulatory Model Numbers: STL010 Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 23: European Union (Eu) Ce Marking Requirements
Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 24: Fcc Verification
2.13.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. The RoHS2 restricts the use of certain hazardous substances such as Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ether (PBDE), BisBis(2-Ethylhexyl) phthalate (DEHP), Benzyl butyl phthalate (BBP), Dibutyl phthalate (DBP), and Diisobutyl phthalate (DIBP) in electrical and electronic equipment (EEE). -
Page 25: China Requirements -China Rohs 2
Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products. To comply with China RoHS 2, Seagate determines this product's Environmental Protection Use Period (EPUP) to be 20 years in accordance with the Marking for the Restricted Use of Hazardous Substances in Electronic and Electrical Products, SJT 11364-2014. -
Page 26: Taiwan Requirements - Taiwan Rohs
The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives. Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 27: Reference Documents
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 28: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure Figure 5. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Exos 7E8 SATA drives support latching SATA connectors. Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 29: Drive Mounting
C L OF DRIVE 2.000 .138±.015 1.028 MAX [26.10MM] Figure 6. Mounting configuration dimensions 8TB and 6TB models The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 30 C L OF DRIVE .138±.015 2.000 1.028 MAX 26.10 MM Figure 7. Mounting configuration dimensions 4TB and 2TB models The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 31: About Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two ATA commands: •... -
Page 32: Random Number Generator (Rng)
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: The download must be an SED file. -
Page 33: Power Requirements
The drive shall not support the OVERWRITE EXT and BLOCK ERASE EXT sub-commands. Support of the SANITIZE FREEZE LOCK EXT command shall be determined on a customer-specific basis. OEM drives shall support the command. Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 34: About Fips
Figure 8. Example of FIPS tamper evidence labels. Image is for reference only, may not represent actual drive Note Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 35: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane config- uration. All used voltage pins (V ) must be terminated. Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 36: Supported Ata Commands
/ 0014 Sanitize Device - Freeze Lock Ext / 0020 Sanitize Device - Status Ext / 0000 Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 37 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 38: Identify Device Command
Minimum multiword DMA transfer cycle time per word (120 ns) 0078 Recommended multiword DMA transfer cycle time per word (120 ns) 0078 Minimum PIO cycle time without IORDY flow control (120 ns) 0078 Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 39 NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. 112–118 ATA-reserved 0000 Commands and feature sets supported 43DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx Seagate Exos 7E8 SATA Product Manual, Rev. B...
- Page 40 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Exos 7E8 SATA Product Manual, Rev. B...
-
Page 41: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Exos 7E8 SATA Product Manual, Rev. B... -
Page 42: S.m.a.r.t. Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Exos 7E8 SATA Product Manual, Rev. B... - Page 43 Seagate Technology LLC AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 Publication Number: 100840703, Rev. B May 2019...
