This manual provides the main information to carry out regular maintenance operations on your vehicle. This manual is intended to aprilia Dealers and their qualified mechanics; several concepts have been deliberately omitted as they are considered unnecessary. As it is not possible to include complete mechanical notions in this manual, users should have basic mechanical knowledge or minimum knowledge about the procedures involved when repairing scooters.
INDEX OF TOPICS CHAR HARACTERISTICS S-TOOLS PECIAL TOOLS MAIN AINTENANCE ELE SYS LECTRICAL SYSTEM ENG VE NGINE FROM VEHICLE NGINE P SUPP OWER SUPPLY SUSP USPENSIONS CHAS HASSIS BRAK SYS RAKING SYSTEM COOL SYS OOLING SYSTEM BODYW ODYWORK PRE DE DELIVERY...
RS 125 - Tuono 125 - Euro 4 Characteristics Rules Safety rules Carbon monoxide If you need to keep the engine running while working on the vehicle, please ensure that you do so in an open or very well ventilated area. Never run the engine in an enclosed area. If you do work in an enclosed area, make sure to use a fume extraction system.
RS 125 - Tuono 125 - Euro 4 Characteristics KEEP OUT OF THE REACH OF CHILDREN. NEVER REMOVE THE RADIATOR CAP WHILE THE ENGINE IS STILL HOT. COOLANT IS UNDER PRESSURE AND MAY CAUSE BURNS. Used engine oil CAUTION IT IS ADVISABLE TO WEAR PROTECTIVE IMPERMEABLE GLOVES WHEN SERVICING THE VE- HICLE.
Page 9
REASSEMBLING COMPONENTS CAUTION BEARINGS MUST ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE, OTHERWISE, THEY NEED TO BE REPLACED. • Only use ORIGINAL Aprilia SPARE PARTS. • Comply with lubricant and consumables use guidelines. • Lubricate parts (whenever possible) before reassembling them.
Page 10
That is to permit the adequate adjustment of the pad friction material to the brake discs. AFTER THE SPECIFIED MILEAGE, TAKE YOUR VEHICLE TO AN Official Aprilia Dealer FOR THE CHECKS INDICATED IN THE "RECOMMENDED PRODUCTS" TABLE IN THE SCHEDULED MAIN- TENANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHICLE.
RS 125 - Tuono 125 - Euro 4 Characteristics Vehicle identification SERIAL NUMBER LOCATION These numbers are necessary for vehicle registration. NOTE ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR- TICULAR, MODIFYING THE CHASSIS NUMBER IMMEDIATELY VOIDS THE WARRANTY. This number consists of numbers and letters, as in the example shown below.
Page 12
RS 125 - Tuono 125 - Euro 4 Characteristics Engine ENGINE Specification Desc./Quantity Engine type Single cylinder 4 stroke Engine capacity 124.2 cm³ (7.58 cu in) Bore x stroke (58 x 47) mm; (2.28 x 1.85) in Compression ratio 12.0 +/- 0.5: 1 Start-up electric Idle speed...
Page 58
RS 125 - Tuono 125 - Euro 4 Special tools PECIAL TOOLS Stores code Description 020911Y Engine installation adapter for RS 125 + 020710Y 866714 Swingarm adjustment 805181B Tool for fitting chain link AP8140266 Dial gauge mount 865259 Flywheel retainer 866380 Water pump tool set S-TOOLS - 58...
Page 59
RS 125 - Tuono 125 - Euro 4 Special tools Stores code Description 864868 Flywheel extractor 864567 Camshaft timing adjustment lock pins 864486 Countershaft lock tool 00H05600351 Oil seal guide 020382Y011 Valve removal/installation tool 020287Y Tool for installing seal rings 865261 Piston retainer S-TOOLS - 59...
Page 60
RS 125 - Tuono 125 - Euro 4 Special tools Stores code Description 00H05300041 Clutch lock 865260 Camshaft sprocket lock tool 020376Y Adaptor handle 020359Y 42 x 47 mm Adaptor 020358Y 37 x 40 mm Adaptor 020357Y 32 x 35-mm Adaptor 020439Y 17 mm punch for secondary shaft oil seal S-TOOLS - 60...
Page 61
RS 125 - Tuono 125 - Euro 4 Special tools Stores code Description 020891Y 25 mm (0.98 in) adapter 020363Y 20 mm diam. punch for crankshaft oil seal 020412Y 15 mm diam. punch for clutch oil seal 020375Y 28x30 mm punch 020483Y 30-mm guide 020364Y...
RS 125 - Tuono 125 - Euro 4 Maintenance Scheduled maintenance table Correct maintenance is fundamental for ensuring the longevity of your vehicle and maintaining optimum function and performance. Services must be performed as soon as the specified mileage and time intervals are reached. Services must be performed punctually at the correct intervals to maintain the validity of the warranty.
Page 65
RS 125 - Tuono 125 - Euro 4 Maintenance Km x 1,000 (mi x 1,000) EVERY EVERY (0.6) (3.7) (7.5) (11.2) (14.9) (18.6) (22.4) (26.1) (29.8) MONTH MONTH Screw tightness Front suspension: oil (5) Indicator lamps Final drive (1)(6) Fuel and oil pipes + filters (2) Brake pipes Labour time (minutes) SCHEDULED MAINTENANCE TABLE RESERVED TO THE USA-LATAM MARKET...
RS 125 - Tuono 125 - Euro 4 Maintenance km (mi) x1000 1 (0.6) 6 (3.7) 12 (7.5) 18 (11.2) 24 (14.9) 30 (18.6) 36 (22.4) 42 (26.1) 48 (29.8) Fuel and oil pipes + filters Brake pipes Labour time (minutes) NOTE AT EACH SCHEDULED MAINTENANCE MUST BE VERIFIED WITH THE DIAGNOSTIC TOOL IF THERE ARE ERRORS AND THE IF THE PARAMETERS ARE CORRECT.
RS 125 - Tuono 125 - Euro 4 Maintenance • If any defects are found, replace the spark plug with a new component of the specified type. • Fit the spark plug with the correct incli- nation and hand-tighten it completely into its seat, then tighten definitively to the specified torque.
Page 68
RS 125 - Tuono 125 - Euro 4 Maintenance • From the left hand side of the engine, unscrew and remove the oil dipstick-cap (1). • Wipe the dipstick clean with a clean cloth, then refit and retighten it into the oil filler. •...
Page 69
RS 125 - Tuono 125 - Euro 4 Maintenance • Keep the vehicle upright with both wheels on the ground. • Place a container of suitable capacity under the drain plug (2). • Unscrew and remove the drainage plug (2). •...
RS 125 - Tuono 125 - Euro 4 Maintenance Engine oil filter • Remove the bottom fairing and drain the engine oil. • Undo and remove the oil filter cap. • Remove the oil filter. Air filter • The passenger saddle must be removed in order to remove the air filter. •...
RS 125 - Tuono 125 - Euro 4 Maintenance • Working from behind the tank, lift the filter box cover (3) and remove com- plete with the filter element (4). • Separate the filter element (4) from the filter box cover (3) on a clean, dry sur- face.
Page 72
RS 125 - Tuono 125 - Euro 4 Maintenance TO AVOID SPILLING FLUID WHILE TOPPING UP, KEEP THE LEVEL OF THE FLUID IN THE RES- ERVOIR PARALLEL WITH THE EDGE OF THE RESERVOIR ITSELF (IN HORIZONTAL POSITION). DO NOT ADD ADDITIVES OR OTHER SUBSTANCES TO THE FLUID. FUNNELS OR ANY OTHER IMPLEMENTS USED MUST BE PERFECTLY CLEAN.
RS 125 - Tuono 125 - Euro 4 Maintenance • Top up the reservoir (6) with recom- mended brake fluid to above the mini- mum level marking "MIN". CAUTION ONLY FILL TO THE "MAX" LEVEL AFTER FITTING NEW BRAKE PADS. DO NOT FILL TO THE "MAX" LEVEL WITH WORN PADS, AS THIS WILL CAUSE FLUID TO ESCAPE WHEN REPLACING BRAKE PADS.
RS 125 - Tuono 125 - Euro 4 Maintenance Adjusting the lever Adjustment clutch when the engine stops or the vehicle tends to move forward even when clutch lever is operated and the gear engaged, or if the clutch "slides", resulting in acceleration delay con- sidering the engine revs.
Page 81
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE B - ABS SENSOR The ABS sensor must be fastened with the cable fasteners onto the front brake pipe, must pass through the eyelet of the brake calliper bleeding cap and must be curved as shown in the photo- graph.
Page 82
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE C2 • Using two rubber clamps, lock together the wiring harness of the RH light switch and the wiring harness of the front brake and the brake pipe. D TABLES - ARCH BRACE TABLE D1 1.
Page 83
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE D2 The headlamp wiring harness connector is inside the instrument holder arch brace TABLE E - DETAIL OF LIGHTS 1. Clamps. 2. LH light switch wiring harness. 3. RH light switch wiring harness. The clamps must secure the light switch wiring harnesses to the semi-handlebars.
Page 84
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE F - IGNITION SWITCH 1. Ignition switch. 2. Clamp. 3. Ignition switch wiring harness. The clamp must block the ignition switch wiring harness as shown. TABLE G - INSTRUMENT PANEL 1.
Page 85
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE H2 1. Voltage regulator wiring harness. CAUTION CHECK THAT THE REGULATOR IS CORRECTLY CON- NECTED. IN THE AREA SHOWN IN RED (REGULATOR CABLE, BE- HIND RADIATOR) THE FLYWHEEL CONNECTION MUST NOT BE SEEN BUT BE CONCEALED BEHIND THE PLAS- TIC COVER.
Page 86
RS 125 - Tuono 125 - Euro 4 Electrical system Central part A TABLES - PRE-FITTING OF CHASSIS TABLE A1 1. Retaining clips. 2. Cable guide. TABLE A2 1. Edge clips Place the edge clips between the points indicated on the chassis. TABLE A3 - RH SIDE 1.
Page 87
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE A4 - LH SIDE 1. Cable guide 2. Hole for chassis ground. 3. Rubber edge protectors. TABLE B - PRE-FITTING OF FUEL RESERVE SENSOR 1. Fuel pump 2. Fuel reserve sensor WIRING TABLE C 1.
Page 88
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE D2 1. Coil connector 2. Coil earth. 3. Circlip. E TABLES - CONNECTION OF MIU (3G) CON- TROL UNIT - INJECTOR- WATER TEMPERA- TURE SENSOR TABLE E1 1. Protective rubber. TABLE E2 1.
Page 89
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE E3 1. Connector. 2. Injector. CAUTION CONNECT THE CONNECTOR TO THE INJECTOR AND MAKE SURE IT HAS BEEN CORRECTLY CONNECTED. TABLE E4 CAUTION CONNECT THE WATER TEMPERATURE SENSOR CON- NECTOR AND MAKE SURE THAT IT HAS BEEN CORRECT- LY INSERTED.
Page 90
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE F - PRE-FITTING OF RADIATOR FAN 1. Radiator fan. G TABLES - PRE-FITTING OF ABS - PROCE- DURE FOR INSERTION OF ABS CONNECTOR TABLE G1 1. ABS Modulator. 2. ABS modulator support. 3.
Page 91
RS 125 - Tuono 125 - Euro 4 Electrical system When the connector is fully inserted, the distance between the connector and the ABS control unit must be 7.5 mm. if the initial position of the connector and the driving lever is not as shown in "TABLE G2 - Figure 1", the connector will not be properly coupled and the distance measured will be greater (approx.
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE I2 1. Main wiring harness. 2. Cable guide. CAUTION PLACE THE GREY REFERENCE MARKS ON THE WIRING HARNESS IN THE RESPECTIVE CABLE FASTENERS AND CLOSE THEM, POSITIONING THE WIRING HARNESS AS SHOWN IN THE PHOTOGRAPH.
Page 93
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE L - CONNECTING THE COIL 1. Coil connector. 2. Ground cable. 3. Circlip. CAUTION MAKE SURE THAT THE CONNECTOR HAS BEEN CON- NECTED AND THE GROUND CABLE FASTENED TO THE CIRCLIP CORRECTLY.
Page 94
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE M2 1. Ground cable. CAUTION MAKE SURE THAT THE GROUND CABLE IS FASTENED TO THE CHASSIS CORRECTLY. N TABLES - BATTERY AREA COMPONENTS TABLE N1 1. Turn indicators relay. 2.
Page 95
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE N3 1. Start-up relay. TABLE O - REAR BRAKE SENSOR ROUTING 1. Clamp. 2. Rear brake sensor wiring harness. TABLE P - HORN - NEUTRAL SENSOR - STAND SENSOR 1.
Page 96
RS 125 - Tuono 125 - Euro 4 Electrical system Q TABLES - LAMBDA PROBE - ENGINE OIL PRESSURE SENSOR TABLE Q1 1. Lambda probe wiring harness. 2. Rubber clamps. 3. Engine oil pressure sensor. CAUTION CHECK THAT THE CAP IS CORRECTLY INSERTED ON THE ENGINE OIL PRESSURE SENSOR.
Page 97
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE R - STARTER MOTOR 1. Starter motor ground wiring harness. 2. Starter motor positive wiring harness. CAUTION CHECK THAT THE STARTER MOTOR GROUND CABLE AND POSITIVE CABLE HAVE BEEN FASTENED COR- RECTLY COMPLETE WITH PROTECTIVE CAP.
Page 98
RS 125 - Tuono 125 - Euro 4 Electrical system T TABLES - FUEL TANK WIRING HARNESSES TABLE T1 1. Fuel pipe. 2. Clamps. 3. Fuel pump/sensor wiring harness CAUTION CONNECT THE BRANCH OF THE FUEL PUMP WIRING HARNESS TO THE FUEL PIPE WITH TWO CLAMPS IN LINE WITH THE GREY TAPING.
Page 99
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE T3 1. Fuel pump wiring harness. 2. Wire holders. CAUTION PASS THE FUEL PUMP WIRING HARNESS ONTO THE LH SIDE OF THE TANK AND INSERT IT IN THE SPECIAL WIRE HOLDERS FITTED PREVIOUSLY.
Page 100
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE U 1. Quick shift connector. TABLE V Correct position of battery. Back side TABLE A - PRE-FITTING OF TAILLIGHT 1. Grey taping that indicates the LH rear turn indi- cator cable.
Page 101
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE B - REAR HEADLIGHT ASSEMBLY 1. LH rear turn indicator. 2. Faston: light blue and blue cables. 3. LH rear turn indicator wiring harness. 4. RH rear turn indicator. 5.
Page 102
RS 125 - Tuono 125 - Euro 4 Electrical system D TABLES - FASTENING OF TAIL FAIRING WIRING HARNESS TABLE D1 1. Main wiring harness connector. Check the position of the connector. TABLE D2 1. Rear speed sensor wiring harness. 2.
Page 103
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE D4 1. Rear speed sensor wiring harness. 2. Clamp. 3. Cable fasteners. • The ABS sensor cable must be blocked by the bleeder cap TABLE D5 1. Rear speed sensor connector. ELE SYS - 103...
Page 104
RS 125 - Tuono 125 - Euro 4 Electrical system TABLE D6 1. Taillight wiring harness. 2. USB socket connector. 3. Taillight wiring harness. 4. Cable guide. ELE SYS - 104...
RS 125 - Tuono 125 - Euro 4 Electrical system General wiring diagram 1. Multiple connectors 2. MIU G3 control unit 3. Left hand front turn indicator (10W) 4. Front daytime running lights (5W) ELE SYS - 105...
Page 106
RS 125 - Tuono 125 - Euro 4 Electrical system 5. Low beam headlight lamp (35W) 6. High beam light bulb (55W) 7. Complete headlamp 8. Right hand front turn indicator (10W) 9. Fan 10.Side stand switch 11.Accessories fuse 12.Instrument cluster 13.Clutch switch 14.Flasher unit 15.Left light switch...
RS 125 - Tuono 125 - Euro 4 Electrical system 43.Engine water temperature sensor 44.ECU diagnostics 45.BLUEDASH pre-installation 46.Fall sensor 47.Electronic gearbox (optional) 48.Reserve fuel sensor 49.ABS control unit 50.Front ABS sensor 51.Rear speed sensor 52.USB port 53.- 54.- 55.- 56.- 57.- 58.-...
Page 108
RS 125 - Tuono 125 - Euro 4 Electrical system CAUTION BEFORE STARTING ANY TROUBLESHOOTING PROCEDURES ON THE VEHICLE, CHECK THAT THE BATTERY VOLTAGE IS ABOVE 12V. PROCEDURE FOR CHECKING CONNECTOR This procedure consists of the following checks and inspections: 1.
Page 109
RS 125 - Tuono 125 - Euro 4 Electrical system Tester: set the tester selector to the "DC voltage" symbol and place the red tester probe on the cable under inspection and the black tester probe on the vehicle ground point (or on the battery negative pole).
Page 110
RS 125 - Tuono 125 - Euro 4 Electrical system Engine alarm warning MI • The amber engine alarm warning lamp MI (4) lights continuously in the event of a fault identified by the engine con- trol unit. Check for errors with the di- agnostic tool.
Page 111
RS 125 - Tuono 125 - Euro 4 Electrical system • Segments lit when the ignition switch is turned to Key-on. Use the controls to scroll through the display func- tions in the following order: • • TRIP I • TRIP II •...
RS 125 - Tuono 125 - Euro 4 Electrical system RECHARGING SYSTEM • Disconnect the six-way connector (1) (black colour) located behind the left side cover. NOTE THE ENGINE SIDE IS IDENTIFIED WITH THE LETTER "A" Measurement of resistance (with engine off) •...
RS 125 - Tuono 125 - Euro 4 Electrical system • Resistance of the wires read on the display = 0.47 Ohm • Effective resistance stage 1 = 0.67-0.47 = 0.20 Ohm • If there is a significant difference between one stage and another (other than 0.20 Ohm), this means that the alternator is defective and must be replaced.
Page 115
RS 125 - Tuono 125 - Euro 4 Electrical system stage "2" (outgoing cables from pins 2 and 6), stage "3" (outgoing cables from pins 4 and • Start the engine and carry out the measurement. • If there is a significant difference between one stage and another (other than 15 V), this means that the alternator is defective and must be replaced.
Page 116
RS 125 - Tuono 125 - Euro 4 Electrical system OLD SHORT CIRCUIT CURRENT 2000 4000 6000 8000 RMS DC current (Arms) (average of the 3 stage 12 - 18 12 - 18 12 - 18 12 - 18 currents) Voltage on battery poles with engine speed always between 3000 - 5000 RPM •...
Page 117
RS 125 - Tuono 125 - Euro 4 Electrical system Start-up system check Key: 1. Multiple connectors 2. MIU G3 control unit 3. Side stand 4. Clutch switch 5. Right light switch 6. Ignition switch 7. Starter motor relay 8. Starter motor 9.
RS 125 - Tuono 125 - Euro 4 Electrical system CHECKING THE STARTER MOTOR • To carry out the check, power up the motor with a 12 V 9 AH battery. • Win an AC ammeter clamp measure the steady running absorbed current (after 5 seconds).
RS 125 - Tuono 125 - Euro 4 Electrical system Starter button: on right hand switch set Connector: ... Electrical specifications • Button released: open circuit • Button pressed: closed circuit Diagnostic tool - Parameters and statuses • Starting request - (Absent, Present, Closed Loop, Closed) Diagnostics tool - Logic errors Starter button P0512 - signal not valid...
Page 120
RS 125 - Tuono 125 - Euro 4 Electrical system Warning light on: Magnitude range: MOhm CAUTION UPON REFITTING, MAKE SURE THE ELECTRIC CONNEC- TOR IS CORRECTLY COUPLED. Lights list (RS 125) Key: 1. Instrument panel 2. Flasher unit 3. Left light switch 4.
Page 121
RS 125 - Tuono 125 - Euro 4 Electrical system 15.Battery 16.Main fuses 17.Secondary fuses 18.MIU G3 control unit 19.Front left turn indicator 20.Light relay 21.Front daylight running light 22.Headlamp 23.Low beam light 24.High beam light 25.Front right turn indicator (TUONO 125) Key: 1.
Page 122
RS 125 - Tuono 125 - Euro 4 Electrical system 9. Rear right turn indicator 10.Licence plate light 11.Rear left turn indicator 12.Taillight 13.Starter motor relay 14.Starter motor 15.Battery 16.Main fuses 17.Secondary fuses 18.MIU G3 control unit 19.Front left turn indicator 20.Light relay 21.Front left headlight connector 22.Front right headlight connector...
Page 124
RS 125 - Tuono 125 - Euro 4 Electrical system The main fuses are situated at the front of the motorcycle, under the fuel tank and behind the headstock. The 3A fuse is situated under the rear of the fuel tank CAUTION THE 20A, 15A AND 7.5A FUSES INDICATED (H) ARE SPARES.
RS 125 - Tuono 125 - Euro 4 Electrical system DIAGNOSTIC TOOL:PARAMETERS Battery voltage • Example value with key ON: 12.0 V • Example value with engine on: 14.2 V This is one of the values set by the ECU in the event of recovery mode Battery voltage before prior to Recovery mode •...
Page 126
RS 125 - Tuono 125 - Euro 4 Electrical system Electrical circuit diagram - Level in electrical circuit diagram: ABS system Position on vehicle: On LH stanchion of fork, near the brake calliper mounting bracket CAUTION THE DISTANCE BETWEEN THE ABS SENSOR AND THE PHONIC WHEEL MUST BE BETWEEN 0.3 mm (0.012 in) AND 2 mm (0.079 in).
Page 127
RS 125 - Tuono 125 - Euro 4 Electrical system - If there is no insulation, restore the wiring harness or replace the sensor. Short-circuit to positive: - Disconnect the sensor connector. - Check the battery supply insulation of the two PINS. - If there is no insulation, restore the wiring harness or replace the sensor.
Page 128
RS 125 - Tuono 125 - Euro 4 Electrical system Position of connector (if applicable): Saddle post frame, RH side Pin-out: • PIN1 - Power feed negative/Signal negative (yellow) • PIN2 - Power feed positive/Signal pos- itive (yellow/brown) Diagnostic tool - Parameters and statuses •...
RS 125 - Tuono 125 - Euro 4 Electrical system Error cause Possible tone wheel fault due to deformations or dirt. Troubleshooting - Check that the tone wheel is not damaged and is clean. - Check that the number of teeth on the tone wheel is correct. - Check that the tone wheel and the sensor are correctly positioned;...
RS 125 - Tuono 125 - Euro 4 Electrical system • Check the electric circuit is in good conditions and the flywheel teeth cleaning and correct positioning of the sensor in its own housing; if it is not, replace it. If it is OK, replace the sensor Engine temperature sensor Function...
RS 125 - Tuono 125 - Euro 4 Electrical system Cause of error Open circuit or short circuit to positive: interruption of the circuit or excessive voltage at PIN 13 of the control unit connector. Short circuit to negative: null voltage between PIN 13 and 15 of the control unit connector. Troubleshooting Open circuit: •...
Page 132
RS 125 - Tuono 125 - Euro 4 Electrical system reach a high operating temperature: that is why there is a heating circuit inside. Level in electrical circuit diagram Lambda probe, Injection utilities relay Position • Sensor: exhaust duct • Connector: underneath battery, behind headstock, RH side Electrical specifications...
Page 133
RS 125 - Tuono 125 - Euro 4 Electrical system • If the wiring harness is intact and the error persists, proceed with the following checks. Short circuit to negative: • Disconnect the sensor connector and the control unit connector. •...
RS 125 - Tuono 125 - Euro 4 Electrical system Injector coil is excited for the petrol passage to open. Level in electrical circuit diagram Relay for injection utilities, Coils and injectors Electrical specifications • 14.8 Ώ +/- 5% (at 20 °C - 68°F) Pin-out: 1.
Page 135
RS 125 - Tuono 125 - Euro 4 Electrical system Fuel pump relay P0230 - shorted to positive / shorted to negative / open circuit. Error cause Shorted to positive: excessive voltage at PIN 22 of the control unit connector. Shorted to negative: null voltage at PIN 2 of the injection relay.
Page 136
RS 125 - Tuono 125 - Euro 4 Electrical system Primary: 550 +/- 50 mOhm Secondary: 3.3 +/- 0.3 kOhm Function Allows generation of the electrical discharge on the spark plug, with an increase of voltage. Pin-out: 1. Relay powered (PIN 3 relay side) 2.
RS 125 - Tuono 125 - Euro 4 Electrical system • Verify, with the key turned ON, the presence of voltage on the coil connector PIN 1. If no voltage is read, verify the continuity of the cabling between coil and injection relay (No. 35 on the electrical circuit diagram): Coil PIN 1 - relay PIN 3.
Page 138
RS 125 - Tuono 125 - Euro 4 Electrical system Position • Sensor: rear / upper side of the gearbox • Connector: on the sensor Electrical specifications • Gear in neutral: closed circuit (0 V on wire from control unit to sensor / switch in continuity). •...
Page 139
RS 125 - Tuono 125 - Euro 4 Electrical system Clutch lever sensor Function Indicates the clutch lever position to the control unit Operation / Operating principle In order to start the engine, pull the clutch also with the gear in neutral Level in electrical circuit diagram Start enable switches Position...
Page 140
RS 125 - Tuono 125 - Euro 4 Electrical system • If absent, restore the wiring harness. The vehicle starts even without pulling the clutch lever Error cause • Possible malfunction Troubleshooting • Disconnect the terminals from the sensor and check that, with the clutch released, there is continuity between the two PINs.
Page 141
RS 125 - Tuono 125 - Euro 4 Electrical system • verify continuity of the grey/yellow cable between the sensor and PIN 19 of the control unit. • If absent, restore the wiring harness, if present, with the stand up, check for continuity be- tween the two PINs on the sensor.
RS 125 - Tuono 125 - Euro 4 Electrical system Open circuit: circuit interruption. Troubleshooting Short-circuit to positive: • Disconnect the fan control relay (No. 42 in electrical circuit diagram), turn the ignition switch to ON and measure the voltage at PIN 1 of the relay connector leading to the wiring harness side: if the voltage is 12V, repair the wiring harness, if the voltage is zero, replace the relay.
Page 143
RS 125 - Tuono 125 - Euro 4 Electrical system • RUN position: closed circuit (continui- Pin-out 1. Voltage 0 V with engine kill in STOP; 12V if engine kill in RUN (pink/yellow cable) 2. Always voltage 12 V (with key on) (red/yellow cable) Diagnostic tool - Parameters and statuses •...
Page 144
RS 125 - Tuono 125 - Euro 4 Electrical system Function It manages injection/ignition, the system safety checks and the self-diagnosis function. The con- trol unit is Magneti Marelli MIU G3 Level in electrical circuit diagram Diagnostics, ABS system, pre-configuration for BlueDash Position •...
Page 146
RS 125 - Tuono 125 - Euro 4 Electrical system Diagnostic tool - Parameters and statuses This screen page shows the parameters meas- ured by the several sensors (engine revs, engine temperature, etc.) or values set by the control unit (injection time, ignition advance);...
Page 147
RS 125 - Tuono 125 - Euro 4 Electrical system • RUN/OFF Switch - (RUN-OFF) • Start enable - (NO, YES) • Checking of Probe1 value (...) • Lambda probe - (---, Not enabled, Not active (start), Not active (heat.), Not active (rich), Operating, Not active (lean), Fault •...
Page 148
RS 125 - Tuono 125 - Euro 4 Electrical system Diagnostic tool - Errors screen page This display shows potential errors detected in the vehicle (ATT) or stored in the control unit (MEM) and it allows to check error clearing (STO). Diagnostic tool - Electrical errors Air pressure sensor P0105 - short circuit to positive / open circuit, short circuit to negative, signal not valid...
Page 149
RS 125 - Tuono 125 - Euro 4 Electrical system • This indication appears only if the Level 2 safety has reset the engine (C gravity). The in- strument panel does not indicate the presence of this error even in the ATT status. Troubleshooting •...
Page 150
RS 125 - Tuono 125 - Euro 4 Electrical system • Once the throttle body or the injection control unit is replaced, it is necessary to connect to the diagnostic tool selecting FUEL INJECTION and carry out the operation "THROTTLE POSITIONER AUTODETECTION"...
Page 151
RS 125 - Tuono 125 - Euro 4 Electrical system • Riduzione del numero di cavi: la linea CAN viaggia su doppino tra i vari nodi. • I nodi sono capaci inoltre di isolare gli errori senza causare il breakdown del sistema (Faults- Confination).
RS 125 - Tuono 125 - Euro 4 Engine from vehicle Vehicle preparation • Rest the vehicle on its stand • Support the vehicle rear part using belts and hoist. • Drain off the cooling system. • Beforehand, remove the lug, the side fairings, the battery, the fuel tank, the side fairings, the drive chain, the air filter box, the radiator and the expansion tank.
Page 154
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Remove the rubber plug and loosen the screw. • Disconnect the starter motor cable. • Unscrew and remove the two fixing screws. • Remove the pinion cover. • Undo and remove the fixing screw.
Page 155
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Water temperature connector. • Disconnect the neutral sensor connec- • Remove the oil temperature sensor. • Remove the oil temperature sensor. ENG VE - 155...
Page 156
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Remove the battery compartment. • Remove the coil. • Remove the clamp. • Remove the breather pipe. • Remove the screw. • Remove the cable guide. ENG VE - 156...
Page 157
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Disconnect the injector connector. • Remove the main cable grommet. • Working on both sides, unscrew and remove the two fastener screws. • Remove the screw that fastens the ABS modulator support to the engine. •...
Page 158
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Operating from both sides, remove the pass through screws and collect the retaining nuts. • Operating from both sides, remove the upper fixing screws. • Working from the right side, slide off the pin.
Page 159
RS 125 - Tuono 125 - Euro 4 Engine from vehicle Installing the engine to the vehicle • Place the ring nut and tighten it to the prescribed torque. Specific tooling 866714 Swingarm adjustment • Insert the swingarm pin from the right side and slide it until it reaches the oth- er side.
Page 160
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • On the LH side, place the washer on the swingarm pin and start the nut. • Check that the washer and nut are on the swingarm pin. • Working on both sides, tighten the nuts to the prescribed torque.
Page 161
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Place the cable guide. • Tighten the screw to the prescribed tor- que. • Place the breather pipe and secure it with the clamp. • Connect the ground and fix it with the screw.
Page 162
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Connect the horn. • Connect the oil temperature sensor. • Connect the neutral sensor. CAUTION TAKE CARE NOT TO LOSE THE INSULATING RUBBER HOOD OR THE PLASTIC WASHER FITTED BETWEEN THE CONNECTOR AND THE NEUTRAL SENSOR BULB.
Page 163
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Position and reconnect the chain. • Put in place the gear lever and tighten the screw to the specified torque. • Put in place the pinion cover and tight- en the two screws to the specified tor- que.
Page 164
RS 125 - Tuono 125 - Euro 4 Engine from vehicle • Connect the starter motor ground wire and tighten the screw to the specified torque. • Reattach the clutch cable, making sure to insert it in the cable grommet. •...
Page 167
RS 125 - Tuono 125 - Euro 4 Engine OMPONENTS OF GEARBOX pos. Description Type Quantity Torque Notes Gear sensor retainer 3 Nm (2.21 lb ft) Diagram Filtro olio • Place a recipient with a capacity of at least 900 cm³ (54.91 cu.in) under the drain plug (1) on the clutch side.
RS 125 - Tuono 125 - Euro 4 Engine • Remove the oil filter (4) and clean thor- oughly before refitting. NOTE CHECK AND, IF NECESSARY, REPLACE THE FILTER SEAL WASHER Gearbox shafts Disassembling the gearbox • Remove the desmodromic drum •...
Page 169
RS 125 - Tuono 125 - Euro 4 Engine Removing the primary shaft CAUTION THE PRIMARY SHAFT CANNOT BE DISASSEMBLED. IF NECESSARY, REPLACE THE ENTIRE PRIMARY SHAFT. Removing the secondary shaft CAUTION FIT NEW CIRCLIPS WHEN REASSEMBLING Disassemble the secondary shaft as follows: •...
Page 170
RS 125 - Tuono 125 - Euro 4 Engine • Remove the spacer washer (4) • Remove the fifth speed gear (5). • Remove the circlip (6). • Remove the spacer washer (7) ENG - 170...
Page 171
RS 125 - Tuono 125 - Euro 4 Engine • Remove the third speed gear (8). • Remove the fourth speed gear (9). • Remove the sixth speed gear (10). • Remove the spacer washer (11) ENG - 171...
Page 172
RS 125 - Tuono 125 - Euro 4 Engine • Remove the spacer washer (12) • Remove the second speed gear (13). • Remove the bush (14). • Remove the shim washer (15) ENG - 172...
Page 173
RS 125 - Tuono 125 - Euro 4 Engine Desmodromic demounting • Remove the fork carrier shaft (1) • Remove the desmodromic shaft (2) • Remove the forks (3) Checking the desmodromic drum Check the desmodromic shaft and drum for any signs of damage, scratches or wear, and replace if necessary.
RS 125 - Tuono 125 - Euro 4 Engine • Check that the fork moves uniformly and without impediment; check for damage, dents and signs of wear on the roller (1) and on the teeth (2) of the fork. • Replace the fork if necessary.
RS 125 - Tuono 125 - Euro 4 Engine Removing the starter motor • Undo and remove the two fixing screws (1). • Remove the starter motor (2). NOTE THE STARTER MOTOR CAN ALSO BE REMOVED IF THE ENGINE IS FITTED TO THE VEHICLE. Generator side LYWHEEL COVER pos.
Page 177
RS 125 - Tuono 125 - Euro 4 Engine Rimozione rotore • Remove the starter motor gear. • Fit the specific tool. • Undo and remove the hex socket screw. Specific tooling 865259 Flywheel retainer • Retrieve the washer. • Fit the tool and pull out the rotor.
RS 125 - Tuono 125 - Euro 4 Engine • Remove the rotor. • Remove the key. Removing the stator • Remove the two screws fastening the plate securing the stator cable • Remove the two screws fastening the stator ENG - 178...
Page 179
RS 125 - Tuono 125 - Euro 4 Engine • Remove the stator. Freewheel removal • Undo and remove the indicated retain- er screw with the relative plate. • Remove the freewheel. ENG - 179...
RS 125 - Tuono 125 - Euro 4 Engine Disassembling the clutch • Unscrew and remove the six screws by loosening them 1/4 of a turn at a time; operate in stages and diagonally, and retrieve the washers and the clutch springs.
RS 125 - Tuono 125 - Euro 4 Engine • Remove the shim and the clutch hous- ing. • Remove the shim. Checking the clutch plates Characteristic Driving plates thickness 2.85 - 2.95 mm (0.112 - 0.116 in) Number of driving plates Driven plates thickness 1.46 - 1.53 mm (0.057 - 0.06 in) Number of driven plates...
RS 125 - Tuono 125 - Euro 4 Engine Checking the clutch housing Check the primary driven gear for damage and wear and, if necessary, replace the primary driven gear and the clutch bell all together. Make sure there is not excessive noise during op- eration;...
RS 125 - Tuono 125 - Euro 4 Engine Checking the springs • Check the springs for damage and, if necessary, replace the them all togeth- • Measure the clutch spring length when unloaded; if necessary, replace the springs all together. Characteristic Minimum wear limit in the release position of the individual clutch springs...
Page 186
RS 125 - Tuono 125 - Euro 4 Engine • Insert the clutch hub. • Screw in the retainer nut locking the rotation of the clutch housing with the specific tool. Specific tooling 00H05300041 Clutch lock • Lift one side of the lock tab. •...
Page 188
RS 125 - Tuono 125 - Euro 4 Engine RANKSHAFT Pos. Description Type Quantity Torque Notes Gear fixing screw 40 Nm (29.50 lb ft) Balancing countershaft removal • Before taking out the balancing coun- tershaft the clutch cover and flywheel cover must be removed.
Page 189
RS 125 - Tuono 125 - Euro 4 Engine Balancing countershaft fitting • Insert the countershaft from the alter- nator side. • Insert the gear aligning its reference to the primary gear. • Using the specific tool, tighten the nut remember first to place the washer.
Page 190
RS 125 - Tuono 125 - Euro 4 Engine • Remove the primary gear unscrewing and removing the nut. • Collect the washer. • Remove the countershaft gear. • Remove the primary remaining gears. • Remove the head and cylinder. •...
Page 191
RS 125 - Tuono 125 - Euro 4 Engine • Remove the base gear of the main shaft. • Remove the cotter. • Remove the oil pump unscrewing the three fixing screws. • Collect the gasket. • Remove the gear spider screw, un- screwing and removing the fixing screw.
RS 125 - Tuono 125 - Euro 4 Engine • Moving from the left side of the engine, remove the flywheel and all of its com- ponents beforehand. • Unscrew and remove the six screws on the outside of the crankcase (1). •...
RS 125 - Tuono 125 - Euro 4 Engine List of extractors to be used with sleeve 020376Y: RIGHT CRANKCASE • Insertion of main shaft bearing: 020439Y+020359Y Removal of the main shaft bearing: 020358Y • Insertion of desmo bearing: 020439Y+020357Y Removal of desmo bearing: 020891Y •...
Page 194
RS 125 - Tuono 125 - Euro 4 Engine Bushing selection USHING SEAT DIAMETER ON CRANKCASE Specification Desc./Quantity Class 1 MIN 36.500 mm (1.4370 in) MAX 36.508 mm (1.4373 in) Class 2 MIN 36.508 mm (1.4373 in) MAX 36.516 mm (1.4376 in) RANKSHAFT DIAMETER Specification Desc./Quantity...
Page 195
RS 125 - Tuono 125 - Euro 4 Engine • Insertion of secondary shaft roller bearing cage: 020363Y Removal of the secondary shaft roller bearing cage: use universal extractor • Insertion of countershaft roller bearing cage: 020483Y Removal of countershaft roller bear- ing cage: 020364Y NOTE: insertion of the roller bearing cages in line with the crankcase is recommended from the inside to the outside.
Page 196
RS 125 - Tuono 125 - Euro 4 Engine • Fit the selector star. • Fit and tighten the screw. • Fit a new oil pump gasket. • Fit the oil pump, screwing the three screws. • Insert the countershaft gear and posi- tion the washer.
Page 197
RS 125 - Tuono 125 - Euro 4 Engine • Insert the pump drive gear. • Insert the washer and apply the fixing seeger. • Insert the timing chain gear, paying at- tention to the direction. The engraving must face upward. •...
Page 198
RS 125 - Tuono 125 - Euro 4 Engine • Fit the rest of the primary gears. • Tighten the fixing nut. • Remove the countershaft locking tool. • Fit the gear selector. Head and timing EAD COVER pos. Description Type Quantity Torque...
RS 125 - Tuono 125 - Euro 4 Engine IMING SYSTEM pos. Description Type Quantity Torque Notes Chain tensioner pad fastener screw M6x16 10 Nm (7.38 lb ft) Loctite 243 Timing system gear fastener screw M8x40 27 Nm (19.91 lb ft) Loctite 243 Removing the head cover •...
Page 201
RS 125 - Tuono 125 - Euro 4 Engine • Remove the spark plug. Removing the timing control • Turn the crankshaft from the hole on the cover (1) • Take the piston to TDC. • The sign (2) must be aligned with the sign (3).
RS 125 - Tuono 125 - Euro 4 Engine • Remove the spring. • Unscrew and remove the two screws (6) and remove the entire tensioner control. • Lock the timing gear using the specific tool. Specific tooling 865260 Camshaft sprocket lock tool •...
Page 203
RS 125 - Tuono 125 - Euro 4 Engine Removing the overhead camshaft • Remove the two pins from the cam tower. • Remove the eight screws (1). • Remove the cam tower (2). • Remove the two camshafts (intake side and exhaust side).
RS 125 - Tuono 125 - Euro 4 Engine • Remove the head (4). Removing the valves • Remove the head. • Place the head on supporting surface. • Number the valves and their bucket tappets in order to position them cor- rectly upon refitting.
Page 205
RS 125 - Tuono 125 - Euro 4 Engine • Remove both cotter pins. • Release the valve springs. • Remove the cap and the valve spring. Checking the overhead camshaft • Check the camshaft bearings for signs of abnormal wear. Characteristic Standard diameter - Bearing A 19.980 - 19.959 mm (0.7866 - 0.7858 in)
RS 125 - Tuono 125 - Euro 4 Engine Valve check • Measure the width of the sealing surface on the valve seats and on the valves themselves. • If the sealing surface on the valve is wider than the specified limit, damaged in one or more points or curved, replace the valve with a new one.
Page 207
RS 125 - Tuono 125 - Euro 4 Engine • Remove the chain tensioner. • Undo and remove the eight screws and remove the cam tower. • Remove the timing chain and the gears of the camshaft of the valves in ques- tion.
Page 208
RS 125 - Tuono 125 - Euro 4 Engine • Fit the camshaft, the gears and the chain in their correct positions, using the references located on the flywheel side of the crankcase. • Fit the cam tower and tighten the eight screws to the prescribed torque. •...
RS 125 - Tuono 125 - Euro 4 Engine Inspecting the valve housings • Remove any carbon deposits from the valve guides. • Measure the inside diameter of each valve guide. • Measure according to the thrust direction at three different heights. Characteristic Intake guide - standard diameter 4.012 mm (0.1579 in)
RS 125 - Tuono 125 - Euro 4 Engine • Check that the camshaft bushings are not worn. • Check that the head cover surface, the intake manifold and the exhaust manifold are not worn. Installing the valves • Lubricate the valve guides with engine oil. •...
RS 125 - Tuono 125 - Euro 4 Engine Checking the chain • Check that the guide slider and the ten- sioner pad are not excessively worn. • Check that the chain assembly, the camshaft driving pulleys and the sprocket wheel are not worn. •...
RS 125 - Tuono 125 - Euro 4 Engine • Remove the water hose clamp (3). • Remove the cylinder (4). • Remove the gasket (5). Disassembling the piston • Apply the tool under the piston (1). • Cover the base of the cylinder with a cloth.
RS 125 - Tuono 125 - Euro 4 Engine • Remove the pin (3). • Remove the piston (4). Checking the piston • Measure the pin seat diameter on the piston. • Calculate the pin - piston coupling clearance. • Measure the piston outside diameter, perpendicular to the pin axis.
Page 214
RS 125 - Tuono 125 - Euro 4 Engine Characteristic Piston / cylinder Piston pin hole - standard: 15.003 - 15.008 mm (0.5907 - 0.5908 in) Maximum piston / cylinder coupling clearance after use - top ring: 0.075 mm (0.0029 in) - middle ring: 0.065 mm (0.0025 in) - oil scraper: 0.25 mm (0.0098 in) Standard piston / cylinder coupling clearance...
RS 125 - Tuono 125 - Euro 4 Engine Inspecting the wrist pin • Check the pin outside diameter. Characteristic Minimum diameter: 14.995 mm (0.590 in) Standard diameter: 15.0000 +0/-0.0030 mm (0.00012 in) Inspecting the piston rings ANELLI DI TENUTA Specification Desc./Quantity Compression ring (top)
RS 125 - Tuono 125 - Euro 4 Engine Fitting the piston • Install the piston and the piston pin on the connecting rod, orienting the piston with the arrow facing towards the ex- haust side. • Fit the retainer circlip. •...
RS 125 - Tuono 125 - Euro 4 Engine Installing the cylinder • Fit a new cylinder base gasket of the chosen thickness. • Refit the cylinder as indicated in the figure using the specific clamp tighten- er tool. NOTE BEFORE FITTING THE CYLINDER, CAREFULLY BLOW OUT THE LUBRICATION DUCT AND OIL THE CYLINDER BARREL.
Page 218
RS 125 - Tuono 125 - Euro 4 Engine • Screw but do not tighten both central long screws (3) and position the wash- ers. • Screw but do not tighten both central long screws (2) and position the wash- ers.
Page 219
RS 125 - Tuono 125 - Euro 4 Engine • Position the cam tower cap. • Screw but do not and tighten the eight screws. • Place the pins in their positions on the overhead camshafts. Specific tooling 864567 Camshaft timing adjustment lock pins •...
Page 220
RS 125 - Tuono 125 - Euro 4 Engine • Check the valve clearance and adjust it if required. • Refit the tappet cover. Lubrication pos. Description Type Quantity Torque Notes Oil pump fastener screw M5x35 4 Nm (2.95 lb ft) Loctite 243 Oil cap retainer 25 Nm (18.44 lb ft)
Page 221
RS 125 - Tuono 125 - Euro 4 Engine • Remove the pump gear. • Remove the pump gear. • Separate the components to inspect them. Inspection • Measure distance between rotors with a feeler gauge at the positions shown in the picture.
Page 222
RS 125 - Tuono 125 - Euro 4 Engine Radial clearance (2) between points of the rotor: 0.08 mm (0.003 in) Radial clearance (3) between rotor 1 and the pump body: 0.04 mm (0.0015 in) Radial clearance (3) between rotor 2 and the pump body: 0.05 mm (0.0019 in) Installing •...
RS 125 - Tuono 125 - Euro 4 Power supply Circuit diagram Key: 1. Fuel tank 2. Fuel pump 3. Fuel pump ring nut 4. Fuel pump gasket 5. Fuel pipe 6. Fuel level probe Fuel pump P SUPP - 224...
Page 225
RS 125 - Tuono 125 - Euro 4 Power supply Removing Remove and empty the fuel tank. • Remove the fuel hose (4). • Loosen the ring nut (3) and slide off the gasket (2). • Remove the pump (1). See also Fuel tank Injection...
Page 226
RS 125 - Tuono 125 - Euro 4 Power supply Diagram P SUPP - 226...
Page 227
RS 125 - Tuono 125 - Euro 4 Power supply 1. ECU control unit position 2. Ignition switch 3. Fuel pump 4. Instrument panel 5. Air temperature sensor 6. Throttle valve position sensor 7. Injector 8. Coolant temperature sensor 9. Lambda probe position 10.Engine speed sensor 11.Electric fan P SUPP - 227...
RS 125 - Tuono 125 - Euro 4 Power supply Removing the throttle body • Remove the filter box. • Loosen and remove the nut and un- hook the throttle cable. • Disconnect the connector. • Undo and remove the screw and re- move the cable guide.
RS 125 - Tuono 125 - Euro 4 Suspensions • Pull the axle out completely and re- move the collar. • Remove the wheel. Checking the front wheel FRONT WHEEL BEARINGS Check the bearings installed on the wheel. CHECK THE CONDITION OF ALL COMPONENTS AND OF THE COMPONENTS INDICATED AS FOLLOWS IN PARTICULAR.
RS 125 - Tuono 125 - Euro 4 Suspensions ALWAYS REPLACE THE BEARINGS WITH COMPONENTS OF THE SAME TYPE. SEALS • Check the condition of the seals; replace if damaged or excessively worn. ALWAYS REPLACE BOTH SEALS TOGETHER. ALWAYS REPLACE THE SEALS WITH COMPONENTS OF THE SAME TYPE. WHEEL AXLE •...
RS 125 - Tuono 125 - Euro 4 Suspensions Front fork Removing the fork legs The following instructions describe the procedure for removing one fork but are applicable for both forks. • Support the front of the vehicle, fasten- ing a suitable strap to the handlebar and to a hoist.
Page 237
RS 125 - Tuono 125 - Euro 4 Suspensions • Fit the fork in the vice using the special Teflon grips. • Unscrew and remove the cap • Remove the internal piston and, lower- ing the lock washer, remove the two half cylinders SUSP - 237...
Page 238
RS 125 - Tuono 125 - Euro 4 Suspensions • Remove the lock washer CAUTION BEFORE PROCEEDING WITH THE FOLLOWING OPERATIONS GET A SUITABLE COLLECTION CONTAINER. • Remove the stem from the vice and drain off the oil inside it into the collec- tion container.
RS 125 - Tuono 125 - Euro 4 Suspensions • Remove the oil seal from the sleeve, taking care not to damage it Checking the components SPARE WHEEL HOLDER STEM • Check that the sliding surface is not scratched or scored. Any scoring can be removed by sanding with damp sandpaper (grain 1).
Page 240
RS 125 - Tuono 125 - Euro 4 Suspensions • Check for damage and/or cracks; if it is damaged, replace it. • Check the condition of the sliding bush- ings (1). • If there is evidence of excessive wear or damage, replace the component concerned.
Page 241
RS 125 - Tuono 125 - Euro 4 Suspensions • Insert the retainer ring • Insert the retainer ring • Position the two half cylinders and lock them in place with the retainer ring • Position the fork vertically in a vice •...
RS 125 - Tuono 125 - Euro 4 Suspensions Installing the fork legs • Fit the fork tube complete with stan- chion into the bottom and top steering yokes. • Insert the wheel axle into both stan- chions to align the holes. •...
RS 125 - Tuono 125 - Euro 4 Suspensions • Lower the hoist arm. CAUTION BEFORE RELEASING THE BELTS MAKE SURE THAT THE OPTIONAL REAR STAND IS COR- RECTLY POSITIONED. • Correctly install the lower shield, the mudguard, the front wheel and the brake callipers. •...
Page 244
RS 125 - Tuono 125 - Euro 4 Suspensions DURING REMOVAL, TAKE CARE NOT TO DAMAGE THE PIPE, THE DISC AND THE BRAKE PADS. CAUTION THE SPECIFIC REAR SUPPORT STAND IS NEEDED TO REMOVE THE REAR WHEEL. • Place the vehicle on the specific rear stand.
RS 125 - Tuono 125 - Euro 4 Suspensions Checking the rear wheel CHECK THE CONDITION OF ALL COMPONENTS AND OF THE COMPONENTS INDICATED AS FOLLOWS IN PARTICULAR. REAR WHEEL BEARINGS Check the bearings installed on the wheel. CHECKING ROTATION •...
RS 125 - Tuono 125 - Euro 4 Suspensions the indicated limits after replacing the bearings, replace the wheel (2). Characteristic Maximum radial (A) eccentricity: 0.6 mm (0.0236 in) Maximum lateral (B) eccentricity: 0.5 mm (0.0197 in) CROWN GEAR • Check the condition of the teeth of the crown gear (3).
Page 248
RS 125 - Tuono 125 - Euro 4 Suspensions Removing • Remove both central side fairings. • Place the vehicle on its optional front service stand. • Support the vehicle rear part using belts and hoist. • Place a support under the swingarm, so that it stays in neutral position.
Page 252
RS 125 - Tuono 125 - Euro 4 Chassis • Working on both sides, loosen the nuts fastening the swingarm pivot bolt. • On the LH side, undo and remove the nut and retrieve the washer. • On the RH side of the vehicle, undo and remove the nut and retrieve the washer.
RS 125 - Tuono 125 - Euro 4 Chassis • Rotate the pinion lock plate to remove it the from the shaft. • Remove the pinion Inspection • Check the state of the teeth of the front and rear sprockets. If excessively worn, replace: the rear sprocket, front sprocket and drive chain.
Page 255
RS 125 - Tuono 125 - Euro 4 Chassis Removing • Support the vehicle with the optional rear stand. • Loosen the chain tension, by unscrew- ing the rear adjuster screws. • Identify the master link; slide off the clip. •...
Page 256
RS 125 - Tuono 125 - Euro 4 Chassis • Check that the measurement notches between the mobile part and the fixed part of the instrument match (1/2 step) New chain: • the notch of the mobile measuring in- strument coincides with the first notch on the right of the fixed part of the in- strument Chain to be replaced:...
RS 125 - Tuono 125 - Euro 4 Chassis • Insert the new fork from the rear • Insert the connecting plate at the point of the dowels • Place the tool on the chain, inserting the centring dowel between the chain rollers •...
Page 258
RS 125 - Tuono 125 - Euro 4 Chassis The spring has been inserted in its housing cor- rectly when it measures a maximum of 9.4 mm (0.37 in). Adjusting To check chain deflection: • Shut off the engine. • Rest the vehicle on the side stand.
RS 125 - Tuono 125 - Euro 4 Chassis If, after checking the deflection, it is necessary to adjust the chain tension, follow the instructions given below. • Place the vehicle on the specific rear support stand. • On both sides of the vehicle, loosen the nut (1) completely.
Page 261
RS 125 - Tuono 125 - Euro 4 Chassis • If necessary, replace the spring. Installing • Fit the spring (1) on the chain tensioner bracket (2), positioning correctly. • Fit the bush (3) with the machined end on the outer side as shown in the fig- ure.
RS 125 - Tuono 125 - Euro 4 Chassis • Remove the footpeg mount (4). REMOVING THE RIGHT HAND SIDE RIDER FOOTPEG: FOOTPEG GUARD: • After disconnecting the rear brake master pump, remove the two fastener screws (5) of the footpeg guard, taking care not to lose the washers.
Page 265
RS 125 - Tuono 125 - Euro 4 Chassis • Remove the screw (8) fastening the brake lever, holding the nut to prevent it from turning. • Remove the bush (9), the spring wash- ers (10) and the spacer washer (11). FOOTPEGS: NOTE THE PROCEDURE DESCRIBED AS FOLLOWS IS THE SAME FOR BOTH FOOTPEGS...
Page 266
RS 125 - Tuono 125 - Euro 4 Chassis • Remove the footpeg (14) and the re- turn spring (15). LEFT HAND SIDE RIDER FOOTPEG: • Working on the left hand side of the motorcycle, remove the circlip (1) re- taining the gear lever control rod.
RS 125 - Tuono 125 - Euro 4 Chassis REMOVING THE LEFT HAND SIDE RIDER FOOTPEG: FOOTPEG GUARD: • Remove the two screws (4) fastening the footpeg guard, taking care not to lose the washers. • Remove the footpeg guard (5). GEAR LEVER: •...
RS 125 - Tuono 125 - Euro 4 Chassis Stand TAND pos. Description Type Quantity Torque Notes Low nut M10x1.25 10 Nm (7.38 lb ft) Loctite 243 Stand mounting fixing screw M8x30 25 Nm (18.44 lb ft) Loctite 243 Chain roller fixing screw M8x45 25 Nm (18.44 lb ft) Side stand switch fastening screws...
Page 269
RS 125 - Tuono 125 - Euro 4 Chassis • Slide off the nut and remove the cable grommet. • Slide off the stand together with the plate. Exhaust XHAUST Pos. Description Type Quantity Torque Notes Exhaust fixing clamp 15 Nm (11.06 lb ft) Silencer fixing screw M8x50 25 Nm (18.44 lb ft)
Page 270
RS 125 - Tuono 125 - Euro 4 Chassis Removing the tail pipe • Undo and remove the two upper stay- screws and collect the relative nuts and washers. • Beforehand, remove the side fairings and the fairing lug. • Loosen the clamp.
RS 125 - Tuono 125 - Euro 4 Chassis Removing the exhaust manifold • Unscrew and remove the two screws. • Remove the manifold. • Remove the muffler. • Lift the saddle and disconnect the lambda probe connector. See also Removing the tail pipe CHAS - 271...
RS 125 - Tuono 125 - Euro 4 Braking system ABS functional diagram key 1. Front system circuit. 2. Front brake master cylinder. 3. Front brake control lever. 4. ABS control unit. 5. Front brake calliper. 6. Front brake circuit inlet solenoid valve (normally open). 7.
Page 280
RS 125 - Tuono 125 - Euro 4 Braking system C - Maintaining pressure: the pressure in the calliper (5) remains low until total recovery of the correct wheel speed state / wheel grip. The system returns the fluid taken from the calliper (5) to the section of circuit between the brake master cylinder (2) and the ABS inlet valve (6 ).
Page 281
RS 125 - Tuono 125 - Euro 4 Braking system When sensors (3) detect a significant speed difference between the rear and the front wheels (for example, when rearing up on the back wheel), the ABS system could take this as a dangerous situation. In this case, 2 things may occur: - the ABS system intervenes by releasing pressure from the calliper until the wheel turns again at the same speed of the other wheel;...
Page 282
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the screw (3) that fastens the modulator support to the engine. • Remove the two screws (4) that fasten the modulator support to the chassis. • Remove the protective casing (5) of the control unit connector (6) and discon- nect •...
Page 283
RS 125 - Tuono 125 - Euro 4 Braking system • Operating from the LH side of the mo- torcycle, remove the ABS modulator with support • Release the relays (9) on the sides from the battery support and remove the support fastener screw (10).
Page 284
RS 125 - Tuono 125 - Euro 4 Braking system • Move the support aside. • Disconnect the fuse supports from the two brackets on the headstock. • After releasing the front ABS sensor wiring harness from the brake pipe, re- move the two brake calliper fastener screws (18).
Page 285
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the two brake pump fastener screws (19). • Disconnect the front brake sensor (20) of the brake pump. • Remove the clamp (21) and the cable fastener (22) to release the brake pump. •...
Page 286
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the complete ABS system. REMOVAL OF MODULATOR / ABS CONTROL UNIT • Remove the modulator as described above. • Mark the pipes so that they can be cor- rectly re-installed on the new modula- tor.
Page 287
RS 125 - Tuono 125 - Euro 4 Braking system MORE OIL IS REQUIRED TO BLEED THE ABS SYSTEM THAN A CONVENTIONAL SYSTEM. FOR THIS REASON, CAREFULLY CHECK THE OIL LEVEL IN THE BRAKE TANK. • If even after bleeding, the front brake lever feels "spongy", the secondary circuit in the ABS control unit must be bled.
RS 125 - Tuono 125 - Euro 4 Braking system The ABS system is disabled! The system operates perfectly just as any other braking system without ABS. The detection of malfunctions may require more or less time according to the type of failure. Error detection logic foresees that for the errors to be diagnosed one or more conditions must persist within a given time.
Page 289
RS 125 - Tuono 125 - Euro 4 Braking system ECU INFO screen page Diagnostic tool - Control unit info screen page In this screen page are read the general data re- garding the control unit, for example: type of soft- ware, control unit programming data, etc.
Page 290
RS 125 - Tuono 125 - Euro 4 Braking system When turning the wheel or acting on the brake, a variation of parameters must be detected. ACTIVATION screen page On this screen page, you can delete the errors from the memory of the controller and you can en- able some systems controlled by the control unit.
RS 125 - Tuono 125 - Euro 4 Braking system P.A.D.S. characteristic. Value/example Units of Notes measure ment Rear wheel speed sensor electrical C1031 Short circuit or open circuit to negative or short diagnosis circuit to positive Rear wheel speed sensor functional C1032 Signal not plausible diagnosis...
Page 292
RS 125 - Tuono 125 - Euro 4 Braking system • Go to the page Error codes. • Select an error and show the Ambient parameter error(where provided). • Repeat the operation by selecting each error and showing the corresponding Ambient pa- rameter error (where provided).
RS 125 - Tuono 125 - Euro 4 Braking system SETTINGS screen page This screen is used to adjust some control unit pa- rameters. ADJUSTMENTS Diagnostic tool characteristics Value/example Units of Notes measure ment Disabling of VR-shut down Enabling of VR-shut down EVAC and wires ABS bleeding phase 1 ABS bleeding phase 2...
RS 125 - Tuono 125 - Euro 4 Braking system C1089 Configuration error Cause of error The configuration stored in the ABS control unit does not correspond to the configuration in the vehicle it is installed on. Troubleshooting Check the control unit mapping and reset the vehicle configuration. CAN LINE ERRORS U2921 Controller error U2922 Line failure (busoff)
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the rear brake calliper. • Unscrew the coupling from the rear brake calliper after placing a container for collecting the brake fluid. CAUTION WHEN FITTING THE REAR BRAKE CALLIPER TIE THE ABS SENSOR CABLE TO THE BLEED PROTECTION CAP.
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the tone wheel. • Remove the brake disc. Disc Inspection This procedure must be performed with the brake disc installed on the wheel. • Check the disc for wear by measuring the minimum thickness with a micro- meter in different points.
RS 125 - Tuono 125 - Euro 4 Braking system Installing • Fit the brake disc and tone wheel in the respective seat. • Fit the six fastener screws and tighten to specified torque. NOTE FIRST HAND-TIGHTEN TIGHTEN ALL THE SCREWS, THEN TIGHTEN TO THE DEFINITIVE TORQUE IN A CROSSED PATTERN IN THE SEQUENCE A-D-B-E-C-F CAUTION...
Page 298
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the brake disc. Disc Inspection This procedure must be performed with the brake disc installed on the wheel. • Check the disc for wear by measuring the minimum thickness with a micro- meter in different points.
RS 125 - Tuono 125 - Euro 4 Braking system ALL TRACES OF THE OLD THREAD-LOCK SEALANT HAVE BEEN ELIMINATED. Front brake pads Removal • Working on the front brake calliper, on the left side of the vehicle, unscrew and remove the two screws fixing the brake calliper.
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the brake pads. • Check the brake pads. • Measure the thickness of the brake pads. If either one is under the service limit, replace them. Service limit 1.5 mm (0.05 in). WARNING IF THE BRAKE LEVER IS OPERATED WITH THE CLAMP EXTRACTED IT MIGHT BE NECESSARY TO CARRY OUT THE CORRESPONDING BLEEDING.
Page 301
RS 125 - Tuono 125 - Euro 4 Braking system • Measure the thickness of the brake pads. If either one is under the service limit, replace them. Service limit 1.5 mm (0.05 in). WARNING IF THE BRAKE LEVER IS OPERATED WITH THE CLAMP EXTRACTED IT MIGHT BE NECESSARY TO CARRY OUT THE CORRESPONDING BLEEDING.
Page 302
RS 125 - Tuono 125 - Euro 4 Braking system NOTE THE FOLLOWING OPERATIONS REFER TO ONE FRONT BRAKE CALLIPER ONLY, BUT ARE VALID FOR BOTH. THE VEHICLE MUST BE ON LEVEL GROUND TO BE PURGED. WHILE PURG- ING THE HYDRAULIC SYSTEM, FILL THE RESERVOIR WITH THE NECESSARY QUANTITY OF BRAKE FLUID.
RS 125 - Tuono 125 - Euro 4 Braking system CONSIDERING THE DANGER FOR VEHICLE AND RIDER, IT IS STRICTLY NECESSARY, AFTER REFITTING BRAKES AND RESTORING THE BRAKING SYSTEM TO THE REGULAR USE CON- DITIONS, THAT THE HYDRAULIC CIRCUIT BE AIR PURGED. THE VEHICLE MUST BE ON LEVEL GROUND TO BE PURGED.
RS 125 - Tuono 125 - Euro 4 Braking system • Drain the system as for the bleeding procedure, proceeding till reaching the indicated level in the inspection glass. • Place the gasket and the cover and tighten the two fixing screws. WARNING IF THE BRAKE LEVER IS OPERATED WITH THE CLAMP EXTRACTED IT MIGHT BE NECESSARY TO CARRY OUT THE CORRESPONDING BLEEDING.
Page 305
RS 125 - Tuono 125 - Euro 4 Braking system Installing Where you need to replace the front brake lever: • Carry out a complete inspection of the piston and the cylinder to check the braking system is working properly. Make sure no other component is dam- aged.
RS 125 - Tuono 125 - Euro 4 Braking system • The measurement must be carried out at the indicated point. CAUTION LIFT THE FRONT WHEEL AT THE END OF THE OPERATION AND CHECK THAT IT SPINS FREE- LY WITH THE BRAKE LEVER IN REST POSITION. CHECK THAT THE BRAKE LEVER HAS FREE STROKE WITHIN THE LIMITS PRESCRIBED IN THE ASSEMBLY PHASE.
Page 307
RS 125 - Tuono 125 - Euro 4 Braking system • Unscrew and remove the two screws, and retrieve the respective nuts. • Unscrew and remove the nut, and re- trieve the screw. • Remove the rear brake pump. • To reassemble, repeat the procedure described above in reverse order.
Page 308
RS 125 - Tuono 125 - Euro 4 Braking system • Remove the two brake pump fixing screws. • Unscrew the coupling and disconnect the oil pipes from brake pump in order to remove it. BRAK SYS - 308...
RS 125 - Tuono 125 - Euro 4 Cooling system 19.Electric fan 20.Washer 21.Pin 22.Washer 23.Screw 24.Screw Electric fan • Remove the radiator • Undo and remove the three screws and collect the washers; remove the electric fan. See also Removing the radiator Coolant replacement...
Page 313
RS 125 - Tuono 125 - Euro 4 Cooling system • Release the clamp. Remove the pipe and drain the coolant into a container of adequate capacity. CAUTION DO NOT DISPOSE OF THE FLUID INTO THE ENVIRONMENT. FILLING THE COOLING SYSTEM •...
RS 125 - Tuono 125 - Euro 4 Cooling system • Remove the clutch cover; • Heat the clutch cover to facilitate extraction of the water pump spindle assembly; • Support the clutch cover on a press and with the specific tool "B", remove the water pump shaft group, acting from the external part to the internal one.
Page 315
RS 125 - Tuono 125 - Euro 4 Cooling system ALWAYS REPLACE THE BEARINGS, THE OIL SEAL, AND THE SEALING RING, WHENEVER IT IS NECESSARY TO REMOVE THE WATER PUMP. • Place the new bearings on the press and with the specific tool "B" push the shaft until it stops;...
RS 125 - Tuono 125 - Euro 4 Cooling system • Place the gear paying attention that the operation is oriented to the cover; • Use the specific tool "B" as an endstop in order to push the gear, with the press, until it is in line with the shaft.
Page 317
RS 125 - Tuono 125 - Euro 4 Cooling system • Lift the fuel tank and disconnect the electric fan connector. See also Removing the expansion tank • Unscrew the radiator cover and let it connect to the hoses. • Loosen the clamp with a screwdriver.
RS 125 - Tuono 125 - Euro 4 Cooling system • Sliding it off the fitting slots, remove the radiator. • Remove the electric fan if necessary. Radiator installation • Install the radiator following the removal operations but in reverse order. •...
RS 125 - Tuono 125 - Euro 4 Cooling system • Loosen the clamp and slide off the ho- ses. See also Side fairings Coolant replacement • Unscrew and remove the tank fixing screw. • Slide off the coolant tank. INSTALLATION •...
Page 336
RS 125 - Tuono 125 - Euro 4 Bodywork ILTER BOX Pos. Description Type Quantity Torque Notes Air filter box fastening screw 3.5 Nm (2.58 lb ft) Driving mirrors (RS 125) • Unscrew and remove the two nuts in- side the top fairing, two for each mirror. •...
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the protective rubber (1) • Using a suitable wrench unscrew the threaded pin (2) • Remove the right rear view mirror (3) • Repeat the entire procedure to remove the left rear-view mirror Instrument panel (RS 125)
Page 338
RS 125 - Tuono 125 - Euro 4 Bodywork • Unscrew and remove the six perimeter screws and remove the two cases. REMOVING INSTRUMENT CLUSTER MOUNT- • Unscrew and remove the two through- passing screws and retrieve the wash- er form the left side and the nut from the right side.
Page 339
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the clamp (6) • Retrieve the four bushings (7) • Turn the instrument panel mounting 180° • Unscrew and remove the screw (8) • Unscrew and remove the screw (9) and retrieve the washer (10) •...
Page 340
RS 125 - Tuono 125 - Euro 4 Bodywork • Unscrew and remove the two screws (13) and retrieve the two washers (14) • Disconnect the connector (15) • Remove the instrument panel (16) • Remove the left instrument panel mounting (17) Headlight assy.
RS 125 - Tuono 125 - Euro 4 Bodywork • Unscrew and remove the four top fair- ing fastening screws • Remove the light assembly. (TUONO 125) • Remove the top fairing • Unscrew and remove the two screws • Disconnect the two connectors (2) •...
Page 342
RS 125 - Tuono 125 - Euro 4 Bodywork • First remove the fairing and the rear- view mirrors. • Unscrew and remove the turn indicator screw. • Remove the glass and disconnect the two bulb wires. • Remove the two screws inside the top fairing from both sides of the motorcy- cle.
Page 343
RS 125 - Tuono 125 - Euro 4 Bodywork • Disconnect the instrument panel con- nector. • Remove the top fairing. (TUONO 125) • Remove the side fairings • Unscrew and remove the two screws • Unscrew and remove the two screws •...
Page 344
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the right lamp side panel (5) • Remove the instrument panel dash- board (6) • Undo and remove the screw (7) • Unscrew and remove the screw (8) BODYW - 344...
Page 345
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the rivet (9). • Undo and remove the screw (10) • Retrieve the washer (11) and the spacer (12) • Undo and remove the screw (13) • Retrieve the washer (14) and the bush- ing (15) •...
Page 346
RS 125 - Tuono 125 - Euro 4 Bodywork • Disconnect the connector (17) • Disconnect the connector (18) • Remove the front fairing (19) • Unscrew and remove the two screws (20) BODYW - 346...
Page 347
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the top fairing (21) Front wheelhouse • Remove the fairing from the side of the wheel housing that you want to re- move. • Operating from the left shield, unscrew and remove the regulator fixing screw, collecting the nut and the washer.
RS 125 - Tuono 125 - Euro 4 Bodywork Taillight assy. • First remove the tail fairing and the passenger seat. • Remove the two side screws (1). • Remove the two top screws (2). • Disconnect the connector. • Take off the rear light unit, by removing it from the hooks.
RS 125 - Tuono 125 - Euro 4 Bodywork Tail guard Side body panels The following procedure is only shown from one side of the vehicle, but it is valid for both side fair- ings • Remove the saddle • Undo and remove the screw (1) •...
Page 350
RS 125 - Tuono 125 - Euro 4 Bodywork The following describe the procedure for removing one fairing but are applicable for both. • Rest the vehicle on its stand. • Remove the side fairing. • Unscrew and remove the two screws (1) and retrieve the washers.
Page 351
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the rivet (3) • Undo and remove the screw (4) • Remove the right side engine fairing • Remove the rivets (6) BODYW - 351...
Page 352
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the rivets (7) • Remove the rivet (8) • Undo and remove the screw (9) • Remove the left side engine fairing (10) BODYW - 352...
Page 353
RS 125 - Tuono 125 - Euro 4 Bodywork • Undo and remove the screw (11) • Remove the front right turn indicator from its seat (12) • Undo and remove the screw (13) • Remove the washer (14) • Remove the spacer (15) BODYW - 353...
Page 354
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the inside right side fairing (16) • Remove the clamp (17) • Remove the clamp (18) • Undo and remove the screw (19) BODYW - 354...
Page 355
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the front left turn indicator from its seat (20) • keeping the two screws locked (21) un- screw and remove the two fastening nuts (23) • Retrieve the two washers (22) •...
Page 356
RS 125 - Tuono 125 - Euro 4 Bodywork • Undo and remove the screw (27) • Retrieve the washer (28) • Retrieve the washer (29) • Remove the inside left side fairing (30) License plate holder • First remove the passenger saddle. •...
Page 357
RS 125 - Tuono 125 - Euro 4 Bodywork • Unscrew and remove the lower central screw. • Unscrew and remove the two lower screws. • Remove the three clamps. • Disconnect the connector. • Remove the licence plate support. BODYW - 357...
Page 358
RS 125 - Tuono 125 - Euro 4 Bodywork Air box • Remove the passenger footrest, the saddle, the tank, the fairing and the splash guard. • Unscrew and remove the four screws (1). • Loosen the clamp and remove the in- take tube.
RS 125 - Tuono 125 - Euro 4 Bodywork Rear mudguard • Unscrew and remove the screw. • Slide off the pipe grommet. • Operating from the right side, unscrew and remove the central screw. • Working on the left side, unscrew and remove the two screws.
Page 360
RS 125 - Tuono 125 - Euro 4 Bodywork • - Remove the side fairings. • Put the vehicle on the optional rear stand, with the side stand open. • Remove the side rivet. • Carry out the following operations on one side of the vehicle and then on the other side.
Page 361
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the lower rivet. • From the right side take out the right half-fairing. • Remove the left engine fairing from the left side, accompanying it along the profile of the stand. (TUONO 125) •...
Page 362
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the pipes (8) from the point shown in the figure • Remove the engine fairing complete with lower fairings • Unscrew and remove the five fixing screws (9) • Remove the lower left fairing (10) •...
Page 363
RS 125 - Tuono 125 - Euro 4 Bodywork Fuel tank • Remove the rider saddle. • Working on both sides of the vehicle, undo and remove the lateral screw. • After removing the passenger saddle, lift the saddle and support its weight adequately.
RS 125 - Tuono 125 - Euro 4 Bodywork • Operating from both sides, unscrew and remove the screw and collect the nut on the internal side. • Keeping the tank in position, lower it by removing the supporting rod. •...
Page 365
RS 125 - Tuono 125 - Euro 4 Bodywork • Unscrew and remove the two lower screws. • Slide off the radiator cover. • Working from both sides of the vehicle, release the two rivets and slide off the front lug. Tail guard (RS 125) •...
Page 366
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the saddle • Remove the side fairings • Unscrew and remove the screw (1) • Unscrew and remove the screw (2) • Unscrew and remove the seven screws (3) •...
Page 367
RS 125 - Tuono 125 - Euro 4 Bodywork • Remove the top handle (6) • Unscrew and remove the six screws • Remove the top handle (8) • Unscrew and remove the two screws BODYW - 367...
Page 368
RS 125 - Tuono 125 - Euro 4 Bodywork • Undo and remove the screw (10) • Remove the right tail fairing (11). • Unscrew and remove the screws (12) • Undo and remove the screw (13) BODYW - 368...
Page 369
RS 125 - Tuono 125 - Euro 4 Bodywork • Disengage the saddle opening cable (14) • Remove the left tail fairing (15). BODYW - 369...
Page 371
RS 125 - Tuono 125 - Euro 4 Pre-delivery Carry out the listed checks before delivering the motorcycle. WARNING HANDLE FUEL WITH CARE. Aesthetic inspection - Paintwork - Fitting of Plastic Parts - Scratches - Dirt Tightening torques inspection - Safety fasteners: front and rear suspension unit front and rear brake calliper retainer unit front and rear wheel unit...
Page 372
RS 125 - Tuono 125 - Euro 4 Pre-delivery - Through the diagnostic tool, check that the last mapping version is present in the control unit/s and, if required, program the control unit/s again: consult the technical service website to know about avail- able upgrades and details regarding the operation.
RS 125 - Tuono 125 - Euro 4 Pre-delivery Road test - Cold start - Instrument panel operation - Response to throttle control - Stability when accelerating and braking - Front and rear brake efficiency - Front and rear suspension efficiency - Abnormal noise Static test Static check after test drive:...
RS 125 - Tuono 125 - Euro 4 Pre-delivery Specific operations for the vehicle (RS 125) To fit the Quick Shift, follow the fitting instructions. • Remove the gear tie-rod by unscrew- ing and removing the two fixing screws. • Place the screw (1) with its compo- nents in the spherical joint of the Quick Shift sensor.
Page 375
RS 125 - Tuono 125 - Euro 4 Pre-delivery • Access the Quick Shift connector by lifting the tank, the connector is placed, as shown in the figure, internally on the left side of the chassis. • Connect the two cables. PRE DE - 375...
