DISPLAY SETUP

The Vacuum Fluorescent Display (VFD) and On-Screen Display (OSD) can be
shown in various ways by navigating through the parameters at the "Display
Setup" menu. Use a combination of [ ] and [
"Display Setup" menu items.
Display: Select "On" to display all applicable data or characters at the VFD.
Nothing will be shown at VFD if "Off" is selected. However at "Temp" setting,
whenever any of the front panel controls or their corresponding keys in the
remote control is activated, the appropriate VFD characters will be shown
temporarily and then fade away.
Dimmer: If it is desired to reduce the brightness of the VFD, set Dimmer to
"Dim". Otherwise, select "Bright" to return to normal VFD brightness.
Line 1, Line 2: The VFD shows two main lines of data or characters. Line
2 is the line of data or characters located at the lower bottom of the VFD
while directly above it is Line 1. For both lines, one can select which display
could be shown by choosing through the following
Source: Shows the active Source.
Volume: Current Volume level is shown.
Listening Md (Listening Mode): Selected Listening Mode is shown.
AudioSrcForm (Audio Source Format): Shows the audio format
detected at the active Source.
Off: Select "Off" if it is desired not to show any data at the applicable Line.
Temp Line: Choose between Line 1 and Line 2 as the desired line where
VFD will be temporarily shown if "Off" is selected at "Display" option as
described above.
NOTE
The configurations set forth at "Display Setup" are carried over
whenever it is enabled during A/V PRESETS SETUP setting. Refer also to
the next section about "A/V PRESETS SETUP".

A/V PRESETS SETUP

The T 737's simple but powerfully flexible system of "Presets" allows you
to customize virtually every aspect of your audio-video playback. The
] keys to step through the "Listening Mode", "Tone Controls", "Speaker Setup" and "Display Setup"
parameter settings are stored together as a Single Preset.
You might create one Preset optimized for pop music and another for
classical. One more Preset can be set up to recall each family member's
favorite setting or one for fully cinematic home-theater playback and
yet another one for late-night movies, with each Preset fine-tuned to a
particular scenario or preference.
CREATING PRESETS
Creating a Preset consists simply of storing a complete set of the
parameters set forth in the "Listening Mode", "Tone Controls", "Speaker
Setup" and "Display Setup" configurable through "Setup Menu".
Go to "A/V Presets Setup" to save a collection of said parameter settings to a
Preset. Select a Preset number and by a combination of pressing the [
you can selectively include in the particular Preset any of the above-mentioned
parameter settings by choosing "Yes". If you decide not to include in the particular
Preset a certain parameter setting, select "No".
Now in order to save the settings chosen for the particular Preset number,
scroll down to "Save Current Setup" and press the [
load instead the default settings, scroll down to "Load Defaults to Preset"
and press the [
In addition to the parameter settings, the Preset label itself can be assigned a
new name. This new Name will be shown in the VFD as well as on the OSD.
To rename the Preset label, scroll to "Name" and press [
character. Then, press [
selections. Press [
previous character and at the same time save the changes done on the
current character.
RECALLING PRESETS
You may recall a Preset at any time using the AVR 3 remote control.
Press the AVR 3's A/V PSET key and then the numeric key 1-5 corresponding
to the desired preset number. The newly recalled Preset will then manifest
or replace the previous Preset (if any).
OPERATION
USING THE T 737 – SETUP MENU
] key. If you chose to
] key to restore the default settings.
] to pick and select through the alphanumeric
] to move to the next character or back to the
] keys,
] to go the
25
