Features and Technical Specifications

Data Interface
Data Rates
Server-to-Client Data
Rates
Client-to-Server Data
Rates
Client-to-Client Data
Rates
Fax Rates
Modem Compatibility
Fax Compatibility
Error Correction
Data Compression
Flow Control
Transmit Level
Environmental
Mechanical Dimensions
& Weight
Command Buffer
Other Features
Manufacturing
Information
Certification
Warranty
Multi-Tech Systems, Inc. MT5634IND User Guide (S000369B)
Serial, Binary, Asynchronous
Serial interface supports speeds up to56K
56K speeds when accessing a server (actual speed depends on server capabilities
and line conditions)
Up to 48Kbps when accessing a V.92 server (actual speed depends on server
capabilities and line conditions); otherwise, the same rates as client-to-client data
rates apply (see Client-to-Client Data Rates).
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400, 12000, 9600,
7200, 4800, 2400, 1200, 0-300 bps
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400, 12000, 9600,
7200, 4800, 2400, 300 bps
V.92, V.90, V.34, V.32bis, V.32, V.22bis, V.22, Bell 212A and 103/113, V.21, V.23,
V.42bis, V.44
ITU-T "Super" Group 3; Class 1.0, 2.0, 2.1; T.4; T.30; V.21; V.27ter; V.29; V.34; V.17;
and TIA/EIA Class 1, 2; TR29.2
V.42
V.44, V.42bis
XON/XOFF; hardware (RTS/CTS)
-13 dBm
Temperature range -40°C to +85°C
4.3" w x 2.4" h x 0.94" d; 4.2 oz.
(11 cm x 6.1 cm x 2.4 cm; 120 g)
60 characters
Global approvals in many countries for worldwide use
Desktop or panel mounting
Industrial chassis (a rugged, water-resistant, industrial chassis made of aluminum)
Automatic fallback to slower speeds in noisy line conditions and fall-forward to faster
speeds as conditions improve
Fully AT command compatible
2-wire leased-line support
Flash memory for easy updates
Callback security; Remote configuration
Caller ID (in U. S.)
Autodial, redial, repeat dial, dial pauses; Pulse or tone dial and touch-tone dial
Dial tone and busy signal detection for reliable call progress reporting
Nonvolatile memory for storage of custom settings and two telephone numbers
Call status display
Auto parity and data rate selections
On-screen displays for modem option parameters
Trade Name: MultiModem
Model Number: MT5634IND
Registration Number: The embedded SocketModem MT5634SMI is the registered
part of this product: AU7USA-25814-M5-E
Ringer Equivalence: 0.3B
Modular Jack (USOC): RJ11
EMC Safety Approvals:
FCC Part 15 Class B – Emissions for U.S.A. and Canada
EN55022 Class B – Emissions for EU countries. Needed for CE marking
EN55024 – Immunity for EU countries. Needed for CE marking
EN61000-6-2 – Immunity for industrial environments
Safety Certifications:
UL60950-1 – U.S.A. and Canada Safety
EN60950-1 – Safety for EU countries. Needed for CE marking
GR1089 – Clause 4 NEBS Tested
Reliability:
Temperature Range: -40°C to +85°C
EN60068-2-6 – Vibration 10 to 500 Hz sine vibration 5g
EN60068-2-30 – Temp/Humidity Damp Heat cycling
EN60068-2-1 – Cold (-40°C)
EN60068-2-2 – Dry Heat (+85°C)
EN60068-2-14 – Change of Temperature (-40°C to +85°C)
IEC 68-2-27 – Shock – 3 shocks/3mS duration 50g
5 years
