Introduction
The menu system for the MultiDSU provides a set of user-friendly
configuration menus that are accessible from a main menu. The Main
Menu contains four options that enable you to configure your MultiDSU,
check the current operating status, display hourly and daily statistics, or
run diagnostic tests; you can also exit (quit) the command mode from
the Main Menu.
T1 DSU Main Menu
1. Configurations
2. Current Status
3. Statistics
4. Diagnostics
5. System Information
Enter Selection (-(previous), q(uit), <1>): _
To select one of the four main options from the Main Menu, enter the
number corresponding to the option and press the ENTER key to open
the associated submenu.
Configurations Menu
The Configurations menu provides various options for configuring the
T1 Line, including DS0 speed and allocation, selection of the source for
clocking. This menu also enables the usere to select "Forced" or
"Independent" RTS or DTR on the Data port. Other options enable the
user to set the configurations, set and save them, or reset the unit to its
factory defaults.
T1 Line Configuration Menu
This menu enables you to select the framing format, line coding, and
line type and length to match the characteristics of the T1 line provided
by your Telco or, for back-to-back connections to set the Master/Slave
units to identical settings.
