ROYAL ENGLISH OAK AND WINcHEStER OAK UNVENtED
OWNER'S OPERAtION AND INStALLAtION MANUAL
Patent Pending
18" VARIAbLE MANUALLY-cONtROLLED
Also Design-Certified as Vented Decorative Appliance
f i r e - p a r t s . c o m
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
(VENt-FREE) GAS LOG HEAtER
MODELS cSL2718N AND cSL2718P
For more information, visit www.desatech.com
Advertisement
Table of Contents
Related Manuals for Desa CSL2718N
Summary of Contents for Desa CSL2718N
- Page 1 OWNER’S OPERAtION AND INStALLAtION MANUAL Patent Pending 18" VARIAbLE MANUALLY-cONtROLLED MODELS cSL2718N AND cSL2718P Also Design-Certified as Vented Decorative Appliance f i r e - p a r t s . c o m WARNING: If the information in this manual is not fol- lowed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
tAbLE OF cONtENtS Safety Information .......... Troubleshooting ..........0 Product Identification ........... 4 Specifications ............ 4 Local Codes............5 Technical Service..........4 Unpacking............5 Service Hints ............. 4 Product Features ..........5 Replacement Parts ..........4 Air For Combustion and Ventilation ..... 5 Accessories ............ -
Page 3: Safety Information
SAFEtY INFORMAtION WARNING: Do not allow fans Continued to blow directly into the fireplace. Avoid any drafts that alter burner WARNING: This product con- flame patterns. Ceiling fans can tains and/or generates chemicals create drafts that alter burner known to the State of California flame patterns. -
Page 4: Product Identification
11. Before using furniture polish, wax, carpet SAFEtY INFORMAtION cleaner or similar products, turn heater off. If Continued heated, the vapors from these products may 1. This appliance is only for use with the type of create a white powder residue within burner gas indicated on the rating plate. -
Page 5: Local Codes
LOcAL cODES PRODUct FEAtURES Install and use heater with care. Follow all local OpERATION codes. In the absence of local codes, use the lat- This heater is clean burning. It requires no outside est edition of The National Fuel Gas Code ANSI venting. - Page 6 AIR FOR cOMbUStION Confined Space and Unconfined Space The National Fuel Gas Code ANSI Z223.1/NFPA AND VENtILAtION 54 defines a confined space as a space whose Continued volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m per kw) of the aggregate input Exhaust fans, fireplaces, clothes dryers and fuel rating of all appliances installed in that space and...
- Page 7 nent openings: one within 12" of the ceiling and AIR FOR cOMbUStION one within 12" of the floor on the wall connecting AND VENtILAtION the two spaces (see options 1 and 2, Figure 2). You Continued can also remove door into adjoining room (see option 3, Figure 2).
-
Page 8: Installation
INStALLAtION WARNING: Never install the NOTICE: This heater is intended heater for use as supplemental heat. • in a bedroom or bathroom un- Use this heater along with your less installed as a vented appli- primary heating system. Do not ance (see page 11) install this heater as your pri- •... - Page 9 INStALLAtION NOTICE: Manual control heaters Continued may be used as a vented product. If so, you must always run heater INSTALLATION AND CLEARANCES with chimney flue damper open. If (Vent-Free Operation Only) running heater with damper open, WARNING: Maintain the noncombustible material above fire- minimum clearances.
- Page 10 INStALLAtION Determining Minimum Mantel Clearance when Using a Hood Continued If minimum clearances in Figure 6 are not met, you must have a hood. When using a hood there are If Using Mantel You must have noncombustible material(s) above still certain minimum mantel clearances required. the fireplace opening.
- Page 11 If reasons number 1 or 2 apply to you, you must INStALLAtION permanently open chimney flue damper. You must Continued install the damper clamp accessory (to order, see Accessories, page 25). This will insure vented FLOOR CLEARANCES operation (see Figure 10). The damper clamp will A.
- Page 12 IMPORTANT: Hold gas regulator with INStALLAtION wrench when connecting flexible gas hose. Continued 2. Locate masonry screws in hardware package. INSTALLING HEATER BASE 3. Position heater base assembly in fireplace. ASSEMBLY 4. Place log in its proper position on heater base (see Installing Log, page 15).
- Page 13 For propane/LP gas, the installer must supply an INStALLAtION external regulator. The external regulator will Continued reduce incoming gas pressure. You must reduce incoming gas pressure to between 11" and 14" of CONNECTING TO GAS SUppLY water. If you do not reduce incoming gas pres- sure, heater regulator damage could occur.
- Page 14 INStALLAtION CAUTION: For propane/LP Continued units, make sure external regula- We recommend that you install sediment trap in tor has been installed between supply line as shown in Figure 14. Locate sediment propane/LP supply and heater. trap where it is within reach for cleaning. Install in piping system between fuel supply and heater.
- Page 15 INStALLAtION INSTALLING LOG Continued WARNING: Failure to position Propane/LP Equipment Shutoff Valve the parts in accordance with these Supply Tank diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury. CAUTION: After installa- tion and periodically thereafter, Control Valve...
-
Page 16: Operating Heater
OPERAtING HEAtER LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: • If fireplace has glass doors, WARNING: If you do not fol- never operate this heater with low these instructions exactly, glass doors closed. If you op- a fire or explosion may result erate heater with doors closed, causing property damage, per- heat buildup inside fireplace... - Page 17 OPERAtING HEAtER Ignitor Pilot Burner Electrode Continued 5. Slightly depress and turn control knob counterclockwise to the PILOT position. Press in control knob for five (5) seconds (see Figure 19). Thermocouple Note: You may be running this heater for Propane/LP the first time after hooking up to gas sup- Ignitor Electrode ply.
-
Page 18: Inspecting Burners
OPERAtING HEAtER BURNER PRIMARY AIR HOLES Air is drawn into the burner through the holes in Continued the fitting at the entrance to the burner. These holes MANUAL LIGHTING may become blocked with dust or lint. Periodically inspect these holes for any blockage and clean as pROCEDURE 1. - Page 19 cLEANING AND Injector Holder (May Be Brass or Aluminum MAINtENANcE Depending on Model) Continued Burner Tube BURNER INjECTOR HOLDER AND pILOT AIR INLET HOLE The primary air inlet holes allow the proper Primary Air Inlet amount of air to mix with the gas. This provides Holes (Shape of a clean burning flame.
-
Page 20: Troubleshooting
tROUbLESHOOtING WARNING: Turn off and unplug heater and let cool before servicing. Only a qualified service person should service and repair heater. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY... - Page 21 tROUbLESHOOtING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY ODS/pilot lights but flame goes 1. Control knob not fully pressed 1. Press in control knob fully out when control knob is re- leased 2. Control knob not pressed in 2. After ODS/pilot lights, keep con- long enough trol knob pressed in 30 seconds 3.
- Page 22 tROUbLESHOOtING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Slight smoke or odor during initial 1. Not enough air 1. Check burner for dirt and operation debris. If found, clean burner (see Cleaning and Mainte- nance, page 18) 2. Gas regulator defective 2.
- Page 23 tROUbLESHOOtING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 24: Specifications
1-866-672-6040. When calling please have your model and serial numbers of your heater ready. When calling DESA Heating Products, have ready You can also visit DESA Heating Products’ techni- cal service web site at • model number of your heater www.desatech.com •... -
Page 25: Accessories
Purchase these fireplace accessories from your local dealer. If they can not supply these acces- sories, either contact your nearest Parts Central or call DESA Heating Products’ Sales Department at 1-866-672-6040 for information. You can FIREpLACE HOOD also write to the address listed on the back page Black - GA6050 of this manual. - Page 26 ILLUStRAtED PARtS bREAKDOWN VARIABLE MANUALLY-CONTROLLED WINCHESTER OAK MODELS CSL2718N AND CSL2718p f i r e - p a r t s . c o m www.desatech.com 119347-01A...
- Page 27 PARtS LISt VARIABLE MANUALLY-CONTROLLED WINCHESTER OAK MODELS This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 24 of this manual. NO. PART NO. DESCRIpTION QTY. 119500-01 One Piece Log Set •...
-
Page 28: Warranty Information
This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to proper operating condition and an allowance for labor when provided by a DESA Heating Products Authorized Service Center. Warranty part(s) MUST be obtained through authorized dealers of this product and/or DESA Heating Products who will provide original factory replacement parts.
