CS/CSP/MCS Series Current
Switches
WARNING
Failure to follow these instructions will result in
death or serious injury.
AVERTISSEMENT
Le non-respect de ces instructions entraîne un
risque de blessures graves, voire la mort.
WARNING
This product can expose you to chemicals
including 1,3 Butadiene, which is known to the
State of California to cause cancer and
reproductive harm. For more information, go to
www.P65Warnings.ca.gov
AVERTISSEMENT
Ce produit peut vous exposer à des produits
chimiques, dont le 1,3-Butadiène, considéré par
l'État de Californie comme étant cancérigène et
nocif pour la reproduction. Pour en savoir plus,
consultez le site www.P65Warnings.ca.gov
CAUTION
Hazard of electrical shock, explosion, and arc
flash
• Follow ALL requirements in NFPA 70E for safe work
practices and for Personal Protective Equipment (USA)
and other applicable local codes when installing this
product
INSTALLATION INSTRUCTIONS
• Only qualified electrical personnel should install this
product
• Read, understand, and follow all instructions
thoroughly
• Install only on insulated conductors
• Lock out and tag out all power sources prior to
installation. Use properly rated voltage sensing
instrument to determine no voltage is present
MISE EN GARDE
Risque de décharge électrique, d'explosion et
d'arc électrique
• Respectez TOUTES les exigences de la norme
NFPA 70E concernant les pratiques de travail
sécuritaires et les équipements de protection
individuelle (États-Unis), ainsi que les autres codes
locaux applicables lors de l'installation de ce produit
• Seul le personnel qualifié dans le domaine électrique
est autorisé à installer ce produit
• Lisez, comprenez et respectez scrupuleusement toutes
les instructions
• N'installez que sur les conducteurs isolés
• Verrouillez et étiquetez toutes les sources
d'alimentation avant l'installation. Utilisez un détecteur
avec la tension nominale appropriée pour déterminer
l'absence de tension
CAUTION
Automated equipment may start without
warning
• Equipment monitored/operated by this device may
start without warning. Keep clear of apparatus at all
times
IMPORTANT
• Only qualified trade installers should install this
product
• This product is not intended for life-safety applica-
tions
• Do not install in hazardous or classified locations
• The installer is responsible for all applicable codes
• This product must be installed in a suitable electri-
cal enclosure
• Clamp sensor around INSULATED CONDUCTOR
ONLY, 600VAC MAX to be monitored.
31-00432M-01
Advertisement
Related Manuals for Honeywell CS Series
Summary of Contents for Honeywell CS Series
- Page 1 CS/CSP/MCS Series Current Switches INSTALLATION INSTRUCTIONS • Only qualified electrical personnel should install this product • Read, understand, and follow all instructions thoroughly • Install only on insulated conductors • Lock out and tag out all power sources prior to installation.
-
Page 2: Installation
• N'installez pas dans des endroits dangereux ou PRODUCT APPLICATION LIMITATION: classés comme tels Honeywell products are not designed for life or safety • L’installateur est responsable de tous les codes applications. Honeywell products are not intended for use applicables in critical applications such as nuclear facilities, human •... - Page 3 CS/CSP/MCS SERIES CURRENT SWITCHES TECH TIPS Table 1. Troubleshooting On low current loads, wrap sensor Symptom Causes Remedy multiple times to increase sensi- Amperage is below Loop monitored tivity sensor minimum conductor multiple threshold turns through CAUTION sensor. See Tech Tips Do not exceed sensor Incorrect control Ensure control loop...
- Page 4 CS/CSP/MCS SERIES CURRENT SWITCHES Motor Nameplate 100% Motor FLA MODEL 2345 HP 10 KW 7.5 RPM 3450 RPM 345 BELT LOSS Hz 60 AMP 28.4 Normal Run Range PH 3 S.F. 1.15 S F 1 15 (Closed above this level) Sensor Threshold (Open below this level) 1-5HP...
- Page 5 1 through 5 above during initial setup to get correct appropriately for your application. Set the dial so that the setting. Once adjusted the Honeywell ECM current turn-on amperage is slightly higher than your ECM stand- switch will provide a true status output as shown in by current.
- Page 6 CS/CSP/MCS SERIES CURRENT SWITCHES Reliable operation requires variable frequency drive to increase frequency to a minimum of 40Hz when load is lost. Typical load status applications include: • Proof of flow • Belt-loss detection • Coupling shear Table 2. Specification by Product Core Product Number Trip Point...
-
Page 7: Specification
CS/CSP/MCS SERIES CURRENT SWITCHES SPECIFICATION Maximum surrounding air ambient, 60 ° C. For use in Pollution Degree 2 Environment. FIXED CURRENT SWITCHES ADJUSTABLE CURRENT SWITCHES Output Type Turn-on Amperage CSP-NO-AVFD-150A NO, solid-state FET 1A(30Hz min), 1.5A(20Hz min), 2.5A(10Hz min) Output Rating Output Type 1.0A@30VAC/DC Max. - Page 8 CS/CSP/MCS SERIES CURRENT SWITCHES Honeywell Building Technologies In the U.S.: Honeywell 715 Peachtree Street NE ® U.S. Registered Trademark Atlanta, GA 30308 ©2020 Honeywell International Inc. 31-00432M—01 M.S. 10-20 customer.honeywell.com Printed in United States...
