Honeywell C6097 Series Operating Instructions

03251518
D GB F NL I
www.docuthek.com
➔
Operating instructions
Gas pressure switches
C6097A, C6097B
Cert. version 02.20
Safety
Please read and keep in a safe place
Please read through these instructions
carefully before installing or operating. Following the
installation, pass the instructions on to the opera-
tor. This unit must be installed and commissioned
in accordance with the regulations and standards
in force. These instructions can also be found at
www.docuthek.com.
Explanation of symbols
• , 1 , 2 , 3 ... = Action
▷
= Instruction
Liability
We will not be held liable for damage resulting from
non-observance of the instructions and non-com-
pliant use.
Safety instructions
Information that is relevant for safety is indicated in
the instructions as follows:
DANGER
Indicates potentially fatal situations.
WARNING
Indicates possible danger to life and limb.
CAUTION
Indicates possible material damage.
All interventions may only be carried out by qualified
gas technicians. Electrical interventions may only be
carried out by qualified electricians.
E
Conversion, spare parts
All technical changes are prohibited. Only use OEM
spare parts.
Changes to edition 09.18
The following chapters have been changed:
– Cert. version
– Adjustment
Checking the usage
Gas pressure switches C6097 for monitoring increas-
ing and decreasing gas or air pressure.
C6097A: switches with falling pressure,
C6097B: switches with rising pressure.
Positive pressure
Gas, air, flue gas,
C6097A
biogas
Gas, air, flue gas,
C6097B
biogas
This function is only guaranteed when used within the
specified limits – see page 3 (Technical data). Any
other use is considered as non-compliant.
Part designations
2
1
Type label
D-49018 Osnabrück, Germany
C6097
CE –
2
1
GB-1
Negative pressure
Air, flue gas
Air, flue gas
1 Upper housing section
with cover
2 Lower housing section
3
3 Hand wheel
4 M16 cable gland
4
Max. inlet pressure = with-
stand pressure, mains volt-
age, ambient temperature,
enclosure: see type label.
3
