Page 1 440 Pipe and Cable Survey System Manual Related Customer Package Part No.s: P/N 500268 440 Complete System (110V AL) P/N 500269 440 Complete System (230V AL) P/N 500270 440 Complete System (110V SS) P/N 500271 440 Complete System (230V SS)
Page 2 The information in this manual is subject to change without notice and does not represent a commitment on the part of Teledyne TSS...
Page 3: Table Of Contents
4 Electrical Installation ........................ 4-1 4.1 Sub-sea Components ......................4-1 4.1.1 Ground Connections ....................4-3 4.1.2 Care of Sub-sea Connectors ..................4-3 4.1.3 Power Supply Pod ...................... 4-3 4.1.3.1 Power Requirement .................... 4-4 DPN 402196 Issue 4.1 © Teledyne TSS...
Page 4: Contents
5.3.3 Configuration Menu ....................5-20 5.3.3.1 System parameters ................... 5-20 5.3.3.2 Altimeter ......................5-20 5.3.3.3 External Output ....................5-23 5.3.3.4 Load Factory Defaults ..................5-24 5.3.3.5 Video Overlay Setup ..................5-25 5.3.4 Toolbars ........................5-26 © Teledyne TSS DPN 402196 Issue 4.1...
Page 5 6.3.2.3 Oscilloscope Test ....................6-13 6.3.2.4 Altimeter Test ....................6-13 6.3.3 Background Compensation and Monitoring ............. 6-14 6.3.4 Seawater Compensation ..................6-16 6.3.5 Background Noise Profile ..................6-16 6.3.6 The Survey Operation ....................6-16 DPN 402196 Issue 4.1 © Teledyne TSS...
Page 6 8 System Specifications ......................8-1 8.1 Specifications ........................8-2 8.1.1 Surface Display Computer ..................8-2 8.1.2 Sub-sea Electronics Pod .................... 8-2 8.1.3 Sub-sea Power Supply Pod ..................8-3 8.1.4 Search Coil Array ....................... 8-4 © Teledyne TSS DPN 402196 Issue 4.1...
Page 7 A.2.4.1 Background Compensation ................A-6 A.2.4.2 Active Compensation ..................A-6 A.2.4.3 Checking the Rejection ..................A-8 A.2.4.4 Rejection Parameters ..................A-9 A.2.4.5 Background Noise Profile .................. A-9 A.2.5 Trenching Vehicles ....................A-10 A.2.6 Limitations........................ A-10 DPN 402196 Issue 4.1 © Teledyne TSS...
Page 8 C Altimeter ........................... C-1 D Reference..........................D-1 D.1 Target Scaling Procedure ....................D-3 D.2 Target Scaling Results....................... D-5 D.3 Performance Envelope Results ..................D-7 D.4 Survey Details........................D-9 D.5 System Configuration Details..................... D-9 E Index............................E-1 © Teledyne TSS DPN 402196 Issue 4.1...
Page 9: List Of Figures
List of Figures List of Figures Figure 2-1: Components of the 440 System................... 2-1 Figure 2-2: Surface Display Computer (SDC10) overview ............. 2-3 Figure 3-1: SDC10 transit case - lid removal.................. 3-2 Figure 3-2: SDC10 - Panel PC fixings .................... 3-3 Figure 3-3: SEP and PSU mounting arrangement .................
Page 10 Figure 10-11: 401071-2 Analogue Board - Control ..............10-12 Figure 10-12: 401071-3 Analogue Board - Pre-amps ..............10-13 Figure 10-13: 401050-1 PSU Filter Assembly ................10-14 Figure 10-14: 490228-1 Power Supply Pod - 110V Version............10-15 viii © Teledyne TSS DPN 402196 Issue 4.1...
Page 11 Figure A-10: Typical lift curves with a fixed target present ............A-10 Figure B-1: Surface Display Computer (SDC10)................B-3 Figure B-2: Sub-sea components of the Teledyne TSS 350 or 350 Powertrack Systems ..... B-4 Figure B-3: Sub-sea components of the Teledyne TSS 440 System ..........B-4 Figure B-4: Electrical interconnection of sub-sea components ............
Page 13: List Of Tables
List of Tables List of Tables Table 2-1: Components of the 440 Pipe and Cable Survey System ..........2-2 Table 4-1: System interconnection details..................4-2 Table 4-2: Power and Communications cable................4-4 Table 4-3: RS232 connections for the altimeter (9-way D-type female cable) ....... 4-8 Table 4-4: Ideal twisted pair characteristics for successful communication ........
Page 14 List of Tables Table 10-1: Electrical Drawings....................10-1 Table 10-2: Mechanical drawings....................10-16 Table B-1: Components of the Dualtrack System ................B-4 Table C-1: Benthos PSA-916 part numbers ...................C-1 Table C-2: TSS ALT-250 part numbers..................C-1 © Teledyne TSS DPN 402196 Issue 4.1...
Page 15: Revision History
References to 3 coil algorithm removed Seawater compensation details added Factory defaults note added Video overlay modes clarified Note re signals data packet identifier added Note re spaces in altimeter strings added DPN 402196 Issue 4.1 © Teledyne TSS xiii...
Page 17: Glossary
Sub-sea electronics pod. The depth rated unit that performs the measurement operation on the target. Vertical range to target. The distance measured by the 440 System along a line perpen- dicular to the coil surface, between the coil array and the closest point of the conductive target.
Page 19: Introduction
Do not use the 440 System to survey targets buried beneath iron ore, which will mask signals from the target. The 440 System includes a display and control computer that you should install where you may see its screen easily while you operate the ROV. The display includes information to help you guide the ROV along the course of the target.
Page 20: Conventions Used
1 – Introduction Significant differences between 340 and 440. ❐ Increased range due to improved detection algorithm. ❐ Increased sensitivity from new search coils. ❐ Easier setup and survey from new Windows SDC and software. ❐ Raw signal data available at SDC.
Page 21: System Description
Surface Display Computer (SDC) You should use the SDC to configure and control the 440 System. It communicates with the sub-sea installation using bi-directional signals transmitted through the ROV umbilical. By interpreting the signals from the sub-sea installation, the SDC generates a clear graphical display that helps you to guide the ROV along the course of the target.
Page 22: Principle Of Operation
1.5 Warranty Teledyne TSS Ltd warrants the 440 Pipe and Cable Survey System to be free of defects in materials or workmanship for 12 months beginning on the date when the equipment was shipped from the Teledyne TSS Ltd factory.
Page 23: Product Support
This warranty is expressly in lieu of all other warranties, expressed or implied, including without limitation the implied warranties of merchantability or fitness for a particular purpose. The foregoing states the entire liability of Teledyne TSS Ltd with respect to the products described herein.
Page 25: System Overview
Optionally, you may use the 440 System as part of a Dualtrack installation. In this mode, a single SDC controls the operation of the 440 Pipe and Cable Survey System when its sub-sea components are connected to either a Teledyne TSS 350 or 350 Powertrack Cable Survey System.
Page 26: Unpacking And Inspection
3.1.3 "Coil for additional information. Array" on page 3-5 Three Teledyne TSS search coils arranged as shown with connections to Channels 1 to 3 on the SEP. Power and data cable that connects the altimeter to the SEP Sub-sea altimeter 2.1 Unpacking and Inspection...
Page 27: Surface Components
Notify Teledyne TSS immediately if there are parts or sub-assemblies missing from your shipment. If you see any damage to the System, file a claim with the insurers and inform Teledyne TSS. The title page of this Manual lists the contact details for Teledyne TSS. Teledyne TSS also operates a 24-hour emergency telephone support line managed by trained and experienced engineers.
Page 28 To configure and control the 440 System. The SDC uses the Windows 7 operating environment. DeepView for Windows is installed on the SDC prior to delivery and is used to configure the 440 System after installation, and to operate the System during a survey. See Chapter 5 "System Configuration"...
Page 29: Sub-Sea Components
❐ A sub-sea altimeter. ❐ Cables to interconnect the sub-sea components of the 440 System and to connect them to the electrical distribution system of the ROV. 2.3.1 Power Supply Unit The PSU accepts a single phase AC electrical supply nominally at 110V AC at 45 to 65Hz. A switched- mode circuit inside the PSU generates the conditioned DC supplies required by the SEP, with all DC supplies passing through a -filter network to prevent noise and interference from reaching the SEP.
Page 30: Sub-Sea Electronics Pod
RS232 communications. On the other end-cap: There are four electrically identical connection ports for the four active channels. The 440 System uses only channels 1 to 3 during normal operations, although you may use channel 4 as a substitute if one of the other channels fails.
Page 31: Search-Coils
440 System. On some types of tracked ROV, you may arrange to keep the coil array of the 440 System at a fixed height above the seabed. In these circumstances you could avoid the need for an altimeter by configuring DeepView for Windows to use a fixed coil height.
Page 33: Physical Installation
3 Physical Installation This section of the Manual explains how to install the surface and the sub-sea components of the Teledyne TSS 440 System. During the installation procedure you should make a written record of certain parameters and retain them with the survey log for reference during the post-processing operation. The DeepView for Windows software on the SDC allows you to examine the System parameters and to create a printed copy that you may retain with the survey records.
Page 34: Figure 3-1: Sdc10 Transit Case - Lid Removal
ROV. 2. Open the four fixings located on the front and rear of the transit case. Secure the transit case so that it cannot slide or fall with movements of the vessel. © Teledyne TSS DPN 402196 Issue 4.1...
Page 35: Sub-Sea Installation
4-17 for instructions to change the analogue output settings. 3.1.1 Sub-sea Installation The care that you take when you install the sub-sea components of the 440 System will have a significant influence on the accuracy of survey data. Read the following instructions carefully and ensure that you have all the necessary parts and tools available before you attempt to install the System.
Page 36 ROV. ❐ Locate the housings so that you may route the cables easily between the sub-assemblies of the 440 System. ❐ Do not apply sharp bends or other mechanical stresses to the cables during installation or operation.
Page 37: Coil Array
NOTE You should read this section before you attempt to install the array of search-coils. These details are critical to the successful operation and performance of the 440 System. Follow these instructions carefully to obtain the best performance from the System and to avoid interference with other equipment on board the ROV.
Page 38: Search-Coil Configuration
3 – Physical Installation 3.1.3.1 Search-coil Configuration The standard 440 System uses three search-coils of dimension 1.0m × 0.94m × 0.03m. They must be mounted so that the sides without mounting holes point in a fore-aft direction. NOTE Versions of the 340 System used search-coils of different dimension. Do not use type 41 or other old coil types with the 440 System.
Page 39: Figure 3-4: Coil Separation Distance
NOTE Based upon considerable field experience, Teledyne TSS recommends a front- mounting location for the coils of the 440 System. This is both effective and practi- cal for the majority of installations. The preferred position to mount the coil array is on the front of the ROV. This will help the pilot to follow the most effective course along the target by using the DeepView for Windows Run Window.
Page 40: Coil Assembly And Installation
ROV. 3.1.3.3 Coil Assembly and Installation You must use the correct non-conductive mounting components supplied with the 440 System to fix the search-coils to the ROV frame. These mounting components include six pre-drilled cast nylon beams and nylon threaded stud, nuts and washers.
Page 41: Figure 3-5: Components Of The Coil Frame
240mm 390mm 390mm 870mm 870mm 900mm 900mm Outrigger 1290mm 2130mm 2160mm Tie Bar 2130mm 2160mm Figure 3-5: Components of the coil frame Figure 3-6 shows how to construct the coil frame. DPN 402196 Issue 4.1 © Teledyne TSS 3- 9...
Page 42: Figure 3-6: Assembly Of The Coil Frame
To construct the coil frame and assemble the coils to the ROV you will need the following facilities, components and items: ❐ All the components and fixings of the coil frame supplied by Teledyne TSS. ❐ Stainless steel bolts or U-bolts to fix the coil frame to the ROV.
Page 43 5mm diameter holes through the stud above and below the fixing nuts and use cable ties to lock the nuts into position. DPN 402196 Issue 4.1 © Teledyne TSS 3- 11...
Page 44: Figure 3-7: Coil Fixing And Use Of Spacers For Coil Arrangement
Use stainless-steel bolts or U-bolts to secure the free ends of the tie-bars to the ROV frame as shown in Figure 3-6(d). You may have to shorten the tie-bars so that they do not snag the ROV umbilical. 3-12 © Teledyne TSS DPN 402196 Issue 4.1...
Page 45: Altimeter
Note that it is the position of the altimeter that causes these errors. Measurements of vertical range made by the 440 System will retain their accuracy under all normal conditions. NOTE Do not place the altimeter at the opposite end of the ROV to the coils. If you do not follow this advice, it is possible that the survey data might contain errors caused by pitch of the ROV or uneven seabed topography.
Page 46: Installation Check-List
0.75 to 1.2 metres between the coil array and the ROV body. ❐ If you intend to install the 440 System on the same ROV as a Teledyne TSS 350 or 350 Pow- ertrack System, follow the instructions and recommendations concerning coil installation in Appendix B.
Page 47: Electrical Installation
ROV and on the 440 System. Do not reconnect the mains electrical supply to the ROV or to the 440 System until you have completed all work and you have fitted all safety covers and ground connections.
Page 48: Figure 4-1: System Interconnection Diagram
The SEP drives the search coils through the coil search cables. Three coil connection cables Three Teledyne TSS search coils arranged as shown with connections to Channels 1 to 3 on the SEP. Power and data cable that connects the altimeter to the SEP Sub-sea altimeter ©...
Page 49: Ground Connections
4 – Electrical Installation 4.1.1 Ground Connections If you provide the 440 System with an inadequate ground connection, parts of the System will act as ‘sacrificial anodes’ and will slowly decay during sub-sea operations. This will occur whether or not you use the 440 System.
Page 50: Power Requirement
It is very important to provide a good ground connection on pin number 2 of the cable. A poor or a missing connection will severely degrade the performance of the 440 System. You must make all connections to the ROV using waterproof connectors or splices of good quality.
Page 51: Sub-Sea Electronics Pod
On one end cap: ❐ Connection ports for coil channels 1 to 4. A label identifies the four coil channels. The 440 Sys- tem uses only three channels during a survey. You must ensure the unused port has a blank- ing plug fitted to protect it during sub-sea operations.
Page 52: Sub-Sea Altimeter
System to protect it from contact with sea water. Further plugs can be obtained if required (Teledyne TSS P/N 202208). If you do not fit this blanking plug, rapid corrosion of the port will occur and the port will fail.
Page 53: Direct Connection To The Sep
4.1.6.2 Connection to the SDC Use this method to connect all other types of altimeter compatible for use with the 440 System. These altimeters use RS232 communications. To send their signals through the umbilical, you must add them to the ROV multiplex unit and extract them at the surface. You must also provide a separate power supply for the altimeter.
Page 54: Surface Display Computer
Transmit. Necessary for use only with the OSEL Bathymetric System, eter where communications must be bi-directional. RS232 common Ground Use the DeepView for Windows software to configure the 440 System for use with the appropriate type of altimeter. See Chapter 5 "System Configuration" Chapter 6 "Operating software" for relevant instructions.
Page 55: Table 4-4: Ideal Twisted Pair Characteristics For Successful Communication
The SDC10 uses the 15-way D-Type labelled ‘COMMS FROM SEP ‘to communicate with the 440 SEP. This connector is internally linked to ‘COM1’ used by DeepView to establish communication with the 440 SEP. There is no requirement to make an external connection to link the SDC10 and 440 SEP comms.
Page 56: Table 4-5: Power And Communications Cable - 2-Wire Current Loop Connections
To use current-loop communications you must reserve either one or two conductor pairs in the ROV umbilical for the exclusive use of the 440 System. The System includes a cable that you should use to connect the ‘COMMS FROM SEP’ port on the SDC to the twisted pairs in the ROV umbilical. The cable has a 15-way D-type connector for connection to the SDC ‘COMMS FROM SEP’...
Page 57: Alternative Communication Methods
RS232 communications. This method of communication is only suitable for use with umbilical cables up to 15m. To configure the 440 System to use an alternative communication method, you must change link settings inside the SEP and the position of the external switch on the SDC comms enclosure.
Page 58: Figure 4-3: Sepcard Support Block
4 – Electrical Installation and wrist-strap. Teledyne TSS will not accept responsibility for any damage caused by failure to take such measures. NOTE If you need to select a different communication method, change the settings of links inside the SEP before you install it on board the ROV.
Page 59: Table 4-8: Sep Link Header Part Numbers
Each of the headers has a different Teledyne TSS part number and establishes a different communications protocol. You may order a complete set of SEP headers from Teledyne TSS if you need to change the communication method.
Page 60: Figure 4-5: Comms Selector Switch Positions
DeepView for Windows to re-establish comms or comms errors will be generated. NOTE You must perform a communication check as part of the pre-dive tests. See sec- tion 6.3.2 "Pre-dive Checks" on page 6-12 for details of the recommended pre- dive test procedure. 4-14 © Teledyne TSS DPN 402196 Issue 4.1...
Page 61: Interface To Data Logger
4.2.3 Interface to Data Logger Use the SDC port ‘COM3 (EXT O/P)’ During normal survey operations, the 440 System acquires data at a rate of up to 1MB per hour. You should arrange to record the official survey log on a suitable data logger.
Page 62: Interface To Video
(COM3) is hard-wired to the analogue PCB input via a bespoke cable loom. This cable should not be removed or modified without contacting Teledyne TSS. If the external output is disabled via DeepView, the Analogue Output will not provide any outputs.
Page 63: Analogue Output Dip Switch Settings
1. Remove the transit case lid using the 4 x fixings provided. Figure 4-6: Removing the transit case lid 2. Remove the 8 x fixings from the Panel PC attaching it to the angled bracket secured to the transit case base. DPN 402196 Issue 4.1 © Teledyne TSS 4- 17...
Page 64: Figure 4-7: Sdc10 Fixings To Angled Bracket
6. Table 4.10 outlines the function of each the DIP switches. Configure the switches to meet installation requirements. Table 4.10: Analogue output DIP switch settings Switch Function State Output CH1 2V/m CH1 gain CH1 1V/m 4-18 © Teledyne TSS DPN 402196 Issue 4.1...
Page 65 9. If operating the SDC from the transit case, fit the 8 x fixings attaching the Panel PC to the angled bracket secured to the transit case base. 10. Verify the SDC is operating as required. DPN 402196 Issue 4.1 © Teledyne TSS 4- 19...
Page 67: Operating Software
5 – Operating Software 5 Operating Software NOTE Before you power-on the SDC and the sub-sea components of the 440 System, make certain that: ❐ You have installed the surface and sub-sea components correctly as instructed in Chapter 3 "Physical Installation".
Page 68 440 System. The System starts to operate when you provide the correct electrical supply to the PSU. Power-on the sub-sea components of the 440 System. At the SDC, apply power to the unit and it will automatically power-on.
Page 69: Initial Configuration
Figure 5-1: System Configuration Wizard 5.2.1 Sub-Sea Electronics Pod Define whether there is no SEP, a 440 or whether it is part of a Dualtrack System. This setting determines the data format that DeepView for Windows expects to receive from the sub-sea installation and sets the style of Run Window that the software will use to display the System measurements.
Page 70: Communication Ports
COM3 (labelled ‘LOG O/P (COM3)’ on the rear connector panel of the SDC) is used to connect the SDC to a separate user-supplied data logger. You should use a data logger to record the survey measurements acquired by the 440 System. See section 5.3.3.3 "External Output" on...
Page 71: Figure 5-2: System Configuration Wizard - Summary
5 – Operating Software Figure 5-2: System Configuration Wizard - Summary DeepView will now be configured to operate with the 440 System. Before clicking on ‘Finish’ you have tick options to select:- ❐ Show the pre-dive checklist when the System Configuration Window is closed.
Page 72: System Parameters
5.2.3 System Parameters The following items are key parameters that must be set prior to and during the survey. These will enable 440 to find the position of the target. To carry out an accurate survey, these parameters must ➥...
Page 73: Threshold
Set an appropriate value for threshold. High settings will make the 440 System less sensitive to noise but will also decrease its operating range. The default setting of 15µV has proved to be suitable for the majority of survey operations.
Page 74 The exact algorithm used to determine range is beyond the scope of this manual, since correcting for the exact nature of the coil response is complex. © Teledyne TSS DPN 402196 Issue 4.1...
Page 75: Print Configuration
5 – Operating Software 5.2.4 Print Configuration It is important to print details of the 440 System configuration at the start and end of a survey. ➥ Select File Print Configuration to send a copy of the System Configuration to the Windows Notepad application.
Page 76: Operating Deepview For Windows
5 – Operating Software 5.3 Operating DeepView for Windows Teledyne TSS TSS designed DeepView for Windows to provide full functionality when you use a pointing device. The SDC10 utilises touch-screen technology to select commands and controls within DeepView via the touch-screen panel and software keyboard (a shortcut is locate on the SDC desktop).
Page 77: Menu Commands
Print Configuration Use this command to send a copy of the 440 System configuration to win- dows Notepad. You should print the configuration details from that appli- cation at the start of the survey and again at the end of the survey. Retain the hard copy prints with the survey records.
Page 78 Toggle Height Scale Use this command to modify the available selection of displayable vertical [Ctrl + H] ranges. The vertical ranges vary between the 440 and the 440 systems and are as follows: 440 mode: 0m to 2m, 5m, 15m or 30m 440 mode: 0m to 2m and 0m to 5m.
Page 79 Pre-dive Checklist Use this command to open the on-line Help structure that explains the [ALT][H][P] checks you should make on the 440 System before you start a survey. 6-4. You may section 6.2 "Pre-dive Checks" on page access the checklist from within the DeepView Help structure.
Page 80: View Menu
5.3.2 View Menu 5.3.2.1 Run Window The Run Window is the most important and informative display of the 440 System. Anyone who will operate or maintain the system should therefore spend some time to make themselves familiar with the layout of the window and the information that it shows.
Page 81 (ALT) above the seabed F, lateral offset (LAT) of the target relative to the centre line G, vertical range to the target (VRT) H and target depth of cover (COV) I. The 440 System measures VRT and LAT directly, with positive measurements of LAT representing a starboard offset relative to the centre line.
Page 82: Toggle Height Scale
For example, if a small target is being tracked a reduced height scale may be required. This feature provides the user with control over the displayed height range. The vertical ranges for the 440 System are either 0m to 2m or 0m to 5m. 5-16 ©...
Page 83: Toggle Swath Width
‘spectrum analyser’ displays. (The spectrum analyser feature applies to the 350 System only). Figure 5-6: Scope Window The above screen shows an example of the 440 Oscilloscope Window with panels for the three active channels, Port, Centre and Starboard. During operation each of these display panels shows the signal voltage measured on their respective channels against a horizontal time scale and a vertical scale of percentage of full scale.
Page 84: System Errors Window
The System Errors window, shown in Figure 6-5, displays a list of all errors and events reported by the 440 System. The list includes cleared and uncleared errors. The window can include up to 600 lines of text, with a scroll bar that allows you to search through the list. When the list includes 600 lines of text, DeepView for Windows will delete the oldest message in the list to provide space for any new ones.
Page 85: Terminal Window
It has a toolbar, a client area that displays black text against a white background, and a status bar. The figure shows the Terminal Window displaying data packets from the 440 SEP in the client area. If you select the altimeter as the active serial device, the client area will show data packets from this device instead.
Page 86: Video Overlay Enable
To view data transmitted by an altimeter connected to an SDC serial communication port, use the Terminal Window described in sub-section section 5.3.2.6 "Terminal Window" on page 5-19. Figure 5-9: Altimeter Configuration 5-20 © Teledyne TSS DPN 402196 Issue 4.1...
Page 87: Table 5-4: Altimeter Configuration Parameters
The Altimeter Configuration Window allows you to select an SDC serial communication port that you will use to accept data from the altimeter and to set its communication parameters. Note that the 440 and 440 systems can have different offsets. Although a single altimeter is present, its height above the 440 and 440 coils will be different.
Page 88: Figure 5-10: Altimeter Test
5 – Operating Software Figure 5-10: Altimeter Test 5-22 © Teledyne TSS DPN 402196 Issue 4.1...
Page 89: External Output
5 – Operating Software 5.3.3.3 External Output DeepView for Windows allows you to record the survey data acquired by the 440 System. ➥ To edit these settings, select Configuration External Output. Note external logging is defaulted to on. Figure 5-11: External Output Configuration and Serial Port menu...
Page 90: Load Factory Defaults
External Output Packet Coords + signal, 4/second Altimeter Comms Parameters COM port not specified, 9600, 8, n, 2 Altimeter Type Disabled Altimeter Offset Seawater Rejection Enabled, 10-25C Target Scaling 1277uV Target Weight Coating 5-24 © Teledyne TSS DPN 402196 Issue 4.1...
Page 91: Video Overlay Setup
VRT and target position, are overlaid. The positions and colours of each of these elements can be fully controlled by the user. Figure 5-12: Video Overlay Setup DPN 402196 Issue 4.1 © Teledyne TSS 5- 25...
Page 92: Toolbars
A tooltip appears to remind you of the button functions if you hover the pointer over a button, with the same information also appearing in the status bar. You may also access some of the button 5-26 © Teledyne TSS DPN 402196 Issue 4.1...
Page 93: Table 5-7: Deepview Toolbar
Run Window. See section 5.3.5 "Function Keys" on page 5-28 for a list of all the available function keys that you may use in the 440 mode. Table 5-7: DeepView Toolbar Function...
Page 94: Function Keys
Run Window. See section 5.3.5 "Function Keys" on page 5-28 for a list of all the available function keys that you may use in the 440 mode. Table 5-8: Run Window Toolbar Button...
Page 95: After The Dive
After you recover the ROV, perform all the post-survey checks and make any necessary repairs to the 440 System before you store it. This helps to ensure the System will be ready for immediate deployment when needed again. Use a fresh water hose to wash deposits of salt and debris off the System.
Page 96: Replaying A Log File
Goto time Function key Help button 5.6 Quality Control The Quality Control function of the 440 System defines an envelope within which the measurements meet the specifications for accuracy listed in Chapter 8 "System Specifications". Whenever the co-ordinates of the target fall outside the limits of the Quality Control envelope, the following occurs: ❐...
Page 97: System Recovery Procedure
SDC10 and restart it by disconnecting and then reconnecting power, or by pressing the power reset On-Off button. ❐ If closing and restarting the SDC10 does not resolve the problem, reinstall the Teledyne TSS DeepView for Windows software (see section 5.8 "Reinstall DeepView for Windows Proce- dure"...
Page 98: Required Equipment
1. Close down the SDC10 by disconnecting the power cable. 2. Remove the USB port dust cover caps on the front of the Panel PC and attach the Teledyne TSS SDC10 recovery USB pen drive and a USB keyboard.
Page 99: Figure 5-17: Power Reset Button
4. Use the arrow keys to select the USB drive. The name of the drive may be different from the one shown in Figure 5-18. Press the Enter key on your keyboard to continue. You will see a blank screen. DPN 402196 Issue 4.1 © Teledyne TSS 5- 33...
Page 100: Figure 5-19: Windows Setup In Progress
5. Immediately press the Enter key for a second time. Figure 5-19: Windows Setup in progress 6. The Windows Setup programme displays a progress bar (Figure 5-19). Figure 5-20: Automated recovery screen 5-34 © Teledyne TSS DPN 402196 Issue 4.1...
Page 101: Figure 5-21: Select Start Recovery Command
5-21). NOTE If you have any difficulties with the system recovery procedure please do not use the contact details on the Automated System Recovery screen and instead con- tact Teledyne TSS. DPN 402196 Issue 4.1 © Teledyne TSS 5- 35...
Page 102: Figure 5-22: Confirm Recovery
8. On the confirmation dialog use the arrow keys on your keyboard to select Yes and press Enter (Figure 5-22). While the Reinstall Procedure is running the system displays a progress bar (Figure 5-23). Figure 5-23: Recovery in progress 5-36 © Teledyne TSS DPN 402196 Issue 4.1...
Page 103: Reinstall Deepview For Windows Procedure
5.9 PC Software Installation Teledyne TSS TSS supplies a USB pen drive (memory stick) containing the DeepView for Windows software with the 440 System. This is in addition to the USB pen drive for system recovery (see section 5.7 "System Recovery Procedure" on page 5-31).
Page 104 ‘My Computer’ and the respective drive for your USB port. Within the contents of the USB pen drive you will find the setup program which automatically installs the software. 3. To use DeepView for Windows, double click on the Teledyne TSS icon that the installation pro- gramme places on your Windows 7 desktop.
Page 105: Operating Procedure
440 System. By making this decision early in the planning procedure, they can assign the correct equipment and personnel to the operation. Contact Teledyne TSS for advice if you are unsure whether the 440 System is suitable for use in a particular survey application.
Page 106: Training And Availability
Teledyne TSS 440 Pipe and Cable Survey System. Ensure that a 440 System in good working order will be available at the time of the survey operation. 6.1.2 Target Scaling The 440 System features a simple and quick method to set the target scaling factor automatically for a particular target type and size.
Page 107: Data Collection
By prior arrangement, Teledyne TSS can perform this service before the survey using a suitable 5-metre sample length of target.
Page 108: Pre-Dive Checks
DeepView for Windows has a comprehensive Help structure written specially for it. The Help structure includes a set of pre-dive checks that you should perform before you deploy the 440 System underwater. You may configure DeepView for Windows to display a summary of these checks automatically after you complete the System Configuration Wizard.
Page 109: Coil Installation
This position also provides better protection for the coils. ❐ Cables. Use plastic cable ties to secure the cables to the ROV frame. Make certain the cables cannot move providing a false target during survey operations. DPN 402196 Issue 4.1 © Teledyne TSS 6- 5...
Page 110 Altimeter. Do not attach any altimeter to the coil array. Measure the vertical offset distance between the coils and the transducer face of the altimeter. Use this distance to configure the 440 SEP. © Teledyne TSS DPN 402196 Issue 4.1...
Page 111: Electrical
6.3 Survey Operations This sub-section is of special interest to personnel who will operate the 440 System during a survey. It explains how to use the System correctly. Before you start a survey that uses the 440 System: ❐...
Page 112 9. Print the configuration and retain a copy with the survey records. Pre-dive Checks 10. Power-on the 440 System thirty minutes before you deploy the ROV. If practical, perform a tar- get detection test. 11. Use the SDC oscilloscope display and check for correct waveforms on all channels.
Page 113 NOTE A “Flick” in the target voltages occurs at approx. 4m above the seabed, this is not a fault in the 440 System or its configuration. Data Logging 18. Log all survey data including the regular background compensation, seawater compensation checks and Background Noise Profile check.
Page 114: Establishing The Survey Configuration
6.3.1 Establishing the Survey Configuration 6.3.1.1 Target Scaling Target scaling is the method used by the 440 System to determine the relationship between the coil signal strength and the range to the target. It allows the System to know whether a specific signal level comes from a small target close to the coils or a larger one farther away.
Page 115: External Logging Format
Enter a positive value if the altimeter is higher on the ROV than the search-coils. If you have no altimeter fitted to the 440 System and your ROV allows you to set the coils at a fixed altitude above the seabed, enter the fixed altitude value.
Page 116: Coil Mapping
System configuration with the survey log. 6.3.2 Pre-dive Checks You should perform these important functional checks on the 440 System before you deploy the ROV. Note that you may display a list of the recommended pre-dive checks by pressing [F8] from the Operation Menu.
Page 117: Coil Insulation Test
ROV off the deck. Power-on the 440 System and allow a period of about five minutes for the System to settle. If the ROV is resting on the deck of the survey vessel, the proximity of the deck and other metal fittings will cause the search-coils to saturate.
Page 118: Background Compensation And Monitoring
6 – Operating Procedure 6.3.3 Background Compensation and Monitoring To ensure that information acquired by the 440 System is accurate, you must perform the full background compensation 20 minutes after you immerse the System in water and turn on the for the dive.
Page 119 System completes its final set of measurements. The background compensation results used by the 440 System are those included in the last line on the display. Examine the columns of figures that appear under each of the three channels. Within each of the used channels, the column of figures should all be the same within ±5µV.
Page 120: Seawater Compensation
6.3.4 Seawater Compensation The 440 system is based on being able to separate the different signals arising from seawater and target. This allows the range to the target to be determined from two coils. This is achieved by means of a signal processing routine, which differentiates the target signal from the unwanted seawater signal on the basis of its slower decay rate.
Page 121 If you have connected an altimeter to the System, the SDC determines the state of target burial by performing the simple calculation: COV = VRT – ALT A positive value for COV indicates that the target is covered. DPN 402196 Issue 4.1 © Teledyne TSS 6- 17...
Page 122 Left/Right Tracking occurs when the 440 system is able to calculate a valid lateral offset but unable to calculate a valid vertical offset. This condition will set the Quality Code to ‘99’ and the Quality Flag will be SET.
Page 123: Data Logging
The survey log should therefore include: ❐ The data logged to an external logger ❐ The video recording of the 440 System installation and configuration procedures (if one has been made) ❐ The video recordings from cameras on board the ROV DPN 402196 Issue 4.1...
Page 124: Replay Logged Data
The file includes target co-ordinates, signal values and important quality control information generated by the 440 System during the survey. You should use this logging method to generate the primary survey recording.
Page 125: Data Quality
6.4 Data Quality 6.4.1 Profile During post-processing you may use the data acquired by the 440 System to plot additional information onto the target profile. Similarly, you may use the additional quality control information contained in the data packets to modify the way that the profile of the target appears on the chart: ❐...
Page 126: Figure 6-1: Example Of A Target Profile Modified Using Quality Control Information
6 – Operating Procedure Figure 6-1: Example of a target profile modified using quality control information 6-22 © Teledyne TSS DPN 402196 Issue 4.1...
Page 127: External Logging Format
‘Target Scaling’ feature of the software, VRT measurements will be to the top of the weight coating. There are several conditions that will cause the field to contain ‘???’: ❐ The target is out of range DPN 402196 Issue 4.1 © Teledyne TSS 6- 23...
Page 128 Although the VRT measurements displayed and logged will be valid to the top of the weight coating, the 440 System always measures to the top of the conductive part of the target. The SDC compensates for the thickness of any weight coating and outputs the corrected value.
Page 129: Table 6-2: External Co-Ordinates And Signals Format - Mm Resolution
Coil saturation has occurred NOTE Although the VRT measurements displayed and logged will be valid to the top of the weight coating, the 440 System always measures to the top of the conductive DPN 402196 Issue 4.1 © Teledyne TSS...
Page 130: Table 6-3: Qc Check Code Meaning - External Logging Format
There are several conditions that will cause the field to contain ‘????’: ❐ The target is out of range ❐ The 440 System cannot compute an accurate position for the target ❐ Coil saturation has occurred ❐ There is no fixed coil height or information available to the SDC from an altimeter 8.
Page 131: Figure 6-2: Quality Code Areas
Figure 6-2: Quality Code Areas NOTE When Left/Right Tracking, the Quality Code will be set to ‘99’. Port Centre Starboard Coil 3 Coil 2 Coil 1 TARGET Figure 6-3: Vertical range and offset distances DPN 402196 Issue 4.1 © Teledyne TSS 6- 27...
Page 132: Figure 6-4: Vertical Range With Weight Coating Thickness
‘Target Scaling’ feature of the software, VRT measurements will be to the top of the weight coating. If milli- metre resolution is used the field length will be increased by one character to 6-28 © Teledyne TSS DPN 402196 Issue 4.1...
Page 133: Table 6-5: Timestamped Coordinates Format
Although the VRT measurements displayed and logged will be valid to the top of the weight coating, the 440 System always measures to the top of the conductive part of the target. The SDC compensates for the thickness of any weight coating and outputs the corrected value.
Page 134: Internal Logging Format
The values in the packet are rounded and it is possible that they will not precisely match those on the Run Display screen. Table 6-6: Internal Co-ordinates format 6-30 © Teledyne TSS DPN 402196 Issue 4.1...
Page 135: Table 6-7: Internal Signals Format
❐ The Start character is a colon – ASCII 3Ah. ❐ The number of coils fitted to the 440 System is always 3. ❐ Coil altitude (ALT) information comes from an altimeter if the System includes one. Otherwise this field will contain three space characters and a zero.
Page 136: Background Noise Profile Logging Format
The Signals Data packet is in the standard internal signals format (see Table 7-5) except for the start character (ASCII 3Ah) and Event Identification char- acter are comma separated from the following fields. 6-32 © Teledyne TSS DPN 402196 Issue 4.1...
Page 137: Target Scaling
D.1 "Target Scaling Procedure" on page D-3. Make a note of the value suggested by the 440 System for the target scaling factor and use this as the first estimate in the scaling process. Determining the nominal Target Scaling factor Position the target under the centre of the search-coils, and ensure that the target and the coil array are mutually at right angles.
Page 138 6 – Operating Procedure If the vertical ranges shown by the 440 System are greater than the actual vertical range, reduce the value for target scaling factor, and vice versa. Repeat the tests using the new value for target scaling factor –...
Page 139: Altimeter Data Format
0.17m with 10° of roll applied to the ROV. Vertical measurements made by the 440 System are relatively unaffected by small angles of roll. Under the conditions described in the above example, the vertical measurement will contain an error of only 15mm.
Page 140: Datasonics Psa 900 And Psa 9000
6.6.2 Datasonics PSA 900 and PSA 9000 The transmission formats for the Teledyne TSS altimeter, and the Datasonics PSA 900 and PSA 9000 are identical. They transmit data at 2400 baud using 7 data bits, 1 start bit, 1 mark bit and 1 stop bit.
Page 141: Osel Bathymetric System
2. The contents of these output data fields are set externally and have no effect on operation of the 440 System. 6.6.5 OSEL Bathymetric System The OSEL Bathymetric system transmits data at 9600 baud using 8 data bits, 1 stop bit and no parity.
Page 142: Tritech Seaking Bathy 704
OSEL altimeter and the SDC must therefore be bi-directional. The SDC transmits the interrogating character automatically when configured to use the OSEL altime- ter. 6.6.6 Tritech SeaKing Bathy 704 The SeaKing Bathy system transmits data continuously using RS232 communications at 9600 baud. 6-38 © Teledyne TSS DPN 402196 Issue 4.1...
Page 143: Table 6-15: Tritech Seaking Bathy Format
For example, if the count were 162712, then: Altitude = ((162712 × 200ns) × 1475)  2 = 24.000 metres This is the true distance from the transducer face of the altimeter to the seabed. DPN 402196 Issue 4.1 © Teledyne TSS 6- 39...
Page 145: Operational Considerations
The logged data packets include a Quality Control flag to identify data that might show degraded accuracy. You may use all the information and facilities available from the 440 System to identify any drop in System performance so that you may take effective and appropriate corrective action.
Page 146: Rov Handling
You operate the ROV so that, as far as possible, the target remains positioned centrally beneath the coil array. It is important also to recognise that, under the above conditions, these errors affect only the depth of cover measurements. © Teledyne TSS DPN 402196 Issue 4.1...
Page 147: Trim
0.17 metres with 10° of roll applied to the ROV. Measurements of VRT performed by the 440 System will remain relatively unaffected by small angles of roll. Under the conditions described in the above example, the vertical measurement will contain an error of only 15mm caused by the ROV attitude.
Page 148: Skew
ROV is surveying a partially covered pipe at the bottom of a shallow trench. Low spoil heaps created by the action of a trenching plough mark the two sides of the trench. © Teledyne TSS DPN 402196 Issue 4.1...
Page 149: Figure 7-4: Effects Of Altimeter Mounting Position
7 – Operational Considerations Heads of scanning profiler 440 coil array VRT measured Seabed measured by 440 System by scanning profiler Mean Seabed Level Altimeter A Depth of Cover to the top of the target Altimeter B Depth of Cover to the bottom of the trench...
Page 150: Electrical Interference
Appendix A describes the principle of Pulse Induction used by the 440 System. This method detects and locates any conductive material within range of the coil array. Normally, the conductive material will be a valid target and the 440 System will supply data concerning its location and depth of cover with no loss of accuracy.
Page 151: Power-Carrying Cables
7.3 ROVs You may use the 440 System with most types and size of ROV, and you may operate it at depths down to its specified depth rating listed in Chapter 8 "System...
Page 152: Speed Of Operation
7.3.2 Altitude above the Seabed The vertical detection range of the 440 System is limited by the characteristics of the target, in particular its size. The low signal strength that the System receives from a small target will reduce its detection range. If you use the System to survey a small target you should therefore operate the ROV as near as possible to the seabed, while avoiding damage.
Page 153: Tracked Rov
You must then perform a background compensation procedure before you continue the survey. 7.3.4 Tracked ROV You may install the 440 System on tracked ROVs. This type of ROV should allow you to set a fixed coil height. DPN 402196 Issue 4.1 ©...
Page 155: System Specifications
8 – System Specifications 8 System Specifications Along with a detailed specification of the 440 System and its major assemblies, this section of the Manual also includes examples to show the measurement performance that the System can deliver under ideal operating conditions.
Page 156: Specifications
10% to 95% R.H. non-condensing at 40 Vibration resistance: 5 to 17Hz 2.5mm double amplitude displacement. 17 to 500Hz 1.5g peak-to-peak Ingress protection: IP65 8.1.2 Sub-sea Electronics Pod Size: Ø148 × 468mm* {Ø5.83 × 18.43 inches*} © Teledyne TSS DPN 402196 Issue 4.1...
Page 157: Sub-Sea Power Supply Pod
Maximum power demand 2.8A Operating temperature 0° to 30°C {32°F to 86°F} Depth rating (aluminium) 3000 metres {9842 feet} (stainless steel) 6000 metres {19684 feet} Finish (aluminium) Hard black anodised aluminium (stainless steel) Polished DPN 402196 Issue 4.1 © Teledyne TSS 8- 3...
Page 158: Search Coil Array
Weight: In air 15kg {33.07 pounds} each In water 4.75kg {10.47 pounds} each Depth rating: 6000 metres {19684 feet} Material: High density polyethylene (HDPE) SEP connection cable: 4 metres (6 metre option available) © Teledyne TSS DPN 402196 Issue 4.1...
Page 159: Performance
8 – System Specifications 8.2 Performance The following tables show the results of tests performed by Teledyne TSS using 5 metre lengths of sample targets. They illustrate the range and accuracy that you may achieve under ideal conditions by following the procedures described in Chapter 6 "Operating Procedure"...
Page 160: Table 8-1: Standard Pipeline Diameter = 0.27M (10 Inch)
8 – System Specifications Table 8-1: Standard pipeline diameter = 0.27m (10 inch) True Lateral Offset (±cm) Vertical Range Target Scaling = 1400µV Threshold = 15µV © Teledyne TSS DPN 402196 Issue 4.1...
Page 161: Table 8-2: Standard Pipeline Diameter = 0.11M (4 Inch)
8 – System Specifications Table 8-2: Standard pipeline diameter = 0.11m (4 inch) True Lateral Offset (±cm) Vertical Range Target Scaling = 420µV Threshold = 15µV DPN 402196 Issue 4.1 © Teledyne TSS 8- 7...
Page 162: Table 8-3: Cable Diameter = 0.025M (1 Inch)
True Lateral Offset (±cm) Vertical Range Target Scaling = 26µV Threshold = 15µV Table 8-4: Umbilical diameter = 0.11m (4 inch) True Lateral Offset (±cm) Vertical Range Target Scaling = 550µV Threshold = 15µV © Teledyne TSS DPN 402196 Issue 4.1...
Page 163: Update Rate
Update rates available from independent seabed profiling systems may be different from the update rate you have set for the 440 System. If your ROV includes both these systems, you must allow for their different update rates when you analyse the survey data.
Page 165: Maintenance
9 Maintenance You will find it easier to identify and clear a fault on the 440 System if you have a full understanding of the location of the individual sub-assemblies, and of the way they interact. This section helps you to maintain and service the System by describing the main internal components of the sub-sea installation.
Page 166: Power Supply Pod
Power for the sub-sea installation comes from the ROV electrical supply. Normally this will be nominal 110V single phase AC rated at 350VA. For special applications, Teledyne TSS can supply the 440 System with a PSU that accepts nominal 240V AC instead.
Page 167: Filter Assembly
SEP unit. NOTE When opening the sub-sea housing Teledyne TSS recommend that you use screws inserted into the drilled holes to jack the endcap off. Under no circum- stances should a screwdriver (or similar) be used to lever the endcap off as this will result in damage to the o-ring seal and the casing.
Page 168: Sub-Sea Electronics Pod
An LC filter smoothes the current drawn from the PSU to an approximately continuous level (not RMS) of 7A (with three search-coils attached). 9.1.2.3 Analogue Board (See drawing 401071 in Section Chapter 10 "System Drawings") © Teledyne TSS DPN 402196 Issue 4.1...
Page 169: Communications Loop
When you configure the System to use the 2-wire current-loop communications method, the SEP and the SDC share a twisted pair in the umbilical. To avoid possible contention, the 440 System assigns ‘Master’ status to the SDC, and ‘Slave’ status to the SEP.
Page 170: Surface Display Computer
Many components within the SDC are susceptible to damage due to electrostatic discharge. You must take precautions against such damage: These precautions include the use of a grounded conductive mat and wrist-strap. Teledyne TSS will not accept responsibility for any damage caused by failure to take such precautionary measures.
Page 171 11. The Main Board is located on one side of the central support block, and the Driver Board and the Analogue Board are located together on the other side. DPN 402196 Issue 4.1 © Teledyne TSS 9- 7...
Page 172: Power Supply Pod
SEP. Note that a partial vacuum may form inside the PSU as you remove the end-cap and this may make removal difficult. Do not insert any hard or sharp instruments into the gap to act as a lever. © Teledyne TSS DPN 402196 Issue 4.1...
Page 173: Fault Identification
9.3 Fault Identification The remainder of this section includes advice and a series of flow charts to help you locate a fault in the sub-sea components of the 440 System. The SDC oscilloscope function is a powerful fault identification tool.
Page 174 9 – Maintenance If your System fails, perform the following checks before you call Teledyne TSS engineers for assistance. 1. Check that you have installed the 440 System correctly according to the instructions in Chap- ter 3 "Physical Installation" Chapter 4 "Electrical Installation".
Page 175: Fault On Single Channel Only
See sub-section 10.2.2 Check connections and wiring to the Driver Board Is the Repair or renew the wiring connector wiring. good? Go to CHART 2 Figure 9-4: Single channel failure – CHART 1 DPN 402196 Issue 4.1 © Teledyne TSS 9- 11...
Page 176 Driver PCB WARNING Dangerous voltages exist in this area of circuitry. You must disconnect power from the System before you perform work in these areas. Figure 9-5: Single channel failure – CHART 2 9-12 © Teledyne TSS DPN 402196 Issue 4.1...
Page 177: Current Loop Communications Failure
SEP operates ±20% power supply source from a 240V supply Power-off the System Reconnect the SEP Power/Comms cable Go to CHART 2 Figure 9-6: Communications failure – CHART 1 DPN 402196 Issue 4.1 © Teledyne TSS 9- 13...
Page 178 Pin 7 (+) and Pin 6 (-) good? Renew the Power Supply PCB Is -15V present? Renew the filter assembly Go to CHART 3 From CHART 3 Figure 9-7: Communications failure – CHART 2 9-14 © Teledyne TSS DPN 402196 Issue 4.1...
Page 179 Power-on the System Check the supply LEDs on the Driver PCB Check wiring and LEDs supply voltages Change the faulty PCB Go to CHART 4 Figure 9-8: Communications failure – CHART 3 DPN 402196 Issue 4.1 © Teledyne TSS 9- 15...
Page 180: Figure 9-9: Communications Failure - Chart 4
D1 D3 D4 D1 D4 Check cable continuity Renew the Main PCB and repeat target scaling Check communications Comms Re-assemble the SEP Go to CHART 5 Figure 9-9: Communications failure – CHART 4 9-16 © Teledyne TSS DPN 402196 Issue 4.1...
Page 181: Altimeter Failure
Figure 9-10: Communications failure – CHART 5 9.3.3 Altimeter failure. These flow charts should help you to identify a fault with the Teledyne TSS ALT250 altimeter connected directly to the SEP. If a fault develops when you use an alternative altimeter connected to SDC ‘ALTIMETER’ (COM2), select COM2 from the terminal mode and check the data strings against those listed in section 6.6...
Page 182 Press OK to end test altimeter Altimeter is good updating? Check correct altimeter type is selected Refer altimeter manual Go to CHART 2 Contact TSS for advice Figure 9-11: Altimeter failure – CHART 1 9-18 © Teledyne TSS DPN 402196 Issue 4.1...
Page 183 Contact TSS for advice See sub-section 10.2.2 Disassemble the SEP for SEP disassembly Check wiring to end-cap wiring Repair/renew wiring Renew the SEP Driver Board Figure 9-12: Altimeter failure – CHART 2 DPN 402196 Issue 4.1 © Teledyne TSS 9- 19...
Page 184: Unexpected Signal Variation During Normal Operation
Compensation Section 6. Lift ROV off the sea-bed to 3m Signal increase less than or equal to 10 µV System OK Go to Chart 2 Figure 9-13: Signal shifts – CHART 1 9-20 © Teledyne TSS DPN 402196 Issue 4.1...
Page 185 Check if signal variations are below 10 µV Variations Continue the survey below 10 V? µ operation Go to Chart 3 Figure 9-14: Signal shifts – CHART 2 DPN 402196 Issue 4.1 © Teledyne TSS 9- 21...
Page 186 Continue the Signal variations survey operation less than 50 V µ Check background compensation regularly Contact Teledyne TSS for assistance Contact VT TSS for assistance Figure 9-15: Signal shifts – CHART 3 9-22 © Teledyne TSS DPN 402196 Issue 4.1...
Page 187: System Drawings
10 – System Drawings 10 System Drawings The following sub-sections contain all the electrical and mechanical drawings relevant to the 440 Pipe and Cable Survey System. 10.1 Electrical Drawings Table 10-1: Electrical Drawings Drawing Description Number 490232 – 1 Sub-sea Electronics Pod (Aluminium and Stainless Steel) 401178 –...
Page 188: Figure 10-1: 490232-1 Sub-Sea Electronics Pod
10 – System Drawings Figure 10-1: 490232-1 Sub-sea Electronics Pod 10-2 © Teledyne TSS DPN 402196 Issue 4.1...
Page 189: Figure 10-2: 401178-1 Main Board
10 – System Drawings Figure 10-2: 401178-1 Main Board DPN 402196 Issue 4.1 © Teledyne TSS 10- 3...
Page 190: Figure 10-3: 401178-2 Main Board - Processor
10 – System Drawings Figure 10-3: 401178-2 Main Board - Processor 10-4 © Teledyne TSS DPN 402196 Issue 4.1...
Page 191: Figure 10-4: 401178-3 Main Board - Analogue Ad & Da
10 – System Drawings Figure 10-4: 401178-3 Main Board - Analogue AD & DA DPN 402196 Issue 4.1 © Teledyne TSS 10- 5...
Page 192: Figure 10-5: 401178-4 Main Board - Timing And Comms
10 – System Drawings MACHN STATE Figure 10-5: 401178-4 Main Board - Timing and Comms 10-6 © Teledyne TSS DPN 402196 Issue 4.1...
Page 193: Figure 10-6: B929935-1 Main Board - Piggy-Back Board
10 – System Drawings Figure 10-6: B929935-1 Main Board - Piggy-back board DPN 402196 Issue 4.1 © Teledyne TSS 10- 7...
Page 194: Figure 10-7: 401181-1 Driver Board
10 – System Drawings Figure 10-7: 401181-1 Driver Board 10-8 © Teledyne TSS DPN 402196 Issue 4.1...
Page 195: Figure 10-8: 401181-2 Driver Board - Control
10 – System Drawings DS[1..2] Figure 10-8: 401181-2 Driver Board - Control DPN 402196 Issue 4.1 © Teledyne TSS 10- 9...
Page 196: Figure 10-9: 401181-3 Driver Board - Mosfets
10 – System Drawings Figure 10-9: 401181-3 Driver Board - MOSFETS 10-10 © Teledyne TSS DPN 402196 Issue 4.1...
Page 197: Figure 10-10: 401071-1 Analogue Board
10 – System Drawings Figure 10-10: 401071-1 Analogue Board DPN 402196 Issue 4.1 © Teledyne TSS 10- 11...
Page 198: Figure 10-11: 401071-2 Analogue Board - Control
10 – System Drawings Figure 10-11: 401071-2 Analogue Board - Control 10-12 © Teledyne TSS DPN 402196 Issue 4.1...
Page 199: Figure 10-12: 401071-3 Analogue Board - Pre-Amps
10 – System Drawings Figure 10-12: 401071-3 Analogue Board - Pre-amps DPN 402196 Issue 4.1 © Teledyne TSS 10- 13...
Page 200: Figure 10-13: 401050-1 Psu Filter Assembly
10 – System Drawings Figure 10-13: 401050-1 PSU Filter Assembly 10-14 © Teledyne TSS DPN 402196 Issue 4.1...
Page 201: Figure 10-14: 490228-1 Power Supply Pod - 110V Version
10 – System Drawings $66(0%/< ),/7(5 Figure 10-14: 490228-1 Power Supply Pod - 110V Version DPN 402196 Issue 4.1 © Teledyne TSS 10- 15...
Page 202: Mechanical Drawings
601203 - 1 Benthos Altimeter Cable Assembly – 3.0m standard 500268 - 1 440 Pipe and Cable Survey System Complete Assembly 500270 - 1 * Stainless Steel Drawing Numbers included in this table for information only. For details and specification see the corresponding Standard Product Drawing Numbers.
Page 203: Figure 10-15: Sdc10 Dimensions
10 – System Drawings Figure 10-15: SDC10 Dimensions DPN 402196 Issue 4.1 © Teledyne TSS 10- 17...
Page 204: Figure 10-16: 400604-1 Power Supply Chassis Assembly
10 – System Drawings Figure 10-16: 400604-1 Power Supply Chassis Assembly 10-18 © Teledyne TSS DPN 402196 Issue 4.1...
Page 205: Figure 10-17: 400667-1 Main Chassis Assembly
10 – System Drawings Figure 10-17: 400667-1 Main Chassis Assembly DPN 402196 Issue 4.1 © Teledyne TSS 10- 19...
Page 206: Figure 10-18: 400667-2 Main Chassis Assembly
10 – System Drawings Figure 10-18: 400667-2 Main Chassis Assembly 10-20 © Teledyne TSS DPN 402196 Issue 4.1...
Page 207: Figure 10-19: 401181-1 Driver Pcb Assembly
10 – System Drawings Figure 10-19: 401181-1 Driver PCB Assembly DPN 402196 Issue 4.1 © Teledyne TSS 10- 21...
Page 208: Figure 10-20: 401071-1 Analogue Pcb Assembly
10 – System Drawings Figure 10-20: 401071-1 Analogue PCB Assembly 10-22 © Teledyne TSS DPN 402196 Issue 4.1...
Page 209: Figure 10-21: 400654-1 Psu Filter Assembly
10 – System Drawings Figure 10-21: 400654-1 PSU Filter Assembly DPN 402196 Issue 4.1 © Teledyne TSS 10- 23...
Page 210: Figure 10-22: 490232-1 Processor Pod Assembly
10 – System Drawings Figure 10-22: 490232-1 Processor Pod Assembly 10-24 © Teledyne TSS DPN 402196 Issue 4.1...
Page 211: Figure 10-23: 490228-1 Power Supply Pod Assembly - 110V Version
10 – System Drawings Figure 10-23: 490228-1 Power Supply Pod Assembly - 110v version DPN 402196 Issue 4.1 © Teledyne TSS 10- 25...
Page 212: Figure 10-24: 500045-1 Coil Mounting Frame
10 – System Drawings Figure 10-24: 500045-1 Coil Mounting Frame 10-26 © Teledyne TSS DPN 402196 Issue 4.1...
Page 213: Figure 10-25: B930892-1 Coil Assembly
10 – System Drawings Figure 10-25: B930892-1 Coil Assembly DPN 402196 Issue 4.1 © Teledyne TSS 10- 27...
Page 214: Figure 10-26: 601004-1 Coil Cable Assembly
10 – System Drawings Figure 10-26: 601004-1 Coil Cable Assembly 10-28 © Teledyne TSS DPN 402196 Issue 4.1...
Page 215: Figure 10-27: B930473-1 Psu To Rov (Pwr/Comms) Cable - 3.0M
10 – System Drawings Figure 10-27: B930473-1 PSU to ROV (PWR/COMMS) Cable - 3.0m DPN 402196 Issue 4.1 © Teledyne TSS 10- 29...
Page 216: Figure 10-28: 601824-1 Teledyne Tss Altimeter 250 Cable Assembly - 3.0M Standard
10 – System Drawings Figure 10-28: 601824-1 Teledyne TSS Altimeter 250 Cable Assembly - 3.0m standard 10-30 © Teledyne TSS DPN 402196 Issue 4.1...
Page 217: Figure 10-29: 601203-1 Benthos Altimeter Cable Assembly - 3.0M Standard
10 – System Drawings Figure 10-29: 601203-1 Benthos Altimeter Cable Assembly - 3.0m standard DPN 402196 Issue 4.1 © Teledyne TSS 10- 31...
Page 218: Figure 10-30: 500268-1 440 Pipe And Cable Survey System Complete Assembly
10 – System Drawings Figure 10-30: 500268-1 440 Pipe and Cable Survey System Complete Assembly 10-32 © Teledyne TSS DPN 402196 Issue 4.1...
Page 219: A Operating Theory
The System uses a simplified scaling procedure that allows a high degree of measurement accuracy and stability. This appendix describes the technique of Pulse Induction, and the method used by the 440 System to derive the signal strength and the target co-ordinates.
Page 220: Waveform Measurement
After the initial voltage peak, the shape of the decaying waveform will depend upon the nature and the proximity of any nearby conductive material. The 440 System uses this feature to determine the range between the coil and the target.
Page 221: Timing
The 440 System waits for a further 100µs to allow the voltage spike to decay and to allow the effects of sea water to dissipate. The System then begins a 1200µs sampling period as shown at Figure A-2(c).
Page 222: Derivation Of Signal Voltage
A – Operating Theory how the 440 System derives the signal voltage from these measurements for use in the calculation process. The SEP applies this measurement cycle to each channel sequentially as shown in Figure A-3. The measurement cycle for each channel lasts a total of 3125µs. With measurements repeated on four channels, it follows that the SEP measures each channel every 12500µs, or 80 times per second.
Page 223: Compensation: How It Works
Figure A-4: Seawater signal The seawater signal, to the 440's search coils, looks similar to a target. This means that as the vehicle is lifted off the seabed, a voltage over and above the target signal is seen. This voltage could easily be interpreted as a change in the target's position.
Page 224: Background Compensation
The “x scale” and “y scale” values can be decreased to zoom in on the graph, but should immediately returned to 150 and 1000µV respectively. This ensures that the © Teledyne TSS DPN 402196 Issue 4.1...
Page 225: Figure A-5: Perfect Lift With The Results Passing Through The Origin
Figure A-8 shows another effect due to the coils moving as the vehicle was lifted. The vehicle was not lifted smoothly, resulting in missing points in the middle of the graph. DPN 402196 Issue 4.1 © Teledyne TSS A- 7...
Page 226: Checking The Rejection
The Teledyne TSS 440 system operates at much greater survey ranges and this places stringent requirements on the background compensation and the rigidity of the coil mounting frame.
Page 227: Rejection Parameters
The format of the Background Noise Profile log file is shown in section 6.4.1.3 "Background Noise Profile Logging Format" on page 6-32. DPN 402196 Issue 4.1 © Teledyne TSS A- 9...
Page 228: Trenching Vehicles
4m. A sudden jump in the target voltages when the ROV is lifted is to be expected, and is not due to a deficiency in the system or its configuration. A-10 © Teledyne TSS DPN 402196 Issue 4.1...
Page 229: Range Determination
The two coil calculation is also able to adapt to the position of the target, using the centre and one other coil at larger lateral ranges. DPN 402196 Issue 4.1 © Teledyne TSS A- 11...
Page 231: B Options
Survey System. Such a System provides all the facilities you will need to survey a target lying on or buried beneath the seabed. For some applications, the 440 System may be more effective if you specify it with one or more of the available options.
Page 232: The Equipment
DeepView for Windows can operate in all modes necessary to use the Dualtrack System. The sub-sea components and the SDC supplied with the Dualtrack System are exactly as described in the relevant parts of the 440 System Manual and the 350 or 350 Powertrack Manual, except for those differences listed in section B.1.2 "The Differences"...
Page 233: Scope Of Delivery
Note that, in a Dualtrack System, you must connect the altimeter only to the ALTIMETER port of the 440 SEP, or to an SDC serial port. Do not connect the altimeter to the 350 or 350 Powertrack SEP. 4 Operation...
Page 234: Figure B-2: Sub-Sea Components Of The Teledyne Tss 350 Or 350 Powertrack Systems
B – Options Figure B-2: Sub-sea components of the Teledyne TSS 350 or 350 Powertrack Systems Figure B-3: Sub-sea components of the Teledyne TSS 440 System Table B-1: Components of the Dualtrack System Item Description Refer to Figure B-1: The SDC includes Surface Display Computer (SDC) pre-loaded with Microsoft Windows™...
Page 235: Physical Installation
Two connection cables with waterproof connectors for the port and the starboard coil triads. Port and starboard coil triads. Teledyne TSS 440-to-350 link cable (Teledyne TSS P/N B930477). The cable is 2.5 metres long and has waterproof connectors at both ends.
Page 236: Sub-Sea Pods
If your System includes coils that have no diode protection (serial numbers below 570), you should ensure that there is a clearance of more than 0.75 metres between the coils of the 440 System and the coils of the 350 System. Contact Teledyne TSS for advice if necessary.
Page 237: Figure B-4: Electrical Interconnection Of Sub-Sea Components
Manual. Route the coil connection cables to the correct ports on the 440 SEP. Use plastic cable clips to secure the cables to the fixed framework of the ROV. 2. Install the altimeter near the centre of the 440 search-coil array as described in section 3.1.4...
Page 238 Connect the 440 System to the 350 System: 7. Use the 440-to-350 Link Cable (Teledyne TSS P/N B930477) to connect the 8-way ‘Power/ Comms’ connector on the 440 PSU to the AUX OUTPUT port on the 350 SEP. This link uses RS232 communications at 9600 baud.
Page 239: System Configuration
5.3 "DeepView For Windows - System Configuration" on page 5-4 of this Manual for instruc- tions to configure the 440 System. Refer to the 350 / 350 Powertrack Manual for instructions to configure that System. IMPORTANT You must select Dualtrack as the SEP type even if you intend to use only one of the Systems during the survey.
Page 240: Forward Search Window
B – Options Contact Teledyne TSS for advice if you wish to upgrade an existing 440 or 350 / 350 Powertrack System to a Dualtrack. 1. Refer to this Manual and the 350 / 350 Powertrack Manual for instructions to use DeepView for Windows in its 440 and 350 and 350 Powertrack modes.
Page 241: Power Supply Requirement
The Teledyne TSS 440 Pipe and Cable Survey System is a precision ‘front line’ survey tool. To exploit the full potential of the System, all personnel involved with a survey that uses the 440 System – from the initial planning stages to final data presentation – should possess a sound understanding of the performance of the System and its application.
Page 243: C Altimeter
B934703 Altimeter mounting kit spares assembly Table C-2: TSS ALT-250 part numbers 500292 Altimeter, subsea Teledyne TSS-ALT-250 - 3000m (no cable or accessories) 500294 As above, detection kit - 3000m (includes bracket 601824A) 500295 Altimeter - 3000m, including 3m pigtail 601826A...
Page 245: D Reference
The following pages contain blank sample copies of forms that you may use to record details about the 440 System before and during a survey. You should complete these forms and include copies with the final survey results to help the post-processing engineers with their survey analyses.
Page 247: Target Scaling Procedure
µV Channel 4 Early µV µV Standard µV µV Water Temperature Medium Cold Compensation Manual Final target scaling Target scaling factor (generated by the ‘Auto Scaling’ facility of the System): µV DPN 402196 Issue 4.1 © Teledyne TSS D- 3...
Page 249: Target Scaling Results
D – Reference D.2 Target Scaling Results Automatic target scaling factor: [ ] µV Nominal True VRT 440 VRT Range error Channel signals (µV) VRT (cm) COL 1 COL 2 COL 1 – COL 2 Starboard Centre Port Optimised target scaling factor: [ ] µV...
Page 251: Performance Envelope Results
V R T V A L U E S D I S P L A Y E D B Y S D C Lateral offset (cm) to port [ ] or to starboard [ DPN 402196 Issue 4.1 © Teledyne TSS D- 7...
Page 253: Survey Details
Initial compensation values early: Centre Starboard Port Initial compensation values standard: Centre Starboard Water temperature: Medium Cold Compensation: Manual Survey Completed by: Teledyne TSS 440 Training Certificate No.: Date of training: DPN 402196 Issue 4.1 © Teledyne TSS D- 9...
Page 255: E Index
Oscilloscope test Replay Depth of target cover See COV Display software 34, 3 Configuration file Pitch effects 8, 12 Default configuration Pre-dive checks Mapping Altimeter test Starting from DOS Coil insulation DPN 402196 Issue 4.1 © Teledyne TSS Page E-1...
Page 256 Coil height Connection Installation Insulation test 7, 8 Location Separation distance 3, 6, 5 6, 7 Altimeter port Analogue board Blanking plugs Circuit description Coil ports 4, 12 Communication method Driver board Page E-2 © Teledyne TSS DPN 402196 Issue 4.1...

This manual is also suitable for:

500268 500269 500270 500271

Teledyne 440 System Manual

Quick Links

Related Manuals for Teledyne 440

Summary of Contents for Teledyne 440
