Audi A8 1994 Service Manual

Motronic injection and ignition system (6-cylinder)
Hide thumbs Also See for A8 1994:
Table of Contents

Advertisement

Quick Links

Download this manual
Service
Audi A8 1994 ➤
Motronic injection and ignition system (6-cylinder)
Engine ID
Edition 02.1999
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Service Department. Technical Information
AQD APR
