La Crosse Technology WS-7059U4 Instruction Manual

Wireless 433 mhz temperature station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WS-7059U
Wireless 433 MHz
Temperature Station
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology WS-7059U4

Summary of Contents for La Crosse Technology WS-7059U4

  • Page 1 WS-7059U Wireless 433 MHz Temperature Station Instruction Manual...

  • Page 2: Table Of Contents

    Topic Inventory of Contents/Additional Equipment About WWVB Battery Installation Program Mode Time Setting (WWVB & Manual) Time Zone Setting Daylight Saving Time Year Setting Setting the Date Selecting °F or °C Setting the Forecast Sensitivity Displaying Relative/Absolute inHg/hPa Manually Setting Relative Air Pressure Setting the LCD Contrast 12 or 24 hour Time Setting Features...

  • Page 3: Inventory Of Contents/Additional Equipment

    Weather Station. However, due to the nature of the Earth’s Ionosphere, reception is very limited during daylight hours. The Weather Station will search for a signal every night when reception is best. The WWVB radio station derives its...

  • Page 4: Battery Installation

    These physicists have created an international standard, measuring a second as 9,192,631,770 vibrations of a Cesium 133 atom in a vacuum. This Weather Station regulates the WWVB transmitter. SET-UP GUIDE I. BATTERY INSTALLATION 1.

  • Page 5: Program Mode

    6:00 am, when there is less atmospheric interference. To keep your time as accurate as possible, the Weather Station conducts a WWVB search every night between these hours, and overrides any time that has been set manually. The WWVB tower icon...
  • Page 6 in progress, will remain steady when the signal has been received, and nothing will be displayed in all other situations. If the WWVB time has not been received after 10 minutes of battery installation, you may manually set the time or leave the time function alone (reception will occur regardless).

  • Page 7: Time Zone Setting

    The default time zone is EST (Eastern Standard Time), to change this setting: 1. Press and hold the MODE/SET button for 5 seconds, or until “Lcd 5” flashes in the TIME LCD. 2. Press the MODE/SET button four more times; “-5” should flash in the TIME LCD. 3.

  • Page 8: Daylight Saving Time

    1. Press and hold the MODE/SET button for 5 seconds, or until “Lcd 5” flashes in the TIME LCD. 2. Press the MODE/SET button 5 more times to reach the DST selection mode. DST 1 is the default setting and both “DST” and “1” are flashing in the TIME LCD.

  • Page 9: Setting The Date

    Note: This is only necessary if you do not wish to wait for the WWVB reception. All manual set data will be over- ridden by the reception of the WWVB signal. 1. Press and hold the MODE/SET button for 5 seconds, or until “Lcd 5”...

  • Page 10: Setting The Forecast Sensitivity

    back. 5. Press the MODE/SET button to confirm and to advance to the Weather Forecast Sensitivity setting. IX. SETTING WEATHER FORECAST SENSITIVITY (hPa) Note: A higher hPa (Hekto Pascal) setting decreases the forecasting sensitivity of the unit, a feature available for persons living in areas where the air pressure changes significantly (not necessarily related to a change of weather).

  • Page 11: Displaying Relative/Absolute Inhg/Hpa

    changes. 5. Press the MODE/SET button to confirm and advance to set the Relative or Absolute display setting. X. DISPLAYING RELATIVE hPa/inHg OR ABSOLUTE hPa/inHg Note: Air pressure can be displayed in four different measures: Relative hPa, Absolute hPa, Relative inHg, and Absolute inHg.

  • Page 12: Manually Setting Relative Air Pressure

    3. The numerals in the PRESSURE LCD will flash (only for relative air pressure) 4. Press the CH/+ to increase the relative air pressure. Refer to your local weather station for an appropriate setting. 5. Press the MODE/SET button to confirm.

  • Page 13: Or 24 Hour Time Setting

    1. Press and hold the MODE/SET button for 5 seconds, or until the “Lcd #" of your choice flashes in the TIME LCD. 2. Press the MODE/SET button once more to reach the 12/24 time setting mode. 3. Press the CH/+ button to toggle between 12 and 24-hour time.

  • Page 14: Features

    I. WEATHER FORECAST The weather forecasting feature is estimated to be 75% accurate. By adjusting the sensitivity setting, you can achieve a better accuracy of forecast. The weather forecast is based solely upon the change of air pressure over time. In areas where the weather is not affected by the change of air pressure, this feature will be less accurate.

  • Page 15: Air Pressure History Bar Graph

    then the weather has not changed or the change has been slow and gradual. If this happens on a regular basis, it may be necessary to adjust the weather forecast sensitivity. 2. WEATHER TENDENCY ARROWS Other possible displays in the TENDENCY LCD are 2 weather tendency arrows, one that points up and one that points down.

  • Page 16: Indoor Temperature/Humidity (Min/Max)

    the graph than the left) then the air pressure has a falling trend, and the weather should worsen. 2 hPa of change equals 0.06 inHg of change. Note: The air pressure history is taken every hour by averaging the last 11 readings (taken every minute). III.
  • Page 17 displayed for a period of 20 seconds before the unit returns to the current time, date, temperature, and humidity readings. 2. VIEWING THE MAXIMUM INDOOR TEMPERATURE AND HUMIDITY Press the MIN/MAX/RESET button twice (once if pressed while “MIN” appears in the INDOOR LCD).

  • Page 18: Optional Outdoor Remote Senders

    SENDERS (OPTIONAL) The WS-7059U is able to receive signals from 3 different Remote Control Senders (RCS). The RCS model(s) that you choose will come with their own set of instructions— follow these instructions for a complete guide to setting up. When the RCS units are set up, INDOOR LCD also becomes the OUTDOOR LCD, however it will only be referenced as the former.
  • Page 19 batteries from all units currently in operation. 2. Remove the battery covers to all RCS units. 3. Place all RCS units in a numeric sequential order (if more than one unit is to be installed). 4. In sequential order, install batteries. 5.

  • Page 20: Mounting

    Temperature Station is able to receive WWVB signals from the desired location. Also, extreme and sudden changes in temperature will decrease the accuracy of the Weather Station, and changes in elevation will result with inaccurate weather forecasting for the next 12 to 24 hours. These changes will require a 12 to 24 hour wait before obtaining reliable data.
  • Page 21 2. Fix a screw (not included) into the desired wall, leaving approximately 3/16 of an inch (5mm) extended from the wall. 3. Place the Indoor Temperature Station onto the screw using the hanging hole on the backside. Gently pull the Station down to lock the screw into place.

  • Page 22: Troubleshooting

    Problem: No reception of WWVB time signal. Solution: 1) Wait overnight for signal. 2) Be sure Weather Station is at least 6 feet from any electrical devices, such as televisions, computers, or other radio-controlled clocks. 3) Remove batteries for five minutes, reinsert and leave alone without pressing buttons overnight.

  • Page 23: Maintenance And Care

    • Extreme temperatures, vibration, and shock should be avoided to prevent damage to the units. • Clean displays and units with a soft, damp cloth. Do not use solvents or scouring agents; they may mark the displays and casings. • Do not submerge in water.

  • Page 24: Specifications

    Radio controlled time signal: WWVB Recommended operating temperature: Weather Station: 32°F to 122°F (0°C to 50°C) LCD contrast: 8 levels Temperature measuring range: Indoor: 32°F to 122°F with 0.2°F resolution. (0°C to 50°C with 0.1°C resolution) (“OFL” displayed if outside this range)

  • Page 25: Warranty Information

    Contact La Crosse Technology immediately upon discovery of any defects covered by this warranty. Before sending the Weather Station in for repairs, contact La Crosse Technology. The Weather Station will be repaired or replaced with the same or similar model.
  • Page 26 THIS PRODUCT IS NOT A TOY. KEEP OUT OF CHILDRE’S REACH. This warranty gives you specific legal rights. You may also have other rights specific to your State. Some States do no allow the exclusion of consequential or incidental damages therefore the above exclusion of limitation may not apply to you.
