ADTRAN U-BR1TE User Manual

Dual plug-in/plug-on option card
Hide thumbs Also See for U-BR1TE:
Table of Contents

Advertisement

Quick Links

Download this manual
Dual U-BR1TE Plug-In Option Card
(Part Number 1200107L1#HS)
and Dual U-BR1TE Plug-On Option Card
(Part Number 1200108L1)
61200107L1#HS-1B
June 2000
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for ADTRAN U-BR1TE

Summary of Contents for ADTRAN U-BR1TE

  • Page 1 Dual U-BR1TE Plug-In Option Card (Part Number 1200107L1#HS) and Dual U-BR1TE Plug-On Option Card (Part Number 1200108L1) USER MANUAL 61200107L1#HS-1B June 2000...
  • Page 2 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 (256) 963-8000 © 2000 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A.
  • Page 3 Notes provide additional useful information. Cautions signify information that could prevent service interrup- tion. Warnings provide information that could prevent damage to the equipment or endangerment to human life.
  • Page 4 If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is cor- rected or it is certain the equipment is not malfunctioning.
  • Page 5 FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equip- ment is operated in a commercial environment.
  • Page 6 CANADIAN EQUIPMENT LIMITATIONS Notice: The Canadian Industry and Science Canada label identifies certified equipment. This certification means that the equipment meets certain telecom- munications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfac- tion.
  • Page 7 WARRANTY AND CUSTOMER SERVICE ADTRAN will replace or repair this product within five years from the date of shipment if it does not meet its published specifications or fails while in service. For detailed warranty, repair, and return information refer to the ADTRAN Equipment Warranty and Repair and Return Policy Procedure.
  • Page 8 Customer or a third party (including, but not limited to, loss of data or informa- tion, loss of profits, or loss of use). ADTRAN is not liable for damages for any cause whatsoever (whether based in contract, tort, or otherwise) in excess of the amount paid for the item.

  • Page 9: Table Of Contents

    Table of Contents List of Figures ......................xi List of Tables ......................xiii Chapter 1. Introduction ..................1-1 Dual U-BR1TE Plug-in and Plug-on Option Cards ..........1-1 Functional Description ..................1-1 Features ....................... 1-2 Dual U-BR1TE Option Card ..............1-2 Physical Description ..................1-3 Chapter 2.
  • Page 10 Table of Contents Appendix A. Dual U-BR1TE Option Card Menu Tree ........A-1 Appendix B. Dual U-BR1TE Failure Messages..........B-1 Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 11: List Of Figures

    Submenus ............3-5 ONFIGURATION Figure 3-6. Network Locations ................3-6 Figure 3-7. P Submenus ..............3-7 TILITY Figure 3-8. P Submenus ................3-7 Figure A-1. Dual U-BR1TE Option Cards Menu Tree ........A-1 61200107L1#HS-1 Dual U-BR1TE Plug-in Option Card User Manual...
  • Page 12 List of Figures Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 13: List Of Tables

    List of Tables Table 2-1. 2-Wire Voice Pinout Connection............2-3 Table 3-1. P Parameters............3-5 ONFIGURATION Table 3-2. P Parameters................3-8 61200107L1#HS-1 Dual U-BR1TE Plug-in Option Card User Manual xiii...
  • Page 14 List of Tables Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 15: Chapter 1. Introduction

    The Dual U-BR1TEs are configured in the same manner as the host multiplexer. The internal menu for the configu- ration of each U-BR1TE is a part of the Dual U-BR1TE Module and is automatically available when the Dual U- BR1TE is installed into the TSU.

  • Page 16: Features

    "downstream" (toward the NT1) direction • Local performance monitoring without test equip- ment Dual U-BR1TE Option Card The Dual U-BR1TE Option Cards conform to the follow- ing specifications: U-Interface Line 2-wire (tip and ring) Rate...

  • Page 17: Physical Description

    This allows a plug-on board to be added to the Dual U-BR1TE Card. The PORT X.Y indication is linked to the port numbering philosophy of the TSU 100 product fam- ily.

  • Page 18: Figure 1-2. Dual U-Br1Te Plug-On Option Card

    1.3 and 1.4. These port numbers appear in the front panel liquid crystal display (LCD) menu displays. The Dual U-BR1TE Plug-on Option Card (see Figure 1-2) is designed to plug on any TSU/DSU plug-in card. Figure 1-2. Dual U-BR1TE Plug-on Option Card...

  • Page 19: Chapter 2. Installation

    Carefully inspect the option module for any shipping damage. If damage is suspected, file a claim immediately with the carrier and contact ADTRAN Customer and Product Service. If possible, keep the original shipping container for use in shipping the option module for repair or for verification of damage during shipment.

  • Page 20: Provided By Customer

    Figure 2-1. Installing the Option Module Power Connection Each option module derives power from the base TSU/ 120/600 unit. Power to the base unit is supplied by a cap- tive eight foot power cord. Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 21: Wiring

    Description Tip lead of 2-wire interface RING Ring lead of 2-wire interface 1, 2, 3, 6, 7, 8 UNUSED Pins used to mate with the Dual U-BR1TE connector are as follows: RJ-11 pin 4 Ring pin 3 RJ-45 pin 5...

  • Page 22: Figure 2-2. Installing Plug-On Board

    Figure 2-2. Installing Plug-on Board The connection of the header pins between the option card and the plug-on board must be visually verified. Severe damage of the device can result from an improper connection. Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 23: Power Up Testing And Initialization

    See the chapter Operation in the main user manual. Failed Self Test If the Dual U-BR1TE card fails one or more of the self tests, a message is displayed in the LCD during power up. See the TSU 100/120/600 user manual. Specific failures of the Dual U-BR1TE Card are identified in the appendix Dual U-BR1TE Failure Messages in this manual.
  • Page 24 Chapter 2. Installation Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...

  • Page 25: Chapter 3. Operation

    Operation Chapter 3 OVERVIEW The Dual U-BR1TE card is controlled as part of the TSU 100/120/600 using the same methods as described in the TSU 100/120/600 User Manual. See the TSU 100/120/600 User Manual for descriptions of front panel indicators and buttons.

  • Page 26: Dual U-Br1Te Menu Items

    Chapter 3. Operation Once the option module is selected, the Dual U-BR1TE menus appear as a subset of, and operate the same as, menus for the TSU 100/120/600. Use the up and down ar- rows to place the cursor on the desired item, and press to display the first two submenu choices.

  • Page 27: Sync

    TATUS place the cursor on it and press to display the first Enter available port. Scroll to select 1.1 U-BR1TE and press Enter to activate either of the submenus shown in Figure 3-2. 1)NI PERF REPORTS STATUS 2)NI ERRORS...

  • Page 28: Figure 3-4. T1 Status Display

    , a submenu of TSU 100/120/600 main ONFIG menu item C , is used to configure the Dual ONFIGURATION U-BR1TE. The submenu items shown in Figure 3-5 on page 3-5 are used to configure the parameters. Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...
  • Page 29 For proper operation, the ZBS (zero byte substitution) for two U-BR1TE ports connected by a T1 facility must be the same value. The ENABLE parameter for ZBS must be se- lected if the T1 is using AMI line coding. If the T1 facility is using B8ZS line coding, the DISABLE parameter may be chosen.

  • Page 30: Figure 3-6. Network Locations

    Chapter 3. Operation The U-BR1TE port should be configured to operate in the MODE LULT mode if being operated in the Adjacent to Customer or Tandem Office Source positions (see Figure 3-6 on page 3-6). The MODE should be set to LUNT if the port is oper- ated in the Adjacent to Switch or Tandem Office Sink po- sitions.
  • Page 31 , a submenu of the TSU 100/120/600 main menu item T , activates tests of the selected data ports. Selecting the Dual U-BR1TE displays tests available for this option card. See Figure 3-8. 1)NETWORK TESTS 1)B1 REMOTE LPBK...
  • Page 32 MOTE LPBK TEST er than the B1 channel. LOCAL The local U-BR1TE may be commanded to loop back ei- ther the B1 or B2 channel. When a channel is put in L LPBK OCAL , it will loop back both the T1 and U-interface OOPBACK data associated with the channel.

  • Page 33: Tsu Features Used With Dual U-Br1Te Options

    PATT ther the T1 (T1_TX) or the U-interface (LP_TX) direction. The pattern may be looped back to the U-BR1TE port and verified with the results viewed by choosing 7)PATT RE- SULTS, or the 2047 pattern may be verified using test equipment at accessible points in the network.
  • Page 34 Chapter 3. Operation stalled default setting for all Dual U-BR1TE option mod- ule parameters. When F is displayed, place the cursor on ACTORY ESTORE it and press . The unit is restored to preset factory de- Enter faults and returns to the main menu. The factory default for port configuration parameters is shown in Table 3-1 on page 3-5.

  • Page 35: Figure A-1. Dual U-Br1Te Option Cards Menu Tree

    Dual U-BR1TE Option Appendix A Card Menu Tree The menu tree for the Dual U-BR1TE Plug-in and Plug-on Option Cards is provided in Figure A-1. 1)Port Status 1)LOOP STATUS 2)T1 STATUS 3)LOOP MONITOR 1)SERVICE 2)Port Config 2)ZBS: 3)MODE 4)WAKE-UP TONE:...
  • Page 36 Appendix A. Dual U-BR1TE Option Card Menu Tree Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...
  • Page 37 Dual U-BR1TE Card: E01 - EPROM CS EPROM checksum error E02 - RAM DATA Data Bus Failure E03 - RAM ADDR Address Bus Failure E04 - RAM CELL Ram Cell Failure 61200107L1#HS-1 Dual U-BR1TE Plug-in Option Card User Manual...
  • Page 38 Appendix B. Dual U-BR1TE Failure Messages Dual U-BR1TE Plug-in Option Card User Manual 61200107L1#HS-1...
  • Page 39 (800) 615-1176 Sales (800) 827-0807 Post-Sale Support Please contact your local distributor first. If your local distributor cannot help, please contact ADTRAN Technical Support and have the unit serial number avail- able. Technical Support (888) 4ADTRAN Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Sup- port will coordinate with the Customer and Product Service (CaPS) department to issue an RMA number.
