Operating Instructions
Proline Fieldcheck
Flow Simulator
BA00067D/06/EN/13.11
71158188
Valid as of version
V 1.07.XX (device software)

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proline Fieldcheck

Summary of Contents for Endress+Hauser Proline Fieldcheck

  • Page 1 Operating Instructions Proline Fieldcheck Flow Simulator BA00067D/06/EN/13.11 71158188 Valid as of version V 1.07.XX (device software)

  • Page 3: Table Of Contents

    Proline Fieldcheck Table of contents Table of contents Safety instructions ....5 Operation ..... . 32 Designated use .
  • Page 4 Proline Fieldcheck Table of contents Device functions - Coriolis measuring systems ......61 11.1 Block FUNCTION ......61 11.1.1 Group SIMULATION .

  • Page 5: Safety Instructions

    The Fieldcheck flow simulation system may only be used for the simulation of sensor signals with a flowmeter of the Endress+Hauser Proline generation of instruments. The device is designed for use by service technicians who are familiar with the function and operating method of the equipment, and the specific requirements of the individual applications.

  • Page 6: Safety Instructions For Operating Fieldcheck With Proline Flowmeter Systems

    Safety instructions Proline Fieldcheck Safety instructions for operating Fieldcheck with Proline flowmeter systems with an approval for hazardous areas (e.g. II3GD, II2GD, II1/2GD, II1GD, Zone 1, Zone 21, Zone 2, Zone 22, Ga, Gb, Gc, Da, Db, Dc, Class I/II/III Div.1 or Div.2) The following safety instructions must be observed when using Fieldcheck and its related accessories (Simubox, test box, etc.) with Proline flowmeter systems with approval for use in...

  • Page 7: Identification

    Proline Fieldcheck Identification Identification Device designation The Fieldcheck flow simulation system consists of the following components: • The Fieldcheck flow simulator itself • The Simubox for correct connection to measuring device in question 2.1.1 Fieldcheck nameplate FIELDCHECK 50095658 Order Code: 12345678901 Ser.No.:...

  • Page 8: Scope Of Delivery

    The measuring system described in these Operating Instructions meets the statutory requirements and complies with the EC Directives which are listed in the Declaration of Conformity. Endress+Hauser confirms successful testing of the device and compliance with the EC Directives by affixing the CE mark.

  • Page 9: Wiring

    When connecting Ex-certified devices, see the notes and diagrams in the Ex-specific supplement to the Operating Instructions of the relevant measuring device. Fieldcheck may not be used in hazardous areas. Please do not hesitate to contact your Endress+Hauser service organization if you have any questions.

  • Page 10: Supervisor Mode

    Wiring Proline Fieldcheck 3.1.3 Supervisor mode If Fieldcheck is operated with the external power unit or a current or frequency measuring cable, and is not connected to a transmitter, the following message appears on the display after a brief period:...

  • Page 11: Connecting To Promag 10

    Proline Fieldcheck Wiring Connecting to Promag 10 Note! Fieldcheck can only be used with devices with software version 1.01.xx or higher. " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 12: Connecting Sensor Test Box To Promag 10

    Wiring Proline Fieldcheck 3.2.1 Connecting sensor test box to Promag 10 Note! • Fieldcheck can only be used with devices with software version 1.01.xx or higher. • The start-up procedure must have been executed via the Simubox before connecting the sensor test box.

  • Page 13: Connecting To Promag 50, 53, 55 Field Housing

    Proline Fieldcheck Wiring Connecting to Promag 50, 53, 55 field housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (5).

  • Page 14: Promag 50, 53, 55 Field Housing

    Wiring Proline Fieldcheck 3.3.1 Connecting sensor test box to Promag 50, 53, 55 field housing Note! The start-up procedure must have been executed via the Simubox before connecting the sensor test box. " Caution! Connect the ground terminal of the adapter to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 15: Connecting To Promag 50, 53, 55 Wall-Mount Housing

    Proline Fieldcheck Wiring Connecting to Promag 50, 53, 55 wall-mount housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the connection compartment (4).
  • Page 16 Wiring Proline Fieldcheck 3.4.1 Connecting sensor test box to Promag 50, 53, 55 wall-mount housing Note! The start-up procedure must have been executed via the Simubox before connecting the sensor test box. " Caution! Connect the ground terminal of the adapter to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 17: Connecting To Promass 40, 80, 83, 84 Field Housing

    Proline Fieldcheck Wiring Connecting to Promass 40, 80, 83, 84 field housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (5).
  • Page 18 Wiring Proline Fieldcheck 3.5.1 Connecting sensor test box to Promass 40, 80, 83, 84 field housing Note! The start-up procedure must have been executed via the Simubox before connecting the sensor test box. " Caution! Connect the ground terminal of the adapter to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 19: Promass 80, 83, 84 Wall-Mount Housing

    Proline Fieldcheck Wiring Connecting to Promass 80, 83, 84 wall-mount housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the connection compartment (4).

  • Page 20: Promass 80, 83, 84 Wall-Mount Housing

    Wiring Proline Fieldcheck 3.6.1 Connecting sensor test box to Promass 80, 83, 84 wall-mount housing Note! The start-up procedure must have been executed via the Simubox before connecting the sensor test box. " Caution! Connect the ground terminals of the adapter to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 21: Connecting To T-Mass 65 Field Housing

    Proline Fieldcheck Wiring Connecting to t-mass 65 field housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (4).

  • Page 22: Connecting To Remote Version Of T-Mass 65 With Wall- Mount Housing

    Wiring Proline Fieldcheck Connecting to remote version of t-mass 65 with wall- mount housing Note! You can only test remote versions of measuring devices if the distance between the electronic connections and sensor connections does not exceed 5 m (196 inch). A long Simubox cable can be acquired for this purpose (material no.: 71110466 ä...

  • Page 23: Connecting To Remote Version Of T-Mass 65 With Field Housing

    Proline Fieldcheck Wiring Connecting to remote version of t-mass 65 with field housing Note! You can only test remote versions of measuring devices if the distance between the electronic connections and sensor connections does not exceed 5 m (196 inch). A long Simubox cable can be acquired for this purpose (material no.: 71110466 ä...

  • Page 24: Connecting To Prowirl 72, 73

    Wiring Proline Fieldcheck 3.10 Connecting to Prowirl 72, 73 " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (3).
  • Page 25 Proline Fieldcheck Wiring Loosen the fixing screw (6) of the cover of the connection compartment (7) and fold down the cover. Connect Fieldcheck to the current output/power supply (8) and to the pulse output (9) if available. The terminals can be disconnected for this.

  • Page 26: Connecting To Prosonic Flow

    Wiring Proline Fieldcheck 3.11 Connecting to Prosonic Flow 90, 93 wall-mount housing Note! Fieldcheck can only be used with devices with software version 1.06.xx or higher. " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment.

  • Page 27: Connecting To Prosonic Flow 91 Field Housing

    Proline Fieldcheck Wiring 3.12 Connecting to Prosonic Flow 91 field housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the connection compartment.

  • Page 28: Connecting To Prosonic Flow 92 In Single-Chamber Housing

    Wiring Proline Fieldcheck 3.13 Connecting to Prosonic Flow 92 in single-chamber housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (5), remove the display module and lift up the plastic cover.

  • Page 29: Connecting To Prosonic Flow 92 In Twin-Chamber Housing

    Proline Fieldcheck Wiring 3.14 Connecting to Prosonic Flow 92 in twin-chamber housing " Caution! Connect the ground terminals on the cables to the uninsulated housing components or to the ground terminals in the connection compartment. Remove the cover of the electronics compartment (6), remove the display module and lift up the plastic cover.

  • Page 30: Connecting To Prosonic Flow 93 In The Field Housing

    Wiring Proline Fieldcheck 3.15 Connecting to Prosonic Flow 93 in the field housing Note! • Fieldcheck can only be used with devices with software version 1.06.xx or higher. • To connect Fieldcheck to the sockets in the Ex d field housing, the "PSONIC93 wall housing connection plate set"...

  • Page 31: Post-Connection Check

    Proline Fieldcheck Wiring 3.16 Post-connection check • Fieldcheck can only complete the startup procedure correctly if the simulation box and the service cable are correctly connected. • Current and frequency outputs which are incorrectly connected or mixed up result in an incorrect verification result.

  • Page 32: Operation

    Operation Proline Fieldcheck Operation Display and operating elements The local display enables you to read all important variables of the simulation and configure the device using the function matrix. Verif. Transmitter +7.000 dm3/m +7.012 dm3/m Flow 73 sec a0001725 Fig. 24:...

  • Page 33: Brief Operating Instructions For The Function Matrix

    Proline Fieldcheck Operation Brief operating instructions for the function matrix The function matrix comprises a multiplicity of functions which, for the sake of clarity, are arranged on a number of menu levels (blocks, groups and function groups). Note! A detailed description of all the functions as well as a detailed overview of the function matrix are provided in Sections 9 to 12.

  • Page 34: Fieldcare Operating Software

    Proline Fieldcheck FieldCare operating software FieldCare is Endress+Hauser's FDT-based plant asset management tool.  It offers a wide variety of functionalities, from basic device configuration to solutions for monitoring status. FieldCare enables you to configure, operate and monitor your plant.

  • Page 35: Commissioning

    Proline Fieldcheck Commissioning Commissioning Function check Make sure that Fieldcheck is correctly connected to the measuring device to be simulated ä 9 The measuring device must work without any interference so that a simulation or verification can be started. Battery operation / power supply The Fieldcheck can be powered via: •...

  • Page 36: Maintenance

    Maintenance Proline Fieldcheck Maintenance Fieldcheck requires no special maintenance. As with other measuring equipment, we recommend calibrating the Fieldcheck on an annual basis. Measuring the open-circuit voltage and the short-circuit current at every output is an integral part of the factory calibration.

  • Page 37: Accessories

    Proline Fieldcheck Accessories Accessories Various accessories can be supplied for Fieldcheck and they can be ordered separately from Endress+Hauser. Your Endress + Hauser service organization can provide detailed information on the order code of your choice. Device-specific accessories Accessory Description Order code Plug-in power supply unit...

  • Page 38: Service-Specific Accessories

    Accessories Proline Fieldcheck Service-specific accessories Accessory Description Order code FieldCare FieldCare is Endress+Hauser's FDT-based plant asset Refer to product management tool.  page on the  It offers a wide variety of functionalities, from basic Endress+Hauser Web site  device configuration to solutions for monitoring status.

  • Page 39: Technical Data

    Proline Fieldcheck Technical data Technical data Technical data at a glance 8.1.1 Input Measured variable • Current input • Frequency input Measuring range • Current input: 0 to 25 mA • Frequency input: 0 to 15000 Hz 8.1.2 Power supply...

  • Page 40: Mechanical Construction

    CE mark The measuring system complies with the statutory requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by affixing the CE mark. C-Tick mark The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)".

  • Page 41: Device Functions - General Section

    Proline Fieldcheck Device functions - general section Device functions - general section Notes The description of device functions is split into the following sections: • Device functions - general section ä 41 This introduces you to the function matrix and provides you with an overview of the device functions and a description of the device functions which apply to all applications.

  • Page 42: Description

    Device functions - general section Proline Fieldcheck 9.1.2 Using the graphic of the function matrix to locate a function description This step-by-step, top-down approach starts with the blocks, the highest level, and works down through the matrix to the description of the function you need: All the blocks available, and their related groups, are illustrated in the following section.

  • Page 43: Block User Interface

    Proline Fieldcheck Device functions - general section Block USER INTERFACE Block Group Function group Function USER CONTROL LANGUAGE CONTRAST BACK LIGHT FORMAT DATE   ä 44 INTERFACE DATE ä 43 ä 43 ä 43 ä 44 ä 44 CHARGE...
  • Page 44 Device functions - general section Proline Fieldcheck Function description USER INTERFACE  CONTROL BACK LIGHT Use this function to select whether the display is backlit. Options: ON (AUTOMATIC) Factory setting: ON (AUTOMATIC) Note! If the ON (AUTOMATIC) setting is selected, the lighting of the display is automatically switched off if the device is not used for 10 minutes.

  • Page 45: Block Basic Information

    Proline Fieldcheck Device functions - general section Block BASIC INFORMATION Block Group Function group Function BASIC DEVICE DATA DEVICE DATA INFORMATION   ä 45 ä 45  READ IN READ IN  PARAMETERS PARAMETERS ä 45 ä 45 9.3.1...

  • Page 46: Block Supervision

    Device functions - general section Proline Fieldcheck Block SUPERVISION Block Group Function group Function SUPERVISION RESULTS STORAGE RESULT VER. RESULT VER. RESULT VER. RESULT VER.   LOCATION TRANS. MID SENSOR MID TRANS. COR. SENSOR COR. ä 46 ä 46 ä...
  • Page 47 Proline Fieldcheck Device functions - general section Function description SUPERVISION  RESULTS RESULT The measured values are grouped and displayed over a maximum of 5 lines. VERIFICATION Use the ENTER key to go to the next group. SENSOR MID Display: Measurement of ground connection, optional: measurement of magnetic coil resistance.

  • Page 48: Group Version Info

    Device functions - general section Proline Fieldcheck Function description SUPERVISION  RESULTS DEL. STORAGE Use this function to delete the content of the memory. Options: STORAGE LOCATION STORAGE LOCATION Use this function to specify the storage location whose contents should be deleted.

  • Page 49: Device Functions - Electromagnetic Measuring Systems

    Proline Fieldcheck Device functions - electromagnetic measuring systems Device functions - electromagnetic measuring systems 10.1 Block FUNCTION Block Group Function group Function FUNCTION SIMULATION CONFIGURATI OPERATION FLOW SIGNAL 1 SIG. 1 PERIOD SIG. 1 PROFILE MODE SPECIFICATIO LEVEL SIG. 2 PERIOD SIG.

  • Page 50: Group Simulation

    Device functions - electromagnetic measuring systems Proline Fieldcheck 10.1.1 Group SIMULATION Function group CONFIGURATION Function description FUNCTION  SIMULATION  CONFIGURATION OPERATION MODE Use this function to select the operation mode for the simulation. There are two freely adjustable flow signals of –12.5 m/s to +12.5 m/s and the assigned duration of simulation is 1 second to 999 seconds.
  • Page 51 Proline Fieldcheck Device functions - electromagnetic measuring systems Function description FUNCTION  SIMULATION  CONFIGURATION FLOW SPECIFICATION Use this function to select which measurement is to be simulated. Options: VOLUME FLOW MASS FLOW Note! • "Calculated mass flow" simulation is only possible with Promag 53 type devices.
  • Page 52 Device functions - electromagnetic measuring systems Proline Fieldcheck Function group OPERATION Function description FUNCTION  SIMULATION  OPERATION SIMULATE Use this function to control the simulation. Options: START STOP Factory setting: START Display during the simulation: Simulation 1500.0 dm3/m 1501.3 dm3/m I=12.003 mA,...

  • Page 53: Group Verification Transmitter

    Proline Fieldcheck Device functions - electromagnetic measuring systems 10.1.2 Group VERIFICATION TRANSMITTER In the VERIFICATION TRANSMITTER group, a measuring device can be checked for the following characteristic values: • Functionality and deviation in the flow measurement (based on the set point preset by Fieldcheck) •...
  • Page 54 Device functions - electromagnetic measuring systems Proline Fieldcheck Analyzing the results During verification, the current verification test section is displayed in the 'HOME position'. The results can be shown on the display once verification is complete. They can be filed in Fieldcheck under a storage location number of your choice (up to max.
  • Page 55 Proline Fieldcheck Device functions - electromagnetic measuring systems Function group LIMIT VALUES You can specify the limit values for measured variables in this function group. If the deviation of a verification step (see OPERATION, P. 38) lies within the configured limit values the result is PASSED;...
  • Page 56 Device functions - electromagnetic measuring systems Proline Fieldcheck Function group PARAMETER Verification of the amplifier takes place along four measuring points MP1 to MP4. Use this function group to enter the full scale value MP4 of the verification flow (100%) and the two selectable measuring points MP2 and MP3 (in % of the full scale value).
  • Page 57 Proline Fieldcheck Device functions - electromagnetic measuring systems Function group OPERATION Use this function group to verify the measuring point. Function description FUNCTION  VERIFICATION  OPERATION VERIFICATION Use this function to define the scope of the verification. Note! • Verification of the current and frequency outputs of the transmitter can only be achieved with the TRANSM.

  • Page 58: Group Verification Sensor

    Device functions - electromagnetic measuring systems Proline Fieldcheck 10.1.3 Group VERIFICATION SENSOR The VERIFICATION SENSOR function is part of the Fieldcheck menu. Configuration of the test run is completely menu-guided. Preparing for the test run • The start-up procedure must have been executed via the Simubox before connecting the sensor test box.
  • Page 59 Proline Fieldcheck Device functions - electromagnetic measuring systems Group VERIFICATION SENSOR Function description FUNCTION  VERIFICATION SENSOR INSTRUMENT Use this function to enter the measuring device version. VERSION Options: COMPACT / REMOTE: Remote version with a cable length of up to 20 meters max. or compact version REMOTE >...
  • Page 60 Device functions - electromagnetic measuring systems Proline Fieldcheck Function description FUNCTION  VERIFICATION SENSOR OPERATION Use this function to start the sensor verification, cancel a verification that is running or save data after verification has been completed. Options: START STOP...

  • Page 61: Device Functions - Coriolis Measuring

    Proline Fieldcheck Device functions - Coriolis measuring systems Device functions - Coriolis measuring systems 11.1 Block FUNCTION Block Group Function group Function FUNCTION SIMULATION CONFIGURATI OPERATION FLOW SPE- APPLIC. SPEC. APPLIC. SPEC. SIG. 1 LEVEL    MODE CIFICATION...

  • Page 62: Group Simulation

    Device functions - Coriolis measuring systems Proline Fieldcheck 11.1.1 Group SIMULATION Function group CONFIGURATION Function description FUNCTION  SIMULATION  CONFIGURATION OPERATION MODE Use this function to select the operation mode for the simulation. There are two freely adjustable flow signals of –12.5 m/s to +12.5 m/s and the assigned duration of simulation is 1 second to 999 seconds.
  • Page 63 Proline Fieldcheck Device functions - Coriolis measuring systems Function description FUNCTION  SIMULATION  CONFIGURATION APPLIC. SPEC. DATA 1 Use this function to select the application-specific temperature for the carrier and TEMP M/C measuring tube in the simulated process. Options: –25, +15, +60, +125 °Celsius...
  • Page 64 Device functions - Coriolis measuring systems Proline Fieldcheck Function group OPERATION Function description FUNCTION  SIMULATION  OPERATION SIMULATE Use this function to control the simulation. Options: START STOP Factory setting: START Display during the simulation: Simulation 1500.0 kg/m 1501.3 kg/m I=12.003 mA,...

  • Page 65: Group Verification Transmitter

    Proline Fieldcheck Device functions - Coriolis measuring systems 11.1.2 Group VERIFICATION TRANSMITTER In the VERIFICATION TRANSMITTER group, a measuring device can be checked for the following characteristic values: • Functionality and deviation in the flow measurement (based on the set point preset by Fieldcheck) •...
  • Page 66 Device functions - Coriolis measuring systems Proline Fieldcheck Verification of sensor circuits A series of internal tests are run through for checking the sensor connections and the closed-control loops of excitation current and frequency with connectors plugged in for the excitation current and amplifier.
  • Page 67 Proline Fieldcheck Device functions - Coriolis measuring systems Function group APPLICATION/OUTPUTS During verification, the function and accuracy of a current output and a frequency output can be checked. Fieldcheck determines the current and frequency outputs available in the measuring device.
  • Page 68 Device functions - Coriolis measuring systems Proline Fieldcheck Function group LIMIT VALUES You can specify the limit values for measured variables in this function group. If the deviation of a verification step (see OPERATION, P. 38) lies within the configured limit values the result is PASSED;...
  • Page 69 Proline Fieldcheck Device functions - Coriolis measuring systems Function group PARAMETER Verification of the amplifier takes place along four measuring points MP1 to MP4. Enter the full scale value MP4 of the verification flow (100%) and the two selectable measuring points MP2 and MP3 (in % of the full scale value) for the STANDARD RANGE option in the FLOW RANGE function.
  • Page 70 Device functions - Coriolis measuring systems Proline Fieldcheck Function group OPERATION Use this function group to specify the scope of the verification and to start/stop the verification. Function description FUNCTION  VERIFICATION  OPERATION VERIFICATION Use this function to define the scope of the test.

  • Page 71: Group Verification Sensor

    Proline Fieldcheck Device functions - Coriolis measuring systems 11.1.3 Group VERIFICATION SENSOR The VERIFICATION SENSOR function is part of the Fieldcheck menu. Configuration of the test run is completely menu-guided. Preparing for the test run • The start-up procedure must have been executed via the Simubox before connecting the sensor test box.
  • Page 72 Device functions - Coriolis measuring systems Proline Fieldcheck Group VERIFICATION SENSOR Function description FUNCTION  VERIFICATION SENSOR INSTRUMENT Use this function to enter the measuring device version. VERSION Options: COMPACT / REMOTE: Remote version with a cable length of up to 20 meters max. or compact version REMOTE >...

  • Page 73: Device Functions - Thermal Measuring

    Proline Fieldcheck Device functions - thermal measuring systems Device functions - thermal measuring systems 12.1 Block FUNCTION Block Group Function group Function FUNCTION SIMULATION CONFIGURA- OPERATION FLOW SPE- SIGNAL 1 TION MODE CIFICATION LEVEL    ä 74 ä 74 ä...

  • Page 74: Group Simulation

    Device functions - thermal measuring systems Proline Fieldcheck 12.1.1 Group SIMULATION Function group CONFIGURATION Function description FUNCTION  SIMULATION  CONFIGURATION OPERATION MODE Use this function to select the operation mode for the simulation. Users can freely configure a flow signal from 0.0 to the displayed maximum value.
  • Page 75 Proline Fieldcheck Device functions - thermal measuring systems Function group OPERATION Function description FUNCTION  SIMULATION  OPERATION SIMULATE Use this function to control the simulation. Options: START STOP Factory setting: START Display during the simulation: Simulation 1500.0 kg/m 1501.3 kg/m I=12.003 mA,...

  • Page 76: Group Verification Transmitter

    Device functions - thermal measuring systems Proline Fieldcheck 12.1.2 Group VERIFICATION TRANSMITTER In the VERIFICATION TRANSMITTER group, a measuring device can be checked for the following characteristic values: • Functionality and deviation in providing a required power rating at the heated sensor element in four points of the range available.
  • Page 77 Proline Fieldcheck Device functions - thermal measuring systems Analyzing the results During verification, the current verification test section is displayed in the 'HOME position'. The results can be shown on the display once verification is complete. They can be filed in Fieldcheck under a storage location number of your choice (up to max.
  • Page 78 Device functions - thermal measuring systems Proline Fieldcheck Function group LIMIT VALUES You can specify the limit values for measured variables in this function group. If the deviation of a verification step (see OPERATION, P. 38) lies within the configured limit values the result is PASSED;...
  • Page 79 Proline Fieldcheck Device functions - thermal measuring systems Function group PARAMETER Verification of the amplifier takes place along four measuring points MP1 to MP4. Use this function group to enter the full scale value MP4 of the verification flow (100%) and the two selectable measuring points MP2 and MP3 (in % of the full scale value).
  • Page 80 Device functions - thermal measuring systems Proline Fieldcheck Function group OPERATION Use this function group to verify the measuring point. Function description FUNCTION  VERIFICATION  OPERATION VERIFICATION Use this function to define the scope of the verification. Note! • Verification of the current and frequency outputs of the transmitter can only be achieved with the TRANSM.

  • Page 81: Devices

    Proline Fieldcheck Device functions - vortex measuring devices Device functions - vortex measuring devices 13.1 Block FUNCTION Block Group Function group Function FUNCTION SIMULATION CONFIGURA- OPERATION FLOW SPE- APPL.SPEC. SIGNAL 1    TION MODE CIFICATION DATA LEVEL ä 82 ä...

  • Page 82: Group Simulation

    Device functions - vortex measuring devices Proline Fieldcheck 13.1.1 Group SIMULATION Please note the following: • In contrast to Coriolis or electromagnetic flow measuring devices, a gap-free flow range 0 – Q cannot be simulated with vortex flowmeters. Below a certain fluid speed (approx. 0.15 m/s for water), the amplitude of the vortex signal becomes so small that it is no longer possible to record the measured value.
  • Page 83 Proline Fieldcheck Device functions - vortex measuring devices Function description FUNCTION  SIMULATION  CONFIGURATION APPLICATION-  Note! SPECIFIC DATA This function is only available for Prowirl 73 Use this function to select the application-specific temperature range in the simulated process.
  • Page 84 Device functions - vortex measuring devices Proline Fieldcheck Function group OPERATION Function description FUNCTION  SIMULATION  OPERATION SIMULATE Use this function to control the simulation. Options: START STOP Factory setting: START Display during the simulation: Simulation 1500.0 dm3/m 1501.3 dm3/m I=12.003 mA,...

  • Page 85: Group Verification Transmitter

    Proline Fieldcheck Device functions - vortex measuring devices 13.1.2 Group VERIFICATION TRANSMITTER In the VERIFICATION TRANSMITTER group, a measuring device can be checked for the following characteristic values: • Functionality and deviation in the flow measurement (based on the set point preset by Fieldcheck) •...
  • Page 86 Device functions - vortex measuring devices Proline Fieldcheck Analyzing the results During verification, the current verification test section is displayed in the 'HOME position'. The results can be shown on the display once verification is complete. They can be filed in Fieldcheck under a storage location number of your choice (up to max.
  • Page 87 Proline Fieldcheck Device functions - vortex measuring devices Function group LIMIT VALUES You can specify the limit values for measured variables in this function group. If the deviation of a verification step (see OPERATION, P. 38) lies within the configured limit values the result is PASSED;...
  • Page 88 Device functions - vortex measuring devices Proline Fieldcheck Function group PARAMETER Verification of the amplifier takes place along four measuring points MP1 to MP4. Use this function group to enter the two selectable measuring points MP2 and MP3 (in % of the full scale value).
  • Page 89 Proline Fieldcheck Device functions - vortex measuring devices Function group OPERATION Use this function group to specify the scope of the verification and to start/stop the verification. Function description FUNCTION  VERIFICATION  OPERATION VERIFICATION Use this function to define the scope of the test.

  • Page 90: Systems

    Device functions - ultrasonic measuring systems Proline Fieldcheck Device functions - ultrasonic measuring systems 14.1 Block FUNCTION Block Group Function group Function FUNCTION SIMULATION CONFIGURA- OPERATION SELECT SIGNAL 1    TION MODE CHANNEL LEVEL ä 91 ä 91 ä...

  • Page 91: Group Simulation

    Proline Fieldcheck Device functions - ultrasonic measuring systems 14.1.1 Group SIMULATION Function group CONFIGURATION Function description FUNCTION  SIMULATION  CONFIGURATION OPERATION MODE Use this function to select the operation mode for the simulation. There are two freely adjustable flow signals of –12.5 m/s to +12.5 m/s and the assigned duration of simulation is 1 second to 999 seconds.
  • Page 92 Device functions - ultrasonic measuring systems Proline Fieldcheck Function group OPERATION Function description FUNCTION  SIMULATION  OPERATION SIMULATE Use this function to control the simulation. Options: START STOP Factory setting: START Display during the simulation: Simulation 1500.0 dm3/m 1501.3 dm3/m I=12.003 mA,...

  • Page 93: Group Verification Transmitter

    Proline Fieldcheck Device functions - ultrasonic measuring systems 14.1.2 Group VERIFICATION TRANSMITTER In the VERIFICATION TRANSMITTER group, a measuring device can be checked for the following characteristic values: • Functionality and deviation in the flow measurement (based on the set point preset by Fieldcheck) •...
  • Page 94 Device functions - ultrasonic measuring systems Proline Fieldcheck Analyzing the results During verification, the current verification test section is displayed in the 'HOME position'. The results can be shown on the display once verification is complete. They can be filed in Fieldcheck under a storage location number of your choice (up to max.
  • Page 95 Proline Fieldcheck Device functions - ultrasonic measuring systems Function group LIMIT VALUES You can specify the limit values for measured variables in this function group. If the deviation of a verification step (see OPERATION, P. 38) lies within the configured limit values the result is PASSED;...
  • Page 96 Device functions - ultrasonic measuring systems Proline Fieldcheck Function group PARAMETER Verification of the amplifier takes place along four measuring points MP1 to MP4. Use this function group to enter the full scale value MP4 of the verification flow (100%) and the two selectable measuring points MP2 and MP3 (in % of the full scale value).
  • Page 97 Proline Fieldcheck Device functions - ultrasonic measuring systems Function group OPERATION Use this function group to verify the measuring point. Function description FUNCTION  VERIFICATION  OPERATION VERIFICATION Use this function to define the scope of the verification. Note! • Verification of the current and frequency outputs of the transmitter can only be achieved with the TRANSM.

  • Page 98: Index

    Proline Fieldcheck Index Index CONFIGURATION (function group) Coriolis measuring devices ..... 62 Accessories....... . . 37, 40 Electromagnetic measuring devices .
  • Page 99 Proline Fieldcheck Index Promag 50, 53, 55 (field housing) ....13 CONFIGURATION Promag 50, 53, 55 (wall-mount housing) ... 15 Coriolis measuring devices .
  • Page 100 Proline Fieldcheck Index VERIFICATION TRANSMITTER Coriolis measuring devices ....65 Nameplate Electromagnetic measuring devices ... . . 53 Fieldcheck.
  • Page 101 Proline Fieldcheck Index Promag 10 Simubox ........48 Electrical connection .
  • Page 102 Proline Fieldcheck Index USER INTERFACE (block) ......43 VERIFICATE (function) Coriolis measuring devices ..... . 70 Electromagnetic measuring devices .
  • Page 103 Proline Fieldcheck Index Endress+Hauser...
  • Page 104 www.endress.com/worldwide BA00067D/06/EN/13.11 71158188 FM+SGML 9.0 ProMoDo...
