- Page 1 Products Solutions Services BA00481C/07/EN/15.13 71233207 valid from: Software version 1.00.03 Operating Instructions Memocheck Sim CYP03D Testing tool for analysis measuring points...
-
Page 3: Table Of Contents
Cleaning ......39 Battery replacement ....39 Endress+Hauser... -
Page 4: Document Information
Corrective action This symbol alerts you to situations that can result in damage NOTICE to property and equipment. Cause/situation Consequences if safety message is not heeded ‣ Action/note Symbols used Additional information, tip Permitted or recommended Forbidden or not recommended Endress+Hauser... -
Page 5: Basic Safety Instructions
Make sure that electric cables and hose connections are not damaged. ‣ Do not commission damaged products. Protect them against unintentional startup. Label and identify the damaged product as defective. ‣ If the faults cannot be eliminated, take the products out of service and protect them against unintentional startup. Endress+Hauser... -
Page 6: Product Safety
The IECEx certificate to this effect and the EC certificate of conformity for ATEX are an integral part of these Operating Instructions. • Power is supplied to the Memocheck Sim CYP03D via three alkaline batteries with a total nominal voltage of 4.5 V. Only the following types of battery may be used for this purpose:... -
Page 7: Device Description
Sensor simulation in a complete measuring system consists of: • Memocheck Sim CYP03D • Transmitter with Memosens technology • Memosens data cable CYK10 a0014717 Fig. 1: Measuring system with Memocheck Sim CYP03D Transmitter with Memosens technology, e.g. Liquiline CM44x Memosens data cable CYK10 Memocheck Sim CYP03D Endress+Hauser... -
Page 8: Iecex
Device description CYP03D IECEx The approved digital Memocheck Sim CYP03D sensor simulator may only be connected in IECEx-rated environments using the following IECEx-certified measuring cable: CYK10-G*** (IECEx BVS 11.0052X) It may also be connected using a Memosens measuring cable which has IECEx certification and is identical both in terms of design, appliance technology and function. -
Page 9: Quick Wiring Guide In Ex Areas
= 15 μF = 14.1 μF = 95 μΗ = 237.2 μΗ Ex-relevant electrical connection parameters Electrical connection must be established in accordance with the wiring diagram. Quick wiring guide in Ex areas a0017245-en Fig. 2: Connection in hazardous areas Endress+Hauser... -
Page 10: Temperature Classes
Ambient temperature range T Temperature class CYP03D-**-** Memocheck Sim -20 to +50 ˚C (-4 to 122 ˚F) If the ambient temperatures shown above are not exceeded no invalid temperatures for the particular temperature class will occur at the simulator. Endress+Hauser... -
Page 11: Incoming Acceptance And Product Identification
The order code and serial number of your device can be found in the following locations: • On the nameplate • In the delivery papers • On the packaging To establish the version of your device, enter the order code from the nameplate into the search field at the following address: www.products.endress.com/order?ident Endress+Hauser... -
Page 12: Scope Of Delivery
Incoming acceptance and product identification CYP03D Scope of delivery The delivery comprises: • Memocheck Sim CYP03D • Operating Instructions • Quality certificate • Cable as per order (optional) • Case to store CYP03D and cable (optional) • Certificate of calibration (optional) -
Page 13: Operation Options
Fig. 3: Display (Example: simulation mode) "-/+": Configures numerical data If an error message occurs, reset the device. If this action does not rectify the error, contact your Endress+Hauser sales center. 5.1.2 Key functions ENTER key The ENTER key has the following functions: •... - Page 14 Pressing the MINUS and ENTER keys simultaneously for longer allows you to reset the device. PLUS key and ENTER key Pressing the PLUS and ENTER keys simultaneously for longer allows you to reset the device to the factory settings. This also deletes all the setups saved. Endress+Hauser...
-
Page 15: Structure And Function Of The Operating
Setup Simulation Parameter Memosens pH glass pH + ORP pH ISFET Conductive cond. Oxygen amper. Chlorine pH glass SIL Fixed cable Toroidal conductivity Oxygen optical Turbidity Nitrate Sim main value Test values Save setup Load setup Advanced Date Time Endress+Hauser... - Page 16 Operation options CYP03D Menu Switch off auto. Advanced functions Calibration value Error simulation Ramp Diagnostics Diagnostic list Order code Serial number Software Hardware Reset Factory setting Switch off Endress+Hauser...
- Page 17 4. Press to confirm your entry. The "Escape" function ( pressed simultaneously) is disabled here in order to prevent incorrect entries. 5. Select the tick mark (arrow key) and press The edited value is accepted. Endress+Hauser...
-
Page 18: Commissioning
• Français • Español • Italiano 3. Select your language, e.g. "Deutsch". 4. Confirm with From now on, you will be guided through the menu in the language of your choice. Pressing takes you back to the main menu. Endress+Hauser... - Page 19 2. Under "Setup/Simulation/Test values", enter the test values (see the section "Configuring sim. main value and test values"). 3. Press simultaneously. You are in the simulation mode. You can now simulate the selected parameter using the selected settings. Endress+Hauser...
-
Page 20: Configuring The Measuring Device
Commissioning CYP03D Once you connect the Memocheck Sim CYP03D to a Memosens transmitter, the Memosens symbol appears in the status line of the simulator. It indicates that the simulator is communicating with the transmitter. The simulation symbol displayed indicates whether or not the transmitter is in simulation mode: •... - Page 21 Select a free storage location to ensure that none of the settings previously saved are overwritten. In the "Setup/Save setup" menu, you can save up to 10 setups under the relevant parameter name. If you wish to use a saved setup, select it under the "Setup/Load setup" menu. Endress+Hauser...
- Page 22 Memosens: • pH glass/pH glass SIL: - pH value - Temperature - Raw value - Raw value temperature - SCS resistance • pH + ORP: - pH value - ORP potential - rH value - Temperature Endress+Hauser...
- Page 23 - Raw value current - Raw value temperature Fixed cable: • Toroidal conductivity: - Conductivity - Temperature - Resistance - Raw value temperature - Phase • Oxygen optical: partial pressure saturation content - Temperature - Raw value temperature - Slope Endress+Hauser...
-
Page 24: Advanced Settings
• If you change a calibration value, there will be a brief interruption to communication between the Memocheck Sim CYP03D and the transmitter to allow the transmitter to accept the calibration settings. • An unfavorable configuration may result in measured values outside the specified measuring range. - Page 25 Fig. 6: Linear function • You will obtain a negative slope for the ramp if you set the starting value higher than the stop value. Zero point Slope Starting value Stop value Time x2-x1 Duration a0017359 Fig. 7: Negative slope Endress+Hauser...
- Page 26 10 to 6000 s 1 to 200 0.5 to 600 s Raw value -40.0 ˚C 150.0 ˚C 60 s temperature -40.0 to 150.0 ˚C -40.0 to 150.0 ˚C 10 to 6000 s 1 to 200 0.5 to 600 s Endress+Hauser...
- Page 27 0.0 to 100.0 % ORP % slope 20.0 mV/% -30.0 to 30.0 mV/% ORP % zero point -400.0 mV -1.0 to 1.0 mV rH value rH offset 0.0 rH -300.0 to 300.0 rH Temperature Temp. offset 0.0 ˚C -10.0 to 10.0 ˚C Endress+Hauser...
- Page 28 10 to 6000 s 1 to 200 0.5 to 600 s Raw val. temp. -40.0 ˚C 150.0 ˚C 60 s -40.0 to 150.0 ˚C -40.0 to 150.0 ˚C 10 to 6000 s 1 to 200 0.5 to 600 s Endress+Hauser...
- Page 29 -750.0 to 750.0 mV 10 to 6000s 1 to 200 0.5 to 600 s Raw value -40.0 ˚C 150.0 ˚C 60 s temperature -40.0 to 150.0 ˚C -40.0 to 150.0 ˚C 10 to 6000s 1 to 200 0.5 to 600 s Endress+Hauser...
- Page 30 10 to 6000 s 1 to 200 0.5 to 600 s Raw value -40.0 ˚C 150.0 ˚C 60 s temperature -40.0 to 150.0 ˚C -40.0 to 150.0 10 to 6000 s 1 to 200 0.5 to 600 s ˚C Endress+Hauser...
- Page 31 To delete the error again, remove the check mark using No Cond. display Temp. sens. defect Sensor supply For toroidal conductivity: Conductivity sensor defective Invalid conductivity value Temp. sens. defect Temp. value invalid High coil current Low coil current Ramp Endress+Hauser...
- Page 32 0.0 ˚C -10.0 to 10.0 ˚C Temp. gradient -3.0 to 3.0 Temp. coeff. 1 0.03079 0.02 to 0.04 Temp. coeff. 2 0.0004476 0.0001 to 0.0005 Temp. coeff. 3 0.000004224 0.0000005 to 0.000005 Temp. coeff. 4 0.00000006675 0.000000001 to 0.00000007 Endress+Hauser...
- Page 33 0.5 to 600 s 6.4.7 Advanced function: Oxygen optical Path: Menu/Advanced functions Function Configuration options (factory settings in bold) Calibration value Slope 100.0 % 0.0 to 200.0 % 20.0 μs 5.0 to 100.0 μs Temp. offset 0.0 ˚C -10.0 to 10.0 ˚C Endress+Hauser...
- Page 34 1 to 200 0.5 to 600 s 6.4.8 Advanced functions: Chlorine Path: Menu/Advanced functions Function Configuration options (factory settings in bold) Calibration value Slope -25.0 nA/g/l -500.0 to -0.01 nA/g/l Zero point 0.0 pA -100.0 nA to 100.0 nA Endress+Hauser...
- Page 35 Once you have selected an error using , the error is output at the Turbidity too high transmitter. Electronics test To delete the error again, remove the check mark using Sensor polluted Uncertain measured value No calibration data Temperature error Invalid measured value Measurement stop Endress+Hauser...
- Page 36 10 to 6000 s 1 to 200 0.5 to 600 s 3.0 g/l N content 0.0 mg/l 500.0 mg/l 60 s 0.0 μg/l to 500.0 mg/l 0.0 μg/l to 10 to 6000 s 1 to 200 0.5 to 600 s 500.0 mg/l Endress+Hauser...
- Page 37 10 to 6000 s 1 to 200 0.5 to 600 s Raw value -40.0 ˚C 150.0 ˚C 60 s temperature -40.0 to 150.0 ˚C -40.0 to 150.0 ˚C 10 to 6000 s 1 to 200 0.5 to 600 s Endress+Hauser...
-
Page 38: Diagnostics
Diagnostics CYP03D Diagnostics Path: Menu/Diagnostics Function Info Diagnostic list The diagnostic messages provide information to Endress+Hauser service personnel. Order code CYP03D-xxx Serial no. xxxxxxxxxxx Software x.xx.xx Hardware x.xx.xx Reset Device is restarted. Your stored settings will be preserved. Factory setting All device settings are reset to the factory settings. -
Page 39: Maintenance
Only ever open the battery compartment in the non-hazardous area! Calibration and qualification The Memocheck Sim CYP03D can, with the quality or calibration certificate, also be used as a qualification tool for your measuring point. The quality and calibration certificates can be renewed: For such services, you will need to return Memocheck Sim CYP03D to Endress+Hauser, see the "Returns"... -
Page 40: Repair
The product must be returned if repairs or a factory calibration are required, or if the wrong product has been ordered or delivered. According to legal regulations Endress+Hauser, as an ISO-certified company, is required to follow certain procedures when handling returned products that are in contact with the medium. -
Page 41: Accessories
10.2 Storage case Order No. Case for Memocheck Sim CYP03D 71183327 In the hazardous area, the Memocheck simulator case should only be opened to remove or put back the Memocheck simulator. When opened, the case should never be exposed to process-related intensive electrostatic charges. -
Page 42: Technical Data
Weight (incl. batteries): 0.3 kg (0.7 lbs) 11.2.2 Battery For the Memocheck Sim CYP03D, use only the following battery types, as only these are covered by the Ex approval: • Duracell batteries, MN1500 (AA, 1.5 V, LR6 as per IEC), x 3 •... -
Page 43: Appendix
CYP03D Appendix Appendix a0017231 Endress+Hauser... - Page 44 Appendix CYP03D a0017237 Endress+Hauser...
-
Page 45: Index
ISFET ......29 Turbidity ......35 Endress+Hauser... - Page 46 CYP03D Safety instructions Designated use ......5 Operational safety ..... 5 Product safety.
