  • Page 1 15" LCD TV Operating Instructions Model No. 15MF050V/17...

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION Content -------------------------------------------------------------------------------------------- Important Safety Instructions ------------------------------------------------------- 02~05 Product Description -------------------------------------------------------------------------- Product Features ------------------------------------------------------------------------------ Package Contents ---------------------------------------------------------------------------- 2. SYSTEM SETUP Top Panel & Remote Controller Function ------------------------------------- 09~12 Assembly and Connections -------------------------------------------------------------- Input/Output Signal Connections ------------------------------------------------- 14~17 Wall-mount Operation Instruction ----------------------------------------------------- 3.

  • Page 3: Important Safety Instructions

    Important Safety Instructions: Read Instructions All the safety and operating instructions should be read before the product is operated. Retain Instructions The safety and operating instructions should be retained for future references. Heed Warnings All Warnings on the product and in the operation instructions should be adhered to. Follow Instructions All Operating and user instructions should be followed.
  • Page 4 Important Safety Instructions Continued Ventilation DO NOT block any ventilation openings. Install in accordance with manufacture's instructions. Slots and openings in the cabinet and the back and bottom are provided for ventilation, and to ensure reliable operation of the product and to protect it from Overheating.
  • Page 5 Important Safety Instructions Continued ¡PContact service center if the picture displayed by the unit is getting dimmer. ¡PIf liquid has been spilled, or objects have fallen into the product. ¡PIf the product has been exposed to rain or water. ¡PIf the product does not operate normally after following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.
  • Page 6 Important Safety Instructions Continued CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The Lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "DANGEROUS VOLTAGE"...

  • Page 7: Introduction

    1. INTRODUCTION Product Description Thank you for choosing the 15MF050V/17 TFT-LCD Color TV/Monitor and for your continued support and use of our products. The 15MF050V/17 combines the features of a TV/MONITOR with a THIN FILM TRANSISTOR liquid crystal display (TFT-LCD). This new generation of TFT-LCD incorporates a high quality display in a light weight module.

  • Page 8: Product Features

    Product Features TFT-LCD screen connected with Computer support DDC1/2B for"Plug & Play"compatibility. 15-Inch high-resolution LCD Monitor which supports XGA 1024x768 resolution. Super 262,144 high-resolution pixels to enhance TFT-LCD definition. Super 250cd/m high-brightness for picture enjoyment. Super wide viewing angle : Horizontal : 150 , Vertical : 145 (CR=5) . Super-low power consumption ;...

  • Page 9: Package Contents

    Package Contents Please check the 15MF050 V/17 Package to make sure it contains the following items : SPEAKERS 15"TFT-LCD BASE TRANS Power Transformer Cord Slim-type Remote Control 15" LCD TV Operating Instructions Model No. 15MF050V/17 Power Cord User Manua l M5 Change M4 Screw...

  • Page 10: System Setup

    2. SYSTEM SETUP Top Panel & Remote Control Function TOP PANEL : VOL- MENU VOL+ POWER VOL - : Volume down Button : decreases volume MENU : Menu Button : Selects command function VOL + : Volume up Button : Increases volume POWER : Power Button : Power on/off control CH - : Channel down Button : Decreases setting channel...
  • Page 12 Remote Control Battery Installation/Removal : Open CR2025 Open CR2025 Pull out LITHIUM BATTERY CR2025 IMPORTANT !! The Remote Control is shipped with the Battery pre-installed and protected with a Plastic Shipping Tab. This Tab must be removed prior to attempting Plastic ShippingTab to operate the unit.
  • Page 13 Re m o t e C o n t r o l O p e r at i n g I n s t r u c t i o n : Th e Remot e Co nt r o l Tr an s m is s ion c on sists of an Infr ar ed (IR ) S ignal. Mak e s ure the line - o f - s igh t b e tw ee n R emote C ontr ol and 15M F050V/17 is cl ear of ob jec ts that c o uld int e r fe r e w ith th e r emote IR signal.

  • Page 14: Assembly And Connections

    A s s e m b l y a n d C o n n e c t i o n Th e Sp ea ke r s w er e pr em ou n ted to t h e T V d is p la y in t h e f a c t o r y pr io r t o s h ip me n t . Loca te t he pow e r c ab l e i n th e a cce s s ory bo x a n d c o n ne c t it t o t h e DC- I N .

  • Page 15: Input/Output Signal Connections

    Input/Output Signal Connections SPEAKER DC-IN VGA IN VIDEO IN S-VIDEO IN TV-ANT EARPHONE AUDIO IN 1. ANT. CABLE INPUT 2. POWER ADAPTER INPUT 3. EARPHONE OUTPUT 4. RIGHT SPEAKER OUTPUT 5. LEFT SPEAKER OUTPUT 6. VGA INPUT 7. AV INPUT 8.
  • Page 16 DC Power Socket DC-IN Connecting Left and Right Speakers SPEAKER...
  • Page 17 Connecting to SVIDEO terminal equipment such as DVD, VCR or Gaming Console. S-VIDEO IN VIDEO FROM ANT TO TV S-VIDEO Connecting to 15-PIN VGA from a PC VGA-IN VGA-OUT...
  • Page 18 Connecting to AV-terminal equipment such as DVD, VCR, and Gaming Console. AUDIO IN VIDEO IN Yellow White Yellow White FROM ANT S-VIDEO VIDEO TO TV...

  • Page 19: Wall-Mount Operation Instruction

    Wa l l - M o u n t i n g O p e r at i n g I n s t r u c t i o n s ( D o n o t i n cl u d e Wa l l - M o u n t ) Unlock stand 7 5 m m 7 5 m m...

  • Page 20: Mf050V/17 Operating Instructions

    3 . 1 5 M F 0 5 0 V / 1 7 O P E R AT I N G I N S T RU C T I O N S T V a n d AV O p e r at i n g I n s t r u c t i o n s M A I N D I S P L AY P res s an d r el ea s e t he Me n u b ut ton to dis pla y t h e f ollo win g M ain Me nu...
  • Page 21 AUDIO Select the desired level of BASS, TREBLE and LOUDNESS. 1. AUDIO CHANNEL - Choose Audio Input Source (AV, TV). 2. BASS - Adjusts Bass 3. TREBLE - Adjusts Treble 4. EXIT - Back to Main Menu Display Access the Main Menu and highlight AUDIO then press and release the Menu button to select.
  • Page 22 CLOSE CAPTION The caption can display the spoken audio . 1. CAPTION - You can choose to show the caption or not. 2. DISPLAY : a. BOX - You can choose to box the caption. b. SHADOW - You can choose to show the caption in shadow (not boxed) format. 3.
  • Page 23 PARENTAL CONTROL With the Main Menu displayed, Press a nd r ele a se the button to highlight PARENTAL CONTROL : MAIN DISPLAY AUDIO CLOSE CAPTION PARENTAL CONTROL OSD SETUP TV SETUP BRIGHTNESS CONTRAST SATURATION SHARPNESS RECALL EXIT 640X H:31.4KHZ V:59.8HZ Input the four-digit PARENTAL CONTROL Password and confirm using the Menu button (Default Code is 3308)
  • Page 24 PARENTAL CONTROL (continued) The TV set also allows you to restrict access to potentially unsuitable content via auxiliary inputs. The following procedure will completely block off any content via the Svideo and AV inputs. From the PARENTAL CONTROL Main Menu. Press a n d r e le ase the button to highlight V-CHIP lock then Press and...
  • Page 25 PARENTAL CONTROL (continued) PARENTAL CONTROL RATINGS From the PARENTAL CONTROL Main Menu. Press a nd r ele a se the button to highlight MPAA OPTION and press menu : PG-13 NC-17 EXIT 640X H:31.4KHZ V:59.8HZ Select the desired rating level and press Menu. Select EXIT to return to the main PARENTAL CONTROL menu.
  • Page 26 ON SCREEN DISPLAY(OSD) SETUP : With the Main Menu displayed, Press a nd Press and release the Menu button to rele as e t he button to highlight OSD select LANGUAGE, OSD COLOR or OSD SETUP TIMER MAIN DISPLAY LANGUAGE AUDIO OSD COLOR CLOSE CAPTION...
  • Page 27 With the MAIN MENU displayed, Select TV SETUP using the Menu button : MAIN DISPLAY AUDIO CLOSE CAPTION PARENTAL CONTROL OSD SETUP TV SETUP BRIGHTNESS CONTRAST SATURATION SHARPNESS RECALL EXIT 640X480 H:31.4KHZ V:59.8HZ Select TV SETUP and highlight ADD/ ERASE then Press and release the Menu button.
  • Page 28 With the MAIN MENU displayed, select MAIN DISPLAY BRIGHTNESS, CONTRAST, SATURATION, AUDIO CLOSE CAPTION HUE or SHARPNESS then Press and PARENTAL CONTROL release the Menu button to confirm. The OSD SETUP TV SETUP following screen(s) will be displayed (see BRIGHTNESS CONTRAST screens below) SATURATION...
  • Page 29 W ith th e M A IN M E N U displayed, S e lec t R E CA LL using the Menu button MAIN DISPLAY AUDIO CLOSE CAPTION PARENTAL CONTROL OSD SETUP TV SETUP BRIGHTNESS CONTRAST SATURATION SHARPNESS RECALL EXIT 640X480 H:31.4KHZ V:59.8HZ...
  • Page 30 EXIT Exits the on-screen-menu controls W it h th e M A IN M E N U displayed, select E X IT u s ing th e M EN U button to exit the M AI N ME N U MAIN DISPLAY AUDIO CLOSE CAPTION...

  • Page 31: Using The 15Mf050V/17 As A Computer Monitor

    U s i n g t h e 1 5 M F 0 5 0 V / 1 7 a s a C o m p u t e r M o n i t o r Pre s s the bu t to n t o h ig hlig h t S elect V G A and P ress and release MAI N DI SP L AY a n d P r e s s a nd r e lea s e...
  • Page 32 AUTO ADJUST Automatically optimizes the VGA signal for viewing. With the Main Menu displayed,use button to select AUTO ADJUST MAIN DISPLAY AUTO ADJUST CONTRAST BRIGHTNESS AUDIO COLOR QUALITY POSITION OSD SETUP RECALL SAVE EXIT EXIT 800X600 H:53.6KHZ V:84.8HZ Then Press and release the Menu button to display the following screen : AUTO ADJUST IN PROGRESS...
  • Page 33 With the Main Menu displayed, use the button to selcet COLOR. MAIN DISPLAY AUTO ADJUST CONTRAST BRIGHTNESS AUDIO COLOR QUALITY POSITION OSD SETUP RECALL SAVE EXIT EXIT 800X600 H:53.6KHZ V:84.8HZ Press and rele a se th e Menu b u tt o n to When USER is selected, Color can be manually display the COLOR Menu : adjusted by selecting the following displayed...
  • Page 34 ADVANCE TUNE W ith the Ma in Me n u d is pla y e d, u s e Then Press and release the Menu button to access the following screen. t he but to n t o s e le c t Q UA LI TY. ADVANCE TUNE MAIN DISPLAY...
  • Page 35 IMAGE POSITION W ith the Main Menu displayed, us e T hen Pr ess and releas e the Menu button to select P OSITI ON. button to ac c ess the following s c reen. IMAGE POS. MAIN DISPLAY OSD POS. AUTO ADJUST EXIT CONTRAST...
  • Page 36 POSITION 1. IMAGE POS. a. HORIZONTAL - Adjusts the horizontal size by increasing or decreasing this setting. b. VERTICAL - Adjusts the vertical size by increasing or decreasing this setting. c. CENTER - Automatic adjusting image to center. 2. OSD POS. You can choose where you would like the OSD control window to appear on your screen. Selecting OSD location allows you to manually adjust the position of the OSD control menu left, right, up or down.

  • Page 37: Reference

    Re fe r e n c e D i s p l a y M o d e s NOTE : Max resolution is 1024x768 Recommend vertical scan frequency is 60 Hz. LC D M o n i t o r D i s p l a y A n g l e Horizontal : Up 30 /Down 5...

  • Page 38: Troubleshooting

    Troubleshooting Before calling our serviceman, please refer to the following chart to see if you can adjust the problems yourself. Trouble Checks and Adjustments TV will not turn on Plug TV in. Plug something else into the outlet to make sure it is working. Make sure batteries in the remote are not dead.
  • Page 39 Troubleshooting Interference Please note the following common TV reception interferences: Ignition effect Black spots or vertical lines may appear. Screen jumps crazily or is very unstable. This is commonly the result of car ignition system interference, neon lights, or other forms of electrical interferences.
  • Page 40 Troubleshooting You may have problems that can be fixed with a few minor adjustments. Look for the type of problem you are having below and then apply the suggestions to get your TV going again. Picture with no sound Check if you have accidentally pressed the "mute" button Check other channels if the same problem exist.
  • Page 41 Troubleshooting Picture too dark Check your brightness level Check your contrast level In the on screen display (OSD) select RECALL Check your LCD monitor for possible damage Remote Control Failure Check TV main power source Check if remote control batteries are weak Check if batteries have been correctly installed Check if there are obstructions between your remote control and the main TV remote sensor...
  • Page 42 Note Customer Record: This Model number and serial number of this product can be found on its rear panel. You should note this serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identification in the event of theft or loss, and Warranty Service purpose.

  • Page 43: Specification

    Product Specifications: Monitor Display Specifications: 15" (Viewable) Screen Size 4:3 aspect Aspect Ratio 1024x768 Resolution 0.29mm x 0.29mm Pixel pitch 16.7 million true color display Total Display Colors Horizontal:150 Vertical:145 Viewing Angle (CR=5) 400:1 (typ) Contrast Ratio 250 cd/M (250 cd/ M typical) Panel Brightness (cd/ ¢T ) 30,000 hrs min Backlight Lamp Life...
