Kodak Ngenuity 9090DB Reference Manual

1
Activity #
Clean Feed Rollers (skimmer
rollers & separator roller)
Clean Transport
Clean Transport Rollers
Skimmer Tires and Separator
Roller Replacement
3
Clean Optics :
Clean Glass Flats
Clean Cameras' Glass Covers
Clean Transport Sensors
(entry & exit)
Clean Paper Present Sensor
1
A complete set of cleaning and replacement instructions can be found in the Maintenance section of the Ngenuity Operator Manual (S008769)
2
Cleaning Material used should be limited to those items/products included in the Ngenuity Cleaning Kits provided by BÖWE BELL + HOWELL
3
All components that are considered part of the scanner Optics should be cleaned at the same time. Caution: LEDs (lamps) are NOT considered part
of the scanner Optics and should NOT be cleaned or wiped using any type of solvent!
The instructions and descriptions contained in this Quick Reference Maintenance Guide were accurate at the time of publishing; howver, succeeding products and documents are
subject to change without notice. Therefore, BÖWE BELL + HOWELL Scanners, L.L.C. assumes no liability for damages directly or indirectly from errors, omissions, or discrepancies
between the product and this Quick Reference Maintenance Guide.
©2009 BÖWE BELL + HOWELL, All Rights Reserved.
Quick Reference Maintenance Guide
Frequency
10,000 pages / Daily
50,000 pages / Weekly
50,000 pages / Weekly
600,000 scans (250,000 NCR)
50,000 pages / Daily
50,000 pages / Daily
50,000 pages / Daily
50,000 pages / Daily
Symptoms
Skewed documents, excessive
multifeeds, feeder jams
Page frame errors, transport jams
Page frame errors, transport jams
Excessive multifeeds, feeder jams
Fuzzy images, streaks on images,
reduced OCR/ICR/bar code
recognition rates
Fuzzy images, streaks on images,
reduced OCR/ICR/bar code
recognition rates
Entry/exit errors
Feeder table won't lower when out of
paper
2
Cleaning Material
Cleaning wipes
Lint free cleaning cloth
Transport cleaning sheets
Replacement tires and rollers
Roller & Glass cleaner with Lint
free cloth (spray cleaner on cloth,
not in scanner)
Lint free swab
Blower brush
S008771 Rev A
